Register your product and get support at
www.philips.com/welcome
Flat TV
42PFL7403
42PFL7603
47PFL7403
52PFL7803
User Manual
2007 © Koninklijke Philips Electronics N.V. All rights reserved. Specifications are subject to change
without notice. Trademarks are the property of Koninklijke Philips Electronics N.V. or their respective
owners.
Philips reserves the right to change products at any time without being obliged to adjust earlier supplies
accordingly.
The material in this manual is believed adequate for the intended use of the system. If the product, or its
individual modules or procedures, are used for purposes other than those specified herein, confirmation
of their validity and suitability must be obtained. Philips warrants that the material itself does not infringe
any United States patents. No further warranty is expressed or implied.
Warranty
No components are user-serviceable. Do not open or remove covers to the inside of the product.
Repairs may only be done by Philips Service Centres and official repair shops. Failure to do so shall void
any warranty, stated or implied. Any operation expressly prohibited in this manual, any adjustments, or
assembly procedures not recommended or authorized in this manual shall void the warranty.
Pixel characteristics
This LCD product has a high number of color pixels. Although it has effective pixels of 99,999% or more,
black dots or bright points of light (red, green or blue) may appear constantly on the screen. This is a
structural property of the display (within common industry standards) and is not a malfunction.
Compliance with EMF
Koninklijke Philips Electronics N.V. manufactures and sells many products targeted at consumers, which,
like any electronic apparatus, in general have the ability to emit and receive electromagnetic signals.
One of Philips’ leading Business Principles is to take all necessary health and safety measures for our
products, to comply with all applicable legal requirements and to stay well within the EMF standards
applicable at the time of producing the products.
Philips is committed to develop, produce and market products that cause no adverse health effects.
Philips confirms that if its products are handled properly for their intended use, they are safe to use
according to scientific evidence available today.
Philips plays an active role in the development of international EMF and safety standards, enabling Philips to
anticipate further developments in standardization for early integration in its products.
Copyright
VESA, FDMI and the VESA Mounting Compliant logo are trademarks of the Video Electronics
Standards Association.
Manufactured under license from BBE Sound, Inc. Licensed by BBE, Inc under one or more
of the following US patents: 5510752,5736897. BBE and BBE symbol are registered
trademarks of BBE Sound Inc. (Available on selected models).
® Kensington and Micro Saver are registered US trademarks of ACCO World Corporation with issued
registrations and pending applications in other countries throughout the world. All other registered and
unregistered trademarks are the property of their respective owners.
CONTENTS
Important .......................................................................... .5
Overview of television controls and connectors .... .7
Side controls ............................................................... .7
Side connectors.......................................................... .7
Rear connectors .........................................................7
Overview of remote control keys and functions .... .8
Get started ....................................................................... .10
Position the TV .......................................................... .10
Install the remote control batteries ...................... .10
Use the Source List ................................................... .11
Wall-mount the TV ................................................... .12
Secure the VESA-compatible wall bracket to the
TV .................................................................................. .13
Select your location .................................................. .14
Select your on-screen menu language (TV mode
only) .............................................................................. .14
Automatic installation .................................................... .15
Manual installation ...........................................................16
Change the Tuner Mode ...........................................16
Change the TV System ............................................. .17
Fine tune your channels ........................................... .18
Name your channels .......................................................19
Store your favorite channels ........................................ .20
Adjust your picture settings ......................................... .21
Use the Advance Picture features............................... .22
Use Contrast + .......................................................... .22
Use Active Control ................................................... .22
Use Artifacts Reduction and Dig. Natural Motion
(available in selected models) ..................................23
Adjust your sound settings ........................................... .24
Use the timer ................................................................... .25
Set the TV time .......................................................... .26
Setting the TV timer ................................................. .27
Child-lock the TV .......................................................... .29
Enable Child Lock ...................................................... .29
Disable Child Lock .................................................... .29
Control access to TV channels .....................................30
Access Parental Lock ................................................ .30
Change Access Code ................................................ .31
Lock channels ............................................................. .32
Lock all channels ........................................................ .32
Unlock all channels .................................................... .32
Control access to TV programs ...................................33
Use the movie rating lock (for certain regions
only) .............................................................................. .33
Use the TV Rating lock (For certain regions only)
....................................................................................... .35
Unblock programs ..................................................... .37
Block other programs ............................................... .37
Turn on closed captions ................................................ .38
Use the Demo modes(available on selected models)
............................................................................................. .39
Use Ambilight (available on selected models) .......... .40
Turn on Ambilight ..................................................... .40
Turn off Ambilight ..................................................... .40
Adjust brightness ....................................................... .41
Select Ambilight modes ............................................ .41
Select Ambilight color .............................................. .42
Using Custom color .................................................. .42
Set Ambilight balance ................................................ .43
Change your picture format ......................................... .44
Use Smart Mode settings .............................................. .45
Use the Surf feature ....................................................... .46
Remove channels from Surf list .............................. .46
Use your TV as a computer monitor ......................... .47
Picture settings (VGA mode) .................................. .47
Feature settings (VGA mode) ................................. .47
Use your TV in High Definition mode ....................... .48
Connect the HD equipment ................................... .48
Control the TV settings in HD mode ................... .48
Use Mode Selection (For 480p, 720p and 1080p
formats only)............................................................... .49
Use Native 1080 mode(For 1080p TV models
only) .............................................................................. .49
Use Philips EasyLink .................................................. .50
Troubleshoot ................................................................... .51
Specifications .................................................................... .53
Important
Congratulations on your purchase and welcome to Philips! To fully benefit from the support
that Philips offers, register your product at www.philips.com/welcome.
Read this user manual before you start to use this product.
In particular, pay close attention to this section and follow the safety and screen care instructions. The product warranty does not apply if damage is caused by failing to follow these
instructions.
Safety
Two people are required to lift and carry a TV that weighs more than 25 kilos (55lb). •
Improper handling of the TV can result in serious injury.
To avoid short circuit, do not expose the TV, remote control or remote control batteries •
to rain or water.
To avoid risk of fire or electric shock, do not place the TV, remote control or remote •
control batteries near naked flame sources (for example, lighted candles) and other heat
sources including direct sunlight.
Do not touch any part of the TV, power connector or antenna cable during lightning •
storms.
Do not install the TV in a confined space such as a bookcase. Leave a space of at least •
10cm (four inches) around the TV for ventilation. Be sure air flow is not obstructed.
If mounting the TV on a flat surface, be sure to use only the supplied stand and to mount •
the TV on a level, solid surface. Do not move the TV if the stand is not properly screwed
to the TV.
Wall mounting of the TV should only be performed by qualified personnel. The TV must •
only be mounted on an appropriate wall bracket and on a wall that can safely hold the
weight of the TV. Improper wall mounting can result in severe injury or damage. Do not
attempt to wall mount the TV yourself.
If the TV is mounted on a swivel base or swivel arm, ensure no strain is placed on the •
power cord when the TV is swivelled. Strain on the power cord can loosen connections
and casue arcing or fire.
Do not place the TV on the cord or anything else that can pinch the cord or loosen the •
mains plug. An improperly connected mains plug or
damaged mains cord can cause arcing, fire or electric shock.
Be sure that you have full access to the mains cord for •
easy disconnection of the TV from the mains.
When disconnecting the TV from the mains, be sure to:•
Turn off the TV, then the mains power (if available).•
Unplug the mains cord from the mains socket outlet. •
5
Important
Unplug the mains cord from the power connector at the back of the TV. Always pull the •
mains cord by the plug. Do not pull the mains cord.
Permanent hearing loss may occur if you use earphones or headphones at high volumes. •
Though high volume may sound normal over time, it can damage your hearing. To protect
your hearing, limit the amount of time you use earphones or headphones at high volume.
Although your TV consumes very little power when in standby, energy continues to be •
consumed as long as the mains remain connected and powered. When not in use for extended periods of time, switch off and disconnect the TV from the mains.
Screen care
Turn off and unplug the mains cord before cleaning the screen.•
Clean the screen with a soft, dry cloth. Do not use substances such as household cleaning •
agents as these may damage the screen.
To avoid deformations or color fading, wipe off water droplets as soon as possible.•
Do not touch, push, rub or strike the screen with hard objects as this may damage the •
screen permanently.
Where possible, avoid stationary images that remain on-screen for extended periods of •
time. Examples include screen menus, teletext pages, black bars or stock market tickers. If
you must use stationary images, reduce the screen contrast and brightness to avoid screen
damage.
Environmental care
This product is designed and manufactured for material recycling.•
Recycle the product packaging at your local recycling centre and dispose of used batteries •
according to local regulations.
