www.philips.com/welcome

61x2 series

User Manual

50PUT6102

50PUT6102S

55PUT6102

55PUT6102S

65PUT6162

65PUT6162S

1 My new TV 4

1.1 Smart TV 4

1.2 App gallery 4

1.3 Rental videos 4

1.4 Ultra HD TV 4

1.5 Social Networks 4

1.6 Pause TV and recordings 4

2 Setting up 5

2.1 Read safety 5

2.2 TV stand and wall mounting 5

2.3 Tips on placement 5

2.4 Power cable 5

2.5 Antenna cable 5

3 Network 7

3.1 Network and Internet 7

4 Connect devices 11

4.1 About Connections 11

4.2 HDMI Ports 11

4.3 Y Pb Pr - Component 12

4.4 CVBS - Audio L R 13

4.5 Audio Out - Optical 13

4.6 Receiver - Set-Top Box 13

4.7 Home Theatre System - HTS 14

4.8 Smartphones and tablets 14

4.9 Blu-ray Disc Player 14

4.10 DVD Player 15

4.11 Headphones 15

4.12 Game Console 15

4.13 USB Hard Drive 16

4.14 USB Keyboard 17

4.15 USB Flash Drive 17

4.16 Photo Camera 18

4.17 Camcorder 18

4.18 Computer 18

5 Switching On and Off 20

5.1 On or standby 20

5.2 Keys on TV 20

5.3 Sleep timer 20

5.4 Switch off timer 20

6 Remote control 22

6.1 Key overview 22

6.2 IR sensor 23

6.3 Batteries 23

6.4 Cleaning 23

7 Channels 24

7.1 Install Channels 24

7.2 Switch channels 24

7.3 Channel lists 24

7.4 Watching channels 25

7.5 Favourite Channels 27

8 TV Guide 28

8.1 What you need 28

8.2 Using the TV guide 28

9 Recording and Pause TV 30

9.1 Recording 30

10 Home menu 32

10.1 About the Home menu 32

10.2 Open the Home menu 32

11 Utilities 33

11.1 About Utilities 33

12 Netflix 34

12.1 About Netflix 34

13 Sources 35

13.1 Switch to a device 35

13.2 Options for a TV Input 35

13.3 Scan connections 35

13.4 Game or computer 35

14 Internet 36

14.1 Start Internet 36

14.2 Options on Internet 36

15 Movie, photos and music 37

15.1 From a USB connection 37

15.2 From a computer 37

15.3 Menu bar and sorting 37

15.4 Play your movie 37

15.5 View your photos 37

15.6 Play your music 38

16 Smartphones and tablets 39

16.1 Miracast 39

16.2 MHL 40

16.3 Smart TV 40

17 Multi room 44

17.1 About Multi room 44

17.2 What you need 44

17.3 Using Multi room 44

18 Settings 45

18.1 Quick settings 45

18.2 Picture 45

18.3 Sound 48

18.4 Eco settings 51

18.5 General settings 52

18.6 Clock and language 53

18.7 Universal access 56

19 Networks 58 20 Channel installation 59

20.1 Antenna/cable installation 59

20.2 Channel list copy 61

21 Software 63

21.1 Update software 63

21.2 Software version 63

21.3 Local updates 63

21.4 Look for OAD updates 63

21.5 Open source software 64

21.6 Open source license statement 64

21.7 Open source license 64

22 Specifications 75

22.1 Environmental 75

22.2 Power 75

22.3 Reception 75

22.4 Display 76

22.5 Dimensions and Weights 76

22.6 Connectivity 76

22.7 Sound 76

22.8 Multimedia 76

23 Troubleshooting and support 78

23.1 Register your TV 78

23.2 Help 78

23.3 Troubleshooting 78

23.4 Online help 80

23.5 Consumer care / Repair 80

24 Safety and care 82

24.1 Safety 82

24.2 Screen care 83

25 Terms of use, copyrights and licenses

25.1 Terms of use 84

26 Copyrights 85

26.1 Dolby 85

26.2 MHL 85

26.3 Ultra HD 85

26.4 HDMI 85

26.5 DTS 2.0 + Digital Out ™ 85

26.6 Microsoft 85

26.7 Wi-Fi Alliance 85

26.8 Kensington 85

26.9 Other trademarks 86

Index 87

My new TV

* Depending on the video streaming service of the selected video store.

1.1

Smart TV

Connect this Philips Smart LED TV to the Internet and discover a new world of television. You can make a wired connection to your router or you can link up wirelessly with Wi-Fi.

With the TV connected to your home network, a smartphone can show a photo on TV, you can play videos stored on your computer or control the TV with your tablet.

With your TV connected to the Internet, you can watch a rental video from an online video store, read the online TV guide or record your favourite TV show on a USB Hard Drive.

The Smart TV Apps add to the fun with all sorts of entertainment and convenient services.

In Help, press  Keywords and look up Smart TV for more information.

1.4

Ultra HD TV

This TV has an Ultra HD display. Its resolution is four times as much as normal HD displays. Ultra HD means 8 million pixels for the most refined and lifelike picture on TV.

On top, the new Ultra Pixel HD Engine continuously converts any incoming TV signal into Ultra HD resolution. So you can enjoy this stunning picture quality the moment you switch on the TV. Or you can watch native Ultra HD videos through an HDMI connection. Ultra HD offers TV viewing that is crisp and sharp even on a big screen.

1.5

1.2

App gallery

Open the App gallery in Smart TV to browse the Apps, the collection of tailored websites for TV.

There are Apps to rent a video from an online video store and Apps for watching programmes you missed.

If the App gallery does not hold what you are looking for, try the World Wide Web and surf the Internet on TV.

In Help, press  Keywords and look up App gallery for more information.

1.3

Rental videos

To watch a rental video, you don't need to leave your home. Simply rent the latest movie from your regional online video store.

Start Smart TV and add the video store App to the Smart TV start page.

