Philips 6581, 49PUS6581, 55PUS6581 User Manual
Register your product and get support at
www.philips.com/welcome
6581 series
User Manual
49PUS6581
55PUS6581
Contents
1 What's new 4
1.1 All-in-one source menu 4
1.2 Top picks 4
1.3 Media browser 5
2 Setting Up 6
2.1 Read Safety 6
2.2 TV Stand and Wall Mounting 6
2.3 Tips on Placement 6
2.4 Power Cable 6
2.5 Antenna Cable 7
2.6 Satellite Dish 7
3 Remote Control 8
3.1 Key Overview 8
3.2 Pairing the Remote Control 9
3.3 Voice Search 9
3.4 Touch Pad 10
3.5 Keyboard 10
3.6 Remote Control Sensor 11
3.7 Batteries 11
3.8 Cleaning 11
4 Switching On and Off 13
4.1 On or Standby 13
4.2 Keys on TV 13
5 Channels 14
5.1 Satellite Installation 14
5.2 Antenna/Cable Installation 16
5.3 Channel List Copy 18
5.4 About Channels 19
6 Connect Devices 26
6.1 About Connections 26
6.2 HDMI Ports 26
6.3 Y Pb Pr - Component 28
6.4 Scart 28
6.5 Audio Out - Optical 28
6.6 CAM with Smart Card - CI+ 28
6.7 Receiver - Set-Top Box 29
6.8 Home Theatre System - HTS 30
6.9 Smartphones and Tablets 31
6.10 Blu-ray Disc Player 31
6.11 DVD Player 31
6.12 Bluetooth - Speakers and Gamepads 31
6.13 Headphones 32
6.14 Game Console 33
6.15 Gamepad 33
6.16 USB Hard Drive 34
6.17 USB Keyboard 35
6.18 USB Flash Drive 35
6.19 Photo Camera 36
6.20 Camcorder 36
6.21 Computer 36
7 Connect your Android TV 38
7.1 Network and Internet 38
7.2 Google Account 40
7.3 Philips App Gallery 41
7.4 Android Settings 41
7.5 Home Menu 42
8 Apps 43
8.1 About Apps 43
8.2 Google Play 43
8.3 Start or Stop an App 44
8.4 Lock Apps 44
8.5 Manage Apps 45
8.6 Storage 46
9 Internet 47
9.1 Start Internet 47
9.2 Options on Internet 47
10 TV Menu 48
10.1 About TV Menu 48
10.2 Open TV Menu 48
11 Sources 49
11.1 Switch to a device 49
11.2 Options for a TV Input 49
11.3 Device Name and Type 49
11.4 Computer 49
12 Settings 51
12.1 Frequent Settings 51
12.2 Picture 51
12.3 Sound 55
12.4 Ambilight Settings 58
12.5 Eco Settings 60
12.6 General Settings 61
12.7 Clock, Region and Language 63
12.8 Universal Access 66
12.9 Child Lock 67
13 Videos, Photos and Music 68
13.1 From a USB Connection 68
13.2 From a Computer or NAS 68
13.3 From a Cloud Storage Service 68
13.4 Favourites, Most Popular, Last Played menu
68
13.5 Play your Videos 68
13.6 View your Photos 69
13.7 Play your Music 69
14 TV Guide 71
14.1 What You Need 71
14.2 TV Guide Data 71
14.3 Using the TV Guide 71
15 Recording and Pause TV 73
15.1 Recording 73
15.2 Pause TV 74
16 Smartphones and Tablets 75
16.1 Philips TV Remote App 75
16.2 Google Cast 75
16.3 AirPlay 75
16.4 MHL 75
17 Games 76
17.1 What You Need 76
17.2 Play a Game 76
18 Ambilight 77
18.1 Ambilight Style 77
18.2 Ambilight Off 77
18.3 Ambilight Settings 77
19 Top Picks 79
19.1 About Top Picks 79
19.2 Now on TV 79
19.3 TV on Demand 79
2
19.4 Video on Demand 79
20 Netflix 81
21 Multi View 82
21.1 Text and TV 82
21.2 HDMI and TV 82
21.3 Nettv and TV 82
21.4 Nettv and HDMI 82
22 Software 83
22.1 Update Software 83
22.2 Software Version 83
22.3 Open Source Software 83
22.4 Open Source License 83
22.5 Announcements 111
23 Specifications 112
23.1 Environmental 112
23.2 Power 112
23.3 Operating System 112
23.4 Reception 113
23.5 Display Type 113
23.6 Display Input Resolution 113
23.7 Dimensions and Weights 113
23.8 Connectivity 113
23.9 Sound 113
23.10 Multimedia 114
24 Help and Support 115
24.1 Register your TV 115
24.2 Using Help 115
24.3 Troubleshooting 115
24.4 Online Help 117
24.5 Support and Repair 117
25 Safety and Care 118
25.1 Safety 118
25.2 Screen Care 119
26 Terms of Use 120
26.1 Terms of Use - TV 120
26.2 Terms of Use - Philips App Gallery 120
27 Copyrights 121
27.1 MHL 121
27.2 Ultra HD 121
27.3 HDMI 121
27.4 Dolby Digital Plus 121
27.5 DTS Premium Sound ™ 121
27.6 Microsoft 121
27.7 Wi-Fi Alliance 121
27.8 Kensington 122
27.9 Other Trademarks 122
28 Disclaimer regarding services and/or
software offered by third parties 123
Index 124
3
1
What's new
1.1
All-in-one source menu
About All-in-one source menu
For the first time you press SOURCES, you can
see instructions how to set your source menu.
The improved source menu contains normal source
menu, easily open TV Guide, and also you can
use (plus key) to set a reminder or schedule a
recording in TV Guide.
An all-in-one Sources menu, a restyled TV guide and
a new easy programme browser.
Your list of favourite channels is now part of
the Sources menu. Same for the channel lists of
both tuners Antenna/Cable and
The new Sources menu will have all connected
devices in the list but also all tuners, so in the
Sources menu the user will find all possible ‘sources’
for TV.
Satellite.
Improved TV guide
A clear and better looking TV guide. Select a
programme and read the programme info or
press to set a reminder or schedule a recording.
Switch from tuner, channel, and TV
guide
Select a tuner source and press to open the list of
channels. Press again to open the TV guide
to see what’s on. Press to return to the list of
channels.
1.2
Top picks
With TOP PICKS your TV recommends current
TV programmes, the latest rental videos and Online
TV services for you to watch.
1 - Press TOP PICKS.
2 - Select one programme and use (plus key) to
schedule a recording, set a reminder or watch the
programme.
3 - Use Arrow / navigation keys to select 3 dots on
the right-top of the screen, then press OK to
open OPTIONS menu.
Select to record, or select to set a reminder
4
Select to mark as favourites
1.3
Media browser
Browse your media as you like it or mark any channel,
song or photo as a favourite easily.
1 - Press (plus key) to mark any video, song or
photo as a favourite.
2 - You can view videos, songs, and photos in grid
view or list view.
3 - Use Arrow / navigation keys to select 3 dots on
the right-top of the screen, then press OK to
open OPTIONS menu.
4 - When playing, there is a secondary control bar on
the bottom of the screen, use the arrows
and OK key to select what you want.
Grid view
List view
5
2
Setting Up
2.1
Read Safety
Read the safety instructions first before you use the
TV.
For more information, in Help, select Keywords and
look up Safety Instructions.
2.2
TV Stand and Wall Mounting
TV Stand
You can find the instructions for mounting the TV
stand in the Quick Start Guide that came with the TV.
In case you lost this guide, you can download it
from www.philips.com.
Use the model number of the TV to look for
the Quick Start Guide to download.
Wall Mounting
Your TV is also prepared for a VESA-compliant wall
mount bracket (sold separately).
Use the following VESA code when purchasing the
wall mount . . .
VESA MIS-F 400x200, M6
• 65PUS6521
VESA MIS-F 400x200, M6
Preparation
First remove the 4 plastic screw caps out of the
threaded bushes on the back of the TV.
