Page 1

www.philips.com/support

40PFL4707

EN User Manual

ES Manual del Usuario

FR Manuel d’Utilisation

EN: For further assistance, call the customer support service in your country.

• To obtain assistance, contact Philips Customer Care Center at

México D.F. and Área Metropolitana; 58 87 97 36 Interior de la Republica; 01 800 839 19 89 Costa Rica; 01 800 052 1564 Colombia; 01 800 952 0640

ES: Para obtener más información, llame al servicio de soporte al cliente de su

país.

• Para obtener asistencia, póngase en contacto con CENTRO DE INFORMACION AL CLIENTE,

México D.F. y Área Metropolitana; 58 87 97 36 Interior de la Republica; 01 800 839 19 89 Costa Rica; 01 800 052 1564 Colombia; 01 800 952 0640

FR: Pour obtenir de l’aide supplémentaire, communiquez avec le centre de service

à la clientèle de votre pays.

• Entrez en contact avec le centre de soin de client de Philips à,

México D.F. et Área Metropolitana; 58 87 97 36 Interior de la Republica; 01 800 839 19 89 Costa Rica; 01 800 052 1564 Colombia; 01 800 952 0640

Page 2

English

Contents

1 Notice 5

2 Important 6

Positioning the TV 6 Regulatory notices 6 Environmental care 6

6 Upgrade your TV software 29

Checking your current software version 29 Upgrading the software 29

7 Connecting devices 30

Selecting your connection quality 30 Connecting your devices 30

3 Get started 7

Features 7 Supplied accessories 7 Symbols used in this User Manual 7 Attaching the base 8 Managing cables 8 Installing the remote control batteries 8 Remote control 9 Control panel 10 Terminals 10 Connecting the antenna or the cable 11 Plugging in the AC power cord 11 Initial setup 12

8 Useful tips 33

FAQ 33 Troubleshooting 33

9 Information 35

Glossary 35 Maintenance 35

10 Speciﬁ cations 36

4 Use your TV 14

Switching on your TV and putting it in standby mode 14 Adjusting volume 14 Switching channels 14 Watching channels from an external device 15 Using auto mode 15 Sleep timer 15 Freeze mode 15 Switching audio mode 16 Changing picture format 16 TV screen information 17

5 Use more of your TV 18

Displaying the main menu 18

Picture 19 Sound 20 Setup 20

Autoprogram 20 Channel list 21 Add channels 21 Antenna conﬁ rmation 21

Features 22

Caption settings 22 Child and ratings lock 23 PC settings 25 EasyLink 26 Setting your location to home 27 E-sticker 27

Language 27 USB 28

Page 3

English

Return your Product Registration Card or visit at

http://www.productrecords.com/philips/ today to get the very most from your purchase.

Registering your model with Philips makes you eligible for all of the valuable benefits listed below, so don't miss out. Complete and return your Product Registration Card at once or visit at www.philips.com/support to ensure:

*Product Safety Notification *Additional Benefits

By registering your product, you'll receive notification directly from the manufacturer - in the rare case of a product recall or safety defect.

Registering your product guarantees that you'll receive all of the privileges to which you're entitled, including special money-saving offers.

Know these safety symbols

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT

REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS

INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

The caution marking is located on the rear or bottom of the cabinet.

WARNING: To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture. Apparatus shall

not be exposed to dripping or splashing and no objects filled with liquids, such as vases, shall be placed on the apparatus.

CAUTION: To prevent electric shock, match wide blade of plug to wide slot, fully insert. ATTENTION

: Pour éviter les choc électriques,introduire la lame la plus large de la fiche dans la borne correspondante de la

prise et pousser jusqu’au fond.

Visit our World Wide Web Site at www.philips.com/support

The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the apparatus’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the apparatus.

www.CE.org/safety

Page 4

English

Important Safety Instructions

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with dry cloth.

7. Do not block any ventilation openings. Install in accordance with the

manufacturer’s instructions.

8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including ampliﬁ ers) that produce heat.

9. Do not defeat the safety purpose of the polarized or groundingtype plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not ﬁ t into your outlet, consult an electrician for replacement of the obsolete outlet.

10. Protect the power cord from being walked on or pinched

particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.

11. Only use attachments / accessories speciﬁ ed by the manufacturer.

12. Use only with the cart, stand, tripod, bracket, or

table speciﬁ ed by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart / apparatus combination to avoid injury from tip-over.

13. Unplug this apparatus during lightning storms or when unused for long periods of time.

14. Refer all servicing to qualiﬁ ed service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

Note to the CATV system installer:

This reminder is provided to call the CATV system installer’s attention to Article 820-40 of the NEC that provides guidelines for proper grounding and, in particular, speciﬁes that the cable ground shall be connected to the grounding system of the building, as close to the point of cable entry as practical.

Example of Antenna Grounding as per NEC − National Electric Code

GROUND CLAMP

ELECTRIC SERVICE EQUIPMENT

ANTENNA LEAD IN WIRE

ANTENNA DISCHARGE UNIT (NEC SECTION 810-20)

GROUNDING CONDUCTORS (NEC SECTION 810-21) GROUND CLAMPS

POWER SERVICE GROUNDING ELECTRODE SYSTEM (NEC ART 250, PART H)

Wall Mount Bracket Kit

Brand: PHILIPS

Model # Screw dimension

40PFL4707 SQM6435/17

• The recommended Wall Mount Bracket Kit (sold separately) allows the mounting of the TV on the wall.

• For detailed information on installing the wall mount, refer to the Wall Mount Instruction Book.

• P&F Mexicana is not responsible for any damage to the product or injury to yourself or others if you elect to install the TV Wall Mount Bracket or mount the TV onto the Bracket on your own.

• The Wall Mount Bracket must be installed by experts.

M6 x 1.614” (41mm)

with spacer

P&F Mexicana is not liable for these types of accidents or injury noted below.

• Install the Wall Mount Bracket on a sturdy vertical wall.

• If installed onto a ceiling or slanted wall, the TV and Wall Mount Bracket may fall which could result in a severe injury.

• Do not use screws that are longer or shorter than their speciﬁ ed length. If screws too long are used this may cause mechanical or electrical damage inside the TV set. If screws too short are used this may cause the TV set to fall.

• Do not fasten the screws by excessive force. This may damage the product or cause the product to fall, leading to an injury.

• For safety reasons use 2 people to mount the TV onto a Wall Mounting Bracket.

• Do not mount the TV onto the Wall Mounting Bracket while your TV is plugged in or Turned On. It may result in an electrical shock injury.

When installing the unit on the wall, allow this much space.

Top: 11.8 inches (30cm) Left and right side: 5.9 inches (15cm) Bottom: 3.9 inches (10cm)

Page 5

English

1 Notice

Trademarks are the property of Koninklijke Philips Electronics N.V. or their respective owners.

P&F Mexicana reserves the right to change products at any time without being obliged to adjust earlier supplies accordingly.

The material in this User Manual is believed adequate for the intended use of the system. If the product or its individual modules or procedures are used for purposes other than those speciﬁ ed herein, conﬁ rmation of their validity and suitability must be obtained. P&F Mexicana warrants that the material itself does not infringe any United States patents. No further warranty is expressed or implied.

P&F Mexicana cannot be held responsible neither for any errors in the content of this document nor for any problems as a result of the content in this document. Errors reported to P&F Mexicana will be adapted and published on the P&F Mexicana support website as soon as possible.

Pixel characteristics

This LCD product has a high number of color pixels. Although it has effective pixels of 99.999% or more, black dots or bright points of light (red, green or blue) may appear constantly on the screen. This is a structural proper ty of the display (within common industry standards) and is not a malfunction.

Warranty

No components are user serviceable. Do not open or remove covers to the inside of the product. Repairs may only be done by Service Centers and ofﬁ cial repair shops. Failure to do so shall void any warranty, stated or implied.

Any operation expressly prohibited in this User Manual, any adjustments or assembly procedures not recommended or authorized in this User Manual shall void the warranty.

Federal Communications Commission Notice

This equipment has been tested and found to comply with the limits for a Class B Digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and the receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced radio or television technician for help.

Modiﬁ cations

This apparatus may generate or use radio frequency energy. Changes or modiﬁ cations to this apparatus may cause harmful interference unless the modiﬁ cations are expressly approved in the User Manual. The user could lose the authority to operate this apparatus if an unauthorized change or modiﬁ cation is made.

Cables

Connections to this device must be made with shielded cables with metallic RFI / EMI connector hoods to maintain compliance with FCC Rules and Regulations.

Canadian notice

This Class B Digital apparatus complies with Canadian ICES-003. Standard Television Receiving Apparatus, Canada BETS-7 / NTMR-7.

All other registered and unregistered trademarks are the proper ty of their respective owners.

The terms HDMI and HDMI High-Deﬁ nition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI

Consumer Notice:

This TV has been set to maximize energy efﬁ ciency while delivering the best possible picture using the factory installed home mode settings. Changing or enabling other features in this TV (e.g. brightened backlighting) will possibly increase energy consumption beyond the original ENERGY STAR

The American Academy of Pediatrics discourages television viewing for children younger than two years of age.

Licensing LLC in the United States and other countries.

Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby Laboratories.

is a trademark of SRS Labs, Inc. TruSurround HD technology is incorporated under license from SRS Labs, Inc. SRS TruSurround HD™ creates an immersive, feature-rich surround sound experience from two speakers, complete with rich bass, high frequency detail and clear dialog.

ENERGY STAR® is a joint program of the U.S. Environmental Protection Agency and the U.S. Department of Energy helping us all save money and protect the environment through energy efﬁ cient products and practices.

qualiﬁ ed limits.

Declaration of Conformity

Trade Name : PHILIPS Responsible Party : P&F Mexicana, S.A. de C.V. Model : 40PFL4707 Address : Av. La Palma No. 6, Col. San Fernando La

Herradura, Huixquilucan Edo. de México

Telephone Number : 52 (55) 52 69 90 00

C.P. 52787

Page 6

English

2 Important

Positioning the TV

• Large screen TVs are heavy. 2 people are required to carry and handle a large screen TV.

• Make sure to hold the upper and bottom frames of the unit ﬁ rmly as illustrated.

• Install the unit in a horizontal and stable position.

• Do not install the unit in direct sunlight or in a place subject to dust or strong vibration.

• Depending on the environment, the temperature of this unit may increase slightly. This is not a malfunction.

• Avoid a place with drastic temperature changes.

• Do not place anything directly on top or bottom of the unit.

• Depending on your external devices, noise or disturbance of the picture and / or sound may be generated if the unit is placed too close to them. In this case, please ensure enough space between the external devices and the unit.

• Do not insert the AC power cord into the power socket outlet before all the connections are made.

• Ensure that you always have easy access to the AC power cord or plug to disconnect the TV from the power.

