AZ101
AZ1004
CD Soundmachine
User Manual
Meet Philips at the Internet
http://www.philips.com
W
CLASS 1
LASER PRODUCT
AZ 101
Printed in China ALJW-0445
6 x R14 • UM-2 • C-CELLS
%
#
$
0 9! 8 7
4
321
5
6@
1
A AB
C
X
7
4
5
3
2
6
English Controls/Power Supply
Supplied accessories
AC mains lead
Top and front panels (See 1)
1
VOLUME– adjusts volume level
2
Source selector : CD, TUNER,
TAPE/POWER OFF
–
selects CD, tuner or tape source of sound
–
power off switch
3
CD door
4 TUNING
– tunes to radio stations
5 BAND –
selects waveband
6
PREVIOUS, NEXT ∞ , §
–
skips or searches a passage/track
backwards or forward
7 PROG – programs and reviews
programmed track numbers
8
Cassette recorder keys:
;–pauses playback or recording
9
/ –
stops the tape;
–
opens the cassette holder
5 or 6–fast winds/ rewinds tape
1–starts playback
0–starts recording
9 Cassette door
0
CD Display–shows the CD functions
!
PLAY/PAUSE 2; - star ts or pauses CD
playback.
@
STOP 9–stop playback;
–
erases a CD program.
Back panel
#
Telescopic antenna - improves FM
reception.
$ Battery door - open to insert 6 x 1.5V
R-14/ UM2/ C-cells.
% AC MAINS - inlet for power cord
CAUTION
Use of controls or adjustments or
performance of procedures other
than herein may result in hazardous
radiation exposure or other unsafe
operation.
This set complies with the radio
interference requirements of the
European Community.
Power Supply
Whenever convenient, use the mains supply
cord if you want to conserve battery life.
Make sure you remove the plug from the set
and wall outlet before inserting batteries.
Batteries (not included)
1 Open the battery compar tment and inser t
six batteries, type R-14, UM-2 or C-cells,
(preferably alkaline) with the correct polarity
as indicated by the "+" and "–" symbols inside
the compartment. (See 1)
2 Replace the compartment door, making sure
the batteries are firmly and correctly in place.
The set is now ready to operate.
Batteries contain chemical substances, so
they should be disposed of properly.
Power Supply
General operation/Radio
• Incorrect use of batteries can cause
electrolyte leakage and will corrode the
compartment or cause the batteries to burst:
• Do not mix battery types: e.g. alkaline with
carbon zinc. Only use batteries of the same
type for the set.
• When inserting new batteries, do not try to
mix old batteries with the new ones.
• Remove the batteries if the set is not to be
used for a long time.
Using AC Mains
1 Check if the power/mains voltage, as shown
on the type plate located on the
bottom of the set, corresponds to your
local power supply. If it does not, consult your
dealer or service center.
2 Connect the power cord to the AC
POWER/MAINS inlet and the wall socket.
The mains lead is now connected and ready
for use.
3 To switch the set off completely, withdraw the
power cord from the wall socket.
• Disconnect the mains lead from the wall
socket to protect your set during heavy
thunderstorms.
Helpful hints : To avoid unnecessar y energy
consumption, always adjust the source
selector to
TAPE/POWER OFF
after using
the set. Also check that the tape deck keys
are released
The type plate is located on the bottom
of the set.
For users in the U.K., please follow the
boxed instructions ‘Important notes...’ on
this sheet.
General operation
1 To select your sound source adjust the
source selector to : CD,
TUNER
or
TAPE/POWER OFF
.
2 Adjust the sound with the VOLUME
control.
3 To switch off the set, adjust the source selec-
tor to
TAPE/POWER OFF
position and check
the cassette keys are released.
Radio reception
1 Adjust the source selector to
TUNER
.
2 Adjust BAND to select your desired
waveband, FM or MW.
3 Tur n TUNING to tune to a station.
• For FM, extend and turn the telescopic
antenna for best reception. Reduce its length
if the signal is too strong.
• For MW, the set uses a built-in antenna.
Direct this antenna for best reception by
turning the whole set.
4 To switch off the radio, adjust the source
selector to
TAPE/POWER OFF
position and
check the cassette keys are released.
CD Player
CD Player Cassette Recorder
Playing a CD
This CD player plays Audio Discs including
CD-Recordables and CD-Rewritable.
• MP3 CD-ROMs, CD-I, CDV,VCD, DVD or
computer CDs are not possible for playback
on this set.
Important: CDs encoded with copyright
protection technologies by some record
companies may be unplayable by this product.
1 Adjust the source selector to CD.
2 Insert a CD/ CD-R(W) with the printed side
facing up and press the CD door gently
close.
