Philips
Flat TV with Perfect Pixel
HD Engine

47"

LCD Full HD 1080p

47PFL7403D

222

Be part of the action

Experience brilliant performance with a breathtaking full HD 1080p, 120Hz display.
Combined with a powerful Perfect Pixel HD engine, HD Natural Motion and exciting
invisible sound, this Flat TV ensures you’re always part of the action.

See every detail of the action

• Perfect Pixel HD Engine for unrivalled sharpness and clarity

• Full HD LCD display, with a 1920x1080p resolution

• HD Natural Motion for ultra smooth motion in Full HD movies

• 120Hz Clear LCD, 2ms performance for superb motion sharpness

Hear exciting and powerful sound

• Invisible speakers with incredible surround

• 30 watt with BBE for powerful sound and great voice clarity

• Dolby Digital output for connection to a home theatre system

Easy to connect and enjoy

• 4 HDMI inputs for full digital HD connection in one cable

• EasyLink: easy control of TV & connected device via HDMI CEC

• Settings assistant for effortless personalized TV settings

Ready for digital

•ATSC & QAM tuner receives over the air and unscrambled cable

Flat TV with Perfect Pixel HD Engine

47" LCD Full HD 1080p

Specifications

47PFL7403D/27

Picture/Display

• Aspect ratio: Widescreen

• Brightness: 500 cd/m²

• Dynamic screen contrast: 29000:1

• Response time (typical): 2 ms

• Viewing angle: 178º (H) / 178º (V)

• Diagonal screen size: 47 inch / 119 cm

• Visible screen diagonal (inch): 46.96 inch

• Panel resolution: 1920x1080p

• Picture enhancement: Pixel Plus 3 HD, 3/2 - 2/2
motion pull down, 3D Combfilter, Active Control +
Light sensor, Dynamic contrast enhancement,
Progressive Scan, 120Hz LCD, HD Natural Motion

Supported Display Resolution

• Computer formats
Resolution Refresh rate
640 x 480 60Hz
800 x 600 60Hz
1024 x 768 60Hz
1280 x 768 60Hz
1280 x 1024 60Hz
1360 x 768 60Hz
1920 x 1080i 60Hz
1920 x 1080p 60Hz

• Video formats
Resolution Refresh rate
480i 60Hz
480p 60Hz
720p 60Hz
1080i 60Hz
1080p 60Hz

Sound

• Equalizer: 5-bands

• Output power (RMS): 30W

• Sound Enhancement: Incredible Surround

• Sound System: Dolby Digital (AC-3), BBE

Loudspeakers

• Built-in speakers: 4

Convenience

• Child Protection: Child Lock+Parental Control

• Clock: On main display, Sleep Timer

• Ease of Installation: Autostore

• Ease of Use: 4 favorite lists, Auto Volume Leveller
(AVL), Channel list, Settings assistant Wizard, Side
Control

• Remote Control: TV

• Screen Format Adjustments: 4:3, Auto Format,

Movie expand 14:9, Movie expand 16:9, Super
Zoom, Widescreen, unscaled (1080p dot by dot)

Multimedia Applications

• Multimedia connections: USB memory class device

• Playback Formats: MP3, Slideshow files (.alb), JPEG
Still pictures

Tuner/Reception/Transmission

• Aerial Input: 75 ohm F-type

• TV system: ATSC, NTSC

• Video Playback: NTSC

• Cable: Unscrambled Digital Cable -QAM

• Tuner bands: Hyperband, S-Channel, UHF, VHF

Connectivity

• AV 1: Audio L/R in, YPbPr

• AV 2: Audio L/R in, YPbPr

• AV 3: CVBS in, S-Video in

• HDMI 1: HDMI v1.3

• HDMI 2: HDMI v1.3

• HDMI 3: Analog audio L/R in, HDMI v1.3

• HDMI-control (CEC features): One touch play,
Power status, System info (menu language), System
standby

• Front / Side connections: HDMI v1.3, S-video in,
CVBS in, Audio L/R in, Headphone out, USB

• Audio Output - Digital: Coaxial (cinch)

Power

• Ambient temperature: 5 °C to 40 °C

• Mains power: 110-240V, 50-60Hz

• Power consumption: 295 W

• Standby power consumption: < 1 W

Dimensions

• Set dimensions in inch (W x H x D):

45.8

x 28 x 4.1 inch

• Set dimensions with stand in inch (W x H x D):

45.8

x 31 x 12.9 inch

• Weight incl. Packaging (lb): 101.6

• Product weight (lb): 90.7 (with stand), 75.3 (without
stand)

• Box dimensions in inch (W x H x D):

50.67

x 34.76 x 15.4 inch

Accessories

• Included Accessories: Tabletop swivel stand, Power
cord, Quick start guide, User Manual, Registration
card, Remote Control

•
