6863XL
Cordless/Corded Razor
3
ENGLISH 4
ESPAÑOL 20
6863XL
4 ENGLISH
IMPORTANT SAFETY INSTRUCTIONS
When using an electric razor, basic safety precautions should always be followed, including the following:
Read all instructions before using this appliance.
DANGER
To reduce the risk of electric shock:
1.Do not reach for a razor that has fallen into water. Unplug immediately.
2.Do not use razor while bathing or in a shower.
3.Do not place or store razor where it can fall or be pulled into a tub or sink. Do not place in or drop into water or other liquid.
4.Always unplug this razor from the electrical outlet immediately after use, except when razor is (re)charging.
5.Unplug this razor before cleaning.
6.When discarding razor, unplug razor and remove rechargeable batteries. See Battery Removal Instructions.
WARNING
To reduce the risk of burns, fire, electric shock, or injury to persons:
1.Close supervision is necessary when this razor is used by, on, or near children or invalids.
2.Use this razor for its intended household use as described in this manual. Do not use attachments not recommended by Philips Electronics North America Corporation.
3.Never operate this razor if it has a damaged cord or plug, if it is not working properly, if it has been dropped or damaged, or dropped into water. Return the razor to an Authorized Norelco Service Location for examination and repair.
ENGLISH 5
4.Keep the razor and cord away from heated surfaces.
5.Never drop or insert any object into any opening.
6.Do not charge or plug in razor outdoors or operate where aerosol (spray) products are being used or where oxygen is being administered.
7.Do not use this razor with a damaged or broken comb, as facial injury may occur.
8.Always attach plug to razor first, then into outlet. Be certain that
plug is inserted firmly into razor, up to mark indicated on plug.To disconnect, turn razor off then remove plug from outlet.
10.Never put razor in direct sunlight or store in a pouch at a temperature above 140ºF.
11.To prevent possible damage to the cord, do not wrap cord around the razor.
SAVE THESE
INSTRUCTIONS
IMPORTANT
Your razor contains NICKEL-CADMIUM RECHARGEABLE BATTERIES. See Battery Removal instruction sheet for battery disposal information.
6 ENGLISH
60 - DAY MONEY-BACK GUARANTEE
To enjoy the closest and most comfortable shave from your new Norelco Men’s Razor, the razor should be used exclusively for 3 weeks. This allows your hair and skin enough time to adapt to the Norelco Shaving System. If, after that period of time, you are not fully satisfied with your Norelco Men’s Razor, send the product back and we’ll refund you the full purchase price.
The razor must be shipped prepaid by insured mail, insurance prepaid, and have the sales slip, indicating purchase price and the date of purchase, enclosed. The razor must be postmarked no later than 60 days after the date of purchase. Norelco reserves the right to verify the purchase price of the razor and limit refunds not to exceed suggested retail price.
Send dated sales slip, your complete name and address as indicated below, and the razor, prepaid to:
Norelco Consumer Products Company
A Division of Philips Electronics North America Corporation
450 North Medina Road, Dock 16
Roselle, IL 60172-2329
Please allow 4-6 weeks for delivery of check. (Please Print)
Name_________________________________________________________
Address________________________________________________________
City___________________________________________________________
State_____Zip__________________________________________________
Daytime Telephone No. (____)_____________________________________
AREA CODE
Email Address___________________________________________________
REASON FOR RETURNING:______________________________________
______________________________________________________________
______________________________________________________________
______________________________________________________________
______________________________________________________________
______________________________________________________________
______________________________________________________________
ENGLISH 7 |
|
Table of Contents |
|
Features......................................................... |
8-9 |
LED Battery Charge Meter ....................... |
10 |
Charging ................................................... |
10-12 |
Recharging...................................................... |
12 |
Put It To The Test & Shaving Tips ........ |
12-13 |
How To Shave With An |
|
Electric Razor.......................................... |
13-14 |
Trimming......................................................... |
14 |
Cleaning.................................................... |
14-18 |
Assistance....................................................... |
18 |
Accessories.................................................... |
18 |
Battery Removal............................................ |
18 |
Warranty............................................ |
Back side |
Spanish ............................................................ |
20 |
8 ENGLISH
Features
Reflex Plus
Shaving System
Razor Head Assembly
Protective Razor
Head Cap
Individually Floating Heads
Razor Head Release
Button
•Hair Chamber captures shaven hair
Electronic ON/OFF
Button
LED Battery Charge
• Indicates the amount of of charge remaining in batteries
How the Norelco Lift and Cut® Patented
Shaving System Makes Close Comfortable:
ENGLISH 9
Full Width Pop-Up
Trimmer
Automatic Worldwide Voltage 100V to 240V AC
Cleaning Brush
Travel/Storage Pouch
Rechargeable-Initial 4- hour Full Charge for up to 45 minutes of cordless shave time
1-Hour Quick Charge
Cord/Cordless-To shave with or without a cord
Full 2-Year Warranty
60-Day Money-Back
Guarantee
Groove channels beard |
Lifter raises hair |
Blade cuts hair which |
closer to cutting system |
|
then drops below skin level |
10 ENGLISH
LED Battery Charge Meter
The Meter provides the following information:
C LED Battery Charge Meter
The number (percentage) on the display indicates approximately how much power is left in the
batteries.
