Contents
Use Philips EasyLink 24
Use a Kensington lock 26
1 Notice 2
2 Important
3 Your TV
TV overview 5
3
5
4 Use your TV 7
Switch your TV on/off or to standby 7
Switch channels 7
Watch connected devices 8
Adjust TV volume
8
5 Use more of your TV 9
Access TV menus 9
Change picture and sound settings 9
Create and use lists of favorite channels 12
Use timers 13
Use child control 14
Use the TV clock 14
View photos, play music and watch video
from a USB storage device 15
Use Scenea to display a picture as TV
wallpaper 17
Update the TV software 18
Change TV preferences 18
Start a TV demo 18
Reset the TV to factory settings 19
8 Product information 27
9 Troubleshooting 29
10 Index 31
English
6 Install channels 20
Automatically install channels 20
Manually install channels 20
Rename channels 20
Rearrange channels 21
7 Connect devices 22
Back connectors 22
Side connectors 22
Connect a computer 23
Use dual view 23
Assign devices 27
EN
1
Page 4
1 Notice
2009 © Koninklijke Philips Electronics N.V. All
rights reserved.
Speci cations are subject to change without
notice. Trademarks are the proper ty of
Koninklijke Philips Electronics N.V. or their
respective owners. Philips reserves the right
to change products at any time without being
obliged to adjust earlier supplies accordingly.
The material in this manual is believed
adequate for the intended use of the system.
If the product, or its individual modules or
procedures, are used for purposes other than
those speci ed herein, con rmation of their
validity and suitability must be obtained. Philips
warrants that the material itself does not
infringe any United States patents. No fur ther
warranty is expressed or implied.
Philips cannot be held responsible neither for
any errors in the content of this document
nor for any problems as a result of the content
in this document. Errors repor ted to Philips
will be adapted and published on the Philips
support website as soon as possible.
Pixel characteristics
This LCD product has a high number of
color pixels. Although it has effective pixels of
99.999% or more, black dots or bright points of
light (red, green or blue) may appear constantly
on the screen. This is a structural property of
the display (within common industry standards)
and is not a malfunction.
Compliance with EMF
Koninklijke Philips Electronics N.V. manufactures
and sells many products targeted at consumers,
which, like any electronic apparatus, in
general have the ability to emit and receive
electromagnetic signals.
One of Philips’ leading Business Principles is to
take all necessary health and safety measures
for our products, to comply with all applicable
legal requirements and to stay well within
the EMF standards applicable at the time of
producing the products.
Philips is committed to develop, produce and
market products that cause no adverse health
effects. Philips con rms that if its products are
handled properly for their intended use, they
are safe to use according to scienti c evidence
available today.
Philips plays an active role in the development
of international EMF and safety standards,
enabling Philips to anticipate further
developments in standardisation for early
integration in its products.
Copyright
All other registered and unregistered
trademarks are the property of their respective
owners.
® Kensington and Micro Saver are registered
US trademarks of ACCO World corporation
with issued registrations and pending
applications in other countries throughout the
world.
Warranty
No components are user serviceable. Do not
open or remove covers to the inside of the
product. Repairs may only be done by Philips
Service Centres and of cial repair shops. Failure
to do so shall void any warranty, stated or
implied.
Any operation expressly prohibited in
this manual, any adjustments, or assembly
procedures not recommended or authorised in
this manual shall void the warranty.
2
EN
VESA, FDMI and the VESA Mounting Compliant
logo are trademarks of the Video Electronics
Standards Association.
Portions of this software are copyright © The
FreeType Project (www.freetype.org).
Page 5
2 Important
Read and understand all instructions before you
use your TV. If damage is caused by failure to
follow instructions, the warranty does not apply.
Safety
•
Risk of electric shock or re!
•
Never expose the TV to rain or
water. Never place liquid containers,
such as vases, near the TV. If
liquids are spilt on or into the TV,
disconnect the TV from the power
outlet immediately. Contact Philips
Consumer Care to have the TV
checked before use.
•
Never place the TV, remote control
or batteries near naked ames or
other heat sources, including direct
sunlight.
To prevent the spread of re, keep
candles or other ames away from
the TV, remote control and batteries
at all times.
•
Never inser t objects into the
ventilation slots or other openings on
the TV.
•
When the TV is swiveled ensure that
no strain is exerted on the power
cord. Strain on the power cord can
loosen connections and cause arcing.
•
Risk of shor t circuit or re!
•
Never expose the remote control or
batteries to rain, water or excessive
heat.
Avoid force coming onto power
•
plugs. Loose power plugs can cause
arcing or re.
•
Risk of injury or damage to the TV!
•
Two people are required to lift and
carry a TV that weighs more than
25 kg.
•
When stand mounting the TV, use
only the supplied stand. Secure the
stand to the TV tightly. Place the
TV on a at, level surface that can
support the combined weight of the
TV and the stand.
•
When wall mounting the TV, use
only a wall mount that can support
the weight of the TV. Secure the wall
mount to a wall that can support the
combined weight of the TV and wall
mount. Koninklijke Philips Electronics
N.V. bears no responsibility for
improper wall mounting that results
in accident, injury or damage.
•
Risk of injury to children!Follow these
precautions to prevent the TV from
toppling over and causing injury to
children:
•
Never place the TV on a surface
covered by a cloth or other material
that can be pulled away.
•
Ensure that no par t of the TV hangs
over the edge of the surface.
•
Never place the TV on tall furniture
(such as a bookcase) without
anchoring both the furniture and TV
to the wall or a suitable support.
•
Educate children about the dangers
of climbing on furniture to reach the
TV.
•
Risk of overheating! Never install the
TV in a con ned space. Always leave a
space of at least 10 cm around the TV
for ventilation. Ensure curtains or other
objects never cover the ventilation slots
on the TV.
•
Risk of damage to the TV! Before you
connect the TV to the power outlet,
ensure that the power voltage matches
the value printed on the back of the TV.
Never connect the TV to the power
outlet if the voltage is different.
English
EN
3
Page 6
•
Risk of injury, re or power cord damage!
Never place the TV or any objects on the
power cord.
•
To easily disconnect the TV power cord
from the power outlet, ensure that you
have full access to the power cord at all
times.
