Philips AZ1510 User Manual

ACCESSORIES

TOP AND FRONT PANEL (See 1)

1 VOLUME 3 , 4 - to adjust volume level.
2 DBB (Dynamic Bass Boost) - activates a more vivid

3 POWER slider - selects TAPE/ RADIO / CD

4 BAND - selects waveband.
5 0-9: - digit panel

6 PROGRAM

7 SEARCH ∞ , §

8 MODE - selects different play modes: e.g. REPEAT

9 2; - starts or pauses CD playback.
0 9 - to stop playback;

! Display - shows the status of the set.
@ OPEN•CLOSE – opens/ closes the CD-tape door
# REMOTE SENSOR - (for AZ1515 model only)

$ CASSETTE RECORDER keys:

English CONTROL/POWER SUPPLY POWER SUPPLY DIGITAL TUNER

CD Soundmachine

Remote Control for
AZ1515 model only

AZ1510
AZ1515

Audio

Audio

A AB

C

X

DBB

MW

FM

PROG

DBB

PROG

SHUFFLE

PROG

VOLUME

SEARCH

PRESET

TUNING

REPEAT

SHUFFLE

SEARCH

+

-

4

0

PRES

E

T

DIGITALTUNER

1

9

8

6

7

2

4

3

5

&

%

^

*

2134

9!@#$ 0

65 7

8

1

Remote Control for
AZ1515 model only

A AB

C

X

DBB

2

MW

FM

PROG

DBB

PROG

SHUFFLE

PROG

3

4

5

8

6

7

9

Important notes for users in the U.K.

Mains plug

This apparatus is fitted with an approved 13 Amp plug. To change a fuse in this type of plug
proceed as follows:

1.Remove fuse cover and fuse.

2.Fix new fuse which should be a BS1362 5 Amp,A.S.T.A.or BSI approved type.

3.Refit the fuse cover.

If the fitted plug is not suitable for your socket outlets, it should be cut off and an appro­priate plug fitted in its place. If the mains plug contains a fuse, this should have a value of
5 Amp. If a plug without a fuse is used, the fuse at the distribution board should not be
greater than 5 Amp.

Note: The severed plug must be disposed of to avoid a possible shock hazard should it
be inser ted into a 13 Amp socket elsewhere.

How to connect a plug

The wires in the mains lead are coloured with the following code:blue = neutral (N),
brown = live (L).As these colour s may not correspond with the colour markings iden­tifying the terminals in your plug, proceed as follows:

• Connect the blue wire to the terminal mar ked N or coloured black.

• Connect the brown wire to the terminal mar ked L or coloured red.

• Do not connect either wire to the earth terminal in the plug, marked E (or e) or
coloured green (or green and yellow).

Before replacing the plug cover,make cer tain that the cord gr ip is clamped over the
sheath of the lead - not simply over the two wires.

Copyright in the U.K.

Recording and playback of material may require consent. See Copyright Act 1956 and
The Performer’s Protection Acts 1958 to 1972.

English CONTROL/POWER SUPPLY POWER SUPPLY DIGITAL TUNER

ACCESSORIES

1 x AC mains lead
1 x Remote Control (for AZ1515 model only)

TOP AND FRONT PANEL (See 1)

1 VOLUME 3 , 4 - to adjust volume level.
2 DBB (Dynamic Bass Boost) - activates a more vivid

bass response.

3 POWER slider - selects TAPE/ RADIO / CD

function and also the power off switch (TAPE/ OFF).

4 BAND - selects waveband.
5 0-9: - digit panel

CD: - track selection and direct playback;
RADIO: -

6 PROGRAM

7 SEARCH ∞ , §

8 MODE - selects different play modes: e.g. REPEAT

9 2; - starts or pauses CD playback.
0 9 - to stop playback;

! Display - shows the status of the set.
@ OPEN•CLOSE – opens/ closes the CD-tape door
# REMOTE SENSOR - (for AZ1515 model only)

$ CASSETTE RECORDER keys:

selecting a preset station.

CD: -

programs tracks and reviews the program;

Tuner:-

programs preset radio stations.

CD: - searches backward and forward within a track;

- skips to the beginning of a current track/ previ­ous/ later track.

(down, up) tunes to radio stations.

RADIO: -

or SHUFFLE (random) order.

- erases a CD program.

infrared sensor for remote control.

RECORD 0 - to start recording.
PLAY 2 - to start playback.
SEARCH 5 / 6 - fast rewinds/ winds tape.
STOP 9 - stops tape.
PAUSE; - pauses playback or recording.

BACK PANEL

% Telescopic aerial - improves FM reception.
^

p

- 3.5 mm stereo headphone socket.

