26PFL3321S
32PFL3321S
www.philips.com/support
EN USER MANUAL
4
1
2
3
Stationary images on the TV screen
A characteristic of LCD and Plasma Panels is that
displaying the same image for a long time can
cause a permanent after-image to remain on the
screen. This is called phosphor burn in. Normal
use of the TV should involve the showing of
pictures that contain constantly moving and
changing images that fill the screen.
Examples of stationary images (this is not an all
inclusive list, you may encounter others in your
viewing).
• TV and DVD menus: listings of DVD disk
content.
• Black bars: when black bars appear at the left
and right side of the screen, it is recommended
to change to a picture format so that the
picture fills the entire screen;
• TV channel logo: present a problem if they are
bright and stationary. Moving or low-contrast
graphics are less likely to cause uneven aging of
the screen;
• Stock market stickers: presented at the bottom
of the TV screen;
• Shopping channel logos and pricing displays:
bright and shown constantly or repeatedly in
the same location on the TV screen.
• Examples of still pictures also include logos,
computer images, time display, teletext and
images displayed in 4:3 mode, static images or
characters, etc.
Tip:
Reduce contrast and brightness when viewing.
Electric, Magnetic and Electromagnetic
Fields (“EMF”)
• Philips Royal manufactures and sells many
products targeted at consumers, which, like
any electronic apparatus, in general have the
ability to emit and receive electro magnetic
signals.
• One of Philips’ leading Business Principles is to
take all necessary health and safety measures
for our products, to comply with all applicable
legal requirements and to stay well within
the EMF standards applicable at the time of
producing the products.
• Philips is committed to develop, produce and
market products that cause no adverse health
effects.
• Philips confirms that if its products are handled
properly for their intended use, they are safe
to use according to scientific evidence available
today.
• Philips plays an active role in the development
of international EMF and safety standards,
enabling Philips to anticipate further
developments in standardisation for early
integration in its products.
1
Thank you for purchasing this television set.
This handbook has been designed to help you install and operate your TV set.
We strongly recommend that you read it thoroughly.
Introduction
Table of Contents
Recycling
The packaging of this product is intended to be recycled. Apply to the local authorities
for correct disposal.
Disposal of your old product
Your product is designed and manufactured with highly quality material and components,
which can be recycled and reused. When this crossed-out wheeled bin symbol is attached
to a product, it means the product is covered by the European Directive 2002/976/EC.
Please inform yourself about the local separate collection system for electrical and
electronic products.
Please act according to your local rules and do not dispose off your old products with
your normal household waste. The correct disposal of your product will help prevent
potential negative consequences for the environment and human health.
2
X
X
Safety information
Avoid placing your TV set under direct sunlight
or heat.
To prevent fire or shock hazard, do not expose
your TV to rain or moisture.
Take care not to connect too many equipment
to the same mains socket as it may cause
overloading resulting in fire or electric shock.
Pull the power lead by the plug. Do not pull on
the power lead. Do not use a poor fitting mains
socket. Insert the plug fully into the mains. If it is
loose, it may cause arching and result in fire.
No naked flame sources (lighted candles) should
be placed on the top of the set or near it.
When cleaning the surface or the screen of the
set, wipe gently with absorbent cotton or cloth
or other soft material like chamois. Do not use
too wet a cloth which is dripping with water.
Do not use acetone, toulene or alcohol to
clean the TV. As a safety precaution, unplug the
power cord from the mains.
As a safety precaution, do not touch any part of
the TV, power lead or aerial lead during lightning
storms.
Installation of the TV set on the wall should be
carried out by qualified serviceman. Improper
and incorrect installation may render the set
unsafe.
Avoid placing vase filled with water on the TV.
Water spilled into the set could result in electric
shock. Do not operate set if water is spilled into
it. Have it checked immediately by a qualified
serviceman.
Leave at least 10 cm around each side of the
TV set to allow for proper ventilation. Place
the set on a stable, level surface. Never cover
the ventilation slots of the TV with a cloth or
other material. It may cause overheating. Do not
insert anything in the ventilation holes. If metal
or something flammable is inserted in these
holes, it may result in fire or electric shock.
10 cm
10 cm
10 cm
X
X
X
X
X
3
2
3
Using the Remote Control
Pull out the plastic insulation sheet from the
battery to enable the remote control to operate.
Switching on the TV set
• To switch on the TV set, press the POWER
button. A green indicator comes on and the
screen lights up.
• If the TV set remains in standby mode (red
indicator), press the PROGRAM – /
+ key on
the keyboard or the P – / + key on the
remote control.
4
1
Preparation / Getting started
Positioning the TV set
Place your TV set on a solid stable surface,
leaving a space of at 10 cm around the set.
Connections
• Insert the aerial plug into the 75Ω :
socket at the bottom of the set.
• Insert the mains plug into a wall socket
(220-240V / 50/60Hz).
• Ensure the power cord is fully inserted in
the TV mains socket and the wall socket.
Warning!
If the TV is mounted on a swivel base or
swivel arm, ensure no strain is placed on
the power cord when the TV is swivelled.
Strain on the power cord can loosen
connections. This may cause arching and
result in fire.
10 cm
10 cm
10 cm
–
.
–
4
Television keys and connectors
––
.
1
3
4
2
6
7
8
9
10
EXT 4
EXT 2 /SVHS2
EXT 1
DVI
(AUDIO IN)
HDMI
AUDIO
R L
IN
Pr
Pb Y
L
R
AUDIO
IN
R
L
VIDEO
IN
S-VIDEO
11
EXT3/SVHS3
5
AC in ~
5
Television keys and connectors
1
POWER . : to switch the TV on and off.
