Philips 50PUD7406/71, 65PUD7406/71, 55PUD7406/71 user manual

7406 Series

User Manual

50PUD7406

55PUD7406

65PUD7406

Register your product and get support at

www.philips.com/TVsupport

Contents

1 Home Screen 4

1.1 Home Screen and Channels

1.2 Open the Home Screen

1.3 Home Screen Update

4
4
4

2 Setting Up 6

2.1 Read Safety

2.2 TV Stand and Wall Mounting

2.3 Tips on Placement

2.4 Power Cable

2.5 Antenna Cable

6
6
6
6
7

3 Remote Control 8

3.1 Key Overview (Type 2)

3.2 Pair Your Remote Control to the TV

3.3 Voice Search

3.4 IR Sensor

3.5 Batteries

3.6 Cleaning

8
9
9
9
10
10

4 Switching On and Off 11
5 Channel Installation 12

5.1 First Time to Install Channels

5.2 Antenna

5.3 Cable Installation

5.4 Channel Installation Options

12
12
12
12

6 Channels 14

6.1 About Channels and Switch Channels

6.2 Channel Lists

6.3 Watching channels

6.4 Favorite Channels

14
14
15
15

7 Connect Devices 17

7.1 About Connections

7.2 Home Theater System - HTS

7.3 Video Device

7.4 Audio Device

7.5 USB Hard Drive

7.6 USB Flash Drive

7.7 Computer

17
18
18
18
19
20
20

8 Bluetooth 21

8.1 What You Need

8.2 Pairing a Device

8.3 Select a Device

8.4 Rename a Device

8.5 Remove a Device

21
21
21
21
21

9 Connect your Android TV 23

9.1 Network and Internet

9.2 Google Account

23
24

10 Apps 25

10.1 About Apps

10.2 Google Play

10.3 Start or Stop an App

25
25
26

10.4 Manage Apps

26

11 Sources 27

11.1 Switch to a device

27

12 Settings 28

12.1 TV Options

12.2 Picture Settings

12.3 Sound Settings

12.4 Power Settings

12.5 Advanced Options

12.6 Other settings

12.7 Reboot

12.8 Factory Reset

12.9 Clock and Language Settings

12.10 Accessibility Settings

28
28
29
30
30
30
32
32
32
33

13 Videos, Photos, Music & Text 34

13.1 From a USB Connection

13.2 Play your Videos

13.3 View your Photos

13.4 Play your Music

13.5 View your Text

34
34
34
35
35

14 TV guide 36

14.1 TV Guide Data

14.2 Using the TV Guide

36
36

15 Recording and Time Shift 37

15.1 Record Options

15.2 Recording

15.3 Time Shift

37
37
38

16 Smartphones and Tablets 39

16.1 Google Cast

39

17 Netflix 40
18 Software 41

18.1 Update Software

18.2 Software Version

18.3 Open Source Licenses

41
41
41

19 Specifications 42

19.1 Environmental

19.2 Power

19.3 Operating System

19.4 Reception

19.5 Display Type

19.6 Display Input Resolution

19.7 Connectivity

19.8 Sound

19.9 Multimedia

42
42
42
42
42
42
43
43
43

20 Help and Support 44

20.1 Register your TV

20.2 Troubleshooting

20.3 Online Help

20.4 Support and Repair

44
44
46
46

2

21 Safety and Care 47

21.1 Safety

21.2 Screen Care

47
48

22 Terms of Use 49
23 Copyrights 50

23.1 HDMI

23.2 Dolby Vision and Dolby Atmos

23.3 DTS-HD

23.4 Wi-Fi Alliance

23.5 Kensington

23.6 Other Trademarks

24 Disclaimer regarding services

50
50
50
50
50
50

51

and/or software offered by third
parties
Index 52

3

1

Home Screen

This channel contains your Recommended,
Subscriptions or Trending YouTube videos.

Customize channels

1.1

Home Screen and Channels

The Home launcher

To enjoy the benefits of your Android TV, connect the
TV to the Internet. Press Home on your remote
control to get your new Android Home screen. Like on
your Android smartphone or tablet, the Home screen
is the center of your TV. From here you can decide
what to watch by browsing entertainment options
from app and live TV. Your Home has channels to let
you discover great contents from your favorite apps.
You can also add additional channels or find new
apps to get more contents.

The Home screen is organized in channels. Apps may
populate their recommendation (if available)
according to their own choice as an individual
channels in the home screen.

Apps

Your favorite Apps are placed on the first row. This
row contains a number of pre-installed apps. The
order of these apps is according to business
agreements with content service providers. You can
also add more apps as favorite from the Apps page,
such as the Live TV and MMP (MultiMediaPlayer). The
Apps page can be opened by clicking the Apps icon
at the left end of the Apps row.

Live TV

The Live TV row shows the currently running
programs from the installed channels. It contains up
to 10 channels as the recommendation for you to
select the TV channels. The first channel on Live TV
row is the channel you are watching, and the
following channels will be the channels on your
favorites list*.
* Note: If there are still more spaces available on Live
TV row, it will include the channels from your DTV
(digital TV) source.

Play Next channel
You can always know what to watch next from Play

Next channel on the Home screen. Start watching

from where you left off and get notifications about
new episodes in the Play Next channel. Press and
hold Select on a movie or TV show to add it directly
to the Play Next channel.

Google Play Movies & TV channel

Rent movies or TV shows on this channel from
Google Play Movies & TV.

Click the Customize channels button to add and
remove channels from your Home screen.

See also www.support.google.com/androidtv

Accessing settings from Home

You can access the Settings menu via the icon at the
top right corner.

Accessing USB flash drive from Home

To view the files from the USB flash drive, you need
to add the MMP (MultiMediaPlayer) app to the Home
page first. Press Home, clicking the Apps icon at the
left end of the Apps row. You can add MMP apps
from the Apps page.

System bar on Home screen

The System bar on the top of Home screen contains
the following features.

- Search button: to trigger Google search with voice*
or text input. The search result and its order are
rendered according to business agreements with
content service providers.

- Notifications: to provide you the messages about
your Smart TV system.

- Input source: to launch the input source list and
switch to any of the connected devices.

- Settings: to access all setting menu and adjust the
TV settings.

- Clock: to indicate the system clock.
* Note: In order to take advantage of Google Assistant

in case of a remote control without a microphone,
please use the Android TV Remote Control app
available in the Google Play Store for Android and
Apple App store for iOS devices.

1.2

Open the Home Screen

To open the Home screen and open an item…

1 - Press Home.
2 - Select an item and press OK to open or start it.
3 - Press Back continuously or press Home to go

back to Home screen.
When opening the Home screen, the background

application/content playback will stop. You have to
select the application or content from the Home
screen to resume.

YouTube channel

4

1.3

Home Screen Update

You may receive the update notification from Google
and have a new version of Home launcher installed.
With the new Home launcher, you will have a new
look and features on your TV’s Home screen.

New highlights on your home screen
With multiple tabs like Home, Discover, Apps and

Search, you can discover movies and shows from

your services and popular apps. Sign in to your
Google Account to get personalized
recommendations from your streaming services
based on what you have watched and what interests
you.

New look, new navigation

Decide what to watch next with easy-to-use
navigation. Browse your personalized
recommendations, pick up where you left off, or
quickly find a certain app using the new tab system.

Discover personalized recommendations

Browse shows and movies that you will love on all
your favorite media services. Sign in to your Google
Account to get started.

Get recommendations across Google

Your services are saved to your Google Account so
you can get better recommendations across Google.

5

2

Setting Up

2.1

Read Safety

Read the safety instructions first before you use the
TV.

To read the safety instructions, go to Safety and Care
section on this Help manual for the information.

2.2

TV Stand and Wall Mounting

TV Stand

You can find the instructions for mounting the TV
stand in the Quick Start Guide that came with the TV.
In case you lose this guide, you can download it
from www.philips.com/TVsupport.

Wall mounting the TV requires special skills and
should only be performed by qualified personnel. The
TV wall mounting should meet safety standards
according to the TVs weight. Also read the safety
precautions before positioning the TV.
TP Vision Europe B.V. bears no responsibility for
improper mounting or any mounting that results in
accident or injury.

2.3

Tips on Placement

• Position the TV where light does not shine directly
on the screen.

• The ideal distance to watch TV is 2 to 5 times its
diagonal screen size. When seated, your eyes should
be level with the center of the screen.

• When wall mounted, position the TV up to 6 inches
away from the wall.

Use the model number of the TV to look for
the Quick Start Guide to download.

Wall Mounting

Your TV is also prepared for a VESA-compliant wall
mount bracket (sold separately).
Use the following VESA code when purchasing the
wall mount . . .

• 43PUx7406

VESA MIS-F 100x200, M6 (Min.: 10mm, Max.: 12mm)

• 50PUx7406

VESA MIS-F 200x200, M6 (Min.: 18mm, Max.:
22mm)

• 55PUx7406

VESA MIS-F 200x200, M6 (Min.: 14mm, Max.: 16mm)

• 65PUx7406

VESA MIS-F 300x300, M6 (Min.: 18mm, Max.:
22mm)

• 70PUx7406

VESA MIS-F 300x300, M8 (Min.: 10mm, Max.: 22mm)
Caution

Note:

Please keep the TV away from dust-producing
sources such as stoves. It is suggested to clean the
dust regularly to avoid getting dust into the TV.

2.4

Power Cable

• Insert the power cable into the POWER connector
on the back of the TV.

• Make sure the power cable is securely inserted in
the connector.

• Make sure that the power plug, in the wall socket, is
accessible at all times.

• When you unplug the power cable, always pull the
plug, never pull the cable

6

Although this TV has a very low standby power
consumption, unplug the power cable to save energy
if you do not use the TV for a long period of time.

2.5

Antenna Cable

Insert the antenna plug firmly into
the Antenna socket at the back of the TV.

You can connect your own antenna or an antenna
signal from an antenna distribution system. Use an
IEC Coax 75 Ohm RF antenna connector.

Use this antenna connection for antenna digital or
analog input signals.

7

3

Remote Control

3.1

• To pair the remote control to the TV.
10 - Google Assistant™

To launch the Google Assistant™.

Key Overview (Type 2)

Top

1 - Power (Standby / On)

To switch the TV on or back to Standby.

2 - VOICE microphone
3 - MENU

To open the TV Menu with typical TV functions.
4 - Amazon Prime Video

To launch the Amazon Prime Video App.
5 - NETFLIX

To launch the Netflix App with the TV switched on or
from standby.

• If you have a Netflix subscription, you can enjoy
Netflix on this TV. Your TV must be connected to the
Internet.

• To open Netflix, press the NETFLIX key to open the
Netflix App. You can open Netflix immediately from a
TV in standby.

6 - INFO
Press to open the program information screen. Press
once to show brief channel information, press again
to show expanded screen with program title and
more information, press again to show full program
information. Keep pressing the key can switch to
different views of the information.

7 - Google Play
To launch the Google Play App.

Middle

1 - OK key

To confirm a selection or setting. To open the channel
list while watching TV.

2 - Back

• To return to previous menu or TV source.

• To go back to the previous App.
3 - Playback and Record

• Play, to playback.

• Pause, to pause playback

• Stop, to stop playback

• Rewind, to rewind

• Fast forward, to go fast forward

• Record, to start recording
4 - Color keys

Follow the on-screen instructions to select more
options or operations.
Press Blue key on Home screen to open the Help.

5 - Navigation keys
To navigate up, down, left or right.

6 - Home
To open the Home menu.

7 - TV GUIDE
To open or close the TV Guide.

8 - YouTube
To launch the YouTube App.

9 - SOURCES / PAIR

• To open or close the Sources menu.

8

Bottom

1 - EXIT

To leave from current menu or App.
2 - Volume

Press + or - to adjust the volume level.
3 - Number keys

To select a channel directly.
4 - (Dot)

To enter digital sub-channels.
5 - Channel

Press + or - to switch to the next or previous
channel in the channel list.

