TABLE OF CONTENTS
Thank you for purchasing this televison set. You are now the proud owner
of a PHILIPS TV set which promises full value to you as a customer.
Please read the instruction manual carefully and thoroughly to help you
install and operate your TV set.
Introduction
Safety Information/Useful Tips .................................................................................................. 3
Before Calling Service ................................................................................................................. 4
Basic Installation/Functions
Hooking Up Your TV (Basic Connection) ............................................................................... 5
Use/Care of remote Control .................................................................................................... 5
Connecting the Audio/Video Sockets (Playback) .................................................................. 6
Connecting the Audio/Video Sockets (Recording) ............................................................... 8
Functions of Remote Control ................................................................................................... 9
Functions of TV Controls ...........................................................................................................11
TV Installation
Selecting the Menu Language and Automatic Tuning of Channels...................................... 12
Manual Tuning of Channels ......................................................................................................... 14
Selecting the Colour/Sound System ........................................................................................ 15
Fine Tuning Of Channels ............................................................................................................. 16
Sorting of Channels...................................................................................................................... 17
Editing of Channels........................................................................................................................18
Naming of Channels...................................................................................................................... 19
Features
Using the /Sound Menu................................................................................................................ 20
Activating the Timer...................................................................................................................... 21
Using the Active Control Feature.............................................................................................. 23
Activating the Child Lock.............................................................................................................24
Using the Surf Control................................................................................................................. 28
Using the Screen Format ............................................................................................................ 29
Using the Rotation Feature......................................................................................................... 30
Using the Blue Mute Feature...................................................................................................... 31
Using the Program List Feature................................................................................................. 31
Smart Picture Control and Smart Sound Control................................................................ 32
Activating the PIP (Picture-in-Picture) and Double Control Feature................................ 33
Using the Teletext.......................................................................................................................... 36
General
Specifications...................................................................................................................................38
30321/Eng/p1-5 3/22/02, 10:20 AM2
2
SAFETY INFORMATION AND USEFUL T IPS
Safety Information
• Disconnect mains plug when :
– the red light below the TV screen is flashing continuously.
– a bright white line is displayed across the screen.
– cleaning the TV screen. Never use abrasive cleaning agents. Use a slight damp chamois
leather or soft cloth.
– there is a lightning storm.
– the set is left unattended for a prolonged period of time.
• No naked flame sources, such as lighted candles, should be placed on top of the TV or
in the vicinity.
• Do not place your TV set under direct sunlight or heat.
• Leave at least 5 cm around each side of TV set to allow for proper ventilation.
• Avoid placing your set (e.g. near the window) where it is likely to be exposed to rain
or water.
• No objects filled with liquids should be placed on top the TV so as to avoid dripping
or splashing of liquids on the set.
Useful Tips
• Do not leave your set on standby mode for a prolonged period of time. Switch off set
to allow it to be demagnetised. A demagnetised set supports good picture quality.
• Do not shift or move the set around when it is switched on. Uneveness in colour in
some parts of the screen may occur.
• Never attempt to repair a defective TV yourself. Always consult a skilled service
personnel.
Recycling Directive – To minimise harm to the environment, the batteries
supplied with the TV set do not contain mercury or nickel cadmium. If possible,
when disposing of batteries, use recycling means available to you. Your TV set
uses materials which are reusable or which can be recycled. To minimise the
amount of waste in the environment, specialist companies recover used sets for
dismantling and collection of reusable materials (contact your dealer).
3
30321/Eng/p1-5 3/22/02, 10:20 AM3
BEFORE CALLING SERVICE
Below is a list of frequently occurred symptoms. Before you call for service, make these simple
checks. Some of these symptoms can easily be rectified if you know what to do.
Symptom What you should do
Colour patch • Switch off the TV by the mains power button. Wait for 20
(uneveness) minutes before switching on again.
• Check the TV is not placed too near speakers or magnetic
objects.
No power • Check the TV’s AC power cord is plugged into the mains
socket. If there is still no power, disconnect plug. Wait for
60 seconds and re-insert plug. Switch on the TV again.
No picture • Check the antenna connection at the rear of the TV.
• Possible TV station problem. Try another channel.
Good picture • Try increasing the volume.
but no sound • Check that the sound is not muted. If it is muted, press the
Mute button on the remote control to restore sound.
Good sound but poor • Try increasing the contrast and brightness setting.
colour or no picture
Snowish picture and • Check antenna connection at the rear of the TV.
noise
Horizontal dotted lines • Possible electrical interference e.g. hairdryer, vacuum
cleaner, etc. Switch off appliances.
Double images or • Possible poor positioning of antenna. Using a highly
“Ghost” images directional antenna may improve reception.
TV not responding to • Check life span of batteries of remote control handset.
remote control handset • Aim remote control handset directly at remote control
sensor lens on the TV.
4
30321/Eng/p1-5 3/22/02, 10:20 AM4
HOOKING UP Y OUR TV (BASIC CONNECTION)
Antenna Connection
• Connect the aerial plug to the antenna socket
on the backcover.
• Insert the mains plug into the wall socket.
Mains Connection
• For correct mains voltage, refer to type sticker at
the rear of the TV set
• Consult your dealer if mains supply is different.
Note : This diagram is not representative of the
actual plug and socket.
Switching on the Set
• Press the main power button to switch on/
off the TV.
• If the set is on standby (indicator is red),
press the Power button on the remote
control to switch on set.
¬¬
¬
¬¬
30321/Eng/p1-5 3/22/02, 10:21 AM5
USE/CARE OF REMOTE CONTROL
• Insert the correct type of batteries into the
compartment.
• Ensure the batteries are placed in the right
direction.
5
CONNECTING THE AUDIO/VIDEO SOCKETS (PLAYBACK)
S-VIDEO
AV sockets
on rear of
TV
Back of
VCR
VIDEO
L/Mono
AUDIO
R
OUT
ANTENNA
IN
AV1 in AV2 inMonitor out
Y
Pb
Pr
COMPONENT VIDEO INPUT
OUT
VIDEO
IN
OUT
L
R
AUDIO
IN
VCR (Equipped with
Video and Audio Output
sockets
You can view the playback of VCR tapes (Video Disc players, camcorders, etc.) by using the AUDIO and
VIDEO INPUT sockets on the rear of the TV.
– Connect the VIDEO and AUDIO IN sockets on the rear of the TV to the AUDIO and
VIDEO OUT sockets on the VCR.
R
COMPONENT VIDEO INPUT
AV1 in AV2 inMonitor out
Y
Pb
Pr
S-VIDEO
AV sockets
on rear of
TV
VIDEO
L/Mono
AUDIO
OUT
L
R
VIDEO
AUDIO
IN
OUT
OUT
OUT
ANTENNA
IN
Back of S-VHS VCR
S-VIDEO
IN
The S-Video connection on the rear of the TV is used for the playback of S-VHS VCR tapes, Video Discs,
Video Games or Compact Disc-Interactive (cd-i) discs. Better picture detail and clarity is
possible with the S-Video playback as compared to the picture from a normal antenna (RF)
connection.
– Connect the S-VIDEO socket on the rear of the TV to the S-VHS OUT socket on a
S-VHS VCR.
– Connect the AUDIO IN sockets from the rear of the TV to the AUDIO OUT sockets
on the VCR.
Note : You need not connect the VIDEO IN socket of the TV if S-VIDEO IN socket is
connected.
6
30321/Eng/p6-8 3/22/02, 10:21 AM6
CONNECTING THE AUDIO/VIDEO SOCKETS (PLAYBACK)
Camcorder
Connect headphone jack to
socket for personal listening
For more convenient direct playback connections, the Side Audio/Video Input sockets allow for quick
and easy connections, particularly Camcorder tape recordings.
