Philips AZB798T/12 User Manual

Always there to help you

Question?

Contact

Philips

Register your product and get support at

www.philips.com/support

AZB798T

User manual

Contents

1 Important 2

Hearing safety 2

2 Your CD Soundmachine 3

Introduction 3
What's in the box 3
Overview of the main unit 4
Overview of the remote control 5

3 Get started 7

Prepare the remote control 7
Connect power 7
Turn on 8
Turn off 8

4 Play 9

Play CD 9
Play from USB devices 9
Play from Bluetooth-enabled devices 9
Play tape 10
Play from an external device 11

5 Play options 12

Control play 12
Program tracks 12
Adjust sound 12

8 Use system menus 16

Reset the product 16
Check the current software version 16

9 Other features 17

Set the sleep timer 17
Adjust the display brightness 17
Listen through the headphone 17

10 Product information 18

Specications 18

Supported MP3 disc formats 19
USB playability information 19
Maintenance 19

11 Troubleshooting 21

12 Notice 22

Compliance 22
Care of the environment 22
Trademark notice 22

6 Listen to FM radio 13

Tune to FM radio stations 13
Store radio stations automatically 13
Store radio stations manually 13
Select a preset radio station 13

7 Listen to DAB radio stations 14

Listen to DAB radio stations 14

For the rst time use 14

Program radio stations 14
Display DAB information 14
Use DAB menus 14

1EN

1 Important

Warning

• Never remove the casing of this apparatus.

• Never lubricate any part of this apparatus.

• Never look into the laser beam inside this apparatus.

• Never place this apparatus on other electrical

equipment.

• Keep this apparatus away from direct sunlight, naked

ames or heat.

• Ensure that you always have easy access to the power

cord, plug or adaptor to disconnect the apparatus from
the power.

• The device shall not exposed to dripping
or splashing.

• Do no place any source of danger on the

device (e.g. liquid lled objects. lit candles).

• Where the MAINS plug or an appliance
coupler is used as the disconnect device,
the disconnect device shall remain readily
operable.

• Make sure that there is enough free space
around the product for ventilation.

• Battery usage CAUTION – To prevent
battery leakage which may result in bodily
injury, property damage, or damage to the
unit:

• Install all batteries correctly, + and - as

marked on the unit.

• Batteries (packed or installed) shall not

be exposed to excessive heat such as

sunshine, re or the like.

• Remove batteries when the unit is not

used for a long time.

• Only use attachments/accessories specied
by the manufacturer.

Hearing safety

Caution

• To avoid hearing damage, limit the time you use the

headphones at high volume and set the volume to a
safe level. The louder the volume, the shorter is the safe
listening time.

Be sure to observe the following guidelines
when using your headphones.

• Listen at reasonable volumes for
reasonable periods of time.

• Be careful not to adjust the volume as your
hearing adapts.

• Do not turn up the volume so high that
you can't hear what's around you.

• You should use caution or temporarily
discontinue use in potentially hazardous
situations.

• Excessive sound pressure from earphones
and headphones can cause hearing loss.

Caution

• Use of controls or adjustments or performance of

procedures other than herein may result in hazardous
laser exposure or other unsafe operation.

Warning

• Never remove the casing of this apparatus.

• Never place this apparatus on other electrical

equipment.

• Never look into the laser beam inside this apparatus.

2 EN

2 Your CD

Soundmachine

Introduction

With this CD Soundmachine, you can:

• listen to FM radio;

• enjoy audio from tapes, USB device,
Bluetooth devices, and other external
audio devices;

• program the play sequence of tracks.

The unit offers you Dynamic Bass Boost (DBB)
and Digital Sound Control (DSC) to enrich

sound.

What's in the box

Check and identify the contents of the package:

• Main unit

• AC power cord

• Remote control (with battery)

• Short user manual

• Safety sheet

3EN

Overview of the main unit

a

c

d

e
f

g
h

i
j

k

o

r

q
p

n
m

l

b

a FM antenna

• Improve FM reception.

b

• Headphone socket.

c AUDIO-IN

• Connect an external audio device.

d

• Turn the unit on or off.

e Tape controls

•

Start tape play.