•
When you disconnect the power cord,
always pull the plug, never the cable.
•
Disconnect the TV from the power
outlet and antenna before lightning
storms. During lightning storms, never
touch any part of the TV, power cord or
antenna cable.
•
Risk of hearing damage! Avoid using
earphones or headphones at high
volumes or for prolonged periods of time.
If the TV is transported in temperatures
•
below 5°C, unpack the TV and wait
until the TV temperature matches room
temperature before connecting the TV to
the power outlet.
•
Risk of damage to the TV screen! Never
touch, push, rub or strike the screen with
any object.
•
To avoid deformations and color fading,
wipe off water drops as soon as possible.
Recycling
Your product is designed and manufactured
with high quality materials and components,
which can be recycled and reused.
When you see the crossed-out wheel bin
symbol attached to a product, it means the
product is covered by the European Directive
2002/96/EC:
Screen care
•
Avoid stationary images as much as
possible. Stationary images are images
that remain on-screen for extended
periods of time. Examples include:
on-screen menus, black bars and time
displays. If you must use stationary
images, reduce screen contrast and
brightness to avoid screen damage.
•
Unplug the TV before cleaning.
•
Clean the TV and frame with a soft,
damp cloth. Never use substances such as
alcohol, chemicals or household cleaners
on the TV.
Never dispose of your product with other
household waste. Please inform yourself about
the local rules on the separate collection of
electrical and electronic products. The correct
disposal of your old product helps prevent
potentially negative consequences on the
environment and human health.
Your product contains batteries covered by
the European Directive 2006/66/EC, which
cannot be disposed of with normal household
waste.
Please inform yourself about the local rules on
separate collection of batteries. The correct
disposal of batteries helps prevent potentially
negative consequences on the environment
and human health.
4
EN
Page 7
3 Your TV
Remote control
Congratulations on your purchase, and
welcome to Philips! To fully bene t from the
support that Philips offers, register your product
at www.philips.com/welcome.
TV overview
This section gives you an overview of
commonly used TV controls and functions.
Side controls and indicators
4
4
3
3
2
2
29
28
27
26
25
24
23
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
English
1
1
a POWER : Switches the TV on or off.
The TV is not powered off completely
unless it is physically unplugged.
b P/CH +/- : Switches to the next or
previous channel.
c
d VOLUME +/- : Increases or decreases
SOURCE : Selects connected devices.
volume.
22
a ( Standby-On )
•
Switches the TV to standby if the TV
is on.
•
Switches the TV on if the TV is in
standby.
19
20
21
EN
5
Page 8
b
TELETEXT
Toggles teletext on or off.
r CH +/- ( Channel +/- )
Switches to the next or previous channel.
c
SOURCE
Selects connected devices.
d Color buttons
Selects tasks or options.
e SLEEP
Sets a delay after which the TV switches
to standby.
f DUAL
Switches Stereo and Nicam Stereo to
Mono. Selects rst language (Dual I)
or second language (Dual II) in bilingual
programs.
g
( Home )
Toggles the home menu on or off.
h
OPTIONS
Accesses options relating to the current
activity or selection.
i OK
Con rms an entry or selection.Displays a
matrix of channels.
j
( Navigation buttons )
Navigates through the menus.
k
INFO
Displays program information, if available.
l
( Backward )
Searches backward.
m
( Forward )
Searches forward.
s
FORMAT
Selects a picture format.
t 0-9 ( Numeric buttons )
Selects a channel or setting.
u
PICTURE ( Smart picture )
Launches the smart picture menu.
v
SOUND ( Smart Sound )
Launches the smart sound menu.
w
+/- ( Volume +/- )
Increases or decreases volume.
x
BACK A/CH
Returns to a previous screen.
Toggles between the current channel and
the last viewed channel.
y
BROWSE
Displays a matrix of channels.
z SCENEA ( Wallpaper )
Displays wallpaper on your TV screen.
{ DEMO
Toggles the demonstration menu on or
off.
| TV
Switches back to the antenna source from
EasyLink mode.
}
INCR. SURR
Enables Incredible Surround for stereo
sources. Enables spatial mode for mono
sources.
n
( Play/Pause )
Starts, pauses or resumes disc play.
o
( Record )
Starts or stops video recording.
p
( Stop )
Stops disc play.
q
( Mute )
Mutes or restores audio output.
6
EN
Page 9
4 Use your TV
Switch channels
This section helps you perform basic TV
operations.
Switch your TV on/off or to
standby
To switch on
If the standby indicator is off, press
•
POWER at the side of the TV.
•
If the standby indicator is red, press
( Standby-On ) on the remote control.
To switch to standby
•
Press
control.
»
To switch off
•
Press
»
( Standby-On ) on the remote
The standby indicator switches to red.
POWER at the side of the TV.
The standby indicator switches off.
English
Press BACK A/CH on the remote
•
control to return to the previously
viewed channel.
Press CH +/- on the remote control or
•
P/CH +/- on the side of the TV.
Press OK to use the channel matrix.
•
Enter a channel number using the
•
Numeric buttons .
Note
When you use a favorite list, you can only
•
select those channels in the list (see ‘Select a
favorite list’ on page 12 ) .
Tip
Though your TV consumes ver y little power
•
when in standby, energy continues to be
consumed. When not in use for an extended
period of time, disconnect the TV power cable
from the power outlet.
Note
If you cannot locate your remote control and
•
want to switch on the TV from standby, press
P/CH +/- at the side of the TV.
EN
7
Page 10
Watch connected devices
Use the source button
Adjust TV volume
1 Press SOURCE .
»
The source list appears.
2 Press or to select the connected
device.
3 Press OK to watch the connected device.
Use the home menu
Note
You can add new devices to the home menu
•
for easy access .
1 Press ( Home ).
»
The home menu appears.
To increase or decrease volume
Press
•
•
Press VOLUME +/- on the side of the TV.
To mute or unmute sound
•
Press
•
Press
+/- .
to mute the sound.
again to restore the sound.
2 Press to select the device.
3 Press OK to watch the connected device
on your TV.