Make sure that the metal screws, to mount the TV to
the VESA-compliant bracket, go about 10mm deep
inside the threaded bushes of the TV.
Caution
Wall mounting the TV requires special skills and
should only be performed by qualified personnel. The
TV wall mounting should meet safety standards
according to the TVs weight. Also read the safety
precautions before positioning the TV.
TP Vision Europe B.V. bears no responsibility for
improper mounting or any mounting that results in
accident or injury.
2.3
Tips on Placement
• Position the TV where light does not shine directly
on the screen.
• Position the TV up to 15 cm away from the wall.
• The ideal distance to watch TV is 3 times its diagonal
screen size. When seated, your eyes should be level
with the centre of the screen.
15
cm
• 43PUS6501
VESA MIS-F 200x200, M6
• 49PUS6501, 49PUS6551, 49PUS6561
VESA MIS-F 400x200, M6
• 55PUS6501, 55PUS6551, 55PUS6561, 55PUS6581
2.4
Power Cable
• Insert the power cable into the POWER connector
on the back of the TV.
• Make sure the power cable is securely inserted in
the connector.
• Make sure that the power plug, in the wall socket, is
accessible at all times.
• When you unplug the power cable, always pull the
plug, never pull the cable.
6
Although this TV has a very low standby power
consumption, unplug the power cable to save energy
if you do not use the TV for a long period of time.
2.5
Antenna Cable
Insert the antenna plug firmly into
the Antenna socket at the back of the TV.
You can connect your own antenna or an antenna
signal from an antenna distribution system. Use an
IEC Coax 75 Ohm RF antenna connector.
Use this antenna connection for DVB-T and DVB-C
input signals.
2.6
Satellite Dish
Attach the satellite F-type connector to the satellite
connection SAT at the back of the TV.
7
3
Remote Control
3.1
Key Overview
Top
1 - Standby / On
To switch the TV on or back to Standby.
2 - VOICE microphone
3 - LIST
To open or close the channel list.
4 -
To select one of the Ambilight style.
5 - TV GUIDE
To open or close the TV Guide.
6 - SETTINGS
To open the Frequent Settings.
7 - TOP PICKS
To open the menu with recommended programmes,
Video on Demand (Rental Videos) or Online TV
(Catch Up TV).
If available.
8 - VOICE
To start speaking your voice search.
AMBILIGHT
1 - TV Menu
To open the TV Menu with typical TV functions.
2 - SOURCES
To open or close the Sources menu.
3 - INFO
To open or close programme info.
4 - BACK
To switch back to the previous channel you selected.
To return to previous menu.
To go back to the previous App/Internet page.
5 -
Direct selection of options.
6 - EXIT
To switch back to watching TV. To leave an interactive
TV application.
7 - OPTIONS
To open or close the Options menu.
8 - OK key
To confirm a selection or setting.
9 - Arrow / navigation keys
To navigate up, down, left or right.
10 - HOME
To open the Home menu.
Colour keys
Middle
Bottom
8
Pair again
If the pairing with the remote control was lost, you
can pair the TV with the remote control again.
To start pairing...
1 - On the back of the TV, standing in front of the TV
at the right, press the joystick power key in for 3
seconds. A message will show that the TV is ready to
pair.
2 - Press the colour keys (red) and (blue)
simultaneously for 1 second. A message appears
when the pairing is successful.
3.3
1 -
To open the Netflix App directly. With the TV switched
on or from standby.
2 To adjust the volume level.
3 - Number keys
To select a channel directly.
4 - SUBTITLE
To switch subtitles on, off or to show automatically.
5 - Playback and Record
• Play , to playback.
• Pause , to pause playback
• Stop , to stop playback
• Rewind , to rewind
• Fast forward , to go fast forward
• Record , to start recording
6 - Channel
To switch to the next or previous channel in the
channel list. To open the next or previous page in
Text/Teletext. To start the next or previous chapter on
a disc.
7 To mute the sound or to restore it.
8 - TEXT
To open or close Text/Teletext.
3.2
Volume
Mute
Voice Search
You can search for videos, music or anything else on
the Internet by simply using your voice. You can
speak into the microphone on the remote control.
Alternatively, you can use the remote control
keyboard to enter text.
To use Voice…
1 - Press VOICE. The blue light on the remote
control lights up and the search field opens. As long
as the icon is red on screen, the microphone is
active.
2 - Speak out clearly what you are looking for. You
can speak for 10 seconds before the microphone
switches off. It might take some time for the results to
appear.
3 - In the list of search results, you can select the
item you want.
4 - Press BACK to close the search results if
necessary.
To use the remote control keyboard to search…
1 - Press VOICE to open the search field.
2 - Press (right) to highlight the text field.
3 - Turn the remote control keyboard facing upwards
and type what you are looking for.
4 - Press BACK to hide the onscreen keyboard.
5 - In the list of search results, you can select the
item you want.
6 - Press BACK to close the search results if
necessary.
Pairing the Remote Control
For the remote control to communicate with the TV,
both TV and remote control should be paired (linked)
with each other.
Pairing
When you started the initial TV installation, the TV
invited you to press the OK key, and by doing so,
the pairing was done. If the TV does not react on any
remote control key press, pairing was unsuccessful.
See also www.support.google.com/androidtv
Voice Settings
You can set the language you like to use with Voice.
To set the language for Voice Search…
1 - Press , select All Settings and press OK.
2 - Select Android Settings and press OK.
3 - Select Preferences > Speech and
press OK.
9
4 - Select the language you want to use and
press OK.
5 - Press BACK to go back one step or
press EXIT to close the menu.
3.4
Touch Pad
in your remote control, even you reload batteries.
3.5
Keyboard
Overview
The diamond shaped area of the navigation keys on
the remote control - the keys for up, down, left and
right - is also a small touch pad. You can use this
touch pad to swipe through long lists or to go through
a list step by step.
How to use the touch pad…
1 - Open any kind of TV menu with a list, e.g. the
Home menu or Channel list.
2 - Use your thumb to swipe across the touch pad
and towards the direction the list must scroll. Up or
down, or left to right. If you swipe the touch pad, the
highlight will move 1 step. If you swipe and then hold
your thumb on the touch pad (no need to press), the
highlight will scroll through the list until you lift your
thumb from the touch pad.
Take some time to learn this swipe or swipe and hold
gesture. It's really helpful to go through long lists.
Activate/Deactivate touch pad function
To deactivate touch pad on remote control...
1 - Press remote control number keys 8, 6, 8, 7,
and Mute key in sequential order.
Qwerty and Azerty
Overview of a Qwerty/Azerty keyboard.*
1 - Azerty character
Character position if the keyboard layout is set to
Azerty.
2 To type uppercase characters.
3 - Fn key
To type a number or punctuation character.
4 - Spacebar
5 - Navigation and OK
6 - Share this
To share online what you are watching at the
moment.
Shift
2 - The remote control LED indicator lights blue, your
remote control touch pad function is switched off
successfully.
3 - To reactivate touch pad function, you may repeat
the above steps.
Note: The setting (activate/deactivate) will be stored
* Your remote control has a Qwerty / Azerty or a
Qwerty / Cyrillic keyboard, depending on your region.
Qwerty and Cyrillic
Overview of a Qwerty/Cyrillic keyboard.*
1 - Cyrillic characters
Characters available when the keyboard is switched
to Cyrillic.
2 - Cyrillic keyboard switch
To switch the keyboard to the Cyrillic characters or
back to Qwerty.
3 To type uppercase characters.
4 - Fn key
To type a number or punctuation character
5 - Spacebar
6 - Share this
To share online what you are watching at the
moment.
Shift
10
7 - Navigation and OK
* Your remote control has a Qwerty/Azerty or a
Qwerty/Cyrillic keyboard, depending on your region.
Writing Text
Cyrillic keyboard
Depending on your region, the Remote Control
Keyboard can be switched to Cyrillic characters.
The Cyrillic characters are shown at the top right of
the keyboard keys.