➜ Display shows -- and later, the total
number of tracks. (See 2, 3)
3 Press
PLAY/PAUSE 2;
on the set to start
playback.
➜Display:
2
and the current track number.
(See 4)
4 To pause playback press
PLAY/PAUSE 2;
.
Press
PLAY/PAUSE 2;
again to resume
play.
5 To stop CD play, press
STOP 9
.
6 To switch off the set, adjust the source
selector to
TAPE/POWER OFF
position and
check the cassette keys are released.
Helpful hints : CD play will also stop when:
- you open the CD compartment;
- you select
TUNER
or
TAPE/POWER OFF
sound source;
- the CD has reached the end of playback.
Selecting a different track
• Press
PREVIOUS, NEXT
∞ or § once or
repeatedly until the desired track number
appears in the display.
• In the pause/stop position, press 2; to start
playback.
Finding a passage within a
track
1 During playback, press and hold down
∞ / §
.
➜ The CD is played at high speed and low
volume.
2 When you recognize the passage you want
release
∞ / §
.
➜ Normal playback resumes.
Helpful hints : When searching within a final
track and you reach the end of the last track,
the CD goes to stop mode.
Programming track
numbers
You may store up to 20 tracks in the desired
sequence. If you like, store any track more
than once.
1 In the stop position, press PROG to activate
programming.
➜ Display: PROG and 00 flash.
2 Press ∞or §to select your desired track
number.
➜ Display: PROG and your desired track
number flash. (see 5)
3 Press PROG to store the desired track
number.
➜ Display: PROG and 00 flash for you to
program the next track. (see 6)
4 Repeat steps 2 to 3 to select and store all
desired tracks in this way.
➜ Display shows --after 20 tracks are
stored
5 To play your program, press
PLAY/PAUSE
2;
.
➜ Display: PROG flashes during program
playback
To review a program
• In the stop position, press PROG repeatedly
to see your stored track numbers.
Erasing a program
You can erase the contents of the memor y
by:
– Pressing
STOP 9
(twice during playback or
once in the stop position)
– Selecting
TUNER
or
TAPE/POWER OFF
sound source;
– opening the CD door;
Cassette playback
1 Adjust the source selector to
TAPE/POWER OFF
.
2 Press 9/ to open the cassette holder and
insert a cassette and close the deck.
3 Press 1to start playback.
4 To pause playback press ;.
5 To resume, press ;again.
6 To stop the tape, press 9/.
Fast forwarding/rewinding
1 Press
5 or 6
until you reach your desired
passage.
2 Press 9/ to stop rewinding/fast forwarding.
Helpful hints :
- During playback, the keys are automatically
released at the end of a tape and the set is
switched off (unless PAUSE mode
;
has been
activated.)
- During fast forwarding/rewinding, the keys will
not be released at the end of a tape.To switch
off the set, make sure the cassette keys are
also released.
General information on recording
• Recording is permissible insofar as copyright
or. other rights of third parties are not
infringed.
• For recording, use only NORMAL type cassettes (IEC type I) on which the tabs have
not yet been broken.This deck is not suited
for recording on CHROME (IEC II) or
METAL (IEC IV) type cassettes.
• The best recording level is set automatically.
Altering the VOLUME will not affect the
recording.
•To protect a tape from accidental erasure,
break out the tabs. If you wish to record
again, cover the tabs with a piece of adhesive
tape.
CD synchro start recording
1 Select CD source.
2 Insert a CD and if desired, program track
numbers.
3 Press
9
/ to open the cassette holder. Insert
a blank tape and close the deck.
4 Press0to start recording.
➜ Playing of the CD/ program starts
automatically from the beginning. It is not
necessary to star t the CD player separately.
5 For brief interruptions, press ;.To resume
recording, press ;again.
6 To stop recording, press 9/.
Recording from the Radio
1 Adjust the Source selector to
TUNER
.
2 Adjust BAND to select your desired
waveband, FM or MW.
3 Tune to the desired radio station (see Radio
reception).
4 Follow steps 3-6 under CD sychro start
recording.
Precautions & General
Maintenance (See 7)
• Place the set on a hard, flat and stable surface
so that the system does not tilt.
• Do not expose the set, batteries, CDs to
humidity, rain, sand or excessive heat caused
by heating equipment or direct sunlight.
• The apparatus shall not be exposed to
dripping or splashing.
• Adequate ventilation with a minimum gap of
15cm between the ventilation holes and surrounding surfaces is necessary to prevent
heat build-up.
• The ventilation should not be impeded by
covering the ventilation openings with items,
such as newspapers, table-cloths, cur tains, etc..
• No objects filled with liquids, such as vases,
shall be placed on the apparatus.
• No naked flame sources, such as lighted candles, should be placed on the apparatus.
