Philips 22PFL5604D-12 User Manual

Download

www.philips.com/welcome

22PFL5604D/12 26PFL5604D/12

EN User Manual

Model

www.philips.com/support

Serial

Österreich 0810 000205 €0.07 pro Minute België/Belgique 078250145 €0.06 Per minuut/Par minute България +3592 489 99 96 Местен разговор Hrvatska 01 6403 776 Lokalni poziv Česká republika 800142840 Bezplatný hovor Danmark 3525 8759 Lokalt opkald Estonia 6008600 local Suomi 09 2311 3415 paikallispuhelu France 0821 611655 €0.09 Par minute Deutschland 01803 386 852 €0.09 pro Minute Ελλάδα 0 0800 3122 1280 Κλήση χωρίς χρέωση Magyarország 0680018189 Ingyenes hívás Ireland North 0800 055 6882

free

South 1800-PHILIPS 7445477 Italia 840320086 €0.08 Al minuto Қазақстан +7 727 250 66 17 local Latvia 67228896 local Lithuania 52737691 local Luxemburg/Luxembourg 40 6661 5644 Ortsgespräch/Appel local Nederland 0900 8407 €0.10 Per minuut Norge 2270 8111 Lokalsamtale Polska (022) 3491504 połączenie lokalne Portugal 800 780 903 Chamada local România 031-810 71 25

Apel local

0800-89 49 10 Россия Moscow (495) 961-1111

Местный звонок

Outside Moscow 8-800-200-0880 Србија +381 114 440 841 Lokalni poziv

Slovensko 0800 004537 Bezplatný hovor Slovenija 00386 12 80 95 00 lokalni klic España 902 888 784 €0.10 Por minuto Sverige 08 5792 9100 Lokalsamtal Suisse/Schweiz/Svizzera 0844 800 544 Appel local/Ortsgespräch/Chiamata locale Türkiye 0800 261 3302 Şehiriçi arama United Kingdom General No: 0870 900 9070

local General National Rate No: 0870 911 0036

Україна 8-800-500-69-70 Місцевий виклик

This information is correct at the time of press. For updated information, see www.philips.com/support.

Contents

1 Notice 2

2 Important 4

3 TV overview 6

Side controls and indicators 6 Remote control 6

4 Use your product 8

Switch your TV on/off or to standby 8 Switch channels 8 Watch connected devices 9 Adjust TV volume 9 Use teletext 10

5 Use more of your product 11

Access TV menus 11 Remove devices from the home menu 11 Change picture and sound settings 11 Use advanced teletext features 14 Create and use lists of favourite channels

15 Use the Electronic Programme Guide 16 Watch TV in dual view 17 Use timers 17 Use TV lock and parental ratings 18 Use subtitles 19 Use the TV clock 20 View photos and play music from a USB

storage device 21 Use Scenea 22 Listen to digital radio channels 23 Update the TV software 24 Change TV preferences 24 Access decoder channel 25 Start a TV demo 25 Reset the TV to factory settings 25

Rename channels 28 Reorder channels 28 Test digital reception 28

English

7 Connect devices 29

Back connector for 22 inch TV 29 Back connectors for 26 inch TV 31 Side connectors 32 Connect a computer 33 Use a Conditional Access Module 34 Use Philips EasyLink 35 Use a Kensington lock 37

8 Product information 38

Supported display resolutions 38 Multimedia 38 Tuner/Reception/Transmission 38 Remote control 38 Power 38 Supported TV mounts 39

9 Troubleshooting 40

General TV issues 40 TV channel issues 40 Picture issues 40 Sound issues 41 HDMI connection issues 41 Computer connection issues 41 Contact us 41

10 Index 42

6 Install channels 26

Automatically install channels 26 Manually install channels 27

1 Notice

Speciﬁcations are subject to change without

notice. Trademarks are the property of Koninklijke Philips Electronics N.V or their respective owners. Philips reserves the right to change products at any time without being obliged to adjust earlier supplies accordingly. The material in this manual is believed adequate for the intended use of the system. If the product, or its individual modules or procedures, are used for pu those speciﬁed herein, conﬁrmation of their validity and suitability must be obtained. Philips warrants that the material itself does not infringe any United States patents. No fur ther warranty is expressed or implied.

Warranty

Risk of injury, damage to TV or void of • warranty! Never attempt to repair the TV yourself. Use the TV and accessories only as • intended by the manufacturer. The caution sign printed on the back of • the TV indicates risk of electric shock. Never remove the TV cover. Always contact Philips Customer Support for service or repairs.

rposes other than

bright points of light (red, green or blue) may appear constantly on the screen. This is a structural property of the display (within common industry standards) and is not a malfunction.

