Philips 43PUS7657/12, 55PUS7657/12, 50PUS7657/12 User guide

7657 Series

User Manual

43PUS7657

50PUS7657

55PUS7657

Register your product and get support at

www.philips.com/TVsupport

Contents

1 Get Support 4

1.1 Identify and Register your TV

1.2 TV Help and User Manual

1.3 Consumer Care / Repair

4
4
4

2 Software 5

2.1 Update Software

2.2 Software Version

2.3 Automatic Software Update

2.4 View Software Update History

5
5
5
5

3 Quick Guide 7

3.1 Remote Control

3.2 IR sensor

7
9

4 Setting Up 10

4.1 Read Safety

4.2 TV Placement

4.3 Turn on TV

10
10
10

5 Connections 12

5.1 Connectivity guide

5.2 Antenna

5.3 Satellite

5.4 Video Device

5.5 Audio Device

5.6 Mobile Device

5.7 Other Device

5.8 Computer

12
12
12
12
12
13
14
15

6 Switch Source 16

6.1 Source List

6.2 Rename Device

16
16

7 Channels 17

7.1 About Channels and Switch Channels

7.2 Install Channel

7.3 Channel List

7.4 Favourite Channels

7.5 Text / Teletext

17
17
22
23
24

8 TV Guide 25

8.1 What You Need

8.2 Using the TV Guide

25
25

9 Freeview Play (for UK models) 26

9.1 About Freeview Play

9.2 Using Freeview Play

26
26

10 Videos, Photos and Music 27

10.1 From a USB Connection

10.2 From a Computer or NAS

10.3 Photos

10.4 360° Photo

10.5 Videos

10.6 Music

27
27
27
27
28
29

11 Open TV Setting Menus 30

11.1 Home Menu Overview

30

11.2 Frequent Settings and All settings

11.3 All Settings

30
30

12 Wireless and Networks 41

12.1 Home Network

12.2 Connect to Network

12.3 Wireless and Network Settings

41
41
41

13 Smart TV 43

13.1 Setup Smart TV

13.2 Smart TV Collection

43
43

14 Netflix 44
15 Rakuten TV 45
16 Amazon Prime Video 46
17 YouTube 47
18 Alexa 48

18.1 About Alexa

18.2 Using Alexa

48
48

19 Google Assistant 49
20 Environmental 50

20.1 European Energy Label

20.2 EPREL Registration Number

20.3 End of Use

20.4 UK Declaration of Conformity

50
50
50
50

21 Specifications 51

21.1 Power

21.2 Reception

21.3 Display Resolution

21.4 Supported Input Resolution

21.5 Sound

21.6 Multimedia

21.7 Connectivity

51
51
51
51
51
51
52

22 Troubleshooting 53

22.1 Tips

22.2 Switch On

22.3 Remote Control

22.4 Channels

22.5 Satellite

22.6 Picture

22.7 Sound

22.8 HDMI - UHD

22.9 USB

22.10 Wi-Fi and Internet

22.11 Wrong Menu Language

53
53
53
53
54
54
55
55
56
56
56

23 Safety and Care 57

23.1 Safety

23.2 Screen Care

57
58

24 Terms of Use 59
25 Copyrights 60

25.1 HDMI

25.2 HEVC Advance

60
60

2

25.3 Dolby Vision and Dolby Atmos

25.4 DTS-HD

25.5 Wi-Fi Alliance

25.6 Other Trademarks

60
60
60
60

26 Open Source 61

26.1 Open Source Software

26.2 Open Source License

27 Disclaimer regarding services

61
61

65

and/or software offered by third
parties
Index 66

3

1

Get Support

1.1

installation.

• Contact info - Show the telephone number or web
address for your country or region.

* Sorting channels is only applicable for certain
countries.

Identify and Register your TV

Identify your TV - TV model number and serial
number

You might be asked to provide the TV product model
number and serial number. Find these numbers on
the packaging label or on the type label on the back
or bottom of the TV.

Register your TV

Register your TV and enjoy a range of benefits
including full support (including downloads),
privileged access to information about new products,
exclusive offers and discounts, the chance to win
prizes and even participate in special surveys about
new releases.

Go to www.philips.com/TVsupport

1.2

TV Help and User Manual

 (Home) > Settings > Help
You can use Help function to diagnose and get more

information about your TV.

** Ambilight setting is only for models which support
Ambilight function.

1.3

Consumer Care / Repair

For support and repair, call the Consumer Care
hotline in your country. Our service engineers will take
care of a repair, if necessary.

Find the telephone number in the printed
documentation that came with the TV.
Or consult our
website www.philips.com/TVsupport and select
your country if needed.

TV model number and serial number

You might be asked to provide the TV product model
number and serial number. Find these numbers on
the packaging label or on the type label on the back
or bottom of the TV.

 Warning

Do not attemp to repair the TV yourself. This may
cause severe injury, irrepairable damage to your TV or
void your warranty.

• TV information - View the Model name, Serial

number and Software version of your TV.

• How to - You can see instructions on how to
install channels, sort channels*, update TV software,
connect external devices and use Smart functions on
your TV.

• Check the TV - You can check if the picture, sound,
Ambilight** are working fine during playing a short
video clip.

• Check the network - Check the network
connection.

• Check the remote control - Perform the test to
verify the TV bundled remote control functionality.

• View weak signal history - Display the list of
channel numbers that were automatically saved
when signal strength was weak.

• Update software - Check available software
updates.

• User manual - Read the user manual for TV
information.

• Troubleshooting - Find a solution for frequent ask
questions.

• Factory settings - Reset all settings to factory
settings.

• Reinstall TV - Reinstall and redo the complete TV

4

2

Software

The TV switches itself off for 10 seconds and then
back on again. Please wait.

Do not . . .

2.1

Update Software

Search for Updates

Update from Internet

 (Home) > Settings > Update
software > Search for updates > Internet
(Recommended)

Look for a software update yourself.

• If the TV is connected to the Internet, you may
receive a message to update the TV software. You
need a high-speed (broadband) Internet
connection. If you receive this message, we
recommend you to carry out the update.

• During the software update, there is no picture and
the TV will switch off and on again. This might happen
several times. The update can take a few minutes.

• Wait until the TV picture comes back up. Do not
press the power switch  on the TV or on the
remote control during the software update.

• use the remote control

• remove the USB memory device from the TV

• press  twice

• press the power switch on the TV
The TV switches itself off (for 10 seconds) and then
back on again. Please wait.

The TV software has been updated. You can use the
TV again.
To prevent an accidental update of the TV software,
delete the autorun.upg file from the USB memory
device.

Local Updates

 (Home) > Settings > Update
software > Search for updates > USB > Local
updates.

For dealers and expert users.

2.2

Software Version

Update from USB

 (Home) > Settings > Update
software > Search for updates > USB

• You need a computer with a high-speed Internet
connection and a USB memory device to upload the
software on the TV.

• Use a USB memory device with 512MB free space.
Make sure that write protection is switched off.

1 - Start the update on TV

Select Update software > Search for updates >
USB, then press OK.
2 - Identify the TV

Insert the USB memory into one of the USB
connections of the TV.
Select Start and press OK. An identification file is
written on the USB memory device.

3 - Download the TV software

- Insert the USB memory into your computer.

- On the USB memory device, locate the
file update.html and double click it.

- Click on Send ID.

- If new software is available, download the .zip file.

- After the download, unzip the file and copy the
file autorun.upg onto the USB memory device.

- Do not place this file in a folder.

4 - Update the TV software

Insert the USB memory into the TV again. The update
starts automatically.

 (Home) > Settings > Update
software > Current software info

To view the current TV software version.

2.3

Automatic Software Update

 (Home) > Settings > Update software >
Automatic software update

To switch on Automatic software update to update
your TV software automatically. Leave the TV in
standby.

When the setting is enabled, the upgrade gets
downloaded when the TV is powered ON and
installed 15min after the TV has gone to standby (as
long as there is no alarm scheduled).
When the setting is disabled, the "Upgrade Now" /
"Later" OSD will be shown.

5

2.4

View Software Update
History

 (Home) > Settings > Update software > View
software update history

Display the list of software versions that are
successfully update on the TV.

6

3

Quick Guide

3.1

Remote Control

Batteries and Cleaning

Replace batteries

If the TV does not react on a key press on the remote
control, the batteries might be empty.

To replace the batteries, open the battery
compartment on the back of the remote control.

1 - Slide the battery door in the direction shown by
the arrow.
2 - Replace the old batteries with 2
type AAA-R03-1.5V batteries. Make sure the + and
the - ends of the batteries line up correctly.

1 -  Standby / On
To switch the TV on or back to Standby.

2 -  OPTIONS
To open or close the Options menu.

3 - 
To launch the Amazon prime video App.

3 - Reposition the battery door and slide it back until
it clicks.

• Remove the batteries if you are not using the remote
control for a long time.

• Safely dispose of your old batteries according to the
end of use directions.

Cleaning

Your remote control is treated with a scratch-resistant
coating.

To clean the remote control, use a soft damp cloth.
Never use substances such as alcohol, chemicals or
household cleaners on the remote control.

4 - 
To open the Netflix App directly. With the TV switched
on or from standby.

• If you have a Netflix membership subscription, you
can enjoy Netflix on this TV. Your TV must be
connected to the Internet.

• To open Netflix, press  to open the Netflix
App. You can open Netflix immediately from a TV in
standby.
www.netflix.com

5 -  INFO
To open or close programme info.

6 -  Smart TV Collection
To open the Smart TV Collection page.

7 - 
To launch the Rakuten TV App.

8 -  SOURCES
To open the Sources menu.

9 -  Search
To open the Smart TV searches page.

Key Overview

Top

Top (for UK models)

7

1 -  Standby / On
To switch the TV on or back to Standby.

2 -  OPTIONS
To open or close the Options menu.

3 - 
To launch the Amazon prime video App.

4 - 
To open the Netflix App directly. With the TV switched
on or from standby.

• If you have a Netflix membership subscription, you
can enjoy Netflix on this TV. Your TV must be
connected to the Internet.

• To open Netflix, press  to open the Netflix
App. You can open Netflix immediately from a TV in
standby.
www.netflix.com

5 -  Smart TV Collection
To open the Smart TV Collection page.

6 - Freeview Play
To open the Explore Freeview Play page.

7 - 
To launch the Rakuten TV App.

8 -  SOURCES
To open the Sources menu.

9 -  Search
To open the Smart TV searches page.

1 - OK key
To confirm a selection or setting. To open the channel
list while watching TV if Interactive Service is not
available.

2 -  Back
To close a menu without changing a setting.

3 - Playback and Record

• Play , to playback.

• Pause , to pause playback.

• Stop , to stop playback.

• Rewind , to rewind.

• Fast forward , to go fast forward.
4 -     Colour keys

Direct selection of options. Blue key , opens Help.
5 - Arrow / navigation keys

To navigate up, down, left or right.

6 -  Home

To open the Home menu.
7 -  TV Guide

To open or close the TV Guide.
8 -  Channel list

To open the channel list.

Middle

Bottom

8

1 -  - EXIT
Press in middle to switch back to watch TV. To stop
an interactive TV application. Prese + or - to switch to
the next or previous channel in the channel list. To
open the next or previous page in Text/Teletext.

2 -  Volume
Prese + or - to adjust the volume level.

open the next or previous page in Text/Teletext.
2 -  Volume

Prese + or - to adjust the volume level.
3 - Number keys

To select a channel directly.
4 -  INFO

To open or close programme info.
5 -  Channel

Prese + or - to switch to the next or previous channel
in the channel list. To open the next or previous page
in Text/Teletext.

6 -  Mute
To mute the sound or to restore it.

7 - SUBTITLE
To open Subtitle page.

3.2

IR sensor

3 - Number keys

To select a channel directly.
4 - TEXT

To open or close Text/Teletext.
5 -  Channel

Prese + or - to switch to the next or previous channel
in the channel list. To open the next or previous page
in Text/Teletext.

6 -  Mute
To mute the sound or to restore it.

7 - SUBTITLE
To open Subtitle page.

Bottom (for UK models)

The TV can receive commands from a remote control
that uses IR (infrared) to send commands. If you use
such a remote control, always make sure you point
the remote control at the infrared sensor on the front
of the TV.

 Warning

Do not put any objects in front of IR sensor of the TV,
it may block the IR signal.

1 -  - EXIT
Press in middle to switch back to watch TV. To stop
an interactive TV application. Prese + or - to switch to
the next or previous channel in the channel list. To

9

4

Wall Mounting

Setting Up

4.1

Read Safety

Read the safety instructions first before you use the
TV.

To read the instructions, in Help > User manual,
press the colour key  Keywords and look
up Safety and Care.

4.2

TV Placement

Tips on Placement

• Position the TV where light does not shine directly
on the screen.

• Position the TV up to 15 cm away from the wall.

• The ideal distance to watch Ultra HD TV is 2 to 5
times of its screen height. When seated, your eyes
should be level with the centre of the screen.

Your TV is also prepared for a VESA-compliant wall
mount bracket (sold separately).
Use the following VESA code when purchasing the
wall mount . . .

• 43PUS7657

VESA MIS-F 200x100, M6 (Minimum 8 mm,
Maximum 11 mm)

• 50PUS7657

VESA MIS-F 200x100, M6 (Minimum 8 mm,
Maximum 11 mm)

• 55PUS7657

VESA MIS-F 200x100, M6 (Minimum 8 mm,
Maximum 11 mm)

• 65PUS7657

VESA MIS-F 200x200, M6 (Minimum 12 mm,
Maximum 18 mm)

Caution

Note:

Please keep the TV away from dust-producing
sources such as stoves. It is suggested to clean the
dust regularly to avoid getting dust into the TV.

TV Stand

You can find the instructions for mounting the TV
stand in the Quick Start Guide that came with the TV.
In case you lost this guide, you can download it
from www.philips.com/TVsupport.

Use the model number of the TV to look for
the Quick Start Guide to download.

Wall mounting the TV requires special skills and
should only be performed by qualified personnel. The
TV wall mounting should meet safety standards
according to the TVs weight. Also read the safety
precautions before positioning the TV.
TP Vision Europe B.V. bears no responsibility for
improper mounting or any mounting that results in
accident or injury.

4.3

Turn on TV

Connect Power Cable

• Insert the power cable into the POWER connector
on the back of the TV.

• Make sure the power cable is securely inserted in
the connector.

• Make sure that the power plug, in the wall socket, is
accessible at all times.

• When you unplug the power cable, always pull the
plug, never pull the cable.

10

Although this TV has a very low standby power
consumption, unplug the power cable to save energy
if you do not use the TV for a long period of time.

On or Standby

Before you switch on the TV, make sure you plugged
in the mains power in the POWER connector on the
back of the TV.

Switch On

Press the small joystick key on the bottom of the TV.

Switch to standby

To switch the TV to standby, press  on the remote
control. You can also press the small joystick key on
the bottom of the TV.

In standby mode, the TV is still connected to the
mains power but consumes very little energy.

To switch off the TV completely, disconnect the
power plug.
When disconnecting the power plug, always pull the
power plug, never the cord. Ensure that you have full
access to the power plug, power cord and outlet
socket at all times.

11

5

Connections

5.1

Connectivity guide

Always connect a device to the TV with the highest
quality connection available. Also, use good quality
cables to ensure a good transfer of picture and
sound.

When you connect a device, the TV recognizes its
type and gives each device a correct type name. You
can change the type name if you wish. If a correct
type name for a device is set, the TV automatically
switches to the ideal TV settings when you switch to
this device in the Sources menu.

5.2

Antenna

Insert the antenna plug firmly into
the Antenna socket at the back of the TV.

You can connect your own antenna or an antenna
signal from an antenna distribution system. Use an
IEC Coax 75 Ohm RF antenna connector.

Use this antenna connection for DVB-T and DVB-C
input signals.

5.4

Video Device

HDMI

An HDMI connection has the best picture and sound
quality.

For best signal quality transfer, use a High speed
HDMI cable and do not use an HDMI cable longer
than 5 m, and also connect devices supporting HDR
on any one of HDMI connections.

5.3

Satellite

Attach the satellite F-type connector to the satellite
connection SAT at the back of the TV.

Copy protection

HDMI ports support HDCP (High-bandwidth Digital
Content Protection). HDCP is a copy protection signal
that prevents copying content from a DVD disc or Blu­ray Disc. Also referred to as DRM (Digital Rights
Management).

12

5.5

Audio Device

HDMI ARC/eARC

Only HDMI 1 on the TV have HDMI ARC (Audio
Return Channel).

If the device, typically a Home Theatre System (HTS),
also has the HDMI ARC connection, connect it to any
of the HDMI connections on this TV. With the HDMI
ARC connection, you do not need to connect the
extra audio cable that sends the sound of the TV
picture to the HTS. The HDMI ARC connection
combines both signals.

HDMI eARC (Enhanced Audio Return Channel) is an
advancement over the previous ARC. It supports the
latest high-bitrate audio formats up to192kHz, 24-bit,
and uncompressed 5.1 and 7.1, and 32-channel
uncompressed audio.

5.6

HDMI eARC is only available on HDMI 1.

Digital Audio Out - Optical

Audio Out - Optical is a high quality sound
connection.

This optical connection can carry 5.1 audio channels.
If your device, typically a Home Theatre System
(HTS), has no HDMI ARC connection, you can use this
connection with the Audio In - Optical connection on
the HTS. The Audio Out - Optical connection sends
the sound from the TV to the HTS.

Mobile Device

Screen Mirroring

About Screen Mirroring

You can view your photos or play your music and
videos from a mobile device on your TV with Screen
Mirroring. The mobile device and the TV should be
within range, which usually means being in the same
room.