Note: The speakers will be muted when headphones

are connected to the set.

& AC MAINS - inlet for mains lead.
* Battery compartment - for 6 batteries, type

R-14, UM2 or C-cells.

REMOTE CONTROL (for AZ1515 model only)

1 VOLUME 3 , 4 - adjusts volume level.
2 SHUFFLE - plays all CD tracks in random order.
3 2; - starts or pauses CD playback.
4 SEARCH 5 , 6 - searches backwards/

forwards within a track.

5 PRESET +,-(up, down) - selects a preset radio

station.

6 TUNING ∞ , § (down, up) - tunes to tuner stations.
7 9 - to stop playback;

- erases a CD program.

8 ¡ , ™ - skips to the beginning of a current track

previous/ subsequent track.

9 REPEAT- repeats a track /program/ entire CD.

CAUTION

Use of controls or adjustments or performance of pro­cedures other than herein may result in hazardous
radiation exposure or other unsafe operation.

POWER SUPPLY

Whenever convenient, use the AC power supply to
conserve battery life. Make sure you remove the
power plug from the set and wall outlet before
inserting batteries.

Batteries (not included)

• Insert 6 batteries, type R-14, UM-2 or C-cells, (pre­ferably alkaline) with the correct polarity. (See 7)

• Remote control (AZ1515 model only)
Insert 2 batteries, type AAA, R03 or UM4 (prefera-
bly alkaline). (See 9)

IMPORTANT!

• Incorrect use of batteries can cause electrolyte lea­kage and will corrode the compartment or cause
the batteries to burst.

• Do not mix battery types: e.g. alkaline with carbon
zinc. Only use batteries of the same type for the
set.

• When inserting new batteries, do not try to mix old
batteries with the new ones.

• Batteries contain chemical substances, so

they should be disposed of properly.

Using AC Power

1. Check if the AC power supply, as shown on the

type plate located on the bottom of the set,
corresponds to your local power supply. If it does
not, consult your dealer or service centre.

2. Connect the mains lead to the wall socket.

3. To disconnect the mains supply, unplug the set

from the wall socket.

The type plate is located on the bottom of the
set.

This set complies with the radio interference
requirements of the European Community.

For users in the U.K., please follow the boxed
instructions ‘Important notes...’ on this sheet.

BASIC FUNCTIONS
Switching on and off and selecting function

1. To switch on, adjust the POWER slider to select:
CD, RADIO or TAPE function, and operate the

respective function controls.

2. To switch off, adjust the POWER slider to select
TAPE/OFFand make sure all the

cassette keys are released.

Note : The DBB setting, tuner presets and the volu­me will be retained in the set's memory.

Adjusting volume and sound (See 2)

1. Press the

2. Press DBB once or more to select dynamic bass

VOLUME 3 or 4

volume.

boost on or off.

controls to adjust the

DIGITAL TUNER
Tuning to radio stations

1. Adjust the POWER slider to RADIO.

™ tu is displayed briefly and then the radio

station frequency, waveband and, if pro­grammed, a preset number are shown. (See 3)

2. Press BAND once or more to select your wave-
band.

3. Press and hold SEARCH
frequency in the display starts running.
™ The radio automatically tunes to a station of

sufficient reception. Display shows Srch
during automatic tuning.

4. Repeat step 3 if necessary until you find the
desired station.

To tune to a weak station, press
repeatedly until you have found optimal reception.

To improve radio reception:

• For FM, extend, incline and turn the telescopic
aerial. Reduce its length if the signal is too strong.

• For MW (AM
Direct this aerial by turning the whole set.

Programming radio stations

You can store up to a total of 40 radio stations in the
memory, manually or automatically (Autostore).

Manual programming

1. Tune to your desired station (see Tuning to radio
stations).

2. Press PROGRAM to activate programming.
™ Display: Pr -- and PROG flashes.

3. Use the digit panel on the set to key in a number,
1-40, to select a preset station. E.g. press 1,1 if
you want to store your station as preset 11. (See

4)

• Remote control (AZ1515 models only): Press

PRESET +/ -

tion.

4. Press PROGRAM to confirm.

5. Repeat steps 1-4 to store other stations.

Note : You can erase a preset station by storing

another frequency in its place.

or

once or more to select a preset sta-

∞ or §

until the

∞ or §

briefly and

LW), the set uses a built-in aerial.

DIGITAL TUNER CD PLAYER

CD PLAYER

CASSETTE RECORDER

Autostore

Autostore automatically starts programming radio sta­tions from preset 1. Available stations are program­med in order of waveband reception strength: FM, fol­lowed by MW (AM). Any previous presets e.g.
manually programmed will be erased.