To write Cyrillic characters…
With the keyboard on the back of the remote control,
you can write text in any text field on screen.
To write text…
1 - Select a text field if it is not yet selected.
2 - Turn the remote control keyboard facing upwards
to activate the keyboard keys. Hold the remote
control with two hands and type with both thumbs.
3 - To hide the on screen keyboard, press BACK.
Press OK to confirm the text.
On-screen Keyboard
If you use the on-screen keyboard to enter text, you
can configure the keyboard layout to a layout you are
used to.
To open these settings…
Press HOME, select All Settings and press OK.
5 - Select Android Settings and press OK.
6 - Select Preferences > Keyboard and
press OK.
7 - Select Configure > Language and press OK.
You can set your language keyboard layout here.
8 - Press BACK to close the menu to go back
one step.
• Best distance to operate remote control with the TV
is less than 5 m.
• When using remote control keyboard, best to hold
the remote control with the angle less than 50
degree.
• Do not block the IR ray of the remote control.
Qwerty, Azerty and Cyrillic keyboard
The standard layout of the Remote Control Keyboard
is Qwerty.
Azerty keyboard
Depending on your region, the Remote Control
Keyboard can be set to Azerty. The Azerty characters
are shown at the top right of the relevant keys.
To set the keyboard layout to Azerty…
1 - Press , select All Settings and press OK.
2 - Select Region and Language and
press (right) to enter the menu.
3 - Select Remote Control Keyboard and
press OK.
4 - Select AZERTY or QWERTY and press OK.
5 - Press (left) repeatedly if necessary, to close
the menu.
1 - Press on the remote control.
2 - Press again to switch back to Qwerty.
3.6
Remote Control Sensor
The remote control of the TV uses Bluetooth to send
its commands to the TV. With Bluetooth, you do not
need to point the remote control at the TV.
However, the TV can also receive commands from a
remote control that uses IR (infrared) to send
commands. If you use such a remote control, always
make sure you point the remote control at the
infrared sensor on the front of the TV.
3.7
Batteries
The TV will notify you when the battery power of the
remote control is low.
To replace the batteries, open the battery
compartment on the keyboard side of the remote
control.
1 - Use a small coin or other small, blunt object and
press the rectangular shaped release button to open
the battery lid.
2 - Slide the battery in the direction of the metal
spring and pull the opposite end of the battery out.
3 - Replace the old batteries with 2
type AA-LR6-1.5V alkaline batteries. Make sure the
+ and the - ends of the batteries line up correctly.
4 - Reposition the battery door and push it down
until it clicks.
Remove the batteries if you are not using the remote
control for a long time.
Safely dispose of your old batteries according to the
end of use directions.
For more information, in Help, select Keywords and
look up End of use.
11
3.8
Cleaning
Your remote control is treated with a scratch-resistant
coating.
To clean the remote control, use a soft damp cloth.
Never use substances such as alcohol, chemicals or
household cleaners on the remote control.
12
4
Switching On and
Off
4.1
On or Standby
Make sure the TV is connected to the mains AC
power. Connect the supplied power cord to the AC
in connector at the back of the TV. The indicator light
at the bottom of the TV lights up.
Switch on
Press on the remote control to switch the TV
on. Alternatively, press HOME. You can also
press the small joystick key on the back of the TV to
switch the TV on in case you can't find the remote
control or its batteries are empty.
Switch to standby
movie.
4 - The menu will disappear automatically.
To switch the TV on standby, select and press the
joystick key.
To switch the TV to standby, press on the remote
control. You can also press the small joystick key on
the back of the TV.
In standby mode, the TV is still connected to the
mains power but consumes very little energy.
To switch off the TV completely, disconnect the
power plug.
When disconnecting the power plug, always pull the
power plug, never the cord. Ensure that you have full
access to the power plug, power cord and outlet
socket at all times.
4.2
Keys on TV
If you lost the remote control or its batteries are
empty, you can still do some basic TV operations.
To open the basic menu…
1 - With the TV switched on, press the joystick key on
the back of the TV to bring up the basic menu.
2 - Press left or right to
select Volume, Channel or Sources.
Select Demo, to start a demo movie.
3 - Press up or down to adjust the volume or tune to
the next or previous channel. Press up or down to go
through the list of sources, including the tuner
selection. Press the joystick key to start the demo
13
5
Satellite Installation Settings
Channels
5.1
Satellite Installation
About Installing Satellites
Up to 4 Satellites
You can install up to 4 satellites (4 LNBs) on this TV.
Select the exact number of satellites you wish to
install at the start of the installation. This will speed up
the installation.
Unicable
You can use a Unicable system to connect the
antenna dish to the TV. You can select Unicable for 1
or for 2 satellites at the start of the installation.
Start the Installation
Make sure your satellite dish is connected correctly
and is perfectly aligned before you start the
installation.
The satellite installation settings are preset according
your country. These settings determine how the TV
searches and installs satellites and its channels. You
can always change these settings.
To change the satellite installation settings…
1 - Start the satellite installation.
2 - On the screen where you can start searching for
satellites, select Settings and press OK.
3 - Select the number of satellites you want to install
or select one of the Unicable systems. When you
select Unicable, you can choose the User Band
Numbers and enter the User Band Frequencies for
each tuner.
4 - When you're done, select Next and press OK.
5 - On the Settings menu, press OK to return to the
screen to start searching for satellites.
Homing Transponder and LNB
In some countries, you can adjust the expert settings
for homing transponder and each LNB. Only use or
change these settings when a normal installation fails.
If you have non-standard satellite equipment, you
can use these settings to overrule the standard
settings. Some providers might give you some
transponder or LNB valeus which you can enter here.
To start the satellite installation…
1 - Press , select All Settings and press OK.
2 - Select Channels > Satellite Installation. Enter
your PIN code if necessary.
3 - Select Search for Satellite.
4 - Select Search. TV will search for satellites.
5 - Select Configure. The TV shows the current
satellite installation setup.
If you want to change this setup, select Settings.
If you don't want to change the setup, select Search.
Go to step 7.
6 - In Installation System, select the number of
satellites you want to install or select one of the
Unicable systems. When you select Unicable, you
can choose the User Band Numbers and enter the
User Band Frequencies for each tuner. You can find
user band in unicable router. In some countries, you
can adjust some expert settings for each LNB
in More Settings.
7 - The TV will search for the satellites available on
the alignment of your antenna dish. This may take a
few minutes. If a satellite is found, its name and
reception strength are shown on screen.
8 - When the TV found the satellites you need,
select Install.
9 - If a satellite offers Channel Packages, the TV will
show the available packages for that satellite. Select
the package you need.
10 - To store the satellite setup and installed
channels and radio stations, select Done.
Satellite CAMs
If you use a CAM – a Conditional Access Module with
a smart card – to watch satellite channels, we
recommend to do the satellite installation with the
CAM inserted in the TV.
Most CAMs are used to descramble channels.
Newest generation CAMs (CI+ 1.3 with Operator
Profile), can install all the satellite channels by
themselves on your TV. The CAM will invite you to
install its satellite(s) and channels. These CAMs not
only install and descramble the channels but also
handle regular channel updates.
Channel Packages
Satellite operators can offer channel packages that
bundle free channels (free-to-air) and offer a sorting
that suits a country. Some satellites offer subscription
packages - a collection of channels you pay for.
14
Unicable Setup
Add a Satellite
The Unicable System
You can use a Single Cable system, MDU or Unicable
system to connect the antenna dish to the TV. A
Single Cable system uses one cable to connect the
satellite dish to all satellite tuners in its system. A
Single Cable system is typically used in apartment
buildings. If you use a Unicable system, the TV will ask
you to assign a user band number and corresponding
frequency during the installation. You can install 1 or 2
satellites with Unicable on this TV.
If you notice some missing channels after a Unicable
installation, another installation might have been
done at the same moment on the Unicable system.
Do the installation again to install the missing
channels.
