Philips 7400 series LCD TV with Pixel Plus 3 HD

42"

integrated digital

42PFL7403D

Be part of the action.

Experience brilliant performance with a breathtaking full HD 1080p, 100 Hz display. Combined with a powerful Pixel Plus 3 HD engine, HD Natural Motion and exciting invisible sound, this Flat TV ensures you are always part of the action.

See every detail of the action

• Pixel Plus 3 HD for most sharp and clear pictures

• Full HD LCD display, with a 1920 x 1080p resolution

• HD Natural Motion for ultra-smooth motion in Full HD movies

• 100 Hz LCD, 3 ms performance for superb motion sharpness

• 4 trillion colours processing for vivid and brilliant images

• Dynamic contrast 30000:1 for incredible rich black details

Exciting and powerful sound

• Virtual Dolby Digital for a true life audio experience

Connect, install and enjoy

• Enjoy photo and music playback via USB

• 4 HDMI inputs for full digital HD connection in one cable

• EasyLink: easy control of TV and connected device via HDMI CEC

Ready for digital

• Integrated Digital Tuner for DVB-T reception

Page 2

LCD TV with Pixel Plus 3 HD

42" integrated digital

Highlights

42PFL7403D/10

Pixel Plus 3 HD

Pixel Plus 3 HD offers the unique combination o

f ultimate sharpness, natural detail, vivid colours and smooth natural motion on all qualities of HD, standard TV signals and multimedia content for high definition displays. Each pixel of the incoming picture is enhanced to better match the surrounding pixels, resulting in a more natural picture. Artefacts and noise in all sources from multimedia to standard TV and also in highly compressed HD are detected and reduced, ensuring that the picture is clean and razor sharp.

Full HD LCD display 1920 x 1080p

The Full HD screen has the widescreen resolution of 1920 x 1080p. This is the highest resolution of HD sources for the best possible picture quality. It is fully future-proof as it supports 1080p signals from all sources, including the most recent sources such as Bluray and advanced HD game consoles. The signal processing is extensively upgraded to support this much higher signal quality and resolution. It produces brilliant flicker-free progressive scan pictures with superb brightness and colours.

HD Natural Motion

Philips invented HD Natural Motion to minimise juddering effects that are visible with movie-based picture content. The award winning algorithm estimates motion in the picture and corrects juddering movements in both broadcast and recorded movie material (such as DVD and Blu-ray Disc). The resulting smooth motion reproduction and excellent sharpness take the viewing experience to a higher level.

100 Hz LCD (3 ms)

100 Hz LCD creates extreme motion sharpness for clear and vibrant images even with fast on-screen motion. The Double Frame Rate Insertion works with a high 100 Hz refresh rate. It increases the sharpness of motion reproduction to more than twice that of conventional LCD, resulting in a performance with a response time of 3 milliseconds (measured in Perceived BlurEdge-Width: BEW). This unique Philips technology takes motion sharpness of LCD displays to an unprecedented level.

Dynamic contrast ratio 30000:1

You want the LCD flat display with the highest contrast advanced video processing combined with

and most vibrant images. Philips

unique extreme dimming and backlightboosting technology results in vibrant images. Dynamic Contrast will increase the contrast with excellent black level and accurate rendition of dark shades and colours. It gives a bright, lifelike picture with high contrast and vibrant colours.

Integrated Digital DVB-T tuner

The integrated Digital DVB-T tuner lets you receive digital additional set top box. Enjoy quality TV clutter free.

Virtual Dolby Di

Virtual Dolby Digital is a processing technology for e

nhancing surround sound effects. It will create the sensation of Dolby Pro Logic without the necessity of additional rear speakers. You become totally immersed in your television experience.

4 HDMI inputs

HDMI makes an uncompressed digital RGB conne the ultimate picture quality. HDMI intelligently communicates the highest output resolution with the source device. The HDMI input is fully backwards-compatible with DVI sources and includes digital audio. HDMI uses HDCP copy protection. With 3 HDMI inputs on the back and 1 HDMI on the side of the TV you can connect multiple HD sources, such as an HD set-top box, a Blu-ray player and game console or digital camcorder. Your TV is fully prepared for the HD future.

EasyLink

EasyLink uses the HDMI CEC industry standard proto between connected devices and the TV. With EasyLink only one remote control is needed to operate main functionalities on your TV and connected devices. EasyLink uses the standard HDMI cable to transfer system commands. It works between all electronic devices equipped with HDMI CEC.

terrestrial TV without an

gital

ction from the source to the screen for

col to share functionality

Page 3

LCD TV with Pixel Plus 3 HD

42" integrated digital

Specifications

42PFL7403D/10

Picture/Display

• Aspect ratio: Widescreen

• Brightness: 500 cd/m²

• Dynamic screen contrast: 30000:1

• Response time (typical): 3 (BEW equiv.) ms

• Viewing angle: 176º (H)/176º (V)

