Philips 70PUT7805/56, 65PUT7805/56, 55PUT7805/56 user manual
Register your product and get support at
www.philips.com/TVsupport
7805 series
User Manual
55PUT7805
65PUT7805
70PUT7805
Contents
1 Get Support 3
1.1 Identify and Register your TV 3
1.2 TV Help and User Manual 3
1.3 Consumer Care / Repair 3
2 Software 4
2.1 Update Software 4
2.2 Software Version 4
3 Quick Guide 5
3.1 Remote Control 5
3.2 Pair Your Remote Control to TV 6
3.3 IR sensor 7
3.4 Joystick - Local Control 7
4 Setting Up 8
4.1 Read Safety 8
4.2 TV Placement 8
4.3 Turn on TV 8
5 Connections 10
5.1 Connectivity guide 10
5.2 Antenna 10
5.3 Video Device 10
5.4 Audio Device 10
5.5 Mobile Device 11
5.6 Other Device 12
5.7 Bluetooth 12
6 Switch Source 14
6.1 Source List 14
6.2 Rename Device 14
7 Channels 15
7.1 About Channels and Switch Channels 15
7.2 Install Channel 15
7.3 Channel List 18
7.4 Favourite Channels 19
7.5 Text / Teletext 20
8 TV Guide 22
8.1 What You Need 22
8.2 Using the TV Guide 22
9 Recording and Pause TV 24
9.1 Recording 24
9.2 Pause TV 25
10 Videos, Photos and Music 26
10.1 From a USB Connection 26
10.2 From a Computer or NAS 26
10.3 Photos 26
10.4 Videos 27
10.5 Music 27
11 Open TV Setting Menus 28
11.1 Home Menu Overview 28
11.2 Frequent Settings and All settings 28
11.3 All Settings 28
12 Wireless and Networks 39
12.1 Home Network 39
12.2 Connect to Network 39
12.3 Wireless and Network Settings 39
13 Smart TV 41
13.1 Setup Smart TV 41
13.2 Smart TV Start Page 41
13.3 App Gallery 41
13.4 Video on Demand 41
14 Ambilight 42
14.1 Ambilight Style 42
14.2 Ambilight+hue 42
14.3 Advanced Ambilight Settings 43
14.4 Lounge Light Mode 44
15 Netflix 45
16 Amazon Prime Video 46
17 YouTube 47
18 Alexa 48
18.1 About Alexa 48
18.2 Using Alexa 48
19 Environmental 50
19.1 End of Use 50
20 Specifications 51
20.1 Power 51
20.2 Reception 51
20.3 Display Resolution 51
20.4 Supported Input Resolution - Video 51
20.5 Supported Input Resolution - Computer 51
20.6 Sound 51
20.7 Multimedia 52
20.8 Connectivity 52
21 Troubleshooting 53
21.1 Tips 53
21.2 Switch On 53
21.3 Remote Control 53
21.4 Channels 53
21.5 Picture 54
21.6 Sound 55
21.7 HDMI - UHD 55
21.8 USB 55
21.9 Wi-Fi and Internet 55
21.10 Wrong Menu Language 56
22 Safety and Care 57
22.1 Safety 57
22.2 Screen Care 58
23 Terms of Use 59
24 Copyrights 60
24.1 HDMI 60
24.2 Dolby Audio 60
24.3 Dolby Vision and Dolby Atmos 60
24.4 DTS-HD (italics) 60
24.5 Wi-Fi Alliance 60
24.6 Other Trademarks 60
25 Open Source 61
25.1 Open Source Software 61
25.2 Open Source License 61
26 Disclaimer regarding services and/or
software offered by third parties 65
Index 66
2
1
1.3
Get Support
1.1
Identify and Register your TV
Identify your TV - TV model number and serial
number
You might be asked to provide the TV product model
number and serial number. Find these numbers on
the packaging label or on the type label on the back
or bottom of the TV.
Register your TV
Register your TV and enjoy a range of benefits
including full support (including downloads),
privileged access to information about new products,
exclusive offers and discounts, the chance to win
prizes and even participate in special surveys about
new releases.
Go to www.philips.com/TVsupport
Consumer Care / Repair
For support and repair, call the Consumer Care
hotline in your country. Our service engineers will take
care of a repair, if necessary.
Find the telephone number in the printed
documentation that came with the TV.
Or consult our
website www.philips.com/TVsupport and select
your country if needed.
TV model number and serial number
You might be asked to provide the TV product model
number and serial number. Find these numbers on
the packaging label or on the type label on the back
or bottom of the TV.
Warning
Do not attemp to repair the TV yourself. This may
cause severe injury, irrepairable damage to your TV or
void your warranty.
1.2
TV Help and User Manual
(Home) > Settings > Help
You can use Help function to diagnose and get more
information about your TV.
• TV information - View the Model name, Serial
number and Software version of your TV.
• How to - You can see instructions on how to install
channels, sort channels*, update TV software,
connect external devices and use Smart functions on
your TV.
• Check the TV - You can check if the picture, sound,
Ambilight** are working fine during playing a short
video clip.
• Check the network - Check the network connection.
• Update software - Check available software
updates.
• User manual - Read the user manual for TV
information.
• Troubleshooting - Find a solution for frequent ask
questions.
• Factory settings - Reset all settings to factory
settings.
• Reinstall TV - Reinstall and redo the complete TV
installation.