Do not dispose the product with household waste. Ask your dealer for information on •
how to safely dispose of the product. Uncontrolled waste disposal harms both the environment and human health (EEC 2002/96/EC).
This TV consumes minimal energy in standby mode to minimise environmental impact. Ac-•
tive power consumption is displayed at the back of the TV.
Caution
This is Class 1 apparatus. It must be connected to a mains socket out with a protective earthing connection.
6
Overview of television controls and connectors
POWER
CHANNEL
MENU
VOLUME
1
2
3
4
HDMI 3HDMI 2
AV1 IN
RL
AUDIO IN VGASPDIF OUT
L
R
VIDEO
HDMI 1
CVI-1
L
Pr
Pb
Y
R
CVI-2
L
Pr
Pb
Y
R
SERV. CPBS SX
TV ANTENNA
75X
Side controls
VOLUME + / -1.
To increase or decrease volume.
MENU2.
To display the on-screen menus or to
exit from the on-screen menus.
The CH + /- buttons can be used to
navigate the menu items.
The VOLUME + / - buttons can be used
to select the menu items.
CHANNEL + / -3.
To select the TV channel.
POWER 4. .
To turn off or turn on the TV.
Side connectors
Use the side connectors for mobile devices
such as a digital camera or game console.
You can also connect a pair of headphones.
Rear connectors
Use the rear connectors for antenna and
permanent devices such as a high-definition
disc player, DVD player or VCR.
NOTE:
For more information about TV connections,
see the Quick Start Guide.
7
Overview of remote control keys and functions
1
2
3
4
5
6
7
8
9
10
11
12
13
14
POWER1. .
To switch the TV to standby mode if it
is already turned on. Or to turn on TV
when it is in standby mode.
SOURCE2.
To display the input source list or to
cycle through list of input sources by
repeatedly pressing button.
AMBILIGHT MODE3.
To select or cycle through the available
Ambilight modes. Not applicable on all
models.
AMBILIGHT ON/OFF4.
To turn on or turn off Ambilight.
Not applicable on all models.
TIMER5.
To activate the Timer menu.
SLEEP6.
To switch to standby after a specified
delay.
INCREDIBLE SURROUND7.
To enable Incredible Surround in stereo
mode and Spatial in mono mode.
CURSOR8.
To navigate and select menu items and
adjust individual settings
BACK9.
To return to the previous menu.
MENU10.
To switch the menu on or off.
VOL11. (Volume + / -)
To turn up or turn down the sound level.
STATUS / EXIT14.
To display information on the current
channel or to exit on-screen menus.
MUTE12.
To turn the speaker sound on or off.
Numeric (13. 0-9)
To enter channel number, set time or
timer.
8
Overview of remote control keys and functions
15
16
17
18
19
20
21
22
23
SAP15.
To select SAP, Stereo or Forced
Mono.
CC16. (Closed caption)
To display current closed caption setting
or cycle through list.
SURF17.
To channel surf up to 8 channels.
CHANNEL LIST18.
To display the list of available channels.
FORMAT19.
To cycle through a selection of picture
formats.
OK20.
To select menu items or confirm a
selection.
SMART MODE21.
To select or cycle through predefined
picture and sound settings.
CH22. (Channel + / -)
To select the channel number upwards or
downwards.
A/CH23. (Alternate Channel)
To display the last viewed channel and
the current channel.
NOTE:
Press u to select menu items or confirm
your selection. Alternatively, press Æ.
For brevity, only u is mentioned in the User
Manual.
9
Get started
If necessary, refer to the Quick Start Guide for
stand mounting instructions.
Position the TV
In addition to reading and understanding the
safety instructions at the beginning of the
user manual, consider the following before
positioning your TV:
The ideal viewing distance for watching •
TV is three times its screen size.
Position the TV where light does not fall •
directly on the screen.
Connect your devices before you posi-•
tion your TV.
Your TV is equipped with a Kensington •
Security Slot at the back of the TV.
If connecting an anti-theft Kensington
lock (not supplied), position the TV
within reach of a permanent object (such
as a table) that can be easily attached to
the lock.
For the best Ambilight effect, position •
the TV 10cm (four inches) to 20cm (eight
inches) away from the wall. Ambilight also
works best in a room with dim lighting.
Install the remote control
batteries
Slide the battery cover off the back of the 1.
remote control.
Insert the two supplied batteries. Be sure 2.
the + and - ends of the batteries line up
with the markings inside the case.
Slide the cover back into position.3.
NOTE:
Remove the batteries if not using the remote
control for an extended period of time.
10
Get started
Source List
Source List
TV
HDMI 1
HDMI 2
HDMI 3 *
A V
SIDE AV
CVI 2
CVI 1
VG A
* Not available on all models
Source List
Source List
A V
SIDE AV
CVI 2
CVI 1
VG A
* Not available on all models
HDMI 1
HDMI 2
HDMI 3 *
Side HDMI *
Use the Source List
The Source List lets you select the audio and
video source that your device is connected
to.
Press 1. SOURCE to display the audio and
video source list.
Press 2. ï or Î to highlight your AV
source.
Press 3. u to select your AV source.
The TV displays the AV source.
Source list:
TV• : Normal TV broadcast via the 75-
ohm antenna connector.
AV• : Composite video and audio output.
SIDE AV• : Headphone jack, Composite
video and audio, and S-Video input.
CVI 1• : Component video (Y Pb Pr) with
Component audio input.
CVI 2• : Component video (Y Pb Pr) with
Component audio input.
VGA• : Video Graphics Array with audio
input.
HDMI 1• : High Definition Multimedia
Interface input.
HDMI 2• : High Definition Multimedia
Interface input.
HDMI 3 *• : High Definition Multimedia
Interface input.
Side HDMI *• : High Definition Multime-
dia Interface input.
Refer to Quick Start Guide for connection
instructions.
* Available on selected models.
11
Get started
Wall-mount the TV
WARNING:
Wall mounting the TV should only be
performed by qualified installers. Koninklijke
Philips Electronics N.V. bears no responsibility for improper mounting that results in
accident or injury.
Purchase a VESA-compatible wall bracket 1.
Depending on the size of your TV screen,
purchase one of the following wall
brackets:
Remove the TV stand.2.
NOTE:
These instructions are only applicable to
TV models with mounted stands. If your
TV stand is not mounted, skip to Secure the
VESA-compatible wall bracket to the TV.
Carefully place the TV face down on a 3.
flat, stable surface that is covered by soft
cloth. The cloth should be thick enough
to protect your screen.
Using a cross-head screwdriver (not 4.
supplied), unscrew the four screws that
secure the stand to the TV.
Firmly pull the stand from the bottom of 5.
the TV. Place both the stand and screws
in a secure location for future reinstallation.
12
Get started
x4
Secure the VESA-compatible wall
bracket to the TV
Connect the antenna cable, mains cord and
all other devices to the back of the TV as
described in the Quick Start Guide.
Locate the four mounting nuts at the back 1.
of the TV.
Align the plate/bracket to the four 2.
mounting nuts, placing the spacers (not
supplied) between the plate/bracket and
the mounting nuts.
Using a spanner, insert the bolts through
the plate/bracket and spacers, tightly
securing the bolts to the mounting nuts.
Continue with the instructions provided 3.
with your VESA-compatible wall bracket.
WARNING:
Use the correct bolts and spacers (see table)
to secure the VESA-compatible wall bracket
to your TV.
NOTE:
Depending on your VESA-compatible wall
bracket, you may need to separate the
mounting plate from the wall bracket for
easier installation. Refer to your VESAcompatible wall bracket documentation for
instructions.
TV screen
size (in /cm)
32” / 82cm Adjustable 300 x 300. 4 of M6 x 10mm steel bolt
42” / 107cm
or larger
VESA-compatible wall
bracket (mm)
Fixed 400 x 400. 4 of M8 x 15mm steel bolt
Bolt and spacer type Special instructions
or
4 of M6 x 50mm steel bolt
with 40mm spacer.
or 4 of M8 x 55mm steel
bolt with 40mm spacer.
13
Adjust bracket to
200 x 300
before securing to
the TV.
None.
Get started
Install
Language
Tuner Mode
Auto Program
Manual
Name
Fav. Program
English
Español
Português
Main
Picture Setting
Advance Picture
Sound
Ambilight*
Features
Install
Location
Language
Tuner Mode
Auto Program
Manual
Name
Fav. Program
* Not available on all models
Install
Language
Tuner Mode
Auto Program
Manual
Name
Fav. Program
English
Español
Português
Location
Home
Shop
Please select location
to continue
Select your location
When you switch on your TV for the first
time, the on-screen display will prompt you
to select your location.