– Connect the S-VIDEO socket (if available) from the Camcorder to the Side S-VIDEO
socket of the TV. You need not connect the Side VIDEO IN socket of the TV if the
S-VIDEO socket is connected.
– Connect the AUDIO OUT sockets (Right and Left) from the Camcorder to the Side
AUDIO IN sockets.
R
Pr
AV1 in AV2 inMonitor out
Y
Pb
Pr
COMPONENT VIDEO INPUT
OUT
L
AUDIO
S-VIDEO
Back of DVD
R
DVD (Equipped with “Y”,
“Pb” and “Pr” and Output
VIDEO
L/Mono
AUDIO
OUT
Pb
Y
AV sockets
on rear of
TV
sockets)
You can view the playback of DVD discs by using the COMPONENT VIDEO INPUT sockets on the
rear of the TV.
– Connect the “Y”, “Pb” and “Pr” INPUT sockets on the TV to the “Y”, “Pb” and
“Pr” OUTPUT sockets on the DVD to view playback of DVD discs.
Note : “Y”, “Pb”, “Pr” sockets and AV1 sockets cannot be connected simultaneously.
7
30321/Eng/p6-8 3/22/02, 10:21 AM7
CONNECTING THE AUDIO/VIDEO SOCKETS (RECORDING)
Connection for recording from the TV channel
VIDEO
L/Mono
AUDIO
R
OUT
ANTENNA
AV1 in AV2 inMonitor out
Y
Pb
Pr
COMPONENT VIDEO INPUT
IN
OUT
VIDEO
R
IN
AV sockets
on rear of
TV
S-VIDEO
OUT
L
AUDIO
IN
VCR (Equipped with Video
and Audio Input sockets
– Connect the corresponding INPUT sockets of the VCR to the MONITOR OUTPUT
sockets on the rear of the TV.
– To enhance the sound of your TV, connect the AUDIO L and R sockets to an external
audio system instead of the VCR. For mono equipment, connect only the AUDIO L socket.
Connection for recording from one VCR to another VCR
R
OUT
ANTENNA
AV1 in AV2 inMonitor out
Y
Pb
Pr
COMPONENT VIDEO INPUT
OUT
VIDEO
IN
S-VIDEO
OUT
L
R
AUDIO
IN
IN
ANTENNA
OUT
OUT
OUT
Back of
L
VIDEO
R
AUDIO
VCR
IN
AV sockets on
rear of TV
VIDEO
L/Mono
AUDIO
VCR (Equipped with
Video and Audio
Output sockets
VCR 1
VCR 2
VCR (Equipped with Video
and Audio Input sockets
– Connect the sockets of the VCR which you wish to record from, to the corresponding
sockets at either AV1 or AV2..
– Connect the sockets of the receiving VCR to the MONITOR OUTPUT sockets on the
rear of the TV.
8
30321/Eng/p6-8 3/22/02, 10:21 AM8
FUNCTIONS OF REMOTE CONTROL
& SLEEPTIMER
Allows you to select a time period after which the
set will switch to standby mode automatically.
é A/CH (Alternate Channel)
Allows you to alternate between the last
viewed channel and the present channel.
“ FORMAT
You can have a choice of different formats for
your viewing pleasure, namely : - Auto, 4:3
mode, EXPAND 4:3 mode and COMPRESS
16:9 mode
‘ DIGIT (0 -9)
Allows you select a channel. Note : For a 2-digit
number, the second digit must be entered before
the “–” sign disappears.
( SMART SOUND
Allows you to select your desired sound setting
from 4 types of sound settings.
§ MENU
Displays main menu. Also exits menu from screen.
è CURSOR UP
Allows you to select the next item on the menu.
! CURSOR LEFT
Allows you to access the sub-menus and adjust
the settings.
ç VOLUME + / –
Increases or decreases volume.
0 OSD
– Displays the channel number, sound and colour
transmission mode, status of the sleeptimer.,
channel name (if channel is named) and the
current time (if current time is being entered in
the Timer menu).
– Also allows you to exit menu from screen.
1 AV
Allows you to select the AV channels.
2 DOLBY VIRTUAL
– Allows you to select Incredible Surround/Virtual
Dolby Surround sound and Stereo when
transmission is in stereo mode. Virtual Dolby
Surround allows you to enjoy the sensation of
Home Cinema surround sound with just 2 front
speakers.
– Allows you to select Spatial Sound when
transmission is in mono mode.
&
é
“
‘
(
§
è
!
ç
0
1
2
D
PIP
A/CH
æ
q©
2
1
4
5
8
7
M
0
MENU SURF
i
AV
bh
DOLBY.V
ACTIVE CONTROL
¬
f◊
h
V
B
S
ßê
PIP CH
UP DN
3
6
9
SMARTSMART
a
CH
XC
gU
PROGRAM LIST
î
30321/Eng/p9-11 3/22/02, 10:22 AM9
9
D
PIP
A/CH
æ
q©
2
1
4
5
8
7
M
0
MENU SURF
i
AV
bh
DOLBY.V
ACTIVE CONTROL
¬
f◊
h
V
B
S
ßê
PIP CH
UP DN
3
6
9
SMARTSMART
a
CH
XC
gU
PROGRAM LIST
î
FUNCTIONS OF REMOTE CONTROL
3 STANDBY
– Switch set off temporarily to standby mode. (The
red light indicator lights up when set is on standby
3
4
5
6
7
8
9
20
21
22
23
24
25
mode).
– To switch on set from standby mode, press Channel
Up/Down, Digit (0 -9) or Standby
button.
4 PIP (Picture-in-Picture )
Allows you to access the Picture-in-Picture and
Double Window features. (For more detailed
description of functions, refer to the sections on
“Activating the PIP and Double Window Control”)
5 SMART PICTURE
Allows you to select your desired picture setting
from 5 types of picture settings.
6 SURF
Allows you to select up to a maximum of 10
channels and view quickly the selected channels.
7 CURSOR RIGHT
Allows you to access the sub-menus and adjust
the settings.
8 CURSOR DOWN
Allows you to select the next item on the menu.
9 CHANNEL + / –
Selects channel in ascending or descending order.
MUTE
Mutes sound. To restore sound, press button again.
20
TIMER
Allows you to set the clock to switch to another
21
channel at a specified time while you are watching
another channel or when the set is on standby mode.
44
4
44
Allows you to switch from Stereo to Mono sound
22
during stereo transmission or to choose between
language5or language6during dual sound
transmission.
TELETEXT
Allows you to access teletext informaion. For
23
detailed description of functions, refer to section on
“Using the Teletext”
PROGRAM LIST
Allows you to navigate through a list of installed
programs for a quick overview of the channels
24
and activate the channel you have selected.
ACTIVE CONTROL
Adjusts settings automatically for optimal picture
quality under any signal conditions (Refer to section
25
on “Using the Active Control”).
30321/Eng/p9-11 3/22/02, 10:22 AM10
10
FUNCTIONS OF TV CONTROLS
‘
(
–
VOLUME
+–
CHANNEL
+
➩
➩
A
&
é
“
Not Applicable
& Mains Power button Switch mains power on or off.
é Standby Light indicator Indicate red light when standby mode is activated.
“ Remote Sensor Acts as a sensor for activating the controls of the
TV when remote control handset is aimed at it.
‘ Volume + / – button Adjust sound volume louder/softer.
( Channel + / – button Select channel in ascending/descending order.
Note
• You can enter the main menu by pressing both the Volume + and – buttons at the
same time.
• Press the Channel + or – button to select the next item on the menu.
• Press the Volume + or – button to access the sub-menus and adjust the settings.
11
30321/Eng/p9-11 6/26/02, 2:46 PM11
SELECTING THE MENU LANGUAGE AND
AUTOMATIC TUNING OF CHANNELS
Operating instructions generally explains the operation of the TV set using
the buttons on the remote control unless otherwise stated. Please read the
following instructions carefully and follow the steps as shown to familiarise
yourself with the installations and all features available in your set.