• Contact info - Show the telephone number or web
address for your country or region.
* Sorting channels is only applicable for certain
countries.
** Ambilight setting is only for models which support
Ambilight function.
3
2
Software
2.1
Update Software
Search for Updates
Update from Internet
(Home) > Settings > Update software > Search
for updates > Internet (Recommended)
Look for a software update yourself.
back on again. Please wait.
Do not . . .
• use the remote control
• remove the USB memory device from the TV
• press twice
• press the power switch on the TV
The TV switches itself off (for 10 seconds) and then
back on again. Please wait.
The TV software has been updated. You can use the
TV again.
To prevent an accidental update of the TV software,
delete the autorun.upg file from the USB memory
device.
• If the TV is connected to the Internet, you may
receive a message to update the TV software. You
need a high-speed (broadband) Internet
connection. If you receive this message, we
recommend you to carry out the update.
• During the software update, there is no picture and
the TV will switch off and on again. This might happen
several times. The update can take a few minutes.
• Wait until the TV picture comes back up. Do not
press the power switch on the TV or on the
remote control during the software update.
Update from USB
(Home) > Settings > Update
software > Search for updates > USB
• You need a computer with an high-speed Internet
connection and a USB memory device to upload the
software on the TV.
• Use a USB memory device with 512MB free space.
Make sure that write protection is switched off.
1 - Start the update on TV
Select Update software > Search for updates >
USB, then press OK.
2 - Identify the TV
Insert the USB memory into one of the USB
connections of the TV.
Select Start and press OK. An identification file is
written on the USB memory device.
3 - Download the TV software
- Insert the USB memory into your computer.
- On the USB memory device, locate the
file update.html and double click it.
- Click on Send ID.
- If new software is available, download the .zip file.
- After the download, unzip the file and copy the
file autorun.upg onto the USB memory device.
- Do not place this file in a folder.
4 - Update the TV software
Insert the USB memory into the TV again. The update
starts automatically.
The TV switches itself off for 10 seconds and then
Local Updates
(Home) > Settings > Update
software > Search for updates > USB > Local
updates.
For dealers and expert users.
Look for OAD updates (Over-the-air
Download)
(Home) > Settings > Update
software > Search for updates > Look for OAD
updates.
Scan to search for an Over-the-air software update.
Note:
OAD is for Thailand, Malaysia, and Vietnam only.
2.2
Software Version
(Home) > Settings > Update
software > Current software info
To view the current TV software version.
4
3
Quick Guide
Ambilight.
4 - INFO
To open or close programme info.
3.1
Remote Control
Batteries and Cleaning
Replace batteries
If the TV does not react on a key press on the remote
control, the batteries might be empty.
To replace the batteries, open the battery
compartment on the back of the remote control.
1 - Slide the battery door in the direction shown by
the arrow.
2 - Replace the old batteries with 2
type AAA-1.5V batteries. Make sure the + and the ends of the batteries line up correctly.
3 - Reposition the battery door and slide it back until
it clicks.
• Remove the batteries if you are not using the remote
control for a long time.
• Safely dispose of your old batteries according to the
end of use directions.
Cleaning
Your remote control is treated with a scratch-resistant
coating.
To clean the remote control, use a soft damp cloth.
Never use substances such as alcohol, chemicals or
household cleaners on the remote control.
Key Overview
Top
5 - SOURCES / PAIR
• To open or close the Sources menu.
• Long press to pair the remote control to the TV.
6 - Alexa
To start Alexa voice control operations.
Middle
1 - OK key
To confirm a selection or setting. To open the channel
list while watching TV if Interactive Service is not
available.
2 - BACK
To close a menu without changing a setting.
3 - Playback and Record
• Play , to playback.
• Pause , to pause playback.
• Stop , to stop playback.
• Rewind , to rewind.
• Fast forward , to go fast forward.
• Record , to start recording.
1 - Standby / On
To switch the TV on or back to Standby.
2 - VOICE microphone
Speak near this hole during voice search.
3 -
To select one of the Ambilight style or switch off
4 - Colour keys
Direct selection of options. Blue key , opens Help.
5 - Arrow / navigation keys
To navigate up, down, left or right.
6 - Home
To open the Home menu.
7 - OPTIONS
To open or close the Options menu.
Bottom
5
1 - Character
Character position.
2 - Delete
To delete input characters.
1 -
To open the Netflix App directly. With the TV switched
on or from standby.
• If you have a Netflix membership subscription, you
can enjoy Netflix on this TV. Your TV must be
connected to the Internet.
• To open Netflix, press to open the Netflix
App. You can open Netflix immediately from a TV in
standby.
www.netflix.com
2 - Mute / Volume
Press in middle to mute the sound or to restore it.
Prese + or - to adjust the volume level.
3 - Number keys
To select a channel directly.
4 - TV Guide / Channel list
To open or close the TV Guide. Long press to open
the channel list.
5 - - EXIT
Press in middle to switch back to watch TV. To stop
an interactive TV application. Prese + or - to switch to
the next or previous channel in the channel list. To
open the next or previous page in Text/Teletext.
6 - SMART TV
To open the Smart TV start page.
3 - Shift
To type uppercase characters.
4 - Fn key
To type a number or punctuation character.
5 - Spacebar
6 - Navigation and OK
Writing Text
With the keyboard on the back of the remote control,
you can write text in any text field on screen.
To write text…
1 - Select a text field if it is not yet selected.