• /

Fast rewind or fast forward the tape.
Stop tape play or open the tape door.

•

Pause tape play.

f /MENU

• Stop play.

• Erase a program.

• Enter DAB+/FM menu.

g / TUNING +/-

• Skip to the previous or next track.

4 EN

• Tune to FM radio stations.

• Search within a track.

h ALBUM/PRESET -/+

• Select a preset radio station.

• Skip to the previous or next album.

i MODE/INFO

• Select a play mode: repeat or shufe.

• Display the play information.

j PROG

• Program tracks.

k SOURCE

• Select a source.

l

• USB socket.

m DSC

• Select a preset sound setting.

n DBB/PAIRING

• Turn dynamic bass boost on or off.

• In Bluetooth mode, press and hold to
enter pairing mode.

o VOL +/-

• Adjust volume.

p /OK

i

q
p

r

m

n

o

k

j

l

a

b

c

d

e

f

g

h

• Press to start or pause the play.

• Conrm the selection.

q Display panel

• Display current status.

r OPEN•CLOSE

• Open the disc compartment.

Overview of the remote control

a

• Turn the unit on or off.

b CD/TAPE

• Select the DISC source.

• Select the tape source.

c FM/DAB

• Select the FM source.

• Select the DAB source.

d /

• Skip to the previous/next track.

• Search within a track/disc/USB.

• Tune to a radio station.

• Adjust time.

e MODE

• Select the play mode.

f ALBUM/PRESET /

• Select a preset radio station.

• Skip to the previous/next album.

g INFO/RDS

• During playback, display the play
information.

• For selected FM radio stations, display

RDS information(if available).

h SLEEP

• Set sleep timer.

i DIM

• Adjust the display brightness.

j DBB

• Turn dynamic bass enhancement on/
off.

k

• Mute or restore volume.

l SOUND

• Enrich sound effect with Digital Sound

Control (DSC).

m +/-

• Adjust volume.

n PROG

• Program tracks.

• Program FM/DAB+ radio stations.

5EN

o /MENU

• Stop play or erase a program.

• Access FM/DAB+ menu.

p /OK

• Start, pause, or resume play.

• Conrm the selection.

q USB/AUDIO IN

• Press repeatedly to select the USB or
AUDIO IN source.

r /PAIRING

• Press to select the BT (Bluetooth)
source.

• Press and hold for 2 seconds to enter
pairing mode

6 EN

3 Get started

Caution

• Use of controls or adjustments or performance of

procedures other than herein may result in hazardous
laser exposure or other unsafe operation.

Always follow the instructions in this chapter in
sequence.
If you contact Philips, you will be asked for the
model and serial number of your apparatus. The
model number and serial number are on the
bottom of your apparatus. Write the numbers
here:
Model No. __________________________
Serial No. ___________________________

Prepare the remote control

Caution

• Risk of product damage! When the remote control is

not used for long periods, remove the batteries.

Option 1: AC power

Warning

• Risk of product damage! Make sure that the power

supply voltage corresponds to the voltage printed on
the back or the underside of the unit.

• Risk of electric shock! When you disconnect the AC

power, always pull the plug from the socket. Never pull
the cord.

Connect the AC power cord to:

• the AC~ MAINS socket on the unit.

• the wall socket.

Tip

• To save energy, turn the unit off after use.

To insert the remote control battery:

1 Open the battery compartment.
2 Insert the supplied AAA battery with

correct polarity (+/-) as indicated.

3 Close the battery compartment.

Connect power

The unit can be powered by either AC power
or batteries.

Option 2: Battery power

Caution

• Batteries contain chemical substances, so they should

be disposed of properly.

Note

• Batteries are not supplied with the accessories.

1 Open the battery compartment.
2 Insert 6 batteries (type: R-14, UM-2 or

C-cells) with correct polarity (+/-) as

indicated.