Before you tune in the channels by the AUTO STORE method, select the menu language of
your choice. The LANGUAGE feature allows you to set the TV’s on-screen menu to be
shown in your desired language.
Press buttonStep
Enter main menu.
MENU
Press button repeatedly until
INSTALL is selected.
Enter INSTALL menu.
Result on screen
É
• PICTURE BRIGHTNESS
▼
• SOUND COLOUR
• FEATURES CONTRAST
• INSTALL SHARPNESS
• PICTURE LANGUAGE
• SOUND AUTO STORE
• FEATURES MANUAL STORE
▲
É
• INSTALL SORT
INSTALL
Ñ
LANGUAGE • ENGLISH
Ñ
• AUTO STORE B.MELAYU
▲
É
• MANUAL STORE
• SORT
• CHANNEL EDIT
COLOUR TEMP
CHANNEL EDIT
▲
É
▼
30321/Eng/p12-16 3/22/02, 10:23 AM12
12
SELECTING THE MENU LANGUAGE AND
AUTOMATIC TUNING OF CHANNELS
Press buttonStep
Enter LANGUAGE mode.
Select desired language.
OR
Exit from language mode.
Select AUTO STORE.
Start automatic tuning.
Result on screen
INSTALL
Ñ
LANGUAGE • ENGLISH
• AUTO STORE B.MELAYU
• MANUAL STORE
• SORT
•
CHANNEL EDIT
INSTALL
Ñ
LANGUAGE • ENGLISH
Ñ
• AUTO STORE B.MELAYU
▲
É
• MANUAL STORE
• SORT
• CHANNEL EDIT
INSTALL
Ñ
• LANGUAGE
Ñ
AUTO STORE • SEARCH
• MANUAL STORE
• SORT
• CHANNEL EDIT
INSTALL
Ñ
• LANGUAGE
• AUTO STORE • SEARCHING
• MANUAL STORE PLEASE WAIT
• SORT CHAN.FOUND 8
• CHANNEL EDIT 048.31 MHZ
É
▲
É
▼
▲
É
▼
▲
É
▼
When tuning is completed,
9
30321/Eng/p12-16 3/22/02, 10:23 AM13
i
exit menu from screen.
13
INSTALL
Ñ
• LANGUAGE
Ñ
AUTO STORE • SEARCH
• MANUAL STORE
• SORT
▲
É
• CHANNEL EDIT
▼
MANUAL TUNING OF CHANNELS
Manual tuning allows you to store each programme manually.
9
10
11
12
Press buttonStep
MENU
Enter main menu.
Press button repeatedly until
INSTALL is selected.
Enter INSTALL menu.
Press button repeatedly until
MANUAL STORE is selected.
Enter MANUAL STORE menu.
Select SEARCH.
Start manual tuning of channel.
Searching stops once a transmitting
channel is found.
Select CHANNEL.
2
3
1
4
7
Key in the desired channel number.
6
5
9
8
0
Select STORE.
Store tuned channel. Note : If you
want to continue searching for
another transmitting channel, repeat
steps 7 to 11.
i
Exit menu from screen.
Result on screen
• PICTURE LANGUAGE
• SOUND AUTO STORE
• FEATURES MANUAL STORE
▲
É
• INSTALL SORT
INSTALL
• LANGUAGE COLOUR SYSTEM
• AUTO STORE SOUND SYSTEM
▲
• MANUAL STORE SEARCH
▼
• SORT CHANNEL
• CHANNEL EDIT STORE
•
INSTALL
MANUAL STORE
• COLOUR SYSTEM
• SOUND SYSTEM
Ñ
SEARCH • 048.31MHZ
• CHANNEL
• STORE
INSTALL
MANUAL STORE
• COLOUR SYSTEM
• SOUND SYSTEM
Ñ
SEARCH • 196.25MHZ
• CHANNEL
• STORE
INSTALL
MANUAL STORE
• COLOUR SYSTEM
• SOUND SYSTEM • MANUAL
• SEARCH
Ñ
CHANNEL • 18
• STORE
INSTALL
MANUAL STORE
• COLOUR SYSTEM
• SOUND SYSTEM
• SEARCH
• CHANNEL
Ñ
STORE • STORED
INSTALL
MANUAL STORE
• COLOUR SYSTEM
• SOUND SYSTEM
Ñ
SEARCH • 196.25MHZ
• CHANNEL
• STORE
CHANNEL EDIT
▲
É
▼
▲
É
▼
▲
É
▼
▲
É
▼
▲
É
▼
30321/Eng/p12-16 3/22/02, 10:23 AM14
14
SELECTING THE COLOUR /SOUND SYSTEM
This feature allows you to select your desired COLOUR and SOUND system. If AUTO
is selected, the respective colour and sound system will be automatically selected according
to the transmission system.
Note : Select your desired colour and sound system manually if reception is poor at AUTO
mode.
9
10
11
12
Press buttonStep
Result on screen
Repeat step 1 to step 5 as in “MANUAL TUNING OF CHANNELS”
COLOUR SYSTEM is selected.
Enter COLOUR SYSTEM mode.
Select the desired colour system.
OR
Exit from colour system mode.
Proceed to select SOUND SYSTEM.
Enter SOUND SYSTEM mode.
Select the desired sound system.
OR
Exit from sound system mode.
Press button repeatedly until
STORE is selected.
Store selected system.
i
Exit menu from screen.
INSTALL
MANUAL STORE
Ñ
COLOUR SYSTEM • AUTO
• SOUND SYSTEM PAL•
• SEARCH SECAM
• CHANNEL
• STORE
INSTALL
MANUAL STORE
• COLOUR SYSTEM
Ñ
• SEARCH B/G
• CHANNEL D/K
• STORE
•
INSTALL
MANUAL STORE
• COLOUR SYSTEM
Ñ
SOUND SYSTEM • AUTO
• SEARCH B/G
• CHANNEL D/K
• STORE
INSTALL
MANUAL STORE
• COLOUR SYSTEM
• SOUND SYSTEM
• SEARCH
• CHANNEL
Ñ
STORE •
INSTALL
MANUAL STORE
• COLOUR SYSTEM
• SOUND SYSTEM
• SEARCH
• CHANNEL
Ñ
STORE • STORED
INSTALL
MANUAL STORE
• COLOUR SYSTEM
• SOUND SYSTEM
Ñ
SEARCH • 196.25MHZ
• CHANNEL
• STORE
É
▲
▼
▲
SOUND SYSTEM • AUTO
▼
▲
▼
▲
É
▼
▲
É
▼
▲
É
▼
30321/Eng/p12-16 3/22/02, 10:23 AM15
15
FINE TUNING OF CHANNELS
This feature allows you to adjust picture reception in areas of weak reception.
➠
MENU SURF
INSTALL
➠
• AUTO STORE B.MELAYU
• MANUAL STORE
• SORT
MENU SURF
MENU SURF
➠
• CHANNEL EDIT
1. Enter main menu. 2. Select INSTALL. 3. Enter install menu.
Step
Press button
Press button repeatedly until
MANUAL STORE is selected.
Enter MANUAL STORE menu.
Press button repeatedly until
FINE TUNE is selected.
Start fine-tuning until desired
OR
picture and sound is obtained.
Ñ
LANGUAGE • ENGLISH
Ñ
▲
É
▲
É
▼
▼
Result on screen
INSTALL
• LANGUAGE COLOUR SYSTEM
• AUTO STORE SOUND SYSTEM
▲
• MANUAL STORE SEARCH
▼
• SORT CHANNEL
• CHANNEL EDIT STORE
•
INSTALL
MANUAL STORE
Ñ
COLOUR SYSTEM • AUTO
• SOUND SYSTEM PAL
• SEARCH SECAM
• CHANNEL
• STORE
INSTALL
MANUAL STORE
• SOUND SYSTEM
• SEARCH
• CHANNEL
• STORE
Ñ
FINE TUNE
▲
É
▼
▲
▼
É
Select STORE.