8
EN
Page 11
5 Use more of
4 Press ( Home )to exit.
your TV
Access TV menus
Menus help you to install channels, change
picture and sound settings and access other
features.
Access the home menu
The home menu gives you easy access to
connected devices, picture and sound settings
as well as other useful features.
1 Press ( Home ).
The menu screen appears.
»
Tip
After selecting [Add new device] , follow the
•
on-screen instructions to select the correct
device and connector.
Remove devices from the home menu
If a device is no longer connected to the TV,
remove it from the home menu.
1 Press ( Home ).
2 Press to select a device to remove.
3 Press OPTIONS .
»
The [Remove device] list appears.
4 Press OK and select [Remove] to remove
the device.
The selected device is removed from
»
the home menu.
Change picture and sound
English
Setup
Setup
Watch TV
Watch TV
Add new device
Add new device
2 Press the to select and navigate
through one of the following menus.
[Watch TV] Switches back to the
•
antenna source if another source is
selected.
[Setup] Accesses menus that allow
•
you to change picture, sound and
other TV settings.
[Add new device] Adds new devices
•
to the home menu.
3 Press OK to con rm your choice.
settings
Change picture and sound settings to suit your
preferences. You can apply pre-de ned settings
or change settings manually.
Use settings assistant
Use the settings assistant to guide you through
the best picture and sound settings.
1 Press ( Home ).
2 Press to select [Setup] > [Picture]
> [Settings assistant] .
3 Press OK .
The [Settings assistant] menu appears.
»
Follow the on-screen instructions to
choose your preferred picture settings.
EN
9
Page 12
Use smart picture
Use smart picture to apply pre-de ned
picture settings.
1 Press PICTURE .
»
The [Smart picture] menu appears.
2 Press to select one of the following
smar t picture settings.
•
[Personal] Lists customized personal
picture settings.
•
[Vivid] Maximizes picture settings.
•
[Standard] Adjusts picture settings
to suit most environments and types
of video.
•
[Movie] Applies picture settings
ideally suited for movie viewing.
•
[Game] Applies picture settings
maximized for fast-moving games.
•
[Energy saving] Applies low-energy
picture settings.
3 Press OK to con rm your choice.
»
The selected smart picture setting is
applied.
Manually adjust picture settings
1 Press ( Home ).
2 Press to select [Setup] >
[Picture] .
»
The [Picture] menu appears.
3 Press to select from the following
settings and adjust:
•
[Smart picture] : Accesses pre-
de ned smart picture settings.
•
[Contrast] : Adjusts the intensity
of bright areas, keeping dark areas
unchanged.
•
[Brightness] : Adjusts the intensity
and details of dark areas.
•
[Color] : Adjusts color saturation.
•
[Hue] : Compensates color variations
in NTSC encoded transmissions.
•
[Sharpness] : Adjusts the level of
sharpness in image details.
•
[Noise reduction] : Filters and
reduces noise in an image.
•
[Color temperature] : Introduces
more orange tones ( [Warm] ) or
blue tones ( [Cool] ) to the picture.
[Pixel Plus HD] : Fine tunes each
•
pixel to match surrounding pixels.
This produces a brilliant, highde nition image.
[Dynamic contrast] :
•
Automatically enhances contrast
in an image.
[Dynamic backlight] : Adjusts
•
the brightness of the TV
backlight to match lighting
conditions.
[Color enhancement] : Makes
•
colors more vivid and improves
the resolution of details in bright
colors. You can switch this
feature on or off.
[PC mode] : Adjusts picture settings
•
when a PC is connected to the TV.
[Light sensor] : Dynamically adjusts
•
picture settings to match lighting
conditions.
[Picture format] : Changes the
•
picture format.
[Horizontal shift] : Adjusts the
•
picture horizontally for PC-VGA or
HD input.
[Vertical shift] : Adjusts the picture
•
vertically for PC-VGA or HD input.
Change picture format
1 Press FORMAT .
A picture format bar appears.
»
2 Press to select a picture format.
The selected picture format is
»
activated.
10
EN
Page 13
3 Press OK to con rm your choice.
Summary of picture formats
The following picture settings can be con gured.
Note
Use smart sound
Use smart sound to apply pre-de ned sound
settings.
English
Depending on the format of the picture
•
source, some picture settings are not available.
[Super zoom] (Not for HD
and PC mode.) Removes
the black bars on the side
of 4:3 broadcasts. There is
minimal distortion.
[4:3] Shows the classic 4:3
format.
[Subtitle zoom] Displays
4:3 pictures over the full
area of the screen, with
sub-titles visible. Part of
the top of the picture is
clipped off.
[Movie exp.14:9] (Not for
HD and PC mode.) Scales
4:3 format to 14:9.
[Movie exp.16:9] (Not for
HD and PC mode.) Scales
4:3 format to 16:9.
[Wide screen] Stretches
the classic 4:3 format to
16:9.
[Unscaled] For HD and PC
mode only, and in selected
models only. Allows
maximum sharpness. Some
distortion may be present
due to the broadcaster’s
systems. Set your PC
resolution to wide screen
mode for best results.
1 Press SOUND .
»
The [Smart sound] menu appears.
2 Press to select one of the following
smar t sound settings.
•
[Standard] Adjusts sound settings to
suit most environments and types of
audio.
•
[News] Applies sound settings ideally
suited for spoken audio, such as the
news.
[Movie] Applies sound settings ideally
•
suited for movies.
[Personal] Applies the settings that
•
were customized in the sound menu.
3 Press OK to con rm your choice.
»
The selected smart sound setting is
applied.
Adjust sound settings
1 Press ( Home ).
2 Press to select [Setup] > [Sound] .
»
The [Sound] menu appears.
3 Press to select and adjust:
•
[Smart sound] : Accesses pre-
de ned smart sound settings.
•
[Bass] : Adjusts the bass level.
•
[Treble] : Adjusts the treble level.
•
[Volume] : Adjusts the volume.
•
[Balance] : Adjusts the balance of the
right and left speakers to best suit
your listening position.
EN
11
Page 14
•
[Dual I-II] : Selects between audio
languages if dual sound is broadcast.
•
[TV speakers] : Sets the TV
speakers on or off, or outputs sound
to an EasyLink-compliant device.