User Band Number
In a Unicable system, each connected satellite tuner
must be numbered (e.g. 0, 1, 2 or 3 etc.).
You can find the available user bands and their
number on the Unicable switchbox. User band is
sometimes shortened as UB. There are Unicable
switchboxes that offer 4 or 8 user bands. If you select
Unicable in the settings, the TV will ask you to assign
the unique user band number for each built-in
satellite tuners. A satellite tuner cannot have the same
user band number as another satellite tuner in the
Unicable system.
User Band Frequency
Next to the unique user band number, the built-in
satellite receiver needs the frequency of the selected
user band number. These frequencies are mostly
shown next to the user band number on a Unicable
switchbox.
You can add an additional satellite to your current
satellite installation. The installed satellites and their
channels remain untouched. Some satellite operators
do not allow adding a satellite.
The additional satellite should be seen as an extra, it
is not your main satellite subscription or not the main
satellite of which you use its channel package.
Typically, you would add a 4th satellite when you
have 3 satellites already installed. If you have 4
satellites installed, you might consider removing one
first to be able to add a new satellite.
Setup
If you currently have only 1 or 2 satellites installed, the
current installation settings might not allow adding an
extra satellite. If you need to change the installation
settings, you must redo the complete satellite
installation. You cannot use Add satellite if a change
of settings is needed.
To add a satellite…
1 - Press , select All Settings and press OK.
2 - Select Channels > Satellite Installation.
3 - Select Search for satellite.
4 - Select Add Satellite. The current satellites are
shown.
5 - Select Search. The TV will search for new
satellites.
6 - If the TV has found one or more satellites,
select Install. The TV installs the channels of the
found satellites.
7 - Select Finish and press OK to store the
channels and radio stations.
Remove a Satellite
Manual Channel Update
You can always start an channel update yourself.
To start a channel update manually…
1 - Press , select All Settings and press OK.
2 - Select Channels > Satellite Installation.
3 - Select Search for Channels.
4 - Select Update Channels. The TV will start
updating. The update may take a few minutes.
5 - Follow the instructions on screen. The update
may take a few minutes.
6 - Select Finish and press OK.
You can remove one or more satellites from your
current satellite installation. You remove the satellite
and its channels. Some satellite operators do not
allow removing a satellite.
To remove satellites…
1 - Press , select All Settings and press OK.
2 - Select Channels > Satellite Installation.
3 - Select Search for satellite.
4 - Select Remove Satellite. The current satellites
are shown.
5 - Select a satellite and press OK to mark or
unmark them to remove.
6 - Press (left) repeatedly if necessary, to close
the menu.
15
Manual Installation
Problems
Manual Installation is intended for expert users.
You can use Manual Installation to quickly add new
channels from a satellite transponder. You need to
know the frequency and polarization of the
transponder. The TV will install all channels of that
transponder. If the transponder was installed before,
all its channels - the former and the new ones - are
moved to the end of the channel list All.
You cannot use Manual installation if you need to
change the number of satellites. If this is needed, you
have to do a complete installation with Install
Satellites.
To install a transponder…
1 - Press , select All Settings and press OK.
2 - Select Channels > Satellite Installation.
3 - Select Manual Installation and press (right)
to enter the menu.
4 - If you have more than 1 satellite installed,
select LNB for which you want to add channels.
5 - Set the Polarisation you need. If you set
the Symbol Rate Mode to Manual, you can enter
the symbol rate in Symbol Rate manually.
6 - Press the arrows (up) or (down) to adjust
the frequency, and select Done.
7 - Select Search and press OK. The signal
strenght is shown on screen.
8 - If you want to store the channels of a new
transponder, select Store and press OK.
9 - Press (left) repeatedly if necessary, to close
the menu.
Homing Transponder and LNB
The TV cannot find the satellites I want or the TV
installs the same satellite twice
• Make sure that the correct number of satellites is set
in Settings at the start of the installation. You can set
the TV to search for One, Two or 3/4 satellites.
A dual head LNB cannot find a second satellite
• If the TV finds one satellite but cannot find a second
one, turn the dish a few degrees. Align the dish to get
the strongest signal on the first satellite. Check the
signal strength indicator of the first satellite on screen.
With the first satellite set at the strongest signal, select
Search again to find the second satellite.
• Make sure the settings are set to Two Satellites.
Changing the installation settings did not solve my
problem
• All settings, satellites and channels are only stored
at the end of the installation when you finish.
All satellite channels are gone
• If you use a Unicable system, make sure you
assigned two unique user band numbers for both
built-in tuners in the Unicable settings. It might be
that another satellite receiver in your Unicable system
is using the same user band number.
Some satellite channels seem to have disappeared
from the channel list
• If some channels seem to be gone or displaced, the
broadcaster might have changed the transponder
location of these channels. To restore the channel
positions in the channel list, you can try an update of
the channel package.
In some countries, you can adjust the expert settings
for homing transponder and each LNB. Only use or
change these settings when a normal installation fails.
If you have non-standard satellite equipment, you
can use these settings to overrule the standard
settings. Some providers might give you some
transponder or LNB valeus which you can enter here.
LNB Power
By default, LNB Power is set to On.
22 kHz Tone
By default, the Tone is set to Auto.
Low LO Frequency / High LO Frequency
The local oscillator frequencies are set to standard
values. Adjust the values only in case of exceptional
equipment that needs different values.
I cannot remove a satellite
• Subscription packages do not allow removing a
satellite. To remove the satellite, you have to do a
complete installation again and select another
package.
Sometimes the reception is poor
• Check if the satellite dish is solidly mounted. Strong
winds can move the dish.
• Snow and rain can degrade the reception.
5.2
Antenna/Cable Installation
16
Update Channels
Reinstall All Channels
Automatic Channel Update
If you receive digital channels, you can set the TV to
automatically update these channels.
Once a day, at 6 AM, the TV updates the channels
and stores new channels. New channels are stored in
the Channels List and are marked with a .
Channels without a signal are removed. The TV must
be in standby to automatically update channels. You
can switch off Automatic Channel Update.
To switch off the automatic update…
1 - Press , select All Settings and press OK.
2 - Select Channels > Antenna/Cable Installation.
3 - Enter your PIN code if necessary.
4 - Select Automatic Channel Update.
5 - Select Off.
6 - Press (left) to go back one step or
press BACK to close the menu.
When new channels are found or if channels are
updated or removed, a message is shown at TV start
up. To avoid this message to appear after every
channel update, you can switch it off.
To switch off the message…
1 - Press , select All Settings and press OK.
2 - Select Channels > Antenna/Cable Installation.
3 - Enter your PIN code if necessary.
4 - Select Channel Update Message.
5 - Select Off.
6 - Press (left) to go back one step or
press BACK to close the menu.
In certain countries, the Automatic channel update is
done while watching TV or on any moment when the
TV is in standby.
Manual Channel Update
You can always start an channel update yourself.
To start a channel update manually…
1 - Press , select All Settings and press OK.
2 - Select Channels > Antenna/Cable Installation.
3 - Enter your PIN code if necessary.
4 - Select Search for Channels.
5 - Select Start.
6 - Select Update Digital Channels, select Next.
7 - Select Start to update the digital channels. This
can take a few minutes.
8 - Press (left) to go back one step or
press BACK to close the menu.
You can reinstall all channels and leave all other TV
settings untouched.
If a PIN code is set, you will need to enter this code
before you can reinstall channels.
To reinstall channels…
1 - Press , select All Settings and press OK.
2 - Select Channels > Antenna/Cable Installation.
3 - Enter your PIN code if necessary.
4 - Select Search for Channels.
5 - Select Start and press OK.
6 - Select Reinstall Channels, select Next and
press OK.
7 - Select the country where you are now and
press OK.
8 - Select Next and press OK.
9 - Select the type of installation you want, Antenna
(DVB-T) or Cable (DVB-C) and press OK.
8 - Select Next and press OK.
11 - Select the type of channels you want, Digital
and Analogue Channels or Only Digital
Channels and press OK.
8 - Select Next and press OK.