Compliance with EMF

Koninklijke Philips Electronics N.V. manufactures and sells many products targeted at consumers which, like any electronic apparatus, in general have the ability to emit and receive electromagnetic signals. One of Philips’ leading Business Principles is to take all necessary health and safety measures for our products, to comply with all to stay well within the EMF standards applicable at the time of producing the products. Philips is committed to develop, produce and market products that cause no adverse health effects. Philips conﬁrms that if its products are handled properly for their intended use, they are safe to use according to scientiﬁc evidence available today. Philips plays an active role in the development of international EMF

and safety standards, enabling Philips to anticipate further developments in standardisation for early integration in its products.

applicable legal requirements and

Any operation expressly prohibited in • this manual, or any adjustments and assembly procedures not recommended or authorised in this manual shall void warranty.

Pixel characteristics

This LCD product has a high number of colour pixels. Although it has effective pixels of 99.999% or more, black dots or

the

Mains fuse (UK only)

This TV is ﬁtted with an approved moulded plug. Should it become necessary to replace the mains fuse, this must be replaced with a fuse of the same value as indicated on the plug (example 10A).

1 Remove fuse cover and fuse. 2 The replacement fuse must comply with

BS 1362 and have the ASTA approval mark. If the fuse is lost, contact your dealer in order to verify the correct type.

3 Reﬁt the fuse cover.

In order to maintain conformity to the EMC directive, the mains plug on this product must not be detached from the mains cord cable.

VESA, FDMI and the VESA Mounting Compliant logo are trademarks of the Video Electronics Standards Association. ® Kensington and Micro Saver are registered US trademarks of ACCO World Corporation with issued registrations and pending applications in other countries throughout the world. All other registered and unregistered trademarks are the property of their respective owners.

Eng l i s h

2 Important

Read and understand all instructions before you use your TV. If damage is caused by failure to follow instructions, the warranty does not apply.

Safety

Risk of electric shock or ﬁre!•

Never expose the TV to rain or • water. Never place liquid containers, such as vases, near the TV. If liquids are spilt on or into the TV, disconnect the TV from the power outlet immediately. Contact Philips Consumer Care to have the TV checked before use. Never place the TV, remote control • or batteries near naked ﬂames or other heat sources, including direct sunlight. To prevent the spread of ﬁre, keep candles or other ﬂames away from the TV, remote control and batteries at all times.

Never insert objects into the • ventilation slots or other openings on the TV. When the TV is swivelled ensure • that no strain is exerted on the power cord. Strain on the power cord can loosen connections and cause arcing.

Risk of shor t circuit or ﬁre!•

Never expose the remote control or • batteries to rain, water or excessive heat.

Avoid force coming onto power • plugs. Loose power plugs can cause arcing or ﬁre.

Risk of injury or damage to the TV!•

Two people are required to lift and • carry a TV that weighs more than 25 kg. When stand mounting the TV, use • only the supplied stand. Secure the stand to the TV tightly. Place the TV on a ﬂat, level surface that can support the combined weight of the TV and the stand. When wall mounting the TV, use • only a wall mount that can support the weight of the TV. Secure the wall mount to a wall that can support the combined weight of the TV and wall mount. Koninklijke Philips Electronics N.V. bears no responsibility for improper wall mounting that result in

accident, injury or damage. Risk of injury to children!Follow these • precautions to prevent the TV from toppling over and causing injury to children:

Never place the TV on a surface •

covered by a cloth or other material

that can be pulled away.

Ensure that no par t of the TV hangs •

over the edge of the surface.

Never place the TV on tall furniture •

(such as a bookcase) without

anchoring both the furniture and TV

to the wall or a suitable support.

Educate children about the dangers •

of climbing on furniture to reach the

TV. Risk of overheating! Never install the TV • in a conﬁned space. Always leave a space of at least 4 inches or 10 cm around the TV for ventilation. Ensure curtains or other objects never cover the ventilation slots on the TV. Risk of damage to the TV! Before you • connect the TV to the power outlet, ensure that the power voltage matches

the value printed on the back of the TV. Never connect the TV to the power outlet if the voltage is different. Risk of injury, ﬁre or power cord damage! • Never place the TV or any objects on the power cord. To easily disconnect the TV power cord • from the power outlet, ensure that you have full access to the power cord at all times. When you disconnect the power cord, • always pull the plug, never the cable. Disconnect the TV from the power outlet • and aerial before lightning storms. During lightning storms, never touch any part of the TV, power cord or aerial cable. Risk of hearing damage! Avoid using • earphones or headphones at high volumes or for prolonged periods of time. If the TV is transported in temperatures • below 5°C, unpack the TV and wait until the TV temperature matches room temperature before connecting the TV to the power outlet.

Disposal of your old product and batteries

English

Your product is designed and manufactured with high quality materials and components, which can be recycled and reused.

When this crossed-out wheeled bin symbol is attached to a product it means that the product is covered by the European Directive 2002/96/EC. Please inform yourself about the local separate collection system for electrical and electronic products. Please act according to your local rules and do not dispose of your old products with your normal household waste. Correct disposal of your old product helps to prevent potential negative consequences for the environment and human health.