• Before you move the TV, disconnect attached cables to prevent damage to connectors.

• Be sure to unplug the AC power cord from the AC outlet before moving or carrying the unit.

Environmental care

The packaging of this product is intended to be recycled. Contact your local authorities for information about how to recycle the

packaging. For product recycling information, please visit - www.recycle.philips.com

End of life directives

Philips pays a lot of attention to produce environment-friendly products in green focal areas. Your new TV contains materials which can be recycled and reused. At the end of its life, specialized companies can dismantle the discarded TV to concentrate the reusable materials and to minimize the amount of materials to be disposed of. Please ensure you dispose of your old TV according to local regulations.

Disposal of used batteries

The batteries supplied do not contain the heavy metals mercury and cadmium. Nevertheless, in many areas batteries may not be disposed of with your household waste. Please ensure you dispose of batteries according to local regulations.

Regulatory notices

Do not place the unit on the furniture that is capable of being tilted by a child and an adult leaning, pulling, standing or climbing on it. A falling unit can cause serious injury or even death.

This apparatus should not be placed in a built-in installation such as a bookcase or rack unless proper ventilation is provided. Make sure to leave a space of 4 inches (10cm) or more around this apparatus.

to turn the unit on and go into standby mode.

Press To completely turn Off the unit, you must unplug the AC power cord. Disconnect the AC plug to shut the unit off when trouble is found or not in use. The AC plug shall remain readily available.

Never use a gas duster on this TV. The gas trapped inside of this unit may cause ignition and explosion.

CAUTION: Danger of explosion if battery is incorrectly replaced.

Replace only with the same or equivalent type.

WARNING: Batteries (battery pack or battery installed) shall not be

exposed to excessive heat such as sunshine, ﬁ re or the like.

WARNING: To prevent injury, this apparatus must be securely

attached to the furniture / wall in accordance with the instructions. Tipping, shaking, or rocking the unit may cause injur y / death.

Page 7

English

3 Get started

Features

• DTV / Analog TV / CATV

You can use your remote control to select channels which are broadcast in

Digital format and conventional Analog format. Also, cable subscribers can access their cable TV channels.

• Information display

You can display the title, contents (DTV only) and other information of the

current program on the TV screen.

• Autoprogram

This unit automatically scans and memorizes channels available in your area,

eliminating difﬁ cult setup procedures.

• Child lock

This feature allows you to block children’s access to inappropriate

programs.

• Closed Caption decoder

Built-in Closed Caption decoder displays text for Closed Caption

supported programs.

• MTS / SAP tuner

Audio can be selected from the remote control.

• Auto Standby

If there is no Input signal and no operation for 15 minutes, the unit will go

into Standby mode automatically.

• Sleep timer

You can set the unit to go into Standby mode after a speciﬁ c amount of

time.

• Choices for on-screen language

Select your on-screen language: English, Spanish or French.

• Stereo sound function

• PLL frequency synthesized tuning

Provides free and easy channel selection and lets you tune directly to any

channel using the number and decimal point “•” buttons on the remote control.

• Various adjustment for picture and sound

Customizes image quality suitable for your room and sets your sound

preference.

• EasyLink via HDMI link

EasyLink allows your other HDMI link devices to be controlled by the

HDMI cable connected to your TV.

• HDMI Input

• HDMI-DVI Input

If your video device has DVI Output jack, use an HDMI-DVI conversion

cable to connect the unit.

• Component Video Input

• PC Input

• AV Input

• USB terminal

The picture (JPEG) and video (Motion JPEG) ﬁ les stored on a USB Memory

Stick can be played back on this unit.

• Digital Audio Output

• Headphone Audio Output

Supplied accessories

User Manual Quick Start guide

Quick

Start

Remote Control and batteries (AAA, 1.5V x 2)

AAA

Cable management tie

Note

• If you lose the screws, please purchase the above-mentioned Phillips head screws at

your local store.

• If you need to replace these accessories, please refer to the part name or No. with

the illustrations and call our toll free customer support line found on the cover of this User Manual.

When using a universal remote control to operate this unit.

• Make sure the component code on your universal remote control is set to our brand.

Refer to the instruction book accompanying your remote control for more details.

• We do not guarantee 100% interoperability with all universal remote controls.

TV base and screws

Screws packed with this unit:

Model Quantity Size

40PFL4707 4 M5 x 20

AC power cord

Symbols used in this User Manual

The following is the description for the symbols used in this User Manual. Description refers to:

Digital TV operation

Analog/Cable TV operation

• If neither symbol appears, the operation is applicable to both.

Page 8

English

Attaching the base

You must attach the base to the unit to have it as a table top unit. Be sure the front and rear of the base match the proper direction. For large screen TVs, at least 2 people are required for these steps.

Managing cables

Route your antenna cable and all other cables through the cable management tie at the back of the TV. The holder helps keep your cables tidy and easily manageable.

1 Attach the cable management tie as illustrated below.

2 Pass cables through the cable management tie to avoid tangles.

Note

• Make sure to use a table which can support the weight of this unit and is larger than

this unit.

• Make sure the table is in a stable location.

• When attaching the base, ensure that “FRONT” with “arrow” written on the bottom of

the base is downward.

• When attaching the base, ensure that all screws are tightly fastened. If the base is not

properly attached, it could cause the unit to fall, resulting in injuries as well as damage to the unit.

• To remove the base from this unit, unscrew the Phillips head screws in step 2.

Be careful not to drop the base when you remove it.

Installing the remote control batteries

1 Slide the battery cover off the back of the remote control. 2 Insert the 2 supplied batteries (AAA, 1.5V). Be sure the + and −

ends of the batteries line up with the markings inside the case.

3 Slide the cover back into position.

Note

• Remove the batteries if not using the remote control for an extended period of time.

Page 9

English

Remote control

o n m

*This button does not function on this unit.

f g

a (POWER-ON / STANDBY-ON)

Press to turn the unit On and go into Standby mode. To completely

Turn Off the unit, you must unplug the AC power cord.

b SOURCE

Toggle and select connected devices.

c FORMAT

Selects a picture format.

d SAP

Digital Mode (DTV) : Press to select the Audio language. Analog Mode (Analog TV) : Press to select the Audio mode.

e FREEZE

Press to freeze screen image.

f OK

Press to decide the command of setting when the main menu is

displayed.

g ▲▼◄► (NAVIGATION buttons)

Press to move left / right / up / down through the items.

h INFO

Displays information about the TV channel or accessory device.

i CH + / − Press to select channels. 0 − 9 (NUMBER buttons)

Press to select channels.

• (DOT) Press to shift the subchannel from the main channel. PREV CH Press to return to the previously viewed channel.

j MUTE

Press to turn the sound On and Off.

k VOL + / −

Press to adjust the volume.

l MENU / EXIT

Press to display the main menu.

m BACK

Press to return to the previous menu operation.

n AUTO SOUND

Cycles through preset sound settings.

o AUTO PIC

Cycles through preset picture settings.

p SLEEP

Press to activate the sleep timer.

Page 10

English

Control panel

gef

Terminals

a VOLUME +/−

Press to adjust volume down (−) / up (+) or to move

left (−) / right (+) when selecting menu items.

b MENU

Press to display the main menu.

c CHANNEL +/−

Press to select channels or to move up ( +) / down ( −) when

selecting menu items.

d POWER

Press

POWER to Turn the unit On and go into Standby mode.

To completely Turn Off the unit, you must unplug the AC power

cord.

e Infrared sensor

Receives IR signals from remote control.

f Power On indicator

Lights up white when the unit is turned On and ﬂ ashes while the

unit is turning On.

g Ambient light sensor

Alters the brightness of the TV screen automatically by detecting

your room lighting level. Do not block the light sensor allowing it to work properly.

h Digital Audio Output jack

Digital Audio (S/PDIF) Output to home theaters and other Digital

Audio systems.

i Component (Y/Pb/Pr) / Composite Video (VIDEO) Input jacks for

VIDEO

Composite Video Input (VIDEO) jack is shared jack with

Component Video Input (Y) jack.

j Analog Audio (L/R) Input jacks

Connect Analog Audio signals from;

- HDMI-DVI / Analog Audio (L/R) jacks signal

- Component Video / Analog Audio (L/R) jacks signal

- Composite Video / Analog Audio (L/R) jacks signal

- PC Connection / Analog Audio (L/R) jacks signal with Stereo mini 3.5mm plug Audio cable on PC

k HDMI Input jack(s)

Digital audio and video Input from high deﬁ nition Digital devices

such as Blu-ray disc players, cable boxes and satellite set-top boxes.

l PC Input jack

VGA cable connection for PC.

m USB terminal

Data Input from USB Memory Stick only. Do not connect any device to this terminal such as; Digital

camera, keyboard, mouse, etc.

n 75 ohm Cable / Antenna connection

Signal Input from an antenna, cable or satellite.

o Headphone Audio Output jack

Headphone 3.5mm stereo jack for personal listening.

Page 11

antenna

RF cable

cable

set-top box

RF cable

antenna

RF cable

set-top box

HDMI cable

RF cable

set-top box

RF cable

Audio (L/R) cables

Component (Y/Pb/Pr) video cables

RF cable

cable

set-top box

Blu-ray disc/DVD recorder

Audio (L/R) + Video cables

Audio (L/R) +

Video cables

English

Connecting the antenna or the cable

Be sure your antenna or other device is connected properly before plugging in the AC power cord.

If you connect to an antenna through RF cable

Any DTV programs that are broadcasted in your area can be received for free through an antenna connection.

cable

antenna

ININ

RF cable

If you connect a set-top box through RF cable

If the TV is connected to a cable box or satellite set-top box via a coaxial connection, set the TV to channel 3, 4 or the channel speciﬁ ed by the service provider.

antenna

RF cable

ININ

OUT

RF cable

set-top box

Connecting a set-top box, Blu-ray disc / DVD recorder via composite connectors and Analog Audio

Do not place your recorder too close to the screen because some recorders can be susceptible to signals.

cable

OUT

RF cable

ININ

Audio (L/R) + Video cables

ININ

RF cable

OUT

Audio (L/R) +

Video cables

OUT

Blu-ray disc/DVD recorder

Note

• If you have any question about the DTV’s antenna, visit www.antennaweb.org for further

information.

• Depending on your antenna system, you may need different types of combiners

(mixers) or separators (splitters) for HDTV signal. The minimum RF bandpass on these devices is 2,000MHz or 2GHz.

• For your safety and to avoid damage to this unit, please unplug the RF coaxial cable

from the antenna Input jack before moving the unit.

• If you did use an antenna to receive Analog TV, it should also work for DTV reception.

Outdoor or attic antennas will be more effective than a set-top box or inside antenna.

• To Turn On your reception source easily between antenna and cable, install an antenna

selector.

