Philips 27MS5402 User Manual
27MS5402
27v 100Hz TV
An HDTV monitor with YPbPr-ultimate in digital connectivty. Its widescreen format
ensures that nothing is missing from your movies and with Dolby Virtual surround sound
and 20 watt audio power you're in for an unmatched cinema experience.
• HDTV Monitor for the highest quality display of HDTV signals
• Progressive Scan component video for optimized image quality
• Virtual Dolby Surround for a cinema-like audio experience
• Philips Compass UI for easy navigation and control
• Smart Picture and Smart Sound to personalize your viewing
• Component Video is the best connection for DVD display
27MS5402/17
27v 100Hz TV
Product specifications
Picture/Display
• Aspect ratio: 4:3
• Visible diagonal screen size: 68 cm
• Diagonal screen size - wide: 28 inch
• Diagonal screen size - tele: 72 cm
• Display screen type: Real Flat picture tube
• Picture enhancement: Active Control, Color
Transient Improvement, Crystal Clear III, Digital
Noise Reduction, Dynamic Contrast, Dynamic
Scavem, LTI, Picture Freeze, Progressive Scan
• Screen enhancement: Anti-Reflection coated
screen
• Picture processing: Progressive Scan
Sound
• Sound Enhancement: DSP
• Sound System: Virtual Dolby Surround
• Music Power: 40 W
Loudspeakers
• Built-in speakers: 2
Convenience
• Ease of Installation: Autosearch, Autostore, PLL
Digital Tuning
• Ease of Use: Smart Picture Control, Smart
Sound Control, Top Controls, Auto Volume
Leveller (AVL), Picture Freeze
• Remote control type: RCAU04_SA
• Teletext: Closed Captioning Full Text
• Screen Format Adjustments: 4:3, 4:3 expand,
16:9 compress
• Clock: Sleep Timer, Smart Clock, Wake up Clock
Tuner/Reception/Transmission
• TV system: NTSC
• Aerial Input: 75 ohm coaxial (IEC75)
• Tuner Display: PLL Quartz Digital
• Number of Preset Channels: 140
• EDTV progressive scan: ED 480p, 31.470 kHz,
60 Hz
• HDTV interlaced: HD 1080i, 33.750 kHz, 60 Hz
Connectivity
• Number of AV connections: 4
• Other connections: Monitor out, CVBS, L/R
(cinch), F-Type (75 ohm)
• AV 1: Audio L/R in, YPbPr
• AV 2: Audio L/R in, S-Video
• AV 5: YPbPr
• Front / Side connections: Audio L/R in,
Headphone out, S-video in, Video in
Power
• Power consumption: 140 W
• Standby power consumption: < 1 W
• Power supply: 110V, 60Hz
Dimensions
• Product weight (lb): 108
• Weight incl. Packaging: 53 kg
• Set color: Silver Shadow
HDTV Monitor
HDTV is the latest and best television signal
available. It produces picture quality more than
twice that of traditional analog broadcasts. In order
to effectively maximize the HDTV signal, a
television must incorporate advanced signal input
connectivity
Progressive Scan
Progressive Scan doubles the vertical resolution of
the image resulting in a noticeably sharper picture.
Instead of sending a field comprising the odd lines
to the screen first, followed by the field with the even
lines, both fields are written at one time. A full image
is created instantaneously, using the maximum
resolution. At such a speed, your eye perceives a
sharper picture with no line structure.
Virtual Dolby Surround
Virtual Dolby Surround is a processing technology
for enhancing surround sound effects. It will create
the sensation of Dolby Pro Logic without the
necessity of additional rear speakers. You become
totally immersed in your television experience.
Philips Compass UI
Philips Compass UI is an intuitive and easy-to-use
GUI (graphical user interface). It is based on a
four-way navigational focus point (puck) that at any
time indicates to you where you are in the menu
structure and which directions you can navigate
from there.
Smart Picture and Smart Sound
Philips preset modes for Smart Picture and Smart
Sound provide you with direct access via a single
key on the remote control. You can select optimized
picture and sound settings for the various picture
and sound modes.
Date of issue 2008-02-22
Version: 1.0.3
12 NC: 8670 000 20592
Component Video (YPbPr)
Component video is a technique for recording and
transmitting of video in which each color is
maintained in a separate channel. RGB is an
example of component video using one channel
each for red (R), green (G) and blue (B). It is the
way to connect a DVD player for optimum picture
quality.
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips Electronics N.V. or
their respective owners.
© 2008 Magnavox.
All Rights reserved.
www.magnavox.com
