Philips 55PUD8115/30, 43PUD8145/30, 55PUD8125/30, 65PUD8115/30, 43PUD8135/30 User Manual

81x5 Series

User Manual

43PUD8135
43PUD8145

50PUD8115

50PUD8125

55PUD8115

55PUD8125

65PUD8115

65PUD8125

Register your product and get support at

www.philips.com/TVsupport

Contents

1 Home Screen 3

1.1 Home Screen and Channels 3

1.2 Open the Home Screen 3

2 Setting Up 4

2.1 Read Safety 4

2.2 TV Stand and Wall Mounting 4

2.3 Tips on Placement 4

2.4 Power Cable 4

2.5 Antenna Cable 4

3 Remote Control 6

3.1 Key Overview 6

3.2 IR Sensor 7

3.3 Batteries 7

3.4 Cleaning 7

4 Switching On and Off 8
5 Channels 9

5.1 About Channels and Switch Channels 9

5.2 Channel Lists 9

5.3 Watching channels 9

5.4 Favourite Channels 10

6 Channel Installation 11

6.1 Channel update 11

6.2 Manual Channel Update 11

6.3 Reception Quality 11

7 Connect Devices 12

7.1 About Connections 12

7.2 Home Theatre System - HTS 13

7.3 Video Device 13

7.4 Audio Device 14

7.5 USB Hard Drive 14

7.6 USB Flash Drive 15

8 Bluetooth 16

8.1 What You Need 16

8.2 Pairing a Device 16

8.3 Select a Device 16

8.4 Rename a Device 16

8.5 Remove a Device 16

9 Connect your Android TV 17

9.1 Network and Internet 17

9.2 Google Account 18

10 Apps 19

10.1 About Apps 19

10.2 Google Play 19

10.3 Start or Stop an App 20

10.4 Manage Apps 20

11 Sources 21

11.1 Switch to a device 21

12 Settings 22

12.1 TV Options 22

12.2 Picture Settings 22

12.3 Sound Settings 23

12.4 Power Settings 24

12.5 Advanced Options 24

12.6 Other settings 25

12.7 Reboot 25

12.8 Factory Reset 26

12.9 Clock and Language Settings 26

12.10 Accessibility Settings 27

13 Videos, Photos, Music & Text 28

13.1 From a USB Connection 28

13.2 Play your Videos 28

13.3 View your Photos 28

13.4 Play your Music 29

13.5 View your Text 29

14 TV Guide 30

14.1 TV Guide Data 30

14.2 Using the TV Guide 30

15 Recording and Pause TV 31

15.1 Record Options 31

15.2 Recording 31

15.3 Time Shift 32

16 Smartphones and Tablets 33

16.1 Google Cast 33

17 Netflix 34
18 Software 35

18.1 Update Software 35

18.2 Software Version 35

18.3 Open Source Licenses 35

19 Specifications 36

19.1 Environmental 36

19.2 Power 36

19.3 Operating System 36

19.4 Reception 36

19.5 Display Type 36

19.6 Display Input Resolution 36

19.7 Connectivity 37

19.8 Sound 37

19.9 Multimedia 37

20 Help and Support 38

20.1 Register your TV 38

20.2 Troubleshooting 38

20.3 Online Help 40

20.4 Support and Repair 40

21 Safety and Care 41

21.1 Safety 41

21.2 Screen Care 42

22 Terms of Use 43
23 Copyrights 44

23.1 HDMI 44

23.2 Dolby Audio 44

23.3 Dolby Vision and Dolby Atmos 44

23.4 DTS-HD 44

23.5 Wi-Fi Alliance 44

23.6 Kensington 44

23.7 Other Trademarks 45

24 Disclaimer 46
Index 47

2

1

Home Screen

This channel contains your Recommended,
Subscriptions or Trending YouTube videos.

Customize channels

1.1

Home Screen and Channels

The Home launcher

To enjoy the benefits of your Android TV, connect the
TV to the Internet. Press Home on your remote
control to get your new Android Home screen. Like on
your Android smartphone or tablet, the Home screen
is the centre of your TV. From here you can decide
what to watch by browsing entertainment options
from app and live TV. Your Home has channels to let
you discover great contents from your favourite apps.
You can also add additional channels or find new
apps to get more contents.