7EN

3 Close the battery compartment.

Turn on

Press .

» The unit switches to the last selected

source.

Tip

• To select a source, press SOURCE repeatedly or the

source selection buttons on the remote control.

Turn off

Press again.

» The backlight on the display panel

turns off.

8 EN

4 Play

Play CD

1 Press CD to select the disc source.
2 Press OPEN•CLOSE to open the disc tray.
3 Insert a disc with the printed side facing up,

then close the disc tray.

» Play starts automatically.

Play from USB devices

Note

• Make sure that the USB device contains playable audio

content.

1 Press USB to select USB source.
2 Insert the USB device into the socket.

» Play starts automatically. If not, press

.

Play from Bluetooth-enabled devices

With this product, you can listen to audio from
Bluetooth-enabled devices.

Note

• WOOX Innovations does not guarantee the

compatibility with all Bluetooth devices.

• Before pairing a device with this product, read its user

manual for Bluetooth compatibility. Make sure that the
connected Bluetooth device supports the Advanced

Audio Distribution Prole (A2DP) and the Audio Video
Remote Control Prole (AVRCP).

• The product can connect a maximum of 8 Bluetooth

devices simultaneously.

• Make sure that Bluetooth function is enabled on your

device, and your device is set as visible to all other
Bluetooth devices.

• The operational range between this product and a

Bluetooth device is approximately 10 meters (33 feet).

• Any obstacle between this product and a Bluetooth

device can reduce the operational range.

• Keep away from any other electronic device that may

cause interference.

Note

• The maximum current for USB is 0.5A.

1 Press BT to select Bluetooth source.

» [BLUETOOTH](Bluetooth) is

displayed.

» The CD sound machine enters pairing

mode, and [PAIRING] (Pairing) is
displayed on the screen.

9EN

2 On your Bluetooth device, enable

Bluetooth and search for Bluetooth devices

(refer to the user manual of the device).

3 Select [Philips AZB798T] on your device

for pairing. If necessary, enter default
password “0000”.

» After successful pairing and

connection, the product beeps twice,
and [CONNECTED] (connected ) is
displayed on the screen.

Note

• If you cannot nd [Philips AZB798] on your device,

pressDBB/PAIRING on the main unit or //PAIRING
on remote control for 2 seconds to enter pairing
mode,[PAIRING] (Pairing) is display on the screen.

Disconnect the Bluetooth-enabled device

• Press and hold PAIRING for 2 seconds;

• Disable Bluetooth on your device; or

• Move the device beyond the
communication range.

Connect another Bluetooth-enabled device

Disable Bluetooth on the current device, and
then connect another device.

Clear Bluetooth pairing history

Press and hold for 7 seconds to clear the
Bluetooth pairing history.

Philips AZB798T

4 After successful Bluetooth connection, play

audio on the Bluetooth device.

» Audio streams from your Bluetooth

device to the product.

• To skip to previous/next track, press
/ .

• To pause or resume the playback, press

.

10 EN

Play tape

Note

• The CD sound machine will turns off automatically

after an elapsed time of inactivity at tape mode.

1 Press CD/TAPE repeatedly to select TAPE

source.

2 Press / on the CD sound machine to

open the tape door.

3 Load the tape with the open side upward

and the full spool to the right.

4 Press on the CD sound machine to start

play.

• To pause/resume play, press on main
unit .

• To rewind or fast-forward, press /
on CD sound machine .

• To stop play, press .

» The CD sound machine turns off

automatically.

Note

• In playback mode, cassette will be stopped

automatically when playback reaches the end.

• There is no display on the LCD screen in tape mode.

Play from an external device

You can also listen to an external audio device
such as an MP3 player through this product.

1 Press TUNER/AUDIO IN repeatedly to

select [AUDIO-IN] source.

2 Connect an audio cable (3.5mm, not

supplied) to:

• the AUDIO-IN socket on the unit.

• the headphone socket on an external

device.