2
VOLUME –/+: to adjust sound level.
3
MENU : to access or close menus.
The PROGRAM /CHANNEL –/+ keys can
be used to select a menu item and the
VOLUME –/+ keys to enter into the selected
menu item and make adjustments.
4
PROGRAM / CHANNEL –/+ : to select
programmes.
5
POWER socket :
Insert the mains plug into
a wall socket.
6
DVI Audio Input : for connecting a HD
(high definition) equipment or computer with
DVI output.
7
Component Video inputs / Audio Inputs
(
EXT4)
: to connect to equipment like DVD,
Set-Top box which have the same sockets.
Connect the audio inputs of the TV to the
outputs of the device together with the
Component Video Inputs.
8
HDMI socket : to connect to set-top box,
DVD player/recorder, High Definition
equipment or Personal Computer.
9
EXT1 and EXT2/SVHS2 sockets : connect to
equipment
like DVD player/recorder, VCR,
Decorder which have scart connections.
Important : In order to connect your
decoder, please use EXT1 scart only.
10
TV Aerial socket :
Insert the aerial plug
into the 75 : socket.
11
Side connections
EXT3/SVHS3
: for
connecting to devices like camera or
camcorder. Also allows you to connect your
headphone for your personal listening
pleasure.
6
Remote Control keys
1
Standby
To set the TV to standby mode. To switch the
TV set on again, press
,
to
,
P – / + or AV key.
2
No function.
3
DVD / AUX (see page 7).
4
Surround Sound
To activate / deactivate the surround sound
effect. In stereo, this gives the impression that
the speakers are further apart. For models
equipped with Virtual Dolby Surround, you can
experience Dolby Surround Pro Logic sound
effects
.
5
Telextext keys (see page 15).
6
AV
To display Source List to select TV or peripheral
equipment connected to EXT 1, EXT 2/SVHS2,
EXT 3/SVHS3, EXT 4 or HDMI.
Note :
EXT3/SVHS3
is only available for
certain models.
7
Active Control
(
S
ee page 14).
8
MENU
To call up or exit the TV menus.
9
Cursors
These 4 keys are used for selection and adjustment
of menu items.
10
OK
Confirms selection.
11
Volume ( – VOL + )
To adjust the sound level.
12
Smart Picture /Sound
Used to access a series of predefined picture
and sound settings (see page 14).
13
/
Numerical keys
For direct access to programmes. For a 2
digit programme number, the 2nd digit must
be entered before the dash disappears.
14
Screen information
To display/remove the programme number,
the sound mode, the remaining time of the
sleeptimer and the *signal strength indicator.
15
Mode
Select between TV, DVD and AUX mode (see
“Remote Control - Other functions” on page 7).
16
Programme List
To display / clear the list of programmes.
Use the Î ï keys to select a programme and
the Æ key to display it.
17
Picture-in-Picture
To display a PIP window on the TV screen (see
page 12 on how to use the PIP feature).
18
Sound mode
Used to force programmes in Stereo
and Nicam Stereo to Mono or, for
bilingual programmes, to choose between
Dualå or Dual». The Mono indication is red
when in forced position.
19
Screen Format
(see page 13).
20
DVD / AUX (see page 7).
21
Mute
Press to mute or restore sound.
22
Selecting TV programmes (P – / +)
To select the next or previous programme.
The number and the sound mode
are displayed for a few seconds. For some
TV programmes, the title of the programme appears
at the bottom of the screen.
23
Previous/Present programme
To alternate between the last viewed and
present programme.
* The signal strength indicator shows
the signal strength of the transmission
of the programme you are watching.
11
AUX
1
2
3
5
6
7
8
9
4
10
12
13
14
15
16
17
18
19
20
21
22
23
7
Remote Control keys (Other functions)
The remote control also allows you to control the main functions of some Philips DVD models
Press the
key to select the required mode: DVD or AUX.
The remote control indicator lights up to display the selected mode. It switches off automatically
after 20 seconds if left idle. The mode automatically returns to TV mode.
The following buttons are operational, depending on the equipment:
to
standby
fast rewind
stop
play
fast forward
record
pause
display and exit menu
programme selection
navigation and adjustments,
confirms selection
digit keys
Quick Installation
When you switch on the TV set for the
first time, a menu is displayed on screen.
This menu prompts you to select the
country and language for the menus.
Note
If the above menu is not displayed, proceed to
do the installation of channels by the
Auto Store method (see page 8). If above
menu is displayed, proceed to do the following
steps.
& Use the Î ï keys on the remote control
to select your country. If your country does
not appear in the list, select “. . . “ . Refer to the
“Reference table of Countries available for
selection” on page 24.
é Use the Æ key to move to the Language
mode and select your language by the Î ï
keys.
“ Use the Æ key to start search.
Plug’n’Play
Country
GB
Language
English
The search starts automatically. All the
available TV programmes will be stored. This
operation takes a few minutes. The display
shows the progress of the search and the
number of programmes found.
Important : To exit or interrupt the search
before it is completed, press the key.
If you interrupt search during auto store, not
all channels will be stored. For all channels to
be stored, you need to do a complete auto
store search again.
Note
ATS (Automatic Tuning System) feature
If the transmitter or cable network sends the
automatic sort signal, the programmes will be
numbered correctly. In this case, the installation
is complete. If this is not the case, you need to
use the Sort menu to number the programmes
correctly.
ACI (Automatic Channel Installation)
feature
If a cable system or a TV channel which
broadcasts ACI is detected, a programme
list appears. Without ACI broadcast, the channels
are numbered according to your language and
country selection. You can
use the Sort menu to renumber them.