• Diagonal screen size: 42 inch / 107 cm

• Display screen type: LCD Full HD W-UXGA Act. ix

mat

• Panel resolution: 1920 x 1080p

• Picture enhancement: Pixel Plus 3 HD, 3/2 - 2/2

tio

n pull down, 3D Combfilter, Active Control

mo + Light sensor, Dynamic contrast enhancement, Progressive scan, 100 Hz LCD, 1080p 24/25/30 Hz

essing, 1080p 50/60 Hz processing, HD

pro Natural Motion

• Screen enhancement: Anti-Reflection coated

• Colour processing: 4 trillion colours (14-bit RGB)

Supported Display Resolution

• Computer formats

olution Refresh rate

Res 640 x 480 60 Hz 800 x 600 60 Hz 1024 x 768 60 Hz 1280 x 768 60 Hz 1360 x 768 60 Hz 1920 x 1080i 60 Hz 1920 x 1080p 60 Hz

deo formats

• Vi

Res

olution Refresh rate 480i 60 Hz 480p 60 Hz 576i 50 Hz 576p 50 Hz 720p 50, 60 Hz 1080i 50, 60 Hz 1080p 24, 50, 60 Hz 1080p 24, 25, 30 Hz

Convenience

• Child Protection: Child Lock+Parental Control

• Ease of Installation: Auto Programme Naming,

• Ease of Use: 4 favourite lists, Auto Volume Leveller

• Electronic Programme Guide: Now + Next EPG,

• Picture in Picture: Text dual screen

• Remote Control: TV

• Remote control type: RC2143605

• Screen Format Adjustments: 4:3, Auto Format,

• Teletext: 1200-page Hypertext

• Teletext enhancements: Habit Watch, Programme

• Firmware upgradeable: Firmware auto upgrade

• Multimedia: Digital media reader (browser), USB

• Smart mode: Game, Movie, Personal, Energy

tic Channel Install (ACI), Automatic

Automa Tuning System (ATS), Autostore, Fine Tuning, PLL Digital Tuning, Plug and Play

), Delt

(AVL Interface, On-Screen Display, Programme List, Settings assistant Wizard, Side Control

8-day

Mo and Heading Shift, Super Zoom, Widescreen, unscaled (1080p dot by dot)

info

wizard

autobr

ving, Standard, Vivid

a Volume per preset, Graphical User

Elec

tronic Programme Guide

vie expand 14:9, Mo

rmat

ion Line

, Firmware upgradeable via USB

eak-in

vie expand 16:9, Subtitle

Multimedia Applications

• Multimedia connections: USB

• Playback Formats: MP3, Slideshow files (.alb), JPEG ures, MPEG1, MPEG2

Still pict

Tuner/Reception/Transmission

• Aerial Input: 75 ohm coaxial (IEC75)

• TV system: DVB COFDM 2K/8K

• Video Playback: NTSC, SECAM, PAL

• Digital TV: DVB Terrestrial*

• Tuner bands: Hyperband, S-Channel, UHF, VHF

BS in, Audio L/R in,

• Other connections: Analogue S/PDIF out (coaxial), Common Interface

adphone out, USB

audio Left/Right out,

Power

• Ambient temperature: 5°C to 35°C

• Mains power: AC 220-240

• Power consumption: 206 W

• Power (Energy-saving mode): 150 W

• Standby power consumption: 0.15 W

V +/- 10%

Dimensions

• Set dimensions (W x H x D): 1046 x 644 x 88 mm

• Set dimensions with stand (H x D): 716 x 262 mm

• Weight incl. Packaging: 42 kg

• Product weight: 21 kg

• Product weight (+stand): 25.5 kg

•Box dimensions (W x H x D):

x 793 x 333 mm

• Colour cabinet: High gloss black deco front with

abinet

black c

• VESA wall mount compatible: 400 x 400 mm

Accessories

• Included accessories: Power cord, Quick start guide, User Manual, Warranty certificate, Remote Control, Batteries for remote control

•

Sound

• Output power (RMS): 2 x 15 W

• Sound Enhancement: Auto Vo Signal Processing, Dynamic Bass Enhancement, Graphic Equalizer, Smart Sound

• Sound System: Virtual Dolby Digital, BBE

lume Leveller, Digital

Loudspeakers

• Built-in speakers: 2

Issue date 2010-09-03

Version: 6.0.18

12 NC: 8670 000 36256 EAN: 87 12581 38881 2

Connectivity

• Ext 1 Scart: Audio L/R, CVBS in, RGB

• Ext 2 Scart: Audio L/R, CVBS in, RGB

• Ext 3: YPbPr, Audio L/R in, VGA PC-in

• Ext 4: HDMI v1.3

• Ext 5: HDMI v1.3

• Ext 6: HDMI v1.3

• EasyLink (HDMI-CEC): One touch play, System ontrol, System standby

dio c

• Front/Side connections: HDMI v1.3, S-video in,

Specifications are subject to change without notice. Trademarks are the property of Koninklijke Philips Electronics N.V. or their respective owners.