Screen care

Avoid stationary images as much as • possible. Stationary images are images that remain on-screen for extended periods of time. Examples include: on-screen menus, black bars and time displays. If you must use stationary images, reduce screen contrast and brightness to avoid screen damage. Unplug the TV before cleaning.• Clean the TV and frame with a soft, • damp cloth. Never use substances such asalcohol, chemicals or household cleaners on the TV. Risk of damage to the TV screen! Never • touch, push, rub or strike the screen with any object. To avoid deformations and colour fading, • wipe off water drops as soon as possible.

Your product contains batteries covered by the European Directive 2006/66/EC, which cannot be disposed with normal household waste. Please inform yourself about the local rules on separate collection of batteries because correct disposal helps to prevent negative consequences for the environmental and human health.

3 TV overview

Remote control

This section gives you an overview of commonly used TV controls and functions.

Side controls and indicators

a POWER: Switches the product on

or off. The product is not powered off completely unless it is physically unplugged.

b P/CH +/-: Switches to the next or

previous channel.

28 27 26 25

1 2

3 4

5 6 7

8 9

10 11

12 13 14 15

16 17

c d VOLUME +/-: Increases or decreases

SOURCE: Selects connected devices.

volume.

(Standby-On)

Switches the TV to standby if it is on.• Switches on the TV if it is in standby.•

b MHEG/TELETEXT

Toggles teletext on or off.

SOURCE

Selects connected devices.

d Colour buttons

Selects tasks or options.

e AD (Audio Descriptor) (For RF Digital

TV only)

UK only: Enables audio commentary for the visually handicapped.

(Home)

Toggles the home menu on or off.

o (Stop)

Stops playback.

(Mute)

Mutes or restores audio output.

q P +/- (Programme +/-)

Switches to the next or previous channel. When the TV menu is on, this functions as Page Up/Down.

FORMAT

Selects a picture format.

s 0-9 (Numeric buttons)

Selects a channel or setting.


Launches the picture menu. (Not supported on all models.

English

OPTIONS

Accesses options relating to the current activity or selection.

h OK

Conﬁrms an entry or selection and displays the channel grid, when watching TV.

(Navigation buttons)

Navigates through the menus.

INFO

Displays programme information, when available. If the information spans multiple pages, press OPTIONS to go to the next page .

(Backward)

Searches backward.

(Forward)

Searches forward.

(Play/Pause)

Starts, pauses or resumes playback.

(Record) (only used for Easylink features (see ‘Use Philips EasyLink’ on page 35))

Star ts or stops video recording.

SOUND

Launches the sound menu. (Not supported on all models.)

+/- (Volume +/-)

Increases or decreases volume.

BACKP/P (Previous channel)

Returns to a previous channel or menu screen.

GUIDE

Switches between channel grid and programme list.

y SCENEA (Wallpaper)

Displays wallpaper on your TV screen.

z DEMO

Toggles the demonstration menu on or off.

{ TV

Switches back to the aerial source.

| SUBTITLE (For RF Digital TV only)

Enables or disables subtitles.

4 Use your

product

This section helps you perform basic operations (see ‘Use more of your product’ on page 11).

Switch your TV on/off or to standby

Note

If you cannot locate your remote control and • want to switch on the TV from standby, press

P/CH +/- or SOURCE at the side of the TV.

Switch channels

To switch on

If the standby indicator is off, press • POWER at the side of the TV. If the standby indicator is red, press • (Standby-On) on the remote control.

To switch to standby

Press • control.

To switch off

Press •

Tip

Though your TV consumes very little power • when in standby, energy continues to be consumed. When not in use for an extended period of time, disconnect the TV power cable from the power outlet.

(Standby-On) on the remote

The standby indicator switches to red. »

POWER at the side of the TV.

The standby indicator switches off. »

Press • P +/- on the remote control or P/CH +/- on the side of the TV. Enter a channel number using the • Numeric buttons. Use the channel • grid (see ‘Switch channels with the channel grid’ on page

9).

Note

When you use a favourite list, you can only • select those channels in the list.

Switch channels with the channel grid

The channel grid allows you to view all available channels in a grid format.

3 Press OK to conﬁrm your choice.

The TV switches to the selected » device.

English

Adjust TV volume

1 Press OK.

The channel grid appears. »

2 Press to browse the channel grid

and preview a channel.

The channel content is displayed after » a lapse of approximately two seconds.

3 When you ﬁnd a channel of your choice,

press OK to watch.

The selected channel appears. »

Watch connected devices

Note

Switch on the device before selecting it as a • source on the TV.

To increase or decrease volume

Press • Press • VOLUME +/- on the side of the TV.

To mute or unmute sound

Press • Press •

+/-.

to mute the sound. again to restore the sound.

Use the source button

1 Press SOURCE.

The source list appears. »

2 Press the Navigation buttons to select a

device.

Use teletext

1 Press MHEG/TELETEXT.

The main index page appears. »

2 Select a page as follows:

Press the • Numeric buttons to enter a page number Press • P +/- or or previous page Press the • Colour buttons to select a colour coded item Press • previously viewed page

BACK to return to a

to view the next

3 Press MHEG/TELETEXT to exit teletext.

Note

For UK users only: Some digital TV channels • offer dedicated digital text services (for example, BBC1).