• Press PROGRAM for 4 seconds or more to activate
autostore programming.
™ The display shows AUtO, PROG blinks,

followed by the radio station details when

stored.
After all stations are stored, the first preset station
will then automatically play.

To listen to a preset station

• Direct Easy Access: use the digit panel on the set

to key in a number, 1-40, to select a preset station.

• Remote control (AZ1515 models only): optionally,

press

PRESET

CD PLAYER
Playing a CD

This CD player plays Audio Discs including CD­Recordables and CD-Rewritables.

1. Adjust the POWER slider to CD.

2. Insert a CD with the printed side facing up and

close the door.
™ noCd if no CD inserted/ CD dirty, incorrectly

inserted or damaged.

™ nFCd if you have inserted a non-finalized CD-

R(W).

3. Press

2;

™ dAtA if your CD contains non-audio i.e. data

files.

4. To pause playback press 2;. Press 2;again to

resume play.
™ Display: 2flashes during pause.

5. To stop CD playback, press the 9button.
Note : CD play will also stop when:

- the CD-tape door is opened

- the CD has reached the end

- you select TAPE or RADIO function.

Selecting a different track

There are 2 ways:

,-

to select your preset station.

+

to start playback.

Direct Easy Access

• Key in the number of the track using the digit panel
on the set.

∞ or §

SEARCH

• Press SEARCH
ect your track.

Finding a passage within a track

1. Press and hold SEARCH
– The CD is played at high speed and low volume.

2. When you recognize the passage you want,
release

Note : During a CD program or if SHUFFLE/ REPEAT
active, searching is only possible within a track.

Different play modes: SHUFFLE and REPEAT

You can select and change the various play modes
before or during playback, and combine the modes
with PROGRAM. (See 5)
SHUFFLE - tracks of the entire CD/ program are play­ed in random order
SHUFFLE REPEAT ALL- to repeat the entire CD/
program continuously in random order

REPEAT ALL- repeats the entire CD/ program
REPEAT- plays the current track continuously

1. To select play mode, press MODE once or more.

2. Press

3. To select normal playback, press MODE repeated-

ly until the various modes are no longer displayed.
– You can also press the 9button to cancel your

play mode.

Programming track numbers

In the stop position, select and store your CD tracks in
the desired sequence. Up to 20 tracks can be stored in
the memory.

1. Press SEARCH
desired track number.

2. Press PROGRAM.
™ Display: PROG, Pr and your selected track

number. (See 6)

™ If you attempt to program without first

selecting a track number, noSE is shown.

∞ or §

once or repeatedly to sel-

∞ or §

.

∞ or §

to resume normal playback.

2;

to start playback if in the stop position.

∞ or §

on the set to select your

3. Repeat steps 1-2 to select and store all desired
tracks.
™ Display: FULL if you try to program more

than 20 tracks.

Reviewing the program

In the stop position, press and hold PROGRAM until
the display shows all your stored track numbers in
sequence.

Erasing a program

You can erase the program by:

• pressing

• You select TAPE or RADIO function.

CASSETTE RECORDER
Cassette playback

1. Adjust the POWER slider to TAPE.

2. Insert a cassette as shown and close the door.

3. Press

4. To pause playback press PAUSE;. Press again to

5. Press SEARCH

6. To stop the tape, press STOP9.

The keys are automatically released at the end of a
tape and the set switched off, except if PAUSE;has
been activated.

General information on recording

• Recording is permissible insofar as copyright or.

• For recording, use only NORMAL type cassettes

• The best recording level is set automatically.

9

twice

™ CLr is displayed briefly and PROG

disappears.

2

to start playback.

™ Display: shows tAPE throughout tape

operation.

resume.

5 or 6

to fast wind the tape.

other rights of third parties are not infringed.

(IEC type I) on which the tabs have not yet been
broken. This deck is not suited for recording on
CHROME (IEC II) or METAL (IEC IV) type casset­tes.

Altering the VOLUME or DBB controls will not
affect the recording.

• To protect a tape from accidental erasure, break
out the tabs. If you wish to record again, cover the
tabs with a piece of adhesive tape.

CD Synchro Start Recording

1. Adjust the POWER slider to CD.

2. Insert a CD and if desired, program track numbers.

3. Insert a suitable tape into the cassette deck and

close the door.

RECORD 0

4. Press
– Playing of the CD program starts automatically

from the beginning of the program. You don't
need to start the CD player separately.

™ To select and record a particular passage

within a CD track:

• Press SEARCH
you recognize the passage you want.

• To pause CD playback, press

• Recording starts from this exact point in the track
when you press

5. To pause recording, press PAUSE;. Press
PAUSE

6. To stop recording, press STOP

Recording from the Radio

1. Tune to the desired radio station (see Tuning to
radio stations).

2. Follow steps 3-6, under CD Synchro Start
Recording.

to start recording.