Press 1. Î or ï to select Home or Shop.
Press 2. u to confirm your choice.
Select your on-screen menu
language (TV mode only)
Before using the on-screen menus, select
your menu language.
Press 1. H to display the on-screen menus.
Press 2. ï until Install is highlighted.
Press 3. u to select Language.
The available languages are displayed.
Press 4. u to highlight the first language
or press ï to select the other available
languages.
Press 5. u to select the Language.
Press 6. H to exit.
14
Automatic installation
Main
Picture Setting
Advance Picture
Sound
Ambilight*
Features
Install
Location
Language
Tuner Mode
Auto Program
Manual
Name
Fav. Program
* Not available on all models
Install
Language
Tuner Mode
Auto Program
Manual
Name
Fav. Program
Press OK
to continue
Auto Program
Program 3
TV 196 MHz
Press 1. H to display the on-screen menus.
Press 2. ï until Install is highlighted.
Press 3. u to select Install.
Press 4. ï until Auto Program is
highlighted.
Press 5. u to start Auto Program.
Auto Program starts scanning for
channels automatically. When scanning
is complete, the first installed channel
displays on-screen.
Press 6. H to exit.
TIP:
To cancel or interrupt auto searching, press
H. Only channels that were found
before interruption are stored.
15
Manual installation
Main
Picture Setting
Advance Picture
Sound
Ambilight*
Features
Install
Location
Language
Tuner Mode
Auto Program
Manual
Name
Fav. Program
* Not available on all models
Install
Language
Tuner Mode
Auto Program
Manual
Name
Fav. Program
Auto
Antenna
Cable
You can manually set the TV tuner and
system as well as fine tune the channels.
Change the Tuner Mode
If you have problems using Auto Program
to search for channels, you can manually set
the tuner system.
Press 1. H to display the on-screen menus.
Press 2. ï until Install is highlighted.
Press 3. u to select Install.
Press 4. ï until Tuner Mode is highlighted.
Press 5. u to select Tuner Mode.
Press 6. ï or Î to select Auto, Antenna
or Cable.
Press 7. u to select the option.
Press 8. H to exit.
Tuner Modes:
Auto• : The TV automatically detects if the
cable signal input is present.
Antenna• : The TV detects antenna signals
and searches for all antenna TV channels
available in your local area.
Cable• : The TV detects cable signals and
searches for all cable TV channels available in your local area.
16
Manual installation
Main
Picture Setting
Advance Picture
Sound
Ambilight*
Features
Install
Location
Language
Tuner Mode
Auto Program
Manual
Name
Fav. Program
* Not available on all models
Install
Language
Tuner Mode
Auto Program
Manual
Name
Fav. Program
System
Fine Tune
Manual
System
Fine Tune
Auto
NTSC
PAL-M
PAL-N
Change the TV System
Press 1. H to display the on-screen menus.
Press 2. ï until Install is highlighted.
Press 3. u to select Install.
Press 4. ï until Manual is highlighted.
Press 5. u to select Manual.
Press 6. u to select System.
Press 7. ï or Î to select Auto, NTSC,
PAL-M or PAL-N.
Press 8. u to select the option.
Press 9. H to exit.
TV Systems:
Auto• : Detects the tuner system auto-
matically.
NTSC• : For North American and some
South American countries.
PAL-M• : For Brazil.
PAL-N• : For Argentina, Uruguay and
Paraguay.
17
Manual installation
Main
Picture Setting
Advance Picture
Sound
Ambilight*
Features
Install
Location
Language
Tuner Mode
Auto Program
Manual
Name
Fav. Program
* Not available on all models
Manual
System
Fine Tune
Install
Language
Tuner Mode
Auto Program
Manual
Name
Fav. Program
System
Fine Tune
Fine tune your channels
You can fine tune the channels after you have
searched them automatically by using the
Fine Tune feature.
Switch to the channel number that you want
to fine tune.
Press 1. H to display the on-screen menus.
Press 2. ï until Install is highlighted.
Press 3. u to select Install.
Press 4. ï until Manual is highlighted.
Press 5. u to select Manual.
Press 6. ï until Fine Tune is highlighted.
Press 7. u to select Fine Tune.
The Fine Tune level bar is displayed.
Press 8. ï or Î to manually fine tune the
channel reception.
Press 9. H to exit.
18
Name your channels
Main
Picture Setting
Advance Picture
Sound
Ambilight*
Features
Install
Location
Language
Tuner Mode
Auto Program
Manual
Name
Fav. Program
* Not available on all models
Main
Picture Setting
Advance Picture
Sound
Ambilight*
Features
Install
Location
Language
Tuner Mode
Auto Program
Manual
Name
Fav. Program
* Not available on all models
Install
Language
Tuner Mode
Auto Program
Manual
Name
Fav. Program
001
002
003
004
005 SPORT
006
007
008
You can assign a short name for your
channels with the Name feature. This is
available in TV mode only.
Press 1. H to display the on-screen menus.
Press 2. ï until Install is highlighted.
Press 3. u to select Install.
Press 4. ï until Name is highlighted.
Press 5. u to select the first channel
number on the list.
Press 6. u to start naming the channel.
Press 7. Æ until a rectangular block cursor
appears next to the channel number.
Press 8. ï or Î to cycle through the list
(A-Z, 0-9) to select the characters or
numbers to use for the channel name.
Press 9. u to move the cursor to the second space and assign the next character
or number.
You can use up to 5 characters or numbers to name your channels.
Press 10. u to store the name of the
channel.
The channel number and name are
displayed on the top left of the screen.
Press 11. H to exit.
19
Store your favorite channels
Main
Picture Setting
Advance Picture
Sound
Ambilight*
Features
Install
Location
Language
Tuner Mode
Auto Program
Manual
Name
Fav. Program
* Not available on all models
Install
Language
Tuner Mode
Auto Program
Manual
Name
Fav. Program
001
002
003
004
005
006
007
008
Install
Language
Tuner Mode
Auto Program
Manual
Name
Fav. Program
001
002
003
004
005
006
007
008
The Fav. Program feature lets you store
only the channels you want on an easily accessible favorite list.
Press 1. H to display the on-screen menus.
Press 2. ï until Install is highlighted.
Press 3. u to select Install.
Press 4. ï until Fav. Program is highlighted.
The list of channel numbers is displayed
on the right panel.
All channel numbers with a tick () are
marked as favorite channels.
Press 5. u to select the first channel
number on the list, or press ï to move
down the list.
Press 6. u to remove the tick or add the
tick to the corresponding number.
Only channel numbers with the tick are
added to your favorite list. When you
use the CH + / - buttons on the remote
control, only your favorite channels are
accessible.
Press 7. H to exit.
TIP:
Press the numeric (0-9) to access channels
not on the favorite list.
20
Adjust your picture settings
Main
Picture Setting
Advance Picture
Sound
Ambilight*
Features
Install
Location
Brightness
Color
Contrast
Sharpness
Tint
Color Temp
* Not available on all models
Picture Setting
Brightness
Color
Contrast
Sharpness
Tint
Color Temp
Picture Setting
Brightness
Color
Contrast
Sharpness
Tint
Color Temp
Cool
Normal
Warm
The Picture menu lets you adjust the
picture settings.
Press 1. H to display the on-screen menus.
Press 2. u to select the Picture Setting.
Press 3. ï or Î to highlight the
menu items.
Press 4. u to select the menu item.
Press 5. ï or Î to adjust the settings of the
menu items.
Depending on which setting you are
adjusting, some items will have the
level indicator bar while some will have
discreet settings such as Cool, Normal
and Warm.
Press 6. H to exit.
Picture settings:
Brightness• : Adjusts the brightness.
Color• : Adjusts color saturation.
Contrast• : Adjusts the contrast.
Sharpness• : Adjusts the detail level of the
picture.
Tint• : Adjusts the detail of the skin tones
of the picture. (TV or AV modes only)
Color Temp• : Sets the color to Cool
(more blue), Normal (balanced) or
Warm (more red).
21
Main
Picture Setting
Advance Picture
Sound
Ambilight*
Features
Install
Location
* Not available on all models
Contrast +
Active Control
Artifacts Reduction*
Dig. Natural Motion*
Use the Advance Picture features
Main
Picture Setting
Advance Picture
Sound
Ambilight*
Features
Install
Location
Contrast +
Active Control
Artifacts Reduction*
Dig. Natural Motion*
* Not available on all models
Advance Picture
Contrast +
Active Control
Artifacts Reduction*
Dig. Natural Motion*
* Not available on all models
Off
On
Use Contrast +
Contrast + optimizes the contrast for overall
picture quality.