Using Screen Mirroring
Switch on Screen Mirroring

Press  SOURCES > Screen Mirroring
Share a Screen on TV

1 - Activate Screen mirroring on your mobile device.
2 - On your mobile device, select the TV. (This TV will

be displayed as TV model name)
3 - Select the TV name on your mobile device, after
connection, you can enjoy using Screen Mirroring.

Stop Sharing

You can stop sharing a screen from the TV or from the
mobile device.

From the device

With the application you use to start Screen Mirroring,
you can disconnect and stop watching the screen of
the device on TV. The TV will switch back to the last
selected programme.

13

From the TV

To stop watching the screen of the device on TV, you
can . . .

• press  EXIT to watch a TV broadcast

• press  (Home) to start another activity on TV

• press  SOURCES to open the Sources menu
and select a connected device.

Block a Device

The first time you receive a request to connect from a
device, you can block the device. The request from
this device and all its requests in the future, will be
ignored.

To block a device…
Select Block… and press OK.

Unblock all devices

All previously connected and also blocked devices
are stored in the Screen Mirroring list of connections.
If you clear this list, all blocked devices will be
unblocked.

To unblock all blocked devices…

 (Home) > Settings > All settings > Wireless
and networks > Wired or Wi-Fi > Reset Screen
Mirroring connections.

Blocking a previously connected device

If you want to block a device that you previously
connected, you need to clear the Screen Mirroring
connections list first. If you clear this list, you will have
to confirm or block the connection for every device
again.

Apps - Philips TV Remote App

The new Philips TV Remote App on your smartphone
or tablet is your new TV buddy.

Download the Philips TV Remote App from your
favourite app store today.

The Philips TV Remote App is available for iOS and
Android and is free of charge.

5.7

Other Device

CAM with Smart Card - CI+

About CI+

This TV is ready for the CI+ Conditional Access.
With CI+ you can watch premium HD programmes,

like movies and sports, offered by digital TV operators
in your region. These programmes are scrambled by
the TV operator and descrambled with a prepaid CI+
module.
Digital TV operators provide a CI+ module
(Conditional Access Module - CAM) and an
accompanying smart card, when you subscribe to
their premium programmes. These programmes have
a high level of copy protection.

Contact a digital TV operator for more information on
terms & conditions.

Reset Screen Mirroring connections

All previously connected devices are stored in the
Screen Mirroring list of connections.

To clear all connected Screen Mirroring devices…

 (Home) > Settings > All settings > Wireless
and networks > Wired or Wi-Fi > Reset Screen
Mirroring connections.

Screen Delay

The normal delay when sharing a screen with Screen
Mirroring is about 1 second. The delay might be longer
if you are using older devices with less processing
power.

Smart Card

Digital TV operators provide a CI+ module
(Conditional Access Module - CAM) and an
accompanying smart card, when you subscribe to
their premium programmes.

Insert the smart card into the CAM module. See the
instruction you received from the operator.

To insert the CAM in the TV…

1. Look on the CAM for the correct method of
insertion. Incorrect insertion can damage the CAM
and TV.

2. While looking at the back of the TV, with the front
of the CAM facing towards you, gently insert the CAM

14

into the slot COMMON INTERFACE.

3. Push the CAM in as far as it will go. Leave it in the
slot permanently.

When you switch on the TV, it may take a few minutes
before the CAM is activated. If a CAM is inserted and
subscription fees are paid (subscription methods can
differ), you can watch the scrambled channels
supported by the CAM smart card.

The CAM and smart card are exclusively for your TV. If
you remove the CAM, you will no longer be able to
watch the scrambled channels supported by the
CAM.

For more information on watching or playing content
from a USB flash drive, in Help, press the colour
key  Keywords and look up Photos, Videos and

Music.

Set Passwords and PIN Codes

For some CAMs, you must enter a PIN code to watch
its channels. When you set the PIN code for the CAM,
we recommend you to use the same code you are
using to unlock the TV.

To set the PIN code for the CAM…

1. Press  SOURCES .

2. Select the channel type you are using the CAM for.

3. Press  OPTIONS and select Common
Interface.

4. Select the TV operator of the CAM. The following
screens come from the TV operator. Follow the on­screen instruction to look up the PIN code setting.

USB Flash Drive

You can view photos or play your music and videos
from a connected USB flash drive. Insert a USB flash
drive in one of the USB connections on the TV while
the TV is switched on.

5.8

Computer

You can connect your computer to the TV using a
high quality HDMI cable and use the TV as a PC
monitor.

* Note for Nvidia Graphics card users:
If you connect your computer to TV via HDMI, Nvidia
card may automatically output Variable Refresh Rate
(VRR) video to TV when TV’s HDMI Ultra HD setting is
Optimal (Auto Game). Please always ensure turn off
VRR function in graphics card before you change TV’s
HDMI Ultra HD to Optimal or Standard, the TV UI
selection Optimal or Standard will turn off VRR
support in TV.

* Note for AMD Graphics card users:
If you connect your computer to TV via HDMI, please
ensure following settings in graphics card used to
have proper performance.

- If graphics card output video is 4096 x 2160p or
3840 x 2160p and RGB pixel format is used, RGB 4:4:4
pixel format studio (limited RGB) shall be set in
computer graphic card.

The TV detects the flash drive and opens a list
showing its content.
If the contents list does not appear automatically,
press  SOURCES and select USB.

15

6

Switch Source

6.1

Source List

• To open the sources menu, press  SOURCES .

• To switch to a connected device, select the device
with the arrows  (Right) or  (Left) and press OK.

• To view the technical information of the connected
device you are watching, press  OPTIONS and

select Device info.

• To close the source menu without switching to a
device, press  SOURCES again.

6.2

Rename Device

 (Home) > Settings > All settings > General
settings > Edit input sources > Source

1 - Select one of the device icons, the preset name
appears in the typing fieldand select.

2 - Select Rename to open on-screen keyboard.
3 - Use navigation keys to select characters.
4 - Select Close when complete the editing.

16

7

Channels

7.1

About Channels and Switch Channels

To watch TV channels

• Press . The TV tunes to the TV channel you last
watched.

• Press  (Home) > TV > Channels and
press OK.

• Press  + or  - to switch channels.

• If you know the channel number, type in the number
with the number keys. Press OK after you entered
the number to switch channels.

• To switch back to the previously tuned channel,
press  Back .

To switch to a channel from a channel list

• While watching a TV channel, press OK to open the
channel lists.

• The channel list can have several pages with
channels. To view the next or previous page,
press  + or  -.

• To close the channel lists without switching
channels, press  Back or  EXIT .

Channel icons

After an Automatic channel update of the channel list,
newly found channels are marked with a  (star).
If you lock a channel, it will be marked with
a  (lock).

Radio channels

If digital broadcasting is available, digital radio
stations are installed during installation. Switch to a
radio channel just like you switch to a TV channel.

This TV can receive digital television standard DVB. TV
may not work properly with some operators of digital
television , non-compliance with requirements of the
standard in full.

7.2

Install Channel

for channels

1 - Select Start now and press OK.
2 - Select Update channels to only add new digital

channels.
3 - Select Start and press OK to update channels.
This can take a few minutes.

Quick reinstall
 (Home) > Settings > Install

Channels > Antenna/cable installation > Search
for channels

1 - Select Start now and press OK.
2 - Select Quick reinstall to install all channels again

with default settings.
3 - Select Start and press OK to update channels.
This can take a few minutes.

Advanced reinstall
 (Home) > Settings > Install

Channels > Antenna/cable installation > Search
for channels

1 - Select Start now and press OK.
2 - Select Advanced reinstall to do a full re-

installation which takes you through each step.
3 - Select Start and press OK to update channels.
This can take a few minutes.

Channel Settings

 (Home) > Settings > Install
Channels > Antenna/cable installation > Search
for channels > Advanced reinstall

1 - Select Start now and press OK.
2 - Select Advanced reinstall to do a full re-

installation which takes you through each step.

3 - Select Start and press OK.
4 - Select the country where you are now and

press OK.
5 - Select Antenna (DVB-T) or Cable (DVB-C) ,
and select one item you need to re-install.

6 - Select Digital and analogue channels, Only
digital channels, or Only analogue channels.

7 - Select Settings and press OK.
8 - Press  Reset to reset, or press  Done when

complete the settings.

Frequency scan

Select the method of searching for channels.

Antenna and Cable

Manually Search for Channels and Channel Settings

Search for Channels
Update channels

 (Home) > Settings > Install
Channels > Antenna/cable installation > Search

• Quick: select the faster method and use the
predefined settings used by most cable providers in
your country.

• Full: If this results in having no channels installed or
if some channels are missing, you can select the
extended Full method. This method will take more
time to search for and install channels.

• Advanced: If you received a specific network
frequency value to search for channels,

17

select Advanced.
Frequency step size

The TV searches for channels in steps of 8MHz.
If this results in having no channels installed or if
some channels are missing, you can search in smaller
steps of 1MHz. Using the 1MHz steps will take more
time to search for and install channels.

Network frequency mode

If you intend to use the fast Quick method
in Frequency scan to search for channels,
select Automatic. The TV will use 1 of the predefined
network frequencies (or HC - homing channel) as
used by most cable providers in your country.
If you received a specific network frequency value to
search for channels, select Manual.

or removed, a message is shown at TV start up. The
TV must be in standby to automatically update
channels.

Channel Update Message

 (Home) > Settings > Install
Channels > Antenna/cable installation > Channel
update message

When new channels are found or if channels are
updated or removed, a message is shown at TV start
up. To avoid this message to appear after every
channel update, you can switch it off.

Network frequency

With the Network frequency mode set to Manual,
you can enter the network frequency value received
from your cable provider here. To enter the value,
use the number keys.

Network ID

Enter the network ID supplied by your cable
provider.

Symbol rate mode

If your cable provider did not give you a
specific symbol rate value to install the TV channels,
leave the Symbol rate mode setting on Automatic.
If you received a specific symbol rate value,
select Manual.

Symbol rate

With the Symbol rate mode set to Manual, you can
enter the symbol rate value by using the number
keys.

Free / Scrambled

If you have a subscription and a CAM - Conditional
Access Module for pay TV services, select Free +
scrambled. If you did not subscribe to pay TV
channels or services, you can select Free

channels only .

Automatically Search for Channels

Digital: Reception Test

 (Home) > Settings > Install
Channels > Antenna/cable installation > Digital:
reception test

The digital frequency is shown for this channel. If the
reception is poor, you can reposition your antenna.
To check the signal quality of this frequency again,
select Search and press OK.
To enter a specific digital frequency yourself, use the
remote control digit keys. Alternatively, select the
frequency, position the arrows on a number
with  and  and change the number
with  and . To check the frequency,
select Search and press OK.

Analogue: Manual Installation

 (Home) > SettingsInstall
Channels > Antenna/cable
installation > Analogue: manual installation

Analogue TV channels can be manually installed,
channel by channel.

• System
To set up the TV system, select System.
Select your country or the part of the world where
you are now and press OK.

 (Home) > Settings > Install
Channels > Antenna/cable
installation > Automatic channel update

If you receive digital channels, you can set the TV to
automatically update the list with new channels.

Alternatively, you can start a channel update yourself.

Automatic channel update

Once a day, at 6 AM, the TV updates the channels
and stores new channels. New channels are stored in
the All channels list but also in the New channels list.
Empty channels are removed.
If new channels are found or if channels are updated

• Search Channel
To find a channel, select Search Channel and
press OK. You can enter a frequency yourself to find
a channel or let the TV search for a channel.
Press OK, select Search and press OK to search
for a channel automatically. The found channel is
shown on screen and if the reception is poor,
press Search again. If you want to store the channel,
select Done and press OK.

• Fine tune

18

To fine tune a channel, select Fine tune and
press OK. You can fine tune the channel
with  or .
If you want to store the channel found,
select Done and press OK.

• Store
You can store the channel on the current channel
number or as a new channel number.
Select Store and press OK. The new channel
number is shown briefly.

You can redo these steps until you have found all
available analogue TV channels.

Satellite

Search for Satellite and Satellite Settings

 (Home) > Settings& > Install
Channels > Satellite installation > Search for
satellite

Re-install all channels
 (Home) > Settings > Install

Channels > Satellite installation > Search for
satellite > Reinstall channels

• Select the group of channels you want to install.

• Satellite operators can offer channel packages that
bundle free channels (free-to-air) and offer a sorting
that suits a country. Some satellites offer subscription
packages - a collection of channels you pay for.

Connection type

Select the number of satellites you want to install.
The TV sets the appropriate connection type
automatically.

• Up to 4 Satellites - You can install up to 4 satellites
(4 LNBs) on this TV. Select the exact number of
satellites you wish to install at the start of the
installation. This will speed up the installation.

• Unicable - You can use an Unicable system to
connect the antenna dish to the TV. You can select
Unicable for 1 or for 2 satellites at the start of the
installation.

LNB settings

In some countries, you can adjust the expert settings
for homing transponder and each LNB. Only use or
change these settings when a normal installation fails.
If you have non-standard satellite equipment, you
can use these settings to overrule the standard
settings. Some providers might give you some
transponder or LNB values which you can enter here.

• Low LO Frequency / High LO Frequency - The local
oscillator frequencies are set to standard values.
Adjust the values only in case of exceptional
equipment that needs different values.

• 22 kHz Tone - By default, the Tone is set to
Automatic.

• LNB Power - By default, LNB Power is set to
Automatic.

Automatically Search for Channels

 (Home) > Settings > Install
Channels > Satellite installation > Automatic
channel update

If you receive digital channels, you can set the TV to
automatically update the list with new channels.

Alternatively, you can start a channel update yourself.

Automatic channel update

Once a day, at 6 AM, the TV updates the channels
and stores new channels. New channels are stored in
the All channels list but also in the New channels list.
Empty channels are removed.
If new channels are found or if channels are updated
or removed, a message is shown at TV start up. The
TV must be in standby to automatically update
channels.

* Only available when Satellite channel list is set to

From a sorted package

Channel Update Message

 (Home) > Settings > Install
Channels > Satellite installation > Channel update
message

When new channels are found or if channels are
updated or removed, a message is shown at TV start
up. To avoid this message to appear after every
channel update, you can switch it off.

Automatic Update Option

 (Home) > Settings > Install
Channels > Satellite installation > Automatic
update option

Unselect a satellite if you do not want to update
automatically.

* Only available when Satellite channel list is set to

From a sorted package

• Universal or Circular - The general type of LNB,
usually you can select this type for your LNB.

19

Manual Installation

 (Home) > Settings > Install
Channels > Satellite installation > Manual
installation

Manually install satellite.

• LNB - Select the LNB for which you want to add
new channels.

• Polarisation - Select the polarisation you need.

• Symbol rate mode - Select Manual to enter symbol
rate.

• Frequency - Enter the frequency for the
transponer.

• Search - Search for transponder.

Satellite CAMs

If you use a CAM – a Conditional Access Module with
a smart card – to watch satellite channels, we
recommend to do the satellite installation with the
CAM inserted in the TV.

1 - Switch on the TV. This TV should have channels
installed.

2 - Plug in a USB flash drive to USB 2* port.
3 - Select  (Home) > Settings > All

settings > Channels > Channel list copy > Copy
to USB and press OK.

4 - When copying is done, unplug the USB flash
drive.

Now you can upload the copied channel list onto
another Philips TV.

* Note: only the USB port that marked with USB 2
supports copying channel list operation.

Check channel list version
 (Home) > Settings > All

settings > Channels > Channel list copy > Current
version

Upload a Channel List

Most CAMs are used to descramble channels.
CAMs (CI+ 1.3 with Operator Profile) can install all the

satellite channels by themselves on your TV. The
CAM will invite you to install its satellite(s) and
channels. These CAMs not only install and
descramble the channels but also handle regular
channel updates.

Channel List Copy

Introduction

Channel list copy is intended for dealers and expert

users.
With Channel list copy, you can copy the channels

installed on one TV onto another Philips TV of the
same range. With Channel list copy, you avoid the
time-consuming channel search by uploading a
predefined channel list on a TV. Use a USB flash drive
of minimum 1 GB.

Conditions

• Both TVs are from the same year range.

• Both TVs have the same hardware type. Check the
hardware type on the TV type plate on the back of
the TV.

• Both TVs have compatible software versions.

Copy a Channel List, Check Channel List Version
Copy a channel list to USB flash drive

To copy a channel list…

To not Installed TVs

Depending on whether your TV is already installed or
not, you must use a different method to upload a
channel list.

To a TV that is not yet installed

1 - Plug in the power plug to start the installation and
select language and country. You can skip the
channel search. Finish the installation.
2 - Plug in the USB flash drive that holds the channel
list of the other TV.
3 - To start the channel list upload, select 

(Home) > Settings > All
settings > Channels > Channel List Copy > Copy
to TV and press OK. Enter your PIN code if

necessary.
4 - The TV notifies you if the channel list is copied to
the TV successfully. Unplug the USB flash drive.

To Installed TVs

Depending on whether your TV is already installed or
not, you must use a different method to upload a
channel list.

To an already installed TV

1 - Verify the country setting of the TV. (To verify this
setting, see chapter Re-install channels. Start this
procedure until you reach the country setting.
Press  Back to cancel the installation.)
If the country is correct continue with step 2.
If the country is not correct, you need to start a
reinstallation. See chapter Re-install channels and
start the installation. Select the correct country and
skip the channels search. Finish the installation. When

20

done, continue with step 2.
2 - Plug in the USB flash drive that holds the channel
list of the other TV.
3 - To start the channel list upload, select 

(Home) > Settings > All
settings > Channels > Channel List Copy > Copy
to TV and press OK. Enter your PIN code if

necessary.
4 - The TV notifies you if the channel list is copied to
the TV successfully. Unplug the USB flash drive.