5 Use more of

Remove devices from the home menu

your product

Access TV menus

Menus help you to install channels, change picture and sound settings and access other features.

1 Press (Home).

The menu screen appears. »

Add new device

Watch TV

Setup

If a device is no longer connected to the TV, remove it from the home menu.

1 Press (Home). 2 Press to select a device to remove. 3 Press OPTIONS.

The » [Remove device] list appears.

4 Press OK and select [Remove] to remove

the device.

The selected device is removed from » the home menu.

Change picture and sound settings

Change picture and sound settings to suit your preferences. You can apply pre-deﬁned settings or change settings manually.

English

2 Press to select and navigate

through one of the following menus.

• [Watch TV]Switches back to the

aerial source if another source is selected.

• [Setup]Accesses menus that allow

you to change picture, sound and other TV settings.

• [Add new device]Adds new devices

to the home menu.

3 Press OK to conﬁrm your choice. 4 Press (Home) to exit.

Tip

After selecting • [Add new device], follow the on-screen instructions to select the correct device and connector.

Use settings assistant

Use the settings assistant to guide you through the best picture and sound settings.

1 Press (Home). 2 Press to select [Setup] > [Picture]

> [Settings assistant].

3 Press OK.

The » [Settings assistant] menu appears. Follow the on-screen instructions to choose your preferred picture settings.

Use smart picture

Use smart picture to apply pre-deﬁned picture settings.

1 Press PICTURE.

The » [Smart picture] menu appears.

2 Press to select one of the following

smart picture settings.

• [Personal]Lists customised personal

picture settings.

• [Vivid]Maximises picture settings.

• [Standard]Adjusts picture settings

to suit most environments and types of video.

• [Movie]Applies picture settings

ideally suited for movie viewing.

• [Game]Applies picture settings

maximised for fast-moving games.

• [Energy saving]Applies low-energy

picture settings.

3 Press OK to conﬁrm your choice.

The selected smart picture setting is » applied.

Manually adjust picture settings

1 Press (Home). 2 Press to select [Setup] >

[Picture].


Sound

Features

Installation

Software update

Settings assist.

Smart picture

Contrast

Brightness

Colour

Hue

Sharpness

Noise reduction

Action

Personal

Off

3 Press to select one of the

following picture settings.

• [Smart picture]Accesses pre-deﬁned

smart picture settings.

• [Contrast]Adjusts the intensity of bright

areas, keeping dark areas unchanged.

• [Brightness]Adjusts the intensity and

details of dark areas.

• [Colour]Adjusts colour saturation.

• [Hue]Compensates colour variations in

NTSC encoded transmissions.

• [Sharpness]Adjusts the level of sharpness

in image details.

• [Noise reduction]Filters and reduces

noise in an image.

• [Tint]Adjusts the colour balance in an

image.

• [Custom tint]Make a customised tint setting. (Only available if [Tint] > [Custom] is selected)

• [Pixel Plus HD]Fine-tunes each pixel to match surrounding pixels. This produces a brilliant, high-deﬁnition image.

• [Dynamic contrast]Automatically

enhances contrast in an image. A [Medium] setting is recommended.

• [Dynamic backlight]Adjusts the

brightness of the TV backlight to match lighting conditions.

• [MPEG artifact reduction]Smoothes

out transitions on digital pictures. You can switch this feature on or off.

• [Colour enhancement]Makes

colours more vivid and improves the resolution of details in bright colours. You can switch this feature on or off.

• [PC mode]Adjusts the picture when a PC is connected to the TV via HDMI or DVI.

• [Light sensor]Dynamically adjusts picture settings to match lighting conditions.

• [Picture format]Changes the picture format.

• [Horizontal shift]Adjusts the picture horizontally for PC-VGA, DVI, HDMI or YPbPr.

• [Vertical shift]Adjusts the picture vertically for PC-VGA, DVI, HDMI or YPbPr.

Change picture format

1 Press FORMAT.

A picture format bar appears. »

2 Press or FORMAT to select a

picture format.

The selected picture format is » activated.

3 Press OK to conﬁrm your choice.

Summary of picture formats

The following picture settings can be conﬁgured.

Note

Depending on the format of the picture • source, some picture settings are not available.

[Auto format](Not for PC mode.) Enlarges the picture automatically to best ﬁt the screen. The subtitles remain visible.

[Super zoom](Not for HD and PC mode.) Removes the black bars on the side of 4:3 broadcasts. There is minimal distortion.

[4:3]Shows the classic 4:3 format.

[Subtitle zoom]Displays 4:3 pictures over the full area of the screen, with sub-titles visible. Part of the top of the picture is clipped off.

[Movie expand 14:9](Not for HD and PC mode.) Scales 4:3 format to 14:9.

[Movie expand 16:9](Not for HD and PC mode.) Scales 4:3 format to 16:9.

[Unscaled]For HD and PC mode only, and in selected

Use smart sound

Use smart sound to apply pre-deﬁned sound settings.

models only. Allows maximum sharpness. Some distortion may be present due to the broadcaster’s systems. Set your PC resolution to wide screen mode for best results.