Some transmitters or cable networks broadcast their
own sort parameters (region, language, etc.). In this
case, indicate your choice using the Î ï keys and
confirm with Æ key.
Note : Functions not available to Philips DVD-R device.
8
Programme Sort
Press the
key. The TV Menu is
displayed on the screen.
Use the ï key, select the Install menu
and the Æ /
key to enter the
Install menu.
Use the ï key to select Sort and the
Æ / key to enter sort mode.
Select the programme number you want to
move using the Î ï keys and the Æ /
key to enter sorting mode (The arrow cursor
now points to the left).
Use the Î ï keys to select the new
programme number and confirm with the
Í / key. (The arrow points to the
right and sorting is completed).
Repeat steps and for each
programme number you wish to re-number.
To return to previous menu, press the
key.
To exit the menu, press the
key.
1
4
5
4
3
5
6
2
7
TV Menu
Sound
Features
Install
Install
Language
Country
Auto Store
Manual Store
Sort
Name
Æ • 0
Æ • 1
Æ • 2
Æ • 3
Æ • 4
Æ • 5
Auto Store
Press the
key.
Using the ï key, select Install and the
Æ /
key to enter the Install menu
(Language is highlighted).
Select your desired menu *Language with
the Í Æ keys.
Select Country with the ï key and
use the Í Æ keys to select the country of
your choice.
Using the ï key, select Auto Store and
the Æ /
key to start automatic
searching of the channels. All the available TV
programmes will be stored. This operation
takes a few minutes. The display shows the
progress of the search and the number of
programmes found.
After the search is completed, press the
key to exit menu.
Important : To exit or interrupt the search
before it is completed, press the
key.
If you interrupt search during auto store, not
all channels will be stored. For all channels to
be stored, you need to do a complete auto
store search again.
1
2
3
5
4
6
TV Menu
Sound
Features
Install
Install
Language
Country
Auto Store
Manual Store
Sort
Name
Search
Æ
Æ
Æ
Æ
Æ
* Selecting the language
If you have selected the wrong language for one
reason or another and do not understand the
language to operate the set, do the following to
bring you back to your preferred language :
– press the key to exit the existing
menu.
– press the
key to enter the TV menu.
– press the
ï key repeatedly until the
FOURTH item in the TV menu is
highlighted.
– press the
Æ / key to go into the Install
menu.
– press the Í Æ keys to select your preferred
language (the menu will now appear in the
chosen language). You can proceed to install
the TV channels.
8
9
Manual Store
Search :
Press the Æ / key. The search starts.
Once a programme is found, the scanning
stops and its name is displayed (if available).
Go to the next step. If you know the
frequency of the required programme, this
can be entered directly using the
to
keys.
Program No. :
Enter the required number with the
to or Í Æ keys.
Fine Tune :
If the reception is not satisfactory, adjust
using the Í Æ keys.
Store :
To store the changes, press Æ /
key .
The programme is now stored.
Repeat steps
6
to
9
for each programme
to be stored.
To return to previous menu, press the
key.
To exit the menu, press the
key.
System : Use the Í Æ keys to select
Europe (automatic detection*),
France (LL’ standard),
UK (I standard),
West Europe (BG standard) or
East Europe (DK standard).
* Except for France (LL’ standard), you must
select France.
1
3
4
2
5
6
7
8
9
10
11
This menu is used to store the programmes
one at a time.
Press the
key.
With the ï key, select Install and the
Æ /
key to enter the Install menu.
Use the ï key to select Manual Store and
the Æ /
key to enter Manual Store
menu.
Use the Î ï keys to select the items in the
Manual Store menu to adjust or activate.
TV Menu
Sound
Features
Install
Manual Store
System
Search
Program No.
Fine Tune
Store
Europe
Æ
Æ
Æ
Æ
Naming of Channel
You can give a name to the TV channel.
Press the
key.
With the ï key, select Install and the
Æ /
key to enter the Install menu.
1
3
4
2
Use the ï key to select Name and
the Æ /
key to enter name mode.
Use the Î ï keys to select the programme
you want to name and the Æ /
key to
enter naming mode.
Use the Î ï keys to select the characters
and use the Í Æ keys to move around the
name display area (maximum of 5
characters).
Press Í Æ / key until the name
appears at the top left hand corner of the
TV screen. The name is now stored.
7
To exit the menu, press the
key.
5
6
TV Menu
Sound
Features
Install
Install
Language
Country
Auto Store
Manual Store
Sort
Name
8
Æ
Æ
Æ
Æ
Æ
Æ
12
10
Picture and Sound Settings
Press the key.
Use the Î ï keys to select Picture or
Sound.
Use the Í Æ /
keys to enter
Picture or Sound menu.
Use the Î ï keys to select a Picture or
Sound setting and the Í Æ keys to adjust.
Use the Î ï keys to select Store.
To store the changes, press key.
To return to previous menu, press the
key.
To exit the menu, press the key.
1
2
3
4
5
TV Menu
Sound
Features
Install
Brightness
Colour
Contrast
Sharpness
Colour Temp.
Store
39
TV Menu
Sound
Features
Install
Sound
• 120 Hz
• 500 Hz
• 1500 Hz
• 5 KHz
• 10 KHz
Equalizer Æ
Balance Æ
Delta Voliume Æ
AVL Æ
Dolby Virtual Æ
Store Æ
Description of the Picture settings
Brightness : this changes picture brilliance.
Colour : this changes the intensity of the colour.
Contrast : this changes the difference between
the light and dark tones.
Sharpness : this increases or decreases the
sharpness level to improve details in the picture.
Colour Temp. : this changes the colour
rendering: Cool (bluer), Normal (balanced) or
Warm (redder).
Store : to store the picture adjustments and
settings.