Open the video store App, create your personal account, select the movie and press play. No fuss with downloading, you can watch the movie immediately*.

Social Networks

No need to get up to check your friend's messages on your computer.

On this TV you get the messages from your social network on your TV screen. You can send a return message from your couch.

For more information, in Help, press the colour key  Keywords and look up Apps.

1.6

Pause TV and recordings

If you connect a USB Hard Drive, you can pause and record a broadcast from a digital TV channel.

Pause your TV and answer that urgent phone call or simply take a break during a sports match, while the TV stores the broadcast on the USB Hard Drive. You can watch it again later. With a USB Hard Drive connected, you can also record digital broadcasts. You can record while you are watching a programme or schedule a recording of an upcoming programme.

For more information, in Help, press the colour key  Keywords and look up Pause TV or Recording.

In Help, press  Keywords and look up Rental videos for more information.

Setting up

2.1

Read safety

Read the safety instructions first before you use the TV.

2.4

To read the instructions, in Help, press the colour key  Keywords and look up Safety instructions.

2.2

TV stand and wall mounting

You can find the instructions for mounting the TV stand in the Quick Start Guide that came with the TV.

Your TV is also prepared for a VESA-compliant wall mount bracket (sold separately). Use the following VESA code when purchasing the wall mount . . .

• For 50-inch TV: VESA MIS-F 200x200, M6

• For 55-inch TV: VESA MIS-F 400x200, M6

• For 65-inch TV: VESA MIS-F 400x200, M6

Caution

Wall mounting the TV requires special skills and should only be performed by qualified personnel. The TV wall mounting should meet safety standards according to the TVs weight. Also read the safety precautions before positioning the TV.

Power cable

• Insert the power cable into the POWER connector on the back of the TV.

• Make sure the power cable is securely inserted in the connector.

• Make sure that the power plug, in the wall socket, is accessible at all times.

• When you unplug the power cable, always pull the plug, never pull the cable.

Although this TV has a very low standby power consumption, unplug the power cable to save energy if you do not use the TV for a long period of time.

For more information, in Help, press the colour key  Keywords and look up Switching on for more information.

2.5

Antenna cable

2.3

Tips on placement

• Position the TV where light does not shine directly on the screen.

• Position the TV up to 15 cm away from the wall.

• The ideal distance to watch TV is 3 times its diagonal screen size. When seated, your eyes should be level with the centre of the screen.

Insert the antenna plug firmly into the Antenna socket at the back of the TV.

You can connect your own antenna or an antenna signal from an antenna distribution system. Use an IEC Coax 75 Ohm RF antenna connector.

Use this antenna connection for DVB-T and DVB-C input signals.

Network

3.1

Network and Internet

Home network

To enjoy the full capabilities of your TV, your TV must be connected to the Internet.

Connect the TV to a home network with a high-speed Internet connection. You can connect your TV wirelessly or wired to your network router.

networks in your proximity.

• WPS If your router has WPS, you can directly connect to the router without scanning. Go to the router, press the WPS button and return to the TV within 2 minutes. Then press Connect to make the connection. If you have devices in your wireless network that use the WEP security encryption system, you cannot use WPS. If you must use the WPS PIN code to connect, select

Scan instead of WPS. Step 7 - In the list of networks found, select your

wireless network and press OK. If your network is not in the list because the network name is hidden (you switched off the SSID broadcast of the router), select Manual entry to enter the network name yourself.

Connect to network

Wireless connection

What you need

To connect the TV to the Internet wirelessly, you need a Wi-Fi router with a connection to the Internet.

Use a high-speed (broadband) connection to the Internet.

Make the connection

Step 8 - Depending on the type of router, you can

now enter your encryption key (WEP, WPA or WPA2). If you entered the encryption key for this network before, you can select Next to make the connection immediately. If your router supports WPS or WPS PIN, you select WPS, WPS PIN or Standard. Select your choice and press OK.

• Standard Select Standard to enter the encryption key (password, passphrase or security key) manually.You can use the keyboard on the remote control to enter the encryption key. Once you have entered the key, press Connect.

• WPS PIN To make a secured WPS connection with a PIN code, select WPS PIN and press OK. Write down the 8-digit PIN code shown and enter it in the router software on your PC. Return to the TV and press Connect. Consult the router manual on where to enter the PIN code in the router software.

Step 9 - A message will be shown when the connection is successful.

To make a wireless connection… Step 1 - Make sure that the router of your wireless

network is switched on. Step 2 - Press , select Network and press (right) to enter the menu. Step 3 - Select Connect to network > Start now and press OK.

Step 4 - Select Connect and press OK. Step 5 - Select Wireless and press OK. Step 6 - Select Scan to scan for your wireless

network. If you have a router with WPS (Wi-Fi Protected Setup), you can select WPS. Select your choice and press OK.

• Scan Select Scan to scan for your wireless network (your wireless router). The TV might find several wireless



Problems

Wireless network not found or distorted

• Microwave ovens, DECT phones or other Wi-Fi

802.11b/g/n devices in your proximity might disturb the wireless network.

• Make sure that the firewalls in your network allow access to the TV's wireless connection.

• If the wireless network does not work properly in your home, try the wired network installation.

Internet does not work

• If the connection to the router is OK, check the router connection to the Internet.

The PC and Internet connection are slow

• Look in your wireless router's user manual for information on indoor range, transfer rate and other factors of signal quality.

• Use a high-speed (broadband) Internet connection for your router.

DHCP

• If the connection fails, you can check the DHCP (Dynamic Host Configuration Protocol) setting of the router. DHCP should be switched on.

Wired connection

What you need

Network settings

View network settings

You can view all current network settings here. The IP and MAC address, signal strength, speed, encryption method, etc.

To view the current network settings… 1 - Press , select Network and press  (right) to

enter the menu.

2 - Select View network settings and press OK. 3 - Select Close to close the menu.