9
10
30321/Eng/p12-16 3/22/02, 10:23 AM16
i
Store last fine-tuned status.
Exit menu from screen.
16
INSTALL
MANUAL STORE
• COLOUR SYSTEM
• SOUND SYSTEM
• SEARCH
• CHANNEL
Ñ
STORE • STORED
INSTALL
MANUAL STORE
• COLOUR SYSTEM
• SOUND SYSTEM
Ñ
SEARCH • 196.25MHZ
• CHANNEL
• STORE
▲
É
▼
▲
É
▼
SORTING OF CHANNELS
This feature allows you to change the channel number to your choice for a particular TV
station.
MENU SURF
MENU SURF
➠➠
MENU SURF
INSTALL
➠
• AUTO STORE B.MELAYU
• MANUAL STORE
• SORT
• CHANNEL EDIT
1. Enter main menu. 2. Select INSTALL. 3. Enter install mode.
Press buttonStep
Press button repeatedly until
SORT is selected.
Enter SORT menu.
2
3
1
4
7
1
4
7
9
10
Key in the channel number in the
6
5
FROM column, that is, the channel
9
8
you want to swap from.
0
Select TO .
Key in the channel number in the
2
3
TO column. that is, the channel
6
5
you want to swap to.
9
8
0
Select EXCHANGE.
Activate exchange of channels.
Ñ
LANGUAGE • ENGLISH
Ñ
▲
É
▲
É
▼
▼
Result on screen
INSTALL
• LANGUAGE FROM
• AUTO STORE TO
• MANUAL STORE EXCHANGE
▲
É
• SORT
▼
• CHANNEL EDIT
INSTALL
SORT
Ñ
FROM • 8
• TO
• EXCHANGE
INSTALL
SORT
• FROM 8
Ñ
TO • 6
• EXCHANGE
INSTALL
SORT
• FROM
• TO
EXCHANGE • EXCHANGED
Ñ
▲
É
▼
▲
É
▼
▲
É
11
30321/Eng/p17-20 3/22/02, 10:24 AM17
i
Exit menu from screen.
17
INSTALL
SORT
• FROM
• TO
EXCHANGE •
Ñ
▼
▲
É
▼
EDITING OF CHANNELS
This feature allows you to edit or skip channels which have bad or weak TV signal or channels
that you do not watch often.
Note : Once a channel is skipped, you cannot have access to it by the CHANNEL + or –
button. You can only access the channel by the DIGIT (0 -9) button.
➠
MENU SURF
INSTALL
Ñ
LANGUAGE • ENGLISH
Ñ
➠
• AUTO STORE B.MELAYU
▲
É
• MANUAL STORE
• SORT
MENU SURF
MENU SURF
➠
• CHANNEL EDIT
1. Enter main menu. 2. Select INSTALL. 3. Enter install mode.
Press buttonStep
Press button repeatedly until
Result on screen
INSTALL
CHANNEL EDIT is selected.
OR
i
Enter channel edit mode.
Select the channel you want to skip.
Activate skipped mode.
Exit menu from screen.
INSTALL
• LANGUAGE 3
• AUTO STORE 4
• MANUAL STORE 5
• SORT 6
Ñ
INSTALL
• LANGUAGE 3
• AUTO STORE 4
• MANUAL STORE 5
• SORT 6
Ñ
▲
É
▼
▼
• LANGUAGE 3
• AUTO STORE 4
• MANUAL STORE 5
• SORT 6
Ñ
CHANNEL EDIT • 7
CHANNEL EDIT • 7
CHANNEL EDIT • 7 SKIPPED
▲
É
▼
▲
É
▼
▲
É
▼
How to add back channels
• Repeat steps 1 to 5 as in “Editing of Channels”.
• Select the channel you want to add back by the (CURSOR UP) or (CURSOR
DOWN) button.
• Press the (CURSOR RIGHT) button to activate adding back of channel.
• Exit menu from screen by the (OSD) button.
i
18
30321/Eng/p17-20 3/22/02, 10:24 AM18
NAMING OF CHANNELS
This feature allows a selection of 10 channels of pre-defined names. It also allows you to enter
a new name or modify an existing name of a channel for 40 channels including external
channels.
➠
MENU SURF
INSTALL
➠
Ñ
• AUTO STORE B.MELAYU
• MANUAL STORE
• SORT
MENU SURF
MENU SURF
➠
• CHANNEL EDIT
1. Enter main menu. 2. Select INSTALL. 3. Enter install mode.
Press buttonStep
Press button repeatedly until
NAME is highlighted.
Enter NAME mode.
Select desired preset name and press
(CURSOR RIGHT) button
OR
to store selected pre-set name.
If you select PERSONAL, move
to first character slot
Press button repeatedly to cycle
through the characters and select
OR
desired character.
Move to next character slot by the
(CURSOR RIGHT) button
and select in the next character.
(You can enter up to a maximum
of 5 characters)
MENU
9
10
Store named channel.
i
Exit menu from screen.
Ñ
LANGUAGE • ENGLISH
▲
É
▲
É
▼
▼
Result on screen
INSTALL
• AUTO STORE
• MANUAL STORE
• SORT
• CHANNEL EDIT
Ñ
NAME • 8
INSTALL
• AUTO STORE
• MANUAL STORE
• SORT
• CHANNEL EDIT
Ñ
NAME • PERSONAL
INSTALL
• AUTO STORE
• MANUAL STORE
• SORT
• CHANNEL EDIT
Ñ
NAME • –
INSTALL
• AUTO STORE
• MANUAL STORE
• SORT
• CHANNEL EDIT
NAME • LUCKY
Ñ
INSTALL
• AUTO STORE
• MANUAL STORE
• SORT
• CHANNEL EDIT
Ñ
NAME • PERSONAL
▲
▲
É
▼
▲
É
▼
▲
É
▼
▲
É
▼
▲
▲
É
30321/Eng/p17-20 3/22/02, 10:24 AM19
19
USING THE PICTURE/SOUND MENU
The picture and sound menus allow you to make adjustments to the picture and sound. It also
allow you to select and activate other features in the menu.
1. Press the (MENU) button to enter main menu.
MENU
2. Use the or (CURSOR UP/DOWN) buttons to select the items on the
PICTURE/SOUND menu.
3. Use the or (CURSOR LEFT/RIGHT) buttons to access the sub-menus.
Picture Activities
menu items
Brightness Increase or decrease brightness level.
Colour Increase or decrease color level.
➠
Ñ
• COLOUR
• CONTRAST
• SHARPNESS
• COLOUR TEMP
BRIGHTNESS 38
▲
Contrast Increase or decrease contrast level
until lightest parts of the picture show
good detail.
Sharpness Increase or decrease sharpness level
Colour Temp Allows you a choice of 3 picture settings
Digital Scan Selecting the “ON” option allows you to
to improve detail in the picture.
(NORMAL, WARM and COOL).
reduce picture flickering while watching
• CONTRAST
• SHARPNESS
• COLOUR TEMP
• DIGITAL SCAN
Ñ
DYN. CONTRAST • MIN
➠
▲
▲
É
TV programmes.
Dynamic Allows you a choice of 3 settings
Contrast (Minimum, Medium and Maximum) to
boost the contrast level especially in
dark scene so as to make the picture
more noticeable.
Note : HUE feature is
only applicable to NTSC
programmes. The HUE item
will not appear on the menu
if programme is in PAL mode.