13 - Select Start and press OK to update the
digital channels. This can take a few minutes.
14 - Press (left) to go back one step or
press BACK to close the menu.
DVB-T or DVB-C
DVB Settings
Network Frequency Mode
If you intend to use the fast Quick Scan method
in Frequency Scan to search for channels,
select Automatic. The TV will use 1 of the predefined
network frequencies (or HC - homing channel) as
used by most cable operator in your country.
If you received a specific network frequency value to
search for channels, select Manual.
Network Frequency
With the Network Frequency Mode set to Manual,
you can enter the network frequency value received
from your cable operator here. To enter the value, use
the number keys.
17
Frequency Scan
Select the method of searching for channels. You can
select the faster Quick Scan method and use the
predefined settings used by most cable operator in
your country.
If this results in having no channels installed or if
some channels are missing, you can select the
extended Full Scan method. This method will take
more time to search for and install channels.
signal quality of this frequency. The test result is
shown on screen. You can reposition the antenna or
check the connections to possibly improve the
reception.
7 - You can also change the frequency
yourself. Select the frequency number one by one
and use the (up) or (down) keys to change
the value. Select Search and press OK to test the
reception again.
8 - Press (left) repeatedly if necessary, to close
the menu.
Frequency Step Size
The TV searches for channels in steps of 8MHz.
If this results in having no channels installed or if
some channels are missing, you can search in smaller
steps of 1MHz. Using the 1MHz steps will take more
time to search for and install channels.
Digital Channels
If you know your cable operator is not offering digital
channels, you can skip searching for digital channels.
Analogue Channels
If you know your cable operator is not offering
analogue channels, you can skip searching for
analogue channels.
Free / Scrambled
If you have a subscription and a CAM - Conditional
Access Module for pay TV services, select Free +
Scrambled. If you did not subscribe to pay TV
channels or services, you can select Free
Channels Only .
Manual Installation
Analogue TV channels can be manually installed,
channel by channel.
To install analogue channels manually…
1 - Press , select All Settings and press OK.
2 - Select Channels > Antenna/Cable Installation.
Enter your PIN code if necessary.
3 - Select Analogue: Manual Installation.
• System
To set up the TV system, select System.
Select your country or the part of the world where
you are now and press OK.
• Search Channel
To find a channel, select Search Channel. You can
enter a frequency yourself to find a channel or let the
TV search for a channel. Press (right) to
select Search to search for a channel
automatically. The found channel is shown on screen
and if the reception is poor, press Search again. If
you want to store the channel, select Done and
press OK.
• Store
You can store the channel on the current channel
number or as a new channel number.
Select Store Current Channel or Store as New
Channel. The new channel number is shown briefly.
Reception Quality
You can check the quality and signal strength of a
digital channel. If you have your own antenna, you
can reposition the antenna to try and improve the
reception.
To check the reception quality of a digital channel…
1 - Tune to the channel.
2 - Press , select All Settings and press OK.
3 - Select Channels > Antenna/Cable Installation.
Enter your PIN code if necessary.
4 - Select Digital: Reception Test.
5 - Select Search. The digital frequency is shown
for this channel.
6 - Select Search again and press OK to check the
You can redo these steps until you have found all
available analogue TV channels.
5.3
Channel List Copy
Copy a Channel List
To copy a channel list…
1 - Switch on the TV. This TV should have channels
installed.
2 - Plug in a USB flash drive.
3 - Press , select All Settings and press OK.
4 - Select Channels > Channel List Copy.
5 - Select Copy to USB. You might be asked to enter
18
the Child Lock PIN code to copy the channel list.
6 - When copying is done, unplug the USB flash
drive.
7 - Press (left) repeatedly if necessary, to close
the menu.
Now you can upload the copied channel list onto
another Philips TV.
Channel List version
Check the current version of the channel list...
1 - Press , select All Settings and press OK.
2 - Select Channels and press (right) to enter
the menu.
3 - Select Channel List Copy and select Current
Version, then press OK.
4 - Press (left) repeatedly if necessary, to close
the menu.
done, continue with step 2.
2 - Plug in the USB flash drive that holds the channel
list of the other TV.
3 - To start the channel list upload, press ,
select All Settings and press OK.
4 - Select Channels > Channel List Copy > Copy
to TV. Enter your PIN code if necessary.
5 - The TV notifies you if the channel list is copied to
the TV successfully. Unplug the USB flash drive.
5.4
About Channels
Channel Lists
About Channel Lists
After a channel installation, all channels appear on
the channel list. Channels are shown with their name
and logo if this information is available.
Upload a Channel List
To not Installed TVs
Depending on whether your TV is already installed or
not, you must use a different method to upload a
channel list.
To a TV that is not yet installed
1 - Plug in the power plug to start the installation and
select language and country. You can skip the
channel search. Finish the installation.
2 - Plug in the USB flash drive that holds the channel
list of the other TV.
3 - To start the channel list upload, press ,
select All Settings and press OK.
4 - Select Channels > Channel List Copy > Copy
to TV. Enter your PIN code if necessary.
5 - The TV notifies you if the channel list is copied to
the TV successfully. Unplug the USB flash drive.
To Installed TVs
Depending on whether your TV is already installed or
not, you must use a different method to upload a
channel list.
To an already installed TV
1 - Verify the country setting of the TV. (To verify this
setting, see chapter Reinstall All Channels. Start this
procedure until you reach the country setting.
Press BACK to cancel the installation.)
If the country is correct continue with step 2.
If the country is not correct, you need to start a
reinstallation. See chapter Reinstall All Channels and
start the installation. Select the correct country and
skip the channels search. Finish the installation. When
For each type of tuner - Antenna/Cable (DVB-T/C) or
Satellite (DVB-S) - there is a channel list with all
installed channels. You can only filter this list to show
TV or only Radio channels. Or when you have several
satellites installed, you can filter the channels per
satellite.
With a channel list selected, press the
arrows (up) or (down) to select a channel,
then press OK to watch the selected channel. You
only tune to the channels in that list when
using
Channel icons
After an Automatic Channel Update of the channel
list, newly found channels are marked with
a (star).
If you lock a channel, it will be marked with
a (lock).
The 3 most popular channels being watched by
others at this moment are marked with a 1, 2 or 3.
Radio stations
If digital broadcasting is available, digital radio
stations are installed during installation. Switch to a
radio channel just like you switch to a TV channel. A
Cable (DVB-C) channel installation usually places
radio stations from channel number 1001 onwards.
This TV can receive digital television standard DVB .
TV may not work properly with some operators of
digital television , non-compliance with requirements
of the standard in full.
or
keys.
19
Open a Channel List
Next to the list with all channels for each tuner,
Antenna/Cable or Satellite tuner, you can select a
filtered list or you can select one of the favourite lists
you created.
To open the current channel list…
1 - Press , to switch to TV.
2 - Press LIST* or OK to open the current
channel list.
3 - Press BACK to close the channel list.
To select one of the channel lists…
1 - With a channel list open on screen.
2 - Select the list name at the top of the channel list
and press OK to open the list menu.
3 - In the list menu, select one of the available
channel lists and press OK.
Tip
You can easily switch between the two tuners in
the Sources menu.
Press SOURCES and select Watch TV to switch
to the Antenna/Cable tuner. Select Watch
Satellite to switch to the satellite tuner.
The TV will always open the last selected channel list
for the selected tuner.
* If LIST key is available on your remote control
Filter a Channel List
You can filter a list with all channels. You can set the
channel list to show only TV channels or only Radio
stations. For Antenna/Cable channels you can set the
list to show the Free-to-Air or the Scrambled
channels. When you have several satellites installed,
you can filter the satellite channel list per satellite.
To set a filter on a list with all channels…
1 - Press .
2 - Press OK to open the current channel list.
3 - Select at the upper right corner and press OK.
4 - Select Search Channel and press OK to open
a text field.You can use the remote control keyboard
(if available) or the onscreen keyboard to enter text.