To connect the TV to the Internet, you need a network router with a connection to the Internet.

Use a high-speed (broadband) connection to the Internet.

Make the connection

To make a wired connection… 1 - Connect the router to the TV with a network cable

(Ethernet cable**).

2 - Make sure that the router is switched on. 3 - Press , select Network and press  (right) to

enter the menu. 4 - Select Connect to network > Start now and press OK.

5 - Select Connect and press OK. 6 - Select Wired and press OK. The TV constantly

searches for the network connection. 7 - A message will be shown when the connection is successful.

Network configuration

If you are an advanced user and want to install your network with Static IP addressing, set the TV to Static IP.

To set the TV to Static IP… 1 - Press , select Network and press  (right) to

enter the menu.

2 - Select Network configuration and press OK. 3 - Select Static IP and press OK to enable Static

IP configuration.

4 - Select Static IP configuration and configure the connection.

5 - You can set the number for IP address, Netmask, Gateway, DNS 1, or DNS 2.

6 - Press  (left) repeatedly if necessary, to close the menu.

Switch On with Wi-Fi (WoWLAN)

You can switch this TV on from your smartphone or tablet if the TV is in Standby. The setting Switch On with Wi-Fi (WoWLAN) must be switched on.

To switch on WoWLAN… 1 - Press , select Network and press  (right) to

enter the menu. 2 - Select Switch on with Wi-Fi (WoWLAN) and press OK.

3 - Select On and press OK. 4 - Press  (left) repeatedly if necessary, to close

the menu.

If the connection fails, you can check the DHCP setting of the router. DHCP should be switched on.

Digital Media Renderer - DMR

If your media files do not play on your TV, make sure that the Digitial Media Renderer is switched on. As a factory setting, DMR is switched on.

To switch on DMR… 1 - Press , select Network and press  (right) to

enter the menu.

2 - Select Digital Media Renderer - DMR and press OK.

3 - Select On and press OK. 4 - Press  (left) repeatedly if necessary, to close

the menu.

Switch on Wi-Fi connection

To switch on Wi-Fi Smart Screen… 1 - Press , select Network and press  (right) to

enter the menu.

2 - Select Wi-Fi smart screen and press OK. 3 - Select On and press OK. 4 - Press  (left) repeatedly if necessary, to close

the menu.

You can switch on or off Wi-Fi connection on your TV.

To switch on Wi-Fi… 1 - Press , select Network and press  (right) to

enter the menu.

2 - Select Wi-Fi On/Off and press OK. 3 - Select On and press OK. 4 - Press  (left) repeatedly if necessary, to close

the menu.

Switch on Wi-Fi Miracast

Switch on Wi-Fi Miracast to share the screen of your smartphone, tablet or computer on the TV.

To switch on Miracast… 1 - Press , select Network and press  (right) to

enter the menu.

2 - Select Wi-Fi Miracast and press OK. 3 - Select On and press OK. 4 - Press  (left) repeatedly if necessary, to close

the menu. For more information, in Help, press the colour

key  Keywords and look up Miracast™, switch

on.

TV network name

If you have more than one TV in your home network, you can give the TV a unique name.

To change the TV name… 1 - Press , select Network and press  (right) to

enter the menu.

2 - Select TV network name and press OK. 3 - Enter the name with the on-screen keyboard. 4 - Select Done to confirm the change. 5 - Press  (left) repeatedly if necessary, to close

the menu.

Netflix settings

With Netflix settings, you can view ESN number or deactive Netflix device.

To enter Netflix settings… 1 - Press , select Network and press  (right) to

enter the menu.

2 - Select Netflix settings and press OK. 3 - Press  (left) repeatedly if necessary, to close

the menu.

Reset Wi-Fi Miracast connections

Clear the list of connected and blocked devices that are used with Miracast.

To clear Miracast connections… 1 - Press , select Network and press  (right) to

enter the menu. 2 - Select Reset Wi-Fi Miracast connections and press OK.

3 - Select Clear all and press OK. 4 - Press  (left) repeatedly if necessary, to close

the menu.

Wi-Fi smart screen

To watch digital TV channels on your smartphone, you must switch on Wi-Fi Smart Screen. Some scrambled channels might not be available on your mobile device.

Clear Internet memory

With Clear Internet Memory, you can clear all Internet files and logins stored on your TV, such as passwords, cookies, and history.

To clear the Internet memory… 1 - Press , select Network and press  (right) to

enter the menu.

2 - Select Clear Internet memory and press OK. 3 - Select OK to confirm. 4 - Press  (left) repeatedly if necessary, to close

the menu.

File sharing

The TV can connect to other devices in your wireless network, like your computer or smartphone. You can use a computer with Microsoft Windows or Apple OS X.

On this TV, you can open photos, music and videos stored on your computer.

4.2

Connect devices

4.1

About Connections

Connectivity Guide

Always connect a device to the TV with the highest quality connection available. Also, use good quality cables to ensure a good transfer of picture and sound.

When you connect a device, the TV recognizes its type and gives each device a correct type name. You can change the type name if you wish. If a correct type name for a device is set, the TV automatically switches to the ideal TV settings when you switch to this device in the Sources menu.

If you need help to connect several devices to the TV, you can visit the Philips TV connectivity guide. The guide offers information on how to connect and which cables to use.

Go to www.connectivityguide.philips.com

Antenna Port

If you have a Set-top box (a digital receiver) or Recorder, connect the antenna cables to run the antenna signal through the Set-top box and/or Recorder first before it enters the TV. In this way, the antenna and the Set-top box can send possible additional channels to the Recorder to record.

HDMI Ports

HDMI Quality

An HDMI connection has the best picture and sound quality. One HDMI cable combines video and audio signals. Use an HDMI cable for TV signal.

For best signal quality transfer, use a High speed HDMI cable and do not use an HDMI cable longer than 5 m.

