Philips AP7766/00 user manual [zh]
AP7766
EN User manual 3 ZH-S
用户手册
25
English
Contents
1 Important 4
Safety 4
2 Your air purier 7
Product Overview 7
Controls overview 8
3 Getting started 9
Installing lters 9
4 Using the appliance 11
Understanding the air quality
light 11
Switching on 11
Changing the fan speed 12
Using the lock function 12
Using the light On/O
function 13
5 Cleaning 14
Cleaning schedule 14
Cleaning the body of the
appliance 14
Cleaning the air outlet cover 15
Cleaning the air quality sensor 15
Cleaning the pre-lter 16
7 Resetting the lter lifetime
counter 20
8 Troubleshooting 21
9 Guarantee and service 23
Order parts or accessories 23
10 Notices 24
Electromagnetic elds (EMF) 24
Recycling 24
6 Replacing the air
purication lter 18
Understanding the healthy
air protect lock 18
Replacing the air purication
lter 18
3EN
1 Important
Safety
Read this user manual carefully
before you use the appliance, and
save it for future reference.
Danger
• Do not let water or any
other liquid or flammable
detergent enter the
appliance to avoid electric
shock and/or a fire
hazard.
• Do not clean the
appliance with water,
any other liquid, or a
(flammable) detergent to
avoid electric shock and/
or a fire hazard.
• Do not spray any
flammable materials
such as insecticides or
fragrance around the
appliance.
Warning
• Check if the voltage
indicated on the
appliance corresponds to
the local power voltage
before you connect the
appliance.
• If the power cord is
damaged, you must have
it replaced by Philips, a
service center authorized
by Philips, or similarly
qualified persons in order
to avoid a hazard.
• Do not use the appliance
if the plug, the power
cord, or the appliance
itself is damaged.
• This appliance can be
used by children aged
from 8 years and above
and persons with reduced
physical, sensory or
mental capabilities or
lack of experience and
knowledge if they have
been given supervision or
instruction concerning use
of the appliance in a safe
way and understand the
hazards involved. Child
shall not play with the
appliance. Cleaning and
maintenance shall not be
made by children without
supervision.
• Do not block the air inlet
and outlet, e.g. by placing
items on the air outlet or
in front of the air inlet.
• Make sure that foreign
objects do not fall into the
appliance through the air
outlet.
4 EN
English
Caution
• This appliance is not
a substitute for proper
ventilation, regular
vacuum cleaning, or use
of an extractor hood or
fan while cooking.
• If the power socket used
to power the appliance
has poor connections,
the plug of the appliance
becomes hot. Make
sure that you plug the
appliance into a properly
connected power socket.
• Always place and use the
appliance on a dry, stable,
level, and horizontal
surface.
• Leave at least 20cm free
space behind and on both
sides of the appliance
and leave at least 30cm
free space above the
appliance.
• Do not place anything on
top of the appliance.
• Do not sit or stand on the
appliance. The appliance
is equipped with omni
wheels. Sitting or standing
on the appliance may
lead to potential injuiry.
• Do not place the
appliance directly below
an air conditioner to
prevent condensation
from dripping onto the
appliance.
• Make sure all filters
are properly installed
before you switch on the
appliance.
• Only use the original
Philips filters specially
intended for this
appliance. Do not use any
other filters.
• Combustion of the filter
may cause irreversible
human hazard and/or
jeopardize other lives. Do
not use the filter as fuel or
for similar purpose.
• Avoid knocking against
the appliance (the air inlet
and outlet in particular)
with hard objects.
• Always lift or move
the appliance by both
handles at the sides of the
appliance.
• Do not insert your fingers
or objects into the air
outlet or the air inlet to
prevent physical injury
or malfunctioning of the
appliance.
5EN
• Do not use this appliance
when you have used
indoor smoke-type insect
repellents or in places
with oily residues, burning
incense, or chemical
fumes.
• Do not use the appliance
near gas appliances,
heating devices or
fireplaces.
• Always unplug the
appliance after use
and before cleaning
or carrying out other
maintenance.
• Do not use the appliance
in a room with major
temperature changes,
as this may cause
condensation inside the
appliance.
• To prevent interference,
place the appliance
at least 2m away from
electrical appliances that
use airborne radio waves
such as TVs, radios, and
radio-controlled clocks.
• The appliance is only
intended for use under
normal operating
conditions.
• Do not use the appliance
in wet surroundings or in
surroundings with high
ambient temperatures,
such as the bathroom,
toilet, or kitchen.
• The appliance does
not remove carbon
monoxide (CO) or radon
(Rn). It cannot be used
as a safety device in
case of accidents with
combustion processes
and hazardous chemicals.
• If you need to move the
appliance, disconnect the
appliance from the power
supply first. The appliance
is equipped with omni
wheels and is easy to
move.
• When moving the
appliance, do it slowly
and do not push it rapidly.
• Do not move the
appliance by pulling its
power cord.
6 EN
English
2 Your air purifier
Congratulations on your purchase, and welcome to Philips!
To fully benefit from the support that Philips offers, register your product at
www.philips.com/welcome.