• The mechanical parts of the set contain
self-lubricating bearings and must not be oiled
or lubricated.
•To clean the set, use a dry cloth. Do not use
any cleaning agents containing alcohol,
ammonia, benzene or abrasives as these may
harm the housing.
Ta pe deck maintenance (See 7)
To ensure quality recording and playback of
the tape deck, clean parts A, B and C as
shown, once a month. Use a cotton bud
slightly moistened with alcohol or a special
head cleaning fluid to clean the deck.
1 Open the cassette holder by pressing
9
/.
2 Press1and clean the roller C.
3 Press ;and clean the heads A, and the
capstan B.
4 After cleaning, press 9.
➜ Cleaning of the heads can also be done by
playing a cleaning cassette through once.
CD player and CD handling (See 7)
• If the CD player cannot read CDs correctly,
use a cleaning CD to clean the lens before
taking the set to repair.
• The lens of the CD player should never be
touched!
• Sudden changes in the surrounding
temperature can cause condensation on the
lens of your CD player. Playing a CD is then
not possible. Do not attempt to clean the
lens but leave the set in a warm environment
until the moisture evaporates.
•Always close the CD-tape door to avoid dust
on the lens.
•To clean the CD, wipe in a straight line from
the center towards the edge using a soft,
lint-free cloth. Do not use cleaning agents as
they may damage the disc.
• Never write on a CD or attach any stickers
to it.
Cassette Recorder Maintenance
Problem
– Possible cause
• Remedy
No sound /power
– Volume not adjusted
• Adjust the VOLUME
– Power cord not securely connected
• Connect the AC power cord properly
– Batteries dead/ incorrectly inserted
• Insert (fresh) batteries correctly
– CD contains non-audio files
• Press
PREVIOUS, NEXT ∞ , §
once or
more to skip to a CD audio track, instead of the
data file.
Display does not function properly/ No
reaction to operation of any of the controls
– Electrostatic discharge
• Switch off and unplug the set. Reconnect after a
few seconds
The CD skips tracks
– CD damaged or dirty
• Replace or clean CD
– Program is active
• Quit program mode
- - indication
– No CD inserted
•
Insert a CD
– CD badly scratched or dirty
•
Replace/ clean CD, see Maintenance
– Laser lens steamed up
•Wait until lens has cleared
– CD-R(W) is blank or not finalized
•
Use a finalized CD-R(W) or suitable CD Audio
disc only.
Poor cassette sound quality
– Dust and dirt on the heads, etc.
• Clean deck parts, see Maintenance
– Use of incompatible cassette types (METAL or
CHROME)
• Only use NORMAL (IEC I) for recording
Recording does not work
– Cassette tab(s) may be broken
• Apply adhesive tape over the missing tab space
Troubleshooting
Environmental information
All unnecessary packaging material has been omitted.The packaging can be easily separated
into three materials: cardboard, polystyrene and plastic.
Yo ur set consists of materials which can be recycled if disassembled by a
specialized company. Please observe the local regulations regarding the
disposal of packaging, dead batteries and old equipment.
If a fault occurs, first check the points listed below before taking the set for repair.
If you are unable to remedy a problem by following these hints, consult your dealer or ser vice centre.
WARNING: Do not open the set as there is a risk of electric shock. Under no cir-
cumstances should you try to repair the set yourself, as this will invalidate the guarantee.
Mains plug
This apparatus is fitted with an approved 13 Amp plug. To change a fuse in this
type of plug proceed as follows:
1.Remove fuse cover and fuse.
2.Fix new fuse which should be a BS1362 5 Amp, A.S.T.A. or BSI approved type.
3.Refit the fuse cover.
If the fitted plug is not suitable for your socket outlets, it should be cut off and
an appropriate plug fitted in its place. If the mains plug contains a fuse, this
should have a value of 5 Amp. If a plug without a fuse is used, the fuse at the
distribution board should not be greater than 5 Amp.
Note: The severed plug must be disposed of to avoid a possible shock hazard
should it be inserted into a 13 Amp socket elsewhere.
How to connect a plug
The wires in the mains lead are coloured with the following code: blue = neutral
(N), brown = live (L). As these colours may not correspond with the colour markings identifying the terminals in your plug, proceed as follows:
•Connect the blue wire to the terminal marked N or coloured black.
•Connect the brown wire to the terminal marked L or coloured red.
•Do not connect either wire to the earth terminal in the plug, marked E (or e) or
coloured green (or green and yellow).
Before replacing the plug cover, make certain that the cord grip is clamped over
the sheath of the lead - not simply over the two wires.
Copyright in the U.K.
Recording and playback of material may require consent. See Copyright Act 1956
and The Performer’s Protection Acts 1958 to 1972.
Important notes for users in the U.K.
Loading...