2 - Turn the remote control keyboard facing upwards
to activate the keyboard keys. Hold the remote
control with two hands and type with both thumbs.
3 - To hide the on screen keyboard, press BACK.
4 - Press OK to confirm the text.
3.2
Pair Your Remote Control to
TV
7 - YouTube
To open the YouTube App directly.
8 - TEXT
To open or close Text/Teletext.
Keyboard
Overview
Overview of a keyboard
This remote control uses both Bluetooth and IR
(infrared) to send its commands to the TV.
• You can use this remote control via IR (infrared) for
most operations.
• To use Alexa voice control operations, you need to
pair (link) the TV with the remote control.
When you started the initial TV installation, the TV
invited you to long press the PAIR key, and by
doing so, the pairing was done.
Note:
1 - Once the remote control has entered pairing
mode successfully, the blue LED indicator ring around
the microphone on the front side of the remote
control starts blinking.
2 - The remote control must be kept close to the TV
(within 1m distance) during pairing in order to ensure
6
success.
3 - If the TV does not launch the Alexa voice
control operations when press Alexa, pairing was
unsuccessful.
4 - It is advisable to wait until the set has fully started
up and launched all background processes before
pairing mode is entered as the toast message
containing further instructions may appear too late,
thereby negatively impacting the pairing procedure.
Pairing or pairing again
If the pairing with the remote control was lost, you
can pair the TV with the remote control again.
You can simply long press
the PAIR key (approximate for 3 seconds) for
pairing.
Alternatively, go (Home) > Settings > All settings
> Wireless and network > Remote control > Pair
remote control, then follow the on-screen
instructions.
A message appears when the pairing is successful.
3.4
Joystick - Local Control
Keys on TV
If you lost the remote control or its batteries are
empty, you can still do some basic TV operations.
To open the basic menu…
Remote Control Software
(Home) > Settings > All settings > Wireless and
network > Remote control > Remote control info
Once the remote control is paired, you can check the
current remote control software version.
(Home) > Settings > All settings > Wireless and
network > Remote control > Update remote
control software
Check available remote control software for updates.
3.3
IR sensor
The TV can receive commands from a remote control
that uses IR (infrared) to send commands. If you use
such a remote control, always make sure you point
the remote control at the infrared sensor on the front
of the TV.
1 - With the TV switched on, press the joystick key on
the bottom of the TV to bring up the basic menu.
2 - Press left or right to
select Volume, Channel or Sources.
Select Demo, to start a demo movie.
3 - Press up or down to adjust the volume or tune to
the next or previous channel. Press up or down to go
through the list of sources, including the tuner
selection.
The menu will disappear automatically.
Warning
Do not put any objects in front of IR sensor of the TV,
it may block the IR signal.
7
4
Wall Mounting
Setting Up
4.1
Read Safety
Read the safety instructions first before you use the
TV.
To read the instructions, in Help > User manual,
press the colour key Keywords and look
up Safety and Care.
4.2
TV Placement
Tips on Placement
• Position the TV where light does not shine directly
on the screen.
• Position the TV up to 15 cm away from the wall.
• The ideal distance to watch Ultra HD TV is 2 to 5
times of its screen height. When seated, your eyes
should be level with the centre of the screen.
Your TV is also prepared for a VESA-compliant wall
mount bracket (sold separately).
Use the following VESA code when purchasing the
wall mount . . .
• 55PUT7805
VESA MIS-F 300x200, M6 (Minimum 10 mm,
Maximum 15 mm)
• 65PUT7805
VESA MIS-F 400x200, M6 (Minimum 10 mm,
Maximum 20 mm)
• 70PUT7805
VESA MIS-F 400x200, M8 (Minimum 12 mm,
Maximum 20 mm)
Preparation
Note:
Please keep the TV away from dust-producing
sources such as stoves. It is suggested to clean the
dust regularly to avoid getting dust into the TV.
TV Stand
You can find the instructions for mounting the TV
stand in the Quick Start Guide that came with the TV.
In case you lost this guide, you can download it
from www.philips.com/TVsupport.
Use the model number of the TV to look for
the Quick Start Guide to download.
Make sure that the metal screws, to mount the TV to
the VESA-compliant bracket, go about 10mm deep
inside the threaded bushes of the TV.
Caution
Wall mounting the TV requires special skills and
should only be performed by qualified personnel. The
TV wall mounting should meet safety standards
according to the TVs weight. Also read the safety
precautions before positioning the TV.
TP Vision Europe B.V. bears no responsibility for
improper mounting or any mounting that results in
accident or injury.
4.3
Turn on TV
Connect Power Cable
• Insert the power cable into the POWER connector
on the back of the TV.
• Make sure the power cable is securely inserted in
the connector.
• Make sure that the power plug, in the wall socket, is
accessible at all times.
• When you unplug the power cable, always pull the
plug, never pull the cable.
8
Although this TV has a very low standby power
consumption, unplug the power cable to save energy
if you do not use the TV for a long period of time.
On or Standby
Before you switch on the TV, make sure you plugged
in the mains power in the POWER connector on the
back of the TV.
Switch On
• Press the small joystick key on the bottom of the TV.
Switch to standby
To switch the TV to standby, press on the remote
control. You can also press the small joystick key on
the bottom of the TV.
In standby mode, the TV is still connected to the
mains power but consumes very little energy.
To switch off the TV completely, disconnect the
power plug.
