Page 1
Philips
CD Soundmachine with
Dynamic Bass Boost
MP3
AZ5130
Your Portable Theatre
Video CD Sound Machine with stereo sound through 2 big speakers. Power-packed
sound machine with great stereo sound from VCD, MP3-CD, CD, cassette or radio.
Feature-packed VCD and CD player
• VCD2.0 playback
• MP3-CD,CD-R/RW compatible
Rich and clear sound
• Dynamic Bass Boost for deep and dramatic sound
• Bass Reflex Speaker System delivers a powerful, deeper bass
• 10.2 cm (4") full range speakers for powerful sound
Easy to use
• CD to tape synchro-start recording
• Multi-functional LCD display
• On Screen Display for easy navigation
• 9 frames digest preview for easy navigation
Page 2
CD Soundmachine with Dynamic Bass Boost
MP3
AZ5130/13
Specifications
Sound
• Loudspeaker types: Bass Reflex Speaker System
• Output power (RMS): 2X1.5W
• Sound System: Stereo
• Speaker diameter: 4"
• Volume Control: rotary
Loudspeakers
• Built-in speakers: 2
• Finishing: Metal
• Loudspeaker types: Loudspeakers
Video Playback
• Playback Media: Video CD/SVCD
• Disc Playback Modes: A-B Repeat, Fast Backward,
Fast Forward, Introscan, OSD, Pau
Motion, Zoom
Audio Playback
• Cassette Deck Technology: Mechanical
• Playback Media: CD, CD-R, CD-RW, MP3-CD
• Disc Playback Modes: Fas
Next/Previous Track Search, Repeat Play, Shuffle
Play
•Loader Type: Top
•Number of decks: 1
• Programmable Tracks: 20
t Forward/Backward,
Audio Recording
• Recording Media: Tape
• Tape Recording Enhancement: CD Synchro Start
ording
Rec
se, PBC, Slow
Tuner/Reception/Transmission
• Antenna: AM Antenna, FM Antenna
• Auto digital tuning: No
•Tuner Bands: FM, MW
Connectivity
• Audio output: Stereo Audio (3.5 mm jack) 1x
• Video Output - Analog: Video (3.5mm jack) 1x
Convenience
• Display Digits: 3
• Display Type: LCD
Accessories
• Included accessories: AC Power Cord, Audio/
Video cable, User Manual, Warranty certificate
• Remote control: 33 keys
Dimensions
• Packaging dimensions (W x H x D):
470 x 211 x 260 mm
• Product dimensions (W x H x D):
0 x 173 x 240 mm
40
•Weight: 3.5 kg
• Weight incl. Packaging: 4.2 kg
Power
• Battery type: LR14, UM2
• Battery voltage: 1.5 V
• Mains power
• Number of batteries: 6
•
Highlights
VCD2.0 playback
VCD2.0 playback
MP3-CD,CD-R/RW compatible
MP3-CD,CD-R/RW compatible
Dynamic Bass Boost
Dynamic Bass Boost maximizes your music
enjoyment by emphasizing the bass content of the
music throughout the range of volume settings from low to high – at the touch of a button! Bottomend bass frequencies usually get lost when the
volume is set at a low level. To counteract this,
Dynamic Bass Boost can be switched on to boost
bass levels, so you can enjoy consistent sound even
when you turn down the volume.
Bass Reflex Speaker System
Bass Reflex Speaker System delivers a deep bass
experience from a compact loudspeaker box system.
It differs from a conventional loudspeaker box
system in the addition of a bass pipe that is
acoustically aligned to the woofer to optimize the
low frequency roll-off of the system. The result is
deeper controlled bass and lower distortion. The
system works by resonating the air mass in the bass
pipe to vibrate like a conventional woofer.
Combined with the response of the woofer, the
system extends the overall low frequency sounds to
create a whole new dimension of deep bass.
10.2 cm/4" full range speakers
10.2 cm (4") full range speakers for powerful sound
CD synchro-start recording
CD to tape synchro-start recording
Multi-functional LCD display
Multi-functional LCD display
On Screen Display
On Screen Display for easy navigation
9 frames digest preview
9 frames digest preview for easy navigation
Issue date 2014-02-10
Version: 2.0.3
12 NC: 9073 101 00816
EAN: 87 10895 78263 0
© 2014 Koninklijke Philips N.V.
All Rights reserved.
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips N.V.
or their respective owners.
