1. Important

1. Important

This electronic user’s guide is intended
for anyone who uses the Philips
monitor. Take time to read this user's
manual before you use your monitor.
It contains important information and
notes regarding the operation of your
monitor.

The Philips guarantee applies provided
the product is handled properly for
its intended use, in accordance with
its operating instructions and upon
presentation of the original invoice
or cash receipt, indicating the date of
purchase, dealer’s name and model
and production number of the product.

1.1 Safety precautions and
maintenance

Warnings

Use of controls, adjustments or
procedures other than those specified
in this documentation may result in
exposure to shock, electrical hazards
and/or mechanical hazards.

Read and follow these instructions
when connecting and using your
computer monitor.

Operation

• Please Keep the monitor out of

direct sunlight, very strong bright
lights and away from any other heat
source. Lengthy exposure to this
type of environment may result in
discoloration and damage to the
monitor.

• Remove any object that could fall

into ventilation holes or prevent
proper cooling of the monitor’s
electronics.

• Do not block the ventilation holes

on the cabinet.

• When positioning the monitor,
make sure the power plug and out­let are easily accessible.

• If turning o the monitor by detach­ing the power cable or DC power
cord, wait for 6 seconds before
attaching the power cable or DC
power cord for normal operation.

• Please use approved power cord
provided by Philips at all times. If
your power cord is missing, please
contact your local service center.
(Please refer to Customer Care Con­sumer Information Center)

• Do not subject the monitor to se­vere vibration or high impact condi­tions during operation.

• Do not knock or drop the monitor
during operation or transportation.

Maintenance

• To protect your monitor from pos­sible damage, do not put excessive
pressure on the LCD panel. When
moving your monitor, grasp the
frame to lift; do not lift the monitor
by placing your hand or ngers on
the LCD panel.

• Unplug the monitor if you are not
going to use it for an extensive pe­riod of time.

• Unplug the monitor if you need to
clean it with a slightly damp cloth.
The screen may be wiped with a dry
cloth when the power is o. Howev­er, never use organic solvent, such
as, alcohol, or ammonia-based
liquids to clean your monitor.

• To avoid the risk of shock or per­manent damage to the set, do not
expose the monitor to dust, rain,
water, or excessive moisture envi­ronment.

• If your monitor gets wet, wipe it with
dry cloth as soon as possible.

1

1. Important

• If foreign substance or water gets in
your monitor, please turn the power
o immediately and disconnect the
power cord. Then, remove the for­eign substance or water, and send it
to the maintenance center.

• Do not store or use the monitor in
locations exposed to heat, direct
sunlight or extreme cold.

• In order to maintain the best per­formance of your monitor and use
it for a longer lifetime, please use
the monitor in a location that falls
within the following temperature
and humidity ranges.

• Temperature: 0-40°C 32-104°F

• Humidity: 20-80% RH

• IMPORTANT: Always activate a

moving screen saver program when
you leave your monitor unattended.
Always activate a periodic screen
refresh application if your monitor
will display unchanging static con­tent. Uninterrupted display of still
or static images over an extended
period may cause “burn in”, also
known as “after-imaging” or “ghost
imaging”, on your screen.

• "Burn-in", "after-imaging", or
"ghost imaging" is a well-known
phenomenon in LCD panel technol­ogy. In most cases, the “burned in”
or “after-imaging” or “ghost imag­ing” will disappear gradually over a
period of time after the power has
been switched o.

Warning

Failure to activate a screen saver, or
a periodic screen refresh application
may result in severe “burn-in” or “after­image” or “ghost image” symptoms
that will not disappear and cannot be
repaired. The damage mentioned above
is not covered under your warranty.

Service

• The casing cover should be opened
only by qualied service personnel.

• If there is any need for any docu­ment for repair or integration,
please contact with your local
service center. (please refer to the
chapter of "Consumer Information
Center")

• For transportation information,
please refer to "Technical Specica­tio n s".

• Do not leave your monitor in a car/
trunk under direct sun light.

Note

Consult a service technician if the
monitor does not operate normally, or
you are not sure what procedure to take
when the operating instructions given
in this manual have been followed.

1.2 Notational Descriptions

The following subsections describe
notational conventions used in this
document.

Notes, Cautions and Warnings

Throughout this guide, blocks of text
may be accompanied by an icon and
printed in bold or italic type. These
blocks contain notes, cautions or
warnings. They are used as follows:

Note

This icon indicates important
information and tips that help you make
better use of your computer system.

Caution

This icon indicates information that
tells you how to avoid either potential
damage to hardware or loss of data.

Warning

This icon indicates the potential for

2

1. Important

bodily harm and tells you how to avoid
the problem.

Some warnings may appear in alternate
formats and may not be accompanied
by an icon. In such cases, the specific
presentation of the warning is
mandated by the relevant regulatory
authority.

1.3 Disposal of product and
packing material

Waste Electrical and Electronic
Equipment-WEEE

This marking on the product or on
its packaging illustrates that, under
European Directive 2012/19/EU
governing used electrical and electronic
appliances, this product may not be
disposed of with normal household
waste. You are responsible for disposal
of this equipment through a designated
waste electrical and electronic
equipment collection. To determine the
locations for dropping off such waste
electrical and electronic, contact your
local government office, the waste
disposal organization that serves your
household or the store at which you
purchased the product.

Your new monitor contains materials
that can be recycled and reused.
Specialized companies can recycle
your product to increase the amount of
reusable materials and to minimize the
amount to be disposed of.

All redundant packing material has been
omitted. We have done our utmost to

make the packaging easily separable
into mono materials.

Please find out about the local
regulations on how to dispose of your
old monitor and packing from your
sales representative.

Taking back/Recycling Information for
Customer

Philips establishes technically and
economically viable objectives
to optimize the environmental
performance of the organization's
product, service and activities.

From the planning, design and
production stages, Philips emphasizes
the important of making products that
can easily be recycled. At Philips, end­of-life management primarily entails
participation in national take-back
initiatives and recycling programs
whenever possible, preferably
in cooperation with competitors,
which recycle all materials (products
and related packaging material) in
accordance with all Environmental
Laws and taking back program with the
contractor company.

Your display is manufactured with high
quality materials and components
which can be recycled and reused.

To learn more about our recycling
program please visit

http://www.philips.com/a-w/about/
sustainability.html

s

3

2. Setting up the monitor

2. Setting up the

323E7

©

2
