Philips AC2889/80 user manual [tz]
J L M O PN
Q SR TK
AC2885: non-connected version
AC2889: connected version
© 2021 Philips Domestic Appliances Holding B.V.
All rights reserved.
3000.063.5249.1 (07/06/2021)
AC2889
1 2
A
B
C
D
I
H3
H2
E F G H1
EN User manual 1
ZH-T 使用手冊 19
J L M O PNK
RQ S T
3
4
5
6
23
24
25
26
15
19
7
11
8
12
9
13
10
14
27
31
28
3s
32
29
30
3s
3s
3s
16
20
17
21
18
22
3s
3s
English
Contents
1 Important 2
Safety 2
2 Your air purier 5
Product overview (g.a) 5
Controls overview (g.b) 5
3 Getting started 6
Installing the lters 6
Wi-Fi connection 6
4 Using the air purier 8
Understanding the air quality light 8
Turning on and o 8
Changing the Auto mode setting 9
Changing the fan speed 9
Setting the timer 10
Using the light on/o function 10
Switching the display mode 10
5 Cleaning 11
Cleaning the body of the air
purier 11
Cleaning the air quality sensor 11
Cleaning the pre-lter 12
7 Storage 14
8 Troubleshooting 15
9 Guarantee and service 17
Order parts or accessories 17
10 Notices 17
Electromagnetic elds (EMF) 17
Recycling 18
Notice 18
6 Replacing the lters 13
Filter replacement indicator 13
Replacing the lters 13
Filter reset 14
1EN
1 Important
Safety
Read this user manual carefully before
you use the appliance, and save it for
future reference.
Danger
• Do not let water or any
other liquid or flammable
detergent enter the
appliance to avoid electric
shock and/or a fire
hazard.
• Do not clean the
appliance with water,
any other liquid, or a
(flammable) detergent to
avoid electric shock and/
or a fire hazard.
• Do not spray any
flammable materials
such as insecticides or
fragrance around the
appliance.
Warning
• Check if the voltage
indicated on the
appliance corresponds to
the local power voltage
before you connect the
appliance.
• If the power cord is
damaged, you must have
it replaced by Philips, a
service center authorized
by Philips, or similarly
qualified persons in order
to avoid a hazard.
• Do not use the appliance
if the plug, the power
cord, or the appliance
itself is damaged.
• This appliance can be
used by children aged
from 8 years and above
and persons with reduced
physical, sensory or
mental capabilities or
lack of experience and
knowledge if they have
been given supervision or
instruction concerning use
of the appliance in a safe
way and understand the
hazards involved. Child
shall not play with the
appliance. Cleaning and
maintenance shall not be
made by children without
supervision.
• Do not block the air inlet
and outlet, e.g. by placing
items on the air outlet or
in front of the air inlet.
2 EN
English
• Make sure that foreign
objects do not fall into the
appliance through the air
outlet.
Caution
• This appliance is not
a substitute for proper
ventilation, regular
vacuum cleaning, or use
of an extractor hood or
fan while cooking.
• If the power socket used
to power the appliance
has poor connections,
the plug of the appliance
becomes hot. Make
sure that you plug the
appliance into a properly
connected power socket.
• Always place and use the
appliance on a dry, stable,
level, and horizontal
surface.
• Leave at least 20cm free
space behind and on both
sides of the appliance
and leave at least 30cm
free space above the
appliance.
• Do not place anything on
top of the appliance.
• Do not sit or stand on
the appliance. Sitting or
standing on the appliance
may lead to potential
injuiry.
• Do not place the
appliance directly below
an air conditioner to
prevent condensation
from dripping onto the
appliance.
• Make sure all filters
are properly installed
before you switch on the
appliance.
• Only use the original
Philips filters specially
intended for this
appliance. Do not use any
other filters.
• Combustion of the filter
may cause inreversible
human hazard and/or
jeopardize other lives. Do
not use the filter as fuel or
for similar purpose.
• Avoid knocking against
the appliance (the air inlet
and outlet in particular)
with hard objects.
• Always lift or move the
appliance by the handle
on back side of the
appliance.
3EN
• Do not insert your fingers
or objects into the air
outlet or the air inlet to
prevent physical injury
or malfunctioning of the
appliance.
• Do not use this appliance
when you have used
indoor smoke-type insect
repellents or in places
with oily residues, burning
incense, or chemical
fumes.
• Do not use the appliance
near gas appliances,
heating devices or
fireplaces.
• Always unplug the
appliance after use
and before cleaning,
or carrying out other
maintenance or replacing
the filters.