When disconnecting the power plug, always pull the
power plug, never the cord. Ensure that you have full
access to the power plug, power cord and outlet
socket at all times.
9
5
Connections
5.1
Connectivity guide
Always connect a device to the TV with the highest
quality connection available. Also, use good quality
cables to ensure a good transfer of picture and
sound.
When you connect a device, the TV recognizes its
type and gives each device a correct type name. You
can change the type name if you wish. If a correct
type name for a device is set, the TV automatically
switches to the ideal TV settings when you switch to
this device in the Sources menu.
5.2
Antenna
Insert the antenna plug firmly into
the Antenna socket at the back of the TV.
You can connect your own antenna or an antenna
signal from an antenna distribution system. Use an
IEC Coax 75 Ohm RF antenna connector.
Copy protection
HDMI ports support HDCP (High-bandwidth Digital
Content Protection). HDCP is a copy protection signal
that prevents copying content from a DVD disc or Bluray Disc. Also referred to as DRM (Digital Rights
Management).
Composite
CVBS - Composite Video is a standard quality
connection. Next to the CVBS signal adds the Audio
Left and Right signals for sound.
5.3
Video Device
HDMI
An HDMI connection has the best picture and sound
quality.
For best signal quality transfer, use a High speed
HDMI cable and do not use an HDMI cable longer
than 5 m, and also connect devices supporting HDR
on any one of HDMI connections.
5.4
Audio Device
HDMI ARC
All HDMI on the TV have HDMI ARC (Audio Return
Channel).
If the device, typically a Home Theatre System (HTS),
also has the HDMI ARC connection, connect it
to HDMI connection on this TV. With the HDMI ARC
connection, you do not need to connect the extra
audio cable that sends the sound of the TV picture to
the HTS. The HDMI ARC connection combines both
signals.
10
5.5
Mobile Device
Screen Mirroring
About Screen Mirroring
You can view your photos or play your music and
videos from a mobile device on your TV with Screen
Mirroring. The mobile device and the TV should be
within range, which usually means being in the same
room.
Digital Audio Out - Optical
Audio Out - Optical is a high quality sound
connection.
This optical connection can carry 5.1 audio channels.
If your device, typically a Home Theatre System
(HTS), has no HDMI ARC connection, you can use this
connection with the Audio In - Optical connection on
the HTS. The Audio Out - Optical connection sends
the sound from the TV to the HTS.
Headphones
You can connect a set of headphones to
the connection on the side of the TV. The
connection is a mini-jack 3.5mm. You can adjust the
volume of the headphones separately.
Using Screen Mirroring
Switch on Screen Mirroring
Press SOURCES > Screen Mirroring
Share a Screen on TV
1 - Activate Screen mirroring on your mobile device.
2 - On your mobile device, select the TV. (This TV will
be displayed as TV model name)
3 - Select the TV name on your mobile device, after
connection, you can enjoy using Screen Mirroring.
Stop Sharing
You can stop sharing a screen from the TV or from the
mobile device.
From the device
With the application you use to start Screen Mirroring,
you can disconnect and stop watching the screen of
the device on TV. The TV will switch back to the last
selected programme.
From the TV
To stop watching the screen of the device on TV, you
can . . .
• press EXIT to watch a TV broadcast
• press (Home) to start another activity on TV
• press SOURCES to open the Sources menu
and select a connected device.
Block a Device
The first time you receive a request to connect from a
device, you can block the device. The request from
this device and all its requests in the future, will be
ignored.
To block a device…
Select Block… and press OK.
11
Unblock all devices
All previously connected and also blocked devices
are stored in the Screen Mirroring list of connections.
If you clear this list, all blocked devices will be
unblocked.
To unblock all blocked devices…
(Home) > Settings > All settings > Wireless
and networks > Wired or Wi-Fi > Reset Screen
Mirroring connections.
Blocking a previously connected device
If you want to block a device that you previously
connected, you need to clear the Screen Mirroring
connections list first. If you clear this list, you will have
to confirm or block the connection for every device
again.
highly possible latency/lip sync problem may occur.
Apps - Philips TV Remote App
With the TV Remote App, you master your media
around you. Send photos, music or videos to your big
TV screen or watch any of your TV channels live on
your tablet or phone. Look up what you want to
watch on the TV Guide and watch it on your phone or
TV. With the TV Remote App you can use your phone
as a remote control*.
Download the Philips TV Remote App from your
favourite app store today.
The Philips TV Remote App is available for iOS and
Android and is free of charge.
Reset Screen Mirroring connections
All previously connected devices are stored in the
Screen Mirroring list of connections.
To clear all connected Screen Mirroring devices…
(Home) > Settings > All settings > Wireless
and networks > Wired or Wi-Fi > Reset Screen
Mirroring connections.
Screen Delay
The normal delay when sharing a screen with Screen
Mirroring is about 1 second. The delay might be longer
if you are using older devices with less processing
power.
Bluetooth Audio Sink
You can play your music from a mobile device on
your TV with Bluetooth audio sink. The mobile device
and the TV should be within range, which usually
means being in the same room.
5.6
Other Device
USB Flash Drive
You can view photos or play your music and videos
from a connected USB flash drive. Insert a USB flash
drive in one of the USB connections on the TV while
the TV is switched on.
The TV detects the flash drive and opens a list
showing its content.
If the contents list does not appear automatically,
press SOURCES and select USB.