Press 1. H to display the on-screen menus.
Press 2. ï until Advance Picture is
highlighted.
Press 3. u to select Advance Picture.
Press 4. u to select Contrast +.
Press 5. ï or Î to highlight Off or On.
Press 6. u to confirm your choice.
Press 7. H to exit.
Use Active Control
Active Control is a unique and intelligent way
of optimizing picture quality by measuring
and analyzing the incoming signal to automatically adjust picture quality settings.
Press 1. H to display the on-screen menus.
Press 2. ï until Advance Picture is
highlighted.
Press 3. u to select Advance Picture.
Press 4. ï until Active Control is
highlighted.
Press 5. u to select Active
Control.
Press 6. ï or Î to highlight Off, On or On
+ Light Sensor.
Press 7. u to confirm your choice.
Press 8. H to exit.
22
Advance Picture
Contrast +
Active Control
Artifacts Reduction*
Dig. Natural Motion*
* Not available on all models
Off
On
On + Light Sensor
Advance Picture
Contrast +
Active Control
Artifacts Reduction*
Dig. Natural Motion*
* Not available on all models
Off
On
On + Light Sensor
Use the Advance Picture features
Advance Picture
Contrast +
Active Control
Artifacts Reduction*
Dig. Natural Motion*
* Not available on all models
Off
On
Advance Picture
Contrast +
Active Control
Artifacts Reduction*
Dig. Natural Motion*
* Not available on all models
Off
On
Active Control settings
Off• : Turns off Active Control.
On• : Turns on Active Control.
On + Light Sensor• : Uses a sensor to
adjust the picture brightness depending
on the room light conditions.
Use Artifacts Reduction and Dig.
Natural Motion
(available in selected models)
Artifacts Reduction smoothens the transitions on digital pictures.
Dig. Natural Motion reduces the field and
line flicker and reproduces smooth movement especially in movies.
Press 1. H and select Advanced Picture.
Press 1. ï until Artifacts Reduction or
Dig. Natural Motion is highlighted.
Press 2. u to select Artifacts
Reduction or Dig. Natural Motion.
Press 3. ï or Î to highlight Off or On.
Press 4. u to confirm your choice.
Press 5. H to exit.
23
Adjust your sound settings
Sound
Equalizer
Balance
Auto Vol. Leveler
Incr. Surround
120 HZ
200 HZ
500 HZ
1200 HZ
3000 HZ
12000 HZ
7500 HZ
BBE
SAP
Forced Mono
Equalizer
120Hz
200Hz
500Hz
1200Hz
3000Hz
7500Hz
12000Hz
Sound
Equaliser
Balance
Auto Vol. Leveler
Incr. Surround
BBE
Off
On
Forced Mono
SAP
Sound
Equaliser
Balance
Auto Vol. Leveler
Incr. Surround
BBE
Mono
Spatial
Forced Mono
SAP
The Sound menu lets you adjust the various
sound settings.
Press 1. H to display the on-screen menus.
Press 2. ï to highlight the Sound menu.
Press 3. u to select the Sound menu.
Press 4. ï or Î to highlight the menu items.
Press 5. u to select the Sound menu item.
Press 6. ï or Î to adjust the settings of the
menu items.
Depending on which Sound item you are
adjusting, some items will have the level
indicator bar, some have discreet settings
such as Mono, Spatial, or On and Off.
Press 7. H to exit.
Sound settings:
Equalizer• : Adjusts each individual fre-
quency (tone).
Balance• : Adjusts the left and right
speaker sound level.
Auto Vol• . Leveler: Controls sudden
sound level increase when changing
channels or during advertisement slots.
Incr• . Surround: Enhances stereo effect.
Select Incr. Surround or Stereo (when
in stereo mode) or Mono or Spatial
(when in mono mode).
BBE• : Restores clarity and presence for
better speech intelligibility and musical
realism.
SAP• (Secondary Audio Programming):
Activates alternative languages or commentary.
Forced Mono• : Select Off to leave
broadcast signal as is. Select On to force
the signal to mono.
NOTE:
Select Stereo or Incr. Surround modes
when the TV broadcast is in stereo. You can
also press f to toggle the sound modes.
24
Use the timer
Main
Picture Setting
Advance Picture
Sound
Ambilight*
Features
Install
Location
Timer
Child Lock
Parental Lock
* Not available on all models
Closed Caption
Demo*
Features
Timer
Child Lock
Parental Lock
Sleep
Time
Start Time
Stop Time
Channel No.
Activate
Closed Caption
Demo*
* Not available on all models
Timer
Sleep
Time
Start Time
Stop Time
Off
15
30
45
60
90
120
180
Channel No.
Activate
The timer feature switches the TV to standby
mode or switches the TV to a specified channel at a specified time from standby mode or
while the TV is already switched on.
Set the sleeptimer
Press 1. H to display the on-screen menus.
Press 2. ï until Features is highlighted.
Press 3. u to select the Features.
Press 4. u to select Timer.
Press 5. u to select Sleep.
The right panel displays the sleep timer
settings: Off, 15, 30, 45, 60, 90, 120,
and 180 minutes.
Press 6. ï or Î to select the number of
minutes remaining before the TV automatically switches to standby mode.
Press 7. u to confirm the setting.
Press 8. H to exit.
TIP:
Press STATUS / EXIT to check if the
sleeptimer is enabled or how much time
remaining for the TV to switch to standby
mode.
The status is displayed on the bottom of the
screen.
To cancel the sleeptimer, select Off in the
Sleep menu.
25
Use the timer
Features
Timer
Child Lock
Parental Lock
Sleep
Time
Start Time
Stop Time
Channel No.
Activate
Closed Caption
Demo
Timer
Sleep
Time
Start Time
Stop Time
Channel No.
Activate
10 : 45
Main
Picture Setting
Advance Picture
Sound
Ambilight*
Features
Install
Location
Timer
Child Lock
Parental Lock
* Not available on all models
Closed Caption
Demo*
Set the TV time
Press 1. H to display the on-screen menus.
Press 2. ï until Features is highlighted.
Press 3. u to select the Features.
Press 4. u to select Timer.
Press 5. ï to highlight Time.
Press 6. u to select the Time menu.
Press the numeric (7. 0-9) buttons of the
remote control to enter the time in the
24-hour format. For example, 13:00 (for
1.00 p.m).
Press 8. H to exit.
26
Using the timer
Timer
Sleep
Time
Start Time
Stop Time
Channel No.
Activate
20 : 00
Timer
Sleep
Time
Start Time
Stop Time
Channel No.
Activate
21 : 40
Timer
Sleep
Time
Start Time
Stop Time
2
Activate
Channel No.
Features
Timer
Child Lock
Parental Lock
Sleep
Time
Start Time
Stop Time
Channel No.
Activate
Closed Caption
Demo*
Setting the TV timer
Press 1. H to display the on-screen menus.
Press 2. ï until Features is highlighted.
Press 3. u to select the Features.
Press 4. u to select Timer.
Press 5. ï to highlight Start Time.
Press 6. u to select Start Time.
Press the numeric (7. 0-9) buttons of the
remote control to enter the time in the
24-hour format. For example, 13:00 (for
1.00 p.m).
Press 8. H to exit.
Press 9. Í to return to the Timer menu.
Press 10. ï until Stop Time is highlighted.
Press 11. u to select Stop Time.
Press the numeric (12. 0-9) to enter the
time.
Press 13. Í to return to the Timer menu.
Press 14. ï until Channel No. is highlighted.
Press 15. ï or Î to select the channel
number to be activated at the specified
time.
Press 16. Í to return to the Timer menu.
Press 17. ï to highlight Activate.
27
Use the timer
Timer
Sleep
Time
Start Time
Stop Time
Off
Once
Daily
Channel No.
Activate
Press 18. u to select Activate.
Press 19. ï or Î to select Off, Once or
Daily.
Press 20. u to select the option.
Press 21. H to exit.
Press 22. . to switch the TV to standby
mode.
Activate settings:
Off• : Cancels the TV timer.
Once• : Activates TV timer once only.
Daily• : Activates TV timer everyday at
this time.
NOTE:
If the TV is switched on when the timer •
activates, the TV switches to the channel
specified in the TV timer.
TV timer settings are lost once the TV is •
switched off by POWER button.
28
Child-lock the TV
Main
Picture Setting
Advance Picture
Sound
Ambilight*
Features
Install
Location
Timer
Child Lock
Parental Lock
* Not available on all models
Closed Caption
Demo*
Features
Timer
Child Lock
Parental Lock
Off
On
Closed Caption
Demo*
Features
Timer
Child Lock
Parental Lock
Off
On
Closed Caption
Demo*
Use the Child Lock feature to prevent
children from accessing the TV without adult
supervision.