• Do not use the appliance
in a room with major
temperature changes,
as this may cause
condensation inside the
appliance.
• To prevent interference,
place the appliance at
least 2 meters away from
electrical appliances that
use airborne radio waves
such as TVs, radios, and
radio-controlled clocks.
• The appliance is only
intended for household
use under normal
operating conditions.
• Do not use the appliance
in wet surroundings or in
surroundings with high
ambient temperatures,
such as the bathroom,
toilet, or kitchen.
• The appliance does
not remove carbon
monoxide (CO) or radon
(Rn). It cannot be used
as a safety device in
case of accidents with
combustion processes
and hazardous chemicals.
• If you need to move the
appliance, disconnect the
appliance from the power
supply first.
• Do not move the
appliance by pulling its
power cord.
• Always cleanse your
hands after changing the
filters.
4 EN
English
2 Your air purifier
Controls overview (g.b)
Congratulations on your purchase, and
welcome to Philips!
To fully benefit from the support that
Philips offers, register your product at
www.philips.com/welcome.
Product overview (g.a)
A Air outlet
B Control panel
C Air quality light
D Air quality sensors
NanoProtect HEPA filter
E
(FY2422)
NanoProtect Active Carbon filter
F
(FY2420)
G Pre-filter
H H1, H2 and H3 air inlets
I Front panel
J On/Off button
K Light dimming button
L Auto mode button
M Display screen
N General mode icon
O Allergen mode icon
P Bacteria & Virus mode icon
Q Wi-Fi indicator
R Fan speed button
S Timer button
T Reset button
5EN
3 Getting started
Installing the lters
Note
• Make sure the air purifier is unplugged
from the electrical outlet before
installing the filters.
• Make sure the side of the filter with the
tag is pointing towards you.
1 Pull the bottom part of the front
panel to remove it from the air
purifier (fig.c).
2 Press the two clips down (1) and
pull the pre-filter towards you (2)
(fig.d).
3 Remove all filters (fig.e).
4 Remove all packaging materials
from the filters (fig.f).
5 Place the thick HEPA filter (FY2422)
into the air purifier and then the
thin AC (activated carbon) filter
(FY2420) (fig.g). The model
numbers are shown on each filter.
6 Attach the pre-filter back into the
air purifier (fig.h).
Note
• Make sure the side with the two clips
is pointing towards you, and that all
hooks of the pre-filter are properly
attached to the purifier.
7 Reattach the front panel by pressing
the top part of the panel onto the
top of the air purifier (1). Then,
gently push the panel against the
body of the air purifier (2) (fig.i).
8 Wash your hands thoroughly after
installing filters.
Wi-Fi connection
Setting up the Wi-Fi connection
for the rst time
1 Download and install the Philips
"Clean Home+" app from the
App Store or Google Play.
2 Put the plug of the air purifier in the
power socket and touch to turn
on the air purifier.
» The Wi-Fi indicator blinks
orange for the first time.
3 Make sure that your smartphone or
tablet is successfully connected to
your Wi-Fi network.
4 Launch the "Clean Home+" app and
click on "Connect a New Device"
or press the "+" button on the top
of the screen. Follow the onscreen
instructions to connect the air
purifier to your network.
5 After the successful pairing and
connection, the Wi-Fi indicator
will light up white. If pairing
is not successful, consult the
troubleshooting section, or the
help section in the "Clean Home+"
app for extensive and up-to-date
troubleshooting tips.
6 EN
English
Note
• This instruction is only valid when
the air purifier is being set up for the
first time. If the network has changed
or the setup needs to be performed
again, consult section "Reset the Wi-Fi
connection" on page 7.
• If you want to connect more than
one air purifier to your smartphone
or tablet, you have to do this one by
one. Complete the set up of one air
purifier before you turn on the other air
purifier.
• Make sure that the distance between
your smartphone or tablet and the air
purifier is less than 10 m without any
obstructions.
• This app supports the latest versions
of Android and iOS. Please check
www.philips.com/cleanhome for the
latest update of supported operating
systems and devices.
Reset the Wi-Fi connection
Note
• This applies when the default network
to which your purifier is connected has
changed.
• Reset the Wi-Fi connection when your
default network has changed.
1 Put the plug of the air purifier in the
power socket and touch to turn
on the air purifier.
2 Touch and simultaneously for
3 seconds until you hear a beep.
» The air purifier goes to pairing
mode.
» The Wi-Fi indicator blinks
orange.
3 Follow the steps 4-5 in "Setting up
the Wi-Fi connection for the first
time" section.