3 Play the external device (see the device's

user manual).

11EN

5 Play options

Control play

In CD or USB mode, you can control play
through the following operations.

/ Press and hold to fast-forward

or fast-reverse the track during
playback, then release to resume play.

/ Skip to the previous or next MP3

album.

/ Skip to the previous or next track.

Start or pause play.
Stop play.

MODE [ ]: Play the current track

repeatedly.
[ ]: Play all tracks repeatedly.
[ ]: Play tracks randomly.

Tip

• Only [ ] and [ ] can be selected when you

play the programmed tracks.

6 Press to play the programmed tracks.

» During play, [PROG] (program) is

displayed.

• To erase the program, press twice.

• To review the program, when playback
is stopped, press and hold PROG for
2 seconds.

Adjust sound

During play, you can adjust volume and select
the sound effects.

Key Function
VOL +/- Increase or decrease volume.

Mute or resume sound.

DBB Turn dynamic bass enhancement

on or off.

SOUND Select a preset sound effect:

POWERFUL (powerful);
BALANCE(balance);
WARM(warm); BRIGHT(bright),
and CLEAR(clear),

Program tracks

In CD or USB mode, you can program a
maximum of 20 tracks.

1 Press to stop playback.
2 Press PROG to activate the program

mode.

» [PROG] (program) begin to blink.

3 For MP3 tracks, press ALBUM/PRESET +/-

to select an album.

4 Press / to select a track number, then

press PROG to conrm.

5 Repeat steps 3-4 to program more tracks.

12 EN

6 Listen to FM

Store radio stations manually

radio

Tune to FM radio stations

Note

• For optimal reception, fully extend and adjust the

position of the FM antenna.

1 Press FM/DAB repeatedly to select FM

radio source.

2 Press and hold / for 2 seconds.

» [SEARCH] (search) is displayed.
» The product tunes to a station with

strong reception automatically.

3 Repeat step 2 to tune to more stations.

To tune to a radio station with weak signal:

Press / repeatedly until you nd better
reception.

Store radio stations automatically

Note

• You can program a maximum of 20 FM radio stations.

Note

• You can program a maximum of 20 FM radio stations.

1 Tune to an FM radio station.
2 Press PROG to activate the storing mode.
3 Press to allocate a number (1 to 20)

to this radio station, then press PROG to

conrm.

» The preset number and the frequency

of the preset station are displayed.

4 Repeat the above steps to store other

stations.

Note

• To remove a pre-stored FM radio station, store another

station in its place.

Select a preset radio station

In FM tuner mode, press to select a preset
number.

In tuner mode, press and hold PROG for 2
seconds.

» [AUTO STORE] (auto store) is

displayed.

» The unit stores all the available FM

radio stations.

» The rst stored radio station is

broadcast automatically.

13EN

7 Listen to DAB

5 Repeat steps 1-4 to program more radio

stations.

radio stations

Listen to DAB radio stations

Note

• For optimal reception, fully extend the antenna and

adjust its position.

• You can program a maximum of 20 DAB radio stations.

• Check with local retailer or go to www.WorldDAB.org

for applicable DAB radio frequencies in your area.

For the rst time use

1 Press FM/DAB to select the DAB source.

» [Full scan] menu is displayed.

2 Press OK to activate the automatic search.

» This product automatically stores radio

stations with sufcient signal strength.

» After the search is complete, the

rst stored radio station is broadcast

automatically.

3 Press / to select a station, and then

start listening.

Program radio stations

1 Tune to a DAB radio station.
2 Press PROG to activate the programming.
3 Press to select a preset sequence

number.

4 Press PROG to conrm.

» The radio station is stored with the

selected sequence number.

Note

• If you store a radio station with the sequence number

of another one, the earlier one is overwritten.

Display DAB information

On the display of DAB broadcasting, the rst

line shows station name, and the second line
shows the service information for the current
station.
Press DISPLAY repeatedly to cycle through the

following information (if available).