5 - Enter a number, a name or part of a name and
select Apply and press OK. The TV will search for
matching channel names in the list you selected.
Search results are listed as a channel list - see the list
name at the top. The search results disappear once
you select another channel list or close the list with
search results.
Watching channels
Tune to a Channel
To start watching TV channels, press . The TV
tunes to the channel you last watched.
Switch Channels
To switch channels, press or .
If you know the channel number, type in the number
with the number keys. Press OK after you entered
the number to switch immediately.
If the information is available from the Internet, the TV
shows the current programme name and details
followed by the next programme name and details.
Previous channel
To switch back to the previously tuned channel,
press BACK.
You can also tune to channels from a Channel List.
Lock a Channel
1 - Press .
2 - Press OK to open the current channel list.
3 - With a channel list open on screen, select the list
name at the top of the channel list and press OK to
open the list menu.
4 - In the list menu, select the list you want to filter.
5 - Press (left) to go back one step or
press to close the menu.
Search for a Channel
You can search for a channel to find it in a long list of
channels.
The TV can search for a channel within one of the 3
main channel lists - the Antenna, Cable or Satellite
channel list.
To search for a channel…
Lock and Unlock a Channel
To prevent children from watching a channel, you can
lock a channel. To watch a locked channel, you must
enter the 4 digit Child Lock PIN code first. You
cannot lock programmes from connected devices.
To lock a channel…
1 - Press .
2 - Press OK to open the channel list. If necessary
change the channel list.
3 - Select at the upper right corner and press OK.
4 - Select Lock/UnLock and press OK.
5 - Enter your 4 digit PIN code if the TV asks for it.
6 - Select the channel you want to lock and
press OK. A locked channel is marked with
a (lock).
7 - Press (left) to go back one step or
press BACK to close the menu.
20
To unlock a channel…
1 - Press .
2 - Press OK to open the channel list. If necessary
change the channel list.
3 - Select at the upper right corner and press OK.
4 - Select Lock/UnLock and press OK.
5 - Enter your 4 digit PIN code if the TV asks for it.
6 - Press (left) to go back one step or
press BACK to close the menu.
If you lock or unlock channels in a channel list, you
only have to enter the PIN code just once until you
close the channel list.
Parental Rating
To prevent children from watching a programme not
suitable for their age, you can set an age rating.
Digital channels can have their programmes age
rated. When the age rating of a programme is equal to
or higher than the age you have set as age rating for
your child, the programme will be locked. To watch a
locked programme, you must enter the Parental
Rating code first.
To set an age rating…
1 - Press , select All Settings and press OK.
2 - Select Child Lock > Parental Rating.
3 - Enter a 4-digit Child lock code. If you did not set
a code yet, select Set Code in Child Lock. Enter a
4-digit Child lock code and confirm. Now you can set
an age rating.
4 - Back in Parental Rating, select the age.
5 - Press (left) repeatedly if necessary, to close
the menu.
To switch off the parental age rating, select None.
However, in some countries you must set an age
rating.
For some broadcasters/operators, the TV only locks
programmes with a higher rating. The parental age
rating is set for all channels.
Rename Channel
While watching a channel, you can rename channel.
To rename a channel…
1 - While watching a channel, press OPTIONS.
2 - Select
Preferences > Rename Channel.
3 - Use the keyboard on the back of the remote
control to delete the current name and enter a new
name.
Common Interface
If you installed a CAM in one of the Common
Interface slots, you can view the CAM and operator
information or do some CAM related settings.
To view the CAM information…
1 - Press SOURCES.
2 - Select the channel type you are using the CAM
for, Watch TV or Watch Satellite.
3 - Press OPTIONS and
select
Preferences > Common Interface.
4 - Select the appropriate Common Interface slot
and press (right).
5 - Select the TV operator of the CAM and press OK.
The following screens come from the TV operator.
HbbTV on this Channel
If you want to avoid access to HbbTV pages on a
specific channel, you can block the HbbTV pages for
this channel only.
1 - Tune to the channel of which you want to block
the HbbTV pages.
2 - Press OPTIONS,
select Preferences > HbbTV on this Channel and
press (right).
3 - Select Off and press OK.
4 - Press (left) to go back one step or
press BACK to close the menu.
Channel Options
Open Options
While watching a channel, you can set some options.
Depending on the type of channel you are watching
or depending on the TV settings you made, some
options are available.
To open the options menu…
1 - While watching a channel,
press OPTIONS >
Preferences.
2 - Press OPTIONS again to close.
To block HbbTV on TV completely…
1 - Press , select All Settings and press OK.
2 - Select General Settings > Advanced > HbbTV.
3 - Select Off and press OK.
4 - Press (left) to go back one step or
press BACK to close the menu.
Channel Info
You can view the technical characteristics of a
particular channel, like digital or sound type, etc.
To view the technical information on a channel…
1 - Tune to the channel.
2 - Press OPTIONS, select
21
Preferences and
press OK.
3 - Select Channel Info and press OK.
4 - To close this screen, press OK.
Programme Info
View programme details
To call up the details of the selected programme…
1 - Tune to the channel.
2 - Press OPTIONS, select
press OK.
3 - Select Programme Info and press OK, you can
see progrmme information.
4 - Press BACK to close.
Mono / Stereo
You can switch the sound of an analogue channel to
Mono or Stereo.
To switch to Mono or Stereo…
1 - Tune to an analoge channel.
2 - Press OPTIONS, and
select
press (right).
3 - Select Mono or Stereo and press OK.
4 - Press (left) to go back one step or
press BACK to close the menu.
Preferences > Mono/Stereo and
Preferences and
4 - While watching a channel, press OPTIONS.
5 - Select
6 - Select one item in the list and press OK.
7 - Select Map Channel.
8 - Once completed, you will see the mapped
channel information in the programme.
Change Logo
If there is no programme information in the beginning,
you can get more programme information using
below steps.
1 - Press TV GUIDE, and use navigation keys to
select at the middle and press OK.
2 - Select TV Guide > From the Broadcaster and
press OK.
3 - Select one of channels in TV guide, then
press OK to watch the selected channel.
4 - While watching a channel, press OPTIONS.
5 - Select
6 - Select one item in the list and press OK.
7 - Select Change Logo.
8 - Once completed, you will see the mapped
channel information in the programme.
Preferences > Map Channel.
Preferences > Change Logo.
Favourite Channels
About Favourite Channels
Video Selection
Digital TV channels can offer multi video signals (multifeed broadcast), different camera viewpoints or
angles of the same event or different programmes on
one TV channel. The TV shows a message if any such
TV channels are available.
Dual I-II
If an audio signal contains two audio languages but
one language or both has no language indication, this
option is available.
Map Channel
If there is no programme information in the beginning,
you can do map channel to get more programme
information.
1 - Press TV GUIDE, and use navigation keys to
select at the middle and press OK.
2 - Select TV Guide > From the Internet and
press OK.
3 - Select one of channels in TV guide, then
press OK to watch the selected channel.
In a favourite channel list, you can collect the
channels you like.
You can create 8 lists of favourite channels for easy
channel zapping. You can name each Favourites List
individually. Only in a Favourites List you can reorder
channels.
With a Favourites List selected, press the
arrows (up) or (down) to select a channel,
then press OK to watch the selected channel. You
only tune to the channels in that list when
using
Create a Favourites List
To create a favourite channels list from channel list...
1 - Press , to switch to TV.
2 - Press LIST (if available) or OK to open the
current channel list.
3 - Select at the upper right corner and press OK.
4 - Select Create Favourites list and press OK.
5 - In the list at the left, select a channel you want as
a favourite and press OPTIONS. Channels come in
the list at the right in the order you add them. To
undo, select the channel in the list at the left and
press OPTIONS again. You can also select a
range of channels by pressing (down) to select
or
keys.
22
the last channel of the range you want to add and
then press OK.
6 - To finish adding channels, press BACK.
7 - The TV will ask to rename the Favourites List.
You can use the on-screen keyboard
or press BACK to hide the on-screen keyboard,
then use the keyboard on the back of the remote
control (if available) to enter new name.