Switch on Bluetooth
Press SOURCES > Bluetooth
Share Audio on TV
1 - Activate Bluetooth on your mobile device.
2 - On your mobile device, select the TV. (This TV will
be displayed as TV model name)
3 - Select the TV name on your mobile device, after
connection, you can play and control the audio via
Bluetooth.
Attention
Bluetooth audio is primarily for audio use only.
Playing video is not recommended since there's
For more information on watching or playing content
from a USB flash drive, in Help, press the colour
key Keywords and look up Photos, Videos and
Music.
5.7
Bluetooth
12
What You Need
4 - Press (left) repeatedly if necessary, to close
the menu.
You can connect a wireless device with Bluetooth® to
this TV – a wireless speaker or headphones.
To play the TV sound on a wireless speaker, you must
pair the wireless speaker with the TV. The TV can only
play the sound on one speaker at a time.
Attention - Audio to Video synchronisation
Many Bluetooth speaker systems have a high, so
called, 'latency'. High latency means that the audio
lags behind the video, causing unsynchronised 'lip
sync'. Before you purchase a wireless Bluetooth
speaker system, inform yourself about the newest
models and look for a device with a low latency
rating. Ask your dealer for advice.
Pairing a Device
Position the wireless speaker within a distance of 5
meters from the TV. Read the user manual of the
device for specific information on pairing and on
wireless range. Make sure the Bluetooth setting on TV
is switched on.
When a wireless speaker is paired, you can select it to
play the TV sound. When a device is paired, you do
not need to pair it again unless you remove the
device.
You can also select connected device ...
1 - Select (Home) > Settings > Audio out and
press OK.
2 - In the list, select the wireless device and press
OK.
Remove a Device
You can connect or disconnect a wireless Bluetooth
device. You can also remove a wireless Bluetooth
device. If you remove a Bluetooth device, the device
will be unpaired.
To remove or disconnect a wireless device…
1 - Select (Home) > Settings > All
settings > Wireless and Networks and press OK.
2 - Select Bluetooth > Remove Bluetooth
device and press OK.
3 - In the list, select the wireless device and
press OK.
4 - Select Disconnect or Remove and press OK.
5 - Select OK and press OK to confirm.
6 - Press (left) repeatedly if necessary, to close
the menu.
To pair a bluetooth device with the TV…
1 - Switch on the bluetooth device and place it within
range of the TV.
2 - Select (Home) > Settings > All
settings > Wireless and Networks and
press (right) to enter the menu.
3 - Select Bluetooth > Search Bluetooth Device,
and press OK.
4 - Select Search and press OK. Follow the
instuctions on screen. You will pair the device with the
TV and the TV will store the connection. You might
need to unpair a paired device first if the maximum
number of paired devices was reached.
5 - Select the type of device and press OK.
6 - Press (left) repeatedly if necessary, to close
the menu.
Select a Device
To select a wireless device…
1 - Select (Home) > Settings > All
settings > Wireless and Networks and press OK.
2 - Select Bluetooth > Search Bluetooth
Device and press OK.
3 - In the list, select the wireless device and
press OK.
13
6
Switch Source
6.1
Source List
• To open the sources menu, press SOURCES .
• To switch to a connected device, select the device
with the arrows (Right) or (Left) and press OK.
• To view the technical information of the connected
device you are watching, press OPTIONS and
select Device info.
• To close the source menu without switching to a
device, press SOURCES again.
6.2
Rename Device
(Home) > Settings > All settings > General
settings > Input sources > Source > Edit
1 - Select one of the device icons and press OK, the
preset name appears in the typing field.
2 - Press (up) to move to the typing field, press
OK, then enter new name using on-screen keyboard.
- Press (red) key to enter with lower-case
- Press (green) key to enter with upper-case
- Press (yellow) key to enter number and
symbol
- Press (blue) key to delete a character
3 - Select Enter when complete the editing.
14
7
channels
Channels
7.1
About Channels and Switch
Channels
To watch TV channels
• Press . The TV tunes to the TV channel you last
watched.
• Press (Home) > TV > Channels and
press OK.
• Press + or - to switch channels.
• If you know the channel number, type in the number
with the number keys. Press OK after you entered
the number to switch channels.
• To switch back to the previously tuned channel,
press BACK .
To switch to a channel from a channel list
• While watching a TV channel, press OK to open the
channel lists.
• The channel list can have several pages with
channels. To view the next or previous page, press
+ or -.
• To close the channel lists without switching
channels, press BACK or EXIT .
Channel icons
After an Automatic channel update of the channel list,
newly found channels are marked with a (star).
If you lock a channel, it will be marked with
a (lock).
Radio channels
If digital broadcasting is available, digital radio
stations are installed during installation. Switch to a
radio channel just like you switch to a TV channel.
This TV can receive digital television standard DVB. TV
may not work properly with some operators of digital
television , non-compliance with requirements of the
standard in full.
7.2
Install Channel
Antenna Install
Manually Search for Channels and Channel Settings
Search for Channels
Update channels
(Home) > Settings > Install
Channels > Antenna installlation > Search for
1 - Select Start now and press OK.
2 - Select Update channels to only add new digital
channels.
3 - Select Start and press OK to update channels.
This can take a few minutes.
Quick reinstall
(Home) > Settings > Install
Channels > Antenna installlation > Search for
channels
1 - Select Start now and press OK.