6 - Mute
Press to mute the sound or to restore it.

7 - CC
To enable/disable Closed Caption, or to show it on
mute.

3.2

Pair Your Remote Control to the TV

This remote control uses both Bluetooth and IR
(infrared) to send its commands to the TV.

• You can use this remote control via IR (infrared) for
most operations.

• To use advanced operation like voice search and
remote control keyboard, you need to pair (link) the
TV with the remote control.

When you start the initial TV installation, the TV
invites you to long press the PAIR key until you see
the light pulsing on the remote. By doing so, the
pairing will be done.

2 - The remote control must be kept close to the TV
(within 3 feet) during pairing in order to ensure
success.
3 - If the TV does not launch the voice control
field when you press Google Assistant™, pairing was
unsuccessful.
4 - It is advisable to wait until the set has fully started
up and launched all background processes before
pairing mode is entered as the toast message
containing further instructions may appear too late,
thereby negatively impacting the pairing procedure.

Pairing again

If the pairing with the remote control was lost, you
can pair the TV with the remote control again. Press
the PAIR key until you see the light pulsing on the
remote for pairing.

Unpair

Press and hold 0 and Mute key on the remote
control until you see the light pulsing on the remote.

3.3

Voice Search

You can search for videos, music or anything else on
the Internet by simply using your voice. You can
speak into the microphone on the remote control.

You need to pair the remote control to the TV before
use voice search.

To use Voice...
1 - Press Google Assistant™ on remote control, the

blue light on the remote control lights up and the
search field opens, the microphone is active.
2 - Speak out what you are looking for with clear
pronunciation. You can speak for 10 seconds before
the microphone switches off. It might take some time
for the results to appear.
3 - In the list of search results, you can select the
item you want.

3.4

IR Sensor

The TV can receive commands from a remote control
that uses IR (infrared) to send commands. If you use
such a remote control, always make sure you point
the remote control at the infrared sensor on the front
of the TV.

Note:

1 - Once the remote control has entered pairing
mode successfully, the blue LED indicator ring around
the microphone on the front side of the remote
control starts blinking.

9

Warning

Do not put any objects in front of IR sensor of the TV
as it may block the IR signal.

3.5

Batteries

If the TV does not react on a key press on the remote
control, the batteries might be empty.

To replace the batteries, open the battery
compartment on the back-bottom of the remote
control.

1 - Slide the battery door in the direction shown by
the arrow.
2 - Replace the old batteries with 2 type AAA-1.5V
batteries. Make sure the + and the - ends of the
batteries line up correctly.
3 - Reposition the battery door and slide it back until
it clicks.

Remove the batteries if you are not using the remote
control for a long time.
Safely dispose of your old batteries according to the
end of use directions.

For more information, in Help, select Keywords and
look up End of use.

3.6

Cleaning

Your remote control is treated with a scratch-resistant
coating.

To clean the remote control, use a soft damp cloth.
Never use substances such as alcohol, chemicals or
household cleaners on the remote control.

10

4

Switching On and Off

Make sure the TV is connected to the mains AC
power. The indicator light at the bottom of the TV
lights up.

Switch on

Press Power on the remote control to turn the TV
on. You can also press the small joystick key on the
bottom of the TV to turn the TV on in case you can't
find the remote control or its batteries are dead.

Switch to standby

To turn the TV to standby, press Power on the
remote control. You can also press the small joystick
key on the bottom of the TV.

In standby mode, the TV is still connected to the
mains power but consumes very little energy.

To switch off the TV completely, disconnect the
power plug.
When disconnecting the power plug, always pull the
power plug, never the cord. Ensure that you have full
access to the power plug, power cord and outlet
socket at all times.

11

5

5.3

Channel Installation

5.1

First Time to Install Channels

Install channels during the first TV installation

On the first TV installation, you can follow on-screen
instructions to set the menu language, network
connection, sign in Google account, select your
country and complete other basic settings for the TV.
Moreover, you can also install channels during the
first TV installation.

To install channels during the first TV installation…
1 - The first TV installation starts from Welcome

screen with language setting options, follow on­screen instruction to complete multiple TV settings
until the channel installation part.
2 - Select Antenna or Cable to install channels.
Select Skip to skip the channel installation.
3 - Follow on-screen instructions to complete one of
the channel installation types as your selection. You
can install other types of channel installation later
on MENU > TV options > Settings > Channel.

For more details about Antenna or Cable channel
installation, please refer to respective installation
instruction sections.

Cable Installation

Please note that before installing channels, you
should first change the Channel Installation Mode to
the one you want to install. For the Cable channel
installation, you need to change Channel Installation
Mode to Cable first and then start the installation.

To install Cable channels…

1 - Press Home > Settings > Channel > Channel
Installation Mode and press OK.

2 - Select Cable and then go back to Channel.
3 - Select Channels > Channel Scan or Update

Scan , then press OK.

Alternatively, while watching a TV channel, you can
perform the channel scan by...

MENU > Navigation Keys up > Channels >
Channel

5.4

Channel Installation Options

Channel Skip

You can skip the channels you do not want to watch.

5.2

Antenna

Antenna Installation

Please note that before installing channels, you
should first change the Channel Installation Mode to
the one you want to install. For the Antenna channel
installation, you need to change Channel Installation
Mode to Antenna first and then start the installation.

To install Antenna channels…

1 - Press Home > Settings > Channel > Channel
Installation Mode and press OK.

2 - Select Antenna and then go back to Channel.
3 - Select Channels > Channel Scan and

press OK.

Alternatively, while watching a TV channel, you can
perform the channel scan by...

MENU > Navigation Keys up
> Channels > Channel

To set the skipped channels ...
1 - While watching TV, press MENU > TV
options > Settings > Channel > Channels and
press OK.

2 - Select Channel Skip* and press OK.
3 - Select the channels you want to skip and

press OK. The check mark is shown.
4 - Press Back, repeatedly if necessary, to close the
menu.

* Note: You cannot skip the current watching channel.

Channel Edit

You can edit the channels from the channel list.

To edit the channels ...
1 - While watching TV, press MENU > TV
options > Settings > Channel > Channels and
press OK.

2 - Select Channel Edit and press OK.
3 - Use the Navigation keys to select the channel

and press Yellow key for Select.

4 - Edit the channel number* and channel name.
5 - Press Back, repeatedly if necessary, to close the

menu.

12

* Note: Depending on your installation country or
operator setting, channel number editing is not
always available.

13

6

Open a Channel List

Channels

6.1

About Channels and Switch Channels

To watch TV channels

• Press SOURCES and select TV to watch channels.

• Alternatively, you can Press Home > Live TV and
press OK to watch TV channels. If Live TV is not on
your Apps row, you can press + icon on the end of the
row to add the app.

To change TV channels

• Press Channel + or Channel - to switch channels.

• If you know the channel number, type in the number
with the number keys. Press OK after you entered
the number to change channels.

To change to a channel from a channel list

• While watching a TV channel, press OK to open the
channel lists. The channel list only includes the
channels from current broadcast source.

• To view a different channel list from another
broadcast source, press MENU > Navigation Keys up
> Channels > Channel > Channel Installation Mode
and select other broadcast source you want to watch
channels and view the channel list.

• The channel list can have several pages with
channels. To view the next or previous page, follow
the on-screen instruction.

• To close the channel lists without changing
channels, press Back.

6.2

Channel Lists

About Channel Lists

After a channel installation, channels appear on the
channel list. The channels displayed in All Channel list
is listed based on TV source. Channels are shown with
their name if this information is available.

With a channel list selected, press Navigation keys
up or down to select a channel, then press OK to
watch the selected channel.

Next to the list with all channels, you can select a
filtered list or you can select one of the favorite lists
you created.

To open the current channel list…

1 - While watching TV, press OK to open the current
channel list.
2 - The channel list only includes the channels from
current broadcast source.
3 - To view a different channel list from another
broadcast source, press MENU > Navigation Keys up
> Channels > Channel > Channel Installation Mode
and select other broadcast source you want to watch
channels and view the channel list.

4 - Press Back to close the channel list.

To change the type of channel list…

1 - While watching TV, press OK to open the current
channel list.

2 - Press Yellow key for Select More and then select
Select Type (for example, Broadcast or Favorites) to

immediately change the channel list to your preferred
list.

3 - Press Back to close the channel list.

Search for a Channel

You can search for a channel to find it in a long list of
channels.

To search for a channel…

1 - Press OK to open the current channel list.
2 - Press Yellow key for Select More.
3 - Select Operation > Find and press OK to open

a text field. You can use the remote control keyboard
(if available) or the on-screen keyboard to enter text.
4 - Enter a number, a name or part of a name and
press OK. The TV will search for matching channel
names in the list you selected.

Search results are listed with current channel list type
you have selected (for example, Broadcast or
Favorites). The search will return the matching
channel name with the result arranged in alphabetical
order. The search results disappear once you select
another channel list or close the list with search
results.

The TV may not work properly with some digital
television operators that are non-compliant with the
full requirements of the standard.

14

Channel List Sorting

Program Restrictions

You can do channel list sorting with all channels. You
can set the channel list to show only TV channels or
only Radio stations. For Antenna channels you can
set the list to show the Free or the Scrambled
channels.

To set a filter on a list with all channels…

1 - Press OK to open the current channel list.
2 - Press Yellow key for Select More.
3 - Select Operation > Sort and press OK.
4 - Select the filter you want and press OK to

activate. The name of the filter appears as part of the
channel list name on top of the channel list.
5 - Press Back to close the channel list.

6.3

Watching channels

Tune to a Channel

To start watching TV channels, press SOURCES. The
TV tunes to the channel you last watched.

Alternatively, you can select Live TV from the Home
screen.

Change Channels

To switch channels, press Channel + or Channel -.
If you know the channel number, type in the number
with the number keys. Press OK after you entered
the number to change immediately.

You can also tune to channels from a Channel List
by pressing OK.

Parental Controls

Lock and Unlock a Channel

To prevent children from watching a channel, you can
lock a channel. To watch a locked channel, you must
enter the 4 digit PIN code first. You cannot lock
programs from connected devices.

To prevent children from watching a program that
may not be suitable for them, you can set a rating.

Digital channels can have their programs rated. When
the rating of a program is equal to or higher than the
rating you have set, the program will be locked. To
watch a locked program, you must enter the
PIN code first.

To set a rating…
1 - Press MENU > Settings > Channel > Parental
Controls and press OK.

2 - Enter your PIN code if necessary.
3 - Select Program Restrictions and press OK.
4 - Select On to set the rating.
5 - Select Ratings and press OK.
6 - Set the restrictions for your children.
7 - Press Back, repeatedly if necessary, to close the

menu.
To turn off the parental rating, select None. However,

in some countries you must set a rating.
For some broadcasters/operators, the TV only locks

programs with a higher rating. The parental rating is
set for all channels.

Inputs Blocked

To prevent from using connected devices, you can
lock an input source. To connect a locked input
source, you must enter the 4 digit PIN code first.

To lock or unlock an input source…
1 - Press MENU > Settings > Channel > Parental
Controls and press OK.

2 - Enter your PIN code if necessary.
3 - Select Input Blocked and press OK.
4 - Press Navigation keys up or down to select the

source you want to lock or unlock, and press OK.

5 - A locked source is marked with a lock icon.
6 - Press Back, repeatedly if necessary, to close the

menu.

Change PIN

To lock or unlock a channel…
1 - Press MENU > Settings > Channel > Parental
Controls and press OK.

2 - Enter your PIN code if necessary.
3 - Select Channels Blocked and press OK.
4 - Press Navigation keys up or down to select the

channel you want to lock or unlock, and press OK.

5 - A locked channel is marked with a lock icon.
6 - Press Back, repeatedly if necessary, to close the

menu.