Enable Child Lock
Press 1. H to display the on-screen menus.
Press 2. ï until Features is highlighted.
Press 3. u to select Features.
Press 4. ï until Child Lock is highlighted.
Press 5. u to select Child Lock.
Press 6. ï or Î to highlight On.
Press 7. u to enable Child Lock.
Switch off the TV or put it on standby 8.
mode.
NOTE:
Once Child Lock has been enabled, you
cannot access any TV channels with the
CH + / - buttons on the TV panel or operate any of its buttons except the POWER
button.
The TV displays “Locked” on the bottom of
the screen.
Keep the remote control away from children
to prevent them from using it to by-pass
Child Lock.
Disable Child Lock
Repeat Steps 1 to 5 from 1. Enable Child
Lock.
Press 2. ï or Î to highlight Off.
Press 3. u to disable Child Lock.
29
Control access to TV channels
Features
Timer
Child Lock
Parental Lock
Access Code
- ---
Closed Caption
Demo*
* Not available on all models
Features
Timer
Child Lock
Parental Lock
Incorrect
* ***
Closed Caption
Demo*
* Not available on all models
Parental Lock
Lock Channel
Change Code
Clear All
Lock All
Movie Rating
TV Rating
Block Options
002
003
004
005
006
007
008
009
Features
Timer
Child Lock
Parental Lock
New Code
Closed Caption
Demo*
* Not available on all models
Features
Timer
Child Lock
Parental Lock
Confirmed
* ***
Closed Caption
Demo*
* Not available on all models
The Parental Lock feature lets you control
the type of TV programs that can be
accessed with according to program ratings
based on age and content.
Access Parental Lock
Before you can use the Parental Lock
features, enter your Access Code.
Press 1. H to display the on-screen menus.
Press 2. ï until Features is highlighted.
Press 3. u to select Features.
Press 4. ï until Parental Lock is highlighted.
Press 5. u to select Parental Lock.
If you are using Parental Lock for the first
time, you must enter the factory default
code, 0711.
Enter 6. 0711 with the numeric (0-9)
buttons.
Incorrect is displayed.
Enter 7. 0711 again.
New Code is displayed after entering
the code.
Enter your own four digit code. 8.
You are prompted to confirm your new
code.
Enter your new code again. 9.
Confirmed is displayed after entering
the code.
You can access the Parental Lock menu
now.
30
Control access to TV channels
Parental Lock
Lock Channel
Change Code
Clear All
Lock All
Movie Rating
TV Rating
Block Options
- ---
Parental Lock
Lock Channel
Change Code
Clear All
Lock All
Movie Rating
TV Rating
Block Options
New Code
- ---
Parental Lock
Lock Channel
Change Code
Clear All
Lock All
Movie Rating
TV Rating
Block Options
Confirm Code
* ***
Parental Lock
Lock Channel
Change Code
Clear All
Lock All
Movie Rating
TV Rating
Block Options
Confirmed
* ***
Change Access Code
Access the 1. Parental Lock menu as
described in Access Parental Lock.
Press 2. ï to highlight Change Code.
Press 3. u to select Change Code.
You are prompted to enter your new
access code.
Enter your new four-digit access code 4.
with the numeric (0-9) buttons.
You are prompted to confirm the new
access code.
Re-enter your new access code. 5.
Once the system verifies your new
code, Confirmed is displayed for a few
seconds.
TIP:
If you forget your access code, repeat all the
steps from Access Parental Lock.
31
Control access to TV channels
Channel 2
Blocked By
Channel Blocking
Access Code : ----
Parental Lock
Lock Channel
Change Code
Clear All
Lock All
Movie Rating
TV Rating
Block Options
002
003
004
005 +
006
007
008
009
Parental Lock
Lock Channel
Change Code
Clear All
Lock All
Movie Rating
TV Rating
Block Options
Yes
Locked
Parental Lock
Lock Channel
Change Code
Clear All
Lock All
Movie Rating
TV Rating
Block Options
Yes
Cleared
Lock channels
Access the 1. Parental Lock menu as
described in Access Parental Lock.
Press 2. u to select Lock Channel.
The list of all the available channels are
displayed on the right panel.
Press 3. Î or ï to highlight the channel
number.
Press 4. u to lock the channel.
A padlock symbol + is displayed beside
the channel number to indicate the channel is locked.
Lock all channels
Access 1. Parental Lock menu as described in Access Parental Lock.
Press 2. ï to highlight Lock All.
Press 3. u to select Lock All.
Press 4. u to select Yes.
All the channels are now locked.
Unlock all channels
Access 1. Parental Lock menu as described in Access Parental Lock.
Press 2. ï to highlight Clear All.
Press 3. u to select Clear All.
Press 4. u to select Yes.
All the channels are now locked.
NOTE:
A message is displayed to inform you
that the channel is blocked when you try
to access it. You can choose to enter
the Parental Lock access code to view
the program.
32
Control access to TV programs
Main
Picture Setting
Advance Picture
Sound
Ambilight*
Features
Install
Location
Timer
Child Lock
Parental Lock
* Not available on all models
Closed Caption
Demo*
Parental Lock
Lock Channel
Change Code
Clear All
Lock All
Movie Rating
TV Rating
Block Options
G
PG
PG-13
R
NC-17
X
Parental Lock
Lock Channel
Change Code
Clear All
Lock All
Movie Rating
TV Rating
Block Options
G
PG
PG-13
R �
NC-17 �
X �
Use the movie rating lock
(for certain regions only)
You can control access to movies based on
their content as defined by the Motion
Picture Association of America (MPAA).
Your TV is equipped with a computer chip
(V-chip) which can block program content
based on their rating.
Settings apply to the TV and AV inputs only.
Access 1. Parental Lock menu as described in Access Parental Lock.
Press 2. ï until Movie Rating is highlighted.
Press 3. u to select Movie Rating.
The list of movie rating labels are displayed on the right panel.
Press 4. ï or Î to highlight your choice of
movie rating label.
Press 5. u to enable the rating.
A tick () appears beside the rating
label to indicate the rating lock has been
enabled.
The rating labels below the one you
select are also enabled.
Movie Rating:
G• : Suitable for all ages.
PG• : Some material may not be suit-
able for children.
PG-13• : Some material may not be
suitable for children under 13 years
of age.
R• : Material not suitable for children
under 17 years of age. Requires parental guidance.
NC-17• : Not suitable for children
under 17 years of age. Has excessive
violence, sex or offensive language.
X• : Not suitable for children under 17
years of age. Content is pornographic.
Press 6. Í to return to the Parental Lock
menu.
33
Control access to TV programs
Movie Rating
Movie Rat
G
X
PG
PG - 13
R
TV Rating
i
ng
Ins
TV Rating
TV - Y
TV - PG
TV - 14
TV - MA
Unrated
No Rating
TV - Y7
TV - G
NC - 17
NOTE:
Movies are blocked if they fall under the
movie rating category that you enabled.
A message is displayed to inform you that
the program has been blocked by the movie
rating.
Programs remain locked even after the TV
has been switched off.
You can choose to enter the Parental Lock
access code to view the program.
Subsequently, all other locked programs will
be viewable.
TIP:
Press STATUS / EXIT twice to check
which TV or movie ratings are enabled.
The Movie Rating and TV Rating lists are
displayed.
34
Control access to TV programs
Main
Picture Setting
Advance Picture
Sound
Ambilight*
Features
Install
Location
Timer
Child Lock
Parental Lock
* Not available on all models
Closed Caption
Demo*
Parental Lock
Lock Channel
Change Code
Clear All
Lock All
Movie Rating
TV Rating
Block Options
TV-Y
TV-Y7
TV-G
TV-PG
TV-14
TV-MA
Use the TV Rating lock
(For certain regions only)
Your TV is equipped with a computer chip
(V-chip) that can block content based on TV
ratings defined by your broadcaster. TV ratings are based on age and content.
Age-based rating Content-based rating
TV-Y
TV-Y7
TV-G
TV-PG
TV-14
TV-MA
Access 1. Parental Lock menu as described in Access Parental Lock.
None
FV (Fantasy Violence)
None
V (Violence)
S (Sex)
L (Strong Language)
D (Sexual Dialog)
V (Violence)
S (Sex)
L (Strong Language)
D (Sexual Dialog)
V (Violence)
S (Sex)
L (Strong Language)
TV-Y: Suitable for all children. Programs
are not expected to frighten children.
