Philips BDT6531EM/06 leaflet

Philips
LCD Touch monitor

165 cm (65")

multimedia
Full HD

BDT6531EM

More audience interaction

with the multi-touch 165-cm (65") LCD Display

Deliver vital information or marketing messages to your audience in startling clarity. And
thanks to the interactive touch screen, you can also engage your customer much more
closely than ever before.

Operational flexibility

• Infrared Touch

• True multi-touch with 6 simultaneous touch points

• Software Independent

• Smart insert in the back cover to place a small PC

• Designed for 24/7 operation

• HDMI input

Optimised for public touch

• Full HD LCD display, 1920 x 1080p

• Slim bezel design for a stylish look

Lower total cost of ownership

• SmartPower for energy saving

Sustainable and safe

• Complies with RoHS standards of care for the environment

BDT6531EM/06

LCD Touch monitor

165 cm (65") multimedia, Full HD

Specifications

Picture/Display

• Diagonal screen size: 65 inch / 165.1 cm

• Aspect ratio: 16:9

• Brightness: 500 cd/m²

• Contrast ratio (typical): 2500:1

• Display colours: 16.7 million colours

• Panel resolution: 1920 x 1080p

• Pixel pitch: 0.63 x 0.63 mm

• Response time (typical): 8 ms

• Viewing angle: 178º (H)/178º (V)

Supported Display Resolution

• Computer formats
Resolution Refresh rate
1024 x 768 60 Hz
1280 x 1024 60 Hz
1280 x 768 60 Hz
1280 x 800 60 Hz
1360 x 768 60 Hz
1366 x 768 60 Hz
1440 x 900 60 Hz
1600 x 1200 60 Hz
1920 x 1080 60 Hz
1920 x 1200 60 Hz
640 x 480 60, 67, 72, 75 Hz
800 x 600 56, 60, 72, 75 Hz

deo formats

• Vi
Resolution Refresh rate
1080i 50, 60 Hz
480i 60 Hz
480p 60 Hz
576i 50 Hz
576p 50 Hz
720p 50, 60 Hz
1080p 50, 60 Hz

Accessories

• Included accessories: AC Power Cord, Batteries
for remote control, Owner's Manual, Remote
Control, User manual on CD-ROM, VGA cable,
Touch Driver on USB

• Optional accessories: Ceiling mount, Fixed wall

unt, Flexible wall mount, Electric Stand

mo
BMT1851/00, Software Omnitapps BMT1909/00,
Multi User Touch SW

Connectivity

• AV input: Composite (RCA) x 1, HDMI x 1, S­video x 1, Audio (L/R) x 1, Component RCA

• AV output: Audio (L/R) x 2

• Other connections: External loudspeaker

nnector

co

• PC: 3.5 mm PC audio input x 1, DVI-D x 1, RS232

9, RS232 D-sub9 output, VGA-in D-Sub

D-Sub

15HD, VGA-out D-Sub 15HD

• Touch Screen: USB

Convenience

• Energy-saving functions: Ambient light sensor,
Smart Power

• Keyboard control: Hidden, Lockable

• Network controllable: RS232

• Picture in picture: PBP, PIP, POP

• Picture performance: Advanced colour control

• Placement: Landscape

• Remote control signal: Lockable

• Safety control functions: Heat Control,

mperature Sensor

Te

• Screen-saving functions: Pixel Shift, Low Brightness

• Ease of installation: Carrying Handles

, Smart Insert

Dimensions

• Bezel thickness: 40.50 mm horizontal, 41.60 mm
vertical

• Packaging dimensions (WxHxD): 1630 x 1040 x

5 mm

29

• Product weight: 74 kg

• Smart Insert mount: 300 x 320 x 64 mm

• VESA Mount: 400 x 400 mm

• Set dimensions (W x H x D): 1525 x 891 x

0.50 mm

14

Miscellaneous

• Bezel: black, RAL 9005F13

• On-Screen Display Languages: En
German, Italian, Polish, Russian, Simplified Chinese,
Turkish

• Regulatory approvals: CCC, CE, FCC, Class B,

HS, UL/cUL

Ro

• Warranty: Europe 3 years

glish, French,

Operating conditions

• MTBF: 50,000 hour(s)

• Relative humidity: 10-90 %

• Temperature range (operation): 0 - 40 °C

Power

•Consumption (On mode): 358

• Mains power: 90-264 V AC/50-60 Hz

• Standby power consumption: <1 W

Packaging Data

• Tare weight: 9 kg

• Number of products included: 1

Interactivity

• Multi-touch technology: 6-mm safety glass, 6
Touch points simultaneously, Infrared touch, USB
connection

•

Highlights

Infrared Touch

With an invisible infrared grid on the top of the
screen, you can enjoy amazing accuracy and fast
response times, even when the screen is touched by
a finger, glove or stylus. And no "ghost points".

6 simultaneous touch points

Enjoy a more interactive experience with up to 6
touch points at the same time. Ideal for when you
have more than one user interacting with your
application simultaneously, the 6 touch points offer
an extremely cost-effective solution.

Smart insert

Professional PCs are part of most multi-user Touch
Screen installations. Quite often they add additional
depth to the public display and a lot of cable clutter.
This Multi-user Touch Screen contains a Smart insert
in the back cover that will fit many professional
compact PCs. In addition, it offers provisions for
efficient cable management.

Slim bezel

A slim bezel design adds a stylish look to a Touch
Screen to nicely blend in most environments.

Software Independent

Our touch screens are software independent and
work with most touch-screen software
commercially available, including Windows XP/7 and
Mac OS, Omnitapps – BMT1909/00. Connect via
USB to a PC or laptop.

Designed for 24/7 operation

Designed for 24/7 operation

HDMI input

HDMI makes an uncompressed digital RGB
connection from the source to the screen. By
eliminating conversion to an analogue signal, it
delivers an unblemished image. The non-degraded
signal reduces flicker and leads to a clearer picture.
HDMI intelligently communicates the highest output
resolution with the source device. The HDMI input
is fully backwards-compatible with DVI sources but
includes digital audio. HDMI uses HDCP copy
protection.

SmartPower

The backlight intensity can be controlled and pre-set
by the system to reduce the power consumption by
up to 50%, which saves substantially on energy costs.

Issue date 2019-05-09

Version: 1.0.1

12 NC: 8670 000 86539
EAN: 87 12581 63236 6

© 2019 Koninklijke Philips N.V.
All Rights reserved.

Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips N.V.
or their respective owners.

www.philips.com