Copy protection

HDMI cables support HDCP (High-bandwidth Digital Content Protection). HDCP is a copy protection signal that prevents copying content from a DVD disc or Bluray Disc. Also referred to as DRM (Digital Rights Management).

HDMI ARC

Only HDMI 1 on the TV have HDMI ARC (Audio Return Channel).

If the device, typically a Home Theatre System (HTS), also has the HDMI ARC connection, connect it to HDMI 1 connection on this TV. With the HDMI ARC connection, you do not need to connect the extra audio cable that sends the sound of the TV picture to the HTS. The HDMI ARC connection combines both signals.

HDMI MHL

With HDMI MHL, you can send what you see on your Android smartphone or tablet to a TV screen.

The HDMI 4 connection on this TV incorporates MHL 2.0 (Mobile High-Definition Link).

This wired connection offers great stability and bandwidth, low latency, no wireless interference and good quality sound reproduction. On top of that, the MHL connection will charge the battery of your smartphone or tablet. Although connected, your

mobile device will not be charging when the TV is on standby.

Inform yourself about what passive MHL cable is suited for your mobile device. In particular, with the HDMI connector for the TV on one side, the type of connector you need to connect to your smartphone or tablet.

MHL, Mobile High-Definition Link and the MHL Logo are trademarks or registered trademarks of the MHL, LLC.

HDMI CEC - EasyLink

An HDMI connection has the best picture and sound quality. One HDMI cable combines video and audio signals. Use an HDMI cable for High Definition (HD) TV signals. For best signal quality transfer, use a High speed HDMI cable and do not use an HDMI cable longer than 5 m.

The HDMI CEC functionality has different names on different brands. Some examples are: Anynet, Aquos Link, Bravia Theatre Sync, Kuro Link, Simplink and Viera Link. Not all brands are fully compatible with EasyLink.

Example HDMI CEC branding names are property of their respective owners.

DVI to HDMI

If you still own a device that only has a DVI connection, you can connect the device to any of the HDMI connection with a DVI to HDMI adapter.

Use a DVI to HDMI adapter if your device only has a DVI connection. Use one of the HDMI connections and add an Audio L/R cable (mini-jack 3.5mm) to Audio In for sound, on the back of the TV.

EasyLink HDMI CEC

If your devices are connected with HDMI and have EasyLink, you can operate them with the TV remote control. EasyLink HDMI CEC must be switched On on the TV and the connected device.

With EasyLink you can operate a connected device with the TV remote control. EasyLink uses HDMI CEC (Consumer Electronics Control) to communicate with the connected devices. Devices must support HDMI CEC and must be connected with an HDMI connection.

EasyLink setup

The TV comes with EasyLink switched on. Make sure that all HDMI CEC settings are properly set up on the connected EasyLink devices. EasyLink might not work with devices from other brands.

HDMI CEC on other brands

Copy Protection

DVI and HDMI cables support HDCP (High-bandwidth Digital Content Protection). HDCP is a copy protection signal that prevents copying content from a DVD disc or Blu-ray Disc. Also referred to as DRM (Digital Rights Management).

4.3

Y Pb Pr - Component

Y Pb Pr - Component Video is a high quality connection.

The YPbPr connection can be used for High Definition (HD) TV signals. Next to the Y, Pb and Pr signals add the Audio Left and Right signals for sound.

Match the YPbPr (green, blue, red) connector colours with the cable plugs when you connect.

Use an Audio L/R cinch cable if your device also has sound.

4.4

CVBS - Audio L R

CVBS - Composite Video is a high quality connection. Next to the CVBS signal adds the Audio Left and Right signals for sound.

• Y shares the same jack with CVBS.

• Component and Composite share audio jacks.

If the sound does not match the video on screen, you can adjust the audio to video synchronisation. For more information, in Help, press the colour key  Keywords and look up Audio to video sync.

4.6

Receiver - Set-Top Box

Cable Box

Use 2 antenna cables to connect the antenna to the Set-top box (a digital receiver) and the TV.

4.5

Audio Out - Optical

Audio Out - optical is a high quality sound connection.

This optical connection can carry 5.1 audio channels. If your device, typically a Home Theatre System (HTS), has no HDMI ARC connection, you can use this connection with the Audio In - Optical connection on the HTS. The Audio Out - Optical connection sends the sound from the TV to the HTS.

You can set the type of the audio out signal to fit the audio capabilities of your Home Theatre System. For more information, in Help, press the colour key  Keywords and look up Audio out settings.

Next to the antenna connections, add an HDMI cable to connect the Set-top box to the TV.

Switch Off Timer

Switch off this automatic timer, if you only use the remote control of the Set-top box. Switch this timer off to prevent the TV from switching off automatically after a 4 hour period without a key press on the remote control of the TV.

For more information, in Help, press the colour key  Keywords and look up Switch off timer for more information.

4.7

Home Theatre System - HTS

the TV picture to the Home Theatre System.

Connect with HDMI ARC

Use an HDMI cable to connect a Home Theatre System (HTS) to the TV. You can connect an HTS with a built-in disc player.

HDMI ARC

If your Home Theatre System has an HDMI ARC connection, you can use HDMI 1 on the TV to connect. With HDMI ARC, you do not need to connect the extra audio cable. The HDMI ARC connection combines both signals. HDMI 1 on the TV can offer the Audio Return Channel (ARC) signal. But once you have connected the Home Theatre System, the TV can only send the ARC signal to this HDMI connection.

Audio to video synchronisation (sync)

If the sound does not match the video on screen, you can set a delay on most Home Theatre Systems with a disc player to match the sound with the video.

For more information, in Help, press the colour key  Keywords and look up Audio to video sync.

Problems with HTS sound

Sound with loud noise

If you watch a video from a plugged in USB flash drive or connected computer, the sound from your Home Theatre System might be distorted. This noise is heard when the audio or video file has DTS sound but the Home Theatre System has no DTS sound processing. You can fix this by setting the Audio out format of the TV to Stereo.

