Philips AZ1515/05, AZ1515 Specifications

Page 1

Philips CD Soundmachine with Dynamic Bass Boost

AZ1515

Direct track and station selection

You seek control of your music with ease and precision! The portable AZ1505’s digital tuning with 40 presets let’s you savor your favorite music, easily and quickly.

Easy to use and precise control

• Easy Access Keyboard for selecting tracks or radio stations

• Digital tuning with presets

• Stereo headphone socket

• Handy remote control

Impressive sound

• Dynamic Bass Boost for deep and dramatic sound

• Bass Reflex speakers deliver a powerful, deeper bass

Everything you need

• Compatible with CD-Recordable and CD-ReWritable

• CD shuffle/program/repeat

Page 2

CD Soundmachine with Dynamic Bass Boost

AZ1515/05

Specifications Product highlights

Sound

• Loudspeaker types: Bass Reflex Speaker System

• Output power (RMS): 2X1W

• Sound System: Stereo

• Speaker diameter: 4"

• Sound Enhancement: Dynamic Bass Boost

• Volume Control: Volume Control up/down

Loudspeakers

• Built-in speakers: 2

• Finishing: Metal

• Loudspeaker types: Loudspeakers

Audio Playback

• Disc Playback Modes: Next/Previous Track Search, Fast Forward/Backward, Shuffle Play, Repeat Play

• Playback Media: CD, CD-R, CD-RW

• Loader Type: Top

• Programmable Tracks: 20

Tuner/Reception/Transmission

• Antenna: AM Antenna, FM Antenna

• Auto digital tuning

• Tuner Bands: FM, MW

Convenience

• Display Type: LCD

• Display Digits: 4

• Remote control: remote control

Connectivity

• Headphone: 3.5 mm

Accessories

• Included Accessories: AC Power Cord, User Manual, Warranty certificate

• Remote control: 14 keys

Dimensions

• Packaging dimensions (W x H x D): 475

x 211 x 260 mm

• Product dimensions (W x H x D): 405

x 162 x 232 mm

• Weight: 3.2 kg

• Weight incl. Packaging: 3.9 kg

Power

• Battery voltage: 1.5 V

•Mains power

• Number of batteries: 6

• Battery type: LR14

•

Easy Access Keyboard

The Easy Access Keyboard features a phone-style numerical keypad that is a simple and handy tool for selecting CD tracks, radio presets or tuning in to radio stations. Located conveniently at the front of the set, the ten numerical keys make selection and programming a simple one-touch operation. To select a specific track or choose a tuner preset, simply key in the track number or preset number using the keypad. Tune in to your favorite radio station by simply keying in the frequency. Easy Access Keyboard helps you select a specific track, tuner preset or your favorite radio station.

Digital tuning with presets

Stereo headphone socket

Handy remote control

Dynamic Bass Boost

Dynamic Bass Boost maximizes your music enjoyment by emphasizing the bass content of the music throughout the range of volume settings - from low to high – at the touch of a button! Bottom-end bass frequencies usually get lost when the volume is set at a low level. To counteract this, Dynamic Bass Boost can be switched on to boost bass levels, so you can enjoy consistent sound even when you turn down the volume.

Bass Reflex Speaker System

Bass Reflex Speaker System delivers a deep bass experience from a compact loudspeaker box system. It diff ers fr om a c on ven tio nal lou dsp eak er b ox sys tem in t he addition of a bass pipe that is acoustically aligned to the woofer to optimize the low frequency roll-off of the system. The result is deeper controlled bass and lower distortion. The system works by resonating the air mass in the bass pipe to vibrate like a conventional woofer. Combined with the response of the woofer, the system extends the overall low frequency sounds to create a whole new dimension of deep bass.

CD-R/RW Compatible

CD-Rewritable Compatible means that your audio set can play both CD-Recordable (CD-R) and CD-Rewritable (CD-RW) discs. CD-R discs are recordable once and can be pl ayed on any audio CD player while CD-R W d isc s ca n be recorded and rewritten multip le times and can onl y be played back on compatible audio CD players. The laser pick-up and CD decoder circuitry of CD-RW compatible players are specially designed to read the special audio CD-RW phase-change recording layer, ensuring you can always play your home-recorded discs on your audio CD system.

CD shuffle/program/repeat

Issue date 2009-02-12

Version: 1.0.2

12 NC: 9073 101 00656 EAN: 87 10895 76119 2

Specifications are subject to change without notice. Trademarks are the property of Koninklijke Philips Electronics N.V. or their respective owners.