The Home screen is organized in channels. Apps may
populate their recommendation (if available)
according to their own choice as an individual
channels in the home screen.

Apps

Your favourite Apps are placed on the first row. This
row contains number of apps pre-installed. The order
of these apps are according to business agreements
with content service providers. You can also add more
apps as favourite from the Apps page, such as the
Live TV and MMP (MultiMediaPlayer). The Apps page
can be opened by clicking the Apps icon at the left
end of the Apps row.

Live TV

The Live TV row shows the currently running
programmes from the installed channels. It contains
up to 10 channels as the recommendation for you to
select the TV channels. The first channel on Live TV
row is the channel you are watching, and the
following channels will be the channels on your
favourite list*.
* Note: If there are still more spaces available on Live
TV row, it will include the channels from your DTV
(digital TV) source.

Play Next channel
You can always know what to watch next from Play

Next channel on the Home screen. Start watching

from where you left off and get notifications about
new episodes in the Play Next channel. Press and
hold Select on a movie or TV show to add it directly
to the Play Next channel.

Google Play Movies & TV channel

Rent movies or TV shows on this channel from
Google Play Movies & TV.

Click the Customize channels button to add and
remove channels from your Home screen.

See also www.support.google.com/androidtv

Accessing settings from Home

You can access Settings menu via the icon at the top
right corner.

Accessing USB flash drive from Home

To view the files from the USB flash drive, you need
to add the MMP (MultiMediaPlayer) app to the Home
page first. Press Home, clicking the Apps icon at the
left end of the Apps row. You can add MMP apps
from the Apps page.

System bar on Home screen

The System bar on the top of Home screen contains
following features.

- Search button: to trigger Google search with voice*
or text input. The search result and its order are
rendered according to business agreements with
content service providers.

- Notifications: to provide you the messages about
your Smart TV system.

- Input source: to launch the input source list and
switch to any of the connected devices.

- Settings: to access all setting menu and adjust the
TV settings.

- Clock: to indicate the system clock.
* Note: In order to take advantage of Google Assistant

in case of a remote control without microphone,
please use the Android TV Remote Control app
available in Google Play Store for Android and Apple
App store for iOS devices.

1.2

Open the Home Screen

To open the Home screen and open an item…

1 - Press Home.
2 - Select an item and press OK to open or start it.
3 - Press Back continuously or press Home can

go back to Home screen.
When opening the Home screen, the background

application/content playback will stop. You have to
select the application or content from the Home
screen to resume.

YouTube channel

3

2

Setting Up

TP Vision Europe B.V. bears no responsibility for
improper mounting or any mounting that results in
accident or injury.

2.1

Read Safety

Read the safety instructions first before you use the
TV.

2.2

TV Stand and Wall Mounting

TV Stand

You can find the instructions for mounting the TV
stand in the Quick Start Guide that came with the TV.
In case you lost this guide, you can download it
from www.philips.com/TVsupport.

Use the model number of the TV to look for
the Quick Start Guide to download.

Wall Mounting

Your TV is also prepared for a VESA-compliant wall
mount bracket (sold separately).
Use the following VESA code when purchasing the
wall mount . . .

2.3

Tips on Placement

• Position the TV where light does not shine directly
on the screen.

• The ideal distance to watch TV is 2 to 5 times its
diagonal screen size. When seated, your eyes should
be level with the centre of the screen.

• When wall mounted, position the TV up to 15 cm
away from the wall.

Note:
Please keep the TV away from dust-producing

sources such as stoves. It is suggested to clean the
dust regularly to avoid getting dust into the TV.

2.4

• 43PUD81x5

VESA MIS-F 100x200, M6 (Min.: 10mm, Max.: 12mm)

• 50PUD81x5

VESA MIS-F 200x200, M6 (Min.: 18mm, Max.:
22mm)

• 55PUD81x5

VESA MIS-F 200x200, M6 (Min.: 14mm, Max.: 16mm)

• 65PUD81x5

VESA MIS-F 300x300, M6 (Min.: 20mm, Max.:
24mm)

Caution

Wall mounting the TV requires special skills and
should only be performed by qualified personnel. The
TV wall mounting should meet safety standards
according to the TVs weight. Also read the safety
precautions before positioning the TV.

