Philips AJ260 12 User Manual
AJ260Clock Radio
Register your product and get support at
www.philips.com/welcome
User manual
1
1
2
3
4
5
6
9
0
!
@
7
8
#
$
%
^
&
*
1
2
4
3
5
6
7
3
2
4
English Controls
Congratulations on your purchase, and welcome to Philips! To fully benefit from the support that Philips offers, register your product
at www.philips.com/welcome.
Supplied accessory
– 1 X certified AC 7.5V adapter
(Input: 220-230V ~50Hz 30mA,
Output: 7.5V 250mA)
– 1 X outdoor sensor
Controls (see 1)
1 ALM 1/ ALM 2
– activates/confirms ALARM 1 /ALARM 2
time setting
– switches off the alarm
2 RADIO ON/OFF
– switches the radio on/off
– switches the set on or to standby
– stops the active buzzer or radio alarm for
24 hours
– switches off the sleep timer
3 TIME SET/RCC SYNC
– activates/confirms clock/date setting
– activates RCC (Radio Controlled Clock)
reception
4 AUTO SCAN/DATE
– programs preset radio stations
– displays month and day information in
standby mode
– changes display order between month and
day during setting time
– receives transmission from the sensor
5 DISPLAY
– toggles between indoor temperature,
indoor humidity and outdoor temperature
6 RADIO•BUZ
– selects alarm mode: radio or buzzer
7 REPEAT ALARM/BRIGHTNESS
CONTROL
– pushes to switch off alarm for a 9-minute
period
– changes the brightness of the display
illumination
8 LCD Display – shows the clock/ alarm time
or radio and weather forecast information
9 SLEEP/ALARM RESET
– switches off radio for timer mode
– adjusts timer options for radio playback
– stops the active buzzer or radio alarm for
24 hours
0 PRESET +/-
selects a preset radion station
–
! TUNING +/-
– tunes to radio stations
– adjusts clock / alarm time
@ VOL – adjusts sound level
# Color lamp– indicates the different forth-
$ Battery compartment – opens to inser t
4 x 1.5V AAA batteries
% RESET
– press if the set / display does not react to
operation of any button
^ (oC oF) Slide Switch
– selects between Centigrade (oC) or
Fahrenheit (oF) temperature unit display
& DC 7.5V
– socket for AC/DC 7.5V adapter
* Pigtail – FM antenna to improve FM
coming weather situation
reception
Controls on the sensor (see 1)
1 LCD display
– shows current temperature, and low bat-
tery indication of the sensor
2 LED light
– flashes when the sensor is transmitting
3 RESET
– resets to start transmitting
4 (oC oF) Slide Switch
– selects between Centigrade (oC) or
Fahrenheit (oF) temperature unit display
5 CHANNEL 1/ 2 /3
– selects RF channel to transmit and receive
between the senor and the main unit
6 Door lock
– turns to lock and un-lock the sensor door.
7 Sensor support
– pulls out to stand the sensor