É
Sound Activities
menu items
Treble Increase or decrease the high frequency
level.
Bass Increase or decrease the low frequency
level.
Balance Adjusts the balance of the right and left
speakers’ sound output.
AVL As variation in signal conditions can
(Auto Volume result in a sudden change in volume
Leveller) during commercial breaks or channel
switching, selecting the “ON” function
will enable the volume to remain at a
standard volume level.
Headphone Allows you to adjust the volume and
balance of the headphone.
20
30321/Eng/p17-20 3/22/02, 10:24 AM20
SOUND
➠
Ñ
TREBLE 38
• BASS
• BALANCE
• AVL
• HEADPHONE
➠
SOUND
• TREBLE VOLUME
• BASS BALANCE
• BALANCE
• AVL
Ñ
HEADPHONE
▲
É
USING THE ACTIVE CONTROL FEATURE
This feature automatically adjust settings for optimal picture quality continuously under any
signal conditions. To activate the Active Control feature, select the “ON” option in the
Active Control menu.
How to access the Active Control function
1. Press the (MENU) button to enter main menu
and press the (CURSOR DOWN) button
repeatedly until FEATURES is selected.
2. Press the (CURSOR RIGHT) button to
enter FEATURES menu.
3. Press the (CURSOR DOWN) button to
select ACTIVE CONTROL.
MENU
• PICTURE TIMER
• SOUND ACTIVE CONTROL
▲
É
• FEATURES CHILD LOCK
▼
• INSTALL PIP
FEATURES
• TIMER •
Ñ
ACTIVE CONTROL • OFF
• CHILD LOCK
• PIP
• FORMAT
FORMAT
▲
É
4. Press the (CURSOR RIGHT) button
repeatedly to select ON, option to activate the
Active Control function.
Note : You can also access the ACTIVE CONTROL
function directly by the (ACTIVE CONTROL)
ACTIVE CONTROL
h
button. When ON option is selected via the
(ACTIVE CONTROL) button, the settings of
SHARPNESS and NOISE REDUCTION will be
displayed on the screen.
5. Press the (OSD) button to exit menu from screen.
30321/Eng/p21-23 5/11/02, 11:24 AM21
i
21
ACTIVE CONTROL
h
FEATURES
• TIMER •
Ñ
ACTIVE CONTROL • ON
• CHILD LOCK
• PIP
• FORMAT
▲
É
ACTIVATING THE TIMER
The Timer feature allows you to set the timer to switch to another channel at a specified
time while you are watching another channel or when the TV is on standby mode.
Note : For the timer to function, the set must not be switched off. Once the set is switched
off, the timer is disabled.
Press buttonStep
Enter TIMER menu.
C
Enter TIME mode.
2
1
4
5
8
7
0
MENU
2
1
4
5
8
7
0
Key in the current time For
3
example, if the current time
6
is 12:30, key digit 1 and 2 in the
9
hour column, followed by digit
3 and 0 in the minute column.
Exit from TIME mode.
Select START TIME.
Enter the START TIME mode.
3
Key in the time you want the
6
programme to be switched on.
9
Result on screen
FEATURES
TIMER
Ñ
TIME • --:--
• START TIME
• STOP TIME
• CHANNEL
• ACTIVATE
FEATURES
TIMER
Ñ
TIME • 12:30
• START TIME
• STOP TIME
• CHANNEL
• ACTIVATE
FEATURES
TIMER
• TIME 12:30
Ñ
START TIME • --:--
• STOP TIME
• CHANNEL
• ACTIVATE
FEATURES
TIMER
TIME
Ñ
• START TIME • 13:30
• STOP TIME
• CHANNEL
• ACTIVATE
▲
É
▼
▼
É
▲
É
▼
▼
É
▲
▼
▲
▼
MENU
9
10
2
11
30321/Eng/p21-23 3/22/02, 10:25 AM22
1
4
5
8
7
0
Exit from START TIME mode.
Select STOP TIME.
Enter STOP TIME mode.
3
Key in the time you want the
6
programme to be switched off.
9
22
FEATURES
TIMER
• TIME
• START TIME
STOP TIME • --:--
• CHANNEL
Ñ
• ACTIVATE
FEATURES
TIMER
• TIME
• START TIME
Ñ
STOP TIME • 15:30
• CHANNEL
• ACTIVATE
▲
É
▼
▼
▲
É
▼
ACTIVATING THE TIMER
12
Press buttonStep
MENU
Exit from STOP TIME mode.
Select CHANNEL.
2
3
1
4
7
9
i
Key in the channel you want to
6
5
switch to.
9
8
0
Select ACTIVATE.
Activate timer. You can select
to activate timer by DAILY or
ONCE mode.
Select DISPLAY.
Select ON mode if you want to
display the current time on the
TV creen.
Exit menu from screen.
Result on screen
FEATURES
TIMER
• TIME
• START TIMEE
• STOP TIME
Ñ
CHANNEL • 3
• ACTIVATE
FEATURES
TIMER
• TIME
• START TIMEE
• STOP TIME
Ñ
CHANNEL • 8
• ACTIVATE
FEATURES
TIMER
• TIME
• START TIMEE
• STOP TIME
• CHANNEL
Ñ
ACTIVATE • OFF
FEATURES
TIMER
• TIME
• START TIMEE
• STOP TIME
• CHANNEL
Ñ
ACTIVATE • ONCE
FEATURES
TIMER
• START TIME
• STOP TIMEE
• CHANNEL
• ACTIVATE
Ñ
DISPLAY • ON
▲
É
▼
▼
▲
É
▼
▼
▲
É
▼
▼
▲
É
▼
▼
▲
É
Note
30 seconds before the timer is activated, a message indicating the time left for the channel
switch will appear on the screen. To disable the channel switch, press any button on the
remote control.
23
30321/Eng/p21-23 3/22/02, 10:25 AM23
ACTIVATING THE CHILD LOCK (ACCESS CODE)
The Child Lock feature allows you to lock channels to prevent your children from watching
programmes you deem undesirable.
Note : You cannot have access to the locked channels via the top controls of the TV set.
You can only have access to the locked channels via the remote control. Keep the remote
control out of reach so as to prevent your children from having access to it.
MENU SURF
MENU SURF
➠
➠
MENU SURF
FEATURES
▲
É
• TIMER TIME
▼
➠
• ACTIVE CONTROL START TIME
• CHILD LOCK STOP TIME
• PIP CHANNEL
• FORMAT ACTIVATE
1. Enter main menu. 2. Select FEATURES . 3. Enter FEATURES menu.
Press buttonStep
Select CHILD LOCK .
Enter ACCESS CODE mode.
2
3
1
4
5
8
7
0
2
1
4
5
8
7
0
Key in access code 0711
6
(0711 is the default access code).
9
A message INCORRECT will
appear.
Key in 0711 the second time.
3
6
When the message CORRECT
9
appears, the CHILD LOCK
menu is now accessible.
Result on screen
FEATURES
• TIMER ACCESS CODE
• ACTIVE CONTROL
▲
É
• CHILD LOCK
▼
• PIP
• FORMAT
FEATURES
• TIMER ACCESS CODE
• ACTIVE CONTROL
Ñ
CHILD LOCK INCORRECT
• PIP
• FORMAT
FEATURES
• TIMER ACCESS CODE
• ACTIVE CONTROL
Ñ
CHILD LOCK CORRECT
• PIP
• FORMAT
- - - -
– – – –
X X X X
You can now proceed to change
the access code of your choice.
30321/Eng/p24-28 5/11/02, 11:26 AM24
24
FEATURES
CHILD LOCK
Ñ
LOCK CHANNEL • 2
• CHANGE CODE 3
• CLEAR ALL 4
▲
É
5
6
ACTIVATING THE CHILD LOCK (CHANGE CODE)
9
10
11
Press buttonStep
Select CHANGE CODE.