• If you are not receiving a signal from your cable service, contact the Cable provider.

• Only the left loudspeaker reproduces sound for mono equipment. Use a mono to

stereo adapter (not supplied) for sound reproduction via all internal loudspeakers.

set-top box

OUT

If you connect a set-top box through HDMI

If the TV is connected to a cable box or satellite set-top box via HDMI, make sure you select the correct Source by using SOURCE.

RF cable

ININ OUT

HDMI cable

set-top box

If you connect a set-top box through Component Video Input

If the TV is connected to a cable box or satellite set-top box via Component Video Input, make sure you select the correct Component Video Source by using SOURCE.

RF cable

OUT

Audio (L/R) cables

Component (Y/Pb/Pr) video cables

OUT

OUTOUT

set-top box

Plugging in the AC power cord

Make sure that the AC power cord must be plugged to an AC outlet after all the necessary connections are made.

Caution

• Do not connect the AC power cord to a power supply outside the indicated voltage of

this unit (AC 120V).

• Connecting the AC power cord to a power supply outside of this range may result in

ﬁ re or electrical shocks.

Note

• Each time you plug in the AC power cord, no operations will be performed for a few

seconds. This is not a malfunction.

Page 12

English

These operations are accessible by remote control.

Some may also be accessible by control panel on the main unit.

Initial setup

This section will guide you through the unit’s initial setting which includes selecting a language for your on-screen menu and autoprogram, which automatically scans and memorizes viewable channels.

Before you begin:

Make sure the unit is connected to antenna or cable.

1 After making all the necessary connections, press to Turn On the

unit.

• It may take a few moments to Turn On the unit for the ﬁ rst time.

• Initial setup menu appears automatically after the unit is Turned On.

2 Use ▲▼ to select the on-screen language from the choices

(English / Español / Français) on the right side of the TV screen, then press OK.

3 Use ▲▼ to select Antenna for TV channels or Cable for CATV

channels, then press OK.

Initial setup

Make sure the antenna is connected to ‘’ANTENNA IN’’ jack. Select your signal source.

Antenna

Cable Skip

4 Use ▲▼ to select the desired location setting, then press OK.

Home is ENERGY STAR

Initial setup

qualiﬁ ed setting.

Retail

Location Home is recommended for normal home use and is ENERGY STAR qualified. In the Retail Store mode, all settings are fixed.

Select OK

• Select Retail, the unit will be set up with predeﬁ ned setting for retail displays. In this setting, the power consumption may possibly exceed the limited requirement of the ENERGY STAR qualiﬁ cation.

• Select Home, the unit is set to maximize the energy efﬁ ciency for home setting and it can be adjusted through a choice of picture and sound quality according to your preference. Use this setting to remove the E-sticker if visible from the display.

Home

➠

5 When you select Home, press OK to begin Settings assistant.

Settings assistant

Settings assistant helps you customize picture settings. You will see a series of test pictures where the right side and left side differ. Select the side that is most pleasing to you with the Left/ Right keys.

p. 27

Cable

Select OK Back Skip

ANTENNA IN

– When Antenna is selected, the TV detects antenna signals. It

searches for DTV and Analog TV channels available in your area.

– When Cable is selected, the TV detects signals supplied by cable. It

searches for DTV, Analog TV and Cable channels available in your area.

• Autoprogram will begin.

Initial setup

Please wait while the system is scanning for channels. Auto programming may take more than 20 minutes to complete.

Digital channels

Analog channels

0 ch

Skip

Next Back Exit

6 Press

or Æ 3 times to select the side of the pictures that is the

most pleasing to you, then press OK.

Left side Right side

1/3 Select the picture setting that you prefer.

Select Next Back Exit

7 Press OK to ﬁ nish Settings assistant.

Settings assistant

You have set up your viewing preferences.

Store Back Exit

• When the initial setup is completed, the lowest memorized channel with the conﬁ rmation message of the location setting will be displayed on the TV screen.

• You must set Home in step 4. Otherwise, Picture and Sound settings you adjusted will not be memorized after the unit goes into Standby mode.

Continued on next page.

Page 13

Note

• If you are not receiving a signal from your cable service, contact the Cable provider.

• If you press or MENU / EXIT during autoprogram, this setup of TV channels will be

canceled.

• The initial autoprogram function can be executed for either Antenna or Cable only

once. When you change the connection (Antenna / Cable), set Autoprogram again.

p. 20

➠

• If there is no signal Input from the antenna terminal and no operation for several

seconds after you Turn On the unit, helpful hints appears. Follow the instructions listed on the TV screen.

Initial setup

English

No channel is registered. Try Autoprogram again? Verify that you have a cable connected to the “ANTENNA IN” jack on the back of the TV, the channel installation process searches this connection. If you are using a cable or satellite box, please confirm the input which you have connected to the box and press “SOURCE” key on the remote control to select the appropriate source input.

Select OK Skip

After an initial setup is completed...

• If you want to scan the channels automatically again.

Autoprogram

• You can add the desired cable and Analog channels unmemorized by autoprogram.

Add channels

• If you want to change to another language.

Language

• If you want to change the location setting.

Location

• If you want to restore the picture setting.

Settings assistant

➠

p. 20

p. 21

p. 27

p. 19

Retry

Later

Page 14

English

4 Use your TV

Switching on your TV and putting it in standby mode

To Turn Power On or to Turn Standby On

• Press . on the side panel or the remote control.

Note

• Energy consumption contributes to air and water pollution. When the AC power

cord is plugged in, your TV consumes energy. Your TV has very low standby power consumption.

Switching channels

Adjusting volume

To increase or decrease volume

• Press VOLUME − (down) / + (up) on the side panel or press VOL + / − on the remote control.

To mute or unmute sound

• Press MUTE on the remote control to mute the sound.

• Press MUTE again or VOL + / − to recover the original sound.

To select Channels by using CHANNEL + / − or CH + / −

• Press CHANNEL + (up) / − (down) on the side panel or press CH + / − on the remote control.

To select Channels by using the NUMBER buttons

Digital TV operation

• For Digital channels, press a number followed by a dot “•” and the corresponding sub channel number.

– When selecting Digital channel 11.1

Be sure to press • before entering the subchannel number.

Analog/Cable TV operation

– When selecting cable or Analog channel 11

Press PREV CH to return to the previously viewed channel.

Note

• To select the non-memorized channels, use the NUMBER buttons.

• No Signal will appear on the TV screen after the subchannel broadcast is over.

• Audio only program message will appear on the TV screen, when you receive only

sound signal.

Page 15

English

Watching channels from an external device

Switching Each Input Mode can easily switch with the remote control between TV (DTV or Analog TV) and external devices when they are connected to the unit.

1 Turn On a set-top box or the connected device.

• The picture from your set-top box or the connected device might appear automatically on the TV screen.

If the picture does not appear

Press SOURCE repeatedly to select the set-top box or the

connected device and wait a few seconds till the picture appears.

Source TV HDMI1 HDMI2 HDMI3 Video PC

• Pressing ▲ reverses the direction of the Input modes.

e.g.)

11.1 HDMI1 HDMI2

DTV / AnalogTV

channel

Video

PC HDMI3

Component

Sleep timer

Sleep Timer can set the unit to go into Standby mode after an incremental period of time.

Press SLEEP repeatedly to change the amount of time (increases the time by 30 minutes up to 120

Sleep 120min.

minutes). Press SLEEP once to call up the display for checking the remaining time.

• To cancel sleep timer, press SLEEP repeatedly until Off is displayed.

Freeze mode

2 Use the remote control of the set-top box or the connected device

to select channels.

Using auto mode

Press AUTO PIC or AUTO SOUND to set your TV to a

predeﬁ ned picture and sound setting.

2 Use ▲▼to select one of the following settings :

Auto picture Auto sound Description

Personal

Standard

Vivid

Sports

Movie

Game -

Eco -

- Music

-News

The customized settings you deﬁ ned using the Picture and Sound menu

For normal TV viewing

Enhanced picture contrast, sharpness and sound for viewing in a well-lit room

Brilliant picture settings and clear sound for high action

Deep picture and powerful sound settings for a cinematic experience

Optimized for PCs and game consoles

Eco TV settings for low power consumption

Optimized for music playback

Controls picture tone and set the anchor's voice at a comfortable volume

Freeze Mode can freeze the image shown on the TV screen for 5 minutes.

Press FREEZE to freeze the image.

Freeze

• The sound Output will not be paused.

• To cancel freeze mode, press any buttons except

Page 16

English

Switching audio mode

Digital TV operation

1 Press SAP to display the currently selected

language and the number of available languages.

11.1

English 1/3

2 Press SAP repeatedly to cycle through the available audio languages.

Note

• Available languages differ depending on the broadcast.

• Other is displayed when the audio language cannot be acquired or the acquired

languages are other than English, French or Spanish.

Analog/Cable TV operation

1 Press SAP to display the currently selected audio mode. 2 While receiving an MTS broadcast, press

repeatedly to cycle through the available audio channels.

e.g.) When all audio are available

SAP / STEREO SAP / MONO SAP / STEREO

STEREO : Outputs stereo-audio SAP : Outputs second audio program MONO : Outputs mono-audio

SAP / STEREO

For 16:9 video signal

Normal Movie expand4:3

Full can also be selected

after Wide if an HDMI device is selected. This picture format similarly displays like Normal.

(HDMI device only)

Full

Normal

4:3

Movie expand

Zoom

Wide

Original size.

Shortened horizontally. Sidebars appear on both edges of the screen.

Vertically stretched to ﬁ ll the screen. This only crops out the top of the picture.

Maximum size without changing its horizontal and vertical ratio.

Horizontally stretched picture. This crops out the left and right sides of the picture.

Wide Zoom

For 4:3 video signal

Normal Movie expand

Full can also be selected

after Wide if an HDMI device is selected. This picture format similarly displays like 16:9.

(HDMI device only)

Full

16:9

Wide Zoom

Changing picture format

Display modes can be selected when your TV receives a 16:9 or 4:3 video signal. Three types of display modes can be selected for a PC Input signal.

Press FORMAT repeatedly to switch the TV aspect ratio.

Normal

16:9

Movie expand

Zoom

Wide

Original size. Sidebars appear on both edges of the screen.

Stretched horizontally to ﬁ ll the screen.

Stretched more vertically at the top of the screen. This crops out the top of the picture.

Maximum size that is more vertically stretched to ﬁ ll the screen. This crops out the top and bottom of the picture.

Original size and the edges stretched horizontally to ﬁ ll the screen.

For PC Input signal

Normal

•

This unit can also be connected to your PC that has a DVI terminal. Use an HDMI-DVI conversion cable for this Video connection and it requires Stereo mini 3.5mm plug Audio cable for Analog Audio signal as well.