• Dynamic label segment (DLS)

• Signal strength

• Program type (PTY)

• Ensemble name

• Frequency

• Signal error rate

• Bitrate codec

• Time

• Date

Use DAB menus

1 In DAB mode, press MENU to access the

DAB menus.

2 Press / to toggle through the

menus.

• [FULL SCAN]:Scan for the DAB
stations.

• [MANUAL]: Tune to a station manually.

• [PRUNE]: Remove invalid stations

• [SYSTEM]: Access system setting menu.

3 Press OK to enter the menu.

14 EN

Re-scan for stations

Full scan is used to perform a wide range
search for DAB radio stations.

• Press OK to activate the automatic search.

» This product automatically stores radio

stations with sufcient signal strength.

Tune to a station manually

With this feature, you can tune to a specic

channel/frequency manually. In addition to
antenna orientation for better radio reception,
the optimal reception can also be obtained with
this feature.

1 Press OK to access the station list.
2 Press / to select a station.
3 Press OK to conrm the option.

Remove invalid stations

This option lists active stations and removes any
stations that are in the list but have no service
in your area.

1 Press OK to access the [PRUNE] menu.
2 Press / to select an option.

• [N]: Return to the previous menu.

• [Y]: Remove invalid stations from the
station list.

3 Press OK to conrm the selection.

System menus

1 Press OK to access system menu.
2 Press / to to select a sub-menus.

• For details, refer to the section 'Use
system menus'.

15EN

8 Use system

menus

With the system menus, you can:

• [RESET]: Reset the product to factory
default status.

• [UPGRADE]: Upgrade the software.

• [SW VER]: Check the version of current
software of this product.

Reset the product

1 Press OK to display the options.
2 Press / to select an option.

• [N]: Return to the previous menu.

• [Y]: Reset the product to factory

default status.

3 Press OK to conrm the option.

Check the current software version

Press OK to display the version of current
software.

16 EN

9 Other features

Set the sleep timer

This unit can switch to standby automatically
after a preset period.
When the unit is turned on, press SLEEP
repeatedly to select the sleep timer period (in

minutes).

» When the sleep timer is activated,

appears.

To deactivate sleep timer:

• Press SLEEP repeatedly until [SLEEP OFF]

(sleep off) is displayed.

» When sleep timer is deactivated,

disappears.

Adjust the display brightness

Press DIM repeatedly to select different
brightness levels.

Listen through the headphone

Plug a headphone into the socket on the unit.

17EN

10 Product

information

Note

• Product information is subject to change without prior

notice.

Specications

Tuner

Tuning Range FM: 87.5 - 108MHz

DAB: 174.928 -

239.200 MHz
Tuning grid 50 kHz
Preset stations 20
Sensitivity:

-Mono, 26dB S/N Ratio

-Stereo, 46dB S/N Ratio
Search Selectivity <28dBf
Total Harmonic

Distortion
Signal to Noise Ratio >55 dB

<22 dBf
<43 dBf

<2%

Amplier

Max Output Power 2 x 4 W
Frequency Response 63 -20 KHz, +/-3dB
Signal to Noise Ratio >72 dBA
Total Harmonic

Distortion
Audio-in Input 650 mV RMS

<1 %

22kohm

Disc

Laser Type Semiconductor
Disc Diameter 12cm/8cm
Support Disc CD-DA, CD-R, CD-

RW, MP3-CD
Audio DAC 24Bits / 44.1kHz
Total Harmonic

Distortion
Frequency Response 63 -20 KHz, +/-3dB
S/N Ratio >72 dBA

<1%

Tape deck

Frequency response

- Normal tape (type I)

Signal-to-noise ratio

- Normal tape (type I)
Wow and utter ≤ 0.4% DIN

125 - 8000 Hz

(8 dB)