Enter CHANGE CODE mode.
2
3
1
4
5
8
7
0
2
1
4
5
8
7
0
Key in the access code of your
6
choice.
9
3
Confirm access code.
6
9
When the new code is confirmed,
the message CORRECT will
appear.
Result on screen
FEATURES
CHILD LOCK
• LOCK CHANNEL ENTER
Ñ
CHANGE CODE NEW CODE
• CLEAR ALL
FEATURES
CHILD LOCK
• LOCK CHANNEL ENTER
Ñ
CHANGE CODE NEW CODE
• CLEAR ALL
FEATURES
CHILD LOCK
• LOCK CHANNEL CONFIRM
Ñ
CHANGE CODE CODE
• CLEAR ALL
FEATURES
CHILD LOCK
• LOCK CHANNEL CONFIRM
Ñ
CHANGE CODE CODE
• CLEAR ALL
– – – –
x x x x
x x x x
x x x x
CORRECT
12
i
Exit menu from screen.
Note : After you have exit menu from screen and you want to enter child lock menu again ,
you need to key the new access code only once. If you have forgotten the new access code,
key in 0711 twice to enter the child lock menu. Upon entering the child lock menu, you can
proceed to change code again.
25
30321/Eng/p24-28 3/22/02, 10:25 AM25
ACTIVATING THE CHILD LOCK (LOCK CHANNEL)
MENU SURF
➠
MENU SURF
➠
MENU SURF
FEATURES
➠
▲
É
• TIMER TIME
▼
• ACTIVE CONTROL START TIME
• CHILD LOCK STOP TIME
• PIP CHANNEL
• FORMAT ACTIVATE
1. Enter main menu. 2. Select FEATURES. 3. Enter FEATURES menu.
Press buttonStep
Select CHILD LOCK .
Result on screen
FEATURES
• TIMER ACCESS CODE
• ACTIVE CONTROL
▲
É
• CHILD LOCK
▼
• PIP
• FORMAT
Enter ACCESS CODE mode.
2
3
1
4
5
8
7
0
Key in access code .
6
9
FEATURES
• TIMER ACCESS CODE
• ACTIVE CONTROL
Ñ
CHILD LOCK CORRECT
• PIP
• FORMAT
Enter LOCK CHANNEL mode.
FEATURES
CHILD LOCK
Ñ
LOCK CHANNEL • 2
• CHANGE CODE 3
OR
Select the channel you want to block.
• CLEAR ALL
- - - -
X X X X
É
4
5
6
9
10
i
Activate blocking of channel. A
keylock symbol will appear beside
the channel number indicating that
it is locked.
Exit menu from screen.
FEATURES
CHILD LOCK
Ñ
LOCK CHANNEL • 3
• CHANGE CODE 4
• CLEAR ALL
É
Note : You cannot have access to the locked channels via the top controls of the TV set.
You can only have access to the locked channels via the remote control.
When AV1 source is locked, CV1 source is automatically locked. Like-wise, if CV1 source is
locked, AV1 source is also automatically locked as they share the same audio input.
If you attempt to enter the INSTALL menu after locking a channel, a message
“Enter ACCESS CODE” will appear on the screen. You need to enter the ACCESS CODE
to enable you to enter the INSTALL menu.
26
30321/Eng/p24-28 5/11/02, 11:27 AM26
FF
F
FF
5
6
7
ACTIVATING THE CHILD LOCK (CLEAR ALL)
To unlock channels that you have locked, enter the Child Lock menu and activate the
CLEAR ALL mode.
MENU SURF
MENU SURF
MENU SURF
➠➠
FEATURES
▲
➠
É
• TIMER TIME
▼
• ACTIVE CONTROL START TIME
• CHILD LOCK STOP TIME
• PIP CHANNEL
• FORMAT ACTIVATE
1. Enter main menu. 2. Select FEATURES 3. Enter FEATURES menu.
Press buttonStep
Select CHILD LOCK.
Enter ACCESS CODE mode.
2
3
1
4
5
8
7
0
Key in access code.
6
9
Press button repeatedly until
CLEAR ALL is selected.
Result on screen
FEATURES
• TIMER ACCESS CODE
• ACTIVE CONTROL
▲
É
• CHILD LOCK
▼
• PIP
• FORMAT
FEATURES
• TIMER ACCESS CODE
• ACTIVE CONTROL
Ñ
CHILD LOCK CORRECT
• PIP
• FORMAT
FEATURES
CHILD LOCK
• LOCK CHANNEL
• CHANGE CODE
Ñ
CLEAR ALL •
- - - -
X X X X
▲
É
FEATURES
Activate clearing of all locked
channels.
9
i
Exit menu from screen.
CHILD LOCK
• LOCK CHANNEL
• CHANGE CODE
Ñ
CLEAR ALL • CLEARED
Note
You can also unlock individual channel by the LOCK CHANNEL menu.
• Repeat step 1 to 7 as in “ACTIVATING THE CHILD LOCK (LOCK CHANNEL)”.
• Select the channel you want to unlock by the or (CURSOR UP / DOWN) buttons.
• Press the (CURSOR RIGHT) button to unlock channel (the keylock symbol will
disappear).
27
30321/Eng/p24-28 5/11/02, 11:27 AM27
▲
É
USING THE SURF CONTROL
A list or series of previously viewed channels can be selected with the SURF button. This
feature allows you to switch between different TV programmes that currently interest you.
You can set up to a maximum of ten channels in the SURF list.
How to add a channel to the surf list
1
4
i
Press buttonStep
2
3
Select a channel you want to
6
5
add to the surf list.
9
8
7
0
SURF
Enter SURF menu.
Add selected channel to the
surf list.
Repeat steps 1 - 3 to add more
channels to the surf list.
After you have completed adding the
selected channels to the surf list, exit
menu from screen.
Result on screen
8
SURF
É
• 8 ADD?
SURF LIST EMPTY
SURF
É
• 8 DELETE?
SURF
• 8
É
• 5 ADD?
SURF
• 8
É
• 5 DELETE?
Note : To view the the selected channels in the surf list, press the SURF button repeatedly
to cycle through the channels.
How to delete a channel from the surf list
1. Press the (SURF) button to display surf list.
2. Press the (SURF) button repeatedly to cycle through the surf list and select the
channel you want to delete.
3. Press the (CURSOR RIGHT) button to delete channel from the surf list.
4. Repeat all the above steps if you want to delete more channels from the surf list.
SURF
SURF
28
30321/Eng/p24-28 3/22/02, 10:25 AM28
USING THE SCREEN FORMAT
You can have a choice of different formats for your viewing pleasure, namely : - Auto, 4:3
mode, EXPAND 4:3 mode and COMPRESS 16:9 mode through the FORMAT menu.
How to access the Screen Format
1. Press the (MENU) button to enter main menu
and press the (CURSOR DOWN) button
repeatedly until FEATURES is selected.
2. Press the (CURSOR RIGHT) button to
enter FEATURES menu.
3. Press the (CURSOR DOWN) button
repeatedly until FORMAT is selected.
4. Press the (CURSOR RIGHT) button
repeatedly to cycle through the different formats
(Auto, 4:3, Expand 4:3 or Compress 16:9) and
select your desired format.
Note : You can also select your desired Screen Format
directly by the (CURSOR UP) or
(CURSOR DOWN) button
When to use the Screen Formats
AUTO format
When AUTO format is selected, it will
select the correct screen format provided
the specific signals are transmitted with
the programmes.
4:3 format
Select the 4:3 format if you want to display
the 4:3 picture using the full surface of the
screen.