Power Cable

• Insert the power cable into the POWER connector
on the back of the TV.

• Make sure the power cable is securely inserted in
the connector.

• Make sure that the power plug, in the wall socket, is
accessible at all times.

• When you unplug the power cable, always pull the
plug, never pull the cable.

Although this TV has a very low standby power
consumption, unplug the power cable to save energy
if you do not use the TV for a long period of time.

4

2.5

Antenna Cable

Insert the antenna plug firmly into
the Antenna socket at the back of the TV.

You can connect your own antenna or an antenna
signal from an antenna distribution system. Use an
IEC Coax 75 Ohm RF antenna connector.

Use this antenna connection for DTMB input signals.

5

3

Remote Control

3.1

1 - OK key
To confirm a selection or setting. To open the channel
list while watching TV.

2 - Navigation keys
To navigate up, down, left or right.

Key Overview

Top

1 - Power (Standby / On)

To switch the TV on or back to Standby.

2 - Voice microphone
3 - MENU

To open the Quick Menu with typical TV functions.
4 - AD / INFO

• Short press to access the Audio type.

• Long press to open programme information.

3 - Back

• To return to previous menu or TV source.

• To go back to the previous App.
4 - Playback and Record

• Play, to playback.

• Pause, to pause playback

• Stop, to stop playback

• Rewind, to rewind

• Fast forward, to go fast forward

• Record, to start recording
5 - EXIT

To leave from current menu or App.
6 - Home

To open the Home menu.
7 - Colour keys

Follow the on-screen instructions to select more
options or operations.
Press Blue key on Home screen to open the Help.

Bottom

5 - SOURCES / PAIR

• To open or close the Sources menu.

• To pair the remote control to the TV.
6 - Google Assistant™

• To launch the Google Assistant™.

• While Google Assistant™ is not supported, press to
start voice search.

* Note: Google Assistant™ is only available in
selected countries.

Middle

1 - NETFLIX

To open the Netflix App directly. With the TV switched
on or from standby.

• If you have a Netflix membership subscription, you
can enjoy Netflix on this TV. Your TV must be
connected to the Internet.

• To open Netflix, press NETFLIX to open the Netflix
App. You can open Netflix immediately from a TV in
standby.
www.netflix.com

2 - Mute / Volume
Press in middle to mute the sound or to restore it.
Press + or - to adjust the volume level.

3 - Number keys

6

To select a channel directly.
4 - TEXT

Not support.
5 - TV GUIDE / Channel

• Press in middle to open or close TV Guide.

• Press + or - to switch to the next or previous
channel in the channel list. To open the next or
previous page in Text/Teletext.

6 - Amazon Prime Video
To launch the Amazon Prime Video App.

7 - YouTube
To open the YouTube App directly.

8 - SUBTITLE
To open Subtitle page.

3.2

IR Sensor

The TV can receive commands from a remote control
that uses IR (infrared) to send commands. If you use
such a remote control, always make sure you point
the remote control at the infrared sensor on the front
of the TV.

3.4

Cleaning

Your remote control is treated with a scratch-resistant
coating.

To clean the remote control, use a soft damp cloth.
Never use substances such as alcohol, chemicals or
household cleaners on the remote control.

Warning

Do not put any objects in front of IR sensor of the TV,
it may block the IR signal.

3.3

Batteries

If the TV does not react on a key press on the remote
control, the batteries might be empty.

To replace the batteries, open the battery
compartment on the back-bottom of the remote
control.

1 - Slide the battery door in the direction shown by
the arrow.
2 - Replace the old batteries with 2 type AAA-1.5V
batteries. Make sure the + and the - ends of the
batteries line up correctly.
3 - Reposition the battery door and slide it back until
it clicks.

Remove the batteries if you are not using the remote
control for a long time.
Safely dispose of your old batteries according to the
end of use directions.

For more information, in Help, select Keywords and
look up End of use.