Press  for Sound > Advanced > Audio out

format. No sound

Audio to video synchronisation (sync)

If the sound does not match the video on screen, you can set a delay on most Home Theatre Systems with a disc player to match the sound with the video.

For more information, in Help, press the colour key  Keywords and look up Audio to video sync.

Connect with HDMI

Use a HDMI cable to connect a Home Theatre System (HTS) to the TV. You can connect a HTS with a built-in disc player.

If the Home Theatre System has no HDMI ARC connection, add an optical cable to send the sound of

If you cannot hear the sound from the TV on your Home Theatre System, check if you connected the HDMI cable to an HDMI1 ARC connection on the Home Theatre System.

4.8

Smartphones and tablets

To connect a smartphone or tablet to the TV, you can use a wired connection.

Wired

For a wired connection, use the HDMI 4 MHL connection on the back of the TV. In Help, press the colour key  Keywords and look up HDMI MHL for more information.

4.9

Blu-ray Disc Player

Use a High speed HDMI cable to connect the Bluray Disc player to the TV.

To adjust the volume…

1 - Press , select Sound > Headphones volume and press OK.

2 - Press the arrows  (up) or  (down) to adjust the value. 3 - Press  (left) repeatedly if necessary, to close the menu.

4.10

DVD Player

Use an HDMI cable to connect the DVD player to the TV.

If the DVD player is connected with HDMI and has EasyLink CEC, you can operate the player with the TV remote control.

4.12

Game Console

HDMI

For best quality, connect the game console with a High speed HDMI cable to the TV.

4.11

Headphones

You can connect a set of headphones to the  connection on the back of the TV. The connection is a mini-jack 3.5mm. You can adjust the volume of the headphones separately.

Y Pb Pr - Component

Connect the game console with a component video cable (Y Pb Pr) and an audio L/R cable to the TV.

CVBS - Audio L R

CVBS - Composite Video is a high quality connection. Next to the CVBS signal adds the Audio Left and Right signals for sound.

• Y shares the same jack with CVBS.

• Component and Composite share audio jacks.

To Record

To pause and record a broadcast, you need a minimum of 250GB disk space. If you want to record a broadcast with TV guide data from the Internet, you need to have the Internet connection installed on your TV before you install the USB Hard Drive.

For more information on how to install a USB Hard Drive, in Help, press the colour key  Keywords and look up USB hard drive,

installation.

Installation

Before you can pause or record a broadcast, you must connect and format a USB Hard Drive. Formatting removes all files from the USB Hard Drive.

1 - Connect the USB Hard Drive to one of the USB connections on the TV. Do not connect another USB device to the other USB ports when formatting.

2 - Switch on the USB Hard Drive and the TV. 3 - When the TV is tuned to a digital TV channel,

press  (Pause). Trying to pause will start the formatting.

Best Setting

Before you start playing a game from a connected game console, we advice you to set the TV in the ideal setting Game.

When you finish playing a game and start watching TV again, remember to switch the Game or Computer setting back to Off.

To set the TV to the ideal setting… 1 - Press , select Picture and press  (right) to

enter the menu. 2 - Select Advanced > Game or Computer, and select the device type you want to use. To switch back to TV, select Off. 3 - Press  (left) repeatedly if necessary, to close the menu.

4.13

USB Hard Drive

What You Need

Follow the instructions on screen. When the USB Hard Drive is formatted, leave it

connected permanently.

Warning

The USB Hard Drive is formatted exclusively for this TV, you cannot use the stored recordings on another TV or PC. Do not copy or change recording files on the USB Hard Drive with any PC application. This will corrupt your recordings. When you format another USB Hard Drive, the content on the former will be lost. A USB Hard Drive installed on your TV will need reformatting for use with a computer.

If you connect a USB Hard Drive, you can pause or record a TV broadcast. The TV broadcast must be a digital broadcast (DVB broadcast or similar).

To Pause

To pause a broadcast, you need a USB compatible Hard Drive with a minimum of 4GB disk space.

Formatting

Before you can pause or record a broadcast, you must connect and format a USB Hard Drive. Formatting removes all files from the USB Hard Drive.

Warning

To format a USB Hard Drive… 1 - Connect the USB Hard Drive to one of

the USB connections on the TV. Do not connect another USB device to the other USB ports when formatting.

2 - Switch on the USB Hard Drive and the TV. 3 - When the TV is tuned to a digital TV channel,

press  (Pause). Trying to pause will start the formatting. Follow the instructions on screen. 4 - The TV will ask if you want to use the USB Hard Drive to store apps, agree to the question if you do. 5 - When the USB Hard Drive is formatted, leave it connected permanently.

4.14

USB Keyboard

Connect

Connect a USB keyboard (USB-HID type) to enter text on your TV.

Use one of the USB connections to connect.

Configure

To install the USB keyboard, switch on the TV and connect the USB keyboard to one of the USB connections on the TV. When the TV detects the keyboard for the first time, you can select your keyboard lay-out and test your selection. If you select a Cyrillic or Greek keyboard layout first, you can select a secondary Latin keyboard layout.

To change the keyboard layout setting when a layout was selected…

1 - Press , select General settings and press  (right) to enter the menu. 2 - Select USB keyboard settings, and press OK to start the keyboard setup.

Special Keys

Keys for entering text

• Enter key = OK

• Backspace = delete character before cursor

• Arrow keys = navigate within a text field

• To switch between keyboard layouts, if a secondary layout is set, press the Ctrl + Spacebar keys simultaneously.

Keys for apps and Internet pages

• Tab and Shift + Tab = Next and Previous

• Home = scroll to the top of the page

• End = scroll to the bottom of the page

• Page Up = jump one page up

• Page Down = jump one page down

• + = zoom in one step

• - = zoom out one step

• * = fit the web page to the screen width

4.15

4.17

USB Flash Drive

You can view photos or play your music and movie from a connected USB flash drive.

