Always there to help you
Register your product and get support at
www.philips.com/welcome
Question?
Contact
Philips
AC4030
EN User manual 3
ZH-TW 使用手冊 30
Contents
1 Important 4
Safety 4
2 Yourairpurier 8
Overview 9
3 Getting started 11
Install the anti-virus cartridge 11
Connect 14
For automobile 14
For home or ofce 15
Switch on and change the fan speed 15
4 Cleaningyourairpurier 18
5 Replacing the anti-virus cartridge 19
6 ReplacingtheAClter 22
7 Troubleshooting 24
8 Guaranteeandservice 26
Order parts or accessories 26
9 Notices 27
Electromagnetic elds (EMF) 27
Compliance with EMF 27
Recycling 28
EN 3
1 Important
Safety
Read this user manual carefully before you use the appliance,
and save it for future reference.
Danger
Do not let water or any other liquid or ammable detergent
•
enter the appliance to avoid electric shock and/or a re
hazard.
• Do not clean the appliance with water, any other liquid, or
a (ammable) detergent to avoid electric shock and or a
re hazard.
• Do not operate switches while driving.
• Do not install the appliance where it could hamper visibility
to the front or driving operations, or in place where it could
be dangerous to passengers.
Warning
Check if the voltage indicated on the bottom or at the rear
•
of the appliance corresponds to an automobile outlet for
12V or to the local power voltage before you connect the
appliance.
• This appliance is designed for use in vehicles with 12V
batteries. Do not use it in large trucks, buses, or other
vehicles with 24V batteries.
• Do not pull on the power cord when unplugging the
automobile adapter or the connection plug.
4 EN
• Only use the power supply unit provided with the appliance.
• When transporting, be careful not to drop the appliance or
subject it to shocks. Continued usage as such could lead to
re or electric shock.
• Do not use the appliance if the automobile adapter, plug, the
power cord, or the appliance itself is damaged.
• This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experiences and knowledge if
they have been given supervision or instruction concerning
use of the appliance in a safe way and understand the
hazards involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by
children without supervision.
• Do not block the air inlet and outlet, e.g. by placing items on
the air outlet or air inlet.
• Do not soak the product in water.
• Disconnect the power and remove the automobile adapter
from the cigar socket before replacing the anti-virus
cartridge*, replacing the AC lter, or cleaning the appliance.
• Disconnect the power and remove the automobile adapter
from the cigar socket when the appliance is not in use for an
extended period of time.
• If the cigar socket and ashtray are in one integrated unit, use
the product after the cigar light is gone.
Caution
This appliance is not a substitute for proper ventilation,
•
regular vacuum cleaning, or use of deodorizer.
• If the power socket used to power the appliance has poor
connections, the plug of the appliance becomes hot. Make
EN 5
sure that you plug the appliance into a properly connected
power socket.
• Always place and use the appliance on a dry, stable, level, and
horizontal surface.
• For use in car, it is recommended to place the product in the
cup holder of the car.
• Do not place the appliance in commercially available cup
holders, air vent car holder, or any kind of unstable car
mounts.
• If the appliance risks falling out of the cup holder, especially
when driving on rough roads, over bumps, etc., either
slow down or remove the appliance from the cup holder
beforehand.
• Do not place anything around the appliance nor sit on it.
• Do not place the appliance directly below an air conditioner
to prevent condensation from dripping onto the appliance.
• Make sure the AC lter and the anti-virus car tridge are
properly installed before you switch on the appliance.
• Only use the original Philips AC lter and anti-virus car tridge
specially intended for this appliance. Do not use any other.
• Avoid knocking against the appliance (the air inlet and outlet
in particular) with hard objects.
• Do not insert your ngers or objects into the air outlet.
• Do not use this appliance when you have used indoor
smoke-type insect repellents or in places with oily residues,
burning incense, or chemical fumes.
• Do not use the appliance near gas appliance, heating devices,
or replaces.
• Always unplug the appliance after use and before you clean
it.
6 EN
• Do not use the appliance in a room or in a vehicle with major
temperature changes, as this may cause condensation inside
the appliance.
• For residential use, place the appliance at least 2m away
from electrical appliance that use airborne radio waves
such as TVs, radios, and radio-controlled clocks to prevent
interference.
• The appliance is only intended for household and vehicle use
under normal operating conditions.
• Do not use the appliance in wet surroundings or in
surroundings with high ambient temperatures, such as the
bathroom, toilet, or kitchen.
• This appliance does not remove carbon monoxide (CO)
or radon (Rn). It cannot be used as a safety device in case
of accidents with combustion processes and hazardous
chemicals.
• The anti-virus cartridge may emit a distinct scent. If the scent
discomforts you, please increase ventilation, e.g. by opening
the window or stop using the appliance.
* Tested for MS2 virus species removal at Intertek Institute,
USA (tested in 11 m3 chamber).
EN 7
2 Your air purifier
Congratulations on your purchase, and welcome to Philips!
To fully benet from the support that Philips offers, register
your product at www.philips.com/welcome.
Read this user manual carefully before you install and use the
unit. Save it for future reference.
8 EN
Overview
a
b
c
d
j
Check and identify the product parts.
ghi
e
f
k
EN 9
a Fan speed button
b Light button
c Air inlet
d Bottom cover
e Air outlet
f Power-in socket
g AClter(Activatedcarbonlter)
h Anti-virus cartridge
i Brush
j AC/ DC adapter
k Automobile adapter
10 EN
3 Getting started
Install the anti-virus cartridge
The appliance comes with all accessories, but you have to
remove the packaging of the anti-virus cartridge and insert it
in the appliance before you can use it. Remove the plastic and
the 2 small stickers, and place it into the appliance as described
below.
Note
Always unplug the purier before you install the anti-virus
•
cartridge. (Figure 1)
• Insert the car tridge in the correct position.
EN 11
1 Turn the bottom cover clockwise to open. (Figure 2)
1
2 Detach the front panel cover. (Figure 3)
2
3
3 Remove 2 small stickers of the new cartridge before
placing it in. (Figure 4-6)
4 To reattach the front panel cover, insert the top hooks
into the top of the appliance rst . Then, push the
panel against the body of the appliance . (Figure 7)
12 EN
5 Place the bottom cover, and turn it anti-clockwise to
close. (Figure 8)
4
6
5
7
8
EN 13
Connect
For automobile
Caution
Do not block the air outlet when installing the product.
•
• If you place the product in front of an air conditioner, it
might be heated when the car heater is on. Be careful not
to get injured.
1 Connect the automobile adapter to the power-in socket.
(Figure 1)
2 Connect the cigar plug to the cigar socket. (Figure 2)
14 EN
1
2
Forhomeorofce
1 Connect the AC/DC adapter into the power-in socket.
(Figure 1)
2 Connect the power plug to the power socket. (Figure 2)
1
2
Switch on and change the fan speed
Caution
When you turn off the engine or take off the key of your
•
car, disconnect the cigar plug to prevent the car battery
from discharging.
EN 15
Note
If you turn off the car while using the air purier, it will
•
operate in level 1 fan speed when you restart your car.
• There are 2 levels of fan speed.
1 Press the fan speed button to switch on the air purier.
» The air purier operates in level 1 fan speed.
(Figure 1)
» The light indicator illuminates automatically. To turn
off the light indicator, you can press the light button
to turn off. (Figure 4-5)
2 Press the fan speed button again to change to higher fan
speed. (Figure 2)
16 EN
3 Press the fan speed button the third time to switch off
the air purier. (Figure 3)
1
x 1
3
x 3
2
x 2
4
x 1
5
x 2
EN 17