7

4

Switching On and
Off

Make sure the TV is connected to the mains AC
power. The indicator light at the bottom of the TV
lights up.

Switch on

Press Power on the remote control to switch the TV
on. You can also press the small joystick key on the
bottom of the TV to switch the TV on in case you can't
find the remote control or its batteries are empty.

Switch to standby

To switch the TV to standby, press Power on the
remote control. You can also press the small joystick
key on the bottom of the TV.

In standby mode, the TV is still connected to the
mains power but consumes very little energy.

To switch off the TV completely, disconnect the
power plug.
When disconnecting the power plug, always pull the
power plug, never the cord. Ensure that you have full
access to the power plug, power cord and outlet
socket at all times.

8

5

Search for a Channel

Channels

5.1

About Channels and Switch
Channels

To watch TV channels

• Press SOURCES and select TV source to watch TV.

• Press Home > Live TV and press OK.

• Press Channel + or Channel - to switch channels.

• If you know the channel number, type in the number
with the number keys. Press OK after you entered
the number to switch channels.

To switch to a channel from a channel list

• While watching a TV channel, press OK to open the
channel lists.

• The channel list can have several pages with
channels. To view the next or previous page, follow
the on-screen instruction.

• To close the channel lists without switching
channels, press Back.

TV may not work properly with some operators of
digital television , non-compliance with requirements
of the standard in full.

You can search for a channel to find it in a long list of
channels.

To search for a channel…

1 - Press OK to open the current channel list.
2 - Press Yellow key for Select More.
3 - Select Operation > Find and press OK to open

a text field. You can use the remote control keyboard
(if available) or the on-screen keyboard to enter text.
4 - Enter a number, a name or part of a name and
press OK. The TV will search for matching channel
names in the list you selected.

Search results are listed as a channel list - see the list
name at the top. The search will return the matching
channel name with the result arranged in alphabetical
order. The search results disappear once you select
another channel list or close the list with search
results.

Channel List sorting

You can do channel list sorting with all channels. You
can set the channel list to show only TV channels or
only Radio stations. For Antenna channels you can
set the list to show the Free-to-Air or the Scrambled
channels.

5.2

Channel Lists

About Channel Lists

After a channel installation, channels appear on the
channel list. The channels displayed in All Channel list
is listed based on TV source. Channels are shown with
their name if this information is available.

With a channel list selected, press Navigation keys
up or down to select a channel, then press OK to
watch the selected channel.

TV may not work properly with some operators of
digital television , non-compliance with requirements
of the standard in full.

Open a Channel List

Next to the list with all channels, you can select a
filtered list or you can select one of the favourite lists
you created.

To open the current channel list…

1 - While watching TV, press OK to open the current
channel list.

2 - Press Back to close the channel list.

To set a filter on a list with all channels…

1 - Press OK to open the current channel list.
2 - Press Yellow key for Select More.
3 - Select Operation > Sort and press OK.
4 - Select the filter you want and press OK to

activate. The name of the filter appears as part of the
channel list name on top of the channel list.
5 - Press Back to close the channel list.

5.3

Watching channels

Tune to a Channel

To start watching TV channels, press SOURCES and
select the TV input. The TV tunes to the channel you
last watched.

Alternatively, you can select Live TV from the Home
screen.

Switch Channels

To switch channels, press Channel + or Channel -.
If you know the channel number, type in the number
with the number keys. Press OK after you entered
the number to switch immediately.

You can also tune to channels from a Channel List

9

by pressing OK.

5.4

Favourite Channels

Parental Controls

Lock and Unlock a Channel

To prevent children from watching a channel, you can
lock a channel. To watch a locked channel, you must
enter the 4 digit PIN code first. You cannot lock
programmes from connected devices.

To lock or unlock a channel…
1 - Press MENU > Settings > Channel > Parental
Controls and press OK.

2 - Enter your PIN code if necessary.
3 - Select Channels blocked and press OK.
4 - Press Navigation keys up or down to select the

channel you want to lock or unlock, and press OK.

5 - A locked channel is marked with a lock icon.
6 - Press Back, repeatedly if necessary, to close the

menu.
* Note: if you forgot your PIN code, you can override

the current one by using the code 8888 and entering
a new one.

