Philips 55BDL4550D/00 leaflet

Page 1

Philips Signage Solutions D-Line Display

Chasing innovation

55"

55BDL4550D

Amaze your guests with a smarter, faster signage display. With integrated WiFi and designed for running Android apps, it's the next evolution in signage solutions

Innovative solutions for any signage application

• Save and play content with internal memory

• Integrated dual-band WiFi

• Android SoC processor. Native and web apps

Maximising the impact of your message

• CMND: Take control of your displays

• Manage settings of multiple displays with CMND & Control

• Create and update content with CMND & Create

• Connect and control your content via the cloud

Care about you, your business and your audience

• Keep your content up and running with FailOver

• Ensure your content is running with automatic screenshots

• SmartPower for energy saving

Expand your viewing experience

• ADS wide-view panel display

Page 2

55BDL4550D/00

D-Line Display

55" Powered by Android, 500 cd/m²

Highlights

Control your display via an Internet c

onnection. Android-powered Philips Professional Displays are optimised for native Android apps and you can install web apps directly to the display too. A new Android 8 OS ensures the software is kept secure and stays up to date with the latest specification for longer.

Internal Memory

Save and play content with internal memory. Upload your media into the display and playback content immediately. Working in conjunction with the internal browser, it also serves as a memory cache when streaming online content. If the network ever fails, the internal memory keeps content running by playing a cached version of the content, ensuring that your media stays up even if the network goes down.

FailOver

Keeping your content up and running is critical for demanding commercial applications. While it is unlikely you will face a content disaster, FailOver provides content protection with a revolutionary technology that plays back-up content on screen in the event of a media player failure. FailOver automatically kicks in when the primary input fails. Simply select a primary input connection and a FailOver connection and you're ready for instant protection.

SmartPower

CMND and Create

Design and create compelling content with CMND & Create, a powerful authoring tool. With a drag and drop interface, preloaded templates, and integrated widgets, you'll be able to amaze your customers with compelling content. Available in portrait and landscape mode.

CMND and Control

With CMND & Control, easily manage multiple displays in a central location. With real time display monitoring, setting and software updates from a remote location, and the ability to customise and configure multiple displays at once, such as video wall or menu board displays, controlling your suite of displays has never been easier.

Proof of Play

Content is king, and with the automatic s

creenshot feature, you can make sure that your content is up and running at all times. Screenshots are taken throughout the day, which are then stored in the FTP server. From there, the screenshots can be viewed no matter when, or where you are.

The backlight intensity can be controlled and pre-set by the system to reduce the power consumption by up to 50%, which saves substantially on energy costs.

CMND

A robust display management platform, CMND puts the power back into your hands. Update and manage content with CMND & Create or control your settings with CMND & Control. It's all possible with CMND.

ADS wide-view panel display

Be seen from any angle with ADS wide-view t

echnology. Advanced Super Dimension Switch delivers faster on-display picture processing for smoother content transitions, remarkable image accuracy and superior colour reproduction with 180 degree viewing.

SmartBrowser

Connect and control your content via the cloud w

ith the integrated HTML5 browser. Using the Chromium-based browser, design your content online and connect either a single display or your complete network. Show content in both landscape and portrait mode, with fullHD resolution. Simply connect the display to the Internet using WiFi or with an RJ45 cable, and enjoy your own curated playlists.

Page 3

55BDL4550D/00

D-Line Display

55" Powered by Android, 500 cd/m²

Specifications

Picture/Display

• Diagonal screen size: 54.6 inch / 138.7 cm

• Panel resolution: 3840 x 2160

• Optimum resolution: 3840 x 2160 @ 60 Hz

• Brightness: 500 cd/m²

• Contrast ratio (typical): 5000:1

• Aspect ratio: 16:9

• Response time (typical): 8 ms

• Pixel pitch: 0.315 × 0.315 mm

• Display colours: 1.07 Billion

• Viewing Angle (H / V): 178 / 178 degree

• Operating system: Android 8.0

• Dynamic contrast ratio: 500,000:1

• Panel technology: VA

• Picture enhancement: 3/2 - 2/2 motion pull down, 3D Co contrast enhancement, Motion compens. deinterlacing, Progressive scan

lter, 3D MA deinterlacing, Dynamic

mbfi

Connectivity

• Video input: Display Port1.2 (x 1), DVI-I (x 1), HDMI 2.0 (x 2), USB 2.0 (x 2)