1 Press SOUND.

The » [Smart sound] menu appears.

2 Press to select one of the following

smart sound settings.

• [Standard]Adjusts sound settings to

suit most environments and types of audio.

• [News]Applies sound settings ideally

suited for spoken audio, such as the news.

• [Movie]Applies sound settings ideally

suited for movies.

• [Personal]Applies the settings that

were customised in the sound menu.

3 Press OK to conﬁrm your choice.

The selected smart sound setting is » applied.

English

[Wide screen]Stretches

the classic 4:3 format to 16:9.

Adjust sound settings

1 Press (Home). 2 Press to select [Setup] > [Sound].

The » [Sound] menu appears.


Sound

Features

Installation

Software update

Smart sound

Bass

Treble

Volume

Vol.vis impaired

Balance

Audio language

Dual I-II

Standard

English

Dual I

When enabled, this produces a more consistent audio volume.

• [Delta volume]Levels out volume

differences between channels or connected devices. Switch to the connected device before you change

the delta volume.

Tip

For • [Vol.vis impaired] audio, toggle AD or press both. Select [Off] to disable Audio Descriptor. (Applies to UK only)

to select speaker, headphone or

3 Press to select one of the

following sound settings.

• [Smart sound]Accesses pre-deﬁned

smart sound settings.

• [Bass]Adjusts the bass level.

• [Treble]Adjusts the treble level.

• [Volume]Adjusts the volume.

• [Vol.vis impaired]Sets the mix of

visually impaired audio with regular audio. When available, visually impaired audio includes audio descriptions of on-screen action. You can also enable this by pressing AD (Audio Descriptor).

• [Balance]Adjusts the balance of the

right and left speakers to best suit your listening position.

• [Audio language]Available for digital

channels, when multiple languages are broadcast. Lists available audio languages.

• [Dual I-II]Selects between audio

languages if dual sound is broadcast.

• [Mono/Stereo]Selects between

mono or stereo if stereo is broadcast.

• [TV speakers]Turns TV speakers on

or off.

• [Surround]Enables spatial sound.

• [Headphone volume]Adjusts

headphone volume.

• [Auto volume]Automatically

reduces sudden volume changes, for example, when switching channels.

Use advanced teletext features

Access the teletext options menu

Most of the advanced teletext features are accessed via the teletext options menu.

1 Press MHEG/TELETEXT.

The teletext screen appears. »

2 Press OPTIONS.

The teletext options menu appears. »

3 Press to select one of the following

options.

• [Freeze page]Freezes the current

page.

• [Dual/Full screen]Enables and

disables dual screen teletext, which splits the current channel or source to the left of the screen, with teletext on the right.

• [Reveal]Hides or reveals hidden

information on a page, such as solutions to riddles or puzzles.

• [Cycle subpage]Cycles through

subpages automatically if subpages are available.

• [Language]Switches to a different

language group to display a language correctly when that language uses a different character set.

4 Press OK to conﬁrm your choice. 5 Press MHEG/TELETEXT to exit the

teletext options menu.

Select teletext subpages

Tip

A teletext page can hold several subpages. Subpages are displayed on a bar next to the main page number.

1 Press MHEG/TELETEXT .

The teletext screen appears. »

2 Press to select a teletext page. 3 Press to enter a subpage.

Select T.O.P. teletext broadcasts

Table Of Pages (T.O.P.) teletext broadcasts allow you to jump from one subject to another without using page numbers. T.O.P. teletext is not broadcast on all TV channels.

1 Press MHEG/TELETEXT.

The teletext screen appears. »

2 Press INFO.

The T.O.P. overview appears. »

3 Press to select a subject. 4 Press OK to view the page.

You can create and store up to four favourite • lists on your TV.

Select a favourite list

1 When watching TV, press OK to display

the channel grid.

2 Press OPTIONS.

The channel options menu appears. »

3 Press to select [Show fav. ch.] and

press OK.

The favourite lists appear. »

4 Press to select a favourite list and

press OK.

Only channels in the favourite list » appear in the channel grid.

Note

The favourite channel grid is empty until you • add channels into the favourite lists.

English

Use Teletext 2.5

Teletext 2.5 offers more colours and better graphics than normal teletext. If Teletext 2.5 is broadcast by a channel, it is switched on by default.

1 Press (Home). 2 Press to select [Setup] >

[Installation] >[Preferences] > [Teletext

2.5].

3 Press to select [On] or [Off]. 4 Press OK to conﬁrm your choice.

Create and use lists of favourite channels

You can create lists of your preferred TV channels and radio stations so that you can ﬁnd

those channels easily.

View all channels

You can exit a favourite list, and view all installed channels.

1 When watching TV, press OK to display

the channel grid.

2 Press OPTIONS.

The channel options menu appears. »

3 Press to select [Show fav. ch.] > [All]. 4 Press OK.

All channels are displayed in the » channel grid.

Note

All favourite channels are marked by an • asterisk in the channel grid.