If the channel list is long, alternatively, you can select
any channel, then press OPTIONS to open option
menu, then select Create Favourites
list and press OK.
To create a new favourite channels list by copying
existing favourite channel list...
1 - Press , to switch to TV.
2 - Press LIST (if available) or OK to open the
current channel list.
3 - Select at the upper right corner and press OK.
4 - Select Duplicate Favourites list and press OK.
5 - In the list at the left, select a channel you want as
a favourite and press OPTIONS. Channels come in
the list at the right in the order you add them. To
undo, select the channel in the list at the left and
press OPTIONS again. You can also select a
range of channels by pressing (down) to select
the last channel of the range you want to add and
then press OK.
6 - To finish adding channels, press BACK.
7 - The TV will ask to rename the Favourites List.
You can use the on-screen keyboard
or press BACK to hide the on-screen keyboard,
then use the keyboard on the back of the remote
control (if available) to enter new name.
marked at the left.
Rename a Favourites List
You can only rename a Favourites List.
To rename a Favourites List…
1 - Press SOURCE.
2 - Select Favourites.
3 - Select at the upper right corner and press OK.
4 - Select Rename Favourite List and press OK.
5 - Use the on-screen keyboard
or press BACK to hide the on-screen keyboard,
then use the keyboard on the back of the remote
control (if available) to enter new name.
6 - When done, turn the remote control,
select Close and press OK.
7 - Press BACK to close the channel list.
Remove a Favourites List
You can only remove a Favourites List.
To remove a Favourites List…
1 - Press SOURCE.
2 - Select Favourites.
3 - Select at the upper right corner and press OK.
4 - Select Remove Favourite List and press OK.
Reorder Channels
Only in a Favourites List you can change the
sequence of channels (reorder).
You can add a range of channels in one go or start
a Favourites List by duplicating the channel list with
all channels and removing the channels you do not
want.
Add a Range of Channels
To add a consecutive range of channels to
a Favourites List in one go, you can use Select
Range.
To add a range of channels…
1 - Press SOURCE.
2 - Select Favourites.
3 - Open the Favourites List where you want to
add a range of channels.
4 - Select at the upper right corner and press OK.
5 - Select Edit Favourites List and press OK.
6 - In the list at the left select the first channel of the
range you want to add and press OK.
7 - Press (down) to select the last channel of the
range you want to add and then press OK.
8 - Select Add and press OK. The channels are
To change the sequence of channels…
1 - Press SOURCES, and select Favourites.
2 - Open the Favourites List you want to reorder.
3 - Select at the upper right corner and press OK.
4 - Select Reorder Channels and press OK.
5 - In the Favourites List, select the channel you
want to reorder and press OK. (The channel will be
marked with grey box)
6 - With the (up) or (down) keys move the
channel where you want it.
7 - Press OK to confirm the new location.
8 - You can reorder channels with the same method
until you close the Favourites List with
the BACK key.
23
Text / Teletext
Text Pages
To open Text/Teletext press TEXT, while you are
watching TV channels.
To close Text, press TEXT again.
3 - Press BACK to hide the device keys.
4 - To close Text, press BACK again.
Digital Text (UK only)
Some digital broadcasters offer dedicated Digital Text
or interactive TV on their digital TV channels. This
includes normal Text using the number, colour and
arrow keys to select and navigate.
Select a Text page
To select a page . . .
1 - Enter the page number with the number keys.
2 - Use the arrow keys to navigate.
3 - Press a colour key to select a colour-coded
subject at the bottom of the screen.
Text sub-pages
A Text page number can hold several subpages. The
subpage numbers are shown on a bar next to the
main page number.
To select a subpage, press or .
T.O.P. Text pages
Some broadcasters offer T.O.P. Text.
To open T.O.P. Text pages within Text,
press OPTIONS and select T.O.P. Overview.
Favourite pages
The TV makes a list of the last 10 Text pages you
opened. You can easily reopen them again in the
Favourite Text pages column.
1 - In Text, select (heart) in the top left corner of
the screen to show the column of favourite pages.
2 - Press (down) or (up) to select a page
number and press OK to open the page.
You can clear the list with the option Clear Favourite
Pages.
Search Text
To close Digital Text, press BACK.
Text Options
In Text/Teletext, press OPTIONS to select the
following…
• Freeze page
To stop the automatic rotation of subpages.
• Dual screen / Full screen
To show the TV channel and Text alongside each
other.
• T.O.P. overview
To open T.O.P. Text.
• Enlarge
To enlarge the Text page for comfortable reading.
• Reveal
To unhide hidden information on a page.
• Cycle subpages
To cycle subpages when these are available.
• Hide/Show Favourite Pages
To hide or show the list of favourite pages.
• Clear Favourite Pages
To clear the list of favourite pages.
• Language
To switch the group of characters that Text uses to
display correctly.
• Text 2.5
To activate the Text 2.5 for more colours and better
graphics.
You can select a word and scan Text for all
occurences of this word.
1 - Open a Text page and press OK.
2 - Select a word or number with the arrow keys.
3 - Press OK again to jump immediately to the next
occurence of this word or number.
4 - Press OK again to jump to the subsequent
occurence.
5 - To stop searching, press (up) until nothing is
selected.
Text from a connected device
Some devices that receive TV channels can also offer
Text.
To open Text from a connected device . . .
1 - Press SOURCES, select the device and
press OK.
2 - While watching a channel on the device,
press OPTIONS, select Show Device Keys and
select the key and press OK.
Text Setup
Text language
Some digital TV broadcasters have several Text
languages available.
To set your primary and secondary Text language . . .
1 - Press , select All Settings and press OK.
2 - Select Region and Language and
press (right) to enter the menu.
3 - Select Language > Primary Text or Secondary
Text.
4 - Select your preferred Text languages.
5 - Press (left) repeatedly if necessary, to close
the menu.
Text 2.5
If available, Text 2.5 offers more colours and better
graphics. Text 2.5 is activated as a standard factory
setting.
24
To switch off Text 2.5…
1 - Press TEXT.
2 - With Text/Teletext open on screen,
press OPTIONS.
3 - Select Text 2.5 > Off and press OK.
4 - Press (left) repeatedly if necessary, to close
the menu.
25
6
6.2
Connect Devices
6.1
About Connections
Connectivity Guide
Always connect a device to the TV with the highest
quality connection available. Also, use good quality
cables to ensure a good transfer of picture and
sound.
When you connect a device, the TV recognizes its
type and gives each device a correct type name. You
can change the type name if you wish. If a correct
type name for a device is set, the TV automatically
switches to the ideal TV settings when you switch to
this device in the Sources menu.
If you need help to connect several devices to the TV,
you can visit the Philips TV connectivity guide. The
guide offers information on how to connect and
which cables to use.
HDMI Ports
HDMI Quality
An HDMI connection has the best picture and sound
quality. One HDMI cable combines video and audio
signals. Use an HDMI cable for TV signal.
For best signal quality transfer, use a High speed
HDMI cable and do not use an HDMI cable longer
than 5 m.
If a device connected with HDMI is not working
correctly, check if a different HDMI Ultra HD setting
can solve this problem. For more information,
in Help, select Keywords and look up HDMI Ultra
HD.
Go to www.connectivityguide.philips.com
Antenna Port
If you have a Set-top box (a digital receiver) or
Recorder, connect the antenna cables to run the
antenna signal through the Set-top box and/or
Recorder first before it enters the TV. In this way, the
antenna and the Set-top box can send possible
additional channels to the Recorder to record.
Copy protection
HDMI cables support HDCP 2.2 (High-bandwidth
Digital Content Protection). HDCP is a copy protection
signal that prevents copying content from a DVD disc
or Blu-ray Disc. Also referred to as DRM (Digital
Rights Management).
HDMI ARC
All of the HDMI connections on the TV have HDMI
ARC (Audio Return Channel).