Channel Options

Open Options

While watching a channel, you can set some options.
Depending on the type of channel you are watching

or depending on the TV settings you made, some
options are available.

To open the options menu…

1 - While watching a channel, press  OPTIONS.
2 - Press  OPTIONS again to close.

in Subtitle language.

Subtitles Language

If none of the preferred subtitle languages are
available, you can select another subtitle language if
available. If no subtitle languages are available, you
cannot select this option.

To read more information, in Help, press the colour
key  Keywords and look up Subtitle Language.

Audio Language

If none of the preferred audio languages are
available, you can select another audio language if
available. If no audio languages are available, you
cannot select this option.

To read more information, in Help, press the colour
key  Keywords and look up Audio Language.

Dual I-II

Programme Info

Select Programme info to view the information of the
programme you are watching.

To call up the details of the selected programme…

1 - Tune to the channel.
2 - Press  INFO to open or close programme info.
3 - Alternatively, you can press  OPTIONS,

select Programme Info and press OK to open the
programme info.
4 - Press  OPTIONS again or press  Back to
close the programme info.

Subtitles

To switch on Subtitles, press  OPTIONS and select
Subtitles.

You can switch
subtitles Subtitle on or Subtitle off . Alternatively
you can select Automatic.

If an audio signal contains two audio languages but
one language or both has no language indication, this
option is available.

Common Interface

If prepaid premium content is available from a CAM,
you can set the provider settings with this option.

Mono / Stereo

You can switch the sound of an analogue channel to
Mono or Stereo.

To switch to Mono or Stereo…
Tune to an analogue channel.
1 - Press  OPTIONS, select Mono/Stereo and

press  (right).

2 - Select Mono or Stereo and press OK.
3 - Press  (left) repeatedly if necessary, to close

the menu.

Automatic

If language information is part of the digital broadcast
and the broadcasted programme is not in your
language (the language set on TV), the TV can show
subtitles automatically in one of your preferred
subtitle languages. One of these subtitle languages
must also be part of the broadcast.

You can select your preferred subtitle languages

Channel Info

Select Channel info to view the technical information
of the channel.

To call up the details of the selected channel…

1 - Tune to the channel.
2 - Press  OPTIONS, select Channel info and

press OK to open the channel info.

21

3 - Press  OPTIONS again or press  Back to
close the programme info.

Premium genre are top broadcast channels
positioned with market share above 3%.

HbbTV on This Channel

If you want to avoid access to HbbTV pages on a
specific channel, you can block the HbbTV pages for
this channel only.

1 - Tune to the channel of which you want to block
the HbbTV pages.

2 - Press  OPTIONS and select HbbTV on this
channel and press  (right).

3 - Select Off and press OK.
4 - Press  (left) to go back one step or

press  Back to close the menu.
To block HbbTV on TV completely…

 (Home) > Settings > All
settings > Channels > HbbTV > Off

Universal Access

Only available when Universal access set to On.
 (Home) > Settings > All settings > Universal

access > Universal access > On.

* Note: The listed by genre function is only apply to
Germany.

Channel List Options

Open Option Menu

To open the channel list option menu...

• Press , to switch to TV.

• Press  Channel list to open the channel list.

• Press  OPTIONS , and select one of options.

• Press  Back to close the channel list.

Rename Channel

1 - Press , to switch to TV.
2 - Press  Channel list to open the channel list..
3 - Select one channel you want to rename.
4 - Press  OPTIONS > Rename channel, and

press OK to open on-screen keyboard.

5 - Use navigation keys to select characters.
6 - Select Enter when complete the editing.
7 - Press  Back to close the channel list.

To read more information, in Help, press the colour
key  Keywords and look up Universal Access.

Video Selection

Digital TV channels can offer multi video signals (multi­feed broadcast), different camera viewpoints or
angles of the same event or different programmes on
one TV channel. The TV shows a message if any such
TV channels are available.

7.3

Channel List

Open Channel List

To open the current channel list…

1 - Press , to switch to TV.
2 - Press OK to open the channel list if Interactive

Service is not available, or press  Channel list to
open the channel list.

3 - Press  OPTIONS > Select channel list.
4 - Select one channel list you want to watch.
5 - Press  Back to close the channel list.

The channels displayed in All Channel list is listed
based on genre*. For example: Premium, Premium
News, Premium Local, Children, Sport and etc. The

Select Channel Filter

1 - Press , to switch to TV.
2 - Press  Channel list to open the channel list.
3 - Press  OPTIONS > Digital/analogue,

Free/scrambled

4 - Select one of channel combinations showing in
the channel list.

Create or Edit Favourites Channel List

 > OK >  OPTIONS > Create favourites list
Select a channel then press OK to add in a

favourites channel list, once completed,
press  Done.

 > OK >  OPTIONS > Edit favourites
Select a channel then press OK to add in or remove

from a favourites channel list, once completed, press

 Done.

Select Channel Range

 > OK >  OPTIONS > Select channel range
Select a range of channels in a channel list. Press

OK to mark the beginning of range and then press OK
again to end the range selection. The selected

22

channels will be marked as favourites.

Create a Favourites List

Select Channel List

 > OK >  OPTIONS > Select channel list
Select one of channel lists that sorted by different

kinds of channels.

Search Channels

 > OK >  OPTIONS > Search channel
You can search for a channel to find it in a long list of

channels. The search will return the matching channel
name with the result arranged in alphabetical order.

1 - Press , to switch to TV.
2 - Press  Channel list to open the channel list.
3 - Press  OPTIONS > Search channel, and

press OK to open on-screen keyboard.
4 - Use navigation keys to select a character, then
press OK.

5 - Select Enter when complete the input.
6 - Press  Back to close the channel list.

Lock or Unlock Channel

 > OK >  OPTIONS > Lock channel, Unlock
channel

To prevent children from watching a channel, you can
lock a channel. To watch a locked channel, you must
enter the 4 digit Child Lock PIN code first. You
cannot lock programmes from connected devices.

The locked channel will have  next to the channel
logo.

1 - While watching a TV channel, press  Channel
list to open the channel list.
2 - Select the channel, and press  Mark as
favourites to mark as favourite.

3 - The selected channel is marked with a .
4 - To finish, press  Back . The channels are

added to the Favourites list.

Remove Channel from the Favourites
List

To remove a channel from the favourites list, select
the channel with , then press  Unmark as

favourite again to unmark as favourite.

Reorder Channels

You can reorder — reposition — channels in the
Favourite channel list.

1 - While watching a TV channel, press OK
>  OPTIONS > Select channel list.

2 - Select Antenna favourite, Cable Favourite or
Satellite favourite*, and press  OPTIONS .

3 - Select Reorder channels, select the channel you
want to reorder, and press OK.
4 - Press the Navigation buttons to move the
highlighted channel to another location and
press OK.
5 - Once completed, press  Done.

* Satellite channel only can be searched
on xxPxSxxxx TV models.

Remove Favourite List

 > OK >  OPTIONS > Remove favourite list
To remove existing favourite list, select Yes.

7.4

Favourite Channels

About Favourite Channels

You can create a favourite channel list that only holds
the channels you want to watch. With the Favourite
channel list selected, you will only see your favourite
channels when you switch through channels.

Favourites List on TV Guide

You can link the TV Guide for your Favourite List.
1 - While watching a TV

channel, press OK >  OPTIONS > Select
channel list.

2 - Select Antenna favourite, Cable Favourite or
Satellite favourite*, and press OK.

3 - Press  TV GUIDE to open it.
With the TV Guide you can view a list of the current

and scheduled TV programmes of your favourite
channels. Along with your favourite channels, the first
3 most used channels from the broadcasters’ default
list will be appended after your favourite channels for
your preview. You need to add these channels into
your favourite list to enable its operation (refer to "TV
Guide" chapter).

On each page of TV Guide, there is a "Did you know"

23

grid inserted on your favourite channel list. The "Did
you know"-channel provides useful tips to improve
the way you use your TV.

* Satellite channel only can be searched
on xxPxSxxxx TV models.

7.5

Text / Teletext

Subtitles from Text

If you tune to an analogue channel, you need to
make the subtitles available for each channel
manually.

1 - Switch to a channel and press TEXT to open
Text.

2 - Enter the page number for subtitles, usually 888.
3 - Press TEXT again, to close Text.

If you select On in the Subtitle menu when watching
this analogue channel, subtitles will be shown if
available.

To know if a channel is analogue or digital, switch to
the channel and press  INFO .

Text Options

In Text/Teletext, press  OPTIONS to select the
following…

• Freeze page
To stop the automatic rotation of subpages.

• Dual screen / Full screen
To show the TV channel and Text alongside each
other.

• T.O.P. overview
To open T.O.P. Text.

• Enlarge
To enlarge the Text page for comfortable reading.

• Reveal
To unhide hidden information on a page.

• Language
To switch the group of characters that Text uses to
display correctly.

• Text 2.5
To activate the Text 2.5 for more colours and better
graphics.

Text Setup

Text language

Text Pages

To open Text/Teletext press TEXT, while you are
watching TV channels.
To close Text, press TEXT again.

Select a Text page

To select a page . . .

1 - Enter the page number with the number keys.
2 - Use the arrow keys to navigate.
3 - Press a colour key to select a colour-coded

subject at the bottom of the screen.

Text sub-pages

A Text page number can hold several subpages. The
subpage numbers are shown on a bar next to the
main page number.
To select a subpage, press  or .

T.O.P. Text pages

Some broadcasters offer T.O.P. Text.
To open T.O.P. Text pages within Text,
press  OPTIONS and select T.O.P. overview.

Some digital TV broadcasters have several Text
languages available.

Set teletext preference language
 (Home) > Settings > All settings > Region and

language > Language > Primary text, Secondary
text

Text 2.5

If available, Text 2.5 offers more colours and better
graphics. Text 2.5 is activated as a standard factory
setting.
To switch off Text 2.5…

1 - Press TEXT.
2 - With Text/Teletext open on screen,

press  OPTIONS.

3 - Select Text 2.5 > Off.
4 - Press  (left) repeatedly if necessary, to close

the menu.

* The teletext can only be reached when the channels
are installed directly on the TV’s internal tuner and
the set is on TV mode. If a set-top box is being used,
the teletext will be unavailable via TV. In that case,
the set-top box’s teletext can be used instead.

24

8

Update TV Guide

TV Guide

8.1

What You Need

With the TV guide you can view a list of the current
and scheduled TV programmes of your channels.
Depending on where the TV guide information (data)
is coming from, analogue and digital channels or only
digital channels are shown. Not all channels offer TV
guide information.

The TV can collect TV guide information for the
channels that are installed on the TV (e.g the
channels you watch with Watch TV). The TV cannot
collect the TV guide information for channels viewed
from a digital receiver.

8.2

Using the TV Guide

Open the TV Guide

To open the TV guide, press  TV GUIDE.
Press  TV GUIDE again to close.
The first time you open the TV Guide, the TV scans all

TV channels for programme information. This may
take several minutes. TV guide data is stored on TV.

You can update the TV guide to get the latest
programmes information.

To update the TV guide, press  OPTIONS and
select Update TV guide. It may take few times to
complete the update.

Change Day

If the TV guide information comes from the
broadcaster, you can press Channel up to view the
schedule of one of the next days. Press Channel
down to go back to the previous day.

Alternatively, you can press  OPTIONS and
select Change day.

Search by Genre

If the information is available, you can look up
scheduled programmes by genre like movies, sports,
etc.

To search for programmes by genre,
press  OPTIONS and select Search by genre.
Select a genre and press OK. A list with the found
programmes appears.

Tune to a Programme

Switch to a programme

• From the TV guide, you can switch to a current
programme.

• To select a programme, use the arrow keys to
highlight the programme name.

• Navigate to the right to view programmes scheduled
later that day.

• To switch to the programme (channel), select the
programme and press OK.

View programme details

To call up the details of the selected programme,
press  INFO .

25

9

Freeview Play (for UK models)

9.1

About Freeview Play

To enjoy Freeview Play*, you need to connect your
TV to Internet first.

Freeview Play offers:

• Watch TV programmes you missed from the last
seven days.

• Watch live TV and on demand, all in one place
without entering an app, you can search Freeview
Play programmes in TV Guide.

• Watch over 70 standard channels and upto 15 HD
channels.

• Enjoy on demand services like BBC iPlayer, the ITV
Hub, All 4, Demand 5, BBC NEWS and BBC SPORT.

• There are no contracts and no monthly costs, you’re
in control.

For detail, please visit: https://www.freeview.co.uk
* Freeview Play is only for UK models.

9.2

Using Freeview Play

To open Freeview Play*…

1 - Press  (Home) to open the home menu.
2 - Press  (right) to overview available Freeview

players (apps) or select Explore Freeview Play to
enter Freeview Play page.
3 - You can press  Search or enter a keyword in
search bar at the right-top to search channels.
4 - You can press  Recommendation on TV Guide
to sort different types of programmes on selecting a
specific genre.
5 - Select a programme and press  Episodes Info
to view the details of the selected programme.
6 - Select a programme and press OK to start
watching.
7 - Press  Back to close.

* Freeview Play is only for UK models.

26

10

View Photos

Videos, Photos and Music

10.1

From a USB Connection

You can view your photos or play your music and
videos from a connected USB flash drive or USB Hard
Drive.

With the TV switched on, plug in a USB flash drive or a
USB Hard Drive to one of the USB connections.

Press  SOURCES, then select  USB, you can
browse your files in folder structure you have
organised on the USB Hard Drive.

10.2

From a Computer or NAS

You can view your photos or play your music and
videos from a computer or a NAS (Network Attached
Storage) in your home network.

The TV and computer or NAS must be in the same
home network. On your computer or NAS, you need
to install Media Server Software. Your Media Server
must be set to share your files with the TV. The TV
shows your files and folders as they are organised by
the Media Server or as they are structured on your
computer or NAS.

The TV does not support subtitles on video streams
from a computer or NAS.

1 - Press  SOURCES, select  USB and
press OK.
2 - Select  USB Flash Drive and press  (right)
to select the USB device you need.
3 - Select Photo, you can press  Sort to
browse your photos by day, month or year.
4 - Select one of photos, and press OK to view the
selected photo.

• To view photos, select Photos in the menu bar,
select a photo thumbnail and press OK.

• If there are several photos in the same folder, select
a photo and press  Slide show to start a slide
show of all photos in this folder.

• Watch a photo and press  INFO to show below:
Progress bar, Playback control bar,  (Jump to the
previous photo in a folder),  (Jump to the next photo
in a folder),  (Start slideshow playback),  (Pause
the playback),  (Start slideshow),  (Rotate
photo)

When viewing a photo file, press  OPTIONS to…

Shuffle off, Shuffle on

View the pictures in sequential order, or at random.

Repeat, Play once

View the pictures repeatedly or once only.

Stop music

Stop the music if the music playback is in progress.

Slideshow speed

Set the speed of the slideshow.

Slideshow transitions

Set the transition from one picture to the next.

If the Media Server supports searching for files, a
search field is available.

To browse and play the files on your computer…
1 - Press  SOURCES, select Network and

press OK.
2 - Once a device is connected, the Network device
item will be replaced by connected device name.

3 - You can browse and play your files.
4 - To stop playing videos, photos and music,

press  EXIT.

10.3

Photos

Photo Options

When browsing photo files, press  OPTIONS to…
List/Thumbnails

View photos with list view or thumbnails view.

Shuffle off, Shuffle on

View the pictures in sequential order, or at random.

Repeat, Play once

View the pictures repeatedly or once only.

Stop music

Stop the music if the music playback is in progress.

Slideshow speed

Set the speed of the slideshow.

Slideshow transitions

Set the transition from one picture to the next.

27

10.4

360° Photo

View 360° Photos

1 - Press  SOURCES, select  USB and
press OK.
2 - Select  USB Flash Drive and press  (right)
to select the USB device you need.
3 - Select 360° Photos, you can press  Sort to
browse your 360° photos by date, month, year or
alphabetically by name.
4 - Select one of 360° photos, and press OK to
view the selected 360° photo.

• To view photos, select 360° Photos in the menu
bar, select a photo thumbnail and press OK.

• If there are several 360° photos in the same folder,
select a 360° photo and press  Slide show to
start a slide show of all 360° photos in this folder.

• Watch a photo and press  INFO to show below:
Progress bar, Playback control bar,  (Jump to the
previous photo in a folder),  (Jump to the next photo
in a folder),  (Start slideshow playback),  (Pause
the playback),  (Play all/Play one),  (Little
Planet),  (Auto Mode/Manual mode).

- Little Planet: Little Planet is an alternate and fun
view of 360° photo. When Little Planet view is started,
the 360° photo will be rendered in a wrapped around
view like a planet.

- Auto Mode/Manual mode: when the 360° player is
started, it will auto pan the selected 360° photo from
left to right (0 to 360 degrees) in 360° view. When
manual mode is entered, the 360° player will stop
auto panning/rotating to allow
manually panning/rotating with the remote control
keys.

When viewing a 360° photo file,
press  OPTIONS to…

Shuffle off, Shuffle on

View the pictures in sequential order, or at random.

Repeat, Play once

View the pictures repeatedly or once only.

Reset view

Reset the angle of view.

Stop music

Stop the music if the music playback is in progress.

360° Photo Options

When browsing 360° photo files,
press  OPTIONS to…

List/Thumbnails

View 360° photos with list view or thumbnails view.

Shuffle off, Shuffle on

View the pictures in sequential order, or at random.

Repeat, Play once

View the pictures repeatedly or once only.

Stop music

Stop the music if the music playback is in progress.

10.5

Videos

Play Videos

To play a video on TV…
Select  Videos , and select the file name and

press OK.

• To pause the video, press OK. Press OK again to
continue.