Add a channel to a favourite list

Tip

View all channels before adding a channel to a • favourite list.

7 Press to select [Unmark as fav.] and

press OK.

The channel is removed from the » favourite list.

1 When watching TV, press OK to display

the channel grid.

2 Press to select a channel you want

to add to a favourite list.

3 Press OPTIONS.

The channel options menu appears. »

4 Press to select [Mark as favourite]

and press OK.

The favourite lists appear. »

5 Press to select a favourite list to add

the channel to.

6 Press OK.

The channel is added to the favourite » list.

Tip

When watching TV, save the current channel • in a favourite list by pressing OPTIONS >

[Mark as favourite].

Use the Electronic Programme Guide

EPG is an on-screen guide available for digital channels. EPG allows you to:

View a list of digital programmes being • broadcast View upcoming programmes• Group programmes by genre• Set reminders when programmes star t• Set up preferred EPG channels•

Switch on EPG

1 When watching TV, press GUIDE.

The EPG planner screen appears » displaying information about the scheduled programmes.

Note

Remove a channel from a favourite list

1 When watching TV, press OK to display

the channel grid.

2 Press OPTIONS.

The channel options menu appears. »

3 Press to select [Show fav. ch.] and

press OK.

4 Press to select a favourite list and

press OK to edit.

The favourite channel grid appears. »

5 Press to select a channel that you

wish to remove from the list.

6 Press OPTIONS.

EPG data is available only in selected countries • and can take some time to load.

Tip

Press • GUIDE to switch between EPG and channel grid.

Use EPG

1 When watching TV, press GUIDE.

The EPG planner screen appears. »

2 Press (Home).

The programme guide menu appears. »

3 Press to select an option, and then

press OK to conﬁrm it.

4 Press (Home) to exit the EPG menu.

Note

Only the channels marked with [x] in the • [Pref.

EPG channel] list, appear in the EPG menu.

Use the EPG options menu

The main screen displays the input » source from DVI or VGA.

The auxiliary screen displays the last » viewed channel.

5 Press OK or OPTIONS > [Dual View

OFF] to exit dual view.

English

Use the EPG options menu to set or clear reminders, change day and access other useful EPG options.

1 Press GUIDE. 2 Press OPTIONS.

The EPG menu appears. »

3 Press to select one of the following

options.

• [Set remind]/ [Clear remind]

• [Change day]

• [Show info]

• [Search by genre]

• [Schedule reminders]

• [Pref. EPG channel]

4 Press OK to enter or activate the option. 5 Press BACK to exit the EPG menu.

Tip

Press • GUIDE to switch between EPG and channel grid.

Note

[Dual View] is available only when the TV is

•

connected to a device, such as a PC, via VGA or DVI connection. When in Dual view mode, press

• +/- to

adjust volume in the main screen and press P +/- or Numeric buttons to switch between the TV channels in the auxiliary screen.

Use timers

You can set timers to switch the TV on or switch to standby at a speciﬁed time.

Automatically switch the TV to standby (sleeptimer)

Sleeptimer switches the TV to standby after a pre-deﬁned period of time.

Tip

Watch TV in dual view

You can use the Dual View feature to display the TV channels and the input from a device with VGA or DVI connector (such as a computer or a satellite box) simultaneously on your TV.

1 Select VGA or DVI as the source for your

TV input.

2 Press OPTIONS. 3 Press to select [Dual View ON]. 4 Press OK to activate dual view.

You can always switch off your TV earlier or • reset the sleeptimer during the countdown.

1 Press (Home). 2 Press to select [Setup] >

[Features] > [Sleep timer].

The bar appears. »

3 Press to set the sleep time.

The sleeptimer can be up to 180 » minutes in steps of ﬁve minutes. If set to zero minutes, the sleeptimer is switched off.

4 Press OK to activate the sleeptimer.

The TV switches to standby after the » pre-deﬁned period of time.

Automatically switch the TV on (on timer)

You can switch the TV to a speciﬁed channel at a speciﬁed time, from standby or power-on mode.

1 Press (Home). 2 Press to select [Setup] >

[Features] > [On timer].

3 Press OK or to enter the [On timer]

menu.

• [Activate] Selects the frequency to [Off] or [Once] or [Daily].

• [Time] Sets the starting time to switch on the TV automatically.

• [Programme no.] Selects the channel.

4 Press (Home) to exit.

code is not set, you are prompted to re-enter the code.

Change code

1 Press (Home). 2 Press to select [Setup] >

[Features] > [Change code].

You are prompted to enter your » current code.

3 Enter your current code using the

Numeric buttons.

If the code is validated, you are » prompted to enter your new code.

4 Enter the new code using the Numeric

buttons.

You are prompted to enter the new » code again for conﬁrmation.

Tip

Select • [On timer] > [Activate] > [Off] to disable [On timer].

Use TV lock and parental ratings

You can prevent your children from watching certain programmes or certain channels by locking the TV controls and by using ratings.

Set code

1 Press (Home). 2 Press to select [Setup] >

[Features] > [Set code].

