Introduction
Thank you for purchasing this television set.
This handbook has been designed to help you install and operate your TV set.
We strongly recommend that you read it thoroughly.
Table of Contents |
GB |
Recycling
The packaging of this product is intended to be recycled. Apply to the local authorities for correct disposal.
Disposal of your old product
Your product is designed and manufactured with highly quality material and components, which can be recycled and reused. When this crossed-out wheeled bin symbol is attached to a product, it means the product is covered by the European Directive 2002/976/EC.
Please inform yourself about the local seperate collection system for electrical and electronic products.
Please act according to your local rules and do not dispose of your old products with your normal household waste. The correct disposal of your product will help prevent potential negative consequences for the environment and human health.
1
Safety Information |
|
|
10 cm |
10 cm |
10 cm |
Leave at least 10 cm around each side of the |
|
TV set to allow for proper ventilation. Place |
|
the set on a stable, level surface. Never cover |
|
the ventilation slots of the TV with a cloth or |
|
other material. It may cause overheating. Do not |
|
insert anything in the ventilation holes. If metal |
|
or something flammable is inserted in these |
|
holes, it may result in fire or electric shock. |
|
|
X |
Take care not to connect too many equipment |
|
to the same mains socket as it may cause |
|
overloading resulting in fire or electric shock. |
|
X
When cleaning the surface or the screen of the set, wipe gently with absorbent cotton or cloth or other soft material like chamois. Do not use too wet a cloth which is dripping with water. Do not use acetone, toulene or alcohol to clean the TV. As a safety precaution, unplug the power cord from the mains.
X
Pull the power lead by the plug. Do not pull on the power lead. Do not use a poor fitting mains socket. Insert the plug fully into the mains. If it is loose, it may cause arching and result in fire.
X
X
To prevent fire or shock hazard, do not expose |
No naked flame sources (lighted candles) should |
|
be placed on the top of the set or near it. |
||
your TV to rain or moisture. |
||
|
||
X |
|
Avoid placing your TV set under direct sunlight |
As a safety precaution, do not touch any part of |
|
the TV, power lead or aerial lead during lightning |
||
or heat. |
||
storms. |
||
|
Installation of the TV set on the wall should be carried out by qualified serviceman. Improper and incorrect installation may render the set unsafe.
X
Avoid placing vase filled with water on the TV. Water spilled into the set could result in electric shock. Do not operate set if water is spilled into it. Have it checked immediately by a qualified serviceman.
2
Preparation / Getting started
1Connections
26”
32”
37”/42”/50”
•Insert the aerial plug into the 75Ω : socket at the bottom of the set.
•Insert the mains plug into a wall socket (220-240V / 50/60Hz).
•Ensure the power cord is fully inserted in the TV mains socket and the wall socket.
Warning!
If the TV is mounted on a swivel base or swivel arm, ensure no strain is placed on the power cord when the TV is swivelled. Strain on the power cord can loosen connections. This may cause arching and result in fire.
3 Switching on the TV set
– VOLUME + MENU – PROGRAM +
37”/42”/50”
2Using the Remote Control
26”
32”
Pull out the plastic insulation sheet from the battery to enable the remote control to operate.
NOTE
For more details on other connections, see “CONNECTION GUIDE”.
•To switch on the TV set, press the POWER button. A green indicator comes on and the screen lights up.
•If the TV set remains in standby mode (red indicator), press the PROGRAM – / + key on the keyboard or the P – / + key on the remote control.
3
Television keys and connectors
11
4
3
2
1
POWER – VOLUME + MENU – PROGRAM +
Headphone
32” Audio In AUDIO
R
IN
L
Video In |
IN |
|
VIDEO |
S-Video |
S-VIDEO |
EXT3/SVHS3
|
6 |
|
7 |
|
|
|
|
|
|
|
|
5 |
|
|
|
EXT 4 |
|
|
L |
|
AUDIO R L |
Pr Pb |
Y |
|
|
IN |
|
|
|
|
|
|
|
|
|
HDMI 2 |
R |
HDMI 1 |
|
|
|
AC in ~ |
DVI |
|
EXT 2 /SVHS2 |
EXT 1 |
|
(AUDIO IN) |
|
|
|
||
8 |
9 |
10 |
2 |
|
37”/42”/50” |
|
3 |
|
4 |
|
|
EXT3/SVHS3 |
1 |
11 |
|
CAUTION : This |
5 |
|
|
a Class 1 apparatus. |
|
It must be connected |
|
to a MAINS socket |
|
out with a protective |
|
earthing connection. |
MAINS ~ |
|
|
|
Plasma TV |
67
|
|
|
|
EXT 4 |
Pr |
Pb |
Y |
5 |
|
L |
|
AUDIO R |
L |
|
|||
|
|
IN |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
HDMI 2 |
R |
HDMI 1 |
|
|
|
|
|
|
|
|
|
|
|
|
|
||
|
DVI |
|
EXT 2 /SVHS2 |
|
EXT 1 |
|
|
|
(AUDIO IN) |
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
AC in ~ |
|
|
8 |
|
|
|
9 |
10 |
LCD |
|
|
|
|
|
|
|
|
TV |
4