• To rewind or go fast forward, press  or . Press
the keys several times to speed up - 2x, 4x, 8x, 16x,
32x.

• To jump to the next video in a folder, press OK to
pause and select  on screen and press OK.

• To stop the video playback, press  (Stop).

• To go back to the folder, press .

Open video folder

1 - Press  SOURCES, select  USB and
press OK.
2 - Select  USB Flash Drive and press  (right)
to select the USB device you need.
3 - Select Videos and select one of video, you
can press OK to play the selected video.

• Select a video and press  INFO to show file
information.

• Playback a video and press  INFO to show
below:
Progress bar, Playback control bar,  (Jump to the
previous video in a folder),  (Jump to the next
video in a
folder),  (Playback),  (Rewind),  (Fast
forward),  (Pause the playback),  (Play all/Play
one),  (Shuffle on/Shuffle off)

During the video playback, press  OPTIONS to…

Subtitles

Display the subtitles if available, select On, Off,
or On during mute.

Subtitle language

28

Select subtitles language if available.

Character set

Select the character set if external subtitle is available.

Play songs repeatedly or once.

Audio language

Select audio language if available.

Status

Display the information of the video file.

Repeat, Play once

Play videos repeatedly or once.

Subtitle settings

Set the Font size, Subtitle colour, Subtitle position and
Time sync offset if the options are available.

Video Options

When browsing video files, press  OPTIONS to…
List/Thumbnails

View video files with list view or thumbnails view.

Subtitles

Display the subtitles if available, select On, Off,
or On during mute.

Shuffle off, Shuffle on

Play videos in sequential order, or at random.

Music Options

When browsing music files, press  OPTIONS to…
Shuffle off, Shuffle on

Play songs in sequential order, or at random.

Repeat, Play once

Play songs repeatedly or once.

Repeat, Play once

Play videos repeatedly or once.

10.6

Music

Play Music

Open music folder
1 - Press  SOURCES, select  USB and

press OK.
2 - Select  USB Flash Drive and press  (right)
to select the USB device you need.
3 - Select Music and select one of music, you
can press OK to play the selected music.

• Select a music and press  INFO to show file
information.

• Playback a music and press  INFO to show
below:
Progress bar, Playback control bar,  (Jump to the
previous music in a folder),  (Jump to the next
music in a
folder),  (Playback),  (Rewind),  (Fast
forward),  (Pause the playback),  (Play all/Play
one)

During the music playback, press  OPTIONS to…

Repeat, Play once

29

11

Open TV Setting Menus

11.1

Home Menu Overview

Press  (Home) to select one of below menus, then
press OK.

Sources

This row contains available sources in this TV.

Watch TV

This row contains TV functions which are available for
user.

Apps

This row contains number of apps pre-installed. The
order of these apps are according to business
agreements with content service providers. Each apps
may populate their recommendation (if available)
according to their own choice when the respective
app is highlighted.

• Install channels - Update channels or start a
complete new channel installation.

• Picture style - Select one of preset picture styles
for ideal picture viewing.

• Picture format - Select one of preset picture
format which fits the screen.

• Sound style - Select one of preset sound styles for
ideal sound settings.

• Audio out - Set the TV to play the sound on TV or
on the connected audio system.

• Sleep timer - Set the TV to switch to standby
automatically after a preset time.

• Screen off - If you only listen to music on TV, you
can switch off the TV screen.

• Wireless and networks - Connect to your home
network or adjust the network settings.

• All settings - View all settings menu.

• Help - Diagnose and get more information about
your TV. For more information, in Help, press the
colour key  Keywords and look up Help

Menu for more information.

All settings menu:

Press  (home) key on the remote control,
select Settings > All settings, and press OK.

Search

This row contains an interface to perform the search
within the SmartTV content. The search result and its
order are rendered according to business agreements
with content service providers.

Settings

This row contains settings which are available for
user.

You can reorder the icons on Home menus. To
reposition icons, press OK. Alternatively, you can
select the icon you want to reorder, and hold the OK
key for 3 seconds until the arrows appear around the
icon. Use navigation keys to move the highlighted
icon to another location, then press OK. Press
the  Back key to exit.

11.2

Frequent Settings and All settings

Settings menu:

Press  (Home) > Settings key on the remote
control to find frequent settings.

• How to - Instructions on how to install channels,
sort channels*, update TV software, connect external
devices and use Smart functions on your TV.

* Sorting channels is only applicable for certain
countries.

11.3

All Settings

Picture Settings

Picture Style
Select a style

For easy picture adjustment, you can select a preset
picture style.

 (Home) > Settings > Picture style, press OK to
change to next available option.

The available Picture styles are ...

• Personal - The picture preferences you set during
the first start up

• Vivid - Ideal for daylight viewing

• Natural - Natural picture settings

• Standard - Most energy conscious setting

• Movie - Ideal for watching movies with original
studio effect

• Game - Ideal for gaming*

• Monitor - Ideal for computer monitor**
* Picture style - Game is not available for some video

sources.

30

** Picture style - Monitor is only available when HDMI
source video is applicable for PC application. HDR is
not supported in Monitor mode. The TV is able to play
HDR video in Monitor mode but no HDR processing
will be applied.

Custom a style

You can adjust and store picture settings in in the
currently selected picture style,
like Colour, Contrast or Sharpness.

Adjust the picture contrast
 (Home) > Settings > All

settings > Picture > Backlight contrast

Press the arrows  (Right) or  (Left) to adjust the
contrast value of the picture.

You can decrease contrast value to reduce power
consumption.

Restore a style

To restore the style to its original setting, go
to  (Home) > Settings > All
settings > Picture > Picture style, then
press  Restore style.

• The TV can play HDR programmes from any one of
HDMI connections, broadcasting, from an Internet
source (e.g. Netflix) or from a connected USB memory
device.

• The TV will automatically switched to HDR mode
with indication. TV supports following HDR formats:
Hybrid Log Gamma, HDR10, HDR10+, and Dolby
Vision but it is subject to the availability of such HDR
format in content providers.

For HDR content (Hybrid Log Gamma, HDR10 and
HDR10+)

The styles for HDR (Hybrid Log Gamma, HDR10 and
HDR10+) content are...

• HDR Personal

• HDR Vivid

• HDR Natural

• HDR Movie

• HDR Game

For Dolby Vision HDR content

The styles for Dolby Vision HDR content are...

• HDR Personal

• HDR Vivid

• Dolby Vision Bright

• Dolby Vision Dark

• Dolby Vision Game

Adjust the picture sharpness
 (Home) > Settings > All

settings > Picture > Sharpness

Press the arrows  (Right) or  (Left) to adjust the
sharpness value of the picture.

Adjust the black level of the picture
 (Home) > Settings > All

settings > Picture > Black level

Press the arrows  (Right) or  (Left) to set the
black level of the picture signal.

Note: setting of black level much away from reference
value (50) may result lower contrast.

Expert Mode Picture Settings

Colour Settings

 (Home) > Settings > All
settings > Picture > Expert mode settings

Adjust the colour enhancement
 (Home) > Settings > All

settings > Picture > Expert mode
settings > Colour enhancement

Select Maximum, Medium, or Minimum to set the
level of the colour intensity and the details in bright
colours.

Note: Not available when Dolby Vision signal is
detected.

Colour, Contrast, Sharpness, Black level
Adjust the picture colour

 (Home) > Settings > All
settings > Picture > Colour

Press the arrows  (Right) or  (Left) to adjust the
colour saturation value of the picture.

Select the preset colour temperature
 (Home) > Settings > All

settings > Picture > Expert mode
settings > Colour temperature

Select Normal, Warm, or Cool to set the colour
temperature for your preference.

Customise colour temperature

31

 (Home) > Settings > All
settings > Picture > Expert mode settings >
Custom colour temperature

Select Custom in Colour temperature menu
to customise a colour temperature yourself. Press
the arrows  (Right) or  (Left) to adjust the value.

Whitepoint alignment
 (Home) > Settings > All

settings > Picture > Expert mode settings >
Whitepoint alignment

Dynamic Contrast

 (Home) > Settings > All
settings > Picture > Expert mode
settings > Dynamic contrast

Select Maximum, Medium, or Minimum to set the
level at which the TV automatically enhances the
details in the dark, middle and light areas of the
picture.

Video Contrast, Gamma

Customise the whitepoint alignment based on the
selected colour temperature of the picture. Press
the arrows  (Right) or  (Left) to adjust the value,
press  Reset to reset the value.

Contrast Settings

Contrast Modes

 (Home) > Settings > All
settings > Picture > Expert mode
settings > Contrast mode

Select Normal, Optimized for picture, Optimized for
energy saving to set the TV automatically reduces

the contrast, for best power consumption or for best
picture experience, or select Off to switch off the
adjustment.

HDR Settings

 (Home) > Settings > All
settings > Picture > Expert mode settings > HDR
Plus

Set HDR Plus to Off, Minimum, Medium,
Maximum or Automatic to set the level at which the

TV automatically shows superior contrast and
brightness effect for HDR content.

Video contrast
 (Home) > Settings > All

settings > Picture > Expert mode settings > Video
contrast

Press the arrows  (Right) or  (Left) to adjust the
video contrast level.

Gamma
 (Home) > Settings > All

settings > Picture > Expert mode
settings > Gamma

Press the arrows  (Right) or  (Left) to set a non­linear setting for picture luminance and contrast.

Light Sensor

 (Home) > Settings > All
settings > Picture > Expert mode settings > Light
sensor

To save energy, the built-in ambient light sensor
lowers the brightness of the TV screen when the
surrounding light darkens. The built-in light sensor
automatically adjusts the picture to the lighting
conditions of the room.

Note: Available when High Dynamic Range (HDR)
video is present in selected source except Dolby
Vision case.

• The TV can play HDR programmes from any one of
HDMI connections, broadcasting, from an Internet
source (e.g. Netflix) or from a connected USB memory
device.

• The TV will automatically switched to HDR mode
with indication. TV supports following HDR formats:
Hybrid Log Gamma, HDR10, HDR10+, and Dolby
Vision but it is subject to the availability of such HDR
format in content providers.

Super Resolution

 (Home) > Settings > All
settings > Picture > Expert mode settings > Super
resolution

Select On to have a superior sharpness in line edges
and details.

Picture Clean
Noise reduction

 (Home) > Settings > All
settings > Picture > Expert mode settings > Noise
reduction

32

Select Maximum, Medium, Minimum to set the
level for removing the noise in video content.
Noise is mostly visible as small moving dots in on­screen picture.

MPEG Artefact Reduction
 (Home) > Settings > All

settings > Picture > Expert mode
settings > MPEG Artefact Reduction

Select Maximum, Medium, Minimum to have
different degrees of smoothing the artefacts in
digital video content.
MPEG artefacts are mostly visible as small blocks or
jagged edges in on-screen images.

Picture Format

 (Home) > Settings > All
settings > Picture > Picture format

If the picture is not filling the whole screen, if black
bars are showing on the top or bottom or at both
sides, you can adjust the picture to fill the screen
completely.

To select one of the basic settings to fill the screen…

• Wide screen – automatically zooms in the picture
to 16:9 full screen. Picture content aspect ratio may
change.

• Fill screen – automatically enlarges the picture to
fill the screen. Picture distortion is minimal, subtitles
remain visible. Not suitable for PC input. Some
extreme picture formats can still show black bars.
Picture content aspect ratio may change.

• Fit to screen – automatically zooms in the picture
to fill the screen without distortion. Black bars may be
visible. Not supported for PC input.

• Original – automatically zooms in the picture to fit
the screen with original aspect ratio. No content lost
visible.

 (Home) > Settings > All
settings > Picture > Picture format > Advanced

To format the picture manually…

• Shift – select on the arrows to shift the picture. You
can only shift the picture when it is zoomed in.

• Zoom – select on the arrows to zoom in.

• Stretch – select on the arrows to stretch the
picture vertically or horizontally.

• Undo – select to return to the picture format you
started with.

Dolby Vision Notification

 (Home) > Settings > All
settings > Picture > Dolby Vision Notification

Switch On or Off the Dolby Vision notification when
Dolby Vision content begins to play on your TV.

Quick Picture Settings

 (Home) > Settings > All
settings > Picture > Quick picture settings

• During the first installation, you did some picture
settings in a few easy steps. You can redo these steps
with Quick picture settings menu.

• Select the picture setting you prefer and go to the
next setting.

• To do these steps, make sure the TV can tune to a
TV channel or can show a programme from a
connected device.

Sound Settings

Sound Style

Select a style

For easy sound adjustment, you can select a preset
sound style.

 (Home > Settings > All
settings > Sound > Sound style

The available sound styles are ...

• AI mode - Select AI mode for intelligent switching
of sound style based on audio content.

• Original - Most neutral sound setting

• Movie - Ideal for watching movies

• Music - Ideal for listening to music

• Game - Ideal for gaming

• News - Ideal for speech

• Personal mode - Select to adjust your preferred
sound settings

Restore Personal mode

1 - Set the sound style to Personal mode.
2 - Press the colour key  Restore Style, and

press OK. The style is restored.

Personal Mode Sound Settings

Some Picture format setting selections may not be
available in some conditions. For example, in video
steaming, Android app application, gaming mode, etc.

Speaker virtualizer
 (Home) > Settings > All

settings > Sound > Personal mode
settings > Speaker virtualizer

33

Select On or Auto (Dolby Atmos) to enable Dolby
Atmos which can add height dimension in sound.
With height dimension, sound can be precisely placed
and moved in three-dimensional space.

Clear dialogue
 (Home) > Settings > All

settings > Sound > Personal mode
settings > Clear dialogue

Select On to improve the sound for speech. Ideal for
news programmes.

 (Home) > Settings > All
settings > Sound > Advanced > Delta volume

The Delta volume setting can be used to adjust to
balance the sound level difference between the TV
channel and the HDMI source input. Press the arrows
 (Right) or  (Left) to adjust the delta value for TV
speaker volume.

* Note: Delta volume is available when the input
source is set to HDMI or Analogue sources and the
Audio out is set to TV speakers or HDMI sound

system.

AI Equalizer
 (Home) > Settings > All

settings > Sound > Personal mode settings > AI
Equalizer

Select On to enable intelligent equalizer adjustment
based on audio content and custom settings.

Custom AI Equalizer
 (Home) > Settings > All

settings > Sound > Personal mode
settings > Custom AI Equalizer

Press the arrows  (Right) or  (Left) to adjust the
equalizer settings.

* Note: To restore the Personal mode to its original
setting, select back to Sound style, then
press  Restore style.

TV Placement

Audio Out Settings

 (Home) > Settings > All
settings > Sound > Advanced > Audio out

Set the TV to play the sound on TV or on the
connected audio system.

You can select where you want to hear the TV sound
and how you want to control it.

• If you select TV Speakers, the TV speakers are
always on. All the sound related settings are
applicable to this mode.

• If you select Optical, the TV speakers are switched
off and the sound will be played through the device
connected to Digital Audio Out - Optical.

With an audio device connected with HDMI CEC,
select HDMI sound system. The TV will switch off
the TV speakers when the device is playing the
sound.

To adjust the volume of TV speakers, press Volume
and press the arrows  (right) or  (left) to select the
output source you want to adjust. Press the
arrows  (up) or  (down) to adjust the volume.

 (Home) > Settings > All
settings > Sound > TV placement

Select On a TV stand or On the wall to have best
sound reproduction according to the setting.

Advanced sound settings

Volume Control
Auto volume

 (Home) > Settings > All
settings > Sound > Advanced > Auto volume

Select On to automatically level out sudden volume
differences. Typically when you are switching
channels. Select Night mode for a more
comfortable quiet listening experience.

Delta volume

eARC
eARC setting

 (Home) > Settings > All
settings > Sound > Advanced > eARC

Set eARC mode to Automatic or Off. HDMI eARC
(Enhanced Audio Return Channel) is an advancement
over the previous ARC. It supports the latest high­bitrate audio formats up to192kHz, 24-bit, and
uncompressed 5.1 and 7.1, and 32-channel
uncompressed audio.

HDMI eARC is only available on HDMI 1.

34

Digital Output Settings

Digital output settings are available for SPDIF output
(optical) and HDMI ARC sound signals.

Digital out format
 (Home) > Settings > All

settings > Sound > Advanced > Digital out format

Set the audio out signal of the TV to fit the sound
capabilities of the connected Home Theatre System.

• Stereo (uncompressed): If your audio playback
devices have no multichannel sound processing,
select to only output stereo content to your audio
playback devices.

• Multichannel: Select to output multichannel audio
content (compressed multichannel sound signal) or
stereo audio content to your audio playback devices.

• Multichannel (bypass): Select to send original
bitstream from HDMI ARC to the connected HDMI
Sound System.

- Make sure your audio playback devices support
Dolby Atmos feature.

- SPDIF output (DIGITAL AUDIO OUT) will be
disabled when streaming Dolby Digital Plus content.

Digital out levelling
 (Home) > Settings > All

settings > Sound > Advanced > Digital out
levelling

Adjust the loudness level from device which is
connected to digital audio output (SPDIF) or HDMI.

• Select More to have louder volume.

• Select Less to have softer volume.

• You can set the value in steps of 5ms. Maximum
setting is 60ms.

Dolby Atmos Notification

 (Home) > Settings > All
settings > Sound > Dolby Atmos Notification

Switch On or Off the Dolby Atmos notification when
Dolby Atmos content begins to play on your TV.

Channels

HbbTV Settings - Hybrid Broadcast Broadband TV

 (Home) > Settings > All
Settings > Channels > HbbTV settings > HbbTV

If a TV Channel offers HbbTV services, you must first
switch on HbbTV in the TV settings to access to these
advanced services, e.g. video on-demand and catch­up TV services.