2 - Select Quick reinstall to install all channels again
with default settings.
3 - Select Start and press OK to update channels.
This can take a few minutes.
Advanced reinstall
(Home) > Settings > Install
Channels > Antenna installlation > Search for
channels
1 - Select Start now and press OK.
2 - Select Advanced reinstall to do a full re-
installation which takes you through each step.
3 - Select Start and press OK to update channels.
This can take a few minutes.
Channel Settings
(Home) > Settings > Install
Channels > Antenna installlation > Search for
channels > Advanced reinstall
1 - Select Start now and press OK.
2 - Select Advanced reinstall to do a full re-
installation which takes you through each step.
3 - Select Start and press OK.
4 - Select the country where you are now and
press OK.
5 - Select Antenna (DVB-T), and select one item
you need to re-install.
6 - Select Digital and analogue channels, Only
digital channels, or Only analogue channels.
7 - Select Settings and press OK.
8 - Press Reset to reset, or press Done when
complete the settings.
Frequency scan
Select the method of searching for channels.
• Quick: select the faster method and use the
predefined settings used by most cable providers in
your country.
• Full: If this results in having no channels installed or
if some channels are missing, you can select the
extended Full method. This method will take more
time to search for and install channels.
• Advanced: If you received a specific network
15
frequency value to search for channels,
select Advanced.
Frequency step size
The TV searches for channels in steps of 8MHz.
If this results in having no channels installed or if
some channels are missing, you can search in smaller
steps of 1MHz. Using the 1MHz steps will take more
time to search for and install channels.
Network frequency mode
If you intend to use the fast Quick method
in Frequency scan to search for channels,
select Automatic. The TV will use 1 of the predefined
network frequencies (or HC - homing channel) as
used by most cable providers in your country.
If you received a specific network frequency value to
search for channels, select Manual.
Network frequency
With the Network frequency mode set to Manual,
you can enter the network frequency value received
from your cable provider here. To enter the value,
use the number keys.
Network ID
Enter the network ID supplied by your cable
provider.
Symbol rate mode
If your cable provider did not give you a
specific symbol rate value to install the TV channels,
leave the Symbol rate mode setting on Automatic.
If you received a specific symbol rate value,
select Manual.
Symbol rate
With the Symbol rate mode set to Manual, you can
enter the symbol rate value by using the number
keys.
Automatically Search for Channels
Channel Update Message
(Home) > Settings > Install
Channels > Antenna installlation > Channel
update message
When new channels are found or if channels are
updated or removed, a message is shown at TV start
up. To avoid this message to appear after every
channel update, you can switch it off.
Digital: Reception Test
(Home) > Settings > Install
Channels > Antenna installlation > Digital:
reception test
The digital frequency is shown for this channel. If the
reception is poor, you can reposition your antenna.
To check the signal quality of this frequency again,
select Search and press OK.
To enter a specific digital frequency yourself, use the
remote control digit keys. Alternatively, select the
frequency, position the arrows on a number
with and and change the number
with and . To check the frequency,
select Search and press OK.
Analogue: Manual Installation
(Home) > Settings > Install
Channels > Antenna installlation > Analogue:
manual installation
Analogue TV channels can be manually installed,
channel by channel.
• System
To set up the TV system, select System.
Select your country or the part of the world where
you are now and press OK.
(Home) > Settings > Install
Channels > Antenna installlation > Automatic
channel update
If you receive digital channels, you can set the TV to
automatically update the list with new channels.
Alternatively, you can start a channel update yourself.
Automatic channel update
Once a day, at 6 AM, the TV updates the channels
and stores new channels. New channels are stored in
the All channels list but also in the New channels list.
Empty channels are removed.
If new channels are found or if channels are updated
or removed, a message is shown at TV start up. The
TV must be in standby to automatically update
channels.
• Search Channel
To find a channel, select Search Channel and
press OK. You can enter a frequency yourself to find
a channel or let the TV search for a channel.
Press OK, select Search and press OK to search
for a channel automatically. The found channel is
shown on screen and if the reception is poor,
press Search again. If you want to store the channel,
select Done and press OK.
• Fine tune
To fine tune a channel, select Fine tune and
press OK. You can fine tune the channel
with or .
If you want to store the channel found,
select Done and press OK.
16
• Store
You can store the channel on the current channel
number or as a new channel number.
Select Store and press OK. The new channel
number is shown briefly.
You can redo these steps until you have found all
available analogue TV channels.
Channel List copy
to TV and press OK. Enter your PIN code if
necessary.
4 - The TV notifies you if the channel list is copied to
the TV successfully. Unplug the USB flash drive.
To Installed TVs
Depending on whether your TV is already installed or
not, you must use a different method to upload a
channel list.
Introduction
Channel list copy is intended for dealers and expert
users.
With Channel list copy, you can copy the channels
installed on one TV onto another Philips TV of the
same range. With Channel list copy, you avoid the
time-consuming channel search by uploading a
predefined channel list on a TV. Use a USB flash drive
of minimum 1 GB.
Conditions
• Both TVs are from the same year range.
• Both TVs have the same hardware type. Check the
hardware type on the TV type plate on the back of
the TV.
• Both TVs have compatible software versions.
Copy a Channel List, Check Channel List Version
Copy a channel list to USB flash drive
(Home) > Settings > All settings > Channels
> Channel list copy > Copy to USB
Check channel list version
(Home) > Settings > All settings > Channels
> Channel list copy > Current version
To an already installed TV
1 - Verify the country setting of the TV. (To verify this
setting, see chapter Re-install channels. Start this
procedure until you reach the country setting.
