Philips BDT6531EM Specifications

Philips
LCD Touch monitor

• 165 cm (65")

•multimedia

• Full HD

BDT6531EM

More audience interaction

with the multi touch 165cm (65”) LCD Display

Deliver vital information or marketing messages to your audience in startling clarity. And
thanks to the interactive touch screen, you can also engage your customer much closer
than ever before.

Operational flexibility

• Infrared Touch

•6 Touch Points

• Software Independent

• Smart insert in the backcover to place a small pc

• Designed for 24/7 operation

• HDMI input

Optimized for public touch

• Full HD LCD display, 1920x1080p

• Slim bezel design for a stylish look

Lower total cost of ownership

• SmartPower for energy saving

Sustainable and safe

• Complies with RoHS standards to care for the environment

LCD Touch monitor

Slim Bezel

165 cm (65") multimedia, Full HD

BDT6531EM/06

Specifications

Picture/Display

• Diagonal screen size: 65 inch / 165.1 cm

• Aspect ratio: 16:9

• Brightness: 500 cd/m²

• Contrast ratio (typical): 2500:1

• Display colors: 16.7 million colors

• Panel resolution: 1920x1080p

• Pixel pitch: 0.63 x 0.63mm

• Response time (typical): 8 ms

• Viewing angle: 178º (H) / 178º (V)

Supported Display Resolution

• Computer formats
Resolution Refresh rate
1024 x 768 60Hz
1280 x 1024 60Hz
1280 x 768 60Hz
1280 x 800 60Hz
1360 x 768 60Hz
1366 x 768 60Hz
1440 x 900 60 Hz
1600 x 1200 60Hz
1920 x 1080 60Hz
1920 x 1200 60Hz
640 x 480 60, 67, 72, 75Hz
800 x 600 56, 60, 72, 75Hz

deo formats

• Vi
Resolution Refresh rate
1080i 50, 60Hz
480i 60Hz
480p 60Hz
576i 50Hz
576p 50Hz
720p 50, 60Hz
1080p 50, 60Hz

Accessories

• Included accessories: AC Power Cord, Batteries
for remote control, Quick Start Guide, Remote
Control, User manual on CD-ROM, VGA cable,
Touch Driver

• Optional accessories: Ceiling mount, Fixed wall

unt, Flexible wall mount, Electric Stand

mo
BMT1851/00, Software Omnitapps BMT1909/00,
Multi User Touch SW

Connectivity

• AV input: Composite (RCA) x1, HDMI x1, S-video
x1, Audio (L/R) x1, Component RCA

• AV output: Audio (L/R) x2

• Other connections: External loudspeaker

nnector

co

• PC: 3.5 mm PC audio input x1, DVI-D x1, RS232

9, RS232 D-sub9 output, VGA-in D-Sub

D-Sub

15HD, VGA-out D-Sub 15HD

• Touch Screen: USB

Convenience

• Energy saving functions: Ambient light sensor,
Smart Power

• Keyboard control: Hidden, Lockable

• Network controllable: RS232

• Picture in picture: PBP, PIP, POP

• Picture performance: Advanced color control

• Placement: Landscape

• Remote control signal: Lockable

• Safety control functions: Heat Control,

mperature Sensor

Te

• Screen saving functions: Pixel Shift, Low Brightness

• Ease of installation: Carrying Handles

, Smart Insert

Dimensions

• Bezel thickness: 40,50 mm horizontal, 41,60 mm
vertical

• Packaging dimensions (WxHxD): 1630 x 1040 x

5 mm

29

• Product weight: 74 kg

• Smart Insert mount: 300 x 320 x 64 mm

• VESA Mount: 400 x 400 mm

• Set dimensions (W x H x D): 1525 x 891 x 140,50
mm

Miscellaneous

• Bezel: black, RAL 9005F13

• On-Screen Display Languages: En
German, Italian, Polish, Russian, Simplified Chinese,
Turkish

• Regulatory approvals: CCC, CE, FCC, Class B,

HS, UL/cUL

Ro

• Warranty: Europe 3 years

glish, French,

Operating conditions

• MTBF: 50,000 hour(s)

• Relative humidity: 10 - 90 %

• Temperature range (operation): 0 - 40 °C

Power

•Consumption (On mode): 358

• Mains power: 90-264V AC/50-60 Hz

• Standby power consumption: <1W

Packaging Data

• Tare weight: 9 kg

• Number of products included: 1

Interactivity

• Multi-touch technology: 6 mm safety glass, 6 Touch
points simultaneously, Infrared touch, USB
connection

•

Highlights

Infrared Touch

With an invisible infrared grid on the top of the
screen, you can enjoy amazing accuracy and fast
response times, even when touched by a finger, glove
or stylus. And no “ghost points”.

6 Touch Points

Enjoy amazing functionality with 6 touch points on
this touch screen. More flexibility and optimum
performance couple with excellent operability
opportunities to give you the ultimate in user
interaction.

Smart insert

Professional PC’s are part of most multi-user Touch
Screen installations. Quite often they add additional
depth to the public display and a lot of cable clutter.
This Multi-user Touch Screen contains a Smart insert
in the backcover that will fit many professional
compact PC’s. In addition it offers provisions for
efficient cable management.

Slim bezel

A slim bezel design adds a stylish look to a Touch
Screen to nicely blend in most environments.

Software Independent

Our touch screens are software independent and
work with most touch screen software commercially
available, including Windows XP/7 and Mac OS,
Omnitapps – BMT1909/00. Connect via USB to a PC
or laptop.

Designed for 24/7 operation

Designed for 24/7 operation

HDMI input

HDMI makes an uncompressed digital RGB
connection from the source to the screen. By
eliminating conversion to an analog signal, it delivers
an unblemished image. The nondegraded signal
reduces flicker and leads to a clearer picture. HDMI
intelligently communicates the highest output
resolution with the source device. The HDMI input
is fully backward compatible with DVI sources but
includes digital audio. HDMI uses HDCP copy
protection.

SmartPower

The backlight intensity can be controlled and pre-set
by the system to reduce the power consumption by
up to 50%, which saves substantially on energy costs.

Issue date 2013-06-14

Version: 1.0.1

12 NC: 8670 000 86539
EAN: 87 12581 63236 6

© 2013 Koninklijke Philips N.V.
All Rights reserved.

Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips N.V.
or their respective owners.