∞ or §

. Release the control when

2;

RECORD 0

;

again to resume recording.

.

.

9

.

Meet Philips at the Internet

http://www.audio.philips.com

Printed in China

W

AZ 1510
AZ 1515

3140 115 3023.1

English Français Español Deutsch

Nederlands

CLASS 1

LASER PRODUCT

SAFETY & MAINTENANCE INFORMATION
(See 8)

• Don't expose the set, batteries, CDs or cassettes to
humidity, rain, sand or excessive heat.

• Clean the set with a dry cloth. Don't use any clea­ning agents containing alcohol, ammonia, benzene
or abrasives as these may harm the set.

• Place the set on a hard and flat surface so that the
system does not tilt. Make sure there is good venti­lation to prevent the set overheating.

• The mechanical parts of the set contain self-lubri­cating bearings and must not be oiled or lubricated.

CD player and CD handling

• If the CD player cannot read CDs correctly, use a
cleaning CD to clean the lens before taking the set
to repair.

• The lens of the CD player should never be touched!

• Sudden changes in the surrounding temperature
can cause condensation on the lens of your CD
player. Playing a CD is then not possible. Do not
attempt to clean the lens but leave the set in a
warm environment until the moisture evaporates.

• Always close the CD-tape door to avoid dust on the
lens.

• To clean the CD, wipe in a straight line from the
centre towards the edge using a soft, lint-free
cloth. Do not use cleaning agents as they may
damage the disc.

• Never write on a CD or attach any stickers to it.

Tape deck maintenance

To ensure quality recording and playback of the tape
deck, clean parts A, B and C as shown, once a
month. Use a cotton bud slightly moistened with alco­hol or a special head cleaning fluid to clean the deck.

1. Open the CD-tape door.

2. Press

PLAY 2

and clean the roller C.

3. Press PAUSE;and clean the heads A, and the
capstan B.

4. After cleaning, press STOP9.

Note:

Cleaning of the heads can also be done by playing a
cleaning cassette through once.

No sound /power

– Volume not adjusted

• Adjust the VOLUME
– Mains lead not securely connected

• Connect the AC mains lead properly
– Batteries exhausted/ incorrectly inserted

• Insert (fresh) batteries correctly
– Headphones connected to the set

• Disconnect headphones

Severe radio hum or noise

– Electrical interference: set too close to TV, VCR or

computer

• Move the set to increase the distance

Poor radio reception

– Weak radio signal

• FM: Adjust the FM telescopic aerial

noPr indication

– During programming radio preset stations, you have

keyed in a preset number that exceeds the maximum
preset number i.e. 40

• Key in a preset number from 1-40

noCd indication

– CD badly scratched or dirty

•

Replace/ clean CD, see Maintenance

– Laser lens steamed up

• Wait until lens has cleared

nFCd indication

– CD-R(W) is blank/ not finalized

•

Use a finalized CD-R(W)

dAtA indication

– CD contains non-audio files

•

Press SEARCH

∞ or §

once or more to skip to a

CD audio track, instead of the data file

The CD skips tracks

– CD damaged or dirty

• Replace or clean CD
– SHUFFLE or PROGRAM is active

• Switch off SHUFFLE / PROGRAM

Poor cassette sound quality

– Dust and dirt on the heads, etc.

• Clean deck parts, see Maintenance
– Use of incompatible cassette types (METAL or

CHROME)

• Only use NORMAL (IEC

I

) for recording

Recording does not work

– Cassette tab(s) may be broken

• Apply adhesive tape over the missing tab space

Remote control does not function properly (for
AZ1515 model only)

– Batteries exhausted/ incorrectly inserted

• Insert (fresh) batteries correctly
– Distance/ angle between the set too large

• Reduce the distance/ angle

SAFETY & MAINTENANCE INFORMATION TROUBLESHOOTING

Environmental information

We have done our best to reduce the packaging and make it easy to separate into 3 materials:
cardboard, expandable polystyrene, polyethylene.

Your set consists of materials which can be recycled if disassembled by a speciali­zed company. Please observe the local regulations regarding the disposal of packa­ging, exhausted batteries and old equipment.

If a fault occurs, first check the points listed below before taking the set for repair.
If you are unable to remedy a problem by following these hints, consult your dealer or service centre.

WARNING: Do not open the set as there is a risk of electric shock. Under no cir-

cumstances should you try to repair the set yourself, as this will
invalidate the guarantee.

A AB

C

X

DBB

MW

FM

PROG

DBB

PROG

SHUFFLE

PROG