35 dBA

Bluetooth

Bluetooth Version V3.0 + EDR

Range 10 m (Free space)
Bluetooth Frequency

Band

2.402 GHz ~

2.48GHz

General

Power supply

- AC Power

- Battery
Operation Power

Consumption
Standby Power

Consumption
Dimensions

- Main Unit

(W x H x D)
Weight (Main Unit) 2.96 kg

220-240V~, 50/60 Hz;
DC 9 V, 6 x 1.5 V/R20

/D CELL
15 W

< 0.5 W

435 x 170 x 271 mm

18 EN

Supported MP3 disc formats

• ISO9660, Joliet

• Maximum title number: 512 (depending on

le name length)

• Maximum album number: 255

• Supported sampling frequencies: 32 kHz,

44.1kHz, 48 kHz

• Supported Bit-rates: 32~256 (kbps),

variable bit rates

USB playability information

Compatible USB devices:

• USB ash memory (USB 2.0 or
USB1.1)

• USB ash players (USB 2.0 or USB1.1)

• memory cards (requires an additional
card reader to work with this

apparatus)

Supported formats:

• USB or memory le format FAT12,
FAT16, FAT32 (sector size: 512 bytes)

• MP3 bit rate (data rate): 32-320 Kbps
and variable bit rate

• Directory nesting up to a maximum of
8 levels

• Number of albums/ folders: maximum
99

• Number of tracks/titles: maximum 999

• ID3 tag v2.0 or later

• File name in Unicode UTF8 (maximum

length: 128 bytes)

Unsupported formats:

• Empty albums: an empty album is an
album that does not contain MP3/

WMA les, and is not be shown in the

display.

• Unsupported le formats are skipped.

For example, Word documents (.doc)
or MP3 les with extension .dlf are

ignored and not played.

• WMA, AAC, WAV, PCM audio les

• DRM protected WMA les (.wav, .m4a,

.m4p, .mp4, .aac)

• WMA les in Lossless format

Maintenance

Clean the cabinet

• Use a soft cloth slightly moistened with
a mild detergent solution. Do not use a
solution containing alcohol, spirits, ammonia
or abrasives.

Clean discs

• When a disc becomes dirty, clean it with
a cleaning cloth. Wipe the disc from the
centre out.

• Do not use solvents such as benzene,
thinner, commercially available cleaners,
or antistatic spray intended for analogue
records.

Clean the disc lens

• After prolonged use, dirt or dust may
accumulate at the disc lens. To ensure good
play quality, clean the disc lens with Philips
CD lens cleaner or any commercially
available cleaner. Follow the instructions
supplied with cleaner.

Clean the heads and the tape paths

• To ensure good recording and play quality,
clean the heads A, the capstan(s) B, and
pressure roller(s) C after every 50 hours
of tape operation.

• Use a cotton swab slightly moistened with

cleaning uid or alcohol.

19EN

• You can also clean the heads by playing a
cleaning tape once.

Demagnetise the heads

• Use a demagnetising tape available at your
dealer.

20 EN

11 Troubleshooting

Warning

• Never remove the casing of this device.

To keep the warranty valid, never try to repair
the system yourself.
If you encounter problems when using this
device, check the following points before
requesting service. If the problem remains
unsolved, go to the Philips Web page (www.

philips.com/support). When you contact Philips,

make sure that the device is nearby and the
model number and serial number are available.

No power

• Ensure that the AC power plug of the unit
is connected properly.

• Ensure that there is power at the AC
outlet.

• Inser t the batteries with their polarities

(+/– signs) aligned as indicated.

• Replace the batter y.

No sound or poor sound

• Adjust the volume.

No response from the unit

• Disconnect and reconnect the AC power
plug, then turn on the system again.

• As a power-saving feature, the unit
switches off automatically 15 minutes after
track play reaches the end and no control
is operated.

Remote control does not work

• Before you press any function button, rst
select the correct source with the remote
control instead of the main unit.

• Reduce the distance between the remote
control and the unit.

• Inser t the battery with its polarities (+/–

signs) aligned as indicated.

• Replace the batter y.

• Aim the remote control directly at the
sensor on the front of the unit.