Description of the Sound settings
Equalizer : to adjust the sound tone (from bass:
120 Hz to treble : 10 KHz).
Balance : this balances the sound level on the left
and right speakers.
Delta Volume : this is used to compensate
any volume differences between the different
programmes or EXT sockets. Note : Programmes
0 to 40 have individual volume setting and
programmes 41 and above share common setting.
AVL (Automatic Volume Leveller) : this is used
to limit sudden increases in sound, especially on
programme change or advertising slots.
Dolby Virtual : To activate / deactivate the
surround sound effect.
You can also access these settings with the
key.
Store : this is used to store the sound settings.
6
7
8
11
Using the Contrast+ and NR (Noise Reduction) features
Press the key.
With the ï key, select Features and the
Æ / key to enter the Features menu.
Use the Î ï keys to select Contrast+ or
NR (Noise Reduction) and the Í Æ keys
to select an On or Off option.
To return to previous menu, press the
key.
To exit the menu, press the key.
Definition of the feature settings
Contrast+ :
– optimise the total contrast of the picture for
improved picture visibility.
– select On option to activate feature.
NR (Noise Reduction) :
– improves “noisy” picture (little dots on picture)
due to weak signal transmission.
– select On option to activate feature.
1
3
4
2
5
This menu lets you use the TV set as an alarm.
& Press the
key.
é With the ï key, select Features and the
Æ /
key to enter the Timer menu.
“ Use the Î ï key to access the settings
and the Í, Æ, Î, ï or
key to
select or adjust setting.
Sleep: to select an automatic standby period.
Time: enter the current time. Note: the time
is updated automatically each time the TV set
is switched on via the teletext information on
programme 1. If this programme does not have
teletext, the update will not take place.
Start Time: enter the start time.
Stop Time: enter the standby time.
Program No.: enter the number of the
programme for the wake-up alarm.
Activate: the settings include:
• Once for a single alarm,
• Daily for each day,
• Off to cancel.
‘ Press
to put the TV set in standby.
It will automatically come on at the
time programmed.
If you leave the TV set on, it will just
change programmes at the time entered
(and will go to standby mode at the Stop
Time).
Timer function
TV Menu
Sound
Features
Install
Timer
Sleep
Time
Start Time
Stop Time
Program No.
Activate
10:56
Æ
Æ
Æ
Æ
Æ
12
Using the PIP (Picture-in-Picture) feature
( Use the Î ï keys to select PIP menu items.
§ Use the Í Æ Î ï keys to access the PIP
menu items, make the following adjustments
or options.
è To exit the PIP screen, select PIP Size.
followed by the Off option.
Definitions of PIP items
PIP Size : Select your PIP size (Off, Small,
Medium, Large and Side-by-
Side).
Horizontal :
Move the PIP screen horizontally
from left to right and vice-versa.
Vertical :
Move the PIP screen vertically
from top to bottom and vice-versa.
Accessing the PIP screen via the PIP key
Note : This is only possible when PIP signal is
detected.
& Press the key on the remote control
to display PIP screen. A small PIP screen
will appear on the TV screen.
é Press the
key a second time to change
the small PIP screen to a medium PIP screen
size.
“ Press the key a third time to change the
medium PIP screen to large PIP screen size.
‘ Press the key a fourth time to change
the large PIP screen to a Side-by-Side (a TV
screen on one side and the PIP screen on the
other side).
(
Press the key a fifth time exit PIP screen.
The PIP (Picture-in-Picture) feature allows you
to call up a PIP screen of the PC (Personal
Computer) or HD (High Defintion) device
while watching a TV programme.
IMPORTANT
To call up a PIP screen of the PC equipment,
the following step must be taken :
HDMI input MUST be
connected to the DVI
output of the PC equipment. Use a HDMI/DVI cable
to do the connection.
To call up a PIP screen of the HD equipment,
the following steps must be taken :
HDMI input MUST be
connected to the HDMI
output of the HD equipment.
Accessing the PIP screen via the PIP menu
Note : This is only possible when PIP signal
is detected.
& Press the key to display main menu.
é With the Î ï key, select Features and
the Æ / key to enter the Features
menu.
“ Use the Î ï keys to select PIP.
‘ Use the Æ / key to enter PIP menu.
TV Menu
Sound
Features
Install
Features
Timer
Contrast+
NR
PIP
Æ
Æ
Æ
Æ
• PIP Size
• Horizontal
• Vertical
PIP
PIP Size
Horizontal
Vertical
Æ
Æ
Æ
Off
13
Screen Format
The pictures you receive may be transmitted in 16:9 format (wide screen) or 4:3 format (conventional
screen). 4:3 pictures sometimes have a black band at the left and right of the screen. This function
allows you to optimise the picture display on screen.
Press the
key (or Í Æ) to select the different modes. This TV set is also equipped with
automatic turning which will select the correct-screen format, provided the specific signals are
transmitted with the programmes.
4:3
The picture is reproduced in 4:3 format and a black band is displayed
on either side of the picture.
Movie expand 14:9
The picture is enlarged to 14:9 format, a thin black band remains on
both sides of the picture.
Movie expand 16:9
The picture is enlarged to 16:9 format. This mode is recommended
when displaying pictures which have black bands at the top and bottom
(letterbox format).
Subtitle Zoom
This mode is used to display 4:3 pictures using the full surface of the
screen leaving the sub-titles visible.
Superzoom
This mode is used to display 4:3 pictures using the full surface of the
screen by enlarging the sides of the picture.
Widescreen
The picture is displayed in the correct proportions of images
transmitted in 16:9.
Note: If you display a 4:3 picture in this mode, it will be enlarged
horizontally.