This appliance works with an air filtration system. Read this user manual
carefully before you use the appliance, and save it for future reference.
Product Overview
Air outlet cover
Speed knob
Professional
NanoProtect filter
series 7000B
Pre-filter
Side panels
Type number Filter
AP7076 Professional NanoProtect filter series 7000B*
Air quality sensor
*Hereinafter referred to as "air purification filter".
7EN
Controls overview
: Power On/Off (filter reset) button : Speed 3
: Auto speed : Turbo speed
: Silent speed : Pre-filter cleaning alert
: Speed 1 : Air purification filter
replacement alert
: Speed 2 : Light On/Off (Lock) button
8 EN
English
3 Getting started
2 Pull the top part of the side
panel to remove it from the
appliance.
Installing filters
Remove all packaging of the filters
before using the appliance. Unpack
them and place them into the
appliance described as follows:
Note
• There is one set of filters on
each side of the appliance.
Each side is equipped with
one pre-filter and one air
purification filter.
• Make sure that you place the
air purification filter in the
appliance first and then the
pre-filter.
• Make sure that the side with the
tag is pointing towards you.
1 Remove all packaging materials
of the air purification filters.
3 Press the two clips down and
pull the pre-filter towards you.
4 Put the unpacked air purification
filter back into the appliance.
9EN
5 Put the pre-filter back into the
appliance.
Note
• Make sure that the side with the
two clips is pointing towards
you, and that all hooks of the
pre-filter are properly attached
to the purifier.
6 To reattach the side panel,
mount the panel onto the
bottom of the appliance first
(1). Then, gently push the
panel against the body of the
appliance (2).
7 Repeat the above steps and
assemble the air purification
filter for the other side of the
appliance.
10 EN
English
4 Using the
appliance
Understanding the air
quality light
2 Press the power On/Off button
to switch on the appliance.
Color of the air
quality light
Blue Good
Blue-violet Fair
Red-purple Unhealthy
Red Very
The air quality light automatically
goes on when the appliance is
switched on, and lights up all colors
in sequence.
In a short time the air quality
sensors select the color that
corresponds to the ambient air
quality.
Air quality
level
unhealthy
Switching on
1 Put the plug of the appliance
into the wall socket.
» The appliance beeps.
» All lights go on once and
then go out again.
» The default fan speed is
(AUTO).
» After measuring the air
quality for a short time,
the air quality sensor
automatically selects the
color of the air quality light.
» The running strips " "
displays on the screen when
the appliance is measuring
the PM2.5 level. After a short
time the actual PM2.5 level
will display on the screen.
3 Press the power On/Off button
again to switch off the
appliance.
11EN
Changing the fan speed
(AUTO)
In auto mode, the appliance selects
the fan speed in accordance with
the ambient air quality.
1 Turn the speed knob to select
the auto speed .
» and the current fan
speed indicator lights up.
Manual
1 Turn the speed knob to select
the fan speed you need:
(Silent speed)
(Speed 1)
(Speed 2)
(Speed 3)
(Turbo speed)
Tip
• If the air quality light lights up
blue, it indicates that the air
quality is good, and you can
select a lower fan speed. On
the other hand, if the air quality
light lights up red-purple or red,
it indicates that the air quality is
unhealthy, and you can select
a higher fan speed to purify the
air more quickly.
Using the lock function
You can activate the lock function
to avoid any misoperation.
1 Press and hold the light On/Off
button for 3 seconds.
» The lock indicator lights up
on the screen to show that
the lock function has been
activated.
3S
12 EN
Note
• When the lock function is
activated, the speed knob
and all buttons will no longer
respond to any operation.
English
2 To deactivate the lock function,
press and hold the light On/Off
button for 3 seconds again.
» The lock indicator goes off.
3S
Using the light On/Off
function
With the light On/Off button, you
can switch on or off the air quality
light and the display screen if
needed.
1 Press the light On/Off button
once, the air quality light and
display screen will go out.
2 Press the light On/Off button
again. the fan speed indicator
will go out.
3 Press the light On/Off button
for the third time, all lights and
the display screen will go on
again.
13EN
5 Cleaning
Cleaning schedule
Frequency Cleaning method
Note
• Always unplug the appliance
before you clean it.
• Never immerse the appliance in
water or any other liquid.
• Never use abrasive, aggressive,
or flammable cleaning agents
such as bleach or alcohol to
clean any part of the appliance.
• Only the pre-filter is washable.
The air purifier filter is not
washable nor vacuum
cleanable.
When
necessary
Every two
months
When the
filter cleaning
indicator
lights up on
the screen
When
the filter
replacement
indicator
lights up on
the screen
Wipe the surface
of the appliance
with a soft dry
cloth
Clean the air
outlet cover
Clean the air
quality sensor
with a dry cotton
swab
Clean the prefilter
Replace the air
purification filters
14 EN
Cleaning the body of the
appliance
Regularly clean the inside and
outside of the appliance to prevent
dusts from collecting.
1 Wipe away dust with a soft
dry cloth from the body of the
appliance.
Loading...