Set new or reset PIN code. The PIN code is used to
lock or unlock channels or programs.

1 - Press MENU > Settings > Channel > Parental
Controls and press OK.

2 - Enter your PIN code if necessary.
3 - Select Change PIN and press OK.
4 - Enter the current PIN code and new PIN code.
5 - Press Back, repeatedly if necessary, to close the

menu.

15

6.4

Favorite Channels

About Favorite Channels

In a favorite channel list, you can collect the channels
you like.

You can create 4 different lists of favorite channels for
easy channel zapping.

With a Favorites List selected, press the Navigation
keys up or down to select a channel, then
press OK to watch the selected channel.

Edit a Favorites List

To add a channel to the favorite list…

1 - While watching TV, press OK to open the current
channel list.
2 - Press Navigation keys up or down to select a
channel.
3 - Press Blue key to add the channel to a favorites
list (default list is Favorites1). Press Blue key again will
remove the channel from the favorite list.

4 - Press Back to close the menu.

To create a favorite channels list…

1 - While watching TV, press OK to open the current
channel list.

2 - Press Yellow key for Select More.
3 - Select Select Type > Favorites and then press

Navigation keys up or down to select a list of
Favorites1 to Favorites4 that you want to add.
4 - Press Yellow key for Select More and then select
Select Type to change the channel list to your

preferred list.
5 - Press Blue key to add the channel to the favorites
list you just selected. Press Blue key again will
remove the channel from the favorite list.

6 - Press Back to close the menu.

To move or remove a channel from the favorites
list…

1 - Select a list of Favorites1 to Favorites4 you want
to edit.

2 - Press Yellow key for Select More.
3 - Select Operation > Move to move the channel

positions on the favorites channel list.
4 - Select Operation > Delete to remove the
channels from the favorites channel list.
5 - Press Back, repeatedly if necessary, to close the
menu.

16

7

HDMI ARC

Connect Devices

7.1

About Connections

Connectivity Guide

Always connect a device to the TV with the highest
quality connection available. Also, use good quality
cables to ensure a good transfer of picture and
sound.

When you connect a device, the TV recognizes its
type and gives each device a correct type name. You
can change the type name if you wish. If a correct
type name for a device is set, the TV automatically
switches to the ideal TV settings when you switch to
this device in the Sources menu.

Only HDMI 1 connection on the TV has HDMI
ARC (Audio Return Channel).

If the device, typically a Home Theater System (HTS),
also has the HDMI ARC connection, connect it to
HDMI 1 on this TV. With the HDMI ARC connection,
you do not need to connect the extra audio cable
that sends the sound of the TV picture to the HTS.
The HDMI ARC connection combines both signals.

HDMI CEC

Antenna port

If you have a Set-top box (a digital receiver) or
Recorder, connect the antenna cables to run the
antenna signal through the Set-top box and/or
Recorder first before it enters the TV. In this way, the
antenna and the Set-top box can send possible
additional channels to the Recorder to record.

HDMI ports

HDMI Quality

An HDMI connection has the best picture and sound
quality. One HDMI cable combines video and audio
signals. Use an HDMI cable for High Definition (HD)
TV signals.

For best signal quality transfer, use a High speed
HDMI cable and do not use an HDMI cable longer
than 5 m.

Connect HDMI CEC-compatible devices to your TV,
you can operate them with the TV remote control.

HDMI CEC (Consumer Electronic Control) must be
turned on on the TV and the connected device.

Turn on CEC

Allow the TV to control the HDMI device.

Home > Settings > Device Preferences > Inputs >
HDMI control.

Copy protection

HDMI ports support HDCP 2.2 (High-bandwidth
Digital Content Protection). HDCP is a copy protection
signal that prevents copying content from a DVD disc
or Blu-ray Disc. Also referred to as DRM (Digital
Rights Management).

Device Auto Power Off

Turn off the HDMI devices with the TV.

Home > Settings > Device Preferences > Inputs >
Device auto power off.

TV Auto Power On

Power on the TV with HDMI devices.

17

Home > Settings > Device Preferences > Inputs > TV
auto power on.

Connect with HDMI

HDMI EDID Version

Check the HDMI EDID version number.
Home > Settings > Device Preferences > Inputs

> HDMI EDID Version.

CEC Device List

Check the connected HDMI CEC device list.
Home > Settings > Device Preferences > Inputs

> CEC device list.

Note:

• HDMI CEC might not work with devices from other
brands.

• The HDMI CEC functionality has different names on
different brands. Some examples are: Anynet, Aquos
Link, Bravia Theatre Sync, Kuro Link, Simplink and
Viera Link. Not all brands are fully compatible with
EasyLink. Example HDMI CEC branding names are
property of their respective owners.

7.2

Use an HDMI cable to connect a Home Theater
System (HTS) to the TV. You can connect a Philips
Soundbar or an HTS with a built-in disc player.

If the Home Theater System has no HDMI ARC
connection, add an optical audio cable to send the
sound of the TV picture to the Home Theater System.

Audio to video synchronization (sync)

If the sound does not match the video on screen, you
can set a delay on most Home Theater Systems with
a disc player to match the sound with the video.

7.3

Video Device

HDMI

Use a High speed HDMI cable to connect with best
picture and sound quality.

For best signal quality transfer, use a high-speed
HDMI cable. Do not use an HDMI cable longer than
16 feet (5 meters). You can connect devices
supporting HDR to any of the HDMI connectors.

Home Theater System - HTS

Connect with HDMI ARC

Use an HDMI cable to connect a Home Theater
System (HTS) to the TV. You can connect a Philips
Soundbar or an HTS with a built-in disc player.

HDMI ARC

If your Home Theater System has an HDMI ARC
connection, you can use HDMI ARC connection on
the TV to connect. With HDMI ARC, you do not need
to connect the extra audio cable. The HDMI ARC
connection combines both signals.
Since HDMI 1 on the TV can offer the Audio Return
Channel (ARC) signal, the TV can only send the ARC
signal to this HDMI connection.

Audio to video synchronization (sync)

If the sound does not match the video on screen, you
can set a delay on most Home Theater Systems with
a disc player to match the sound with the video.

Copy protection

HDMI ports support HDCP (High-bandwidth Digital
Content Protection). HDCP is a copy protection signal
that prevents copying content from a DVD disc or Blu­ray Disc. Also referred to as DRM (Digital Rights
Management).

18

7.4

7.5

Audio Device

Digital Audio Out - Optical

Audio Out - Optical is a high quality sound
connection.

This optical connection can carry 5.1 audio channels.
If your device, typically a Home Theater System
(HTS), has no HDMI ARC connection, you can use this
connection with the Audio In - Optical connection on
the HTS. The Audio Out - Optical connection sends
the sound from the TV to the HTS.

USB Hard Drive

What You Need

If you connect a USB Hard Drive, you can pause or
record digital TV broadcasts. The TV broadcast must
be a digital broadcast (DVB broadcasts or similar).

Minimum Disk Space

• To Pause
To pause a broadcast, you need a USB 2.0
compatible Hard Drive with a minimum of 4GB disk
space.

• To Record
To pause and record a broadcast, you need a
minimum of 250GB disk space.

Installation

Before you can pause or record a broadcast, you
must connect and format a USB Hard Drive.
Formatting removes all files from the USB Hard Drive.

Headphones

You can connect a set of headphones to the
headphone connector on the back of the TV. The
connection is a mini-jack 3.5mm.

* Note: TV Speakers will be muted when the
Headphones are plugged in.

1 - Connect the USB Hard Drive to one of
the USB connections on the TV. Do not connect
another USB device to the other USB ports when
formatting.

2 - Switch on the USB Hard Drive and the TV.
3 - When the TV is tuned to a digital TV channel,

press Pause. Trying to pause will start the formatting.
Follow the instructions on screen.
When the USB Hard Drive is formatted, leave it

connected permanently.

Warning

The USB Hard Drive is formatted exclusively for this
TV, you cannot use the stored recordings on another
TV or PC. Do not copy or change recording files on
the USB Hard Drive with any PC application. This will
corrupt your recordings. When you format another
USB Hard Drive, the content on the former will be lost.
A USB Hard Drive installed on your TV will need
reformatting for use with a computer.

19

Formatting

Before you can pause or record a broadcast, or store
apps, you must connect and format a USB Hard
Drive*. Formatting removes all files from the USB Hard
Drive.

Warning

The USB Hard Drive is formatted exclusively for this
TV, you cannot use the stored recordings on another
TV or PC. Do not copy or change recording files on
the USB Hard Drive with any PC application. This will
corrupt your recordings.

* Connect the USB Hard Drive with size less than 2TB
and make sure the available space is more than 1
GB.

To format a USB Hard Drive…

1 - Connect the USB Hard Drive to one of the USB
connections on the TV. Do not connect another USB
device to the other USB ports when formatting.

2 - Switch on the USB Hard Drive and the TV.
3 - Press MENU while watching TV, then

press Navigation keys down to Record > Device info.
4 - Select the device you want to format and press
OK.
5 - Select Format to star the formatting. All files and
data will be removed after formatting.
6 - When the USB Hard Drive is formatted, it is
recommended to leave it connected permanently.

To assign the storage device for PVR and Time
shift…

1 - Once the formatting is done, you can assign the
storage device for PVR or Time shift functions.
2 - Press MENU while watching TV, then
press Navigation keys down to Record > Device info.
3 - Select the device you want to assign and press
OK.
4 - Select Set timeshift to assign the device for Time
shift data storage. The device will be marked with
TSHIFT on Device info list.
5 - Select Set PVR to assign the device for recording
data storage. The device will be marked with PVR on
Device info list.

7.6

USB Flash Drive

To view the files from the USB flash drive, you need
to add the MMP (MultiMediaPlayer) app to the Home
screen first. Press Home, clicking the Apps icon at the
left end of the Apps row. You can add MMP apps
from the Apps page.

To stop watching the USB flash drive content,
press EXIT or select another activity. Exit the MMP
app before you disconnect the flash drive.

To remove the USB flash drive safely…

1 - Press HOME.
2 - Select the Notifications icon from the top-right

corner and press OK.

3 - Select your flash drive and press OK.
4 - Select Eject and press OK.
5 - Wait until the eject procedure is finished and then

pull out the flash drive.

Ultra HD on USB

You can view photos in Ultra HD resolution from a
connected USB device or flash drive. The TV will
downscale the resolution if the resolution of the
photo is higher.

7.7

Computer

You can connect your computer to the TV using a
high quality HDMI cable and use the TV as a PC
monitor.

* Note for AMD Graphics card users:
If you connect your computer to the TV via HDMI,
make sure you apply the right settings in the graphics
card in order to ensure proper performance.

- If graphics card output video is 4096 x 2160p or
3840 x 2160p and RGB pixel format is used, RGB 4:4:4
pixel format studio (limited RGB) shall be set in the
computer graphics card.

You can view photos or play your music and videos
from a connected USB flash drive.

Insert a USB flash drive in one of
the USB connections on the TV while the TV is
switched on.

20

8

8.3

Bluetooth

8.1

What You Need

You can connect a wireless device with Bluetooth® to
this TV – a wireless speaker or headphones*.

To play the TV sound on a wireless speaker, you must
pair the wireless speaker with the TV. The TV can only
play the sound on one speaker at a time.

Attention - Audio to Video synchronization

Many Bluetooth speaker systems have a high, so
called, 'latency.' High latency means that the audio
lags behind the video, causing unsynchronized 'lip
sync.' Before you purchase a wireless Bluetooth
speaker system, become familiar with the newest
models and look for a device with a low latency
rating. Ask your dealer for advice.

* Note: The Bluetooth on TV may not work properly
with cable free true wireless headphones.

8.2

Select a Device

To select a wireless device…

1 - Press MENU > TV
options > Settings > Remote & Accessories and
press OK.