Inputs Blocked

To prevent from using connected devices, you can
lock an input source. To connect a locked input
source, you must enter the 4 digit PIN code first.

To lock or unlock an input source…
1 - Press MENU > Settings > Channel > Parental
Controls and press OK.

2 - Enter your PIN code if necessary.
3 - Select Inputs blocked and press OK.
4 - Press Navigation keys up or down to select the

source you want to lock or unlock, and press OK.

5 - A locked source is marked with a lock icon.
6 - Press Back, repeatedly if necessary, to close the

menu.

About Favourite Channels

In a favourite channel list, you can collect the
channels you like.

You can create 4 different lists of favourite channels
for easy channel zapping.

With a Favourites List selected, press the Navigation
keys up or down to select a channel, then
press OK to watch the selected channel.

Edit a Favourites List

To add a channel to the favourite list…

1 - While watching TV, press OK to open the current
channel list.
2 - Press Navigation keys up or down to select a
channel.
3 - Press Blue key to add the channel to a
favourites list (default list is Favourtites1). Press Blue
key again will remove the channel from the favourite
list.

4 - Press Back to close the menu.

To create a favourite channels list…

1 - While watching TV, press OK to open the current
channel list.

2 - Press Yellow key for Select More.
3 - Select Select Type > Favourites and then press

Navigation keys up or down to select a list of
Favourites1* to Favourites4 that you want to add.
4 - Press Yellow key for Select More and then select
Select Type to change the channel list to your

preferred list.
5 - Press Blue key to add the channel to the
favourites list you just selected. Press Blue key again
will remove the channel from the favourite list.

6 - Press Back to close the menu.

Change PIN

Set new or reset PIN code. The PIN code is used to
lock or unlock channels or programmes.

1 - Press MENU > Settings > Channel > Parental
Controls and press OK.

2 - Enter your PIN code if necessary.
3 - Select Change PIN and press OK.
4 - Enter the current PIN code and new PIN code.
5 - Press Back, repeatedly if necessary, to close the

menu.

To move or remove a channel from the favourites
list…

1 - Select a list of Favourites1 to Favourites4 you
want to edit.

2 - Press Yellow key for Select More.
3 - Select Operation > Move to move the channel

positions on the favourite channel list.
4 - Select Operation > Delete to remove the
channels from the favourite channel list.
5 - Press Back, repeatedly if necessary, to close the
menu.

10

6

Channel Installation

6.1

Channel update

While watching a TV channel, you can perform the
channel scan by...

1 - Press MENU > Navigation Keys up
> Channels > New Channels Available and
press OK.

2 - Follow the on-screen instructions and press OK.
3 - Select Done and press OK to close.

6.2

Manual Channel Update

You can always start a channel update yourself.
To start a channel update manually…
1 - While watching TV, press MENU > TV options

> Settings > Channel > Channels and select one of
below options.
Channel Scan - this kind of scan will auto install
digital channels and analogue channels.
Updte Scan - refers to an incremental scan, which
only scans the frequencies that Channel Scan has not
scanned.
Single RF Scan - is digital manual scan, this allow user
to scan specific frequency by pressing left or right
Navigation Key on the RF Channel item.

2 - Enter your PIN code if necessary.
3 - This can take a few minutes.
4 - Press Back, repeatedly if necessary, to close the

menu.

6.3

Reception Quality

You can check the quality and signal strength of a
digital channel. If you have your own antenna, you
can reposition the antenna to try and improve the
reception.

To check the reception quality of a digital channel…
1 - While watching TV, press MENU > TV
options > Settings > Channel >
Channels > Single RF Scan and press OK.

2 - Select RF Channel.
3 - Press Navigation keys left or right to select a

channel and press OK. The signal level and signal
quality is shown for this channel.
4 - Press Back, repeatedly if necessary, to close the
menu.

11

7

Connect Devices

7.1

About Connections

Connectivity Guide

Always connect a device to the TV with the highest
quality connection available. Also, use good quality
cables to ensure a good transfer of picture and
sound.