 (Home) > Settings > All
Settings > Channels > HbbTV settings > HbbTV
tracking

Switch the tracking of HbbTV browsing behaviour on
or off. Switching off will inform the HbbTV services not
to track your browsing behaviour.

 (Home) > Settings > All
Settings > Channels > HbbTV settings > HbbTV
cookies

Digital out delay
 (Home) > Settings > All

settings > Sound > Advanced > Digital out delay

For some Home Theatre Systems you might need to
adjust the audio sync delay to synchronise the audio
to the video. Select Off if a sound delay is set on
your Home Theatre System.

Digital out offset (Only available when Digital out
delay set to On)

 (Home) > Settings > All
settings > Sound > Advanced > Digital out offset

• If you cannot set a delay on the Home Theatre
System, you can set the TV to sync the sound.

• You can set an offset that compensates for the time
necessary for the Home Theatre System to process
the sound of the TV picture.

Switch the storage of third-party cookies, site data
and cache from HbbTV services on or off.

 (Home) > Settings > All
Settings > Channels > HbbTV settings > HbbTV
Device ID reset

You can reset your TV unique device identifier. A new
identifier will be created.

 (Home) > Settings > All
Settings > Channels > HbbTV settings > Clear
approved app listing

Allow you to clear the list of HbbTV applications that
you have allowed to be launched on the TV.

35

CAM Operator Profile

 (Home) > Settings > All
Settings > Channels > CAM Operator Profile

To switch on operator profile for CI+/CAM for easy
channel installation and updates.

General Settings

Connection Related Settings

USB Keyboard Settings

control > On

Note:

- EasyLink might not work with devices from other
brands.

- The HDMI CEC functionality has different names on
different brands. Some examples are: Anynet, Aquos
Link, Bravia Theatre Sync, Kuro Link, Simplink and
Viera Link. Not all brands are fully compatible with
EasyLink. Example HDMI CEC branding names are
property of their respective owners.

 (Home) > Settings > All settings > General
settings > USB keyboard settings

To install the USB keyboard, switch on the TV and
connect the USB keyboard to one of
the USB connections on the TV. When the TV
detects the keyboard for the first time, you can select
your keyboard lay-out and test your selection.

Mouse Settings

 (Home) > Settings > All settings > General
settings > Mouse settings

Adjust the motion speed of the USB mouse.

HDMI-CEC Connection - EasyLink

Connect HDMI CEC-compatible devices to your TV,
you can operate them with the TV remote
control. EasyLink HDMI CEC must be switched on on
the TV and the connected device.

Screensaver Settings

 (Home) > Settings > All settings > General
settings > Screensaver settings > Screensaver

Select Backdrop to enable the Screensaver. Select Off
to disable the Screensaver.

 (Home) > Settings > All settings > General
settings > Screensaver settings > When to start

Set the duration (in minutes) when TV is in idle state
before activating the Screensaver.

 (Home) > Settings > All settings > General
settings > Screensaver settings > Preview

Press OK to preview the Screensaver.

HDMI Ultra HD
Set the signal quality for each HDMI connectors

Switch on EasyLink
 (Home) > Settings > All settings > General

settings > EasyLink > EasyLink > On

Operate HDMI CEC-compatible devices with TV
remote control

 (Home) > Settings > All settings > General
settings > EasyLink > EasyLink remote

 (Home) > Settings > All settings > General
settings > Input sources > HDMI (port) > HDMI
Ultra HD

This TV can display Ultra HD signals. Some devices ­connected with HDMI - do not recognise a TV with
Ultra HD and might not work correctly or show
distorted picture or sound.

To avoid the malfunctioning of such a device, you can
adjust HDMI Ultra HD setting when TV is in the HDMI
source. Recommended setting for legacy device is
Standard.

• The setting Optimal allows maximum up to Ultra HD
(50Hz or 60Hz) RGB 4:4:4 or YCbCr 4:4:4/4:2:2/4:2:0
signals.

• The setting Standard allows maximum up to Ultra
HD (50Hz or 60Hz) YCbCr 4:2:0 signals.

Maximum supported video timing format for HDMI
Ultra HD options:

• Resolution: 3840 x 2160

36

• Frame rate (Hz): 50Hz, 59.94Hz, 60Hz

• Video data sub-sampling (bit-depth)

- 8 bit: YCbCr 4:2:0, YCbCr 4:2:2*, YCbCr 4:4:4*, RGB
4:4:4*

- 10 bit: YCbCr 4:2:0*, YCbCr 4:2:2*

- 12 bit: YCbCr 4:2:0*, YCbCr 4:2:2*
* Supported only when HDMI Ultra HD is set
to Optimal.

Select Standard if the picture or sound are distorted.

• Set Optimal (Auto Game) to enable TV to support
the HDMI Variable Refresh Rate* video (on some
models only and the Picture style setting is not
Monitor). This option also enables TV to automatically
set Picture/Sound style to Game whenever it is
informed by the HDMI device connected to TV.

* With HDMI Variable Refresh Rate supported, the TV
changes its refresh rate in real time according to the
frame rate signal to synchronize with every picture. It
is applied to reduce the lag, judder and frame tearing
for better gaming experience.

Note:

To watch HDR10+ or Dolby Vision content from HDMI
source, you may need to power off your player and
power on again when the player connected to TV
playing such content for the first time. HDR10+ or
Dolby Vision content is supported only when HDMI
Ultra HD is set to Optimal or Optimal (Auto Game)

automatically adjusts the picture to the lighting
conditions of the room.

Set TV switch off timer
 (Home) > Settings > All settings > General

settings > Eco settings > Switch off timer

Press the arrows  (Right) or  (Left) to adjust the
value. The value 0 (Off) deactivates the automatic
switch off.

Select Switch off timer, the TV switches off
automatically to save energy.

• TV switches off if receiving a TV signal but you don't
press a key on the remote control during a 4 hour
period.

• TV switches off if not receiving a TV signal nor a
remote control command for 10 minutes.

• If you use the TV as a monitor or use a digital
receiver to watch TV (a Set-Top Box - STB) and you
do not use the remote control of the TV, you should
deactivate this automatic switch off, to set the value
to 0.

Location - Home or Shop

 (Home) > Settings > All settings > General
settings > Location

Auto Movie Mode

Set the Auto movie mode
 (Home) > Settings > All settings > General

settings > Auto movie mode

Set Auto movie mode to On, if you want TV to
automatically set Picture style to Movie whenever it is
informed by the HDMI device connected to TV.

Eco Settings
Set screen off to save energy consumption

 (Home) > Settings > All settings > General
settings > Eco settings > Screen off

Select Screen off, the TV screen is switched off, to
switch the TV screen back on, press any key on the
remote control.

Set the Light Sensor
 (Home) > Settings > All settings > General

settings > Eco settings > Light sensor

To save energy, the built-in ambient light sensor
lowers the brightness of the TV screen when the
surrounding light darkens. The built-in light sensor

• Select the location of your TV

• Select Shop, the picture style is switched back
to Vivid, and can adjust shop settings.

• Shop mode is for in-store promotion.

Shop Setup

 (Home) > Settings > All settings > General
settings > Shop setup

If the TV is set to Shop, you can view feature logos or
set the availablility of a specific demo for in store use.

Adjust Picture and audio
 (Home) > Settings > All settings > General

settings > Shop setup > Picture and audio

Select Optimized to shop or Custom settings for
picture and audio settings.

Logos and banner
 (Home) > Settings > All settings > General

settings > Shop setup > Logos and banner
Set to display Feature logos and Promotional banner.

37

Demo Me autostart
 (Home) > Settings > All settings > General

settings > Shop setup > Demo Me autostart
Turn On/Off the Demo Me autostart.

Manage demos

 (Home) > Apps > Demo me > Manage demos
If the TV is set to Shop, you can manage the demo

videos in Demo me app.

Play demo video
 (Home) > Apps > Demo me > Manage

demos > Play

Select a demo video file and play.

Copy demo file
 (Home) > Apps > Demo me > Manage

demos > Copy to USB

Copy demo file to USB drive.

Redo full TV installation , and set TV status back to
the first time you switch on

 (Home) > Settings > All settings > General
settings > Reinstall TV

Enter PIN code and select Yes, the TV will reinstall
completely. All settings will be reset and installed
channels will be replaced. The installation can take a
few minute

Universal Access Settings

 (Home) > Settings > All settings > Universal
access

With Universal Access switched on, the TV is
prepared for use for the deaf, hard of hearing, blind or
partially sighted people.

Switch on universal access settings
 (Home) > Settings > All settings > Universal

access > Universal access > On.

Delete demo file
 (Home) > Apps > Demo me > Manage

demos > Delete

Delete demo file from your TV.

Configuration of demo
 (Home) > Apps > Demo me > Manage

demos > Configuration
Set the TV to Main TV or Sub TV.

Download new demo file
 (Home) > Apps > Demo me > Manage

demos > Download new

If the Configuration is set to Main TV, you can
download new demo file.

Auto delay setting
 (Home) > Apps > Demo me > Manage

demos > Auto delay setting
Set the Auto delay time from 15 seconds to 5 minutes.

Auto loop selection
 (Home) > Apps > Demo me > Manage

demos > Auto loop selection

Select a demo file for auto loop playing.

Universal access for hearing impaired people
 (Home) > Settings > All settings > Universal

access > Hearing impaired > On

• Some digital TV channels broadcast special audio
and subtitles adapted for the hard of hearing or deaf
people.

• Switched on, the TV automatically switches to the
adapted audio and subtitles, if available.

Universal access for blind or partially sighted
people

 (Home) > Settings > All settings > Universal
access > Audio description > Audio description

> On
Digital TV channels can broadcast special audio

commentary describing what is happening on screen.

 (Home) > Settings > All settings > Universal
access > Audio description > Audio
description > Mixed volume, Audio
effects, Speech

Reset TV Settings and Reinstall TV
Reset all settings value to original TV settings

 (Home) > Settings > All settings > General
settings > Factory settings

• Select Mixed volume, you can mix the volume of
the normal audio with the audio commentary. Press
the arrows  (Right) or  (Left) to adjust the value.

• Set Audio effect to On for extra audio effects in
the commentary audio, like stereo or fading sound.

• Select Speech to set speech
preference, Descriptive or Subtitles.

38

Dialogue enhancement
 (Home) > Settings > All settings > Universal

access > Dialogue enhancement

 (Home) > Settings > All settings > Region and
language > Language > Menu language

Set audio preference language

Increase the intelligibility of dialogue and
commentary. Only available when sound setting

Clear dialogue is On and audio stream is AC-4.

Lock Settings

Set Code and Change Code

 (Home) > Settings > All settings > Child
lock > Set code, Change code

Set new code or reset change code. The child lock
code is used to lock or unlock channels or
programmes.

Note: If you forgot your PIN code, you can override
the current code use 8888 and enter a new code.

Lock for Programme

 (Home) > Settings > All settings > Child
lock > Parental rating

Set a minimum age to watch rated programmes.

App lock

 (Home) > Settings > All settings > Child
lock > App lock

 (Home) > Settings > All settings > Region and
language > Language > Primary audio, Secondary
audio

Digital TV channels can broadcast audio with several
spoken languages for a programme. You can set a
preferred primary and secondary audio language. If
audio in one of these languages is available, the TV
will switch to this audio.

Set subtitle preference language
 (Home) > Settings > All settings > Region and

language > Language > Primary
subtitle, Secondary subtitle

Digital channels can offer several subtitle languages
for a programme. You can set a preferred primary and
secondary subtitle language. If subtitles in one of
these languages are available, the TV will show the
subtitles you selected.

Set teletext preference language
 (Home) > Settings > All settings > Region and

language > Language > Primary text, Secondary
text

Some digital TV broadcasters have several Text
languages available.

You can lock apps unsuited for children. The App lock
will ask for a PIN code when you try to start an 18+
rated app. This lock is only valid for 18+ rated apps
from the Philips apps.

Set code

 (Home) > Settings > All settings > Child
lock > Set code

Set the PIN code to lock or unlock the TV.

Region and Language Settings

Language

 (Home) > Settings > All settings > Region and
language > Language

Change the language of the TV menu and
messages

Clock

 (Home) > Settings > All settings > Region and
language > Clock

Correct clock automatically
 (Home) > Settings > All settings > Region and

language > Clock > Auto clock mode

• The standard setting for the TV clock is Automatic.
The time information comes from the broadcasted
UTC - Coordinated Universal Time information.

• If the clock is not correct, you can set the TV clock
to Country dependent.

• When select Country dependent, you can set the
time for Automatic, Standard time, or Daylight saving

time.

Correct clock manually
 (Home) > Settings > All settings > Region and

39

language > Clock > Auto clock mode > Manual
 (Home) > Settings > All settings > Region and

language > Clock > Date, Time

Go to previous menu, and select Date and Time to
adjust the value.

Note:

• If none of the automatic settings display the time
correctly, you can set the time manually.

• The Auto clock mode setting will be back to
Automatic after the TV power is turned off and on
again.

Set time zone or set a time offset for your region
 (Home) > Settings > All settings > Region and

language > Clock > Time zone

Select one of the time zones.

Set the TV to switch to Standby automatically after a
preset time

 (Home) > Settings > All settings > Region and
language > Clock > Sleep timer.

Set the TV to switch to Standby automatically after a
preset time. With the slider bar you can set the time
to up to 180 minutes in increments of 5 minutes. If set
to 0 minutes, the sleep timer is switched off. You can
always switch off your TV earlier or reset the time
during the countdown.

40

12

Wired Connection

Wireless and Networks

12.1

Home Network

To enjoy the full capabilities of your Philips Smart TV,
your TV must be connected to the Internet.

Connect the TV to a home network with a high-speed
Internet connection. You can connect your TV
wirelessly or wired to your network router.

12.2

Connect to Network

Wireless Connection

What You Need

To connect the TV to the Internet wirelessly, you need
a Wi-Fi router with a connection to the Internet. Use
a high-speed (broadband) connection to the Internet.

What You Need

To connect the TV to the Internet, you need a
network router with a connection to the
Internet. Use a high-speed (broadband) connection
to the Internet.

Make the Connection
 (Home) > Settings > All settings > Wireless

and networks > Wired or Wi-Fi > Connect to
network > Wired

1 - Connect the router to the TV with a network cable
(Ethernet cable**).

2 - Make sure that the router is switched on.
3 - The TV constantly searches for the network

connection.
4 - A message will be shown when the connection is
successful.

Make the Connection - Wireless
 (Home) > Settings > All settings > Wireless

and networks > Wired or Wi-Fi > Connect to
network > Wireless

1 - In the list of found networks, select on your
wireless network. If your network is not in the list
because the network name is hidden (you switched
off the SSID broadcast of the router), select Add New
Network to enter the network name yourself.
2 - Enter your encryption key. If you entered the
encryption key for this network before, you can
select OK to make the connection immediately.
3 - A message will be shown when the connection is
successful.

Turn Wi-Fi On or Off
 (Home) > Settings > All settings > Wireless

and networks > Wired or Wi-Fi > Wi-Fi On/Off

If the connection fails, you can check the DHCP
setting of the router. DHCP should be switched on.

**To fulfill EMC regulations, use a shielded FTP Cat.
5E Ethernet cable.

12.3

Wireless and Network Settings

View Network Settings
 (Home) > Settings > All settings > Wireless

and networks > Wired or Wi-Fi > View network
settings

You can view all current network settings here. The IP
and MAC address, signal strength, speed, encryption
method, etc.

Network Configuration - Static IP
 (Home) > Settings > All settings > Wireless

41

and networks > Wired or Wi-Fi > Network
Configuration > Static IP

If you have more than one TV in your home network,
you can give the TV a unique name.

If you are an advanced user and want to install your
network with Static IP addressing, set the TV to Static

IP.

Network Configuration - Static IP Configuration
 (Home) > Settings > All settings > Wireless

and networks > Wired or Wi-Fi > Static IP
configuration

1 - Select Static IP configuration and configure the
connection.

2 - You can set the number for IP
Address, Netmask, Gateway, DNS 1, or DNS 2.

Switch On with Wi-Fi (WoWLAN)
 (Home) > Settings > All settings > Wireless

and networks > Wired or Wi-Fi > Switch On with
Wi-Fi (WoWLAN)

You can switch this TV on from your smartphone or
tablet if the TV is in Standby. The setting Switch On

with Wi-Fi (WoWLAN) must be switched on.

Netflix settings
 (Home) > Settings > All settings > Wireless

and networks > Wired or Wi-Fi > Netflix settings

With Netflix settings, you can view ESN number or
deactive Netflix device.

Clear Internet Memory
 (Home) > Settings > All settings > Wireless

and networks > Wired or Wi-Fi > Clear Internet
Memory

With Clear Internet Memory you clear your Philips
server registration and parental rating settings, your
video store app logins, all Philips App Gallery
favourites, Internet bookmarks and history. Interactive
MHEG applications can also save so-called 'cookies',
on your TV. These files will also be cleared.

Digital Media Renderer - DMR
 (Home) > Settings > All settings > Wireless

and networks > Wired or Wi-Fi > Digital Media
Renderer - DMR

If your media files do not play on your TV, make sure
that the Digital Media Renderer is switched on. As a
factory setting, DMR is switched on.

Switch on Wi-Fi connection
 (Home) > Settings > All settings > Wireless

and networks > Wired or Wi-Fi > Wi-Fi On/Off

You can switch on or off Wi-Fi connection on your
TV.

Reset Screen Mirroring connection
 (Home) > Settings > All settings > Wireless

and networks > Wired or Wi-Fi > Reset Screen
Mirroring connection

Clear the list of connected and blocked devices that
are used with Screen Mirroring.