USB device not supported

• The USB device is incompatible with the
apparatus. Try another one.

No disc detected

• Inser t a disc.

• Check if the disc is inser ted upside down.

• Wait until the moisture condensation at
the lens has cleared.

• Replace or clean the disc.

• Use a nalized CD or correct format disc.

Poor radio reception

• Increase the distance between the unit and

your TV or VCR.

• Fully extend the FM antenna.

Music playback is unavailable on this unit even
after successful Bluetooth connection.

• The device cannot be used to play music
through this unit wirelessly.

The audio quality is poor after connection
with a Bluetooth-enabled device.

• The Bluetooth reception is poor. Move the
device closer to this unit or remove any
obstacle between them.

Bluetooth cannot be connected with this unit.

• The device does not suppor t the proles
required for this unit.

• The Bluetooth function of the device is
not enabled. Refer to the user manual of

the device to nd out how to enable the

function.

• This unit is not in pairing mode.

• This unit is already connected with another
Bluetooth-enabled device. Disconnect that
device and then try again.

The paired mobile device connects and
disconnects constantly.

• The Bluetooth reception is poor. Move the
device closer to this unit or remove any
obstacle between them.

• Some mobile phones may connect and
disconnect constantly when you make
or end calls. This does not indicate any
malfunction of this unit.

• For some devices, the Bluetooth
connection may be deactivated
automatically as a power-saving feature.
This does not indicate any malfunction of
this unit.

21EN

12 Notice

Any changes or modications made to this

device that are not expressly approved by
Gibson Innovations may void the user’s
authority to operate the equipment.

Compliance

Declaration of conformity

Hereby, Gibson Innovations declares that this
product is in compliance with the essential
requirements and other relevant provisions

of Directive 1999/5/EC. You can nd the

Declaration of Conformity on www.philips.com/
support.

Care of the environment

Disposal of your old product and battery

This symbol means that the product contains
batteries covered by European Directive
2013/56/EU which cannot be disposed of with
normal household waste.
Inform yourself about the local separate
collection system for electrical and electronic
products and batteries. Follow local rules and
never dispose of the product and batteries
with normal household waste. Correct disposal
of old products and batteries helps prevent
negative consequences for the environment and
human health.

Removing the disposable batteries

To remove the disposable batteries, see battery
installation section.

Environmental information

All unnecessary packaging has been omitted.
We have tried to make the packaging easy to

separate into three materials: cardboard (box),
polystyrene foam (buffer) and polyethylene
(bags, protective foam sheet.)

Your system consists of materials which can
be recycled and reused if disassembled by
a specialized company. Please observe the
local regulations regarding the disposal of
packaging materials, exhausted batteries and old
equipment.

Your product is designed and manufactured
with high quality materials and components,
which can be recycled and reused.

This symbol on a product means that the
product is covered by European Directive
2012/19/EU.

22 EN

Trademark notice

The making of unauthorized copies of copy­protected material, including computer

programs, les, broadcasts and sound

recordings, may be an infringement of
copyrights and constitute a criminal offence.
This equipment should not be used for such
purposes.

The Bluetooth® word mark and logos are
registered trademarks owned by Bluetooth
SIG, Inc. and any use of such marks by Gibson
Innovations Limited is under license. Other
trademarks and trade names are those of their
respective owners.

This apparatus includes these labels:

Class II equipment symbol

This symbol indicates that the apparatus has a
double insulation system.

The USB-IF Logos are trademarks of Universal
Serial Bus Implementers Forum, Inc.

Note

• The type plate is located on the bottom of the

apparatus.

23EN

2015 © Gibson Innovations Limited. All rights reserved.
This product has been manufactured by, and is sold
under the responsibility of Gibson Innovations Ltd., and
Gibson Innovations Ltd. is the warrantor in relation to
this product.
Philips and the Philips Shield Emblem are registered
trademarks of Koninklijke Philips N.V
license from Koninklijke Philips N.V.

AZB798T_12_UM_V1.0

. and are used under