MENU
• PICTURE TIMER
• SOUND ACTIVE CONTROL
▲
É
• FEATURES CHILD LOCK
▼
• INSTALL PIP
FEATURES
• TIMER
• ACTIVE CONTROL
• CHILD LOCK
• PIP
Ñ
FORMAT • AUTO
FORMAT
▲
É
EXPAND 4:3 format
Select the EXPAND 4:3 format if you want
to expand movie images recorded in the
letterbox format. When this format is
selected, the black horizontal bars at the
top and bottom are expanded thus filling
up the entire TV screen.
COMPRESS 16:9 format
Select the COMPRESS 16:9 format if you
want to compress full screen movie images
into letterbox format. When this format is
selected, black horizontal bars can be seen
at the top and bottom of the TV screen.
30321/Eng/p29-32 5/11/02, 11:35 AM29
29
➩
➩
➠
➩
➩
➠
➩
USING THE ROTATION FEATURE
Due to the earth’s magnetic field and positoin of the TV set, slight tilting of the picture to the
left or right may occur when the set is switched on. When this phenomenon occurs, select
ROTATION in the FEATURE menu and adjust accordingly by the Cursor Right or Left
button.
How to use the Rotation Feature
1. Press the (MENU) button to enter main menu
and press the (CURSOR DOWN) button
repeatedly until FEATURES is selected.
2. Press the (CURSOR RIGHT) button to
enter FEATURES menu.
3. Press the (CURSOR DOWN) button
repeatedly until ROTATION is selected.
4. Press the (CURSOR RIGHT) button
when picture is tilted to the left. Press button
until you deem picture is in normal position.
If picture is tilted to the right, press the
(CURSOR LEFT) button until you
deem picture is in normal position.
MENU
• PICTURE TIMER
• SOUND ACTIVE CONTROL
▲
É
• FEATURES CHILD LOCK
▼
• INSTALL PIP
FEATURES
• ACTIVE CONTROL
• CHILD LOCK
• PIP
• FORMAT
Ñ
ROTATION • 1
FEATURES
• ACTIVE CONTROL
• CHILD LOCK
• PIP
• FORMAT
Ñ
ROTATION • 8
FORMAT
▲
É
▲
É
Picture tilted to the left
PHILIPS
Picture tilted to the right
PHILIPS
30321/Eng/p29-32 5/11/02, 11:35 AM30
After adjustment
➠
PHILIPS
After adjustment
➠
PHILIPS
30
USING THE BLUE MUTE FEATURE
Blue Mute feature indicates to you the absence of signalwhen the TV screen turns blue. To
activate the Blue Mute feature, select the “ON” option in the Blue Mute menu.
How to access the Blue Mute function
1. Press the (MENU) button to enter main menu
and press the (CURSOR DOWN) button
repeatedly until FEATURES is selected.
2. Press the (CURSOR RIGHT) button to
enter FEATURES menu.
3. Press the (CURSOR DOWN) button
repeatedly until BLUE MUTE is selected.
MENU
• PICTURE TIMER
• SOUND ACTIVE CONTROL
▲
É
• FEATURES CHILD LOCK
▼
• INSTALL PIP
FEATURES
• CHILD LOCK
• PIP
• FORMAT
• ROTATION
Ñ
BLUE MUTE • OFF
FORMAT
▲
É
4. Press the (CURSOR RIGHT) button
to select ON option to activate the Blue Mute
function.
5. Press the (OSD) button to exit menu from screen.
i
FEATURES
• CHILD LOCK
• PIP
• FORMAT
• ROTATION
Ñ
BLUE MUTE • ON
▲
É
USING THE PROGRAM LIST FEATURE
Program listing feature allows you to navigate through a list of installed programmes for a
quick overview of the channels and activate the channel you have selected.
PROGRAM LIST
1. Press the (PROGRAM LIST) button to
display the list of installed programmes. The current
channel is highlighted.
2. Press the (CURSOR UP) or
(CURSOR DOWN) button to cycle through
the programme list and highlight the channel
number you want to activate.
3. Press the (CURSOR RIGHT) button to
activate the channel you have selected.
4. Press the (OSD) button to exit menu
from screen.
î
i
PROGRAM LIST
▲
É
• 1
– – – – –
2
– – – – –
3
– – – – –
4
– – – – –
5
– – – – –
▼
PROGRAM LIST
▲
1
ACTIO
2
DRAMA
3
VOILE
4
ROMAN
É
• 5
– – – – –
▼
FF
F
FF
30321/Eng/p29-32 5/11/02, 11:35 AM31
31
SMART PICTURE AND SMART SOUND CONTROL
SMART PICTURE feature offers you a choice of 5 picture settings, namely, RICH,
NATURAL, SOFT, PERSONAL and MULTIMEDIA.
SMART SOUND feature offers you a choice of 4 sound settings, namely, THEATRE,
MUSIC, VOICE and PERSONAL.
Note : If you want to view the pre-set settings for Brightness, Colour, Contrast and Sharpness
levels, for Smart Picture and pre-set settings for Treble and Bass levels for Smart Sound, you
a
i
SMART
M
(Suitable for AV mode in brightly-lit room)
(Suitable for dimly-lit room condition and
gives cinema-like effect when light is
switched off).
playing computer games, surfing, etc.)
PERSONAL
RICH
NATURAL
SOFT
must press the (OSD) button for 5 seconds.
SMART
Press (SMART PICTURE) or (SMART SOUND) button repeatedly to cycle
through the settings to select your desired mode.
Definition of Picture Settings
PERSONAL : Picture settings are set to your preference.
RICH : Emphasize very vibrant colours.
NATURAL : Emphasize original colours.
SOFT : Emphasize “warm” colours.
MULTIMEDIA : Emphasize “soft” colours. (Suitable for
Note : The PERSONAL setting is the setting that you
set up using the Picture menu in the main menu. This
is the only setting in the Smart Picture settings that
can be changed. All the other settings are pre-set at
the factory.
Definition of Sound Settings
PERSONAL : Sound settings are set to your preference.
VOICE : Emphasize high tone. (Treble boosted)
MUSIC : Emphasize low tone. (Bass boosted)
THEATRE : Emphasize sensation to action.
(Bass and Treble boosted)
32
30321/Eng/p29-32 3/22/02, 10:26 AM32
MULTIMEDIA
PERSONAL
VOICE
MUSIC
THEATRE
ACTIVATING THE PIP (PICTURE-IN-PICTURE)
AND DOUBLE WINDOW CONTROL
Picture-in-Picture feature allows you to call up a subscreen within your main screen
enabling you to watch two channels at the same time.
Double Window feature allows you to divide the main screen into two sub-screens
enabling two channels to be watched simultaneously.
Note : PIP and Double Window features cannot be activated when teletext mode is on.
How to switch on the PIP/Double Window screen
Press the (PIP On/Off) button to switch on
PIP mode. (A normal size PIP screen appears).
æ
Press the button the second time to change
æ
the normal size PIP screen to a smaller size.
Press the button the third time to switch to
æ
Double Window screens in 4:3 format.
Press the button the fourth time to switch to
æ
Double Window screens in 16:9 format.
Note : When the programme on the PIP screen is
in NTSC mode or transmission, the picture size
appears smaller. Likewise, when programme on the
main screen is in NTSC mode or transmission, the
picture size appears smaller.
Press the button the fifth time to switch off
æ
16:9 Double Window screens.
16:9 format (NTSC mode)
30321/Eng/p33-39 3/22/02, 10:27 AM33
4:3 format (NTSC mode)
33
ACTIVATING THE PIP (PICTURE-IN-PICTURE) CONTROL
2
3
4
How to select a PIP channel
æ
D
A/CH
æ
q©
PIP
ßê
UP DN
• Press the (PIP On/Off) button to
B
S
PIP CH
switch on PIP screen.
D
A/CH
æ
q©
D
A/CH
æ
q©
D
A/CH
æ
q©
PIP
ßê
UP DN
PIP
ßê
UP DN
PIP
ßê
UP DN
B
S
PIP CH
Down) button to select a PIP channel
in ascending or descending order.