Low battery Indicator
If the batteries run low the "20" Section on the display lights up red.When you turn the razor OFF, the red light will blink for approximately 4 seconds.
Charging Indicator
When you charge razor, the "20" Section on the display turns red. After approximately 3 minutes, it will then turn green and blink. As charging continues, more and more sections of the display meter will briefly blink green and light up to indicate what level (percentage) of the batteries have been charged.
Full Charge Indicator
When the batteries have been fully charged, all the "blocks" on the display will light up green.
Charging
Battery performance is best if you recharge only when the batteries are (almost) completely empty.
ENGLISH 11
Charging or recharging at temperatures below 40cF or higher than 95cF adversely affects lifetime of batteries.
Continuously recharging or continuously using as a corded razor will reduce life of batteries.
You may also shave using the charging plug provided.This razor will not recharge while being used corded.
Recharge only when block "20" lights up red.
|
C |
|
Connect cord to razor. Connect charging |
||
|
1 |
||||
|
|||||
|
|||||
|
|||||
|
|
|
|
plug into any 120V to 240 V AC outlet. Use |
|
|
|
C |
|
only the cord provided. |
|
|
|
|
As you charge razor, the "20" Section on |
||
2 |
|||||
|
|
|
|
the display turns green. If there is enough |
|
|
|
|
|
power for one shave, this green LED will |
|
|
|
|
|
begin blinking. |
|
|
|
|
|
||
|
|
C |
|
As charging continues, more and more |
|
3 |
|||||
|
|
|
|
sections of the display meter will briefly |
|
|
|
|
|
blink green and light up to indicate what |
|
|
|
|
|
level (percentage) of the batteries have |
|
|
|
|
|
been charged. |
|
|
|
|
|
You can shave immediately (corded).
An adaptor plug may be necessary for cord usage in some foreign countries.
Use an attachment plug adaptor of the proper configuration for power outlet.Your new razor will automatically convert internally to work on 100V to 240V AC Systems.
Do not charge razor in pouch.
12 ENGLISH
First time charging and recharging after nonuse for 1 month or more requires a full 4 hours.When batteries are fully charged, all the "blocks" on the display will light up green.
Recharging
1First time charging requires 4 hours.After initial charge, recharging requires approximately 1 hour.
2Disconnect the charging plug from outlet. Do not keep razor permanently plugged into outlet.
Quick Charge
When batteries are totally depleted, recharging the razor for approximately 6 minutes gives enough energy for a 3 minute cordless shave.
Put It To The Test & Shaving Tips
21 Day Trial and Conversion Process. It is a fact that your skin and beard need time to adjust to any new shaving system.
Use your new razor exclusively for 3 weeks to fully enjoy the closeness of a Norelco shave.
At first you may not get as close a shave as you expect, or your face may even become slightly irritated.This is normal since your beard and skin will need time to adjust. Invest
ENGLISH 13
3 weeks and you'll soon experience the full joy of your new razor.
Stick with it! If you alternate shaving methods during the adjustment period, it may make it more difficult to adapt to the Norelco shaving system.
If you are not convinced after 21 days, Norelco will refund you the full purchase price, guaranteed.
How To Shave With An Electric Razor
Use this razor for its intended household use as described in this manual.
Shaving with a clean, dry face gives the best results.
C 1 Turn razor ON. Shave against the direction of beard growth using both straight and circular movements.
2 |
Stretch your skin with your free hand so |
|
blades can lift and cut whiskers. Gently |
|
press razor to skin, so the floating heads |
|
can follow the contours of your face. DO |
|
NOT press too hard.Too much pressure |
|
can pinch the skin into the heads. |
3 |
Turn razor OFF. |
C 4 |
Put the protective razor head cap on the |
|
razor to protect razor heads. |
