Philips
LCD Indoor Touch Totem
BDT4251TI
More audience interaction
with the multi-user touch Totem
Deliver vital information or marketing messages to your audience in startling clarity. And
thanks to the interactive touch screen, you can also engage your customer much more
closely than ever before.
Operational flexibility
• True multi-touch with 6 simultaneous touch points
• Infrared Touch
• Software Independent
Optimised for public touch
• Full HD LCD display, 1920 x 1080p
• Slim bezel design for a stylish look
Lower total cost of ownership
• SmartPower for energy saving
Sustainable and safe
• Temperature sensor measures the health condition
• Complies with RoHS standards of care for the environment
Page 2
BDT4251TI/06
LCD Indoor Touch Totem
Specifications
Picture/Display
• Diagonal screen size: 42 inch / 107 cm
• Panel resolution: 1920 x 1080p
• Optimum resolution: 1920 x 1080 @ 60 Hz
• Brightness: 700 cd/m²
• Contrast ratio (typical): 1100:1
• Response time (typical): 9 ms
• Aspect ratio: 16:9
• Viewing angle: 178º (H)/178º (V)
• Pixel pitch: 0.485 x 0.485
• Display colours: 1.06 Billion colours
• Picture enhancement: 3/2 - 2/2 motion pull down,
mbfilter, Motion compens. deinterlacing,
3D Co
Progressive scan, 3D MA deinterlacing, Dynamic
contrast enhancement
Supported Display Resolution
• Computer formats
Resolution Refresh rate
640 x 480 60, 67, 72, 75 Hz
800 x 600 56, 60, 72, 75 Hz
1280 x 768 60 Hz
1280 x 800 60 Hz
1280 x 1024 60 Hz
1360 x 768 60 Hz
1366 x 768 60 Hz
1600 x 1200 60 Hz
1920 x 1080 60 Hz
1920 x 1200 60 Hz
deo formats
• Vi
Resolution Refresh rate
480i 60 Hz
480p 60 Hz
576i 50 Hz
576p 50 Hz
720p 50, 60 Hz
1080i 50, 60 Hz
1080p 50, 60 Hz
Connectivity
• PC: VGA-in D-Sub 15HD, VGA-out D-Sub 15HD,
DVI-D x 1, RS232 D-Sub9, RS232 D-sub9 output,
3.5 mm PC audio input x 1
• AV input: Component (BNC) x 1, Component
(YPbPr) x 1,
Audio
• AV output: Composite (BNC) x 1, Audio (L/R) x 1
• Touch Screen: USB
• Other connections: AC-out, External loudspeaker
nnector
co
Composite (RCA) x 1, S-video x 1,
(L/R) x 2
• Keyboard control: Hidden, Lockable
• Remote control signal: Lockable
• Ease of installation: AC Out
• Energy-saving functions: Ambient light sensor,
Smart Pow
• Safety control functions: Heat Control,
Te
• Picture performance: Advanced colour control
• Network controllable: RS232
er
mperature Sensor
Dimensions
• Set dimensions (W x H x D): Totem: 598 x 2011 x
154 mm Plate: 598 x 8 x 450.6 mm
• Product weight: 120 kg
Operating conditions
• Temperature range (operation): 0 - 40 °C
• Relative humidity: 5 - 90 %
• MTBF: 50,000 hour(s)
Power
• Mains power: 90-264 VAC, 50/60 Hz
•Consumption (On mode
• Standby power consumption: < 1 W
): Typical 133 W
Sound
• Built-in speakers: 2 x 5 W (8 Ohm)
Accessories
• Included accessories: Remote Control, Batteries
for remote control, AC Power Cord, VGA cable,
User manual on CD-ROM, Owner's Manual,
Touch Driver on USB
• Optional accessories: Multi User Touch SW,
tware Omnitapps BMT1909/00
Sof
Miscellaneous
• Warranty: Europe 2 years
• On-Screen Display Languages: En
German, Italian, Polish, Turkish, Russian, Simplified
Chinese
• Regulatory approvals: CCC, CE, FCC, Class B,
HS, UL/cUL
Ro
• Totem: black, RAL 9005F13
glish, French,
Packaging Data
• Packaging dimensions (W x H x D):: 1200 x 2200 x
800 mm
• Tare weight: 80 kg
• Number of products included: 1
Convenience
• Placement: Portrait
• Picture in picture: PBP, PIP, POP
• Screen-saving functions: Pix
el shift, Low brightness
Issue date 2019-05-09
Version: 1.0.1
12 NC: 8670 000 86534
EAN: 87 12581 63231 1
Interactivity
• Multi-touch technology: 6 Touch points
simultaneously, Infrared touch, USB connection, 4mm safety glass
•