TV network name
 (Home) > Settings > All settings > Wireless

and networks > Wired or Wi-Fi > TV network name

42

13

Smart TV

13.1

Setup Smart TV

The first time you open Smart TV, you need to
configure your connection. Read and agree to the
terms and conditions to continue.

The Smart TV Collection page is your link to the
Internet. You can rent movies online, read
newspapers, watch videos and listen to music, also
shop online, or watch TV programmes when it suits
you with On-line TV.

Open Smart TV Collection

To open the Smart TV Collection page,
press  Smart TV Collection .
Alternatively, you can press  (Home) > Apps,
select  Smart TV Collection and press OK.

The TV connects to the Internet and opens the Smart
TV Collection page. This may take a few seconds.

genres and description keywords to search.

Close Smart TV

To close the Smart TV Collection page, press EXIT.
TP Vision Europe B.V. bears no responsibility

regarding the content and the quality of the content
provided by the content service providers.

13.2

Smart TV Collection

Your Apps
You start Apps from the Smart TV Collection page.

Internet

The Internet App opens the World Wide Web on your
TV.
On your TV, you can view any Internet website but
most of them are not tailored for a TV screen.

- Some plug-ins (e.g. to view pages or videos) are not
available on your TV.

- Internet pages are shown one page at a time and
full screen.

Recommended Apps

In this window, Philips presents a range of
recommended Apps for you. You can select and open
them from the Recommended Apps window.

Search

With Search, you can search for relevant Apps.
Select  and press OK, enter a keyword in the text
fieldto to start searching. You can enter names, titles,

43

14

Netflix

If you have a Netflix membership subscription, you
can enjoy Netflix on this TV. Your TV must be
connected to the Internet.

To open Netflix, press  to open the Netflix
App. You can open Netflix immediately from a TV in
standby.

www.netflix.com

44

15

Rakuten TV

Watch the latest new releases on your Smart TV. The
biggest blockbusters, award winning classics and TV
series available instantly.

Press the  key on your remote control or the
app icon to open the Rakuten TV app. Your TV must
be connected to the Internet to use the app. For more
information about Rakuten TV, please visit
www.rakuten.tv.

45

16

Amazon Prime Video

With an Amazon prime membership, you gain access
to thousands of popular movies and TV show,
including exclusive Prime Originals.

Press the  key to open the Amazon Prime
Video app. Your TV must be connected to the Internet
to use the app. For more information about Amazon
Prime Video, please visit www.primevideo.com.

46

17

YouTube

YouTube provides a platform to connect to the world.
Watch and discover popular videos that uploaded by
YouTube users around the world. Use the YouTube
app to explore the latest topics on music, news, and
more.

Press the app icon to open the YouTube app. Your TV
must be connected to the Internet to use the app.
For more information about YouTube, please visit
www.youtube.com.

47

18

Alexa

18.1

About Alexa

Your TV supports Amazon Alexa* voice control
operations.

About Alexa

Alexa is a cloud-based voice service available on
Alexa Echo devices from Amazon and device
manufacturers. With Alexa working on your TV, you
can switch on/off TV, change channels, change
volume and more.

To control your TV with Alexa, you will need...

• Philips Smart TV that supports Alexa

• Amazon account

• Alexa app* (mobile/tablet version)

• Wireless or wired network connection

• Philips TV Remote App

About Alexa Skill

- Return to this skill in the Alexa App on your phone
to enable it, link accounts, and discover your devices.

- Return to your TV to complete setup.

Setup on TV for Alexa

1 - Press  Home and open "Amazon Alexa" app.
2 - You need Alexa app (on mobile device or web

version) be ready to start the setup.
3 - Follow the instructions on screen to accept
Privacy Policy terms, name your TV and sign in your
Amazon account. The Amazon account is needed to
pair with Alexa on TV.
4 - On your mobile device, sign in with the same
Amazon account in the Amazon Alexa app.
5 - Complete following steps in the Amazon Alexa
app. The first is to enable "Philips SAPHI Smart TV
Voice Control" skill. The second is to link your Amazon
account and then the final is to discover devices
6 - At the end of setup screen, you can select Done
to start to use Alexa.

To start Alexa voice control operations, if your TV
remote control does not have Alexa button, you can
use Philips TV Remote App (iOS and Android) on
mobile devices.

Alexa uses the Alexa Skills to extend the voice control
operations. Skills add new capabilities that create a
more personalised experience with your Alexa
enabled TV. "Philips SAPHI Smart TV Voice Control"
skill can be found on Alexa Skills store, it
offers various voice control commands to work with
your Philips Smart TV.

Note: The supported Ambilight styles may depend on
specific TV models. Please refer the user manual of
your TV to know the supported Ambilight styles.

Amazon, Alexa and all related logos are trademarks of
Amazon.com, Inc. or its affiliates. Amazon Alexa is
available in selected languages and countries.

Services availability depends on region. A part or
whole of software/services installed into or accessible
through the product may be changed, discontinued,
removed, suspended, or terminated without notice

18.2

Using Alexa

To use Alexa, you need to first setup the Alexa client
service on your Philips Smart TV. Start the setup by
launching the "Amazon Alexa" app from the Home
screen of your TV. Follow the instructions and
complete the following steps:

- Select a name for your Smart TV for Alexa to
recognize.

- Select an Amazon account and sign-in.

48

19

Google Assistant

Your TV can work with the Google Assistant. Google
Assistant allows you to use your voice to control your
TV – e.g. changing volume, channels and more.

Note: Google Assistant is not available in all
languages and countries.

To enable Google Assistant on your TV, you will
need...

• A Google Home device, like Google Home Mini

• Internet connection on TV

• Google account

• Google Home app (mobile/tablet version)

Setup TV Control with Google Assistant

1 - Follow the instructions on screen to accept the
Privacy Policy for the usage of Google Assistant voice
control feature on this TV.
2 - Choose a name for the TV so that Google
Assistant can recognise it.
3 - Sign in Google account. If you already have a
Google account, please sign in. If not, please create
an account and sign in. After you have signed in
successfully, select "Get Code" to get the device code
of this TV for your device registration.
4 - On your mobile/tablet, search for "Google Home"
app in app store (iOS and Android). Download and
open the Google Home app. Sign in with the same
Google account, which is used to register this TV. You
need to continue the setup on Google Home app in
mobile/tablet to control your TV with voice
commands.
5 - On Google Home app, select “Set up device”,
then click “Search for TV” to find your TV. Sign in to
link to your Google account and enable TV control on
Google Home app.
6 - You can use Google Assistant to turn on your TV
using voice command. For this, the TV needs to
remain in a special power mode, which may result in
slightly higher power consumption during standby.

Google Assistant is available on Philips Android TVs
running on Android O (8) or higher OS version. GA is
available in selected languages and countries with
English-UK and German-DE and French-FR being
supported from the start. Supported
language/countries list is going to be expanded
overtime. For latest language and countries support
list please contact our consumer care.

Services availability depends on region. A part or
whole of software/services installed into or accessible
through the product may be changed, discontinued,
removed, suspended, or terminated without notice.

You are ready to use your Google Home device to
control this TV. Here are some things to try:

- Turn off TV

- Switch to channel 10 on TV

- Channel down on TV

- Increase volume on TV

- Mute TV

Note: If you logout from Google Assistant, you will no
longer be able to use voice commands on this TV.
You will need to redo the Setup TV control with
Google Assistant to use the feature again.

49

20

Environmental

20.1

European Energy Label

The European Energy Label informs you on the
energy efficiency class of this product. The greener
the energy efficiency class of this product is, the
lower the energy it consumes.
On the label, you can find the energy efficiency class,
the average power consumption of this product in
use. You can also find the power consumption values
for this product on the Philips website for your
country at www.philips.com/TVsupport

20.2

EPREL Registration Number

EPREL registration number

Please inform yourself about the local separate
collection system for electrical and electronic
products.

Please act according to your local rules and do not
dispose of your old products with your normal
household waste. Correct disposal of your old
product helps to prevent potential negative
consequences for the environment and human
health.

Your product contains batteries covered by the
European Directive 2006/66/EC, which cannot be
disposed with normal household waste.

43PUS7607 : 1198292
43PUS7657 : 1198296

50PUS7607 : 1205164
50PUS7657 : 1205173

55PUS7607 : 1205365
55PUS7657 : 1205367

65PUS7607 : 1210227
65PUS7657 : 1210231

70PUS7607 : 1210238

20.3

End of Use

Disposal of your old product and batteries

Your product is designed and manufactured with high
quality materials and components, which can be
recycled and reused.

Please find out for yourself about the local rules on
separate collection of batteries because correct
disposal will help to prevent negative consequences
for the environment and human health.

20.4

UK Declaration of Conformity

Hereby, TP Vision Europe B.V. declares that this
television is in compliance with the essential
requirements and other relevant provisions of
Directives Radio Equipment Regulations 2017 and the
Ecodesign for Energy-Related Products and Energy
Information (Amendment) (EU Exit) Regulations 2019
and the Restriction of the Use of Certain Hazardous
Substances in Electrical and Electronic Equipment
Regulations 2012.

When this crossed-out wheeled bin symbol is
attached to a product it means that the product is
covered by the European Directive 2012/19/EU.

50

21

21.4

Specifications

21.1

Power

Product specifications are subject to change without
notice. For more specification details of this product,
see www.philips.com/TVsupport

Power

• Mains power : AC 220-240V +/-10%

• Ambient temperature : 5°C to 35°C

21.2

Reception

• Aerial input : 75 ohm coaxial (IEC75)

• Tuner bands : Hyperband, S-Channel, UHF, VHF

• DVB : DVB-T2, DVB-C (cable) QAM

• Analogue video playback : SECAM, PAL

• Digital video playback : MPEG2 SD/HD (ISO/IEC
13818-2), MPEG4 SD/HD (ISO/IEC 14496-10), HEVC*

• Digital audio playback (ISO/IEC 13818-3)

• Satellite aerial input : 75 ohm F-type

• Input frequency range : 950 to 2150MHz

• Input level range : 25 to 65 dBm

• DVB-S/S2 QPSK, symbol rate 2 to 45M symbols,
SCPC and MCPC

• LNB : DiSEqC 1.0, 1 to 4 LNBs supported, Polarity
selection 14/18V, Band selection 22kHz, Tone burst
mode, LNB current 300mA max

Supported Input Resolution

Supported Computer/Video resolution

Resolution — Refresh rate
Video Inputs - Max frame rate is 60Hz (TV can be in

Video/Game/Computer mode)

• 640 x 480 - 60Hz

• 576p - 50Hz

• 720p - 50Hz, 60Hz

• 1920 x 1080p - 24Hz, 25Hz, 30Hz, 50Hz, 60Hz

• 2560 x 1440 - 60Hz

• 3840 x 2160p - 24Hz, 25Hz, 30Hz, 50Hz, 60Hz

Supported Video only resolution

Resolution — Refresh rate
Video Inputs (TV can be Video or Game Mode )

• 480i - 60Hz (when HDMI Ultra HD is set to
Standard)

• 576i - 50Hz (when HDMI Ultra HD is set to
Standard)

• 1080i - 50Hz, 60Hz

• Variable refresh rate video 1080p, 1440p, 2160p with
frame rate up to 48-60Hz when HDMI Ultra HD is set
to Optimal (Auto Game)

* Note: Some resolution and frame rate may not be
supported in all input sources.

21.5

* Only for DVB-T2, DVB-S2

21.3

Display Resolution

Diagonal screen size

• 108 cm / 43 inch

• 126 cm / 50 inch

• 139 cm / 55 inch

• 164 cm / 65 inch

• 177 cm / 70 inch

• 189 cm / 75 inch

Display resolution

• 3840 x 2160

Sound

• Output power (RMS) : 20W

• Dolby MS12 V2.5

• Dolby Atmos

• DTS – HD (M6)

• Surround Virtualizer + Height Virtualizer

• Dolby Volume Leveler / Night mode

• Dolby Bass Enhancement

• Clear Dialogue

• AI Sound

• AI EQ

21.6

Multimedia

Connections

• USB 2.0

• Ethernet LAN RJ-45

• Wi-Fi 802.11n (built-in)

Supported USB file systems

• FAT, NTFS

51

Playback formats

• Video Codec : AVI, MKV, H.264/MPEG-4 AVC,
MPEG1, MPEG2, MPEG4, VP9, HEVC (H.265), AV1

• Audio Codec : MP3, WAV, AAC, WMA (v2 up to
v9.2), WMA-PRO (v9 and v10), FLAC

• Subtitles :

- Format : SRT, SMI, SSA, SUB, ASS, TXT

- Character encodings : Western Europe, Turkish,
Central Europe, Cyrillic, Greek, UTF-8 (Unicode),
Hebrew, Arabic, Baltic

• Maximum Supported Data Rate :
– MPEG-4 AVC (H.264) is supported up to High
Profile @ L5.1. 30Mbps
– H.265 (HEVC) is supported up to Main / Main 10
Profile up to Level 5.1 40Mbps

• Image Codec : JPEG, GIF, PNG, BMP, HEIF, 360

Wi-Fi Certified

This TV is Wi-Fi Certified device.

21.7

Connectivity

TV Side

• USB 1 - USB 2.0

• USB 2 - USB 2.0

• Common Interface slot: CI+/CAM

• HDMI 3 in - UHD - HDR

• HDMI 2 in - UHD - HDR

• HDMI 1 in - ARC/eARC - UHD - HDR

• Antenna (75 ohm)

• Satellite tuner

TV Rear

• Audio out - Optical Toslink

• Network LAN - RJ45

52

22

Troubleshooting

22.1

Tips

If you can't find a solution for your TV problem in
Troubleshooting, you can use  Keywords in Help
> User manual to find the information you are looking
for. Select a keyword to go the most relevant page in
the User manual.

If the User manual doesn't answer your question, you
can go to the support website of Philips.

To solve any Philips TV related problem, you can
consult our online support. You can select your
language and enter your product model number.

Go to www.philips.com/TVsupport.

contraction of the TV as it cools and warms up. This
does not affect performance.

The TV goes back to standby after showing the
Philips startup screen

When the TV is in standby, a Philips startup screen is
displayed, then the TV returns to standby mode. This
is normal behaviour. When the TV is disconnected
and reconnected to the power supply, the startup
screen is displayed at the next startup. To switch on
the TV from standby, press  (Standby / On) the
remote control or the TV.

The standby light keeps on blinking

Disconnect the power cable from the power outlet.
Wait 5 minutes before you reconnect the power
cable. If the blinking reoccurs, contact Philips TV
Consumer Care.
In Help > User manual, press the colour
key  Keywords and look up Contact Info.

On the support site you can find your country's
telephone number to contact us as well as answers to
frequently asked questions (FAQs). In some countries,
you can chat with one of our collaborators and ask
your question directly or send a question by email.
You can download new TV software or the manual to
read on your computer.

TV Help on your tablet, smartphone or computer

To carry out extended sequences of instructions more
easily, you can download the TV Help in PDF format
to read on your smartphone, tablet or
computer. Alternatively, you can print the relevant
Help page from your computer.
To download the Help (user manual) go
to www.philips.com/TVsupport

22.2

Switch On

The TV does not switch on

• Disconnect the power cable from the power outlet.
Wait for one minute then reconnect it. Make sure that
the power cable is securely connected. Try switching
on again.

• Connect the TV to another wall mains socket and try
switching on.

• Disconnect all connected devices from the TV and
try switching on.

• If the standby light on TV is on, the TV might not
respond to the remote control.

Creaking sound at startup or switch off

When you are turning the TV on or standby, you hear
a creaking sound from the TV chassis. The creaking
sound is due to the normal expansion and

TV switches off by itself
If the TV switches off suddenly, the setting Switch off

timer might be switched on. With Switch off
timer the TV switches off after 4 hours if no remote

control signals were received. To avoid this automatic
switch off, you can deactivate this switch off.
In Help > User manual, press the colour
key  Keywords and look up Switch Off Timer.
Also, if the TV does not receive a TV signal nor a
remote control command for 10 minutes, the TV
switches off automatically.

22.3

Remote Control

TV does not respond to the remote control

• The TV requires some time to start up. During this
time, the TV does not respond to the remote control
or TV controls. This is normal behaviour.

• The batteries of the remote control might be empty.
Replace the batteries with new ones.

22.4

Channels

No digital channels found during the installation

• Check if the TV was connected with an antenna or is
using a provider signal. Check the cable connections.

• Check if the country where you install the TV, has
digital channels available.

• Check if you selected the correct DVB (Digital Video
Broadcast) system. Select DVB-T (terrestrial) when
you use an antenna or common antenna, select DVB­C (cable) if you use a TV cable service.

• Redo the installation and check if you select the

53

correct country and system.

No analogue channels found during the installation

• Check if the TV was connected with an antenna.
Check the cable connections.

• Check if you selected the correct DVB (Digital Video
Broadcast) system. Select DVB-T (terrestrial) when
you use an antenna or common antenna.

• Redo the installation and select Digital and

analogue channels during the installation.
Some channels disappeared, cannot find all or some

previously installed channels

• Check if you selected the correct Channel
list or Favourites list you normally use.

• Some channels might be moved or even deleted by
the broadcaster. In the normal channels list, try to
search for the channel you're missing. If the channel is
still available, you can put it back in the favourites
list.

• A channel can be deleted from the channel
list during Automatic channel update. These
automatic updates are done overnight if the TV is on
standby.
Channels that do not exist anymore are deleted and
new channels will be added to the channel list.
Exceptionally, a channel can be deleted because the
TV could not find it while checking for its presence. It
might not broadcast at night.
To avoid channels being deleted during
the Automatic channel update because the TV
could not find them although these channels are still
there, you can switch off Automatic channel update.

 (Home) > Settings > All
Settings > Channels > Antenna/cable installation,
Satellite installation* > Automatic channel update

* Satellite installation is only for models which
support satellite functions.