• Video output: DisplayPort 1.2 (x 1), HDMI 2.0 (x 1)

• Audio input: 3.5 mm jack

• Audio output: 3.5 mm jack

• External control: RJ45, RS232C (in/out) 2.5 mm

k, IR (in/out) 3.5 mm jack

• Wi-Fi: dual aerial 2,4Ghz and 5Ghz

Supported Display Resolution

• Computer formats

olution Refresh rate

Res 1920 x 1080 60 Hz 1680 x 1050 60 Hz 1600 x 900 60 Hz 1024 x 768 60 Hz 1280 x 1024 60 Hz 1280 x 720 60 Hz 1440 x 900 60 Hz 3840 x 2160 30, 60 Hz 640 x 480 60 Hz 800 x 600 60 Hz

deo formats

• Vi

olution Refresh rate

Res 1080i 50, 60 Hz 576p 50 Hz 576i 50 Hz 480p 60 Hz

480i 60 Hz 1080p 50, 60 Hz 2160p 24, 30, 60 Hz 720p 50,60 Hz

Dimensions

•Set dimensions (W x H x D):

1241.8 x 712.6 x 63.6 mm

• Set dimensions in inch (W x H x D): 9 x 28.20 x 2.50 inch

48.8

•Bezel width: 13.9 mm (Even bezel)

• Product weight (lb): 36.60 lb

• Product weight: 16.6 kg

• VESA Mount: 400 (H) x 400(V) mm, M6

Convenience

• Placement: Landscape (24/7), Portrait (24/7)

• Tiled Matrix: Up to 10 x 15

• Keyboard control: Hidden, Lockable

• Signal loop through: IR Loop through, DisplayPort,

• Network controllable: RS232

• Screen-saving functions: Pixel Shift, Low Bright

• Energy-saving functions: Smart Power

• WiFi protocol: a b g n, 802.1x

HDMI, R

232

Power

• Standby power consumption: 0.5 W

• Mains power: 100 ~ 240 VAC, 50 ~ 60 Hz

Consumption (Typical): 178 W

•

• Consumption (Max): 218 W

• Energy Label Class: G

Operating conditions

• Temperature range (operation): 0 ~ 40 °C

• Temperature range (storage): -20 ~ 60 °C

• Altitude: 0 ~ 3000 m

• MTBF: 50,000 hour(s)

• Humidity range (operation)[RH]: 20–80% RH (No

nden

sation)

• Humidity range (storage) [RH]: 5–95% RH (No

sation)

conden

Sound

• Built-in speakers: 2 x 10 W RMS

Accessories

• Included accessories: Quick start guide, RS232

cable, AC Power Cord, IR sensor cable (1.8 M),

mote Control and AAA Batteries

• Included Accessories: RS23 Philips logo (x 1), AC Switch Cover, USB Cover (x 1), Screws

• Stand: BM05922(Optional)

aisy-chain cable,

2 d

Multimedia Applications

• USB Playback Audio: AAC, HEAAC, MPEG

• USB Playback Picture: BMP, JPEG, PNG

• USB Playback Video: MPEG, H.26

3, H.264, H.265

Miscellaneous

• On-Screen Display Languages: English, French, German, Spanish, Polish, Turkish, Russian, Italian, Simplified Chinese, Traditional Chinese, Arabic, Japanese, Danish, Dutch, Finnish, Norwegian, Portuguese, Swedish

• Regulatory approvals: CE, RoHS, BSMI, CB, FCC,

ass A, PSB,

•Warranty: 3 year warranty

VCCI, CCC, CU, EMF, ETL

Internal Player

•CPU: 2 x A53 + 2 x A73

• GPU: ARM Mali G51

• Memory: 3 GB DDR

• Storage: 32 GB eMMc

•

Issue date 2021-09-27

Version: 6.1.1

12 NC: 8670 001 68921 EAN: 87 12581 76925 3

Specifications are subject to change without notice. Trademarks are the property of Koninklijke Philips N.V. or their respective owners.