2 - In the list, select the wireless device and
press OK.
3 - Press Back, repeatedly if necessary, to close the
menu.

8.4

Rename a Device

To rename a wireless device…

1 - Press MENU > TV
options > Settings > Remote & Accessories and
press OK.

2 - In the list, select the wireless device and
press OK.

3 - Select Change name and press OK.
4 - Enter a new name for the device.
5 - Press Back, repeatedly if necessary, to close the

menu.

Pairing a Device

Position the wireless speaker within 15 feet of the TV.
Read the user manual of the device for specific
information on pairing and on wireless range. Make
sure the Bluetooth setting on TV is turned on.

Once a wireless speaker is paired, you can select it to
play the TV sound. When a device is paired, you do
not need to pair it again unless you remove the
device.

To pair a Bluetooth device with the TV…
1 - Turn on the Bluetooth device and place it within

range of the TV.

2 - Press MENU > TV
options > Settings > Remote & Accessories and
press OK.

3 - Follow the instructions on screen. You will pair
the device with the TV and the TV will store the
connection. You might need to unpair a paired device
first if the maximum number of paired devices was
reached.
4 - Press Back, repeatedly if necessary, to close the
menu.

8.5

Remove a Device

You can disconnect a wireless Bluetooth device. Once
the Bluetooth device is disconnected, the audio
output device will go back to TV speakers.

To disconnect a wireless device…

1 - Press MENU > TV
options > Settings > Remote & Accessories and
press OK.

2 - In the list, select the wireless device and
press OK.

3 - Select Disconnect and press OK.
4 - Press Back, repeatedly if necessary, to close the

menu.

You can also remove a wireless Bluetooth device. If
you remove a Bluetooth device, the device will be
unpaired.

To remove a wireless device…

1 - Press MENU > TV
options > Settings > Remote & Accessories and
press OK.

2 - In the list, select the wireless device and
press OK.
3 - Select Unpair and press OK.

21

4 - Press Back, repeatedly if necessary, to close the
menu.

22

9

Problems

Connect your Android TV

9.1

Network and Internet

Home Network

To enjoy the full capabilities of your Philips Android
TV, your TV must be connected to the Internet.

Connect the TV to a home network with a high-speed
Internet connection. You can connect your TV
wirelessly or wired to your network router.

Connect to Network

Wireless Connection

What You Need

Wireless network not found or distorted

• Microwave ovens, DECT phones or other Wi-Fi

802.11b/g/n devices in your proximity might disturb
the wireless network.

• Make sure that the firewalls in your network allow
access to the TV's wireless connection.

• If the wireless network does not work properly in
your home, try the wired network installation.

Internet does not work

• If the connection to the router is OK, check the
router connection to the Internet.

The PC and Internet connection are slow

• Look in your wireless router's user manual for
information on indoor range, transfer rate and other
factors of signal quality.

• Use a high-speed (broadband) Internet connection
for your router.

DHCP

• If the connection fails, you can check the DHCP
(Dynamic Host Configuration Protocol) setting of the
router. DHCP should be turned on.

To connect the TV to the Internet wirelessly, you need
a Wi-Fi router with a connection to the Internet.

Use a high-speed (broadband) Internet connection.

Turn Wi-Fi On or Off
MENU > TV options > Settings > Network &

Internet > Wi-Fi.

Make the Connection

MENU > TV options > Settings > Network &
Internet > Wi-Fi.

Wired Connection

What You Need
What You Need

To connect the TV to the Internet, you need a
network router with an Internet connection. Use a
high-speed (broadband) Internet connection.

1 - In the list of found networks, select on your
wireless network. If your network is not in the list
because the network name is hidden (you switched
off the SSID broadcast of the router), select Add new
network to enter the network name yourself.

2 - Follow the on-screen instruction.
3 - A message will be shown when the connection is

successful.

Make the Connection

1 - Connect the router to the TV with a network cable
(Ethernet cable**).

2 - Make sure that the router is turned on.
3 - The TV constantly searches for the network

connection.
4 - A message will be shown when the connection is
successful.

23

If the connection fails, you can check the DHCP
setting of the router. DHCP should be turned on.

**To fulfill EMC regulations, use a shielded FTP Cat.
5E Ethernet cable.

5 - With the on-screen keyboard, enter your email
address and press OK.

6 - Enter your password and press OK to sign in.
7 - Press Navigation keys left repeatedly if

necessary, to close the menu.

Network settings

Proxy Settings
MENU > TV options > Settings > Network &

Internet > Proxy settings.

Enter a valid proxy hostname manually by selecting

Manual.

Network Configuration - IP settings
MENU > TV options > Settings > Network &

Internet > IP settings.

If the connection fails, you can check the DHCP
setting of the router.
Alternatively, if you are an advanced user and want to
install your network with static IP addressing, set the
TV to Static IP.

9.2

Android Settings

You can set or view several Android specific settings
or information. You can find the list of apps installed
on your TV and the storage space they need. You can
configure the onscreen keyboard or allow apps to use
your location. Explore the different Android settings.
You can go
to www.support.google.com/androidtv for more
information on these settings.

To open these settings…

1 - Select Settings and press OK.
2 - Explore the different Android settings.
3 - Press Back if necessary, to close the menu.

Google Account

Sign In

To enjoy the full capabilities of your Philips Android
TV, you can sign in to Google with your Google
Account.

By signing in you'll be able to play your favorite
games across phone, tablet and TV. You'll also get
customized video and music recommendations on
your TV home screen as well as access to YouTube,
Google Play and other apps.

Sign In

Use your existing Google Account to sign in to
Google on your TV. A Google Account consists of an
email address and a password. If you don't have a
Google Account yet, use your computer or tablet to
create one (accounts.google.com). To play games
with Google Play, you need a Google+ profile. If you
did not sign in during the first TV installation, you can
always sign in later.

To sign in after completing the TV installation…

1 - Select Settings.
2 - Select Account & Sign-In and press OK.
3 - Select Sign In and press OK.
4 - Select Use your remote and press OK.

24

10

Apps

Find more information
on www.support.google.com/androidtv

10.1

About Apps

You can find your favorite Apps on Apps row in the
Home menu.

Like apps on your smartphone or tablet, the apps on
your TV offer specific functions for an enriched TV
experience. Apps like YouTube, games, video stores
or weather forecasts (a.o.).

Apps can come from the Google Play™ Store. To
get you started, some practical apps are pre-installed
on your TV.

To install apps from the Google Play™ Store, the TV
must be connected to the Internet. You must sign in
with a Google Account to use the Google Play apps
and Google Play™ Store.

10.2

Google Play

Movies and TV

With Google Play Movies & TV , you can rent or buy
movies and TV shows to watch on TV.

What You Need

• your TV must be connected to the Internet

• you must sign in with your Google Account on the
TV

• add a credit card to your Google Account to
purchase movies and TV shows

To rent or buy a movie or TV show…

1 - Press Home.
2 - Select Google Play Movies & TV.
3 - Select a movie or TV show and press OK.
4 - Select the purchase you want and press OK. You

will be taken through the purchase procedure.
To watch a rented or purchased movie or TV show…

1 - Press Home.
2 - Select Google Play Movies & TV.
3 - Select the movie or TV show from your library in

the app, select the title and press OK.

4 - You can use the Stop, Pause, Rewind or Fast
forward keys on the remote control.

5 - To stop the Movies & TV
app, press Back repeatedly or press EXIT.

If the App is not on you Home screen, you can add
via the Apps page or by the Add app to favorites
item on the Apps row. Some Google Play products
and features aren't available in all countries.

Music

With YouTube Music you can play your favorite
music on TV and buy new music on your computer or
mobile device. Or, on your TV, you can sign up for All
Access, the YouTube Music
subscription. Alternatively, you can play the music
you already own, stored on your computer.

What You Need

• your TV must be connected to the Internet

• you must sign in with your Google Account on the
TV

• add a credit card to your Google Account to add a
music subscription

To start YouTube Music…

1 - Press Home.
2 - Select YouTube Music.
3 - Select the music you want and press OK.
4 - To stop the Music app, press Back repeatedly or

press EXIT.
If the App is not on you Home screen, you can add

via the Apps page or by the Add app to favorites
item on the Apps row. Some Google Play products
and features aren't available in all countries.

Find more information
on www.support.google.com/androidtv

Games

With Google Play Games, you can play games on TV.
Online or offline.

You can see what your friends are playing currently or
you can join the game and compete. You can track
your achievements or start wherever you left off.

What You Need

• your TV must be connected to the Internet

• you must sign in with your Google Account on the
TV

• add a credit card to your Google Account to
purchase new games

Start the Google Play Games app to select and install
new game apps on your TV. Some games are free of
charge. A message appears if a particular game needs
a gamepad to play the game.

To start or stop a Google Play Game…

1 - Press Home.
2 - Select Google Play Games.
3 - Select a game to play or select a new game to

install and press OK.

25

4 - When done, press Back repeatedly or
press EXIT or stop the app with its dedicated
exit/stop button.

If the App is not on you Home screen, you can add
via the Apps page or by the Add app to favorites
item on the Apps row. Some Google Play products
and features aren't available in all countries.

Payments

To make a payment on Google Play on TV, you must
add a form of payment - a credit card (outside the
United States) - to your Google Account. When you
purchase a movie or TV show, you will be charged on
this credit card.

Find more information
on www.support.google.com/androidtv

Google Play Store

From the Google Play Store you can download and
install new apps. Some apps are free of charge.

What You Need

• your TV must be connected to the Internet

• you must sign in with your Google Account on the
TV

• add a credit card to your Google Account to
purchase apps

To install a new app…

1 - Press Home.
2 - Select Google Play Store and press OK.
3 - Select the app you want to install and press OK.
4 - To close the Google Play Store,

press Back repeatedly or press EXIT.
Parental Controls

In the Google Play Store, you can hide apps
according to users/buyers maturity. You need to enter
a PIN code to select or change the level of maturity.

To set the parental control…

1 - Press Home.
2 - Select Google Play Store and press OK.
3 - Select Settings > Parental controls.
4 - Select the level of maturity you want.
5 - When prompted, enter the PIN code.
6 - To close the Google Play Store,

press Back repeatedly or press EXIT.

To add a credit card …
1 - On your computer, go to accounts.google.com

and sign in with the Google Account you will use with
Google Play on TV.
2 - Go to wallet.google.com to add a card to your
Google Account.
3 - Enter your credit card data and accept the terms
and conditions.

10.3

Start or Stop an App

You can start an app from the Home screen.
To start an app…

1 - Press Home.
2 - Move to Apps row, select the app you want and

press OK.
3 - To stop an app, press Back or press EXIT or
stop the app with its dedicated exit/stop button.

When opening the Home screen, the background
application/content playback will stop. You have to
select the application or content from the Home
screen to resume.

A note to start the Live TV app

If you have installed the Live TV app on Home screen,
please note that the HDMI sources are regard as
App’s sources. When the Live TV app is started, it will
open with current source, which includes TV and
HDMI sources.

If the App is not on you Home screen, you can add
via the Apps page or by the Add app to favorites
item on the Apps row. Some Google Play products
and features aren't available in all countries.

Find more information
on www.support.google.com/androidtv

10.4

Manage Apps

If you stop an app and return to the Home menu, the
app is not really stopped. The app is still running in
the background to be readily available when you start
it again. To run fluently, most apps need to save some
data in the cache memory of the TV. It might be good
to stop an app completely or clear the cache data of
a particular app to optimize the overall performance
of apps and to keep memory usage low on your
Android TV. Also, it is best to uninstall apps that you
are not using anymore.

26

11

Sources

11.1

Switch to a device

From the list of Sources, you can switch to any of the
connected devices. You can switch to a tuner to
watch TV or switch to your connected devices to
watch their program, a digital receiver or a Blu-ray
Disc player.