[EasyLink] must be activated in the
[Preferences] menu to make the
[TV speakers] menu available.
[Mono/Stereo] Selects between
•
mono or stereo if stereo is
broadcast.
[Surround] : Enables spatial sound.
•
[Headphone volume] : Adjusts
•
headphone volume.
[Auto volume] : Automatically
•
reduces sudden volume changes, for
example, when switching channels.
When enabled, this produces a more
consistent audio volume.
[Delta volume] : Corrects volume
•
differences between TV channels
and connected devices (switch
to your connected device when
adjusting [Delta volume]
).
2 Press OPTIONS .
The channel options menu appears.
»
3 Press OK to select [Show favorite ch.] .
»
The favorite lists appear.
4 Press to select a favorite list.
5 Press OK .
Only channels in the favorite list
»
appear in the channel grid.
Add a channel to a favorite list
Tip
View all channels before adding a channel to a
•
favorite list.
1 When watching TV, switch to the channel
you want to add to a favorite list (see
‘Switch channels’ on page 7 ) .
2 Press to select a channel to add to
a favorite list.
3 Press OPTIONS .
The channel options menu appears.
»
Create and use lists of
favorite channels
You can create lists of your preferred TV
channels and radio stations so that you can nd
those channels easily.
Tip
You can create and store up to four favorite
•
lists on your TV.
Select a favorite list
1 When watching TV, press OK to display
the channel grid.
4 Press to select [Mark as favorite] .
5 Press OK .
The favorite lists appear.
»
6 Press to select a favorite list to add
the channel to.
7 Press OK .
The channel is added to the favorite
»
list.
Tip
When watching TV, press OPTIONS >
•
[Mark as favorite] to save the current channel
into a favorite list.
12
EN
Page 15
Remove a channel from a favorite list
Note
Select the favorite list to edit, before removing
•
a channel .
1 When watching TV, press OK to display
the channel grid.
2 Press OPTIONS .
»
The channel options menu appears.
3 Press OK to enter [Show favorite ch.] .
4 Press to select a favorite list and press
OK to con rm the choice.
5 Press to choose the channel that
you wish to remove from the list.
6 Press OPTIONS .
7 Press to select [Unmark as fav.] .
8 Press OK .
The channel is removed from the
»
favorite list.
3 Press to set the sleep time.
The sleeptimer can be up to 180
»
minutes in steps of ve minutes. If
set to zero minutes, the sleeptimer is
switched off.
4 Press OK to activate the sleeptimer.
The TV switches to standby after the
»
pre-de ned period of time.
Automatically switch the TV on (on
timer)
You can switch the TV to a speci ed channel
at a speci ed time, from standby.
1 Press ( Home ).
2 Press to select [Setup] >
[Features] > [On timer] .
3 Press to enter the [On timer] menu.
4 Press to select [Activate] and set a
day of the week or frequency.
5 Press OK to con rm.
English
Use timers
You can set timers to switch the TV on or
switch to standby at a speci ed time.
Automatically switch the TV to
standby (sleeptimer)
Sleeptimer switches the TV to standby after a
pre-de ned period of time.
Tip
You can always switch off your TV earlier or
•
reset the sleeptimer during the countdown.
1 Press ( Home ).
2 Press to select [Setup] >
[Features] > [Sleep timer] .
The [Sleep timer] menu appears.
»
6 Press to select [Time] and set the
starting time.
7 Press [Done] to con rm.
8 Press to select [Program no.] and
set the channel.
9 Press OK to con rm.
10 Press ( Home ) to exit.
Tip
Select [On timer] > [Activate] > [Off] to
•
disable [On timer] .
When [On timer] is [Off] , only [Activate] can
•
be selected.
Set the TV clock before activating [On timer]
•
feature .
EN
13
Page 16
Use child control
Lock or unlock one or more channels
You can prevent your children from watching
certain programs or cer tain channels by locking
the TV controls.
Set or change your PIN code
1 Press ( Home ).
2 Press to select [Setup] >
[Features] > [Change/Set code] .
The [Change/Set code] menu appears.
»
3 Enter the code with the Numeric
buttons .
A message appears con rming that
»
your code is created or changed.
Tip
If you forget your code, enter ‘8888’ to
•
override any existing codes.
1 When watching TV, press OK to display
the channel grid.
2 Press to select a channel to lock or
unlock.
3 Press OPTIONS .
4 Press to select [Lock/Unlock chan.] .
5 For each selection, press OK to lock or
unlock the channel.
Use the TV clock
You can display a clock on the TV screen. The
clock displays the current time using time data
received from your TV service operator.
Display the TV clock
1 When watching TV, press OPTIONS .
»
The TV options menu appears.
Lock or unlock all channels and
connected devices
1 Press ( Home ).
2 Press to select [Setup] >
[Features] > [TV lock] .
3 Press to enter the [TV lock] .
A screen appears prompting you to
»
enter code.
4 Enter your code using Numeric buttons .
5 Press to select [Lock] or [Unlock] .
6 Press OK .
All channels and connected devices are
»
locked or unlocked.
7 Press ( Home ) to exit.
Note
If you select [Lock] , you have to enter your
•
code every time you turn on your TV.
2 Select [Clock] .
3 Press OK .
The clock is displayed.
»
Note
The clock is disabled automatically after ten
•
minutes. To disable the clock before that,
repeat this procedure.
Change the clock mode
Note
Not available in all models.•
1 Press ( Home ).
2 Select [Installation] > [Clock] > [Auto
clock] .
The [Auto clock] menu appears.
»
14
3 Select [Automatic] or [Manual] .
EN
Page 17
View photos, play music and
Disconnect a USB storage device
watch video from a USB
storage device
Caution
Philips is not responsible if the USB storage
•
device is not supported nor is it responsible
for damage or loss of data from the device.
Your TV is tted with a USB connector that
enables you to view photos, listen to music or
watch movies stored on a USB storage device.
Supported le formats
Pictures JPEG (non-
progressive only)
Music MP3
Video MP4, M4V, RMVB
Note
Only FAT or DOS-formatted USB storage
•
devices are suppor ted. File names must not
exceed 128 characters.