• Refer to 16:9 video signal on this page if PC has HDMI Output.

Normal

Full

Unscaled

Proportionately stretched picture. Sidebars appear on both edges of the screen.

Stretched out of proportion to ﬁ ll the screen.

Original size.

Full

Unscaled

Page 17

English

TV screen information

You can display the currently selected channel or other information such as the aspect ratio on the TV screen.

In the Digital mode, the detailed broadcasting information for the current off the air channel such as program title and program guides are displayed.

1 Press INFO.

Digital TV operation

ab c d

A Day of Memories

A quarter-century ago,which may now qualify as the good old days of newspapering,run-of-paper sales accounted for 80 percent of the industry's advertising revenues. Department stores and supermarket were

TV: TV-14

KABC

English 1/2

1080i 16:9HD

Rating

11.1

e f

g h

a program title b program guide

(The program guide added to broadcasting information is

displayed to a maximum of 4 lines.)

c broadcast station

Analog/Cable TV operation

SAP / STEREO

480i 4:3SD

TV-PG DLSV

e f

g h

d channel number

Switching channels

➠

p. 14

e audio language (DTV) / audio mode (Analog TV)

Switching audio mode

➠

p. 16

f program’s image aspect ratio

Changing picture format

➠

p. 16

g CC (not available if Closed Caption is set to Off)

Caption settings

➠

p. 22

h child lock rating

Child and ratings lock

➠

p. 23

2 Press INFO to hide the information.

Note

• When the program guide consists of more than 4 lines, use ▲▼ to scroll to the

next / previous lines.

• No description provided. is displayed when the program guide is not provided.

• While the program guide is displayed, the Closed Caption function is interrupted.

• In external Input mode, the following screen is displayed;

e.g.) When an external device is connected to Video Input jack.

Video

480i 4:3SD

TV-PG DLSV

• The information display will automatically disappear in 5 seconds.

Page 18

English

5 Use more of your TV

This section describes the overview of the main menu displayed when you press MENU / EXIT. The main menu consists of the function setting items below.

Displaying the main menu

Press MENU / EXIT to display the main menu.

2 Use ▲▼ to select the desired menu and an item, then press OK

or use ▲▼◄► to determine the setting.


Sound Setup Features Language USB


Adjusting the picture mode or customize the picture quality as your preference.

Sound

Adjusting the sound mode, equalizer and some other sound functions.

Setup

Settings assistant Auto picture Backlight Contrast Brightness Color Tint Sharpness Advanced settings

Personal 18 50 30 30 0 2

Scanning the channels available in your area and see what the antenna levels are.

Features

Adjusting the Closed Caption, parental guide and some other useful functions.

➠

p. 19

p. 20

p. 22

Language

You can choose English, Spanish or French as your on-screen language.p

USB

You can view picture (JPEG) and video (Motion JPEG) ﬁ les stored on a USB Memory Stick.

➠

p. 27

p. 28

3 When the setting is completed, press MENU / EXIT or BACK to

exit.

Page 19


Before you begin:

You must set Home in Location. ➠ p. 27 Otherwise, personalized picture and sound settings will not be

memorized after the unit goes into Standby mode.

1 Press MENU / EXIT and use ▲▼ to select Picture then press OK.


Sound Setup Features Language USB

2 Use ▲▼◄► to select the item you want to adjust, then press

OK.

Settings assistant

Auto picture

Backlight

Contrast

Brightness

Color

Tint

Sharpness

* Advanced settings

Note

• Adjusts backlight for the best picture quality by dynamically adjusting the backlight

intensity in accordance with lighting condition in the room when Active Control is set to Ambient On. Please ensure the room lighting is stable and the light sensor is not blocked.

Settings assistant Auto picture Backlight Contrast Brightness Color Tint Sharpness

Personal 18 50 30 30 0 2

Advanced settings

to guide you through the best picture setting

to select the desired setting, then press OK (Personal, Standard, Vivid, Sports, Movie, Game and Eco) When you adjust the following settings, Personal will be set automatically.

Cursor ◄ Cursor ►

to reduce power consumption

to decrease contrast to increase contrast

to decrease brightness to increase brightness

to decrease color intensity

to add red to add green

to soften to sharpen

to select the desired setting, then press OK (Color alignment, Noise reduction, Active Control, Black stretch, Dynamic contrast and Gamma)

to set the backlight brighter

to increase color intensity

English

*You can set a particular about picture quality in Advanced settings.


Sound Setup Features Language USB

Color

alignment

Noise

reduction

Active

Control

Black

stretch

Dynamic contrast

Gamma

Color alignment Noise reduction Active Control Black stretch Dynamic contrast Gamma

Color

temperature

mode

Red gain

Green gain

Blue gain

Red offset

Green offset

Blue offset

Off

Ambient On

Ambient Off

Off

Gamma 1

Gamma 2

Gamma 3

Normal On Off On On Gamma 2

to set the color temperature to Personal, Cool, Normal and Warm When you adjust the following settings,

Personal will be set automatically.

Cursor ◄ Cursor ►

to decrease contrast with red

to decrease contrast with green

to decrease contrast with blue

to decrease brightness with red

to decrease brightness with green

to decrease brightness with blue

to set noise reduction to Off

to reduce noise in an image

to set Active Control to Off

to adjust backlight for the best picture quality by dynamically adjusting the backlight intensity in accordance with lighting condition in the room

to adjust backlight for best picture quality based on the incoming video signal

to set black stretch to Off

to enhance black color

to set dynamic contrast to Off

to enhance contrast in an image automatically

to change the gamma setting

to increase contrast with red

to increase contrast with green

to increase contrast with blue

to increase brightness with red

to increase brightness with green

to increase brightness with blue

Page 20

English

Sound

Before you begin:

You must set Home in Location. ➠ p. 27 Otherwise, personalized picture and sound settings will not be

memorized after the unit goes into Standby mode.

1 Press MENU / EXIT and use ▲▼ to select Sound, then press OK.

Picture Auto sound Standard

Sound Equalizer

Setup SRS TruSurround HD On Features Auto volume leveling Off Language TV speakers On USB Audio Setting Stereo

2 Use ▲▼◄► to select the item you want to adjust, then press

OK.

to select the desired setting, then press OK. (Personal, Standard, Vivid, Sports, Movie, Music and

Auto sound

Adjust the tonal quality for each frequency.

Equalizer

This selects sound modes for more spatial or surround sound reproduction.

SRS TruSurround HD

This function keeps a constant loudness differential between the TV commercials and the programs.

Auto volume

leveling

You can select the Audio Output from the unit’s speakers or not. If your ampliﬁ er is HDMI link function compatible and connected by an HDMI cable to this unit, some sound operations such as volume up can be changed by using this unit’s remote control. Make sure Master EasyLink is set to On.

You can set the output mode as a default for the sound mode (Analog TV only).

This setting is not interlocked when you change the output mode by pressing SAP. Refer to Switching audio mode.

Audio Setting

➠

TV speakers

News) When you adjust the following settings (Equalizer, SRS TruSurround HD and Auto volume leveling), Personal will be set automatically.

Cursor ◄ Cursor ►

to adjust the each level of tonal quality Press BACK to go back to the previous menu.

Off

p. 26

Off

Speakers EasyLink

Stereo

Mono

SAP

to set SRS TruSurround HD™ to Off

to set SRS TruSurround HD™ to On

to remove the auto volume leveling

to reduce volume differences between the TV commercials and the programs

to output sound from the unit’s speakers

not to output sound from the unit’s speakers

to control Audio Output from your connected EasyLink Compliant Devices with VOL + / − by using this unit's remote control.

p. 16

➠

to output stereo-audio

to output mono-audio

to output second audio program

Setup

Before you begin:

Make sure the unit is connected to antenna or cable.

1 Press MENU / EXIT and use ▲▼ to select Setup, then press OK.

Picture Autoprogram Sound Channel list

Setup Add channels

Features Language USB

2 Adjust the following items.

Autoprogram

Be sure the RF cable is correctly connected to this unit and you are registered with your cable TV provider when you install Cable channels.

1 Use ▲▼ to select Autoprogram, then press OK.

• If you run Autoprogram when you have locked channels, a message appears asking to enter your PIN . Enter your PIN in order to complete the installation. You need to set the channel lock again after the installation.

2 Use ▲▼ to select an appropriate option, then press OK.

– When Antenna is selected, the TV detects antenna signals.

It searches for DTV and Analog TV channels available in your area.

– When Cable is selected, the TV detects signals supplied by cable. It

searches for DTV, Analog TV and Cable channels available in your area.

Picture Sound Antenna

Setup

Features Language USB

Continued on next page.

Antenna

Autoprogram will rescan all channels. Auto programming may take more than 20 minutes to complete.

Select your signal source.

Antenna

Cable

ANTENNA IN

Back

Cable

Page 21

English

• When the scanning and memorizing are completed, the lowest memorized channel will be displayed.

Autoprogram

Please wait while the system is scanning for channels. Auto programming may take more than 20 minutes to complete.

75%

Digital channels

Analog channels

Exit

Note

• After setting Autoprogram, using CH + / − skips unavailable programs automatically.

• If you are not receiving a signal from your cable service, contact the Cable provider.

• If you press or MENU / EXIT during autoprogram, the setup of TV channels will be

canceled.

• Even if Autoprogram is completed, the channel setting will be lost if the AC power

cord is unplugged before the unit goes into Standby mode by pressing

• The PIN Code will be required once you set a PIN code in the Child and ratings lock.

p. 23

➠

• If you want to change your PIN code, follow the instruction of Change PIN.

10 ch

6 ch

➠

Channel list

p. 25

Add channels

This function lets you add the off the air Analog TV or Analog Cable channels that were not added by the autoprogram due to reception conditions during the initial setting.

1 Use ▲▼ to select Add channels, then press OK. 2 Use the NUMBER buttons to enter the number of the channel you

want to add, then press OK.

Picture Add channels Sound

Setup

Features Language USB

Note

• If setup completes successfully, Added to the channel list. is displayed.

• If external Input is used, it is not possible to register the channel and Unavailable will be

displayed on the TV screen.

• Some channels cannot be selected by CH + / −. Use the NUMBER buttons to select

the memorised channels.

For analog channels, select a channel to be added using number keys. For digital channels, you must perform Autoprogram function.

Ch Change Back

The channels selected here can be skipped when selecting the channels using CH + / −.

Those channels can still be selected with the NUMBER buttons.

1 Use ▲▼ to select Channel list, then press OK. 2 Use ▲▼ to select the channel you want to remove, then press

OK.

Picture DTV 11.1 Sound

Setup

Features Language USB

• The channel display for the removed channel darkens. You will not be able to select the channel again using CH + / −.

• To reactivate a removed channel, use ▲▼ and press OK. The registered channels are highlighted.