To switch to a connected device…

1 - Press SOURCES to open the Sources menu.
2 - Select one of the items in the source list and

press OK. The TV will show the program or content of
the device.

One Touch Play

With the TV in standby, you can switch on a disc
player with your TV remote control.
To switch on both disc player and TV from standby
and start playing the disc immediately,
press Play on the TV remote control. The device
must be connected with an HDMI cable and both TV
and device must have HDMI CEC switched on.

27

12

Settings

12.1

TV Options

Press MENU while watching TV, press Navigation
keys up or down to select one of below menus. Press
Navigation keys right or left to view more options

from the selected menu.


• Dolby Vision Bright

• Dolby Vision Dark

• Dolby Vision Vivid

Dolby Vision Notification

MENU > TV options > Picture > Dolby Vision
Notification and press OK.

Turn On or Off the Dolby Vision notification when
Dolby Vision content begins to play on your TV.

Adjust the picture settings.

Sound

Adjust the sound settings.

Closed Captions

To enable/disable Closed Caption, or to show it on
mute.

Power

Set the timers for saving energy.

Advanced Options

Adjust advanced settings.

Settings

View settings menu.

12.2

Picture Settings

Picture Mode

Display Mode

If the picture is not filling the whole screen, if black
bars are showing on the top or bottom or at both
sides, you can adjust the picture to fill the screen
completely.

To select one of the basic settings to fill the screen…

MENU > TV options > Picture > Display mode.
Automatic

Automatically zooms in the picture to fit the screen
with original aspect ratio. No content lost visible.

Super zoom

Remove the black bars on the sides of 4:3 broadcasts.
Not recommended for HD or PC.

4:3

Display the classic 4:3 format.

Movie expand 14:9

Scale 4:3 format to 14:9. Not recommended for HD or
PC.

Select a style
MENU > TV options > Picture > Picture mode.

For easy picture adjustment, you can select a preset
picture style.

• User - The picture preferences you set during the
first start up.

• Standard - Most energy conscious setting - Factory
setting

• Vivid - Ideal for daylight viewing

• Sport - Ideal for sport

• Movie - Ideal for watching movies with original
studio effect

• Game* - Ideal for playing games
* Picture mode - Game is not available for some

video sources.
When TV receives Dolby Vision HDR signal, select a

picture style below:

Movie expand 16:9

Scale 4:3 format to 16:9. Not recommended for HD or
PC.

Wide screen

Stretches the picture to a 16:9 format.

Full

Automatically enlarges the picture to fill the screen.
Picture distortion is minimal, subtitles remain visible.
Not suitable for PC input. Some extreme picture
content can still show black bars. Picture content
aspect ratio may change.

Original

Provide maximum detail for PC.

28

Other Picture Settings

MENU > TV options > Picture and press OK.

Backlight

Adjust the video backlight intensity.

Brightness

Set the level of brightness of the picture signal.
Note: Setting of brightness much away from

reference value (50) may result lower contrast.

Contrast

Adjust the contrast value of the picture.

Saturation

Adjust the color saturation value of the picture.

Hue

• HDMI Auto Game Mode
Allow TV to automatically switch to Game mode
when the game content is notified by source.

Color Tuner

Fine tune the color setting yourself.

11 Point White Balance Alignment

Customize the whitepoint balance based on the
selected color temperature of the picture.

Reset to Default

Reset the current picture settings to default.

12.3

Sound Settings

Adjust the hue value of the picture.

Sharpness

Adjust the level of sharpness in fine detail of the
picture.

Gamma

Set a non-linear setting for picture luminance and
contrast. This is a setting intended for expert users.

Color Temperature

Set the picture to a preset color temperature or adjust
the setting yourself.

Light sensor

Select On to adjust the picture settings automatically
to the lighting conditions of the room.

Advanced Video

Set the advance settings.

• DNR
Digital Noise Reduction, image noise reduction filters
to reduces the image noise.

• MPEG NR
MPEG Noise Reduction feature to improve the quality
of pictures by reducing the noise without
compromising the picture resolution.

• Adaptive Luma Control
Dynamic video contrast enhancement to adjust the
Luma level of the picture signal automatically. If the
PC Mode setting is On, this feature will be off.

• Local Contrast Control
Enhance the contrast level in local area for the image.

• Game Mode
Switch TV to Game mode to have fast response time.

• PC Mode
Switch TV to PC mode to have original picture look.

Sound Mode

MENU > TV options > Sound > Sound Mode > and

press OK.
For easy sound adjustment, you can select a preset

setting with sound mode.

• Game - Ideal for gaming

• Movie - Ideal for watching movies

• Music - Ideal for listening to music

• Dialog - Ideal for speech

• AI mode - Select AI mode for intelligent switching
of sound mode base on audio content.

• User - The sound preferences you set during the
first start up

Other Sound Settings

MENU > TV options > Sound and press OK.
Speakers

Set the TV to play the sound on TV or on the
connected audio system.

You can select where you want to hear the TV sound
and how you want to control it.

• If you select TV speakers off, you permanently
switch off the TV speakers.

• If you select TV speakers, the TV speakers are
always on.

With an audio device connected with HDMI CEC,
select HDMI sound system. The TV will switch off
the TV speakers when the device is playing the
sound.

* Note: TV Speakers will be muted when the
Headphones are plugged in.

USB Audio

29

Turn On or Off for the audio output through USB
audio device if there is a USB audio peripheral
attached to the TV USB port.

Digital Output

Digital output settings are available for optical and
HDMI ARC sound signals.

Set TV switch off timer
Power > Switch off timer.

Select Switch off timer, the TV switches off
automatically at a preset time to save energy. The
timer will not stop unless the setting is changed to
Off.

Set the audio out signal of the TV to fit the sound
capabilities of the connected Home Theater System.

Digital Output Delay

For some Home Theater Systems you might need to
adjust the audio sync delay to synchronize the audio
to the video. Select 0 if a sound delay is set on your
Home Theater System.

DTS night mode

Select DTS night Mode for a more comfortable quiet
listening experience when watching content with DTS
Master Audio.

Dolby Audio Processing

Set the advance settings.

• Volume Leveler: select On to adjust the volume
automatically.

• Dialogue Enhancer: select to get an improved sound
quality for speech program.

• Surround Virtualizer: select On to create a virtual
surround sound experience.

• Dolby Atmos: select On to enable Dolby Atmos,
which can add height dimension in sound. With
height dimension, sound can be precisely placed and
moved in three-dimensional space.

Reset to Default

Reset the current sound settings to default.

12.4

Power Settings

MENU > TV options > Power.

No Signal Auto Power Off
Power > No signal auto power off.

Press Navigation keys up or down to set the
value. Select Off to deactivate the automatic turn off.

* If you use the TV as a monitor or use a digital
receiver to watch TV (a Set-Top Box - STB) and you
do not use the remote control of the TV, you should
deactivate this automatic switch off, to set the value
to Off.

Set auto sleep timer
Power > Auto sleep.

The TV switches to standby mode automatically after
a preset time if the TV does not receive any command
from the remote control.

12.5

Advanced Options

Audio

Set the audio language
MENU > TV options > Advanced Options > Audio

Language.

The TV channels can broadcast audio with several
spoken languages for a program. You can set a
preferred audio language. If audio in one of these
languages is available, the TV will switch to this audio.

Set Sleep timer
Power > Sleep timer.

TV switches to standby mode automatically after a
preset time. You can stop the timer when the
notification pops to say that two minutes are left.

Set screen off to save energy consumption
Power > Picture off.

Select Picture off, the TV screen is turned off, to turn
the TV screen back on, press any key on the remote
control.

MTS

MENU > TV options > Advanced Options > MTS.

You can switch the sound of an analog channel to
Mono, SAP or Stereo.

* Note: MTS is for analog channel only.

30

12.6

Other settings

Device Preferences

Ambilight function.

Storage

Check the device storage.

Home > Settings > Device Preferences.
System Update

Update TV software from local update or from the
Internet.

About

To show the information about this TV or perform
Factory reset operation for the TV.

Date & Time

Adjust the date and time settings.

Timer

Set TV switch on or off timer.

Language

Set or change the menu language.

Keyboard

Set the on-screen keyboard type.

Inputs

Rename the Inputs name and adjust the settings for
Consumer Electronic Control (CEC).

Power

Set the timers for saving energy.


Adjust the picture settings.

Sound

Adjust the sound settings.

Ambilight

Adjust the Ambilight settings.
* Ambilight setting is only for models which support

Home Screen

Customize the home screen. You can enable or
disable the video and audio previews. Reorder the
apps and games. Read the Open-source licenses.

Retail Mode

Switch On or Off the retail mode. If you set the retail
mode to on. You can set the retail message type and
demo.

Google Assistant

Adjust the settings for Google Assistant. You can also
view the Open-source licenses.

Chromecast built-in

Adjust the settings for Chromecast built-in. You can
view the Open-source licenses and the version
number.

Screen Saver

Adjust the screen saver setting for your preference.

Location

Set the location status.

Usage & Diagnostics

Set to on for automatically send diagnostic
information to Google, such as crash reports and
usage data from your device, apps and Chromecast
built in.

Accessibility

Activate special functions for hearing and visually
impaired people.

Reboot

Reboot your TV for better performance when needed.

31

Remote and Accessories

Audio Language

Home > Settings > Remote and Accessories.

You can select the stored bluetooth connection from
the list.

If you cannot find your accessory, select Add
accessory to search for bluetooth connections.

12.7

Reboot

Home > Settings > Device Preferences > Reboot.

Note:

• Disconnect the external USB hard disc before
rebooting.

• Wait for few seconds, the TV restarts automatically.
This will remove unnecessary data and information in

the memory.
If your TV runs low performance when using Apps,

such as the video and audio are not synchronized or
the App is running slow, reboot your TV for better
performance.

Set audio preference language
MENU > TV options > Advanced Options > Audio

Language/Primary Audio/Secondary Audio or Audio
Channel.

The TV channels can broadcast audio with several
spoken languages for a program. You can set a
preferred primary and secondary audio language. If
audio in one of these languages is available, the TV
will switch to this audio.

Clock

Home > Settings > Device Preferences > Date &
time.

Correct clock automatically
Automatic date & time > Use network-provided

time.

• The standard setting for the TV clock is automatic.
The time information comes from the broadcasted
UTC - Coordinated Universal Time information.

12.8

Factory Reset

Reset all settings value to original TV settings
Home > Settings > Device Preferences > About >

Factory reset.

This will erase all data from your device's internal
storage, including: your Google account, system app
data, download apps and settings. All settings will be
reset and installed channels will be erased.

12.9

Clock and Language Settings

Menu Language

Change the language of the TV menu
Home > Settings > Device

Preferences > Language.

Correct clock manually
Automatic date & time > Off.
Select Set date and Set time to adjust the value.

Note:

If none of the automatic settings display the time
correctly, you can set the time manually.

Set time zone or set a time offset for your region
Date & time > Set time zone.

Select the time zone of your preference.

Set the time format to 24-hour
Date & time > Use 24-hour format.

Enable to show the system time in 24-hour format,
else show in 12-hour format time.

1 - Press Home to go to Home screen.
2 - Select Device Preferences > Language.
3 - Select your language and press OK.
4 - Press Back or EXIT repeatedly to close the

menu.

32

Timer

Set TV switch on or off timer
Home > Settings > Device Preferences > Timer.
Set Power on time type or Power off type to On or

Once.

12.10

Accessibility Settings

The TV is prepared for use of the deaf, hard of
hearing, blind or partially sighted people.

Accessibility for blind or partially sighted people
Home > Settings > Device Preferences >

Accessibility > Audio Description.

Digital TV channels can broadcast special audio
commentary describing what is happening on screen.
Select to enable or disable the audio description.

Visually Impaired
Accessibility > Visually Impaired.