14
Using the Smart Picture and Sound features
Using the Active Control feature
Active Control feature automatically adjusts
the picture setting for optimal picture quality
continuously under any signal conditions.
& Press the key repeatedly to toggle
between Active Control Off and Active
Control On
options.
Active Control On
Active Control Off
é Select the Active Control On option to
activate the Active Control feature.
“ Select the Active Control Off option to
deactivate the Active Control feature.
Smart Picture feature offers you a choice of 5
picture settings namely : Rich, Natural, Soft,
Multimedia and Personal.
Press the button repeatedly to cycle
through the settings to select your desired mode.
Smart Sound feature offers you a choice of 4
sound settings namely : Theatre, Music, Voice,
and Personal.
Press the button repeatedly to cycle
through the settings to select your desired mode.
Rich
or
Personal
Multimedia
Natural
Soft
Theatre
or
Music
Voice
Personal
Definition of Picture Settings
Rich : Brilliant and sharp picture settings
suitable for bright environment and
for use in demonstrations to show
off the quality of the TV on good
sources.
Natural : Reference mode for living room
conditions and average signals.
Soft : Intended for bad-quality signals.
Suitable for living room viewing.
Multimedia : Best for graphical applications.
Personal : Pictures settings are set to your
preference.
Definition of Sound Settings
Theatre : Emphasize sensation to action (Bass
and Treble boosted).
Music : Emphasize low tone (Bass boosted).
Voice :
Emphasize high tone (Treble boosted).
Personal : Sound settings are set to your
preference.
NOTE : The Personal setting is the setting that
you set up using the Picture/Sound menu in the
main menu. This is the only setting in the Smart
Picture/Sound settings that can be changed. All
other settings are pre-set at the factory.
15
Teletext
Teletext is an information system broadcast by certain channels which can be consulted like a newspaper.
It also offers access to subtitles for viewers with hearing problems or who are not familiar with the
transmission language (cable networks, satellite channels, etc.).
Teletext call
1
Selecting a page
2
Direct access to
the items
3
Contents
4
5
Sub-page display
Double page
teletext
6
7
Hidden
information
Enlarge a page
8
9
Favourite pages
3
6
2
2
4
5
1
AUX
9
9
7
8
2
AUX
9
9
This is used to switch on or off teletext display. The
summary appears with a list of items that can be accessed.
Each item has a corresponding 3 digit page number. If
channel selected does not broadcast teletext, the
indication 100 will be displayed and the screen will remain
blank. Proceed to exit teletext and select another channel.
Enter the number of the page required using the 0 to 9
keys or P –/+ keys. Example: page 120, enter 120. The
number is displayed at the top left corner of the screen.
When the page is located, the counter stops searching.
Repeat this operation to view another page. If the counter
continues to search, this means that the page is not
transmitted. Select another number.
Coloured areas are displayed at the bottom of the
screen. The 4 colour keys are used to access the items or
corresponding pages. The coloured areas flash when the
item or the page is not yet available.
This returns you to the contents page (usually page 100).
Certain pages contain sub-pages which are automatically
displayed successively. This key is used to stop or resume
sub-page display. The indication
appears top left.
To activate or deactivate the double page teletext display
mode. The active page is displayed on the left and the
following page is displayed on the right. Press
if you
want to hold a page (i.e. the contents page). The active page
is then displayed on the right. To return to normal mode,
press the
key.
To display or hide the concealed information (games
solutions).
This allows you to display the top or bottom part of the
page. Pressing it again will return the page to normal size.
Instead of the standard coloured areas displayed at the
bottom of the screen, you can store 4 favourite pages on
the first 40 channels which can then be accessed using the
coloured keys (red, green, yellow, blue). Once set, these
favourite pages will become the default every time teletext
is selected.
1. Press the
key to change to favourite
pages mode..
2. Use the /
keys to enter the teletext
page that you want to store as a favourite page.
3. Press and hold the colour key of your choice for about 5
seconds. The page is now stored.
4. Repeat steps 2 to 3 with the other coloured keys.
5. To exit favourite page mode, press the
key.
6. To exit teletext mode, press
the key.
NOTE : To clear favourite pages, press and hold
key for about 5 seconds.
16
Using the TV as a PC Monitor
Your TV can be used as a computer monitor.
IMPORTANT
For the TV to function as PC monitor, the
following steps must be taken :
& HDMI input MUST be
connected to the
DVI output of the PC.
Use a DVI to HDMI
adaptor to do the connection.
é Press the
key to display Source List and
use the Î ï key to select HDMI
.
Use the Æ
/
key to switch to the selected
source
.
Using the PC menus
Press the
key to display the PC menu.
Use the Î ï key to access the settings
and the Í Æ /
key to select or adjust
setting (the settings are automatically saved).
Description Picture settings
Brightness / Contrast :
– Adjusts the brightness and contrast.
Colour Temp :
– Changes the colour rendering : Cool (bluer),
Normal (balance) or Warm (redder).
Audio Selection :
– Chooses the audio from the TV or PC/HD.
Source
TV
Æ
EXT 1
EXT 2 / SVHS2
EXT 3 / SVHS3
EXT 4
HDMI
Source
TV
EXT 1
EXT 2 / SVHS2
EXT 3 / SVHS3
EXT 4
HDMI
Æ
Description of Features
Format :
– Chooses between full screen or native format
of the PC screen.
PIP (Picture-in Picture) :
– Displays a PIP screen to watch TV programmes
at the same time.
Using the PIP feature
The PIP (Picture-in-Picture) feature allows you to
call up a PIP screen of a TV programme while you
are in PC mode.