Caution
Follow this procedure to avoid damage to your
•
USB storage device.
1 Press ( Home ) to exit the [USB] menu.
2 Wait for ve seconds before
disconnecting the USB storage device.
View photos
1 In the USB content browser, select
[Picture] and press
to enter.
2 Press GUIDE to switch between
thumbnail and le browsing views.
3 Press to select a photo or a photo
album.
4 Press OK to view the selected photo in
full screen mode.
Tip
When in full screen mode, press to move
•
between photos.
English
Connect a USB storage device and
enter the content browser
1 Turn on the TV.
2 Connect the USB device to the USB port
on the side of the TV .
3 Press ( Home ).
The home menu appears.
»
4 Press to select [Browse USB] .
5 Press OK to con rm.
»
The USB content browser appears.
Tip
Press BROWSE to switch between
•
thumbnail and le browsing views.
View a slide show of your photos
1 When a full screen image of a photo is
displayed, press OK or
»
A slide show begins from the selected
image.
.
2 Press:
OK or
•
»
The
•
Press
images.
•
Press BACK or
show.
to pause the slide show.
icon appears.
or to move between
to stop the slide
EN
15
Page 18
Change slide show settings
View a slide show with music
1 When viewing a slide show, press
OPTIONS .
The slide show options menu appears.
»
2 Press to select one of the following.
•
[Start/Stop slide.] Star ts or stops a
slide show.
•
[Slideshow trans.] Sets the transition
from one picture to the next.
•
[Slideshow freq.] Sets the amount of
time that a picture is shown.
•
[Rotate image] Rotates a picture.
•
[Show info] Displays the picture
name, date, size and next picture in
the slide show.
3 Press OK to con rm your setting.
Listen to music
1 Connect a USB storage device to the
USB port on the side of the TV.
2 Press to enter the menu.
3 Select [Music] , and then press to enter
the [Music] folder.
4 Press or to select a song or a music
album.
5 Press OK or to play the selected
song or album.
•
Press the color buttons on the
remote control to perform the
functions shown at the bottom of
the screen.
•
Press OK or
or
•
Press
•
Press
•
Press
again to resume.
to fast-forward search.
to fast-backward search.
to stop playback.
to pause, press OK
You can view a slide show of your stored
pictures with background music.
1 Select an album of songs.
2 Press OK .
3 Select an album of pictures.
4 Press OK .
Watch video from a USB device
1 In the USB content browsert, press to
enter the [VIDEO] folder.
2 Press to select a video.
3 Press OK or to play the video.
Press the color buttons on the
•
remote control to perform the
functions shown at the bottom of
the screen.
Press OK or
•
or
again to resume.
•
Press
•
Press
•
Press
Note
If the function bar at the bottom of the TV
•
screen disappers, press any color button to
make it reappear.
to fast-forward search.
to fast-backward search.
to stop playback.
to pause, press OK
Note
If the function bar at the bottom of the TV
•
screen disappers, press any color button to
make it reappear.
16
EN
Page 19
Use Scenea to display a
picture as TV wallpaper
Upload a wallpaper picture from a
USB device
You can use the Scenea feature display a still
picture as wallpaper on your TV. This feature is
for home mode only.
Activate Scenea
Single-picture wallpaper
Press SCENEA on your remote control.
The default or pre-loaded picture is
»
displayed.
Note
To deactivate the wallpaper, press any remote
•
control button except
PICTURE .
The wallpaper is also deactivated when you
•
connect a USB storage device to the T V or
start an EasyLink-compliant device through
one-touch play.
, SOUND , and
Before performing this procedure, be sure to
have available a USB storage device containing
the picture you intend to use as wallpaper.
Note
The le size of the picture must not be more
•
than 1MB.
1 Connect the USB storage device to the
TV.
2 Press ( Home ).
The home menu appears.
»
3 Press to select [Browse USB] .
4 Press to select a picture.
5 Press OPTIONS .
6 Select [Set as Scenea] .
7 Press OK .
English
Walllpaper slide show
Make sure the wallpaper is not yet activated.
1 Connect a USB storage device to the TV.
2 Press SCENEA .
All pictures in the USB storage device
»
are displayed.
Note
The wallpaper display duration is determined
•
by the pre-de ned sleep timer settings (see
‘Automatically switch the TV to standby
(sleeptimer)’ on page 13 ) . When sleep timer is
off, the wallpaper is displayed for a maximum
of 120 minutes.
EN
17
Page 20
Update the TV software
Change TV preferences
Philips continuously tries to improve its
products and we recommend that you update
the TV software when updates are available.
Check www.philips.com/support for availability.
Check the current software version
1 Press ( Home ).
2 Select [Setup] > [Software update] >
[Current software] .
Download the software
1 On your PC, open a web browser and go
to www.philips.com/support.
2 Find information and software related
to your TV and download the latest
software upgrade le to your PC.
3 Decompress the ZIP- le.
4 Copy the autorun.upg le to the root
directory of the USB device.
Update software (analog broadcasts)
Before performing this procedure be sure to:
•
Set aside some time to complete the
entire update.
•
Have available a USB storage device with
at least 64MB of storage space.
•
Have access to a computer with a USB
port and internet access.
1 Press ( Home ).
2 Select [Setup] > [Software update] >
[Update assistant] .
3 Select [Start] .
The [Preferences] menu allows you to
customize various features and functions.
1 Press ( Home ).
2 Select [Setup] > [Installation] >
[Preferences] .
•
[Location] : Optimizes TV settings
for your location - home or shop.
•
[Volume bar] : Displays the volume
bar when adjusting the volume.
•
[EasyLink] : Enables one-touch play
and one-touch standby between
EasyLink-compliant devices.
[Pixel Plus Link] : Overrides the
•
settings of connected devices and
uses the settings of the TV.
[E-sticker] : For shop mode only.
•
Sets the location of the e-sticker.
Start a TV demo
You can use demonstrations to better
understand the features of your TV. Some
demos are not available on certain models.
When a demo is available, it is displayed in the
menu list.
1 Press DEMO on the remote control.
2 Press to select a demo and press OK
to view it.
3 Press DEMO to exit.
4 Connect the USB storage device to your
computer.