When Audio Description is on, more Visually Impaired
options are available. Set the speaker, headphone
volume of the normal audio with the audio
commentary or set the extra audio effects in the
commentary audio. You can adjust the effect with
below settings.

• Speaker

• Headphone

• Volume

• Pan and Fade

• Audio for Visually Impaired

• Fader Control

Audio Hearing Impaired
Accessibility > Audio Hearing Impaired.

Turn on/off the text to describe the sound or visual
information on screen.

33

13

13.3

Videos, Photos, Music & Text

13.1

From a USB Connection

You can view your photos or play your music and
videos from a connected USB flash drive.

With the TV turned on, plug in a USB flash drive to
one of the USB connections.

1 - Press Home, select MMP from the Apps list and
press OK.

2 - Use Navigation keys to select the file type.
3 - Follow the on-screen instructions to play the

files.

13.2

Play your Videos

View your Photos

View Photos

View a photo

1 - Press Home, select MMP from the Apps list and
press OK.

2 - Use Navigation keys to select Photo.
3 - Select one of the photos, and press OK.

When browsing photo thumbnails, press MENU to...
Sort

Sort the photo files by your preference.

Media Type

Sort the files by media type.

Thumbnail Size

Change the thumbnail viewing size.

Copy

Copy the file and place it in your preferred folder.

Play a video

1 - Press Home, select MMP from the Apps list and
press OK.

2 - Use Navigation keys to select Video.
3 - Select one of the videos, and press OK to play.

During the video playback...

• Press MENU to show the options.
Play, Pause

Press OK to play or pause the video.

Repeat

Play videos repeatedly or once.

Show Info

Display the information of the video file.

Display Mode

Adjust the display mode.


Adjust the picture settings.

Sound

Adjust the sound settings.

Sound Tracks

Display the soundtracks.

Last Memory

When set to On, you can play the video where you
left last time. Set to Off to turn off the function.

Paste

Place the copied file to your preferred folder.

Delete

Delete the selected file.

Recursive parser
Select from the Recursive parser or Normal parser.

Photo Frame

Select to start the Photo Frame mode.

Photo Options

When viewing photo files, press MENU to...
Pause

Press OK to pause the photos.
Repeat

View the pictures repeatedly or once only.

Shuffle on, Shuffle off

View the pictures in sequential order, or at random.

Duration

Set the speed of the slideshow.

Effect

Set the transition from one picture to the next.

Show info

34

Display the information of the picture file.

Press OK to play or pause the text file preview.

Photo Frame image

Set the picture as Photo Frame image.


Adjust the picture settings.

13.4

Play your Music

Play music

1 - Press Home, select MMP from the Apps list and
press OK.

2 - Use Navigation keys to select Audio.
3 - Select one of the audio, and press OK to play.

During the audio playback...

• Press MENU to show the options.
Play, Pause

Press OK to play or pause the music.
Repeat

Repeat

Preview the text files repeatedly or once.

Shuffle On, Shuffle Off

Preview the text files in sequential order, or at
random.

Font
Adjust the text Size, Style and Color.

Show Info

Display the information of the text file.

Play music repeatedly or once.

Shuffle On, Shuffle Off

Play audio in sequential order, or at random.

Show Info

Display the information of the music file.

Lyric Options

Select the options when the lyrics are available.

Picture Off

Close the screen when play the music for energy
saving.

Sound

Adjust the sound settings.

13.5

View your Text

View text

1 - Press Home, select MMP from the Apps list and
press OK.

2 - Use Navigation keys to select Text.
3 - Select one of the text file, and press OK to

preview.

During the preview...

• Each file lasts 3 seconds for preview. Press OK to
pause the preview to read.

• Press MENU to show the options.

Play, Pause

35

14

TV guide

14.1

TV Guide Data

With the TV Guide you can view a list of the current
and scheduled TV programs of your channels. Not all
channels offer TV Guide information.

The TV Guide receives information (data) from
broadcasters. The TV can collect TV Guide
information for the channels that are installed on the
TV. The TV cannot collect the TV Guide information
for channels viewed from a digital receiver or
decoder.

14.2

Using the TV Guide

To open the TV Guide, press TV GUIDE key on the
remote control. The TV Guide shows the channels of
the selected tuner. Press TV GUIDE again to close

Alternately, while watching TV, press MENU >
Navigation keys up > Channels > Program Guide
to open the TV Guide.

The TV Guide receives information (data) from
broadcasters. In some regions and for some channels,
TV Guide information might not be available.

36

15

Recording and Time

3 - Select Set PVR to assign the device for recording
data storage. The device will be marked with PVR on

Device info list.

Shift

15.1

Record Options

Press MENU while watching TV, then press
Navigation keys down and select one of below

menus.

Record List

You can view and manage your recordings in the list
of recordings.

Device Info

Check the information about the storage device for
TV recording. You can also format or test the speed of
the device.

Schedule List

You can schedule a recording of an upcoming
program and view the scheduled list.

Time Shift Mode

Turn on/off Time Shift Mode. When the mode is on
and your storage device is ready for the time shift
recording, you can pause a TV broadcast and resume
watching it a bit later.

15.2

You cannot record when you are using Time shift
function.

In terms of enforcement of copyright legislation, some
channel providers can apply different restriction by
means of DRM (Digital Right Management)
technology. In case of broadcasting protected
channels, recording, record validity or number of
views may be restricted. Recording may be
completely prohibited. In case of trying to record a
protected broadcasting or play back an expired
recording, an error message can appear.

Note:
Recording function is only for digital TV broadcast. It
is not possible to record content from external
devices (e.g. HDMI).

Record a program

Record Now

To record the program you are watching right now,
press Record key on the remote control. The
recording will start immediately.

To stop the recording, press Stop key on the remote
control.

* Note: The instant recording will be stopped when a
reminder or scheduled recording is triggered.

Recording

What You Need

You can record a digital TV broadcast and watch it
later.

To record a TV program, you need…

• a connected USB storage device formatted to FAT32

• digital TV channels installed on this TV

• to receive channel information for the on-screen TV
Guide

• a reliable TV clock setting. If you reset the TV clock
manually, recordings may fail.

A storage device need to be assigned as the
recording data storage before you can start the
recording.
To assign a storage device for recording…

1 - Press MENU while watching TV, then
press Navigation keys down to Record > Device info.
2 - Select the device you want to assign and press

OK.

Schedule a Recording or Reminder

You can schedule a recording or reminder of an
upcoming program for today or a few days from
today (maximum of 8 days away). The TV will use the
data from the TV Guide to start and end the
recording.

To record a program…

1 - Press MENU > Navigation keys down > Record >
Schedule list and press OK.

2 - Press Record key on the remote control.
3 - Follow the on-screen instruction. Use Navigation

keys to select and set the settings.

4 - Select Add and press OK.
5 - If you need to set a reminder, go to Schedule

Type and change the setting to Reminder.

37

List of Recordings

Pause a program

You can view and manage your recordings in the list
of recordings.

To open the list of recordings…

1 - Press MENU > Navigation keys down >
Record > Record list and press OK.

2 - With a recording selected in the list, you can use
the color keys to remove the recording or show the
recording information.

3 - Press Back to close the menu.

Watch a Recording

To watch a recording…

1 - Press MENU > Navigation keys down >
Record > Record list and press OK.

2 - In the list of recordings, press OK to play the
recording.
3 - You can use the Playback keys for pause, play,
rewind, fast forward or stop.
4 - To switch back to watch TV, press EXIT.

15.3

Time Shift

What You Need

You can pause a digital TV broadcast and resume
watching later.

To pause and resume a broadcast…

• To pause a broadcast, press Pause. A progress bar
at the bottom of the screen appears briefly.

• To call up the progress bar, press Pause again.

• To resume watching, press Play.
With the progress bar on screen, press Rewind or

press Forward to select from where you want to
start viewing the paused broadcast. Press these keys
repeatedly to change speed.

You can pause a broadcast for a maximum time span
of 90 minutes.

To switch back to the live TV broadcast, press Stop.

Replay

Since the TV stores the broadcast you are watching,
you can replay the broadcast for a few seconds.

To replay a current broadcast…

1 - Press Pause
2 - Press Rewind. You can press it repeatedly to

select from where you want to start viewing the
paused broadcast. Press these keys repeatedly to
change speed. At one point you will reach the start of
the broadcast storage or the maximum time span.

3 - Press Play to watch the broadcast again.
4 - Press Stop to watch the broadcast live.

To pause a TV program, you need…

• a connected USB storage device formatted to FAT32

• digital TV channels installed on this TV
A storage device need to be assigned as the Time

shift data storage before you can start the Time shift.
To assign a storage device for Time shift…

1 - Press MENU while watching TV, then
press Navigation keys down to Record > Device info.
2 - Select the device you want to assign and press
OK.
3 - Select Set timeshift to assign the device for Time
shift data storage. The device will be marked with
TSHIFT on Device info list.

With the USB storage device connected and
formatted, the TV continuously stores the TV
broadcast you are watching. When you switch to
another channel, the broadcast of the former channel
is cleared. Also when you switch the TV to standby,
the broadcast is cleared.

You cannot use Time shift function when you are
recording.

38

16

Smartphones and Tablets

16.1

Google Cast

What You Need

If an app on your mobile device has Google Cast, you
can cast your app on this TV. On the mobile app, look
for the Google Cast icon. You can use your mobile
device to control what's on TV. Google Cast works on
Android and iOS.

Your mobile device must be connected to the same
Wi-Fi home network as your TV.

Apps with Google Cast

New Google Cast apps come available every
day. You can already try it with YouTube, Chrome,
Netflix, Photowall … or Big Web Quiz for
Chromecast. See also google.com/cast

Some Google Play products and features aren't
available in all countries.

Find more information on

www.support.google.com/androidtv

Cast to Your TV

To cast an app to the TV screen…
1 - On your smartphone or tablet, open an app that

supports Google Cast.

2 - Tab the Google Cast icon.
3 - Select the TV you would like to cast to.
4 - Press play on your smartphone or tablet. What

you selected should start playing on TV.

39

17

Netflix

If you have a Netflix subscription, you can enjoy
Netflix on this TV. Your TV must be connected to the
Internet. In your region, Netflix might only come
available with future software updates.

To open Netflix, press NETFLIX on the remote control
to open the Netflix App. You can open Netflix
immediately from a TV in standby.

www.netflix.com

40

18

Software

18.1

Update Software

Local Updates

You need a computer with a high-speed Internet
connection and a USB flash drive to upload the
software on the TV. Use a USB flash drive with at least
2GB free space. Make sure that write protection is
switched off.

1 - Press Home > Settings > Device Preferences >
System update > Local Updates and press OK.

2 - Follow the instructions on screen.

Update from Internet

If the TV is connected to the Internet, you may receive
a message to update the TV software. You need a
high-speed (broadband) Internet connection. If you
receive this message, we recommend you carry out
the update.

1 - Press Home > Settings > Device Preferences >
System update > Internet and press OK.

2 - Follow the instructions on screen.

18.2

Software Version

To view the current TV software version…

1 - Select Home > Settings > Device Preferences >
About > Software version.

2 - The version, release notes and creation date are
shown. Also, the Netflix ESN Number is shown if
available.
3 - Press Back if necessary, to close the menu.

18.3

Open Source Licenses

To view the Open-source licenses…
1 - Select Home > Settings > Channel, or

select Home > Settings > Device Preferences >
Google Assistant.

2 - Select Open-source licenses and press OK.
3 - Press Back if necessary, to close the menu.

41

19

19.2

Specifications

19.1

Environmental

End of Use

Disposal of your old product and batteries

Your product is designed and manufactured with high
quality materials and components, which can be
recycled and reused.

When this crossed-out wheeled bin symbol is
attached to a product, it means that the product is
covered by European Directive 2012/19/EU.

