26MF605W
26" LCD HD flat TV
Widen your viewing horizons! High definition TV excitement-ready, the widescreen, high
brightness 26MF605W delivers smart features for hassle-free fun, virtual surround high
performance audio and even doubles as a digital or VGA PC monitor.
•High brightness HDTV-ready LCD TV
•Widescreen LCD TV
•3D combfilter for a crisp and ultra sharp picture
•Fast response time panel technology
•Multiple Audio/Video inputs (480i/p, 720p, 1080i)
•DVI-D input and HDCP support
•VGA input for use as a PC monitor
•Smart picture and sound presets
Page 2
26MF605W/17
26" LCD HD flat TV
Product specifications
Picture/Display
• Aspect ratio: 16:9
• Brightness: 500 cd/m²
• Contrast ratio (typical): 800:1
• Display screen type: LCD WXGA Active Matrix TFT
• Picture enhancement: 3/2 - 2/2 motion pull down,
Combfilter, 3D MA deinterlacing, Automatic skin
3D
tone correction, Black stretch, Blue stretch, Green
enhancement, Progressive Scan, White stretch
• Screen enhancement: Anti-Reflection coated
reen
sc
• Viewing angle (H / V): 176 / 176 degree
• Response time (typical): 8 (grey to grey) ms
• Panel resolution: 1366 x 768p
Supported Display Resolution
Resolution Refresh rate
omputer formats
C
640 x 480 60Hz
800 x 600 56, 60Hz
1024 x 768 60Hz
1280 x 720 60Hz
1280 x 768 60Hz
Video formats
480i 60Hz
480p 60Hz
720p 60Hz
1080i 60Hz
Sound
• Output power (RMS): 2 x 5W
• Sound Enhancement: Virtual Surround Sound
• Sound System: Mono, SAP
Loudspeakers
• Built-in speakers: 2
Convenience
• Ease of Installation: Autostore, Fine Tuning, PLL
Digital Tuning
• Ease of Use: Auto Volume Leveller (AVL), Smart
cture, Smart Sound, Closed Captioning Full Text
Pi
• Remote control type: RC1112713/17B
• Remote Control: TV
• Screen Format Adjustments: 4:3, Superwide,
descreen, Zoom 16:9
Wi
• User convenience: Sleep Timer
• VESA Mount: 100 x 100 mm
• Child Protection: Child Lock+Parental Control
Tuner/Reception/Transmission
• Tuner bands: Hyperband, S-Channel, UHF, VHF
• TV system: NTSC
• Video Playback: Multi-system
• Aerial Input: 75 ohm F-type
• Number of channels (cable): 125
• Number of channels (off-air): 69
Connectivity
• AV 1: Audio L/R in, CVBS in, S-Video
• AV 2: Audio L/R in, CVBS in, S-Video
• AV 3: Audio L/R in, YPbPr, 480i, 576i
• AV 4: Audio L/R, YPbPr, 480i, 480p, 576i, 576p,
, 1080i
720p
• AV 5: Audio L/R in, DVI-D with HDCP, 480i, 480p,
576p, 720p, 1080i
576i,
• AV output: Audio (L/R) x1, Composite (CVBS) x1
• PC: 3.5 mm PC audio input x1, VGA-in D-Sub 15HD
• Rear Connections: Antenna F-type, D-Sub in (PC),
audio in 3.5 mm jack, Headphone out 3.5 mm
PC
jack
Power
• Power consumption: < 100 W
• Standby power consumption: < 1 W
• Ambient temperature: 5 °C to 40 °C
• Power supply: 90-264 VAC, 50/60 Hz
Dimensions
• Product weight (+stand): 14 kg
• Product weight (+stand) (lb): 30.9 lb
• Set dimensions with stand (W x H x D):
820 x 480 x 213 mm
• Set dimensions with stand in inch (W x H x D):
2 x 18.9 x 8.4 inch
32.
HDTV-ready LCD TV
HDTV delivers exceptional picture quality and real
movie-viewing experience that makes television more
dynamic, truer than anything you've seen before. It is
the latest and best television signal available. It
features picture quality more than twice that of
traditional analog broadcasts. In order to effectively
maximize the HDTV signal, a television must
incorporate advanced signal input connectivity and
circuitry design. To use HDTV the TV must be
connected through its component video or DVI inputs
to a DTV set-top box and set to operate in the DTV
mode.
Widescreen LCD TV
The screen's wider width to height aspect ratio
enhances the viewer's entertainment experience.
3D combfilter
A 3D combfilter is a device that performs field-by-field
comparisons of the television image to accurately
separate the color from the black-and-white
information. It separates brightness and color signals
better in the 3D domain to eliminate cross-color,
cross-luminance and dot-crawl distortion - all of which
detract from your viewing pleasure.
Fast response time
Faster response time delivers improved display of
video action with faster transitions that dramatically
reduce visible image artifacts in the display of
fast-moving images.
Multiple AV inputs
Multiple AV inputs accommodate a variety of format
choices in connecting video and audio devices (480i/
p, 720p, 1080i).
DVI-D input and HDCP support
A DVI-D input makes an uncompressed digital RGB
connection from source to screen. By eliminating the
conversion of the digital signal to analog, it delivers an
unblemished image. Thanks to the non-degraded
signal, you get less flicker and a clearer picture. The
DVI input is fully backward compatible with HDMI
sources and also uses HDCP copy protection.
VGA input
VGA input provides a connector to accommodate input
of an analog signal for use as a PC monitor.
Date of issue 2009-07-31
Version: 2.0.5
12 NC: 8639 000 16053
UPC: 0 37849 95943 5
Smart picture & Smart sound
Smart picture and Smart sound presets are optimized
settings for all your favorite types of programs, various
display and audio modes that are directly accessed
through a single key on the remote control.
Virtual surround sound
Virtual surround sound creates additional audio
channels for a theater-like audio experience.
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips Electronics N.V. or their
respective owners.
© 2009 Magnavox.
All Rights reserved.
www.magnavox.com
Page 3
26MF605W/17
26" LCD HD flat TV
Product specifications (continued)
Accessories
• Included Accessories: Batteries for remote control,
Power cord, Quick Use Guide, Remote Control,
Right angle antenna adaptor, User Manual,
Warranty certificate