3 Press OK or to enter [Set code]. 4 Enter your code using the Numeric

buttons.

Tip

If you forget your code, enter ‘8888’ to • override any existing codes.

Lock or unlock the TV

Locking the TV prevents your child from accessing all channels and connected devices.

1 Press (Home). 2 Press to select [Setup] >

[Features] > [TV lock].

You are prompted for a code. »

3 Enter your code using Numeric buttons.

The » [TV lock] menu appears.

4 Press to select [Lock] or [Unlock]. 5 Press OK to conﬁrm.

All channels and connected devices are » locked or unlocked.

5 Re-enter the same code in the new

dialogue box for conﬁrmation.

The dialogue box disappears if the » code is set successfully. However, if the

Note

If you select • [Lock], you must enter your code every time you turn on your TV to access all channels and connected devices.

Lock one or more channels

Set parental ratings

1 When watching TV, press OK to display

the channel grid.

2 Press to select a channel to lock. 3 Press OPTIONS.

The channel options menu appears. »

4 Press to select [Lock channel] and

press OK to enter.

You are prompted to enter your » current code (only at ﬁrst selection).

5 Enter your code and press OK. 6 Repeat the steps to lock more channels.

Note

Restart the TV for the change to take effect. •

Some digital broadcasters rate their programmes according to age. You can set your TV to display only programmes with age ratings higher than your child’s age.

1 Press (Home). 2 Press to select [Setup] >

[Features] > [Parental rating].

A code setup screen appears. »

3 Enter your code using Numeric buttons.

The parental rating menu appears. »

4 Press to select an age rating. 5 Press OK to conﬁrm. 6 Press (Home) to exit.

Use subtitles

English

Unlock one or more channels

1 When watching TV, press OK to display

the channel grid.

2 Press to select a locked channel to

unlock.

3 Press OPTIONS.

The channel options menu appears. »

4 Press to select [Unlock channel] and

press OK.

You are prompted for your current » code (only at ﬁrst selection).

5 Enter your code and press OK. 6 Repeat the process to unlock more

channels.

Note

Restart the TV for the change to take effect. • If you press • P +/- on your remote control to switch between channels, the locked channels are skipped. If you access the locked channels from the

•

channel grid, you are prompted for your current code.

You can enable subtitles for each TV channel. Subtitles are broadcast via teletext or DVBT digital broadcasts. With digital broadcasts, you have the additional option of selecting a preferred subtitle language.

Enable subtitles on analogue TV channels

1 Select an analogue TV channel. 2 Press MHEG/TELETEXT. 3 Enter the three-digit page number of the

subtitle page with the Numeric buttons.

4 Press MHEG/TELETEXT to switch off

teletext.

5 Press SUBTITLE.

The » [Subtitle mode] menu appears.

6 Select [On] to display subtitles always or

[On during mute] to display subtitles only

when audio is muted.

7 Press OK to enable subtitles. 8 Repeat this procedure to enable subtitles

on each analogue channel.

Tip

Use the TV clock

Select • [Subtitle mode] > [Off] to disable subtitles.

Enable subtitles on digital TV channels

1 When watching digital channels, press

SUBTITLE.

The » [Subtitle mode] menu appears.

2 Select [On] to display subtitles always or

[On during mute] to display subtitles only

when audio is muted.

3 Press OK to enable subtitles.

Select a subtitle language on digital TV channels

Note

When you select a subtitle language on • a digital TV channel as described below, the preferred subtitle language set in the installation menu is temporarily overruled.

1 Press (Home). 2 Press to select [Setup] >

[Features] > [Subtitle language].

3 Press OK or to enter the list of

available languages.

You can display a clock on the TV screen. The clock displays the current time using time data received from your TV service operator.

Display the TV clock

1 When watching TV, press OPTIONS.

The TV option menu appears. »

2 Select [Clock]. 3 Press OK.

Note

To disable the clock, repeat the above • procedure.

Change the clock mode

1 Press (Home). 2 Press to select [Setup] >

[Installation] > [Clock] > [Auto clock].

3 Press OK or to enter the [Auto clock]

menu.

4 Press to select [Automatic] or

[Manual].

5 Press OK to conﬁrm.

4 Press to select a subtitle language. 5 Press OK to enable your selection.

Tip

You can also access • [Subtitle language] menu while watching TV by pressing

[Subtitle language].

OPTIONS >

Change the time zone

1 Press (Home). 2 Press to select [Setup] >

[Installation] > [Clock] > [Time zone].

3 Press to select your time zone. 4 Press OK to conﬁrm.

Note

This option is available only if you select • [Auto clock] > [Manual] (In countries with clock transmission data).

Use daylight saving

1 Press (Home) .

4 Press OK to conﬁrm.

The USB thumbnail browser appears. »

2 Press to select [Setup] >

[Installation] > [Clock] > [Daylight saving].

3 Press OK or to enter [Daylight saving]. 4 Press to select [Standard time] or

[Daylight saving time].

5 Press OK to enable your selection.

Note

This option is available only if you select • [Auto

clock] > [Manual].