IMPORTANT
To call up a PIP screen of the TV programme,
the
following step must be taken :
HDMI input MUST be
connected to the DVI
output of the PC equipment. Use a HDMI to DVI
adaptor cable to do the connection.
The PIP menu items : PIP Size, Horizontal and
Vertical works in exactly the same way as when
calling a PIP screen in TV mode.
For description of PIP menu items and how it
works, refer to the section on “Using the PIP
(Picture-in Picture) Feature” page 12.
Supported PC Resolutions
640 x 480, 60 Hz 1024 x 768, 60 Hz
640 x 480, 67 Hz 1024 x 768, 70 Hz
640 x 480, 72 Hz 1024 x 768, 75 Hz
640 x 480, 75 Hz
800 x 600, 56 Hz
800 x 600, 60 Hz
800 x 600, 72 Hz
800 x 600, 75 Hz
17
Using the TV in HD (High Definition) Mode
HD Mode
The HD (High Definition) mode allows you to
enjoy clearer and sharper pictures if you are
using a HD equipment that can produce high
definition programming.
IMPORTANT
For the TV to function in HD mode, the
following steps must be taken :
& HDMI input MUST be
connected to the
HDMI/DVI output of the
HD equipment
. Use
a HDMI to DVI adaptor if DVI is connected.
é Press the
key to display Source List
and
use the Î ï key to select HDMI.
“
Use the Æ
/
key to switch to the selected
source
.
Using the HD menus
&
Press the
key to display the HD menu.
é Use the Î ï key to access the settings
and the Í Æ / key to select or adjust
setting.
HD Install menu
Note : You cannot access Install in the HD
menu There is NO Install function in HD mode.
HD Picture and Sound settings
Functions of HD Picture and Sound settings are
the same as the TV Picture and Sound settings
and work in exactly the same way as the TV
Picture and Sound settings (see page 10).
HD Features
Timer : Functions of the Sleeptimer and Timer
are the same as the TV Sleeptimer and Timer
functions and work in exactly the same way as the
TV Sleeptimer and Timer functions (see page 11).
PIP : Display a PIP screen to watch TV
programmes at the same time. The PIP menu
items : PIP Size, Horizontal and Vertical work
in exactly the same way as when calling a PIP
screen in TV mode.
For description of PIP menu items and how it
works, refer to the section on “Using the PIP
(Picture-in Picture) Feature” page 12.
* Horizontal Shift : Adjust the horizontal
position of the image.
* Mode Selection : When you connect PC or
HD equipment supporting resolutions of 480p,
576p or 720p, the Mode Selection in the
Features menu will be highlighted. This will allow
you to select between the PC and HD mode.
If it does not support the 480p, 576p or 720p
resolutions, you cannot access this function.
Æ
Æ
Æ
Æ
HD
Features
Timer
Contrast+
NR
PIP
Horizontal Shift
Mode Selection
Supported HD format
480p 576p 720p 1080i
Source
TV
Æ
EXT1
EXT2 / SVHS2
AV / SVHS3
EXT 4
HDMI
Source
TV
EXT1
EXT2 / SVHS2
AV / SVHS3
EXT 4
HDMI
Æ
Your Philips TV is HDMI compliant. If you do not get a good picture, please change the video format
on your device (DVD player, cable set-top box, etc.) to a standard format. For example, for DVD
player, select 480p, 576p, 720p or 1080i. For PC, select 640 x 480, 800 x 600 or 1024 x 768. If
the problem persists, please refer to your PC user manual on possible software upgrades to your
graphics card.
Please note that this is not a defect of the TV set.
18
Connect peripheral equipment
CAUTION :
This is Class 1 apparatus.
It must be connected to a
MAINS socket out with a
protective earthing
connection.
Plasma
TV
To wall
socket
ANTENNA
: 75 Ω
Connectors at bottom of TV connection
To wall
socket
3
Press the AV key on the remote control
to display Source list. Select HDMI (ï key)
and confirm selection by the Æ/ key.
Source
TV
Æ
EXT1
Æ
EXT2 / SVHS2
Æ
EXT3 / SVHS3
Æ
EXT 4
Æ
HDMI
Æ
Connect your Cable or Satellite set-top box
Connectors of device is
for reference only. Your
device’s connectors may
be labeled differently.
1
Do connections as shown in diagram.
2
After connecting all cables or devices,
switch on your TV and the device.
EXT 4
EXT 2 /SVHS2
EXT 1
DVI
(AUDIO IN)
HDMI
AUDIO
R L
IN
Pr
Pb Y
L
R
EXT 4
EXT 2 /SVHS2
EXT 1
DVI
(AUDIO IN)
HDMI
AUDIO
R L
IN
Pr
Pb Y
L
R
To wall
socket
Set-Top Box
ANTENNA / CABLE
TO TV
Powercord Powercord
Antenna
Plasma LCD Cable
OR
OR
EXT 4
EXT 2 /SVHS2
EXT 1
DVI
(AUDIO IN)
HDMI
AUDIO
R L
IN
Pr
Pb Y
L
R
ANTENNA / CABLE
TO TV
To wall
socket
OR
AC in
LCD
TV
To wall
socket
1
Do connections
as shown in diagram.
2
After connecting all cables or devices,
switch on your TV and the device.
Connect power and antenna / cable
19
Connect your DVD Recorder / Player
Connect peripheral equipment
Source
TV
Æ
EXT1
Æ
EXT2 / SVHS2
Æ
EXT3 / SVHS3
Æ
EXT 4
Æ
HDMI
Æ
Source
TV
Æ
EXT1
Æ
EXT2 / SVHS2
Æ
EXT3 / SVHS3
Æ
EXT 4
Æ
HDMI
Æ
OR
Connectors of device is for reference only. Your
device’s connectors may be labeled differently. For
more information on connection to DVD
Recorder/Player, refer to device’s instruction manual.