• When you remove a main channel, its subchannels are removed as well.

Note

Highlight channels for Ch Up / Down key selection.

Ch Select Watch / Skip Back

DTV 11.2 DTV 11.3

Antenna conﬁ rmation

Digital TV operation

This function lets you check the Digital signal strength of each channel.

1 Use ▲▼ to select Antenna, then press OK. 2 Use the NUMBER buttons or CH + / − to select the channel for

which you want to check the Digital signal strength.

Picture Sound

Setup

Features Language

Current 50

Max 50

USB

Ch Change

Note

• If the channel is set to Analog channel or external Input, you cannot conﬁ rm the

antenna condition.

Back

• The channel with DTV indicated on the display is ATSC. Otherwise the channel is

Analog TV.

Page 22

Features

So, you must b e P hi li p. Hi!

I’m p le as ed t o me et yo u .

( Background color and Background opacity)

( Font style, Font size, Font color and Font opacity)

(Edge color and Edge type)

1 Press MENU / EXIT and use ▲▼ to select Features, then press OK.

Picture Caption settings Sound Child lock Setup PC settings

Features EasyLink

Language Location Home USB

2 Adjust the following items.

Caption settings

Closed Captioning displays the audio portion of programming as text superimposed over the video.

1 Use ▲▼ to select Caption settings, then press OK.

Picture Caption service Off Sound Digital caption service Setup

Features

Language USB

E-sticker

Software upgrade

Caption style

Off

Analog/Cable TV operation

Select if you do not want caption service.

Off

CC-1

and

CC-3

Caption service

• There are 3 display modes according to programs:

Paint-on

Pop-on

Roll-up

You can choose the size, font, color, background and other characteristics of the caption text.

Caption style

and

CC-2, CC-4,

and

Displays input characters on the TV screen immediately.

Once characters are stored in memory, they are displayed all at once.

Displays the characters continuously by scrolling (max. 4 lines).

Background

The primary caption and text services. The captioning or text is displayed in the same language as the program’s dialog (up to 4

T- 1

lines of script on the TV screen).

Serve as the preferred data channels. The captioning or text is often a secondary language.

T- 3

Rarely available and broadcasters use them only in special conditions, such as when CC-1

T- 2

and CC-3 or T- 1 and T- 3 are not available.

T- 4

Font

Edge

Font style

Font size

Font color

Font opacity

Background

color

Background

opacity

Edge color

Edge type

Closed Captioning font style, size, color and transparency can be changed.

Background color and transparency of the displayed caption can be switched.

Edge color and type of the displayed caption can be switched.

English

2 Use ▲▼◄► to select the item you want to adjust, then press

OK.

Digital TV operation

In addition to the basic Closed Caption, DTV has its own Closed Caption called Digital caption service. Use this menu to change the settings for Digital caption service.

Selects if you do not want Digital

Off

caption service.

Digital caption service

CS-1 to

CS-6

Selects one of these before changing any other item in Caption settings menu. Choose CS-1 under normal circumstances.

Picture display

So, you must be Philip. Hi!

I’m pleased to meet you.

Font

( Font style, Font size, Font color and Font opacity)

Edge

(Edge color and Edge type)

Background

( Background color and Background opacity)

• Review your setting choice made below by looking in the upper right corner of the displayed setting box (not all selections show the differences selected).

Continued on next page.

Page 23

English

Note

• Digital caption service that you can switch differs depending on the broadcast

description.

• Caption style will not effect if the User setting is set to Off.

• Closed Captioning service may not be controlled by this unit’s menu options if you are

watching television through an external cable or satellite set-top box. In which case you will need to use the menu options on the external set-top box to control Closed Captioning.

• The captions do not always use correct spelling and grammar.

• Not all TV programs and product commercials include Closed Caption information.

Refer to your area TV program listings for the TV channels and times of Closed Caption shows. The captioned programs are usually noted in the TV listings with service marks such as CC.

• Not all captioning services are used by a TV channel during the transmission of a

Closed Caption program.

• Closed Caption will NOT be displayed when you are using an HDMI connection.

• To show the Closed Caption on your TV screen, broadcast signal must contain the

Closed Caption data.

• Not all TV programs and commercials have the Closed Caption or all types of the

Closed Caption.

• Captions and texts may not exactly match the TV voice.

• Changing channels may delay the Closed Caption for a few seconds.

• Adjusting or muting the volume may delay the Closed Caption for a few seconds.

• Abbreviations, symbols and other grammatical shortcuts may be used in order to keep

pace with the on-screen action. This is not a malfunction.

• The caption or text characters will not be displayed while the main menu or functions

display is shown.

• If a black box appears on the TV screen, this means that the Closed Caption is set to

the text mode. To clear the box, select CC-1, CC-2, CC-3, CC-4 or Off.

• If the unit receives poor quality television signals, the captions may contain errors or

there might be no captions at all. Some possible causes of poor quality signals are:

- Automobile ignition noise

- Electric motor noise

- Weak signal reception

- Multiplex signal reception (ghosts or screen ﬂ utter)

- Data dropout and Pixelation (for DTV only)

• The unit retains the Closed Caption setting if the power fails.

• When the unit receives special effects playback signal (e.g. Search, Slow and Still) from a

VCR’s video Output channel (ch3 or ch4), the unit may not display the correct caption or text.

Child and ratings lock

You can prevent your children from watching certain programs or certain channels by locking the TV controls and by using ratings.

1 Use ▲▼ to select Child lock, then press OK.

Picture Caption settings Sound Child lock Setup PC settings

Features EasyLink

Language Location Home USB

E-sticker

Software upgrade

Picture Channel lock Sound Setup

Features

Language USB

US movie ratings lock US TV ratings lock Canadian English rating Canadian French rating Region ratings lock Change PIN

Note

• When you select a rating and set it to or , the higher ratings will be blocked

automatically. The lower ratings will be available for viewing.

• When you set the highest rating to , all ratings turn to automatically.

• To block any inappropriate programs, set your limits in US movie ratings lock,

US TV ratings lock and Region ratings lock.

• The child lock setting will be retained after a power failure or after the power is

removed for longer than 10 seconds (except the PIN code reverts to 0000). Child and ratings lock

• Region ratings lock will be available when the unit receives a Digital broadcast using

the new rating system.

• For the United States, the unit may download the Region Ratings Lock Table, if required.

• The Canadian rating systems on this unit are based on CEA-766-A and CRTC policy.

➠

p. 23

Channel lock

Particular channels or external Input modes can be invisible in this function.

3 Use ▲▼ to select Channel lock, then press OK. 4 Use ▲▼ to select the particular channels or external Input, then

press OK repeatedly to switch between view and block.

• indicates that the channel or Input Source is locked.

• indicates that the channel or Input Source is not locked.

Picture Sound Setup

Features

Language USB

HDMI1

HDMI2

HDMI3

Video

40.1 DTV

40.2 DTV

2 Use the NUMBER buttons to enter the 4-digit numbers for your

PIN code.

• When you have not set up your PIN code, enter 0, 0, 0, 0.

• When the PIN code is correct, Child lock menu is displayed.

See the following description for setting each item.

Page 24

English

Setting US movie and TV ratings

US movie ratings lock is the rating system created by MPAA. US TV ratings lock has controlled access to individual programs based on their age ratings and content rating.

3 Use ▲▼ to select US movie ratings lock or US TV ratings lock,

then press OK.

4 Use ▲▼ to select the desired rating, then press OK repeatedly to

switch between view and block.

• For US TV ratings, you can further set the sub ratings to block speciﬁ c elements of programming.

• or indicates that the rating is locked.

• indicates that the rating is not locked.

US movie ratings lock

Picture Sound Setup

Features

Language USB

US TV ratings lock

Picture Sound Setup

Features

Language USB

All

PG-13

NC-17

All

None

TV-Y

TV-Y7

TV-G

TV-PG

TV-14

TV-MA

To set the sub ratings

As for TV-Y7, TV-PG, TV-14 or TV-MA, you can further set the sub ratings to block speciﬁ c elements of programming. To set the sub ratings, follow the step below.

Use ▲▼ ◄► to select the desired rating, then press OK repeatedly

TV-Y7

TV-PG

TV-14

TV-MA

and .

All

None

TV-Y

TV-Y7

TV-G

TV-PG

TV-14

TV-MA

(FV) Fantasy Violence

(D) Dialog (L) Language (S) Sex (V) Violence

(L) Language (S) Sex (V) Violence

to switch between

Picture Sound Setup

Features

Language USB

US TV ratings Sub Rating

Note

• Blocked sub rating will appear beside the main rating category in US TV ratings lock

menu.

• You cannot block a sub rating if the main rating is set to .

• Changing the category to or automatically changes all its sub ratings to the same

(

or ).

US movie

ratings

US TV ratings Description

All

NR None

− TV-Y

− TV-Y7

GTV-G

PG TV-PG

PG-13 −

− TV-14

R −

NC-17 −

X TV-MA

All ratings locked including no rating No rating Appropriate for all children Appropriate for all children 7 and older General audience Parental guidance suggested Unsuitable for children under 13 Unsuitable for children under 14

Restricted under 17 requires accompanying parent or adult guardian

No one under 17 admitted Mature audience only

Page 25

English

Canadian English or Canadian French ratings

You can select the rating for Canadian English or Canadian French broadcasting.

3 Use ▲▼ to select Canadian English rating or

Canadian French rating, then press OK.

4 Use ▲▼ to select the desired rating, then press OK repeatedly to

switch between view and block.

• indicates that the rating is locked.

• indicates that the rating is not locked.

Canadian

English rating

C −

C8+ −

− 8ans+

PG −

− 13ans+

14+ −

− 16ans+

18+ 18ans+

Note

• The V-Chip can block non rated programs as per “CEA-608-E sec. L.3”. If the option to

block NR, None or E programs is used in US movie ratings lock, US TV ratings lock, Canadian English rating or Canadian French rating accordingly “unusual results may occur and the unit may not receive emergency bulletins or other types of programming:” / Emergency Bulletins (Such as EAS messages, weather warnings and others) / Locally originated programming / News / Political / Public Service Announcements / Religious / Sports / Weather.

Change PIN

Although the default PIN code (0000) is supplied with the unit, you can set your own PIN code.

Canadian

French rating

All

Description

Locked all ratings Exempt program For all children For children over 8 General audience Unsuitable for ages under 8 Parental guidance suggested Unsuitable for ages under 13 Unsuitable for ages under 14 Unsuitable for ages under 16 Adult audience only

PC settings

This function lets you adjust the PC screen position, clock and phase during PC Input.

Use ◄► to adjust Clock setting to stabilize the PC screen and Phase setting to improve the clarity of the PC screen.