When you connect a device, the TV recognizes its
type and gives each device a correct type name. You
can change the type name if you wish. If a correct
type name for a device is set, the TV automatically
switches to the ideal TV settings when you switch to
this device in the Sources menu.

HDMI ports support HDCP 2.2 (High-bandwidth
Digital Content Protection). HDCP is a copy protection
signal that prevents copying content from a DVD disc
or Blu-ray Disc. Also referred to as DRM (Digital
Rights Management).

HDMI ARC

Only HDMI 1 connection on the TV has HDMI
ARC (Audio Return Channel).

If the device, typically a Home Theatre System (HTS),
also has the HDMI ARC connection, connect it to
HDMI 1 on this TV. With the HDMI ARC connection,
you do not need to connect the extra audio cable
that sends the sound of the TV picture to the HTS.
The HDMI ARC connection combines both signals.

Antenna port

If you have a Set-top box (a digital receiver) or
Recorder, connect the antenna cables to run the
antenna signal through the Set-top box and/or
Recorder first before it enters the TV. In this way, the
antenna and the Set-top box can send possible
additional channels to the Recorder to record.

HDMI ports

HDMI Quality

An HDMI connection has the best picture and sound
quality. One HDMI cable combines video and audio
signals. Use an HDMI cable for High Definition (HD)
TV signals.

For best signal quality transfer, use a High speed
HDMI cable and do not use an HDMI cable longer
than 5 m.

HDMI CEC

Connect HDMI CEC-compatible devices to your TV,
you can operate them with the TV remote control.

Copy protection

HDMI CEC (Consumer Electronic Control) must be
switched on on the TV and the connected device.

Switch on CEC

Allow the TV to control HDMI device.

MENU > TV options > Settings > Device
Preferences > Inputs > HDMI control.

Device auto power off

Turn off the HDMI devices with the TV.

12

MENU > TV options > Settings > Device
Preferences > Inputs > Device auto power off.

TV auto power on

Power on the TV with HDMI devices.

MENU > TV options > Settings > Device
Preferences > Inputs > TV auto power on.

HDMI EDID Version

Check the HDMI EDID version number.

MENU > TV options > Settings > Device
Preferences > Inputs > HDMI EDID Version.

CEC Device List

Check the connected HDMI CEC device list.

Audio to video synchronisation (sync)

If the sound does not match the video on screen, you
can set a delay on most Home Theatre Systems with
a disc player to match the sound with the video.

Connect with HDMI

MENU > TV options > Settings > Device
Preferences > Inputs > CEC device list.

Note:

• HDMI CEC might not work with devices from other
brands.

• The HDMI CEC functionality has different names on
different brands. Some examples are: Anynet, Aquos
Link, Bravia Theatre Sync, Kuro Link, Simplink and
Viera Link. Not all brands are fully compatible with
EasyLink. Example HDMI CEC branding names are
property of their respective owners.

7.2

Home Theatre System - HTS

Connect with HDMI ARC

Use an HDMI cable to connect a Home Theatre
System (HTS) to the TV. You can connect a Philips
Soundbar or an HTS with a built-in disc player.

HDMI ARC

If your Home Theatre System has an HDMI ARC
connection, you can use HDMI ARC connection on
the TV to connect. With HDMI ARC, you do not need
to connect the extra audio cable. The HDMI ARC
connection combines both signals.
Since HDMI 1 on the TV can offer the Audio Return
Channel (ARC) signal, the TV can only send the ARC
signal to this HDMI connection.

Use an HDMI cable to connect a Home Theatre
System (HTS) to the TV. You can connect a Philips
Soundbar or an HTS with a built-in disc player.

If the Home Theatre System has no HDMI ARC
connection, add an optical audio cable to send the
sound of the TV picture to the Home Theatre System.

Audio to video synchronisation (sync)

If the sound does not match the video on screen, you
can set a delay on most Home Theatre Systems with
a disc player to match the sound with the video.

13

7.3

Video Device

HDMI

Use a High speed HDMI cable to connect with best
picture and sound quality.

For best signal quality transfer, use a High speed
HDMI cable and do not use an HDMI cable longer
than 5 m, and also connect devices supporting HDR
on any one of HDMI connections.

