Philips 84PFL8830 Specifications

Philips 8000 series
Smart TV with Ambilight
Spectra 3 and Perfect Pixel
HD

•84"

•Polarized 3D

84PFL8830

Be part of the action!

Philips PFL8830 has Ambilight and 3D for a truly immersive movie experience. Share &
enrich this experience as Smart TV puts your living room in the center of the online
world.

Best picture quality

• Ambilight Spectra 3 for an immersive viewing experience

• Perfect Pixel High Definition

• PMR 400

•4K2K

Easy connectivity

• USB for fantastic multimedia playback

• WiFi Built-In

Great convenience

• EasyLink: easy control of TV & connected device via HDMI CEC

Smart TV with Ambilight Spectra 3 and Perfect Pixel HD

84" Polarized 3D

84PFL8830/T3

Specifications

Accessories

• Included accessories: 2 x AAA Batteries, 3D
glasses, 4G USB x1, Distribution wire, Power cord,
Quick start guide, Remote Control, RF DC
isolation x2, Table top stand, User Manual,
Warranty Leaflet

• User Manual: Simplfied Chinese

Connectivity

• USB: USB 2.0 x 3

• EasyLink (HDMI-CEC): System standby, System

o (menu language), EasyLink

inf

•AV 1: CVBS with audio L+R (Rear)

•AV 2: CVBS with audio L+R (Rear)

• Component Video 1: YPbPr + L/R audio (Rear)

• PC input: 3.5mm mini audio jack(Rear), D-sub

r)

(Rea

• TV antenna: 75 Ohms (IEC type) (Rear)

•Side: HDMI x4

• AV OUT (@ side): Audio L/R out

• headphone: Headphone out 3.5 mm jack

Convenience

• Child Protection: Child Lock+Parental Control

• Clock: Sleep Timer

• Ease of Use: Auto Volume Leveller (AVL),

yLink, Smart Picture, Smart Sound, On Screen

Eas
Display, Side Control

• Ease of Installation: Autos
Digital Tuning

• On-Screen Display languages
Chinese

• Connection Enhancement: Easy link

• Remote control: TV remote control

• Screen Format Adjustments: 4:3, Movie expand

:9, Movie expand 16:9, Subtitle Zoom, Super

14
Zoom, Widescreen

Dimensions

• Compatible wall mount: VESA 600 x 400 mm

Multimedia Applications

• Multimedia connections: USB

• Playback Formats: MP3, Photo(JPEG), AVI, H.264/

-4 AVC, MPEG1, MPEG2, MPEG4, RMVB

MPEG
(RealMedia var. bitrat)

•Memory Card Types: SD

tore, Fine Tuning, PLL

: English, Simplified

Picture/Display

• Aspect ratio: 16:9 widescreen

• Picture enhancement: 3/2 - 2/2 motion pull down,
2D/3D no
Noise Reduction, Dynamic contrast enhancement,
Sharpness Adjustment, Color Enhancement, 400
PMR, 720p 50/60Hz processing

• Display screen type: Active Matrix LCD

• Diagonal screen size: 84 inch / 213 cm

ise reduction, 3D Combfilter, Digital

Power

• Ambient temperature: 5 °C to 40 °C

• Mains power: 220-240V;50/60Hz

• Standby power consumption: <0.5W

Sound

• Sound Enhancement: Auto Volume Leveller,
Incredible Surround

• Sound System: Mono, Stereo

• Output power (RMS): 2 x 15 W + 2 x 20W

fer

Woo

Supported Display Resolution

• Computer formats
Resolution Refresh rate
640 x 480 60Hz
800 x 600 60Hz
1024 x 768 60Hz
1280 x 1024 60Hz
1280 x 720 60Hz
1280 x 768 60Hz
1920 x 1080 60Hz
1360 x 768 60Hz

deo formats

• Vi
Resolution Refresh rate
480i 60Hz
480p 60Hz
576i 50Hz
576p 50Hz
720p 50, 60Hz
1080i 50, 60Hz
1080p 24/25/30/50/60Hz

Tuner/Reception/Transmission

• TV system: PAL I, PAL D/K

• Video Playback: PAL, NTSC

• Aerial Input: 75 Ohms (IEC type) (Rear)

• Tuner bands: UHF, VHF

• Number of Preset Channels: 200

•

Highlights

Ambilight Spectra 3

Add a new dimension to your viewing experience
with Ambilight Spectra 3. This patented Philips
technology enlarges the screen further by projecting
a glow of light from the back of the screen onto the
surrounding wall. Ambilight adjusts automatically the
colour and brightness of the light surrounding the TV
to match with the picture, creating an immersive
viewing experience. With Ambilight Spectra 3
movies truly come to life!

PMR 400

400Hz Perfect Motion Rate (PMR) creates extreme
motion sharpness for clear and vibrant images in fast
action movies. The new Philips PMR standard shows
the combined visible effect of the fastest panel
refresh rate, Perfect Natural Motion and unique
processing formula, for unprecedented motion
sharpness.

4K2K

4K2K high resolution panel is four times the clarity
of Full HD TV, ultra-HD resolution allows you to
experiences TV watching at its highest standard.

Issue date 2013-08-17

Version: 1.0.1

12 NC: 8670 001 07362
EAN: 69 59033 85035 6