Insert a USB flash drive in one of the USB connections on the TV while the TV is switched on.

The TV detects the flash drive and opens a list showing its content. If the contents list does not appear automatically, press SOURCES and select USB.

To stop watching the USB flash drive content, press EXIT or select another activity. To disconnect the USB flash drive, you can pull out the flash drive anytime.

Camcorder

HDMI

For best quality, use an HDMI cable to connect the camcorder to the TV.

Audio Video LR

You can use an HDMI or YPbPr connection to connect your camcorder.

Ultra HD on USB

You can view photos in Ultra HD resolution from a connected USB device or flash drive. The TV will downscale the resolution to Ultra HD if the resolution of the photo is higher.

For more information on watching or playing content from a USB flash drive, in Help, press the colour key  Keywords and look up Photos, movie and music.

4.16

Photo Camera

To view photos stored on your digital photo camera, you can connect the camera directly to the TV.

Use one of the USB connections on the TV to connect. Switch on the camera after you made the connection.

If the contents list does not appear automatically, press SOURCES , and select USB. Your camera might need to be set to transfer its content with PTP (Picture Transfer Protocol). Read the user manual of the digital photo camera.

For more information on viewing photos, in Help, press the colour key  Keywords and look up Photos, movie and music.

4.18

Computer

Connect

You can connect your computer to the TV and use the TV as a PC monitor.

With HDMI

Use an HDMI cable to connect the computer to the TV.

With DVI to HDMI

Alternatively, you can use a DVI to HDMI adapter (sold separately) to connect the PC to HDMI and an audio L/R cable (mini-jack 3.5mm) to AUDIO IN L/R on the back of the TV.

the menu. Remember to set Game or computer setting

to Off when you stop playing the game.

Ideal Setting

If you connect a computer, we advice you to give the connection, on which the computer is connected, the correct device type name in the Source menu. If you then switch to Computer in the Source menu, the TV is set to the ideal Computer setting automatically.

You can manually switch the ideal setting to Off for watching TV or Game for playing a game from a connected game console (remember to switch back to Off when you stop playing a game).

If you switch to a source and change the Game or Computer setting, it will be stored for this selected source.

To set the TV to the ideal setting… 1 - Press , select Picture and press  (right) to

enter the menu. 2 - Select Advanced > Game or computer, and press OK. 3 - Select Game (for gaming) or select Computer (for watching a movie). 4 - Press  (left) repeatedly if necessary, to close

Switching On and Off

5.1

On or standby

Before you switch on the TV, make sure you plugged in the mains power in the POWER connector on the back of the TV.

movie. 4 - The menu will disappear automatically.

To switch the TV on standby, select  and press the joystick key.

5.3

Sleep timer

With the Sleep Timer, you can set the TV to switch to Standby automatically after a preset time.

With the TV in Standby, press  on the remote control to switch the TV on. You can also press the small joystick key on the back of the TV to switch the TV on in case you can't find the remote control or its batteries are empty.

Switch to standby

To switch the TV to standby, press  on the remote control. You can also press the small joystick key on the back of the TV.

In standby mode, the TV is still connected to the mains power but consumes very little energy.

To switch off the TV completely, disconnect the power plug. When disconnecting the power plug, always pull the power plug, never the cord. Ensure that you have full access to the power plug, power cord and outlet socket at all times.

5.2

Keys on TV

If you lost the remote control or its batteries are empty, you can still do some basic TV operations.

To open the basic menu… 1 - With the TV switched on, press the joystick key on

the back of the TV to bring up the basic menu. 2 - Press left or right to select  Volume, Channel or  Sources. Select  Demo, to start a demo movie. 3 - Press up or down to adjust the volume or tune to the next or previous channel. Press up or down to go through the list of sources, including the tuner selection. Press the joystick key to start the demo



To set the Sleep Timer…

1 - Press , select General settings > Sleep timer and press OK.

2 - With the slider bar you can set the time to up to 180 minutes in increments of 5 minutes. If set to 0 minutes, the Sleep Timer is switched off. You can always switch off your TV earlier or reset the time during the countdown. 3 - Press  BACK to close the menu.

5.4

Switch off timer

If the TV receives a TV signal but you don't press a key on the remote control during a 4 hour period, the TV switches off automatically to save energy. Also, if the TV does not receive a TV signal nor a remote control command for 10 minutes, the TV switches off automatically.

If you use the TV as a monitor or use a digital receiver to watch TV (a Set-Top Box - STB) and you do not use the remote control of the TV, you should deactivate this automatic switch off.

To deactivate the Switch Off Timer … 1 - Press , select Eco settings and

press  (right) to enter the menu.

2 - Select Switch off timer and press OK. 3 - Press the arrows  (up) or  (down) to adjust

the value. The value 0 deactivates the automatic switch off. 4 - Press  (left) repeatedly if necessary, to close the menu.

For more information on environmentally friendly TV settings, in Help, press the colour

key  Keywords and look up Eco settings.

Remote control

6.1

Key overview

Top

1 -  Home

To open the Home menu. 2 -  SMART TV

To open the Smart TV start page.

1 -  Standby / On To switch the TV on or back to Standby.

2 - Playback and Record

• Play , to playback.

• Pause , to pause playback

• Stop , to stop playback

• Rewind , to rewind

• Fast forward , to go fast forward

• Record , to start recording 3 -  Picture Format

To open or close the Picture Format menu. 4 -  TV GUIDE

To open or close the TV Guide. 5 -  Search

To open the searches page. 6 -  Settings

To open the Settings menu. 7 - SOURCES

To open the Sources menu. 8 -  LIST

To open or close the channel list.

3 -

   

Direct selection of options. Blue key , opens Help. 4 -  INFO

To open or close programme info. 5 -  BACK

To switch back to the previous channel you selected. To close a menu without changing a setting. To go back to the previous App/Internet page.