3
Press the AV key on the remote control
to display Source list. Select HDMI or
EXT 1 (ï key) and confirm selection
by the Æ/ key.
1
Do connections as shown in diagram.
2
After connecting all cables or devices,
switch on your TV and the device.
EXT 4
EXT 2 /SVHS2
EXT 1
DVI
(AUDIO IN)
HDMI
AUDIO
R L
IN
Pr
Pb Y
L
R
DVD / DVD-R
Do this connection
for DVD Recording
Connectors at bottom of TV
ANTENNA/CABLE
TO TV
To wall socket
TO
TV
OR
1
Do connections
as shown in diagram.
2
After connecting all cables or devices,
switch on your TV and the device.
3
Press the
AV key on the remote control
to display Source list. Select EXT 4 (
ï
key) and confirm selection by the
Æ/
key.
Source
TV
Æ
EXT1
Æ
EXT2 / SVHS2
Æ
AV / SVHS3
Æ
EXT 4
Æ
HDMI
Æ
Do this connection
for DVD Recording
Pr/R/V Pb/B/U Y/G
OUT
IN
AV
EXT 4
EXT 2 /SVHS2
EXT 1
DVI
(AUDIO IN)
HDMI
AUDIO
R L
IN
Pr
Pb Y
L
R
To wall socket
To TV
DVD / DVD-R
Connectors at bottom of TV
Do this
connection
for DVD
Recording
20
EXT 4
EXT 2 /SVHS2
EXT 1
DVI
(AUDIO IN)
HDMI
AUDIO
R L
IN
Pr
Pb Y
L
R
Connect peripheral equipment
Connect your VCR
3
Press the AV key on the remote control
to display Source list. Select EXT 1 or
EXT 2 / SVHS2 (ï key) and confirm
selection by the Æ/ key.
1
Do connections as shown in diagram.
2
After connecting all cables or devices,
switch on your TV and the device.
ANTENNA/
CABLE
TO TV
To wall socket
Connectors at bottom of TV
VCR
Connectors of device is for reference only. Your
device’s connectors may be labeled differently.
Important : In order to connect your
Decoder box, please use EXT 1 scart only.
OR
1
Do connections as shown in diagram.
2
After connecting all cables or devices,
switch on your TV and the device.
To TV
Antenna
Cable
Connectors at bottom of TV
Side connectors
of TV
VCR
To TV
To wall socket
Source
TV
Æ
EXT1
Æ
EXT2 / SVHS2
Æ
EXT3 / SVHS3
Æ
EXT 4
Æ
HDMI
Æ
3
Press the AV key on the remote control
to display Source list. Select EXT3/SVHS3
(ï key) and confirm selection by the
Æ/ key.
EXT 4
EXT 2 /SVHS2
EXT 1
DVI
(AUDIO IN)
HDMI
AUDIO
R L
IN
Pr
Pb Y
L
R
VIDEO L AUDIO R
S-VIDEO
VIDEO
IN
AUDIO
IN
R
L
21
Connect peripheral equipment
Connectors of device is for reference
only. Your device’s connectors may be
labeled differently.
Connect your PC (Personal Computer)
3
Press the AV key on the remote control
to display Source list. Select HDMI (ï key)
and confirm selection by the Æ/ key.
1
Do connections as shown in diagram.
2
After connecting all cables or devices,
switch on your TV and the device.
NOTE : PC connection is only
available via HDMI / DVI connector.
VGA connection is not supported.
Source
TV
Æ
EXT1
Æ
EXT2 / SVHS2
Æ
EXT3 / SVHS3
Æ
EXT 4
Æ
HDMI
Æ
EXT 4
EXT 2 /SVHS2
EXT 1
DVI
(AUDIO IN)
HDMI
AUDIO
R L
IN
Pr
Pb Y
L
R
Audio
Out
Connectors
of PC
Connectors at bottom of TV
Connect your Game Console /Camera
1
Do connections
as shown in diagram.
2
After connecting all cables or devices,
switch on your TV and the device.
Connectors
of device
Connectors
of device
Connect your
Headphone
For your own personal listening pleasure,
connect the phono jack to the headphone
connector of the TV. There will be no sound
from the TV’s speakers
.
Side connectors
of TV
3
Press the
AV
key on the remote control
to
display Source list. Select
EXT3
/
SVHS3
(
ï
key) and confirm selection by the
Æ
/
key.
OR
S-VIDEO
VIDEO
IN
AUDIO
IN
R
L
S-VIDEO
VIDEO
AUDI
O
R
L
S-VIDEO
VIDEO
IN
AUDIO
IN
R
L
S-VIDEO
VIDEO
IN
AUDI
O
IN
R
L
S-VIDEO
VIDEO
AUDI
O
R
L
Use left (white) audio only
for mono sound
Use left (white) audio only
for mono sound
Side connectors
of TV
22
Troubleshooting Tips
Below is a list of symptoms you may encounter with your TV. Before you call for service, make these
simple checks.
Symptom Possible Causes What you should do
No display on screen • Faulty power supply • Check whether power cord is properly connected
• TV’s Power not turned into the mains socket and to your TV. If there is still
no power, on disconnect plug. Wait for 60 seconds
and re-insert plug. Switch on TV again.
• Press the
key on the remote control.
Poor reception • Faulty antenna connection • Check antenna connection at rear of TV.
(snowish picture and
• Weak transmission • Try manually adjusting your picture (refer to page 9).
noise)
• Wrong TV system •
Have you chosen the right TV system? (refer to page
9).
No picture • Faulty aerial and cable • Check whether euroconnector cables or aerial
sockets are properly connected.