1 Use ▲▼ to select PC settings, then press OK.

Picture Auto adjustment Sound Setup Horizontal position 0

Features Vertical position 0

Language Clock 0 USB Phase 0

2 Use ▲▼ to select the item you want to adjust, then press OK.

• The horizontal/vertical position, clock and phase of the PC screen are automatically adjusted.

Auto adjustment

Horizontal position

Vertical position

Clock

Phase

Note

• You may not obtain an appropriate screen with Auto adjustment for some signals. In

this case, adjust the settings manually. Adjust Phase setting after Clock setting has been properly adjusted.

•

Select if you want to adjust automatically.

Cursor ◄ Cursor ►

to move PC screen left to move PC screen right

to move PC screen down to move PC screen up

to decrease setting value to increase setting value

3 Use ▲▼ to select Change PIN, then press OK. 4 Press the NUMBER buttons to enter the new 4-digit PIN code.

• Enter PIN code again in Conﬁ rm PIN. entry ﬁ eld.

Picture Sound Setup

Features

Language USB

Note

• Make sure new PIN code and conﬁ rm PIN code must be exactly the same. If they are

different, the space is cleared for reentering.

• Your PIN code will be erased and returns to the default PIN code (0000) when a

power failure occurs.

• If you forget the PIN code, unplug the AC power cord then wait for 10 seconds to plug

the AC power cord in again. The unit will restore the PIN code to 0000 as the factory default.

Enter PIN.

---Confirm PIN.

----

PIN Code Back

Page 26

English

EasyLink

This function allows you to operate the linked functions between our brand devices with a EasyLink feature and this unit connecting through an HDMI cable. You must connect this unit to our brand EasyLink devices and be sure its EasyLink setting is also set to On.

1 Use ▲▼ to select EasyLink, then press OK.

Picture Master EasyLink Sound Setup

Features

Auto device off Auto TV on Device list

Language USB

On On On

2 Use ▲▼◄► to select the item you want to adjust, then press

OK.

Set the Master EasyLink On or Off. The following additional settings will be grayed out when you set to Off.

Disables all EasyLink.

Off

Master EasyLink

Selects if you have connected an external device that is compatible with

the EasyLink function.

Device list

This function lets you see the product model number or name of connected devices. Use ▲▼ to select the desired EasyLink devices listed on the TV screen, then press OK. Your connected EasyLink device will be Turned On if the device is in Stand by mode.

Picture Sound Setup

Features

Language USB

HDMI1 DVD recorder

HDMI2 Blu-ray disc player

HDMI3 Home theater system

Input Change Refresh Back

You can set your device to Turn Off by interlocking from this unit’s power.

Your connected EasyLink device stays on

Off

even if the unit goes into Standby mode.

Auto device off

Your connected EasyLink device Turns Off automatically when the unit goes

into Standby mode.

This unit will Turn On when the Power On signal is sent from your connected EasyLink device.

This unit stays in Standby mode even if you Turn On your connected EasyLink

Off

Auto TV on

device. This unit Turns on automatically when

you Turn On your connected EasyLink

device.

Page 27

English

Setting your location to home

You can set the location of your TV to Home or Retail. Choosing Home gives you full ﬂ exibility to change predeﬁ ned settings for picture and sound.

1 Use ▲▼ to select Location, then press OK.

Picture Sound Child lock Setup PC settings

Features EasyLink

Language Location Home USB

Caption settings

E-sticker

Software upgrade

2 Use ▲▼ to select Home or Retail, then press OK.

The unit will be set up with predeﬁ ned settings for

Retail

Home

retail displays. In this setting, the power consumption may possibly exceed the limit requirement of the ENERGY STAR® qualiﬁ cation.

This setting is ENERGY STAR® qualiﬁ ed. The unit is set to maximize the energy efﬁ ciency for home setting and it can be adjusted through a choice of picture and sound quality according to your preference.

Language

1 Press MENU / EXIT and use ▲▼ to select Language, then press OK.

Picture Sound

Select your menu language.

Setup Features

Seleccione el idioma para el menú.

Language

USB

Sélectionnez la langue du menu.

2 Use ▲▼ to select English, Español or Français, then press OK.

Note

• If you need the English menu instead of the Spanish or French menu’s, press MENU / EXIT.

Use ▲▼ to select Idioma or Langue, then press OK. Use ▲▼ to select English then press OK. Press MENU / EXIT to exit the main menu.

English

Español

Français

Note

• You must set Home. Otherwise, personalized picture and sound settings will not be

memorized after the unit goes into Standby mode.

E-sticker

When you set Location to Retail store, E-sticker (Electronic Sticker) is displayed. E-sticker can be Turned Off using procedure below.

1 Use ▲▼ to select E-sticker, then press OK. 2 Use ▲▼ to select Off, then press OK.

Off

To p

Bottom

Note

• If you select Home, E-sticker will not be displayed.

You can Turn Off E-sticker.

E-sticker is displayed on top of the TV screen.

E-sticker is displayed on bottom of the TV screen.

Page 28

English

USB

Your TV is ﬁ tted with a USB connection that enables you to view photos or watch Motion JPEG ﬁ les stored on a USB Memory Stick.

1 Connect the USB Memory Stick to the USB terminal on the side of

your TV.

2 Press MENU / EXIT and use ▲▼ to select USB, then press OK.

• The highlighted text will move to the name of your USB Memory Stick, then press OK again.

Picture Sound Setup

This menu allows you to enjoy your pictures and videos via your USB device.

Features

Language

USB

3 Use ▲▼ to select the Picture or Video, then press OK.

• The ﬁ les recorded under the following speciﬁ cations are required.

Picture (JPEG)

Video

(Motion JPEG)

Note

• Up to 2GB (FAT16) or 8GB (FAT32) capacity can be suppor ted.

• Up to 10,000 ﬁ les or 1,000 folders with 19 hierarchies can be recognized.

• Up to 255 English characters can be recognized.

• This unit does not support MTP(Media Transfer Protocol).

• This unit supports FAT16 and FAT32 ﬁ le systems.

• If the ﬁ le is not supported, an error message appears.

• When the USB Memory Stick is not recognized, try reconnecting it again.

• We cannot be held responsible if your USB Memory Stick is not suppor ted, nor will we

accept any liability for damage or loss of stored data.

• A ﬁ le name exceeding 128 characters or contains a dot character is not suppor ted on

this TV.

• Progressive JPEG ﬁ les are not supported.

• Only a Motion JPEG ﬁ le with an “.avi” extension is supported. An extension “.mov” is

not supported.

• During Motion JPEG playback, “Pause”, “Forward” and “Reverse” do not work on this

unit.

Upper limit 24Mpixel

Size 320 x 240 (QVGA)

Frame rate 30fps

Audio type LPCM

Sampling frequency (32 kHz, 44.1 kHz or 48 kHz) Quantization bit rate (16 bit)

Your USB

Picture (JPEG)

1 Use ▲▼ to select the desired ﬁ le, then press OK.

Your USB


.. Image1.jpg

Image2.jpg Image3.jpg Image4.jpg Image5.jpg

1 2

Press “OK” key to play/pause

• To toggle between List and Thumbnails press the NUMBER 2 button each time.

• The unit goes to the Slide show automatically.

To pause / play the Slide show, press OK.

• Use the NUMBER buttons (1 through 4

) or change the following settings ( 2 ~ 4 ).

(

See the description on the top of the next column.

Item Detail

More Detail

Start show

Transitions

Slide time

Stop show

Rotate

Zoom

Press 1 to display ﬁ le details below. Name, Album, Date, Size and Next.

Press 1 again to remove ﬁ le details. Press 4 or OK to start the Slide show.

While the Slide show is on, the following 2 settings will be displayed.

Press 2, then use ▲▼ to select the transition mode choosing from;

None, Dissolve, Wipe right, Wipe left, Wipe up, Wipe down, Box in and Box out.

Press 3, then use ▲▼ to change the display time choosing from; Short, Medium and Long.

Press 4 or OK to stop the Slide show. While the Slide show is Off, the following 2 settings will be displayed.

Every press on 2 will turn the picture clockwise by 90 degrees.

Press 3, then use ▲▼ to select the zoom factor (1x, 2x or 4x). Press OK to set the zoom factor.

Video (Motion JPEG)

Thumbnails

Picture Picture Image1.jpg

Image1.jpg 1200:900 2009:04:02 17:42:06

3 4

) to see the ﬁ le detail

1 Use ▲▼ to select the desired ﬁ le, then press OK.

Your USB

Video

.. MOVIE1.avi

MOVIE2.avi MOVIE3.avi MOVIE4.avi MOVIE5.avi

Video Video MOVIE1.avi

Title: MOVIE1.avi Director: Date: 2009/04/02 Duration: 00:06:37

1 2 3 4

Supported format: motion jpeg, 320 x 240, 30FPS

• To stop playback and return to the ﬁ le list, press BACK, OK or CH +.

• Press CH − to play back from the beginning.

Item Detail

More Detail

Press 1 to display ﬁ le details below. Title, Director, Date and Duration.

Press 1 again to remove ﬁ le details.

Page 29

English

6 Upgrade your TV software

Philips continuously tries to improve its products and we strongly recommend that you upgrade the TV software when upgrades are available.

New software can be downloaded from our website at

www.philips.com/support

using the model number of your TV to ﬁ nd information.

Checking your current software version 1

Press MENU / EXIT and use ▲▼ to select Features, then press OK.

2 Use ▲▼ to select Software upgrade, then press OK.

Picture Sound Setup

Features

Language USB

Current software info Upgrade

Warning

• When the software upgrade is running, don’t press any buttons.

• Do not remove the USB Memory Stick during the software upgrade.

• If an error occurs during the upgrade, retry the procedure or for further assistance,

please contact Call Center.

Downloading the software

Find information and software related to your TV and download the latest software upgrade ﬁ le to your PC.

1 On your PC, open a web browser and go to

www.philips.com/support

2 Enter the model number in the “Type the Model Number...” ﬁ eld. 3 Click the desired software to be downloaded.

• Decompress the ZIP-ﬁ le.

4 Copy the upgrade ﬁ le to the root directory of the USB Memory

Stick.

Starting the software upgrade

1 Connect your USB Memory Stick with the upgrade ﬁ le to the USB

terminal on the side of your TV.

3 Use ▲▼ to select Current software info, then press OK.

• The version and a description of the current software is displayed.

Picture Sound Setup

Features

Language USB

Release Version: XXXXXXX_XX_XX_XXXX_XX

Back

Upgrading the software

You can upgrade the software by using USB Memory Stick.

Preparing for the software upgrade

You require the following equipment :

• A PC with web browsing capability.

• An archive utility that supports the ZIP-format (e.g. WinZip for Windows or StuffIt for Mac OS).

• An empty clean formatted USB Memory Stick.

Note

• Only FAT / DOS-formatted portable memor y is supported.