5 Follow the on-screen instructions to
complete the update.
18
EN
Page 21
Reset the TV to factory
settings
You can restore the default picture and sound
settings of your TV. Channel installation settings
remain the same.
1 Press ( Home ).
2 Select [Setup] > [Installation] > [Factory
settings] .
3 Press OK or to enter the [Factory
settings] menu.
[Reset] is highlighted.
»
4 Press OK to reset to factory settings.
5 Press ( Home ) to exit.
English
EN
19
Page 22
6 Install channels
The rst time you setup your TV, you are
prompted to select a menu language and to
install TV and digital radio channels (if available).
This chapter provides instructions on how to
reinstall and ne tune channels.
6 Press ( Home ) to exit.
Step 2 Search and store new TV
channels
1 Press ( Home ).
2 Press to select [Setup] >
[Installation] > [Channel install.] >
[Manual install] .
The [Manual install] menu appears.
»
Automatically install channels
This section describes how to search and store
channels automatically.
1 Press ( Home ).
2 Select [Installation] > [Channel install.]
> [Channel assistant] .
3 Press OK .
4 Follow the on-screen instructions to
install channels.
Manually install channels
This section describes how to search and store
analog TV channels manually.
Step 1 Select your system
Note
Skip this step if your system settings are
•
correct.
3 Press to select and enter [Search] .
4 Press or use Numeric buttons to
manually enter the three digit frequency.
5 Press OK to begin search.
6 Press when the new channel is found.
7 Press to select [Store new channel]
to store the new channel under a new
channel number.
8 Press to enter [Store new channel] .
9 Press to select [Yes] and press OK to
store the new channel.
10 Press ( Home ) to exit.
Rename channels
Channels can be renamed so that a name of
your choice appears whenever the channel is
selected.
1 When watching TV, press OK to display
the channel grid .
2 Select the channel you want to rename.
1 Press ( Home ).
2 Press to select [Setup] >
[Installation] > [Channel install.] >
[Manual install]
The [Manual install] menu appears.
»
3 Press to select and enter [System] .
4 Press to select your country or
region.
5 Press OK to con rm.
20
EN
3 Press OPTIONS .
The channel options menu appears.
»
4 Press to select [Rename chan.] .
5 Press to select a character and press
to add another character.
6 Select [Done].
7 Press OK .
Page 23
Rearrange channels
After you install channels, you can rearrange the
order in which they appear.
1 When watching TV, press OK to display
the channel grid .
2 Press OPTIONS .
»
The channel options menu appears.
3 Press to select [Reorder] .
4 Select the channel you want to reorder
and press OK .
5 Press to select the new position
for the channel.
6 Press OK to con rm the new position.
7 Press OPTIONS .
»
[ Done reordering ] appears.
8 Press OK to nish reordering.
English
EN
21
Page 24
7 Connect devices
This section describes how to connect
various devices with different connectors and
supplements examples provided in the Quick
Start.
Note
Different types of connectors may be used to
•
connect a device to your TV, depending on
availability and your needs.
e AV OUT ( VIDEO OUT and AUDIO
OUT L/R )
Audio and video output to analog devices
such as another TV or a recording device.
f AV1 ( VIDEO IN and AUDIO IN L/R )
Analog audio and video input from analog
or digital devices such as DVD players,
satellite receivers and VCRs.
g CVI 1/2 ( Y Pb Pr and AUDIO L/R )
Analog audio and video input from analog
or digital devices such as DVD players or
game consoles.
Back connectors
a HDMI 1/2
Digital audio and video input from highde nition digital devices such as Blu-ray
players.
b VGA/PC and PC AUDIO IN
Audio and video input from a computer.
c TV ANTENNA
Signal input from an antenna, cable or
satellite.
d SERV. U
For use by service personnel only.
Side connectors
1
1
2
2
3
3
4
4
5
5
6
6
a USB
Data input from USB storage devices.
b HDMI
Digital audio and video input from highde nition digital devices such as Blu-ray
players.
c S-VIDEO
S-Video (side) to be used with Audio L/R
connectors for camcorder, game console,
etc. When you use the S-Video (side) for
video signals, do not use the Composite
video (side) input for video signals.
d VIDEO
Composite video input from analog
devices such as VCRs.
22
EN
Page 25
e AUDIO L/R
Audio input from analog devices
connected to VIDEO or S-VIDEO .
f
Connect a computer
Before connecting a computer to the TV
•
•
Connect a computer with one of the
following connectors:
Stereo audio output to headphones or
earphones.
Set the monitor refresh rate on your
computer to 60Hz.
Press
picture format to [Unscaled] .
Note
FORMAT and change the TV
HDMI cable and HDMI-DVI adaptor
•
PC AUDIO IN/ PC IN(AUDIO)
PC AUDIO IN/ PC IN(AUDIO)
VGA cable
•
PC AUDIO IN/ PC IN(AUDIO)
PC AUDIO IN/ PC IN(AUDIO)
DVI
DVI
English
Connections via DVI or VGA require an
•
additional audio cable.
•
HDMI cable
•
DVI-HDMI cable
PC AUDIO IN/ PC IN(AUDIO)
PC AUDIO IN/ PC IN(AUDIO)
DVI
DVI
VGA
VGA
Use dual view
1
Press ( Home ).
2 Select [Setup] > [Features] > [Dual
View] .
3 Select [On] .
4 Press OK .
5 Press OK to exit.
Note
When the dual view mode is turned on, a
•
small window for TV input appears on the
upper right-hand corner of the TV screen. The
audio output is still from the VGA input.
EN
23
Page 26
Add devices
EasyLink features
After connecting devices, assign the device
attached to each connector. This allows you to
easily identify devices connected to your TV.
1 Press ( Home ).
2 Select [Add new device]. Press OK or .
3 Press or to select a device and press
.
4 Press or to select the connector
your device is connected to and press
.
5 If available, press or to select the
audio connector your device is connected
to and press
.
6 Switch on your device and check for
video and audio output.
7 If there is video and audio output, press
OK .
Repeat the procedure until all devices are
correctly assigned to connectors.