TV-Y7: For children 7 years or older
who can tell make-believe from reality.
Some mild fantasy violence or comedic
violence. Programs may frighten younger
children under 7 years of age.
TV-Y7 FV: Fantasy violence more
intense or combative than those in TV-Y7
category.
TV-G: Suitable for all children but not
designed specifically for children.
TV-PG: Parental guidance needed. Some
violence, strong language, sexual
situations or suggestive dialog. Parents
should watch these programs with their
children.
TV-14: Not suitable for children under
14 years of age. Content has violence,
strong language, sexual situations or
suggestive dialog.
TV-MA: For adult viewing. Not suitable
for children under 17 years of age.
Press 2. ï until TV Rating is highlighted.
Press 3. u to select TV Rating.
The list of TV rating labels is displayed on
the right panel.
Press 4. ï or Î to highlight your choice of
TV rating label.
Some of the age-based ratings have
content-based sub ratings.
Press 5. u to select the age-based rating.
35
Control access to TV programs
TV Rating
TV-Y
TV-Y7
TV-G
TV-PG
TV-14
TV-MA
Lock All �
V �
S
L
D
�
�
�
TV Rating
TV-Y
TV-Y7
TV-G
TV-PG
TV-14
TV-MA
Lock All
V
S
L
D
Channel 5
Blocked By
TV - 14
Access Code : ----
Press 6. ï or Î to highlight Lock All.
Press 7. u to enable Lock All.
A tick () appears beside the rating label
to indicate the rating lock is enabled.
Where content-based rating labels are
present, they are also enabled (with a tick
beside them).
To enable one or more content-based
ratings, highlight only those and press u.
NOTE:
The screen displays a message to inform
you that the program is blocked when your
programs fall under the TV rating category
that you enabled.
Even if you turn off and turn on the TV again,
the programs remain locked. You can choose
to enter the your access code to view the
program.
36
Control access to TV programs
Block Options
Unrated
No Rating
Blocking
Off
On
Block Options
Unrated
No Rating
Blocking
Off
On
Block Options
Unrated
No Rating
Blocking
Off
On
Channel 5
Blocked By
No rating
Access Code : ----
Unblock programs
Press 1. u to select Block Options.
Press 2. ï or Î to highlight Off.
Press 3. u to enable Block Options.
Block other programs
You can also block programs that are
unrated, such as documentaries, “director’s
cut” edition or programs that have no advisory data (No Rating).
Access 1. Parental Lock menu as described in Access Parental Lock.
Press 2. ï until Block Options is highlighted.
Press 3. u to select Block Options.
Press 4. ï or Î to highlight Unrated or
No Rating.
Press 5. u to select Unrated or No Rat-
ing.
Press 6. u to highlight On.
Press 7. u to enable Unrated or No
Rating.
NOTE:
Programs with no rating or unrated are
blocked.
37
Turn on closed captions
Main
Picture Setting
Advance Picture
Sound
Ambilight*
Features
Install
Location
Timer
Child Lock
Parental Lock
* Not available on all models
Closed Caption
Demo*
Features
Timer
Child Lock
Parental Lock
CC Off
CC1
CC2
CC Mute
Closed Caption
Demo*
* Not available on all models
You can enable closed captions for your
programs if your broadcasting station
provides caption service.
Closed captions (CC) are subtitles hidden
in the video signals which you can turn on
or off unlike the normal subtitles you see in
movies which cannot be turned off.
Closed captions are subtitles for dialog and
descriptions (useful for the hearing-impaired).
Press 1. H to display the on-screen menus.
Press 2. ï until Features is highlighted.
Press 3. u to select Features.
Press 4. ï until Closed Caption is highlighted.
Press 5. u to select Closed Caption.
Press 6. ï or Î to highlight CC Off, CC1,
CC2 or CC Mute.
Press 7. u to select Closed Caption
option.
Press 8. H to exit.
Closed Caption choices:
CC Off• : Turn off closed captioning.
CC1• : Most channels transmit closed
captions in CC1 mode. Closed captions
can be in Spanish, Portuguese or English.
CC2• : Broadcasters may transmit closed
captions in CC2 mode. CC2 is rarely
used.
CC Mute• : Closed captions in CC1
mode is displayed only when the sound is
turned off via MUTE.
38
Use the Demo modes
Features
Timer
Child Lock
Parental Lock
Closed Caption
Demo*
Pixel Plus HD*
Pixel Plus 2HD*
* Not available on all models
Dig. Natural Motion*
100Hz*
Off
On
* Not available on all models
Dig. Natural Motion*
100Hz*
Demo
Pixel Plus HD*
Pixel Plus 2HD*
(available on selected models)
The Demo mode lets you see the benefits
of the new features of your TV.
Press 1. H to display the on-screen menus.
Press 2. ï until Features is highlighted.
Press 3. u to select Features.
Press 4. ï until Demo is highlighted.
Press 5. u to select Demo.
Press 6. ï or Î to highlight Pixel Plus
HD, Pixel Plus 2HD, Dig. Natural
Motion, and 100Hz.
Depending on your TV model, not all the
options may be available.
Press 7. u to select an option.
Press 8. ï or Î to highlight On and press
u.
When any of the demo modes are used,
the TV displays a vertical split screen with
the new features enabled on one half and
the other half without the features.
Press 9. H to exit.
Demo modes:
Pixel Plus 2HD• : Like Pixel Plus HD, but
also able to detect and reduce
artifacts and noise in your HD content
for cleaner and sharper pictures.
Pixel Plus HD• : Every pixel is improved
to match surrounding pixels for a more
natural picture. Sharpness, depth and
vivid colors are achieved from multiple
sources like HD and DVD content.
Dig. Natural Motion• : Reduces the field
and line flicker and reproduces smooth
movement especially in movies. Set the
level to Maximum, Minimum or Off.
100 Hz• : Transmitted information is
stored on a memory chip to produce
flicker-free images.
39
Use Ambilight (available on selected models)
Main
Picture Setting
Advance Picture
Sound
Ambilight*
Features
Install
Location
Ambilight
Ambilight
Ambilight
Brightness
Mode
Balance
Off
On
Ambilight
Ambilight
Brightness
Mode
Balance
Off
On
The Ambilight feature lets you watch your
programs in a unique ambience by producing
a soft, light glow from the sides of the TV.
Ambient lighting from the TV provides a
more relaxed viewing experience. The
Ambilight colors changes automatically to
match the TV images.
Turn on Ambilight
Press 1. H to display the on-screen menus.
Press 2. ï until Ambilight is highlighted.
Press 3. u to select Ambilight.
Press 4. ï or Î to highlight On.
Press 5. u to turn on Ambilight.
Press 6. H to exit.
Turn off Ambilight
Press 1. H to display the on-screen menus.
Press 2. ï until Ambilight is highlighted.
Press 3. u to select Ambilight.
Press 4. ï or Î to highlight Off.
Press 5. u to turn off Ambilight.
Press 6. H to exit.
40
Use Ambilight (available on selected models)
Main
Picture Setting
Advance Picture
Sound
Ambilight*
Features
Install
Location
Ambilight
Ambilight
Ambilight
Brightness
Mode
Balance
Ambilight
Ambilight
Brightness
Mode
Balance
Color
Relaxed
Moderate
Dynamic
Adjust brightness
Turn on Ambilight as described in 1. Turn on
Ambilight.
Press 2. ï until Brightness is highlighted.
Press 3. u to select the Brightness.
Press 4. ï or Î to adjust the ambient
brightness level.
Press 5. H to exit.
Select Ambilight modes
Turn on Ambilight as described in 1. Turn on
Ambilight.
Press 2. ï until Mode is highlighted.
Press 3. u to select the Mode.
Press 4. ï or Î to highlight the different
modes available.
Press 5. u to select the mode.
Press 6. H to exit.
Ambilight modes:
Color• : Produces constant lighting ac-
cording to the settings in the Color
menu.
Relaxed• : Reduces brightness and color
to give a more relaxed viewing experience.
Moderate• : Uses the factory-defined
brightness and color settings.
Dynamic• : The brightness and color
changes according to the picture state.
41
Use Ambilight (available on selected models)
Main
Picture Setting
Advance Picture
Sound
Ambilight*
Features
Install
Location
Ambilight
Ambilight
Ambilight
Brightness
Mode
Color
Custom Color
Balance
Warm White
Cool White
Blue
Red
Green
Yellow
Magenta
Custom
Ambilight
Ambilight
Brightness
Mode
Color
Custom Color
Balance
Palette
Saturation
Ambilight
Ambilight
Brightness
Mode
Color
Custom Color
Balance
Warm White
Cool White
Blue
Red
Green
Yellow
Magenta
Custom
Select Ambilight color
Turn on Ambilight as described in 1. Turn on
Ambilight.