6 - EXIT To switch back to watch TV.

7 To open or close the Options menu.

8 - OK key To confirm a selection or setting. To open the channel list while watching TV.

9 - Arrow / navigation keys To navigate up, down, left or right.

10 -  MULTIVIEW To open an extra small screen of TV channel on the corner of the TV screen. This function enables user to watch TV channel while TV is on a Smart TV App or the Internet.

OPTIONS



Colour keys

Middle

Bottom

1 -



To open the Netflix App directly. With the TV switched on or from standby.

2 To adjust the volume level.

3 - Number keys To select a channel directly.

4 - SUBTITLE To switch subtitle on, off or to show automatically.

Volume



6.3

Batteries

If the TV does not react on a key press on the remote control, the batteries might be empty.

To replace the batteries, open the battery compartment on the back of the remote control.

1 - Slide the battery door in the direction shown by the arrow. 2 - Replace the old batteries with 2 type AAA-R03-1.5V batteries. Make sure the + and the - ends of the batteries line up correctly. 3 - Reposition the battery door and slide it back until it clicks.

Remove the batteries if you are not using the remote control for a long time. Safely dispose of your old batteries according to the end of use directions.

For more information, in Help, press the colour key  Keywords and look up End of use.

6.4

Cleaning

5 -  Channel

To switch to the next or previous channel in the channel list. To start the next or previous chapter on a disc.

6 To mute the sound or to restore it.

7 - TEXT To open or close Text/Teletext.

6.2



Mute

IR sensor

The TV can receive commands from a remote control that uses IR (infrared) to send commands. If you use such a remote control, always make sure you point the remote control at the infrared sensor on the front of the TV.

Warning



Do not put any objects in front of IR sensor of the TV, it may block the IR signal.

Your remote control is treated with a scratch-resistant coating.

To clean the remote control, use a soft damp cloth. Never use substances such as alcohol, chemicals or household cleaners on the remote control.

Channel icons

Channels

7.1

Install Channels

For more information, in Help, press the colour key  Keywords and look up Channel, Antenna installation or Channel, Cable installation.

7.2

Switch channels

• To watch TV channels, press EXIT. The TV tunes to the TV channel you last watched.

• Alternatively, press  Home to open the Home menu and select Channels and press OK.

• To switch channels, press  + or know the channel number, type in the number with the number keys. Press OK after you entered the number to switch channels.

• To switch back to the previously tuned channel, press  BACK .

To switch to a channel from a channel list

While watching a TV channel, press  LIST to open the channel lists.

The channel list can have several pages with channels. To view the next or previous page, press  + or  -.

To close the channel lists without switching channels, press  LIST again.

Radio channels

 

. If you

If you lock a channel, it will be marked with a  (lock).

Radio stations

If digital broadcasting is available, digital radio stations are installed during installation. Switch to a radio channel just like you switch to a TV channel.

Channel list views

In the channel lists, you can find all installed TV and radio channels.

Next to the channel list All, which holds all installed channels, you can set up a list of Favourites, view the installed Radio stations separately or discover the newly added channels in New channels.

Open a Channel List

Next to the list with all channels for each tuner, Antenna or Cable, you can select a filtered list or you can select one of the favourite lists you created.

To open the current channel list…

1 - Press EXIT, to switch to TV. 2 - Press  LIST to open the current channel list. 3 - Press  LIST again to close the channel list.

Alternatively, you can select the list name at the top of the channel list and press OK to open the list menu.

If digital broadcasting is available, digital radio stations are installed during installation. Switch to a radio channel just like you switch to a TV channel.

7.3

Channel lists

About channel lists

After a channel installation, all channels appear the channel list. Channels are shown with their name and logo if this information is available.

For each type of tuner - Antenna or Cable - there is a channel list with all installed channels. You can filter this list to only show TV or only Radio channels.

With a channel list selected, you can only tune to the channels in that list when using

 

 

keys.

Filter a Channel List

You can filter a list with all channels. You can set the channel list to show only Digital TV channels or only Analogue channels.

To set a filter on a list with all channels…

1 - Press EXIT. 2 - Press  LIST to open the current channel list. 3 - Press  OPTIONS. 4 - Select Digital + Analogue and press OK. 5 - Select the list you want to filter. 6 - In the Options menu, select the filter you want

and press OK to activate. The name of the filter appears as part of the channel list name on top of the channel list. 7 - Press  (left) to go back one step or press  BACK to close the menu.

Search for a Channel

Tune to a channel

You can search for a channel to find it in a long list of channels.

The TV can search for a channel within one of the channel lists - the Antenna or Cable channel list.

To search for a channel… 1 - Press  LIST to open the current channel list

and select All.

2 - Press  OPTIONS. 3 - Select Digital + Analogue and press OK. 4 - Select the list you want to filter and press OK. 5 - Press the colour key

open Find Channel and press OK to open a text field. 6 - Enter a number, a name or part of a name and select Done and press OK. The TV will search for matching channel names in the list you selected.

Search results are listed as a channel list - see the list name at the top. The search results disappear once you select another channel list or close the list with search results.

(green) to



To start watching TV channels, press EXIT. The TV tunes to the channel you last watched.

Switch Channels

To switch channels, press   or  . If you know the channel number, type in the number with the number keys. Press OK after you entered the number to switch immediately.

Previous channel

To switch back to the previously tuned channel, press  BACK.

Child Lock/ Lock a channel

Lock and unlock a channel

To prevent children from watching a channel, you can lock a channel. To watch a locked channel, you must enter the 4 digit Child Lock PIN code first. You cannot lock programmes from connected devices.

To lock a channel…

Rename channels

You can rename channels in the channel list. 1 - Select the channel you want to rename in one of

the channel lists.

2 - Select the channel to rename. 3 - Press .

You can enter text with the remote control keyboard or open the on-screen keyboard.

With the on-screen keyboard

• To open the on-screen keyboard, place the cursor in the name text field and press OK.