Use Philips EasyLink
Your TV supports Philips EasyLink, which
uses the HDMI CEC (Consumer Electronics
Control) protocol. EasyLink-compliant devices
that are connected through HDMI connectors
can be controlled by a single remote control.
One-touch play
When you connect your TV to devices that
support one-touch play, you can control your
TV and the devices with one remote control.
For example, when you press Play on your
DVD remote control, your TV automatically
switches to the correct channel to show the
DVD content.
One-touch standby
When you connect your TV to devices that
support standby, you can use your TV remote
control to put your TV and all connected
HDMI devices in standby mode.
System audio control
When you connect your TV to HDMI
CEC compliant devices, your TV can
switch automatically to play audio from the
connected device.
To use one-touch audio, you must map the
audio input from the connected device to
your TV.
You can use the remote control from the
connected device to adjust the volume.
Remote control (RC) key forwarding
RC key forwarding allows you to control
EasyLink-compliant devices using your TV
remote control.
Note
Philips does not guarantee 100%
•
interoperability with all HDMI CEC devices.
Note
The EasyLink-compliant device must be
•
switched on and selected as the source.
24
EN
[Pixel Plus Link
Pixel Plus Link o verrides the settings of
connected devices and uses the settings of the
TV.
Page 27
EasyLink buttons
Enable or disable EasyLink
You can control EasyLink-compliant devices
with the following buttons on the remote
control of your TV.
Button EasyLink function
( Play/
Pause )
( Stop ) Stops playback on your EasyLink
( Record ) Starts or stops video recording
( Fast
Backward )
( Fast
Forward )
0-9
( Numeric
buttons )
Navigates through the menus of
OK Activates a selection or accesses
OPTIONS
( Standby-
On )
Starts, pauses or resumes
playback on your EasyLink
device.
device.
on your EasyLink device.
Searches backward.
Searches forward.
When EasyLink is enabled,
selects a title, chapter or track.
the EasyLink-compliant device.
the menu of the EasyLinkcompliant device.
Displays the menus of the
EasyLink-compliant device. Note
that when
the TV menu is displayed.
When EasyLink is enabled,
switches the TV and all EasyLink
devices to standby. Note that
you must press and hold
( Standby-On ) for at least 3
seconds for this to occur.
( Home ) is pressed,
Note
Do not enable Philips EasyLink if you do not
•
intend to use it.
1 Press ( Home ).
2 Select [Installation] > [Preferences] >
[EasyLink] .
3 Select [ON] or [OFF] .
Enable or disable remote control key
forwarding
1 Press OPTIONS .
2 Select [En./Dis. RC pass.] .
3 Press OK .
4 Press or to highlight an HDMI
connector.
5 Press OK to enable RC key forwarding
for the selected HDMI connector.
Set TV speakers to EasyLink mode
When enabled, this feature automatically
turns off TV speakers when content from an
EasyLink-compliant home theater system is
played. Audio is played only from the home
theater system’s speakers.
1 Press ( Home ).
2 Press to select [Setup] > [Sound] .
»
The [Sound] menu appears.
3 Select [TV speakers] .
»
The [TV speakers] menu appears.
English
Tip
Press TV to switch back to the antenna source
•
from EasyLink mode.
4 Select [Auto (EasyLink)] .
»
TV speakers are set to EasyLink mode.
EN
25
Page 28
Use a Kensington lock
There is a Kensington security slot at the back
of the TV. Prevent theft by looping a Kensington
lock between the slot and a permanent object,
such as a heavy table.
26
EN
Page 29
8 Product
information
Product information is subject to change
without notice. For detailed product
information, go to www.philips.com/support.
Supported display resolutions
Computer formats
HDMI :
Resolution Refresh rate (Hz)
640x480
800x600
1024x768
128 0x768
128 0x1024
1360 x768
VGA :
60, 72, 75, 85
60, 72, 75, 85
60, 70, 75, 85
60
60
60
Tuner/Reception/
Transmission
•
Antenna input: 75ohm coaxial (IEC75)
•
TV system: NTSC, PAL-M, PAL-N
•
Video playback: NTSC, SECAM, PAL
Multimedia
•
Connection: USB
•
Playback formats: MP4, RM, RMVB, JPEG,
MP3
Container Video
Codec
mpeg1 MPEG -1 MPEG
mpeg4 MPEG -4 AAC/
RealMedia Real Media
8/9/10
Audio
Codec
audio
HE-AAC
AAC,
Cook
English
File
extension
.dat
.mpg
.avi
.mp4
.rm
.rmvb
Resolution Refresh rate (Hz)
640x480
800x600
1024x768
128 0x768
128 0x1024
1360 x768
Video formats
Resolution Refresh rate (Hz)
720 x 480p
720 x 480i
720 x 576p
720 x 576i
1280 x 720p
1280 x 720p
1920 x 1080i
1920x 1080p
60, 72, 75, 85
60, 72, 75, 85
60, 70, 75, 85
60
60
60
60
60
50
50
60
50
50, 60
24, 25, 30, 50, 60
Remote control
•
Batteries: 2 x AAA (R03 type)
Connections
•
Headphone out (stereo mini-jack)
•
TV antenna
•
S-Video
•
CVBS in
•
CVBS out
•
YPbPr: Component video (CVI in)
•
VGA in
•
HDMI
•
VGA Audio in
•
USB
•
Service connector
EN
27
Page 30
Power
•
Mains power: AC 110-240V (50-60Hz)
Standby power: < 0.15W
•
Ambient temperature: 5 to 35 degrees
•
Celsius
Supported TV mounts
To mount the TV, purchase a Philips TV mount
or a VESA-compatible TV mount. To prevent
damage to cables and connectors, be sure to
leave a clearance of at least 5.5 cm from the
back of the TV.
Warning
Follow all instructions provided with the TV
•
mount. Koninklijke Philips Electronics N.V.
bears no responsibility for improper TV
mounting that results in accident, injur y or
damage.
TV
screen
size
VESA-compatible wall
bracket type
32”-37” 200 x 200 mm M6
42”-47” 400 x 400 mm M6 (42”),
M8 (47”)
28
EN
Page 31
9 Troubleshooting
This section describes commonly encountered
issues and accompanying solutions.