Press 2. ï until Mode is highlighted.
Press 3. u to select the Mode.
Press 4. ï or Î to highlight the different
modes available.
Press 5. u to select the mode.
Press 6. ï until Color is highlighted.
Press 7. u to select the Color.
Press 8. ï or Î to highlight the color
choices available.
Press 9. u to select your color choice.
Using Custom color
Press 10. ï until Custom is highlighted.
Press 11. u to select Custom.
This enables the Custom Color menu.
Press 12. Í to highlight Color.
Press 13. ï to highlight Custom Color.
Press 14. ï or Î to highlight Palette or
Saturation.
42
Use Ambilight (available on selected models)
Custom Color
Palette
Saturation
50
Custom Color
Palette
Saturation
50
Main
Picture Setting
Advance Picture
Sound
Ambilight*
Features
Install
Location
Ambilight
Ambilight
Ambilight
Brightness
Mode
Color
Custom Color
Balance
50
Press 15. u to select Palette or Saturation.
Press 16. ï or Î to adjust the settings.
Press 17. H to exit.
Ambilight Custom colors:
Palette• : Adjusts the color mix.
Saturation• : Adjusts the color intensity
of light output.
Set Ambilight balance
The Balance menu lets you adjust the
Ambilight intensity on both sides of the
TV.
Press 1. ï until Balance is highlighted.
Press 2. u to select Balance.
Press 3. ï or Î to adjust the Balance.
Press 4. H to exit.
43
Change your picture format
You can select various screen formats to suit
the type of programs you watch.
Press 1. ë repeatedly to cycle through the
available picture formats.
Picture Formats:
4• :3: The entire picture is reproduced on
the screen with black bands on the left
and right of the screen.
Movie Expand 14• :9: The picture is
enlarged to fit horizontally, with black
bands visible at the sides of the screen.
Movie Expand 16• :9: The picture is
enlarged to fill up the screen. The top and
bottom of the picture is cropped.
Subtitle Zoom• : The 4:3 format pro-
gram is displayed on the entire screen
leaving the subtitles area visible. The top
of the picture is cropped.
Superzoom• : Removes black bands on
the sides of the screen of 4:3 format
programs.
Widescreen• : The picture is displayed in
its original proportions.
4 : 3
(Standard)
Movie Expand
14 : 9
Movie Expand
16 : 9
Subtitle
Zoom
44
Superzoom
Widescreen
(16 : 9)
Use Smart Mode settings
10%
Power
100%
0%
Personal
10%
Power
100%
0%
Pe rsonal
Smart modes are preset settings to match
the different viewing and listening environment.
Press 1. SMART MODE repeatedly to
cycle through the available settings.
The settings are displayed at the bottom
of the screen.
Smart Mode settings:
Personal• : Based on the settings you cus-
tomized in the Picture Setting menu.
Sports• : Vivid picture settings and clear
sound for high action.
Standard• : For normal TV viewing.
Movie• : Brilliant picture settings for a
cinematic experience.
Game• : Optimized for PCs and game
consoles.
Power Saver• : Eco-friendly settings to
reduce power consumption.
NOTE:
The Power meter displayed on the screen
indicates the power consumption for each
mode. For example, 10% means this mode
uses 10% of the TV’s total power
consumption.
45
Use the Surf feature
Surf
Sur
f
037
050
003
012
020
015
024
002
Surf
Sur
f
03705
0
012
020
015
024
002
003
Surf
Sur
f
037
050
012
020
015
024
002
003
Store up to 8 of your favorite channels in the
Surf list.
Add channels to your Surf list
Press the numeric (1. 0-9) buttons or
CH + / - to switch to your favorite
channel.
Press 2. SURF to display the Surf list.
You should only see one channel number
on the list. This is the same channel
number you are on.
Press 3. u to add the channel to the Surf
list.
A tick () is displayed beside the channel number to indicate that it has been
stored in the Surf list.
Repeat Steps 1 to 3 to add more channels 4.
to the Surf list.
Remove channels from Surf list
Press 1. SURF to display the Surf list.
Press 2. ï or Î to highlight the channel
number you want to remove.
Press 3. u to remove the channel from the
Surf list.
The channel number is deleted from the
list.
Repeat Steps 2 and 3 to remove more 4.
channels while the Surf list is still
displayed.
46
Use your TV as a computer monitor
Main
Picture Setting
Sound
Features
Location
Brightness
Contrast
Horizontal
Vertical
Color Temp
Main
Picture Setting
Sound
Features
Location
Timer
Child Lock
Parental Lock
Phase
Clock
Auto Adjust
Reset
Source List
Source List
TV
HDMI 1
HDMI 2
HDMI 3 *
A V
SIDE AV
CVI 2
CVI 1
VG A
* Not available on all models
Source List
Source List
A V
SIDE AV
CVI 2
CVI 1
VG A
* Not available on all models
HDMI 1
HDMI 2
HDMI 3 *
Side HDMI *
Connect the TV to a computer via the VGA
port to use your TV as a computer monitor.
NOTE:
Refer to the Quick Start Guide for connecting
the computer to your TV.
Connect your computer to the TV via 1.
the VGA cable (not supplied).
Press 2. SOURCE to display the audio and
video source list.
Press 3. ï or Î until VGA is highlighted.
Press 4. u to select VGA.
You should see your computer display on
the TV screen.
Picture settings (VGA mode)
Horizontal• : Adjusts the picture to the
left or right.
Vertical• : Adjusts the picture upwards or
downwards.
Feature settings (VGA mode)
Phase / Clock• : Fine tunes your TV to
match the computer’s display settings.
Auto Adjust• : Synchronizes the TV and
computer’s Phase/Clock rate automatically.
Reset• : Overrides with the factory default
settings.
NOTE: 1.
For supported resolutions, refer to
Specifications.
47
Use your TV in High Definition mode
Source List
Source List
A V
SIDE AV
CVI 2
CVI 1
VG A
* Not available on all models
HDMI 1
HDMI 2
HDMI 3 *
Side HDMI *
The High Definition (HD) mode lets you
enjoy clearer and sharper pictures using HD
equipment.
Connect the HD equipment
Connect the HDMI or DVI output from 1.
your HD equipment to the HDMI 1,
HDMI 2, HDMI 3 or Side HDMI
socket of the TV.
Use a DVI-to-HDMI cable if DVI output is
connected.
Connect the audio cable to the 2. L / R
audio jacks (AV) of the TV if you are
using DVI output from your HD equipment to connect to the TV.
Press 3. AV to display the Source List and
the Î or ï to select HDMI 1, HDMI 2,
HDMI 3 or Side HDMI.
Press 4. u to switch to the selected source.
Control the TV settings in HD
mode
Press 1. H to display the on-screen menus.
Press 2. Î or ï to select Picture, Sound
or Features and press u to select the
items in the menu.
Press 3. Î or ï to highlight the settings and
Í or Æ to adjust the settings.
Press 4. Í to return to the previous menu.
Press 5. H to exit.
Picture menu
The • Picture menu options are:
Brightness, Color, Contrast,
Sharpness, Horizontal, Vertical and
Color Temp.
All the options work the same way as the •
ones in Picture menu except for
Horizontal and Vertical.
Horizontal • lets you adjust the horizon-
tal position of the image.
Vertical • lets you adjust the
vertical position of the image.
Sound menu
The • Sound menu options are
Equalizer, Balance, AVL and Incr.
Surround. All the options work the
same way as the ones in the TV Sound
menu.
Features menu
The • Features menu options are Timer,
Child Lock, Parental Lock and Active
Control. All the options work the same
way as the ones in the TV Features
menu except for Mode Selection.
48
Use your TV in High Definition mode
Features
Timer
Child Lock
Parental Lock
Mode Selection
Close Caption
Native 1080
Display
Demo*
Features
Timer
Child Lock
Parental Lock
Mode Selection
Closed Caption
Display
Demo*
PC
HD
Use Mode Selection
(For 480p, 720p and 1080p formats only)
The Mode Selection options are available in
the Features menu when you connect HD
equipment via HDMI supporting resolutions
of 480p, 720p or 1080p.
You can select PC or HD mode.
Press 1. H to display the on-screen menus.
Press 2. ï until Features is highlighted.
Press 3. u to select Features.
Press 4. ï until Mode Selection is highlighted.
Press 5. u to select Mode Selection.
Press 6. ï or Î to select PC or HD
modes.
Press 7. H to exit.