If the device, typically a Home Theatre System (HTS),
also has the HDMI ARC connection, connect it to any
of the HDMI connections on this TV. With the HDMI
ARC connection, you do not need to connect the
extra audio cable that sends the sound of the TV
picture to the HTS. The HDMI ARC connection
combines both signals.
You can use any HDMI connection on this TV to
connect the HTS but ARC is only available for 1
device/connection at a time.
26
HDMI MHL
With HDMI MHL, you can send what you see on your
Android smartphone or tablet to a TV screen.
The HDMI 4 connection on this TV
incorporates MHL 2.0 (Mobile High-Definition Link).
This wired connection offers great stability and
bandwidth, low latency, no wireless interference and
good quality sound reproduction. On top of that, the
MHL connection will charge the battery of your
smartphone or tablet. Although connected, your
mobile device will not be charging when the TV is on
standby.
Inform yourself about what passive MHL cable is
suited for your mobile device. In particular, with the
HDMI connector for the TV on one side, the type of
connector you need to connect to your smartphone
or tablet.
MHL, Mobile High-Definition Link and the MHL Logo
are trademarks or registered trademarks of the MHL,
LLC.
the TV and the connected device.
With EasyLink you can operate a connected device
with the TV remote control. EasyLink uses HDMI CEC
(Consumer Electronics Control) to communicate with
the connected devices. Devices must support HDMI
CEC and must be connected with an HDMI
connection.
EasyLink setup
The TV comes with EasyLink switched on. Make sure
that all HDMI CEC settings are properly set up on the
connected EasyLink devices. EasyLink might not work
with devices from other brands.
HDMI CEC on other brands
The HDMI CEC functionality has different names on
different brands. Some examples are: Anynet, Aquos
Link, Bravia Theatre Sync, Kuro Link, Simplink and
Viera Link. Not all brands are fully compatible with
EasyLink.
Example HDMI CEC branding names are property of
their respective owners.
HDMI CEC - EasyLink
An HDMI connection has the best picture and sound
quality. One HDMI cable combines video and audio
signals. Use an HDMI cable for High Definition (HD)
TV signals. For best signal quality transfer, use a High
speed HDMI cable and do not use an HDMI cable
longer than 5 m.
DVI to HDMI
If you still own a device that only has a DVI
connection, you can connect the device to any of
the HDMI connection with a DVI to HDMI adapter.
Use a DVI to HDMI adapter if your device only has a
DVI connection. Use one of the HDMI connections
and add an Audio L/R cable (mini-jack 3.5mm)
to Audio IN for sound, on the back of the TV.
EasyLink HDMI CEC
If your devices are connected with HDMI and have
EasyLink, you can operate them with the TV remote
control. EasyLink HDMI CEC must be switched On on
27
Copy Protection
DVI and HDMI cables support HDCP (High-bandwidth
Digital Content Protection). HDCP is a copy protection
signal that prevents copying content from a DVD disc
or Blu-ray Disc. Also referred to as DRM (Digital
Rights Management).
6.3
Y Pb Pr - Component
Y Pb Pr - Component Video is a high quality
connection.
The YPbPr connection can be used for High Definition
(HD) TV signals. Next to the Y, Pb and Pr signals add
the Audio Left and Right signals for sound.
6.5
Match the YPbPr (green, blue, red) connector colours
with the cable plugs when you connect.
Use an Audio L/R cinch cable if your device also has
sound.
6.4
Audio Out - Optical
Audio Out - Optical is a high quality sound
connection.
This optical connection can carry 5.1 audio channels.
If your device, typically a Home Theatre System
(HTS), has no HDMI ARC connection, you can use this
connection with the Audio In - Optical connection on
the HTS. The Audio Out - Optical connection sends
the sound from the TV to the HTS.
Scart
SCART is a good quality connection.
The SCART connection can be used for CVBS and
RGB video signals but cannot be used for High
Definition (HD) TV signals. The SCART connection
combines video and audio signals. The SCART
connection also supports NTSC playback.
6.6
CAM with Smart Card - CI+
About CI+
Note: Not support for countries in Asia Pacific,
Middle East, and Africa.
28
CI+
This TV is ready for the CI+ Conditional Access .
With CI+ you can watch premium HD programmes,
like movies and sports, offered by digital TV operators
in your region. These programmes are scrambled by
the TV operator and descrambled with a prepaid CI+
module.
Digital TV operators provide a CI+ module
(Conditional Access Module - CAM) and an
accompanying smart card, when you subscribe to
their premium programmes. These programmes have
a high level of copy protection.
Contact a digital TV operator for more information on
terms & conditions.
Smart Card
Digital TV operators provide a CI+ module
(Conditional Access Module - CAM) and an
accompanying smart card, when you subscribe to
their premium programmes.
Insert the smart card into the CAM module. See the
instruction you received from the operator.
To insert the CAM in the TV…
1 - Look on the CAM for the correct method of
insertion. Incorrect insertion can damage the CAM
and TV.
2 - While looking at the back of the TV, with the front
of the CAM facing towards you, gently insert the CAM
into the slot COMMON INTERFACE.
3 - Push the CAM in as far as it will go. Leave it in the
slot permanently.
When you switch on the TV, it may take a few minutes
before the CAM is activated. If a CAM is inserted and
subscription fees are paid (subscription methods can
differ), you can watch the scrambled channels
supported by the CAM smart card.
The CAM and smart card are exclusively for your TV. If
you remove the CAM, you will no longer be able to
watch the scrambled channels supported by the
CAM.
Passwords and PIN codes
For some CAMs, you must enter a PIN code to watch
its channels. When you set the PIN code for the CAM,
we recommend you to use the same code you are
using to unlock the TV.
To set the PIN code for the CAM…
1 - Press SOURCES .
2 - Select the channel type you are using the CAM
for Watch TV.
3 - Press OPTIONS and select Common
Interface.
4 - Select the TV operator of the CAM. The following
screens come from the TV operator. Follow the onscreen instruction to look up the PIN code setting.
6.7
Receiver - Set-Top Box
Cable Box
Use 2 antenna cables to connect the antenna to the
Set-top box (a digital receiver) and the TV.
Next to the antenna connections, add an HDMI cable
to connect the Set-top box to the TV.
Alternatively, you can use a SCART cable if the Settop box has no HDMI connection.
29
Switch Off Timer
Switch off this automatic timer, if you only use the
remote control of the Set-top box. Switch this timer
off to prevent the TV from switching off automatically
after a 4 hour period without a key press on the
remote control of the TV.
6.8
Home Theatre System - HTS
Connect with HDMI ARC
Use an HDMI cable to connect a Home Theatre
System (HTS) to the TV. You can connect a Philips
Soundbar or an HTS with a built-in disc player.
HDMI ARC
If your Home Theatre System has an HDMI ARC
connection, you can use any HDMI connection on the
TV to connect. With HDMI ARC, you do not need to
connect the extra audio cable. The HDMI ARC
connection combines both signals.
All HDMI connections on the TV can offer the Audio
Return Channel (ARC) signal. But once you have
connected the Home Theatre System, the TV can
only send the ARC signal to this HDMI connection.
Satellite Tuner
Connect the dish antenna cable to the Satellite
receiver.
Next to the antenna connection, add an HDMI cable
to connect the device to the TV.
Alternatively, you can use a SCART cable if the device
has no HDMI connection.
Audio to video synchronisation (sync)
If the sound does not match the video on screen, you
can set a delay on most Home Theatre Systems with
a disc player to match the sound with the video.
Connect with HDMI
Use an HDMI cable to connect a Home Theatre
System (HTS) to the TV. You can connect a Philips
Soundbar or an HTS with a built-in disc player.
Switch Off Timer
Switch off this automatic timer, if you only use the
remote control of the Set-top box. Switch this timer
off to prevent the TV from switching off automatically
after a 4 hour period without a key press on the
remote control of the TV.
If the Home Theatre System has no HDMI ARC
connection, add an optical audio cable (Toslink) to
send the sound of the TV picture to the Home Theatre
System.
30
Loading...