Press BACK to cancel the installation.)
If the country is correct continue with step 2.
If the country is not correct, you need to start a
reinstallation. See chapter Re-install channels and
start the installation. Select the correct country and
skip the channels search. Finish the installation. When
done, continue with step 2.
2 - Plug in the USB flash drive that holds the channel
list of the other TV.
3 - To start the channel list upload,
press (Home) > Settings > All
settings > Channels > Channel List Copy > Copy
to TV and press OK. Enter your PIN code if
necessary.
4 - The TV notifies you if the channel list is copied to
the TV successfully. Unplug the USB flash drive.
Channel Options
Open Options
While watching a channel, you can set some options.
Depending on the type of channel you are watching
or depending on the TV settings you made, some
options are available.
Upload a Channel List
To not Installed TVs
Depending on whether your TV is already installed or
not, you must use a different method to upload a
channel list.
To a TV that is not yet installed
1 - Plug in the power plug to start the installation and
select language and country. You can skip the
channel search. Finish the installation.
2 - Plug in the USB flash drive that holds the channel
list of the other TV.
3 - To start the channel list upload,
press (Home) > Settings > All
settings > Channels > Channel List Copy > Copy
To open the options menu…
1 - While watching a channel, press OPTIONS.
2 - Press OPTIONS again to close.
Programme info
Select Programme info to view the information of the
programme you are watching.
Subtitles
To switch on Subtitles, press OPTIONS and select
Subtitles.
You can switch
17
subtitles Subtitle on or Subtitle off . Alternatively
you can select Automatic.
Automatic
If language information is part of the digital broadcast
and the broadcasted programme is not in your
language (the language set on TV), the TV can show
subtitles automatically in one of your preferred
subtitle languages. One of these subtitle languages
must also be part of the broadcast.
Channel info
Select Channel info to view the technical information
of the channel.
HbbTV on This Channel
Note: This is for Singapore, Australia, and New
Zealand only.
You can select your preferred subtitle languages
in Subtitle language.
Subtitles Language
If none of the preferred subtitle languages are
available, you can select another subtitle language if
available. If no subtitle languages are available, you
cannot select this option.
To read more information, in Help, press the colour
key Keywords and look up Subtitle Language.
Audio Language
If none of the preferred audio languages are
available, you can select another audio language if
available. If no audio languages are available, you
cannot select this option.
To read more information, in Help, press the colour
key Keywords and look up Audio Language.
If you want to avoid access to HbbTV pages on a
specific channel, you can block the HbbTV pages for
this channel only.
1 - Tune to the channel of which you want to block
the HbbTV pages.
2 - Press OPTIONS and select HbbTV on this
channel and press (right).
3 - Select Off and press OK.
4 - Press (left) to go back one step or
press BACK to close the menu.
To block HbbTV on TV completely…
(Home) > Settings > All settings > Channels
> HbbTV > Off
Universal Access
Only available when Universal access set to On.
(Home) > Settings > All settings > Universal
access > Universal access > On.
To read more information, in Help, press the colour
key Keywords and look up Universal Access.
Dual I-II
If an audio signal contains two audio languages but
one language or both has no language indication, this
option is available.
Mono / Stereo
You can switch the sound of an analogue channel to
Mono or Stereo.
To switch to Mono or Stereo…
Tune to an analoge channel.
1 - Press OPTIONS, select Mono/Stereo and
press (right).
2 - Select Mono or Stereo and press OK.
3 - Press (left) repeatedly if necessary, to close
the menu.
7.3
Channel List
Open Channel List
To open the current channel list…
1 - Press , to switch to TV.
2 - Press OK to open the channel list if Interactive
Service is not available, or long press TV Guide to
open the channel list.
3 - Press OPTIONS > Select channel list.
4 - Select one channel list you want to watch.
5 - Press BACK to close the channel list.
18
Channel List Options
Select Channel Range
Open Option Menu
To open the channel list option menu...
• Press , to switch to TV.
• Long press TV Guide to open the channel list.
• Press OPTIONS , and select one of options.
• Press BACK to close the channel list.
Rename Channel
1 - Press , to switch to TV.
2 - Long press TV Guide to open the channel
list..
3 - Select one channel you want to rename.
4 - Press OPTIONS > Rename channel, and
press OK.
5 - In the typing field, press OK to open on-screen
keyboard, or press BACK to hide the on-screen
keyboard.
6 - Use navigation keys to select a character, then
press OK.
- Press (red) key to enter with lower-case
- Press (green) key to enter with upper-case
- Press (yellow) key to enter number and
symbol
- Press (blue) key to delete a character
7 - Select Done when complete the editing.
8 - Press BACK to close the channel list.
Select Channel Filter
1 - Press , to switch to TV.
2 - Long press TV Guide to open the channel
list.
3 - Press OPTIONS > Digital/analogue
4 - Select one of channel combinations showing in
the channel list.
> OK > OPTIONS > Select channel range
Select a range of channels in a favourites channel
list, once completed, press OK.
Select Channel List
> OK > OPTIONS > Select channel list
Select a range of channels in a favourites channel
list, once completed, press OK.
Search Channels
> OK > OPTIONS > Search channel
You can search for a channel to find it in a long list of
channels.