• Wrong source selected • Check whether the source is correctly select ed.
Press key to enter Source list and select
the correct source.
No sound on • Wrong TV system • Check whether the correct TV system is selected
certain channels (refer to page 9).
No sound • Zero volume level • Try increasing volume.
• Sound muted • Check that the mute ( ) mode is not on. If mute
mode is on, press the key to deactivate mute
mode.
• Aim remote control directly at sensor on front of TV.
• Headphone is connected • Disconnect headphone connection.
Sound interference • Electrical appliances • Try switching off any electrical appliances, for
interference example, hairdryer, vacuum cleaner that are in use.
Unable to understand • Wrong language selected •
Press the key to exit menu from screen. Press
the language on accidently
the key to enter main menu. Use the ï key
screen to operate set to
select the fourth item on the main menu. Use
Æ
/
key to enter into the next menu level and
the
Í Æ
key to
select correct language.
TV not responding •
Wrong placement of •
Check the placement of the batteries.
to remote control
batteries
• Flat batteries • Try changing the batteries.
Occasional appearance
• Characteristic of liquid • This symptom is not a problem. The liquid crystal
of red, blue, green crystal panel panel is built with very high precision technology
and black spots on giving you the fine picture details. Occasionally, a few
screen non-active pixels may appear on the screen as a fixed
point of red, blue, green or black. Note that this
does not affect the performance of the set.
Intermittent or • * HDCP (see glossary) • Noise is displayed if the connected digital equipment’s
flickering picture on authentication failed (DVD player or Set-Top box) *HDCP authentication
in HD mode failed. Check user manual for the digital equipment
you are connecting.
• Use a standard HDMI to DVI cable.
No sound or picture but
• Set on standby mode • Press the
key on the remote control.
front panel red light is
on
23
Troubleshooting Tips
Glossary
DVI (Digital Visual Interface) : A digital interface
standard created by the Digital Display Working Group
(DDWG) to convert analog signals into digital signals to
accommodate both analog and digital monitors.
RGB signals : These are the three video signals,
Red Green Blue, which make up the picture. Using
these signals improves picture quality.
S-VHS signals : These are 2 separate Y/C video
signals from the S-VHS and Hi-8 recording
standards. The luminance signals Y (black and
white) and chrominance signals C (colour) are
recorded separately on the tape. This provides
better picture quality than with standard video
(VHS and 8 mm) where the Y/C signals are
combined to provide only one video signal.
NICAM sound : Process by which digital sound
can be transmitted.
16:9 : Refers to the ratio between the length and
height of the screen. Wide screen televisions have
a ratio of 16/9, conventional screen TV sets have a
ratio of 4/3.
HDMI (High-Definition Multimedia Interface) : Provides
an uncompressed, all digital audio/video interface
between the TV and any HDMI-equipped audio/video
component, such as set-top box, DVD player and A/V
receiver. HDMI supports enhanced or high-definition
video plus two-channel digital audio.
System : Television pictures are not broadcast in the
same way in all countries. There are different standards:
BG, DK, I, and LL’. The System setting (page 8) is used
to select these different standards. This is not to be
confused with PAL or SECAM colour coding. PAL is
used in most countries in Europe, SECAM in France,
Russia and most African countries. The United States
and Japan use a different system called NTSC.
HDCP (High-bandwidth Digital-Content Protection):
HDCP encrypts the transmission of digital content
between the video source or transmitter such as a
computer, DVD player or set-top box and the digital
display or receiver such as a monitor, television or
projector.
Symptom Possible Causes What you should do
Cannot access Install • In AV, EXTERNAL or • Press AV key and select TV mode. You can now
menu HD mode access the Install menu by using the Menu key.
PC modes do not • Wrong connections • Check whether connections are correct. (see
work “Using your TV as PC Monitor” on page 16).
• Wrong source selected. • Check whether the source is correctly selected.
Press
button to enter Source list and select
the correct source.
• Wrong display resolution • Check whether you have configured the computer on
a compatible display resolution (see “Using your TV
as PC Monitor” on page 16).
• Wrong setting of PC • Check graphic card setting of PC.
graphic card
S-Video colour • Wrong detection of • Check whether power cord is properly connected
becomes faint signal • Press the P + key on the remote control to do a
channel up and then press the P – key to do a
channel down.
Black bar on top • PC refresh rate too high • Change PC refresh rate to 60 Hz.
and bottom of
screen in PC mode
24
Specifications
Reference table of Countries available for selection
Abbreviation Country Abbreviation Country Abbreviation Country
A Austria GR Greece H Hungary
B Belgium I Italy HR Croatia
CH Switzerland IRL Ireland PL Poland
D Germany L Luxembourg RO Romania
DK Denmark N Norway RUS Russia
E Spain NL Netherlands SK Slovakia
F France P Portugal SLO Slovenia
FI Finland S Sweden TR Turkey
GB England CZ Czech Republic - - - Others
26PFL3321S 32PFL3321S
Panel screen size 66 cm (26”) 80 cm (32”)
Audio output 2 x 5 W 2 x 15 W
TV System PAL, SECAM
Video playback NTSC, PAL, SECAM
Sound System Mono, Nicam Stereo, Virtual Dolby Surround
Power consumption 110 W 120 W
Standby power consumption < 1 W < 1 W
Set dimensions (with stand)
Width 80.5 cm 92.4 cm
Depth 22.2 cm 22.2 cm
Height 47.7 cm 55 cm
Nett Weight (with stand)
13.3 kg 19 kg
Specification and information are subject to change without notice.
© 2006 Koninklijke Philips N.V.
All rights reserved
Document order number:
Loading...