• Check if the settings are set to two satellites.

Changing the installation settings did not solve my
problem

All settings, satellites and channels are only stored at
the end of the installation when you finish.

All satellite channels are gone

If you use an Unicable system, make sure you
assigned two unique user band numbers for both
built-in tuners in the Unicable settings. It might be
that another satellite receiver in your Unicable system
is using the same user band number.

Some satellite channels seem to have disappeared
from the channel list

If some channels seem to be gone or displaced, the
broadcaster might have changed the transponder
location of these channels. To restore the channel
positions in the channel list, you can try an update of
the channel package.

I cannot remove a satellite

Subscription packages do not allow removing a
satellite. To remove the satellite, you have to do a
complete installation again and select another
package.

Sometimes the reception is poor

• Check if the satellite dish is solidly mounted. Strong
winds can move the dish.

• Snow and rain can degrade the reception.

22.6


DVB-T2 HEVC channel

• See the technical specifications to make sure that
your TV supports DVB-T2 HEVC in your country and
reinstall DVB-T channel.

22.5

Satellite

The TV cannot find the satellites I want or the TV
installs the same satellite twice

Check if the correct number of satellites is set in
settings at the start of the installation. You can set the
TV to search for One, Two or 3/4 satellites.

A dual head LNB cannot find a second satellite

• If the TV finds one satellite but cannot find a second
one, turn the dish a few degrees. Align the dish to get
the strongest signal on the first satellite. Check the
signal strength indicator of the first satellite on­screen.

No picture / distorted picture

• Check if the TV is connected with an antenna or is
using a provider signal. Check the cable connections.

• Check if the correct source/input is selected in the
sources menu. Press  Sources and select the
source/input you need.

• Check if the external device or source is properly
connected.

• Check if the reception is poor.

• Check if the picture is set to a minimal value.
Select Picture style and select a style and press OK.

• To check if the TV is broken, try to play a video clip.
Press  (Home) > Settings > Help > Check the
TV.
If the video clip stays black, call Philips. Wait until the
clip ends and select Contact info in the Help menu.
Call the telephone number for your country.

Sound but no picture

• Change to other video sources and then change
back to current source.

• Select Picture style and select a style and
press OK.

54

• Restore picture style, select back to Picture style,
then press  Restore style.

• Reset all TV settings, go
to  (Home) > Settings > All settings > General
settings > Reinstall TV.

• Check the connections of the source/input devices.

Poor reception

If the TV picture is distorted or variable in quality, the
input signal might be poor. A weak digital signal is
seen as a picture that is breaking up in square blocks
and freezes occasionally. Much sooner than a bad
analogue signal, a bad digital signal will fall away.

• If the picture size changes all the
time, press  (Home) > Settings > All
settings > Picture > Picture Format > Fit to screen.

• If the position of the picture is incorrect on the
screen, try to check the signal resolution and output
type of the connected device,
press  (Home) > Settings > All

settings > Picture > Picture Format > Original.
Computer picture is not stable

Make sure that your PC uses the supported resolution
and refresh rate.

• Check if the antenna cable is properly connected.

• Large loudspeakers, unearthed audio devices, neon
lights, high buildings and other large objects can
influence reception quality when you are using an
antenna. Try to improve the reception by changing
the antenna direction or moving devices away from
the TV. Bad weather might deteriorate the reception.

• Check if all connections, to and from your devices,
are properly connected.

• If reception on only one channel is poor, fine-tune
this channel with Analogue: manual installation. (Only
for analogue channels)

• Check if the incoming digital signal is sufficiently
strong. While watching a digital channel,
press  OPTIONS and select Status and
press OK. Check the Signal strength and Signal

quality.
Poor picture from a device

• Make sure that the device is connected properly.
Make sure that the device's output video setting is the
highest possible resolution if applicable.

• Restore picture style or change to another picture
style.

Picture settings change after a while

Make sure that Location is set to Home . You can
change and save settings in this mode.

 (Home) > Settings > All settings > General
settings > Location

22.7

Sound

No sound or poor sound quality

• Check if the sound settings of the TV are OK, press
the  volume or  mute key.

• If you use a digital receiver (set-top box), check if
the volume on this receiver is not set to zero or mute.

• Check if the TV - the audio signal - is properly
connected with the Home Theatre System, if you use
such a system for the TV sound. Check if you
connected the HDMI cable to an HDMI1
ARC connection on the Home Theatre System.

• Make sure that the TV audio output is connected to
the audio input on the Home Theatre System.
Sound should be heard from the HTS (Home Theatre
System) speakers.

Sound with loud noise

If you watch a video from a plugged in USB flash drive
or connected computer, the sound from your Home
Theatre System might be distorted. This noise is heard
when the audio or video file has DTS sound but the
Home Theatre System has no DTS sound processing.
You can fix this by setting the Digital out format of
the TV to Stereo.
Press  (Home) > Settings > All

settings > Sound > Advanced > Digital out format

A banner appears

If an on screen promotion banner appears
occasionally or the Picture style automatically
switches back to Vivid at startup, the TV is in Shop
location. Set the TV to Home location for use at
home.

 (Home) > Settings > All settings > General
settings > Location

Picture does not fit the screen / Wrong or unstable
picture size / Picture position is incorrect

• If the picture size - its aspect ratio - does not fit the
screen, with black bars on the top and bottom or left
and right side of the screen, press  (Home) >

Settings > All settings > Picture > Picture
Format > Fill screen.

22.8

HDMI - UHD

HDMI

• Note that HDCP (High-bandwidth Digital Content
Protection) support can delay the time taken for a TV
to display content from an HDMI device.

• If the TV does not recognise the HDMI device and
no picture is displayed, switch the source from one
device to another and back again.

• This is an Ultra HD TV. Some older devices ­connected with HDMI - do not recognise an Ultra HD
TV electronically and might not work correctly or
show distorted picture or sound. To avoid the
malfunctioning of such a device, you can set the

55

signal quality to a level the device can handle. If the
device is not using Ultra HD signals, you can switch
off Ultra HD for this HDMI connection.
If the picture and sound of a device connected with
HDMI is distorted, check if a different HDMI Ultra

HD setting can solve this problem. In Help > User
manual, press the colour key  Keywords and

look up HDMI Ultra HD.

• If there are intermittent sound disruptions, make
sure that output settings from the HDMI device are
correct.

HDMI EasyLink does not work

• Check if your HDMI devices are HDMI-CEC
compatible. EasyLink features only work with devices
that are HDMI-CEC compatible.

No volume icon shown

• When an HDMI-CEC audio device is connected and
you use the TV Remote Control to adjust the volume
level from the device, this behaviour is normal.

22.9

USB

for your router.

DHCP

• If the connection fails, you can check the DHCP
(Dynamic Host Configuration Protocol) setting of the
router. DHCP should be switched on.

22.11

Wrong Menu Language

Change the language back to your language.

1 - Press  Home , and press  (up) for once.
2 - Press  (right) for twice, and press  (down) for

once.
3 - Press 8 times  (right), make sure the icon is ,
and press OK.
4 - Press 7 times  (down), and press OK 2 times,
select your language and press OK.

Photos, videos and music from a USB device do not
show

• Check if the USB storage device is set to Mass
Storage Class compliant, as described in the storage
device's documentation.

• Check if the USB storage device is compatible with
the TV.

• Check if the audio and picture file formats are
supported by the TV. For more information, in Help,
press the colour key  Keywords and look
up Multimedia.

Choppy playback of USB files

• The transfer performance of the USB storage device
may limit the data transfer rate to the TV which
causes poor playback.

22.10

Wi-Fi and Internet

Wi-Fi network not found or distorted

• Check if the firewalls in your network allow access
to the TV's wireless connection.

• If the wireless network does not work properly in
your home, try the wired network installation.

Internet does not work

• If the connection to the router is OK, check the
router connection to the Internet.

The PC and Internet connection are slow

• Look in your wireless router's user manual for
information on indoor range, transfer rate and other
factors of signal quality.

• Use a high-speed (broadband) Internet connection

56

23

Safety and Care

23.1

Safety

Important

Read and understand all safety instructions before
you use the TV. If damage is caused by failure to
follow instructions, the warranty does not apply.

Risk of Electric Shock or Fire

• Never expose the TV to rain or water. Never place
liquid containers, such as vases, near the TV.
If liquids are spilt on or into the TV, disconnect the TV
from the power outlet immediately.
Contact Philips TV Consumer Care to have the TV
checked before use.

• Never expose the TV, remote control or batteries to
excessive heat. Never place them near burning
candles, naked flames or other heat sources,
including direct sunlight.

• Never insert objects into the ventilation slots or other
openings on the TV.

• Never place heavy objects on the power cord.

• Avoid force coming onto power plugs. Loose power
plugs can cause arcing or fire. Ensure that no strain is
exerted on the power cord when you swivel the TV
screen.

• To disconnect the TV from the mains power, the
power plug of the TV must be disconnected. When
disconnecting the power, always pull the power plug,
never the cord. Ensure that you have full access to
the power plug, power cord and outlet socket at all
times.

ensure that the power voltage matches the value
printed on the back of the TV. Never connect the TV
to the power outlet if the voltage is different.

Stability Hazards

A television set may fall, causing serious personal
injury or death. Many injuries, particularly to children,
can be avoided by taking simple precautions such as:

• ALWAYS ensure the television set is not overhanging
the edge of the supporting furniture.

• ALWAYS use cabinets or stands or mounting
methods recommended by the manufacturer of the
television set.

• ALWAYS use furniture that can safely support the
television set.

• ALWAYS educate children about the dangers of
climbing on furniture to reach the television set or its
controls.

• ALWAYS route cords and cables connected to your
television so they cannot be tripped over, pulled or
grabbed.

• NEVER place a television set in an unstable location.

• NEVER place the television set on tall furniture (for
example, cupboards or bookcases) without anchoring
both the furniture and the television set to a suitable
support.

• NEVER place the television set on cloth or other
materials that may be located between the television
set and supporting furniture.

• NEVER place items that might tempt children to
climb, such as toys and remote controls, on the top of
the television or furniture on which the television is
placed.

If the existing television set is going to be retained
and relocated, the same considerations as above
should be applied.

Risk of Injury or Damage to the TV

• Two people are required to lift and carry a TV that
weighs more than 25 kg or 55 lbs.

• If you mount the TV on a stand, only use the
supplied stand. Secure the stand to the TV tightly.
Place the TV on a flat, level surface that can support
the weight of the TV and the stand.

• When wall mounted, ensure that the wall mount can
safely bear the weight of the TV set. TP Vision bears
no responsibility for improper wall mounting that
results in accident, injury or damage.

• Parts of this product are made of glass. Handle with
care to avoid injury or damage.

Risk of damage to the TV !

Before you connect the TV to the power outlet,

Risk of Batteries

• Do not ingest the battery. Chemical burn hazard.

• The remote control may contains a coin/button cell
battery. If the coin/button cell battery is swallowed, it
can cause severe internal burns in just 2 hours and
can lead to death.

• Keep new and used batteries away from children.

• If the battery compartment does not close securely,
stop using the product and keep it away from
children.

• If you think batteries might have been swallowed or
placed inside any part of the body, seek immediate
medical attention.

• Risk of fire or explosion if the battery is replaced by
an incorrect type.

• Replacement of a battery with an incorrect type that
can defeat a safeguard (for example, in the case of

57

some lithium battery types).

• Disposal of a battery into fire or a hot oven, or
mechanically crushing or cutting of a battery, that can
result in an explosion.

• Leaving a battery in an extremely high temperature
surrounding environment that can result in an
explosion or the leakage of flammable liquid or gas.

• A battery subjected to extremely low air pressure
that may result in an explosion or the leakage of
flammable liquid or gas.

Risk of Overheating

Never install the TV in a confined space. Always leave
a space of at least 20 cm or 8 inches around the TV
for ventilation. Ensure curtains or other objects never
cover the ventilation slots on the TV.

Lightning Storms

23.2

Screen Care

Clean

• Never touch, push, rub or strike the screen with any
object.

• Unplug the TV before cleaning.

• Clean the TV and frame with a soft damp cloth and
wipe gently. Never use substances such as alcohol,
chemicals or household cleaners on the TV.

• To avoid deformations and colour fading, wipe off
water drops as quickly as possible.

• Avoid stationary images as much as possible.
Stationary images are images that remain onscreen
for extended periods of time. Stationary images
include onscreen menus, black bars, time displays,
etc. If you must use stationary images, reduce screen
contrast and brightness to avoid screen damage.

Disconnect the TV from the power outlet and antenna
before lightning storms.
During lightning storms, never touch any part of the
TV, power cord or antenna cable.

Risk of Hearing Damage

Avoid using earphones or headphones at high
volumes or for prolonged periods of time.

Low Temperatures

If the TV is transported in temperatures below 5°C or
41°F, unpack the TV and wait until the TV temperature
reaches room temperature before connecting the TV
to the power outlet.

Humidity

In rare occasions, depending on temperature and
humidity, minor condensation can occur on the inside
of the TV glass front (on some models). To prevent
this, do not expose the TV to direct sunlight, heat or
extreme humidity. If condensation occurs, it will
disappear spontaneously while the TV is playing for a
few hours.
The condensation moisture will not harm the TV or
cause malfunction.

58

24

Terms of Use

2022 © TP Vision Europe B.V. All rights reserved.
This product was brought to the market by TP Vision

Europe B.V. or one of its affiliates, hereinafter referred
to as TP Vision, which is the manufacturer of the
product. TP Vision is the warrantor in relation to the
TV with which this booklet was packaged. Philips and
the Philips Shield Emblem are registered trademarks
of Koninklijke Philips N.V.

Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips N.V
or their respective owners. TP Vision reserves the right
to change products at any time without being obliged
to adjust earlier supplies accordingly.

The written material packaged with the TV and the
manual stored in the memory of the TV or
downloaded from the Philips
website www.philips.com/TVsupport are believed to
be adequate for the intended use of the system.

The material in this manual is believed adequate for
the intended use of the system. If the product, or its
individual modules or procedures, are used for
purposes other than those specified herein,
confirmation of their validity and suitability must be
obtained. TP Vision warrants that the material itself
does not infringe any United States patents. No
further warranty is expressed or implied. TP Vision
cannot be held responsible neither for any errors in
the content of this document nor for any problems as
a result of the content in this document. Errors
reported to Philips will be adapted and published on
the Philips support website as soon as possible.

Therefore, please note this is not subjected to repair,
exchange or refund within and/or out of the warranty
period.

CE compliance
Hereby, TP Vision Europe B.V. declares that this
television is in compliance with the essential
requirements and other relevant provisions of
Directives 2014/53/EU (RED), 2009/125/EC (Eco
Design) and 2011/65/EC (RoHS).

Compliance with EMF
TP Vision manufactures and sells many products
targeted at consumers which, like any electronic
apparatus, in general have the ability to emit and
receive electromagnetic signals. One of TP Vision’s
leading business principles is to take all necessary
health and safety measures for our products, to
comply with all applicable legal requirements and to
stay well within the Electro Magnetic Field (EMF)
standards applicable at the time of producing the
products.

TP Vision is committed to developing, producing and
marketing products that cause no adverse health
effects. TP Vision confirms that, as long as its products
are handled properly for their intended use, they are
safe to use according to scientific evidence available
today. TP Vision plays an active role in the
development of international EMF and safety
standards, enabling TP Vision to anticipate further
developments in standardisation for early integration
in its products.

Terms of warranty - Risk of injury, damage to TV or
void of warranty!
Never attempt to repair the TV yourself. Use the TV
and accessories only as intended by the
manufacturer. The caution sign printed on the back of
the TV indicates risk of electric shock. Never remove
the TV cover. Always contact Philips TV Customer
Care for service or repairs. Find the telephone number
in the printed documentation that came with the
TV. Or consult our website

www.philips.com/TVsupport and select your country

if needed. Any operation expressly prohibited in this
manual, or any adjustments and assembly
procedures not recommended or authorised in this
manual, shall void the warranty.

Pixel characteristics
This TV product has a high number of colour pixels.
Although it has effective pixels of 99.999% or more,
black dots or bright points of light (red, green or blue)
may appear constantly on the screen. This is a
structural property of the display (within common
industry standards) and is not a malfunction.

59

25

Copyrights

25.1

HDMI

HDMI

The terms HDMI, HDMI High-Definition Multimedia
Interface, and the HDMI Logo are trademarks or
registered trademarks of HDMI Licensing
Administrator, Inc.

25.2

HEVC Advance

HEVC Advance

Covered by one or more claims of the HEVC patents
listed at patentlist.accessadvance.com.
Future proof with advanced HEVC decoding.

25.4

DTS-HD

DTS-HD

For DTS patents, see http://patents.dts.com.
Manufactured under license from DTS Licensing
Limited. DTS, the Symbol, DTS and the Symbol
together, DTS-HD, and the DTS-HD logo are
registered trademarks or trademarks of DTS, Inc. in
the United States and/or other countries. © DTS, Inc.
ALL RIGHTS RESERVED.

25.5

Wi-Fi Alliance

Wi-Fi®, the Wi-Fi CERTIFIED logo, the Wi-Fi logo are

registered trademarks of the Wi-Fi Alliance.

25.3

Dolby Vision and Dolby Atmos

Dolby Vision and Dolby Atmos

Dolby, Dolby Vision, Dolby Atmos, Dolby Audio, and
the double-D symbol are registered trademarks of
Dolby Laboratories Licensing Corporation.
Manufactured under license from Dolby Laboratories.
Confidential unpublished works. Copyright ©
2012–2021 Dolby Laboratories.
All rights reserved.

25.6

Other Trademarks

All other registered and unregistered trademarks are
the property of their respective owners.