Power

Product specifications are subject to change without
notice. For more specification details of this product,
see www.philips.com/TVsupport

Power

• Mains power: AC 220-240V +/-10%

• Ambient temperature: 5°C to 35°C (40°F to 95°F)

• Power saving features: Sleep timer, Switch off timer,
Picture off, No Signal Auto Power Off, Auto sleep.

19.3

Operating System

Android OS:
Android 10

19.4

Reception

Please inform yourself about the local separate
collection system for electrical and electronic
products.

Please act according to your local rules and do not
dispose of your old products with your normal
household waste. Correct disposal of your old
product helps prevent potential negative
consequences for the environment and human
health.

Your product contains batteries covered by the
European Directive 2006/66/EC, which cannot be
disposed with normal household waste.

• Antenna input: 75 ohm coaxial (F-type)

• Tuner bands: Hyperband, UHF, VHF

• ISDBT

• Analog video playback: NTSC

• Digital video playback: MPEG2 SD/HD (ISO/IEC
13818-2), MPEG4 SD/HD (ISO/IEC 14496-10)

• Digital audio playback (ISO/IEC 13818-3)

19.5

Display Type

Diagonal screen size

• 108 cm/43 inch

• 126 cm/50 inch

• 139 cm/55 inch

• 164 cm/65 inch

• 177 cm/70 inch

Display resolution

• 3840 x 2160

19.6

Please find out for yourself about the local rules on
separate collection of batteries because correct
disposal will help prevent negative consequences for
the environment and human health.

Display Input Resolution

Supported Video only resolution

Resolution — Refresh rate

• 480i - 60 Hz

• 576i - 50 Hz

• 1080i - 50 Hz, 60 Hz

42

Supported Computer/Video resolution

Resolution — Refresh rate

• 640 x 480 - 60Hz

• 576p - 50Hz

• 720p - 50 Hz, 60 Hz

• 1920 x 1080p - 24 Hz, 25 Hz, 30 Hz, 50 Hz, 60 Hz

• 2560 x 1440 - 60 Hz

• 3840 x 2160p - 24 Hz, 25 Hz, 30 Hz, 50 Hz, 60 Hz

19.7

Connectivity

TV Side

• USB 1: USB 2.0

• Headphones: Stereo mini-jack 3.5mm

• HDMI 1 in: ARC - Ultra HD - HDR

TV Bottom

• Digital Audio out: Optical

• USB 2: USB 2.0

• Network LAN: RJ45

• Antenna (75 ohm)

• HDMI 2 in: Ultra HD - HDR

• HDMI 3 in: Ultra HD - HDR

• HDMI 4 in: Ultra HD - HDR

• Audio Codecs: MP3, WAV, AAC, WMA (v2 up to
v9.2), WMA-PRO (v9 and v10)

• Subtitles :
– Formats : SRT, SMI, SSA, SUB, ASS, TXT
– Character encodings : UTF-8(Unicode), UTF-16,
Simplified Chinese, Central Europe, Cyrillic, Western
Europe, Greek, Turkish, Hebrew, Korean

• Maximum Supported Data Rate :
– MPEG-4 AVC (H.264) is supported up to High
Profile @ L5.1. 30Mbps
– H.265 (HEVC) is supported up to Main / Main 10
Profile up to Level 5.1 40Mbps

• Image Codecs: JPEG, GIF, PNG, BMP, HEIF

19.8

Sound

Output power (RMS): 20W
Dolby MS12 V2.5

• Dolby Atmos

• DTS – HD (M6)

• Surround Virtualizer + Height Virtualizer

• Dolby Bass Enhancement

• Dolby Dialogue Enhancement

• Dolby Volume (AVL/Night Mode)

• AI Sound

19.9

Multimedia

Connections

• USB 2.0

• Ethernet LAN RJ-45

• Wi-Fi 802.11n Dual Band (built-in)

• BT 5.0

Supported USB file systems

• FAT 16, FAT 32, NTFS

Playback formats

• Containers: PS, TS, M2TS, TTS, AVCHD, MP4, M4V,
MKV, ASF, AVI, 3GP, QuickTime

• Video Codecs: AVI, MKV, HEVC, H264/MPEG-4 AVC,
MPEG-1, MPEG-2, MPEG-4, VP9, HEVC (H.265), AV1

43

20

Help and Support

reconnected to the power supply, the startup screen
is displayed at the next startup. To turn on the TV
from standby, press power key on the remote control
or on the TV.

20.1

Register your TV

Register your TV and enjoy a range of benefits
including full support (including downloads),
privileged access to information about new products,
exclusive offers and discounts, the chance to win
prizes and even participate in special surveys about
new releases.

Go to www.philips.com/TVsupport

20.2

Troubleshooting

Switch On and Remote Control

The TV does not switch on

• Disconnect the power cable from the power outlet.
Wait for one minute then reconnect it.

• Make sure that the power cable is securely
connected.

Creaking sound at startup or switch off

When you are turn the TV on, off or to standby, you
hear a creaking sound from the TV chassis. The
creaking sound is due to the normal expansion and
contraction of the TV as it cools and warms up. This
does not affect performance.

The standby light keeps on blinking

Disconnect the power cable from the power outlet.
Wait 5 minutes before you reconnect the power
cable. If the blinking reoccurs, contact Philips TV
Consumer Care.

Channels

No digital channels found during the installation

See the technical specifications to make sure that
your TV supports digital channels in your country.
Make sure that all cables are properly connected and
that the correct network is selected.

Previously installed channels are not in the channel
list

Make sure that the correct channel list is selected.

PIN Code

The PIN code can be set to lock channels or protect
against unauthorized operations, e.g. the TV being
reinstalled or the PIN code being reset. If you forget
your PIN code, you can override the current one by
using the code 8888 and entering a new one.

TV does not respond to the remote control

The TV requires some time to start up. During this
time, the TV does not respond to the remote control
or TV controls. This is normal behavior.
If the TV continues to be unresponsive to the remote
control, you can check if the remote control is working
by means of a mobile phone camera. Put the phone
in camera mode and point the remote control to the
camera lens. If you press any key on the remote
control and you notice the infra red LED flicker
through the camera, the remote control is working.
The TV needs to be checked.
If you do not notice the flickering, the remote control
might be broken or its batteries are low.
This method of checking the remote control is not
possible with remote controls which are wirelessly
paired with the TV.

The TV goes back to standby after showing the
Philips startup screen

When the TV is in standby, a Philips startup screen is
displayed, then the TV returns to standby mode. This
is normal behavior. When the TV is disconnected and


No picture/distorted picture

• Make sure that the antenna is properly connected to
the TV.

• Make sure that the correct device is selected as the
display source.

• Make sure that the external device or source is
properly connected.

Sound but no picture

• Change to other video sources and then change
back to current source, then do picture style restore in
Picture settings or do Factory reset in General settings
option.

Poor antenna reception

• Make sure that the antenna is properly connected to
the TV.

• Loud speakers, unearthed audio devices, neon
lights, high buildings and other large objects can
influence reception quality. If possible, try to improve
the reception quality by changing the antenna
direction or moving devices away from the TV.

• If reception on only one channel is poor, fine-tune

44

this channel with Manual Installation.

Poor picture from a device

• Make sure that the device is connected properly.
Make sure the device's output video setting is the
highest possible resolution if applicable.

• Restore picture style or change to other picture
styles.

Picture settings change after a while

Make sure that Retail mode is set to Off . You can
change and save settings in this mode.

A commercial banner appears
Make sure that Retail mode is set to Off . Press

Home > Settings > Device Preferences > Retail
mode and press OK

Picture does not fit the screen

• Change to a different picture format.

• Change Display mode to Automatic.

Picture position is incorrect

• Picture signals from some devices may not fit the
screen correctly. Check the signal output of the
connected device.

• Change Display mode to Automatic.

Computer picture is not stable

• Make sure that your PC uses the supported
resolution and refresh rate.

• Make sure HDMI video source is not supported HDR
content.

Sound

No sound or poor sound quality

If no audio signal is detected, the TV automatically
switches the audio output off — this does not indicate
malfunction.

• Make sure that the sound settings are correctly set.

• Make sure that all cables are properly connected.

• Make sure that the volume is not muted or set to
zero.

• Make sure that the TV audio output is connected to
the audio input on the Home Theater System.
Sound should be heard from the HTS speakers.

• Some devices may require you to manually enable
HDMI audio output. If HDMI audio is already enabled,
but you still do not hear audio, try changing the digital
audio format of the device to PCM (Pulse Code
Modulation). Refer to the documentation
accompanying your device for instructions.

HDMI and USB

HDMI

• Note that HDCP (High-bandwidth Digital Content
Protection) support can delay the time taken for a TV
to display content from an HDMI device.

• If the TV does not recognize the HDMI device and
no picture is displayed, switch the source from one
device to another and back again.

• If the picture and sound of a device connected to
HDMI is distorted, connect the device to another
HDMI port on TV and power reboot your source
device.

• If there are intermittent sound disruptions, make
sure that output settings from the HDMI device are
correct.

• If you use an HDMI-to-DVI adaptor or HDMI-to-DVI
cable, make sure that an additional audio cable is
connected to AUDIO IN (mini-jack only), if available.

HDMI EasyLink does not work

• Make sure that your HDMI devices are HDMI-CEC
compatible. EasyLink features only work with devices
that are HDMI-CEC compatible.

No volume icon shown

• When an HDMI-CEC audio device is connected and
you use the TV Remote Control to adjust the volume
level from the device, this behavior is normal.

Photos, videos and music from a USB device do not
show

• Make sure that the USB storage device is set to Mass
Storage Class compliant, as described in the storage
device's documentation.

• Make sure that the USB storage device is compatible
with the TV.

• Make sure that the audio and picture file formats are
supported by the TV.

Choppy playback of USB files

• The transfer performance of the USB storage device
may limit the data transfer rate to the TV which
causes poor playback.

Network

Wi-Fi network not found or distorted

• Microwave ovens, DECT phones or other Wi-Fi

802.11b/g/n devices in your proximity might disturb
the wireless network.

• Make sure that the firewalls in your network allow
access to the TV's wireless connection.

• If the wireless network does not work properly in
your home, try the wired network installation.

Internet does not work

• If the connection to the router is OK, check the
router connection to the Internet.

The PC and Internet connection are slow

• Look in your wireless router's user manual for

45

information on indoor range, transfer rate and other
factors of signal quality.

• Use a high-speed (broadband) Internet connection
for your router.

DHCP

• If the connection fails, you can check the DHCP
(Dynamic Host Configuration Protocol) setting of the
router. DHCP should be turned on.

your question directly or send a question by email.
You can download new TV software or the manual to
read on your computer.

20.4

Support and Repair

For support and repair, call the Consumer Care
hotline in your country. Our service engineers will take
care of a repair, if necessary.

Bluetooth

Unable to pair

• Make sure the device is in pairing mode. Read the
user manual of the device.

• Keep the wireless speaker as close to the TV as
possible.

• Trying to pair several devices with the TV at the
same time may not work.

Bluetooth lost connection

• Always position the wireless speaker within a range
of 15 feet from the TV.

Bluetooth Audio and Video synchronization

• Before you purchase a wireless Bluetooth speaker,
learn about its quality of Audio to Video
synchronization, commonly called 'lip sync.' Not all
Bluetooth devices perform correctly. Ask your dealer
for advice.

Wrong Menu Language

Find the telephone number in the printed
documentation that came with the TV.
Or consult our
website www.philips.com/TVsupport and select
your country if needed.

TV model number and serial number

You might be asked to provide the TV product model
number and serial number. Find these numbers on
the packaging label or on the type label on the back
or bottom of the TV.

Warning

Do not attempt to repair the TV yourself. This may
cause severe injury, irreparable damage to your TV or
void your warranty.