• Press the (PIP Up) or (PIP
UP
DN
How to freeze the PIP screen
B
S
PIP CH
to switch on PIP screen.
• Press (PIP Freeze) button once
to freeze the PIP screen
• Press the (PIP On/Off) button
B
S
PIP CH
screen allows you to view a programme
in the still mode. For example, you may
want to write down some information
from the PIP screen, freezing the screen
will allow you time to do so.
• Press the (PIP Freeze) button
the second time to unfreeze the
PIP screen.
æ
ê
. Freezing the PIP
PIP Freeze
ê
PIP Unfreeze
34
30321/Eng/p33-39 3/22/02, 10:27 AM34
ACTIVATING THE PIP (PICTURE-IN-PICTURE) CONTROL
How to position the PIP screen
æ
ß
➠
➠
➠
➠
æ
➠
©
➠
D
A/CH
æ
q©
D
A/CH
æ
q©
D
A/CH
æ
q©
D
A/CH
æ
q©
PIP
ßê
UP DN
PIP
ßê
UP DN
PIP
ßê
UP DN
PIP
ßê
UP DN
• Press the (PIP On/Off)
B
S
PIP CH
button to switch on PIP
screen.
• Press the (PIP Position)
button repeatedly to your
desired position. (You can
B
S
PIP CH
choose the PIP screen to be on
the top left corner, top right
corner, bottom right corner
or the top bottom left corner).
How to swap the PIP screen and the main screen
• Press the (PIP On/Off)
B
S
PIP CH
B
S
PIP CH
button to switch on PIP
screen.
• Press the (PIP Swap)
button to swap the programme
in the PIP screen and the
programme in the main screen.
How to adjust the PIP Hue setting
1. Press the (MENU) button to enter main menu.
2. Press the (CURSOR DOWN) button
repeatedly until FEATURES is selected.
3. Press the (CURSOR RIGHT) button to enter
the FEATURES menu.
4. Press the (CURSOR DOWN) button repeatedly
until PIP is selected.
5. Press the (CURSOR RIGHT) button to enter
PIP menu.
6. Press the (CURSOR LEFT) or (CURSOR
RIGHT) button to adjust HUE setting to your desired level.
7. Press the (OSD) button to exit menu from screen.
Note : Hue adjustments in the PIP programmes will only
take effect if programmes are in NTSC mode.
30321/Eng/p33-39 5/11/02, 11:20 AM35
MENU
i
35
• PICTURE TIMER
• SOUND ACTIVE CONTROL
▲
É
• FEATURES CHILD LOCK
▼
• INSTALL PIP
FORMAT
FEATURES
• TIMER HUE
• ACTIVE CONTROL
• CHILD LOCK
▲
É
• PIP
▼
• FORMAT
FEATURES
PIP
Ñ
▲
HUE 3
USING THE TELEXTEXT
Applicable to model 29PT8420 ONLY
If a TV channel broadcast contains teletext information, each channel that broadcasts
teletext transmits a page (index page) with information on how to use the teletext system,
usually on page 100. The system transmitted is indicated in the option line at the bottom
of the screen.
Press button
1 On/Off teletext Press the button once to switch on
and teletext display. (A channel in which
Superimpose teletext is being transmitted must be
D
A/CH
q©
2
1
4
7
M
MENU SURF
PIP
æ
ßê
PIP CH
UP DN
2
5
8
0
B
S
3
6
9
SMARTSMART
a
3
¬
i
f◊
ACTIVE CONTROL
h
CH
XC
gU
PROGRAM LIST
î
V
5
4
1
AV
bh
6
DOLBY.V
teletext page selected).
over TV Press the button the second time
programme superimpose the teletext page over
b
2 Selecting a Key in the required teletext page
teletext page (3 digits). The page number is
2
1
4
7
3
6
5
9
8
0
3 Accessing Press the CURSOR UP button to
a teletext display the next page and the
page CURSOR DOWN button to
Result on screen
the TV programme.
Press the button the third time
to exit teletext mode.
displayed at the top left hand corner
of the screen. When the teletext
page is located, the counter stops
searching. If the counter keeps
searching, it means that the page is
not available for selection. If you
make a mistake in keying the page
number, you have to complete
keying the 3-digit number before
re-keying the correct page number.
display the previous page.
30321/Eng/p33-39 3/22/02, 10:28 AM36
4 Direct Access to The 4-colour buttons allow you to
an item or access directly an item or
corresponding corresponding pages.
pages
5 Main Index Press the button to return to the
6 Enlarge Press the button once to enlarge and
i
h
main index page.
view the top half of the page.
Press the button the second time to
enlarge and view the bottom half of
the page. Press the button the third
time to return to normal size page.
36
USING THE TELETEXT
10
Press button
7 Hold Not applicable.
D
A/CH
q©
1
4
7
M
MENU SURF
8
V
AV
bh
DOLBY.V
PIP
æ
2
5
8
0
¬
i
f◊
ACTIVE CONTROL
h
B
S
ßê
PIP CH
UP DN
3
6
9
SMARTSMART
a
CH
XC
gU
PROGRAM LIST
î
8 Selecting a For a teletext page with sub-pages,
sub-page press the Cursor Left or Right
9 Subcode/ By adding a sub-code, you can call up
Time a sub-page and hold it. Enterthe
Display teletext page number (the teletext
8
7
9
g
U
Result on screen
button to access the previous subpage or the next subpage.
page must have sub- pages in it).
Press the button and “* * * * “ is
displayed at the upper left hand corner.
Enter the subpage with 4 digits : e.g.
0003 for 3/4 (third of 4 pages). You
can also use the Cursor Left and
Rightbuttons to access the sub-page.
To cancel the subcode, press button
again.
Press this button during normal
viewing (only applicable to those
channels that is broadcasting teletext),
to display the time at the top right
hand corner of the screen.
10 Reveal/ Press the button once to reveal hidden
Conceal information (solutions to puzzles,
riddles, etc). Press the button the
second time to conceal information.
f
This button is applicable only to
teletext page with puzzles, riddles, etc.)
How to select your favourite page
This feature allows you select 4 of your favourite or most commonly viewed page and stored
them in the favourite page selection. You can then access directly your favourite page by the
colour buttons without having to key in the page number.
1. Press the TELEXTEXT ON/OFF) button to enter teletext mode.
2. Press the (MENU) button to enter favourite page selection. Note : The colour
alphabets at the bottom of the screen is now changed to page numbers.
3. Key in your favourite page by the (DIGIT 0 -9) buttons.
4. Press the (INDEX/OSD) button to highlight pager numbers.
b
MENU
2
3
1
4
6
5
9
8
7
i
0
5. Select the colour button on your remote control you want your favourite page to be stored.
6. Repeat step 3 to 5 to select and store other favourite pages.
37
30321/Eng/p33-39 3/22/02, 10:28 AM37
SPECIFICATIONS
34PT8420
Picture tube screen size 850 mm
Picture tube visible area 800 mm
Audio Output :
Speaker 2 x 10 W
Subwoofer 10 W
TV System
NTSC M
PAL B/G
PAL D/K
PAL I
SECAM B/G
SECAM D/K
SECAM K1
Playback System NTSC 3.58, NTSC 4.43, PAL 60
Set Dimensions :
Width 895 mm
Depth 587 mm
Height 699 mm
Net Weight of Set (approximate ) approximate 69 kg
Note
For Operating Voltage, Frequency, Power Consumption and Version Number, refer to the
type number at the rear of the set.
38
30341/Eng/p38-39 5/21/02, 3:06 PM38
30341/Eng/p38-39 5/21/02, 3:06 PM39
3139 125 30341
Loading...