• Use only software upgrades that can be found on the Philips web site.

2 Press MENU / EXIT and use ▲▼ to select Features, then press OK. 3 Use ▲▼ to select Software upgrade, then press OK. 4 Use ▲▼

to select Upgrade, then press OK.

5 Read the on-screen instructions and conﬁ rm that you want to

continue with the installation.

Picture Sound Setup

Features

Language USB

Would you like to upgrade the software?

Start now

6 When the software upgrade is completed, press to set the unit

to go into Standby mode, then remove the USB Memory Stick and then press

• The TV starts up with the new software.

For further assistance, please contact Call Center.

again to Turn the unit On.

Page 30

set-top box

Blu-ray disc player

HD game console

HDMI cable

HDMI-DVI

conversion cable

Audio (L/R) cables

cable receiver or

satellite box with the

DVI Output jack

English

7 Connecting devices

No supplied cables are used with these connections:

• Please purchase the necessary cables at your local store.

Before you connect AC power cord:

Be sure other devices are connected properly before plugging in the AC power cord.

Selecting your connection quality

HDMI - Highest quality

Supports high-deﬁ nition Digital signals and gives highest picture and sound quality. Video and audio signals are combined in one cable. You must use HDMI for full high-deﬁ nition video and to enable EasyLink.

Note

• Philips HDMI supports HDCP (High-bandwidth Digital Contents Protection). HDCP

is a form of Digital Rights Management that protects high deﬁ nition content in Blu-ray discs or DVDs.

Component (Y Pb Pr) - High quality

Connecting your devices

HDMI Digital connection

HDMI connection offers the highest picture quality. HDMI (High-Deﬁ nition Multimedia Interface) transports high deﬁ nition Digital video and multi-channel Digital Audio through a single cable.

set-top box

ININ OUT

HDMI cable

HDMI-DVI connection

This unit can be connected to your device that has a DVI terminal. Use an HDMI-DVI conversion cable for this connection and it requires audio cable for Analog Audio signal as well.

ININ OUT

HDMI-DVI

conversion cable

ININ

Blu-ray disc player

HD game console

cable receiver or

satellite box with the

DVI Output jack

OUT

Supports high-deﬁ nition Analog signals but gives lower picture quality than HDMI. Component (Y/Pb/Pr) Video cables combine red / green / blue video cables with red / white audio (L/R) cables. Match the cable colors when you connect to the TV.

Composite - Basic quality

For analog connections. Composite Video / Audio Analog cable usually combine a yellow video cable with red / white audio (L/R) cables. With this unit, yellow cable must be connected to Y (green) of Component Video Input jacks.

Audio (L/R) cables

Note

• Use an HDMI cable with the HDMI logo (a certiﬁ ed HDMI cable). High Speed HDMI

cable is recommended for the better compatibility.

For HDMI connection

• The unit accepts 480i / 480p / 720p / 1080i, 1080p 24/30/60Hz of video signals, 32kHz

/ 44.1kHz and 48kHz of audio signals.

• This unit accepts 5.1 channel audio signal (Dolby Digital) and 2 channel audio signal

(LPCM).

• This unit accepts only signals in compliance with EIA861.

For HDMI-DVI connection

• The unit accepts 480i, 480p, 720p, 1080i and 1080p video signals.

• HDMI-DVI connection requires separate audio connections as well and the audio

signals are output as Analog (L/R) Audio.

• DVI does not display 480i image which is not in compliance with EIA/CEA-861/861B.

Page 31

Component (Y/Pb/Pr) Video cables

Audio (L/R) cables

set-top box

Blu-ray disc/DVD recorder

DVD player

Audio (L/R) + Video cables

Digital home theater

ampliﬁ er

Digital Audio coaxial cable

English

Component Analog Video Connection

Component Analog Video connection offers better picture quality for video devices connected to the unit. If you connect to the unit’s Component Video (Y/Pb/Pr) Input jacks, connect Analog Audio cables to the Analog Audio (L/R) Input jacks.

OUT

set-top box

Audio (L/R) cables

Component (Y/Pb/Pr) Video cables

OUTOUT

Blu-ray disc/DVD recorder

Note

• The unit accepts 480i / 480p / 720p and 1080i of video signals for this connection.

Composite Analog Video Connection

Composite Analog Video connection offers standard picture quality for video devices connected to the unit. If you connect to the unit’s Composite Video (Y/VIDEO) Input jack, connect audio cables to the Audio (L/R) Input jacks. When the Audio is monaural, then only connect to the Audio L Input jack.

Digital Audio Output Connection

If you connect this unit to an external Digital Audio device, you can enjoy multi-channel audio like 5.1ch Digital broadcasting sound. Use a Digital Audio coaxial cable to connect the unit to external Digital Audio devices.

ININ

Digital Audio coaxial cable

OUT

Digital home theater

ampliﬁ er

OUTOUT

DVD player

Audio (L/R) + Video cables

Note

• With this unit, yellow cable must be connected to Y (green) of Component Video Input

jacks.

• Whenever you connect to the Composite Video Input jack (Y/VIDEO), you must

disconnect the Component Video Input jacks (Pb and Pr). If you leave those jacks connected, it may cause of unstable picture.

• Only the left loudspeaker reproduces sound for mono equipment. Use a mono to

stereo adapter (not supplied) for sound reproduction via all internal loudspeakers.

Page 32

HDMI cable

Stereo mini 3.5 mm plug Audio cable

HDMI-DVI

conversion cable

VGA cable

Stereo mini 3.5 mm plug Audio cable

English

PC connection

HDMI connection

This unit can be connected to your PC that has a HDMI terminal. Use an HDMI cable for this Digital connection.

ININ OUT

HDMI cable

HDMI-DVI connection

This unit can be connected to your PC that has a DVI terminal. Use an HDMI-DVI conversion cable for this Video Digital connection and it requires Stereo mini 3.5mm plug Audio cable for Analog Audio signal as well.

The following video signals can be displayed:

Format Resolution Refresh rate

VGA 640 x 480

SVGA 800 x 600

XGA 1,024 x 768

WXGA

FHD 1,920 x 1,080

1,280 x 768 1,360 x 768

60Hz

Other formats or non-standard signals will not be displayed correctly.

Note

• Please purchase the VGA cable or HDMI-DVI conversion cable that has a ferrite core.

• The following operations may reduce noise.

- Attach a ferrite core to the AC power cord of your PC.

- Unplug the AC power cord and use the built-in battery of your PC.

• Use an HDMI cable with the HDMI logo (a certiﬁ ed HDMI cable). High Speed HDMI

cable is recommended for the better compatibility.

• The unit accepts 480i, 480p, 720p, 1080i and 1080p video signals.

• HDMI-DVI connection requires separate audio connections as well and the audio

signals are output as Analog (L/R) Audio.

• DVI does not display 480i image which is not in compliance with EIA/CEA-861/861B.

USB Memory Stick

This unit offers easy playback of picture (JPEG) and video (Motion JPEG) ﬁ les. Insert the USB Memory Stick into the USB terminal shown below.

p. 28

USB

➠

OUT

ININ

HDMI-DVI

conversion cable

Stereo mini 3.5 mm plug Audio cable

VGA connection

This unit is equipped with a PC Input jack. If you connect this unit to your PC, you can use this unit as a PC monitor. Use a VGA cable for this Video connection and it requires a Stereo mini

3.5mm plug Audio cable for Analog Audio signal as well.

VGA cable

OUTIN

Stereo mini 3.5 mm plug Audio cable

OUT

Note

• The unit recognizes only a USB Memory Stick.

• Do not use a USB hub or an extension cable to connect an external hard disk drive to

the unit. (Not supported.)

• A USB Memory Stick is always inser ted to this unit directly.

• A USB Memory Stick is not supplied with this unit.

• We do not guarantee that all USB Memory Sticks can be supported by this unit.

• Be sure to keep a backup copy of the original ﬁ les on your device before you play them

back on this unit. We have no responsibilities for damage or loss of your stored data.

• To protect your USB Memory Stick ﬁ les from being erased place the write protect

sliding tab in the protect position.

• When you are ready to remove a USB Memory Stick, set the unit to go into Standby

mode to avoid any damage to your data and the unit.

• A USB Memory Stick that requires its own driver or the device with a special system

such as ﬁ ngerprint recognition are not supported.

• This unit is not allowed to use the USB Memory Stick which requires an external

power supply (500mA or more).

Page 33

English

8 Useful tips

FAQ

Question Answer

My remote control does not work. What should I do?

How come the Initial setup appears every time I Turn On this unit?

Why can I not watch some RF signal TV programs.

How come there is no image from the connected external devices?

When I enter a channel number, it changes automatically.

Why are captions not displayed entirely? Or, captions are delayed behind the dialog.

How can I set the clock ? • There is no clock function on this unit.

I cannot change the Child lock setting because my PIN code no longer works.

• Check the antenna or cable connection to the main unit.

• Check the batteries of the remote control.

• Check if there is an obstacle between the infrared sensor window and the remote control.

• Test the signal Output use IR Signal Check. ➠ p. 35

If okay, then possible infrared sensor trouble.

• Aim the remote control directly at the infrared sensor window on the front of the unit.

• Reduce the distance to the unit.

• Re-insert the batteries with their polarities (+/– ) as indicated.

• When there is an infrared-equipped device such as PC near this unit, it may interrupt the remote control signal of this unit. Move the infrared-equipped device away from this unit, change the angle of the infrared sensor or Turn Off the infrared communication function.

• Connect the RF coaxial cable to the unit directly and run the initial setup.

• Make sure to complete the initial setup before the unit goes into Standby mode.

• Autoprogram must be completed when you set up the unit for the ﬁ rst time or move it to a location where previously unavailable channels are broadcast.

• Make sure Autoprogram has been completed.

• The selected channel may not be broadcasting.

• When Autoprogram is interrupted and not completed, some channels will not be received. Make sure to complete the Autoprogram.

• The selected channel cannot be viewed by the Child and ratings lock setting.

• The unit requires some kind of antenna Input. An indoor antenna (Digital or VHF / UHF), an external antenna (Digital or VHF / UHF) or an RF coaxial cable from your wall cable/satellite box needs to be plugged into the unit.

• Check if the correct Input mode is selected by pressing SOURCE or using CH + / −. Refer to Watching channels from an external device. ➠ p. 15

• Check the antenna, cable or other Input connection to the unit.

• When using the Component Video connection check that the Green (Y), Blue (Pb/Cb) and Red (Pr/Cr) connectors are connected to their corresponding colored jacks on the unit.

• Many Digital channels have alternate channel numbers. The unit changes the numbers automatically to the ones signifying the broadcasting station channel number. These basic numbers used for previous Analog broadcasts. (e.g., Input ch# 30 automatically changes to ch# 6.1)

• Captions that are delayed a few seconds behind the actual dialog are common for live broadcasts. Most captioning production companies can display a dialog to maximum of 220 words per minute. If a dialog exceeds that rate, selective editing is used to insure that the captions remain up-to date with the current TV screen dialog.