Use Native 1080 mode
(For 1080p TV models only)
The Native 1080 option in the Display menu
is available when you connect HD equipment
via HDMI or Y Pb Pr supporting resolution
of 1080i.
Watch the original HD format in true resolution from the input signals.
Press 1. H to display the on-screen menus.
Press 2. ï until Features is highlighted.
Press 3. u to select Features.
Press 4. ï until Display is highlighted.
Press 5. u to select Display.
49
Use your TV in High Definition (HD) mode
Display
Native 1080
Off
On
Press 6. ï or Î to select Off or On.
Select On to watch your programs in the
original HD format (1080p).
Press 7. H to exit.
NOTE:
Your Philips TV is HDMI compliant. If you do
not get a good picture, it is not a defect of
your TV set.
Please change the video format on your
device (DVD player, cable set top box, etc)
to a standard format.
For example, you should select 480p, 576p,
720p, 1080i or 1080p for DVD players.
Use Philips EasyLink
Your TV is enabled for HDMI-CEC connections with other devices. The following
features apply to devices that are CEC-compliant and connected to your TV through an
HDMI cable.
HD format 480p 576p 720p 1080i
SD format 480i 576i
HD
format
SD
format
Non-1080p models
1080p models
480p 576p 720p 1080p 1080i
480i 576i
One-touch play
You can control your TV and the devices
with one remote control when you connect
your TV to devices that support One-touch
play. For example, when you press the play
button on your DVD remote control, your
Philips TV will automatically switch to the
correct channel to display the DVD content.
One-touch Standby
You can use your TV’s remote control to put
the devices into standby when you connect
your TV to devices that support One-touch
standby. Press and hold the
remote control for 3-4 seconds.
on the TV’s
50
Troubleshoot
NOTE:
Before calling service, refer to the troubleshooting topic for a list of symptoms and solutions
which may address your problem.
Symptoms Possible cause What should you do
No power or
indicator light.
Error message on
the screen with
HDMI connection.
No sound is
detected from the
PC.
TV does not
respond to the
remote control.
The picture is
distorted. It is
stretched out, has
short, fat, black
bars on the side
or top.
The TV is not
connected to the
power.
HDCP authentication fail.
Incorrect HDMI
port is connected.
Audio cable is
not connected.
Batteries are
installed incorrectly, or low
battery power.
Broadcast video
format.
1. Press . POWER at the right side of the TV, or
press . on the remote control.
2. Ensure the power cord is connected tightly to
the TV power connector and to the mains socket
outlet.
3. Connect the TV to a different mains socket
outlet.
1. Ensure that your HDMI cable is certified.
2. Press SOURCE on the remote control to
switch to another source and then switch back to
the HDMI source.
3. Reset the accessory device and the TV.
Turn on the TV •
Select the HDMI channel•
Turn on the accessory device•
1. Connect a DVI-HDMI cable to the correct HDMI
port on the TV.
2. Connect an audio cable to the DVI AUDIO IN
port on the TV.
3. Press SOURCE on the remote control, and
select the HDMI 3 source.
1. Ensure the indicator light on the TV blinks when
the remote control buttons are pressed.
2. Ensure that you are using the remote control
supplied with the TV.
3. Ensure that the batteries of the remote control
are inserted according to the illustration on the
remote control and that the batteries do not need
to be replaced.
1. Press FORMAT on the remote control to select
the best picture format.
2. For some accessory devices, the picture format
has to be set in the accessory device.
51
Troubleshoot
The picture is
mostly red and
green, or the picture is missing red
when the TV is
connected to an
accessory device
via component
cables.
No sound on the
TV loudspeaker.
Bad picture quality with a coaxial
connection.
No picture or
sound.
Cannot control
your TV and
connected devices
with one remote
control.
Insecure/incorrect connection.
Volume level is
set to zero.
Sound is muted. 2. Press MUTE on the remote control.
Headphones are
connected.
Audio cable is
not connected.
Accessory device
audio output setting is incorrect.
Standard definition channels are
not as clear as
high definition
channels.
Incorrect channel 1. Ensure you have selected the correct channel.
Incomplete channel installation.
1. Ensure all the connections are made according to
the color code.
2. Push the component cables all the way into the
YPbPr sockets on the TV.
1. Increase the volume.
3. Ensure the headphones are not plugged into the
TV.
4. For AV connection, ensure that the Audio L/R
cable is connected.If you are using a component
cable, ensure that you have not crossed the red
audio cable with the red video cable.
5. For HDMI connections, some accessory devices
have an HDMI audio output setting that must be
turned on for HDMI to HDMI connections.
1. Connect the devices via component or HDMI
cables.
1. If the TV receives channels via an AV connection,
set the TV to the correct source input and perform
the auto installation again.
2. If the TV is connected directly to the wall via a
coaxial connection, perform the auto-installation
again.
1. Confirm that the connected devices are EasyLink
compliant and are connected to your TV via an
HDMI cable. Not all brands of devices such as DVD
players use the same system as Philips EasyLink.
Other brands might not work with Philips EasyLink.
52
Specifications
Model no. 42PFL7403
Type 1080p 50 Hz 1080p 100 Hz
Aspect Ratio 16:9
Advance Picture Contrast +, Active Control, Dig. Natural Motion,
Ambilight No Yes
Mono/Stereo/BBE Mono, Stereo, Incredible Surround, BBE
Power output (RMS Watts) 2 x 15 W
Video modes Automatic, 4:3, Movie Expand 14:9, Movie Expand 16:9, Subtitle
PC input via HDMI, VGA
CVI In with Audio L/R 2, supporting 480i/p, 576i/p, 720p, 1080i, 1080p @24Hz-60Hz
CVBS In with audio L/R, S-Video 2 X
HDMI 4 ver1.3a HDMI supporting video: 480i/p, 576i/p, 720p, 1080i, 1080p
Digital audio out Yes, supporting AC-3 & PCM
Headphone 1 X (Side)
Operating power consumption 100-240 V, 50/60 Hz
Standby power [Watt] < 0.15w
Accessories Power cord, Quick Start Guide, User Manual, Remote control,
Set weight (kg) 20
Set weight with stand (kg) 25.5
Set dimensions
(W x H x D) mm
Set dimensions with stand
(W x H x D) mm
47PFL7403
PICTURE ENHANCEMENT
SOUND ENHANCEMENT
EASE OF USE
Zoom, Super Zoom, Wide Screen
CONNECTIONS
@24Hz-60Hz, PC-input: up to WUXGA
MISCELLANEOUS
DIMENSIONS
26 kg
33.5
1046 x 645 x 88
1163 x 712 x 104
1046 x 716 x 262
1163 x 786 x 325
42PFL7603 52PFL7803
Artifacts Reduction
AAA batteries x2
20.5 39
26 47
1046 x 645 x 108 1301 x 798 x 141
1046 x 716 x 262 1301 x 875 x 325
Specifications subject to change without notice.
53
Connect devices
HDMI 3HDMI 2
AV1 IN
RL
AUDIO IN VG ASPDIF OUT
L
R
VIDEO
HDMI 1
CVI-1
L
Pr
Pb
Y
R
CVI-2
L
Pr
Pb
Y
R
SERV. CPBS SX
TV ANTENNA
75X
R
AUDIO INSPDIF OUT
HDMI 1
CVI-1
L
Pr
Pb
Y
R
SERV. CPBS SX
TV ANTENNA
75X
R
A
UDIO INSPDIF OUT
CVI-1
Pr
Pb
Y
SERV.
C
P
BS SX
TV
ANTENN
A
7
5X
21 3 4
5
6
8 9 10
11
7
12
13
14
15
Connection overview
Antenna input1.
CVI-12.
Component video input. Y Pb Pr and
Audio L/R connectors for DVD, digital
receiver or game console, etc.
CVI-23.
Second component video input.
AVI IN4.
Composite video input to be used
together with Audio L/R connectors for
camcorder, game console, etc.
SPDIF Out5.
Digital audio out.
Audio IN for VGA6. .
Service ports7. (For service personnel)
HDMI 1 In 8.
HDMI in connector for Blu-ray Disc
player, HD digital receiver or game
cconsole, etc.
HDMI 2 In 9.
Second HDMI in connector.
HDMI 3 In 10.
Third HDMI in connector.
VGA 11.
Video Graphics connector for personal
computers.
HDMI In (Side)12.
See HDMI 1 In description.
Headphones13. (Side)
Stereo Mini Jack.
Video (Side)14.
Video input connector to be used
together with Audio L/R connectors for
camcorder, game console, etc.
S-Video (Side) 15.
S-Video input connector to be used
together with Audio L/R connectors for
camcorder, game console, etc.
54
Loading...