60

26

Open Source

26.1

Open Source Software

This television contains open source software. TP
Vision Europe B.V. hereby offers to deliver, upon
request, a copy of the complete corresponding
source code for the copyrighted open source
software packages used in this product for which such
offer is requested by the respective licences.

regardless
of the platform on which their software is built,
relieving them of
the need to code special-case conditions to work
around or take
advantage of platform-specific deficiencies or
features.
Source: https://github.com/apache/apr

bind ( 9.11.36)
BIND (Berkeley Internet Name Domain) is a complete,
highly portable implementation of the Domain Name
System (DNS) protocol.
Source: https://github.com/isc-projects/bind9

This offer is valid up to three years after product
purchase to anyone in receipt of this information.
To obtain the source code, please write in English to .
. .

[email protected]

26.2

Open Source License

About Open Source License

README for the source code of the parts of TP Vision
Netherlands B.V. TV software that fall under open
source licenses.

This is a document describing the distribution of the
source code used on the TP Vision Netherlands B.V.
TV, which fall either under the GNU General Public
License (the GPL), or the GNU Lesser General Public
License (the LGPL), or any other open source license.
Instructions to obtain copies of this software can be
found in the Directions For Use.

TP Vision Netherlands B.V. MAKES NO WARRANTIES
WHATSOEVER, EITHER EXPRESS OR IMPLIED,
INCLUDING ANY WARRANTIES OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR
PURPOSE, REGARDING THIS SOFTWARE. TP Vision
Netherlands B.V. offers no support for this software.
The preceding does not affect your warranties and
statutory rights regarding any TP Vision Netherlands
B.V. product(s) you purchased. It only applies to this
source code made available to you.

Open Source

apr (1.7.0)
The Apache Portable Runtime Library provides a
predictable and
consistent interface to underlying platform-specific
implementations, with an API to which software
developers may code
and be assured of predictable if not identical behavior

busybox (1.31.1)
BusyBox combines tiny versions of many common
UNIX utilities into a single small executable. It
provides replacements for most of the utilities you
usually find in GNU fileutils, shellutils, etc. The utilities
in BusyBox generally have fewer options than their
full-featured GNU cousins; however, the options that
are included provide the expected functionality and
behave very much like their GNU counterparts.
BusyBox provides a fairly complete environment for
any small or embedded system.
Source: https://www.busybox.net/downloads/

binutils (2.31.510
The GNU Binutils are a collection of binary tools. The
main ones are:
ld - the GNU linker.
as - the GNU assembler.
Source: https://www.gnu.org/software/binutils/

bzip2 (1.0.6)
bzip2 is a free and open-source file compression
program that uses the Burrows–Wheeler algorithm. It
only compresses single files and is not a file archiver.
It was developed by Julian Seward, and maintained
by Mark Wielaard and Micah Snyder.
Source: https://sourceware.org/bzip2/

c-ares (1.10.1)
c-ares is a C library for asynchronous DNS requests
(including name resolves)
Source: https://c-ares.org/

cario (1.16.0)
Cairo is a 2D graphics library with support for multiple
output devices. Currently supported output targets
include the X Window System (via both Xlib and
XCB), Quartz, Win32, image buffers, PostScript, PDF,
and SVG file output. Experimental backends include
OpenGL, BeOS, OS/2, and DirectFB.
source https://www.cairographics.org/

dbus (1.11.2)
D-Bus is a simple system for interprocess
communication and coordination.

61

The "and coordination" part is important; D-Bus
provides a bus daemon that does things like:

- notify applications when other apps exit

- start services on demand

- support single-instance applications
Source: https://github.com/freedesktop/dbus

e2fsprogs (1.43.3)
e2fsprogs (sometimes called the e2fs programs) is a
set of utilities for maintaining the ext2, ext3 and ext4
file systems. Since those file systems are often the
default for Linux distributions, it is commonly
considered to be essential software
Source: http://e2fsprogs.sourceforge.net/

expat (2.2.9)
xml paser; Expat is an XML parser library written in C.
It is a stream-oriented parser in which an application
registers handlers for things the parser might find in
the XML document (like start tags). An introductory
article on using.
This piece of software is made available under the
terms and conditions of the Expat license, which can
be found below.
Source: http://expat.sourceforge.net/

fuse (2.9.7)
JBoss Fuse is an open source ESB with capabilities
based on Apache Camel, Apache CXF, Apache
ActiveMQ, Apache Karaf and Fabric8 in a single
integrated distribution.
Source https://github.com/jboss-fuse/fuse

gdb (8.2.1)
GDB, the GNU Project debugger, allows you to see
what is going on `inside' another program while it
executes -- or what another program was doing at
the moment it crashed.
Source: https://www.sourceware.org/gdb/

glibc (2.30.0)
Any Unix-like operating system needs a C library: the
library which defines the “system calls” and other
basic facilities such as open, malloc, printf, exit...The
GNU C library is used as the C library in the GNU
system and most systems with the Linux kernel
This piece of software is made available under the
terms and conditions of the glibc license, which can
be found below.
Source: http://www.gnu.org/software/libc/

gstreamer (1.18.3)
The GStreamer team is excited to announce a new
major feature release of your favourite cross-platform
multimedia framework!
Source: https://gstreamer.freedesktop.org/

libasound (1.1.8)
The Advanced Linux Sound Architecture (ALSA)
provides audio and MIDI functionality to the Linux

operating system. ALSA has the following significant
features:
Efficient support for all types of audio interfaces, from
consumer sound cards to professional multichannel
audio interfaces.
Fully modularized sound drivers.
SMP and thread-safe design (PLEASE READ THIS).
User space library (alsa-lib) to simplify application
programming and provide higher level functionality.
Support for the older Open Sound System (OSS) API,
providing binary compatibility for most OSS programs.
Source: https://www.alsa­project.org/wiki/Main_Page

Libcurl (7.79.1)
HTTP client;libcurl is a free and easy-to-use client­side URL transfer library, supporting FTP, FTPS, HTTP,
HTTPS, SCP, SFTP, TFTP, TELNET, DICT, LDAP,
LDAPS, FILE, IMAP, SMTP, POP3 and RTSP. libcurl
supports SSL certificates, HTTP POST, HTTP PUT, FTP
uploading, HTTP form based upload, proxies, cookies,
user+password authentication (Basic, Digest, NTLM,
Negotiate, Kerberos4), file transfer resume, http proxy
tunneling and more!
This piece of software is made available under the
terms and conditions of the Libcurl license, which can
be found below.
Source: http://curl.haxx.se/

libevent (1.4.13)
The libevent API provides a mechanism to execute a
callback function when a specific event occurs on a
file descriptor or after a timeout has been reached.
Furthermore, libevent also support callbacks due to
signals or regular timeouts.
source: https://libevent.org/

libjpeg-turbo (2.1.1)
libjpeg-turbo is a JPEG image codec that uses SIMD
instructions (MMX, SSE2, AVX2, Neon, AltiVec) to
accelerate baseline JPEG compression and
decompression on x86, x86-64, Arm, and PowerPC
systems, as well as progressive JPEG compression on
x86 and x86-64 systems. On such systems, libjpeg­turbo is generally 2-6x as fast as libjpeg, all else being
equal. On other types of systems, libjpeg-turbo can
still outperform libjpeg by a significant amount, by
virtue of its highly-optimized Huffman coding
routines. In many cases, the performance of libjpeg­turbo rivals that of proprietary high-speed JPEG
codecs.
Source: https://libjpeg-turbo.org/

libjpg (6b)
This library is used to perform JPEG decoding tasks.
This piece of software is made available under the
terms and conditions of the libjpg license, which can
be found below.
Source: http://www.ijg.org/

62

libpng (1.0.1)
libpng -THE reference library for reading, displaying,
writing and examining png Image Network Graphics.
This piece of software is made available under the
terms and conditions of the libpng license, which can
be found below.
Source: http://sourceforge.net/projects/libpng/files/

libffi (3.2.1)
Compilers for high level languages generate code that
follows certain conventions. These conventions are
necessary, in part, for separate compilation to work.
One such convention is the "calling convention". The
"calling convention" is a set of assumptions made by
the compiler about where function arguments will be
found on entry to a function. A "calling convention"
also specifies where the return value for a function is
found.
Source: https://sourceware.org/libffi/

libjansson (2.13.1)
Jansson is a C library for encoding, decoding and
manipulating JSON data. Its main features and design
principles are:
Simple and intuitive API and data model
Comprehensive documentation
No dependencies on other libraries
Full Unicode support (UTF-8)
Extensive test suite
Source: https://github.com/akheron/jansson

libmicrohttpd (0.9.73)
GNU libmicrohttpd is a small C library that is
supposed to make it easy to run an HTTP server as
part of another application. GNU Libmicrohttpd is free
software and part of the GNU project
Source:https://www.gnu.org/software/libmicrohttpd/

libupnp (1.6.10)
The portable SDK for UPnP™ Devices (libupnp)
provides developers with an API and open source
code for building control points, devices, and bridges
that are compliant with Version 1.0 of the Universal
Plug and Play Device Architecture Specification and
support several operating systems like Linux, *BSD,
Solaris and others.
Source: https://pupnp.sourceforge.io/

libuuid (1.3.0)
This library is free software; you can redistribute it
and/or
modify it under the terms of the Modified BSD
License.
The complete text of the license is available at the
Documentation/licenses/COPYING.BSD-3 file
Source:https://sourceforge.net/projects/libuuid/

Libxml2 (2.9.12)
The "libxml2" library is used in AstroTV as a support
for the execution of NCL application. This library was

developed for the GNOME software suite and is
available under a "MIT" license.
Source: http://www.xmlsoft.org

linux_kernel (4.19)
The Linux kernel is a mostly free and open-source,[11]
monolithic, modular, multitasking, Unix-like operating
system kernel. It was originally authored in 1991 by
Linus Torvalds for his i386-based PC, and it was soon
adopted as the kernel for the GNU operating system,
which was written to be a free (libre) replacement for
UNIX.
Source: https://www.kernel.org/

mbed TLS (2.26.0)
Mbed TLS is a C library that implements
cryptographic primitives, X.509 certificate
manipulation and the SSL/TLS and DTLS protocols.
Its small code footprint makes it suitable for
embedded systems.
Source: https://github.com/ARMmbed/mbedtls

ncurses (6.1)
The ncurses (new curses) library is a free software
emulation of curses in System V Release 4.0 (SVr4),
and more. It uses terminfo format, supports pads and
color and multiple highlights and forms characters
and function-key mapping, and has all the other
SVr4-curses enhancements over BSD curses. SVr4
curses is better known today as X/Open Curses.
Source: http://www.gnu.org/software/ncurses/

nghttp2 (1.6.3)
nghttp2 is an implementation of HTTP/2 and its
header compression algorithm HPACK in C
Source: https://nghttp2.org/

NTFS-3G (7.8)
NTFS-3G is an open source cross-platform
implementation of the Microsoft Windows NTFS file
system with read-write support. NTFS-3G often uses
the FUSE file system interface, so it can run
unmodified on many different operating systems. It is
runnable on Linux, FreeBSD, NetBSD, OpenSolaris,
BeOS, QNX, WinCE, Nucleus, VxWorks,
Haiku,MorphOS, and Mac OS X It is licensed under
either the GNU General Public License or a
proprietary license. It is a partial fork of ntfsprogs and
is under active maintenance and development.
This piece of software is made available under the
terms and conditions of the NTFS-3G Read/Write
Driver license, which can be found below.
Source: http://www.tuxera.com

openssl (1.1.1l)
OpenSSL is an open source implementation of the
SSL and TLS protocols. The core library (written in the
C programming language) implements the basic
cryptographic functions and provides various utility
functions. Wrappers allowing the use of the OpenSSL

63

library in a variety of computer languages are
available.
Source: http://www.openssl.org/

pcre (8.45)
The PCRE library is a set of functions that implement
regular expression pattern matching using the same
syntax and semantics as Perl 5. PCRE has its own
native API, as well as a set of wrapper functions that
correspond to the POSIX regular expression API. The
PCRE library is free, even for building proprietary
software.
https://www.pcre.org/

procps (ps, top) (3.3.15)
procps is the package that has a bunch of small
useful utilities that give information about processes
using the /proc filesystem.
The package includes the programs ps, top, vmstat, w,
kill, free, slabtop, and skill.
Source: http://procps.sourceforge.net/index.html

SQLite3 (3.36.0)
SQLite is a in-process library that implements a self­contained, serverless, zero-configuration,
transactional SQL database engine.
This piece of software is made available under the
terms and conditions of the SQLite3 license, which
can be found below.
Source: http://www.sqlite.org/

util-linux-ng (2.35.2)
Various system utilities.
Source: http://userweb.kernel.org/~kzak/util-linux­ng/

wpa_supplicant (2.9)
wpa_supplicant is a WPA Supplicant for Linux, BSD,
Mac OS X, and Windows with support for WPA and
WPA2 (IEEE 802.11i / RSN). It is suitable for both
desktop/laptop computers and embedded systems.
Supplicant is the IEEE 802.1X/WPA component that is
used in the client stations. It implements key
negotiation with a WPA Authenticator and it controls
the roaming and IEEE 802.11
authentication/association of the wlan driver.
Source: https://w1.fi/wpa_supplicant/

zlib (1.2.8)
The 'zlib' compression library provides in-memory
compression and decompression functions, including
integrity checks of the uncompressed data.
This piece of software is made available under the
terms and conditions of the zlib license, which can be
found below.
Source: http://www.zlib.net/

64

27

Disclaimer regarding services and/or software offered by third parties

Services and/or software offered by third parties may
be changed, suspended, or terminated without prior
notice. TP Vision does not bear any responsibility in
these sorts of situations.

65

Index

A

Advanced Picture Settings 31
Advanced Sound Settings 34
AI Equalizer 33
Alexa 48
Antenna 12
App lock 39
Audio Language 39
Audio Out Menu 34
Auto Clock Mode 39
Auto movie mode 37
Automatic software update 5

B

Batteries 7

C

CAM PIN 39
Channel List 22
Channel List Copy 20
Channel Options 21
Channel, Channel Filter 22
Channel, Rename Channel 22
Channels 17
Child Lock 39
Child Lock, Change Code 39
Child Lock, Set Code 39
CI Card 14
Clear dialogue 33
Clear Internet Memory 41
Clock 39
Colour Enhancement 31
Colour Settings 31
Colour Temperature 31
Connect Device 12
Connection - Power Cable 10
Consumer Care 4
Contact Info 4

D

Date 39
Daylight Saving 39
Dialogue enhancement 38
Digital Audio Out - Optical 13
Digital Media Renderer - DMR 41
Digital Out Delay 35
Digital Out Format 35
Digital Out Levelling 35
Digital Out Menu 35
Digital Out Offset 35
Dolby Atmos Notification 35
Dolby Vision Notification 33
Dynamic Contrast 32

E

Eco, Light Sensor 37
End of Use 50
Energy Saving 37
European Eco-label 50

F

Favourite Channel, Channel Range 22
Favourite Channel, Create 22

Favourite Channel, Edit 22
Favourite Channels 23

G

Gamma 32
General Settings 36
Get Support 4
Google Assistant 49

H

HbbTV 35
HDMI 12
HDMI - ARC/eARC 13
HDMI - CEC 36
HDMI Sound System 34
HDMI Ultra HD 36
HDR 32
Help Menu 4
Home Menu 30
Home or Shop 37

I

Identify TV 4
Install Channel - Antenna 17
Install Channel - Cable 17
Install Channel - Satellite 19

L

Location 37
Lock Channel 23

M

Menu Languages 39
Mouse Settings 36

N

Netflix Settings 41
Network - Wired 41
Network - Wireless 41
Network Settings 41
Network Settings Menu 41

P

Parental Rating 39
Philips TV Remote App 14
Photos, Videos and Music 27
Picture Clean, Noise Reduction 32
Picture Contrast Menu 32
Picture Contrast Mode 32
Picture Format 33
Picture Style 30
Picture, Brightness 31
Picture, Colour 31
Picture, Contrast 31
Picture, Light sensor 32
Picture, Sharpness 31
Problems 53

Q

Quick Picture Settings 33
Quick Settings Menu 30

R

Reception 51

66

Register TV 4
Remote Control 7
Remote Control - IR Sensor 9
Remote Control and Batteries 7
Rename or replace device icon 16
Repair 4
Reset Settings 38

S

Safety and Care 57
Satellite 12
Screen Mirroring 13
Screen Mirroring Connection 13
Screen Off 37
Screensaver settings 36
Shop Setup 37
Sleep Timer 39
Smart TV 43
Software Version 5
Sound Menu 33
Sound Style 33
Sound, Auto Volume Levelling 34
Sound, Delta Volume 34
Source List 16
Standby Mode 11
Static IP 41
Subtitle Language 39
Super resolution 32
Switch Off Timer 37
Switch On with Wi-Fi 41
Switching On 11

Wi-Fi 41

T

Teletext 24
Text 24
Time 39
Time Zone 39
Troubleshooting 53
TV Guide 25
TV Information 4
TV Network Name 41
TV Placement 34
TV Speaker 34

U

Universal Access 38
Universal Access, Audio Description 38
Universal Access, Audio Effects 38
Universal Access, Hearing Impaired 38
Universal Access, Mixed Volume 38
Universal Access, Speech 38
Unlock Channel 23
Update Software 5
Update Software - Internet 5
Update Software - Local Updates 5
Update Software - USB 5
USB Flash Drive 15
USB Keyboard Settings 36
User Manual 4

V

Video Contrast 32
View Network Settings 41
View software update history 6
Viewing Distance 10

W

Whitepoint Alignment 31

67

Powered by TCPDF (www.tcpdf.org)

68