• If a Power failure occurs for longer than 10 seconds the child lock setting is retained, but the PIN code is reset to the default code

0000. Refer to Child and ratings lock.

➠

p. 20

➠

p. 23

➠

p. 20

➠

p. 23

Troubleshooting

If the unit does not perform properly when operated as instructed in this User Manual,

check the following chart and all connections once before calling for service.

Symptom Remedy

No power • Make sure the AC power cord is plugged in.

• Make sure that the AC outlet supplies the proper voltage, plug another electrical appliance into the AC outlet to ensure that the AC outlet operates normally.

• If a power failure occurs, unplug the AC power cord for 1 minute to allow the unit to reset itself.

Control buttons do not work. • Press only one button at a time. Do NOT press more than one button at the same time.

• Ensure that no buttons on the remote control are depressed and move freely.

Continued on next page.

Page 34

Symptom Remedy

Power is ON but no screen image.

No picture or sound • Check if the Power is on.

No color • View other TV channels. The problem might be limited to the broadcasting station or weak signal strength.

No sound, distorted sound or incorrect Audio Sound is heard when using the HDMI-DVI connections.

Adjusted Picture or Sound settings are not effective every time the unit is Turned On.

Sound OK, picture poor • Electrical interference from nearby appliances may affect picture quality.

Picture OK, sound poor • View other TV channels. The problem might be limited to the broadcasting station or weak signal strength.

You see a distor ted picture or hear an unusual sound.

Ghosts, lines or streaks in picture • Electrical interference from nearby appliances may affect picture quality.

You see noise or trash on the screen.

Different color marks on the TV screen

You switch to a different Input and the volume changes.

You switch to a different Input and the screen size changes.

The display image does not cover the entire screen.

Captions are displayed as a white box. No caption is displayed in the Closed Caption-supported program.

Black box is displayed on the TV screen.

• Check whether the connection of the antenna, cable receiver or satellite box is connected correctly.

• Check whether all the cables to the unit are connected to the correct Output jack of your device like Blu-ray disc / DVD recorder.

• Make sure that the selected Input mode is connected to the working Input jack.

• Check if your computer is NOT in sleep mode when the Input mode of this unit is in PC mode. Tap any key on the keyboard to wake up your computer.

• Check whether all the cables to the unit are connected to the correct Output jack of your device like Blu-ray / DVD recorder.

• View other TV channels. The problem might be limited to the broadcasting station or weak signal strength.

• Unplug the AC power cord and wait for about 1 minute, then plug the AC power cord and Turn On the unit again.

• Check whether the connection of the antenna, cable receiver or satellite box is connected correctly.

• Make sure that the selected Input mode is connected to the working Input jack.

• Check if your computer is NOT in sleep mode when the Input mode of this unit is in PC mode. Tap any key on the keyboard to wake up your computer.

• Make sure that the sound is not muted. Press MUTE so that the volume bar and current volume level will appear on the TV screen.

• Make sure that the volume is NOT set to 0 or

• Adjust Color in Picture settings. ➠ p. 19

• Make sure that the Analog Audio signals from the HDMI-DVI device are connected to the Analog Audio (L/R) Input jacks.

• When using Component Analog Video, Composite Analog Video or PC VGA Video make sure that the Analog Audio (L/R) connectors are mounted into the Audio (L/R) Input jacks.

• You must set Home in Location.

Otherwise, the settings you adjusted will not be memorized after the unit goes into Standby mode.

• Adjust Contrast and Brightness in Picture settings.

• View other TV channels. The problem might be limited to the broadcasting station or weak signal strength.

• For the best picture quality, watch High Deﬁ nition wide screen programs.

If the HD content is not available, watch Standard Deﬁ nition programs instead.

• Check if the audio cable is connected into the unit correctly.

• You may be getting interference from electrical appliances, automobiles, motorcycles or ﬂ uorescent lights.

• Try moving the unit to another location to see if this is the cause of the problem.

• View other TV channels. The problem might be limited to the broadcasting station or weak signal strength.

• When the capabilities of the unit exceed the capabilities of the Digital broadcasting, the signal will be increased to match the capabilities of the display of the unit. This may cause noise or trash.

• View other TV channels. The problem might be limited to the broadcasting station, missing data or pixelation.

• This unit will memorize the volume level from the last time you adjusted it.

• If the volume of the sound from another device is higher or lower, then the loudness will change.

• Make sure Auto volume leveling is set to On.

• This unit will memorize the viewing mode from the last time you used the particular Input modes.

• If you are using the unit as a PC monitor, make sure that Horizontal position and Vertical position in PC settings are set correctly.

• If you are watching TV or using the Composite Video, Component Video or HDMI with 480i Input, press FORMAT repeatedly to switch various screen modes.

• Interference from buildings or weather conditions may cause captioning to be incomplete if watching Analog TV signals.

• Broadcasting station may shorten the program to insert advertisements.

• The Closed Caption decoder cannot read the information of the shortened program.

• The text mode is Selected. For caption, select CC-1, CC-2, CC-3, CC-4 or Off.

➠

p. 27

. If so, use VOL + / − to adjust to the desired volume.

p. 19

➠

p. 20

➠

English

Note

• The LCD screen is manufactured to provide many years of useful life. Occasionally a few non active pixels may appear as a ﬁ xed point of blue, green or red.

This is not to be considered a defect in the LCD screen.

• Some functions are not available in speciﬁ c modes, but this is not a malfunction. Read the description in this User Manual for more details on correct operations.

Page 35

9 Information

English

Glossary

Analog TV (NTSC)

Acronym that stands for National Television Systems Committee and the name of Analog broadcasting standards. Off the air Analog TV signals are no longer being sent by major broadcasting stations in the USA.

Aspect ratio

The width of a TV screen relative to its height. Conventional TVs are 4:3 (in other words, the TV screen is almost square); widescreen models are 16:9 (the TV screen is almost twice as wide as its height).

CEC (Consumer Electronics Control)

This allows you to operate the linked functions between our brand devices with CEC feature and this unit. We do not guarantee 100% interoperability with other brands of CEC compliant devices.

Component Video

This is a video signal format that conveys each of 3 principal colors of light (red, blue and green) through different signal lines. This allows the viewers to experience picture colors as original as it is. There are several signal formats, including Y / Pb / Pr and Y / Cb / Cr.

Dolby Digital

The system developed by Dolby Laboratories to compress Digital sound. It offers stereo sound (2ch) or multi-channel audio.

DTV (ATSC)

Initialism that stands for Advanced Television Systems Committee and the name of the Digital broadcasting standards.

E-sticker

E-sticker is showing set features, technical information, etc on this TV set that is displayed on the TV screen mainly used by TV retailers. Previously the information was on a printed sticker that was put on the display.

HDMI (High-Deﬁ nition Multimedia Interface)

Interface that supports all uncompressed, Digital Audio / Video formats including set-top box, Blu-ray / DVD recorder or Digital television, over a single cable.

HDTV (High Deﬁ nition TV)

Ultimate Digital format that produces high resolution and high picture quality.

PIN code

A stored 4-digit number that allows access to parental control features.

SAP (Secondary Audio Program)

Second-audio channel delivered separately from main-audio channel. This audio channel is used as an alternate in bilingual broadcasting.

SDTV (Standard Deﬁ nition TV)

Standard Digital format that is similar to the Analog TV picture quality.

SRS TruSurround HD™

Creates an immersive, feature-rich surround sound experience from two speakers, complete with rich bass, high frequency detail and clear dialog.

Maintenance

Cabinet Cleaning

• Wipe the front panel and other exterior surfaces of the unit with a soft cloth.

• Never use a solvent or alcohol. Do not spray insecticide liquid near the unit. Such chemicals may cause damage and discoloration to the exposed surfaces.

Panel Cleaning

Wipe the panel of the unit with a soft cloth. Before cleaning the panel, disconnect the AC power cord.

Servicing

Should your unit become inoperative, do not try to correct the problem yourself. There are no user serviceable parts inside. Call our toll free customer support line found on the cover of this User Manual to locate an authorized service center.

IR Signal Check

If the remote control is not working properly, you can use a Digital camera (including a cellular phone with built-in camera) to see if it is sending out an infrared signal.

With a Digital camera (including built-in cell phone cameras): Point the Digital Camera towards the remote control infrared diode at the front of the remote control. Press any button on the remote control and look through the camera display. If the infrared pulsating light appears through the camera, the remote control is sending out an IR signal.

Page 36

English

10 Specifications

Model # 40PFL4707


Type FHD (1920 x 1080 pixels 60Hz)

Aspect ratio 16:9

Viewing angles 178° (V) by 178° (H)

Built-in Digital tuner ATSC / NTSC

Sound

Mono / Stereo Mono, Stereo, SRS TruSurround HD™

Power Output (RMS watts) 10 W x 2

Equalizer 5 band

Ease of use

SD (4:3 Source) : HD (16:9 Source) :

Picture format

Photo slide show JPEG ﬁ les only

HDMI AV (4:3 Source) : HDMI AV (16:9 Source) : PC Source :

Normal / 16:9 / Movie expand / Zoom / Wide Normal / 4:3 / Movie expand / Zoom / Wide Normal / 16:9 / Movie expand / Zoom / Wide / Full Normal / 4:3 / Movie expand / Zoom / Wide / Full Normal / Full / Unscaled (Refer to HDMI AV (16:9 Source) above if PC has HDMI Output.)

Video playback Motion JPEG 320 x 240, 30fps and ﬁ le extension “.avi” only

Connectivity

Component Video Input (Y/Pb/Pr)

Composite Video Input

(shared terminal with Y of components)

HDMI Input

Audio L/R Input 1

PC Input via VGA, HDMI and HDMI-DVI + Analog Audio L/R

USB 1

Digital Audio Output

Headphone Output

Power

Power requirements 120V~ AC +/− 10%, 60Hz +/− 0.5%

Temperature

Operating temperature 41 °F (5 °C) to 104 °F (40 °C)

supporting video signals : 480i/p, 720p, 1080i 60Hz

supporting video signals :

480i/p, 720p, 1080i/p, 24Hz-60Hz

PC-input signal up to FHD (1920 x 1080)

supporting Dolby Digital

1/8 inches (3.5mm)

• Speciﬁ cations are subject to change without prior notice.

Page 37

Av. La Palma No. 6, Col. San Fernando La Herradura,

P&F Mexicana, S.A. de C.V.

Huixquilucan Edo. de México C.P. 52787

Philips and Philips Shield are used under license of Koninklijke Philips Electronics N.V.

A21PAMA

★★★★★