• To delete the character in front of the cursor, press  Backspace .

• To enter a character, select the character with the arrow keys and press OK.

• To select uppercase characters, press .

• To select numbers or special characters, press .

• When you are ready, press  BACK to close the on-screen keyboard.

• To finish renaming, select Done and press OK.

7.4

Watching channels

1 - Press EXIT. 2 - Press

necessary change the channel list.

3 - Select the channel you want to lock. 4 - Press  OPTIONS and select Channel

lock and press OK.

5 - Enter your 4 digit PIN code if the TV asks for it. A locked channel is marked with a  (lock). 6 - Press  (left) to go back one step or press  to close the menu.

To unlock a channel…

1 - Press EXIT. 2 - Press

necessary change the channel list.

3 - Select the channel you want to unlock. 4 - Press  OPTIONS and select Unlock

Channel and press OK.

5 - Enter your 4 digit PIN code if the TV asks for it. 6 - Press  (left) to go back one step or

press  to close the menu. If you lock or unlock channels in a channel list, you

only have to enter the PIN code just once until you close the channel list.

For more information, in Help, press the colour key  Keywords and look up Child Lock for more information.

LIST to open the channel list. If



LIST to open the channel list. If



Parental rating

To prevent children from watching a programme not suitable for their age, you can set an age rating.

Digital channels can have their programmes age rated. When the age rating of a programme is equal to or higher than the age you have set as age rating for your child, the programme will be locked. To watch a locked programme, you must enter the Parental rating code first.

To set an age rating…

1 - Press , select Child lock > Parental rating and press OK.

2 - Enter a 4-digit Child lock code. If you did not set a code yet, select Set code in Child lock. Enter a 4-digit Child lock code and confirm. Now you can set an age rating. 3 - Back in Parental rating, select the age and press OK. 4 - Press  (left) repeatedly if necessary, to close the menu.

again to confirm. 5 - Press  (left) repeatedly if necessary, to close the menu.

The new code is set.

Channel options

Open options

While watching a channel, you can set some options. Depending on the type of channel you are watching

(analogue or digital) or depending on the TV settings you made, some options are available.

To open the options menu…

1 - While watching a channel, press  OPTIONS. 2 - Press  OPTIONS again to close.

Subtitles

To switch off the parental age rating, select None. However, in some countries you must set an age rating.

For some broadcasters/operators, the TV only locks programmes with a higher rating. The parental age rating is set for all channels.

Set code/ Change code

The Child Lock PIN code is used to lock or unlock channels or programmes.

To set the lock code or to change the current code… 1 - Press , select Child lock and press  (right)

to enter the menu. 2 - Select Set code or Change code and press OK. 3 - Enter a 4 digit code of your choice. If a code is set already, enter the current Child Lock code and then enter the new code twice. 4 - Press  (left) repeatedly if necessary, to close the menu.

The new code is set.

Forgotten your Child Lock PIN code?

If you forgot your PIN code, you can override the current code and enter a new code.

To switch on Subtitles, press SUBTITLE. You can switch subtitles on or off with Subtitles on

or Subtitles off. Alternatively you can select Automatic.

Automatic

If language information is part of the digital broadcast and the broadcasted programme is not in your language (the language set on TV), the TV can show subtitles automatically in one of your preferred subtitle languages. One of these subtitle languages must also be part of the broadcast.

You can select your preferred subtitle languages in Subtitle language.

Subtitle Language

Select the desired subtitle language. For more information, in Help, press  Keywords and look up Subtitle language.

Audio language

For digital broadcast, you can select an available audio language temporarily if none of your preferred languages are available. For more information, in Help, press  Keywords and look up Audio language.

1 - Press , select Child lock and press  (right) to enter the menu.

2 - Select Change code and press OK. 3 - Enter the overriding code 8888. 4 - Now enter a new Child Lock PIN code and enter it

Status

Set up your Favourites List

You can view the technical characteristics of a particular channel, like digital or analogue, sound type, etc.

To view the technical information on a channel…

1 - Tune to the channel. 2 - Press  OPTIONS, select Status and

press OK.

3 - To close this screen, press OK.

Dual I-II

If an audio signal contains two audio languages but one language or both has no language indication, this option is available.

Mono / Stereo

You can switch the sound of an analogue channel to Mono or Stereo.

To switch to Mono or Stereo…

You can create a favourite channel list that only holds the channels you want to watch. With the Favourite channel list selected, you will only see your favourite channels when you switch through channels.

Create your favourite channel list

1 - While watching a TV channel, press open the channel list.

2 - Select All to view all channels. 3 - Select the channel, and press  to mark as

favourite.

4 - The selected channel is marked with a . 5 - To finish, press  BACK . The channels are

added to the Favourites list. To remove a channel from the favourites list, select

the channel with , then press  again to unmark as favourite.



LIST to

Reorder Channels

1 - Tune to an analoge channel. 2 - Press  OPTIONS, select Mono/Stereo and

press  (right).

3 - Select Mono or Stereo and press OK. 4 - Press  (left) to go back one step or

press  BACK to close the menu.

Enables the user to communicate his activity with his social networks.

7.5

Favourite Channels

About Favourite Channels

In a favourite channel list, you can collect the channels you like.

With a Favourites List selected, you can only tune to the channels in that list when using the

 

 

keys.

Reorder

You can reorder — reposition — channels in the Favourite channel list.

1 - In the channel list Favourites, highlight the channel you want to reposition.

2 - Press . 3 - Select the channel to reorder and press OK. 4 - Press the Navigation buttons to move the

highlighted channel to another location and press OK.

5 - Press 6 - Once complete, press EXIT to exit from

the Favourite channel list. You can highlight another channel and do the same.



(Done).

+ 62 hidden pages

Philips 65PUT6162S, 55PUT6102, 55PUT6102S, 50PUT6102S, 65PUT6162 User Manual

Contents