General TV issues
The TV does not switch on:
•
Disconnect the power cable from the
power outlet. Wait for one minute then
reconnect it.
•
Check that the power cable is securely
connected.
The remote control is not working properly:
•
Check that the remote control batteries
are correctly inserted according to the
+/- orientation.
•
Replace the remote control batteries if
they are at or weak.
•
Clean the remote control and TV sensor
lens.
The standby light on the TV blinks red:
•
Disconnect the power cable from the
power outlet. Wait until the TV cools
down before reconnecting the power
cable. If the blinking reoccurs, contact
Philips Consumer Care.
You forgot the code to unlock the child lock
feature
•
Enter ‘8888’.
The TV menu is in the wrong language
•
Change the TV menu to your preferred
language.
When turning the TV on/off/to standby, you
hear a creaking sound from the TV chassis:
No action is required. The creaking sound
•
is normal expansion and contraction of
the TV as it cools and warms up. This
does not impact performance.
TV channel issues
Previously installed channels do not appear in
the channel list:
•
Check that the correct channel list is
selected.
No digital channels were found during the
installation:
•
Check that the TV suppor ts DVB-T or
DVB-C in your country. See the listed
countries on the back of the TV.
Picture issues
The TV is on, but there is no picture:
•
Check that the antenna is properly
connected to the TV.
•
Check that the correct device is selected
as the TV source.
There is sound but no picture:
•
Check that the picture settings are
correctly set.
There is poor TV reception from an antenna
connection:
•
Check that the antenna is properly
connected to the TV.
•
Loud speakers, unearthed audio devices,
neon lights, high buildings and other large
objects can in uence reception quality.
If possible, try to improve the reception
quality by changing the antenna direction
or moving devices away from the TV.
•
If reception on only one channel is poor,
ne tune this channel.
There is poor picture quality from connected
devices:
•
Check that the devices are connected
properly.
•
Check that the picture settings are
correctly set.
The TV did not save your picture settings:
•
Check that the TV location is set to the
home setting. This mode offers you the
exibility to change and save settings.
English
EN
29
Page 32
The picture does not t the screen; it is too
big or too small:
•
Try using a different picture format.
The picture position is incorrect:
•
Picture signals from some devices may
not t the screen correctly. Check the
signal output of the device.
Sound issues
There is picture but no sound from the TV:
audio cable is connected to AUDIO L/R
or AUDIO IN (mini-jack only).
Computer connection issues
The computer display on the TV is not stable:
Check that a supported resolution and
•
refresh rate is selected on the computer.
Set the TV picture format to unscaled.
•
Note
If no audio signal is detected, the TV
•
automatically switches the audio output off
— this does not indicate malfunction.
•
Check that all cables are properly
connected.
•
Check that the volume is not set to 0.
•
Check that the sound is not muted.
There is picture but sound quality is poor:
•
Check that the sound settings are
correctly set.
There is picture but sound comes from one
speaker only:
•
Verify that sound balance is set to the
center.
HDMI connection issues
There are problems with HDMI devices:
•
Note that HDCP support can delay the
time taken for a TV to display content
from a HDMI device.
•
If the TV does not recognize the HDMI
device and no picture is displayed, try
switching the source from one device to
another and back again.
•
If there are intermittent sound
disruptions, check that output settings
from the HDMI device are correct.
•
If a HDMI-to-DVI adaptor or HDMI to
DVI cable is used, check that an additional
Contact us
If you cannot resolve your problem, refer to
the FAQs for this TV at www.philips.com/
support.
If the problem remains unresolved, contact
Philips Consumer Care in your country as
listed in this User Manual.
Warning
Do not attempt to repair the T V yourself. This
•
may cause severe injury, irreparable damage to
your TV or void your warranty.
Note
Make a note of your TV model and serial
•
number before you contact Philips. These
numbers are printed on the back of the TV
and on the packaging.
30
EN
Page 33
10 Index
B
Batteries 4 , 29
Bracket
C
Channel list
Channels
Child lock
Clock 14
Computer format
Connections
Connectors
28
favorite 12
troubleshooting 29
update 12
favorite list 12
install
automatic 20
manual 20
rearrange 21
rename 20
TV lock 14
technical speci cations 27
HDMI
troubleshooting 30
technical speci cations 27
troubleshooting 30
assign devices 27
disable 25
enable 25
Environmental care
4
English
F
Factory settings 19
Favorite list
select 12
set up 12
H
HDMI cable
troubleshooting 30
Home mode 18
I
Installation
automatic 20
manual
20
K
Kensington lock 26
L
Language
troubleshooting 29
Location 18
Lock
Kensington 26
TV 14
D
Demo 18
Devices
assign 27
Display
resolution 27
screen saver 17
E
EasyLink
M
Menu
child lock 14
language 29
main menu 9
troubleshooting 29
Multimedia
technical speci cations 27
Music
USB 16
with slideshow 16
EN
31
Page 34
P
Picture format
troubleshooting 29
Picture settings 9
PIN code 29
Power
29
R
Reception 29
Remote control
overview 5
technical speci cations 27
troubleshooting
29
screen care 4
software 18
standby 7
switch channels 7
switch off 7
switch on 7
transporting 3
troubleshooting 29
tuner technical speci cations 27
TV overview 5
wall mount 3 , 28
TV lock
lock channels 14
lock connected devices 14
PIN code
S
Safety 3
Screen saver 17
Settings assistant 9
Sleep timer 13
Slideshow
with music 16
Smart settings 10 , 11
Software
update
analog 18
version 18
Sound settings 11
Standby
troubleshooting
29
T
Technical specifcations 27
Timer
on timer 13
sleeptimer 13
standby 13
Transmission
troubleshooting 29
Troubleshooting 29
TV
adjust volume 8
disconnect from mains 22
menu 9
position 26
safety
3
U
USB
listen to music 16
upload a picture from 17
view photos 15
V
Video format
video format technical speci cations 27
Volume
adjust
W
Wallpaper 17
29
8
32
EN
Page 35
Page 36
© 2009 Koninklijke Philips Electronics N.V.
All rights reserved.
Document order number: 72-PNS000-X981B
Loading...