1 - Press , to switch to TV.
2 - Long press TV Guide to open the channel
list.
3 - Press OPTIONS > Search channel, and
press OK.
4 - In the typing field, press OK to open on-screen
keyboard, or press BACK to hide the on-screen
keyboard.
5 - Use navigation keys to select a character, then
press OK.
- Press (red) key to enter with lower-case
- Press (green) key to enter with upper-case
- Press (yellow) key to enter number and
symbol
- Press (blue) key to delete a character
- Select Enter to start the searching
6 - Select Done when the searching is
completed.
7 - Press BACK to close the channel list.
Lock or Unlock Channel
Create or Edit Favourites Channel List
> OK > OPTIONS > Create favourites list
Select a channel then press OK to add in a
favourites channel list, once completed,
press Done.
> OK > OPTIONS > Edit favourites
Select a channel then press OK to add in or remove
from a favourites channel list, once completed, press
Done.
> OK > OPTIONS > Lock channel, Unlock
channel
To prevent children from watching a channel, you can
lock a channel. To watch a locked channel, you must
enter the 4 digit Child Lock PIN code first. You
cannot lock programmes from connected devices.
The locked channel will have next to the channel
logo.
Remove Favourite List
> OK > OPTIONS > Remove favourite list
To remove existing favourite list, select Yes.
19
7.4
Favourite Channels
About Favourite Channels
3 most used channels from the broadcasters’ default
list will be appended after your favourite channels for
your preview. You need to add these channels into
your favourite list to enable its operation (refer to "TV
Guide" chapter).
You can create a favourite channel list that only holds
the channels you want to watch. With the Favourite
channel list selected, you will only see your favourite
channels when you switch through channels.
Create a Favourites List
1 - While watching a TV channel, long press TV
Guide to open the channel list.
2 - Select the channel, and press Mark as
favourites to mark as favourite.
3 - The selected channel is marked with a .
4 - To finish, press BACK . The channels are
added to the Favourites list.
Remove Channel from the Favourites
List
To remove a channel from the favourites list, select
the channel with , then press Unmark as
favourite again to unmark as favourite.
On each page of TV Guide, there is a "Did you know"
grid inserted on your favourite channel list. The "Did
you know"-channel provides useful tips to improve
the way you use your TV.
7.5
Text / Teletext
Subtitles from Text
If you tune to an analogue channel, you need to
make the subtitles available for each channel
manually.
1 - Switch to a channel and press TEXT to open
Text.
2 - Enter the page number for subtitles, usually 888.
3 - Press TEXT again, to close Text.
If you select On in the Subtitle menu when watching
this analogue channel, subtitles will be shown if
available.
To know if a channel is analogue or digital, switch to
the channel and press INFO .
Reorder Channels
You can reorder — reposition — channels in the
Favourite channel list.
1 - While watching a TV channel, press OK >
OPTIONS > Select channel list.
2 - Select Antenna favourite, and
press OPTIONS .
3 - Select Reorder channels, select the channel you
want to reorder, and press OK.
4 - Press the Navigation buttons to move the
highlighted channel to another location and
press OK.
5 - Once completed, press Done.
Favourites List on TV Guide
You can link the TV Guide for your Favourite List.
1 - While watching a TV channel,
press OK > OPTIONS > Select channel list.
2 - Select Antenna favourite, and press OK.
3 - Press TV GUIDE to open it.
With the TV Guide you can view a list of the current
and scheduled TV programmes of your favourite
channels. Along with your favourite channels, the first
Text Pages
To open Text/Teletext press TEXT, while you are
watching TV channels.
To close Text, press TEXT again.
Select a Text page
To select a page . . .
1 - Enter the page number with the number keys.
2 - Use the arrow keys to navigate.
3 - Press a colour key to select a colour-coded
subject at the bottom of the screen.
Text sub-pages
A Text page number can hold several subpages. The
subpage numbers are shown on a bar next to the
main page number.
To select a subpage, press or .
T.O.P. Text pages
Some broadcasters offer T.O.P. Text.
To open T.O.P. Text pages within Text,
press OPTIONS and select T.O.P. overview.
* The teletext can only be reached when the channels
are installed directly on the TV’s internal tuner and
20
the set is on TV mode. If a set-top box is being used,
the teletext will be unavailable via TV. In that case,
the set-top box’s teletext can be used instead.
Text Options
In Text/Teletext, press OPTIONS to select the
following…
• Freeze page
To stop the automatic rotation of subpages.
• Dual screen / Full screen
To show the TV channel and Text alongside each
other.
• T.O.P. overview
To open T.O.P. Text.
• Enlarge
To enlarge the Text page for comfortable reading.
• Reveal
To unhide hidden information on a page.
• Language
To switch the group of characters that Text uses to
display correctly.
• Text 2.5
To activate the Text 2.5 for more colours and better
graphics.
Text Setup
Text language
Some digital TV broadcasters have several Text
languages available.
Set teletex preference language
(Home) > Settings > All settings > Region and
language > Language > Primary text, Secondary
text
Text 2.5
If available, Text 2.5 offers more colours and better
graphics. Text 2.5 is activated as a standard factory
setting.
To switch off Text 2.5…
1 - Press TEXT.
2 - With Text/Teletext open on screen,
press OPTIONS.
3 - Select Text 2.5 > Off.
4 - Press (left) repeatedly if necessary, to close
the menu.
21
Loading...