Headphones

You can connect a set of headphones to the
headphone connector on the back of the TV. The
connection is a mini-jack 3.5mm.

* Note: TV Speakers will be muted when the
Headphones are plugged in.

Copy protection

HDMI ports support HDCP (High-bandwidth Digital
Content Protection). HDCP is a copy protection signal
that prevents copying content from a DVD disc or Blu­ray Disc. Also referred to as DRM (Digital Rights
Management).

7.4

Audio Device

Digital Audio Out - Optical

Audio Out - Optical is a high quality sound
connection.

This optical connection can carry 5.1 audio channels.
If your device, typically a Home Theatre System
(HTS), has no HDMI ARC connection, you can use this
connection with the Audio In - Optical connection on
the HTS. The Audio Out - Optical connection sends
the sound from the TV to the HTS.

7.5

USB Hard Drive

Installation

Before you can pause or record a broadcast, you
must connect and format a USB Hard Drive.
Formatting removes all files from the USB Hard Drive.

1 - Connect the USB Hard Drive to one of
the USB connections on the TV. Do not connect
another USB device to the other USB ports when
formatting.

2 - Switch on the USB Hard Drive and the TV.
3 - When the TV is tuned to a digital TV channel,

press Pause. Trying to pause will start the formatting.
Follow the instructions on screen.
When the USB Hard Drive is formatted, leave it

connected permanently.

14

Warning

shift…

1 - Once the formatting is done, you can assign the
storage device for PVR or Time shift functions.
2 - Press MENU while watching TV, then
press Navigation keys down to Record > Device info.
3 - Select the device you want to assign and press
OK.
4 - Select Set timeshift to assign the device for Time
shift data storage. The device will be marked with
TSHIFT on Device info list.
5 - Select Set PVR to assign the device for recording
data storage. The device will be marked with PVR on
Device info list.

The USB Hard Drive is formatted exclusively for this
TV, you cannot use the stored recordings on another
TV or PC. Do not copy or change recording files on
the USB Hard Drive with any PC application. This will
corrupt your recordings. When you format another
USB Hard Drive, the content on the former will be lost.
A USB Hard Drive installed on your TV will need
reformatting for use with a computer.

Formatting

Before you can pause or record a broadcast, or store
apps, you must connect and format a USB Hard
Drive*. Formatting removes all files from the USB Hard
Drive.

Warning

The USB Hard Drive is formatted exclusively for this
TV, you cannot use the stored recordings on another
TV or PC. Do not copy or change recording files on
the USB Hard Drive with any PC application. This will
corrupt your recordings.

* Connect the USB Hard Drive with size less than 2TB
and make sure the available space is more than 1
GB.

To format a USB Hard Drive…

1 - Connect the USB Hard Drive to one of the USB
connections on the TV. Do not connect another USB
device to the other USB ports when formatting.

2 - Switch on the USB Hard Drive and the TV.
3 - Press MENU while watching TV, then

press Navigation keys down to Record > Device info.
4 - Select the device you want to format and press
OK.
5 - Select Format to star the formatting. All files and
data will be removed after formatting.
6 - When the USB Hard Drive is formatted, suggest to
leave it connected permanently.

To assign the storage device for PVR and Time

7.6

USB Flash Drive

You can view photos or play your music and videos
from a connected USB flash drive.

Insert a USB flash drive in one of
the USB connections on the TV while the TV is
switched on.

To view the files from the USB flash drive, you need
to add the MMP (MultiMediaPlayer) app to the Home
screen first. Press Home, clicking the Apps icon at the
left end of the Apps row. You can add MMP apps
from the Apps page.

To stop watching the USB flash drive content,
press EXIT or select another activity. Exit the MMP
app before you disconnect the flash drive.

To remove the USB flash drive safely…

1 - Press Home.
2 - Select the Notifications icon from the top-right

corner and press OK.

3 - Select your flash drive and press OK.
4 - Select Eject and press OK.
5 - Wait until the eject procedure is finished and then

pull out the flash drive.

Ultra HD on USB

You can view photos in Ultra HD resolution from a
connected USB device or flash drive. The TV will
downscale the resolution if the resolution of the
photo is higher.

15