7EN
4 Using the air
Turning on and o
purifier
Understanding the air
quality light
Indoor Allergen Index (IAI) is a
real-time numerical display that
provides visual and immediate feedback
on indoor allergen level. It indicates
potential indoor allergen risk level
which is converted from indoor particle
pollutants concentration. Higher IAI
means higher risk.
IAI Air quality
light color
1-3 Blue Good
4-6 Blue-violet Fair
7-9 Red-purple Poor
10-12 Red Very poor
The air quality light automatically goes
on when the air purifier is switched on,
and lights up all colors in sequence.
After approximately 30 seconds, the
air quality sensors select the color that
corresponds to the surrounding air
quality of airborne particles.
Air quality
level
Note
• Always place the air purifier on a
stable, horizontal, and level surface
with the front of the unit facing away
from walls or furniture.
• For optimum purification performance,
close doors and windows.
• Keep curtains away from the air inlet or
air outlet.
1 Put the plug of the air purifier in the
wall outlet.
2 Touch to switch on the air purifier
(fig.j).
» The air purifier beeps.
» The air purifier operates under
the allergen mode by default.
» When the air purifier is warming
up, " " displays on the
screen. After measuring the
particulate matter only in the
air, the air purifier shows the IAI
level and operates in the auto
mode with displayed on the
screen (fig.k).
» After measuring the air
quality for approximately
30 seconds, the air quality
sensor automatically selects
the appropriate air quality light
color.
3 Touch and hold for 3 seconds to
switch off the air purifier.
8 EN
Note
• If the air purifier stays connected to
the electrical outlet after turning OFF,
the air purifier will operate under the
previous settings when turned ON
again.
English
Changing the Auto mode
setting
You can choose the Allergen mode
( ), the General mode ( )or the
Bacteria & Virus mode ( ).
Allergen mode
The extra-sensitive allergen mode
is designed to react to even a small
change in allergen levels in the
surrounding air.
• Touch the Auto mode button to
select the Allergen mode (fig.l).
» Auto (A) and display on the
screen.
Changing the fan speed
In addition to the Auto modes, there are
several fan speeds available.
When using the manual fan speed
settings, the purifier will still monitor the
air quality, but it will not automatically
adjust the fan speed if it detects
changes in the air quality.
Sleep (SL)
In sleep mode, the air purifier operates
quietly on a very low speed.
• Touch the fan speed button to
select the sleep mode (SL) (fig.o).
Note
General mode
A smart auto-setting that automatically
adjusts the air purifier’s settings to the
ideal level.
• Touch the Auto mode button to
select the General mode (fig.m).
» Auto (A) and display on the
screen.
Bacteria & Virus mode
The bacteria & virus mode boosts the
airflow to quickly reduce bacteria &
viruses.
• Touch the Auto mode button to
select the Bacteria & Virus mode
(fig.n).
» Auto (A) and display on the
screen.
• All lights will go off in sleep mode.
• You can turn on the lights manually by
touching the light dimming button .
Manual
• Touch the fan speed button
repeatedly to select the fan speed
you need (fig.p).
Turbo (t)
In turbo mode, the air purifier operates
on the highest speed.
• Touch the fan speed button to
select the turbo mode (t) (fig.q).
9EN
Setting the timer
With the timer, you can have the air
purifier operate for a set number of
hours. When the set time has elapsed,
the air purifier will automatically switch
off.
• Touch the timer button
repeatedly to choose the number
of hours you want the air purifier to
operate (fig.r).
» The timer is available from 1 to
12 hours.
To deactivate the timer, touch the timer
button repeatedly until "---"displays
on the screen.
Note
• If you set the timer once, next time
you use the timer, it starts from the
previous setting time.
Using the light on/o
function
Switching the display
mode
The air purifier has dual display mode,
IAI display and PM2.5 display.
Note
• The air purifier operates in IAI display
mode by default.
1 Touch the light dimming button
for 3 seconds to switch to PM2.5
display mode (Fig.s).
» blinks twice.
» The actual PM2.5 level displays
on the screen.
2 Touch the light dimming button
for 3 seconds again to switch back
to IAI display mode (Fig.t).
» blinks twice.
» The IAI level displays on the
screen.
With the light dimming button, you can
switch on or off the air quality light,
the display screen and the function
indicator if desired.
1 Touch the light dimming button
once, the air quality light will be
dimmed.
2 Touch the light dimming button
again, the air quality light will go off.
3 Touch the light dimming button
for the third time, all lights will be on
again.
10 EN
Loading...