Change the language back to your language

1 - Press Home to go to Home screen.
2 - Press MENU.
3 - Press Navigation key - down for 4 times and

press OK.
4 - Press Navigation key - down for 4 times and
press OK.

5 - Select your language and press OK.
6 - Press Back or EXIT repeatedly to close the

menu.

20.3

Online Help

To solve any Philips TV related problem, you can
consult our online support. You can select your
language and enter your product model number.

Go to www.philips.com/TVsupport
On the support site you can find your country's

telephone number to contact us as well as answers to
frequently asked questions (FAQs). In some countries,
you can chat with one of our collaborators and ask

46

21

Safety and Care

21.1

Safety

Important

Read and understand all safety instructions before
you use the TV. If damage is caused by failure to
follow instructions, the warranty does not apply.

Risk of Electric Shock or Fire

• Never expose the TV to rain or water. Never place
liquid containers, such as vases, near the TV.
If liquids are spilled on or into the TV, disconnect the
TV from the power outlet immediately.
Contact Philips TV Consumer Care to have the TV
checked before use.

• Never expose the TV, remote control or batteries to
excessive heat. Never place them near burning
candles, naked flames or other heat sources,
including direct sunlight.

• Never insert objects into the ventilation slots or other
openings on the TV.

• Never place heavy objects on the power cord.

• Avoid force coming onto power plugs. Loose power
plugs can cause arcing or fire. Ensure that no strain is
exerted on the power cord when you swivel the TV
screen.

• To disconnect the TV from the mains power, the
power plug of the TV must be disconnected. When
disconnecting the power, always pull the power plug,
never the cord. Ensure that you have full access to
the power plug, power cord and outlet socket at all
times.

ensure that the power voltage matches the value
printed on the back of the TV. Never connect the TV
to the power outlet if the voltage is different.

Stability Hazards

A television set may fall, causing serious personal
injury or death. Many injuries, particularly to children,
can be avoided by taking simple precautions such as:

• ALWAYS ensure the television set is not overhanging
the edge of the supporting furniture.

• ALWAYS use cabinets or stands or mounting
methods recommended by the manufacturer of the
television.

• ALWAYS use furniture that can safely support the
television.

• ALWAYS educate children about the dangers of
climbing on furniture to reach the television or its
controls.

• ALWAYS route cords and cables connected to the
television so that they cannot be tripped over, pulled
or grabbed.

• NEVER place a television in an unstable location.

• NEVER place the television on tall furniture (for
example, cupboards or bookcases) without anchoring
both the furniture and television to a suitable support.

• NEVER place the television on cloth or other
materials that may be located between the television
and supporting furniture.

• NEVER place items that might tempt children to
climb, such as toys and remote controls, on the top of
the television or furniture on which the television is
placed.

If the existing television is going to be retained and
relocated, the same considerations as above should
be applied.

Risk of Batteries

Risk of Injury or Damage to the TV

• Two people are required to lift and carry a TV that
weighs more than 25 kg or 55 lbs.

• If you mount the TV on a stand, only use the
supplied stand. Secure the stand to the TV tightly.
Place the TV on a flat, level surface that can support
the weight of the TV and the stand.

• When wall mounted, ensure that the wall mount can
safely bear the weight of the TV set. TP Vision bears
no responsibility for improper wall mounting that
results in accident, injury or damage.

• Parts of this product are made of glass. Handle with
care to avoid injury or damage.

Risk of damage to the TV!

Before you connect the TV to the power outlet,

• Do not ingest the battery. Chemical burn hazard.

• The remote control may contain a coin/button cell
battery. If the coin/button cell battery is swallowed, it
can cause severe internal burns in just 2 hours and
can lead to death.

• Keep new and used batteries away from children.

• If the battery compartment does not close securely,
stop using the product and keep it away from
children.

• If you think batteries might have been swallowed or
placed inside any part of the body, seek immediate
medical attention.

• Risk of fire or explosion if the battery is replaced by
an incorrect type.

• Replacement of a battery with an incorrect type that
can defeat a safeguard (e.g. in the case of some
lithium battery types).

47

• Disposal of a battery into fire or a hot oven, or
mechanically crushing or cutting of a battery, that can
result in an explosion.

• Leaving a battery in an extremely high temperature
surrounding environment that can result in an
explosion or the leakage of flammable liquid or gas.

• A battery subjected to extremely low air pressure
that may result in an explosion or the leakage of
flammable liquid or gas.

Risk of Overheating

Never install the TV in a confined space. Always leave
a space of at least 10 cm or 4 in around the TV for
ventilation. Ensure curtains or other objects never
cover the ventilation slots on the TV.

21.2

Screen Care

• Never touch, push, rub or strike the screen with any
object.

• Unplug the TV before cleaning.

• Clean the TV and frame with a soft damp cloth and
wipe gently. Avoid touching the Ambilight* LEDs on
the backside of the TV. Never use substances such as
alcohol, chemicals or household cleaners on the TV.

• To avoid deformations and color fading, wipe off
water drops as quickly as possible.

• Avoid stationary images as much as possible.
Stationary images are images that remain onscreen
for extended periods of time. Stationary images
include onscreen menus, black bars, time displays,
etc. If you must use stationary images, reduce screen
contrast and brightness to avoid screen damage.

Lightning Storms

Disconnect the TV from the power outlet and antenna
before lightning storms.
During lightning storms, never touch any part of the
TV, power cord or antenna cable.

Risk of Hearing Damage

Avoid using earphones or headphones at high
volumes or for prolonged periods of time.

Low Temperatures

If the TV is transported in temperatures below 5°C or
41°F, unpack the TV and wait until the TV temperature
reaches room temperature before connecting the TV
to the power outlet.

* Ambilight LED is only for models which support
Ambilight function.

Humidity

In rare occasions, depending on temperature and
humidity, minor condensation can occur on the inside
of the TV glass front (on some models). To prevent
this, do not expose the TV to direct sunlight, heat or
extreme humidity. If condensation occurs, it will
disappear spontaneously while the TV is playing for a
few hours.
The condensation moisture will not harm the TV or
cause malfunction.

48

22

Terms of Use

2021 © TP Vision Europe B.V. All rights reserved.
This product was brought to the market by TP Vision

Europe B.V. or one of its affiliates, hereinafter referred
to as TP Vision, which is the manufacturer of the
product. TP Vision is the warrantor in relation to the
TV with which this booklet was packaged. Philips and
the Philips Shield Emblem are registered trademarks
of Koninklijke Philips N.V.

Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips N.V
or their respective owners. TP Vision reserves the right
to change products at any time without being obliged
to adjust earlier supplies accordingly.

The written material packaged with the TV and the
manual stored in the memory of the TV or
downloaded from the Philips
website www.philips.com/TVsupport are believed to
be adequate for the intended use of the system.

TP Vision is committed to developing, producing and
marketing products that cause no adverse health
effects. TP Vision confirms that, as long as its products
are handled properly for their intended use, they are
safe to use according to scientific evidence available
today. TP Vision plays an active role in the
development of international safety standards,
enabling TP Vision to anticipate further developments
in standardization for early integration in its
products.

The material in this manual is believed adequate for
the intended use of the system. If the product, or its
individual modules or procedures, are used for
purposes other than those specified herein,
confirmation of their validity and suitability must be
obtained. TP Vision warrants that the material itself
does not infringe any United States patents. No
further warranty is expressed or implied. TP Vision
cannot be held responsible neither for any errors in
the content of this document nor for any problems as
a result of the content in this document. Errors
reported to Philips will be adapted and published on
the Philips support website as soon as possible.

Terms of warranty - Risk of injury, damage to TV or
void of warranty!
Never attempt to repair the TV yourself. Use the TV
and accessories only as intended by the
manufacturer. The caution sign printed on the back of
the TV indicates risk of electric shock. Never remove
the TV cover. Always contact Philips TV Customer
Care for service or repairs. Find the telephone number
in the printed documentation that came with the
TV. Or consult our
website www.philips.com/TVsupport and select your
country if needed. Any operation expressly prohibited
in this manual, or any adjustments and assembly
procedures not recommended or authorized in this
manual, shall void the warranty.

Pixel characteristics
This TV product has a high number of color pixels.
Although it has effective pixels of 99.999% or more,
black dots or bright points of light (red, green or blue)
may appear constantly on the screen. This is a
structural property of the display (within common
industry standards) and is not a malfunction.

49

23

Copyrights

23.1

HDMI

HDMI

The terms HDMI, HDMI High-Definition Multimedia
Interface and the HDMI Logo are trademarks or
registered trademarks of HDMI Licensing
Administrator, Inc.

23.4

Wi-Fi Alliance

Wi-Fi

The Wi-Fi CERTIFIED™ Logo is a registered trademark
of Wi-Fi Alliance®.

23.2

Dolby Vision and Dolby Atmos

Dolby Vision and Dolby Atmos

Dolby, Dolby Vision, Dolby Atmos, Dolby Audio, and
the double-D symbol are registered trademarks of
Dolby Laboratories Licensing Corporation.
Manufactured under license from Dolby Laboratories.
Confidential unpublished works. Copyright ©
2012–2021 Dolby Laboratories.
All rights reserved.

23.3

23.5

Kensington

(If applicable)

Kensington and Micro Saver are registered US
trademarks of ACCO World Corporation with issued
registrations and pending applications in other
countries throughout the world.

23.6

Other Trademarks

DTS-HD

DTS-HD

For DTS patents, see http://patents.dts.com.
Manufactured under license from DTS Licensing
Limited. DTS, the Symbol, DTS and the Symbol
together, DTS-HD, and the DTS-HD logo are
registered trademarks or trademarks of DTS, Inc. in
the United States and/or other countries. © DTS, Inc.
ALL RIGHTS RESERVED.

All other registered and unregistered trademarks are
the property of their respective owners.

50

24

Disclaimer regarding services and/or software offered by third parties

Services and/or software offered by third parties may
be changed, suspended or terminated without prior
notice. TP Vision does not bear any responsibility in
these sorts of situations.

51

Index

A

Age Rating 15
Android Settings 24
Apps 25
Audio Language 32

B

Bluetooth 21
Bluetooth, Devices 21
Bluetooth, Remove device 21
Bluetooth, Select device 21

C

Channel 14
Channel Install, Antenna 12
Channel List 14
Channel List sorting 15
Channel, age rating 15
Channel, switch to a channel 15
Channel, TV guide 36
Connectivity Guide 17
Consumer Care 46
Contact Philips 46

D

Display Mode 28
Disposal of TV or batteries 42

E

Eco Settings 30
End of use 42

F

Factory Reset 32

H

Home 4

I

Input blocked 15

L

Lock channel 15

M

Media 34
Media files, from a USB drive 34

Problems, Channel 44
Problems, Connection, Internet 45
Problems, Connection, Wi-Fi 45
Problems, HDMI Connection 45
Problems, Picture 44
Problems, Remote control 44
Problems, Sound 45
Problems, USB Connection 45
Problems, Wrong menu language 46
Product Fiche 42

R

Recording 37
Register your product 44
Repair 46

S

Safety Instructions 47
Screen care 48
Search for a Channel 14
Set PIN Code 15
Software, Update 41
Sound Mode 29
Sound, style setting 29
Support, online 46
Switching On 11

T

Troubleshooting 44
TV guide 36
TV Guide Data 36
TV placement 6
TV, standby 11

U

USB Hard Drive, disk space 20
USB Hard Drive, Install 19

V

Viewing distance 6

W

Watch TV 15
Wi-Fi 23
Wired connection 23
Wireless connection 23

N

Network connection 23
Network, setting 24
Network, Wired 23
Network, Wireless 23

O

Online support 46

P

Parental Controls 15
Parental Rating 15
Pause TV 37
Photos, Videos and Music 34
Picture Setting 28
Picture, picture format 28
Power cable 6

52

Powered by TCPDF (www.tcpdf.org)

53