View photos and play music from a USB storage device

Tip

Press • GUIDE to switch between thumbnail and ﬁle browsing views.

View photos

1 In the USB thumbnail browser, select

[Picture] and press

to enter.

2 Press GUIDE to switch between

thumbnail and ﬁle browsing views.

3 Press to select a photo or a photo

album.

4 Press OK to view the selected photo in

full screen mode.

Tip

English

Caution

Philips is not responsible if the USB storage • device is not supported nor is it responsible for damage or loss of data from the device.

Your TV is ﬁtted with a USB connector that enables you to view photos or listen to music stored on a USB storage device.

1 Turn on the TV. 2 Connect the USB device to the USB por t

on the side of your TV.

The home menu appears. »

Add new device

Watch TV

Setup

Browse USB

When in full screen mode, press • to move between photos.

View a slide show of your photos

1 When a full screen image of a photo is

displayed, press OK or

A slide show begins from the selected » image.

2 Press:

• OK or

The »

Press • images. Press • slide show.

Change slide show settings

to pause the slide show.

icon appears.

or to move between

BACK or to stop the

3 Press to select [Browse USB].

1 When viewing a slide show, press

OPTIONS.

The slide show options menu appears. »

2 Press to select one of the following.

• [Start/Stop slide.]Starts or stops a slide show.

• [Slideshow trans.]Sets the transition from one picture to the next.

• [Slideshow freq.]Sets the amount of time that a picture is shown.

• [Rotate image]Rotates a picture.

• [Show info]Displays the picture name, date, size and next picture in the slide show.

3 Press OK to conﬁrm your setting.

1 Press BACK to exit the USB browser. 2 Wait for ﬁve seconds before you

disconnect the USB storage device.

Use Scenea

Scenea transforms your TV into a personalised photo frame. With Scenea enabled, you can display a single picture or a slideshow of pictures on your TV — perfect for parties or other social gatherings.

Note

• [Rotate image] and [Show info] appear only

when you press OK or slideshow.

to pause the

Listen to music

1 In the USB thumbnail browser view,

select [Music] and press

to enter.

2 Press GUIDE to switch between

thumbnail and ﬁle browsing views.

3 Press to select music or a music

album.

4 Press OK to play the selected music.

Music settings

When listening to music, press OPTIONS to access one of the following music settings.

• [Start/Stop play]

• [Repeat/Play once]

• [Shufﬂe on/off]

• [Show info]

• [TV speakers]

Disconnect a USB storage device

Note

Use Eco mode to save energy when the • Scenea wallpaper or a slideshow is displayed on your TV (see ‘Use Eco mode with Scenea wallpaper’ on page 23). Scenea wallpaper is not available in shop

• mode

(see ‘Change TV preferences’ on page 24) or MHEG mode (UK only).

Display a single picture with Scenea

1 While watching TV, press SCENEA.

The default Scenea picture is displayed » on your TV.

2 Press any key except (Standby-On)

PICTURE to return to normal TV

viewing.

Personalize the Scenea picture

1 While the TV is on, connect the USB

storage device containing your pictures (JPEG format only) to the USB connector at the side of your TV.

The home menu appears. If the home » menu does not appear, press (Home).

Caution

Follow this procedure to avoid damage to your • USB storage device.

2 Select [Browse USB], then press OK.

The USB content browser appears. »

3 Press to navigate to the picture of

your choice.

4 Press SCENEA.

Your picture is stored as the default » Scenea picture in your TV.

5 Disconnect the USB storage device. The

device can be disconnected safely while the TV is on.

6 Follow the instructions to display your

personalised Scenea picture (see ‘Display a single picture with Scenea’ on page 22).

Note

If the TV is reset to factory settings, your • personalised Scenea picture is removed from the TV. Repeat these instructions to personalise the Scenea picture again.

Use Eco mode with Scenea wallpaper

Using Eco mode with Scenea saves energy by lowering the TV brightness when a Scenea picture or a slideshow is displayed.

1 While a Scenea picture or slideshow is

displayed, press

The » [Eco mode] menu appears.

PICTURE.

2 Press to select [On]. 3 Press OK.

Eco mode with Scenea is enabled. »

Listen to digital radio channels

English

Display a slideshow of pictures with Scenea

1 While the TV is on, connect the USB

storage device containing your pictures (JPEG format only) to the USB connector at the side of your TV.

The home menu appears. »

2 Press SCENEA.

All pictures in your USB storage device » are displayed in a slideshow, star ting from the default Scenea picture stored in your TV.

3 Press any key except (Standby-On)

PICTURE to return to normal TV

viewing.

If digital broadcasting is available, digital radio channels are installed automatically during installation.

1 When watching TV, press OK to display

the channel grid.

2 Press OPTIONS. 3 Press to select [Filter channels] >

[Radio].

The radio channel grid appears. »

4 Press to select a radio channel and

press OK to listen.

Note

Select • [Filter channels] > [All] to exit radio channels and view all channels.

Use sleeptimer with Scenea wallpaper

By default, your TV displays the Scenea picture or slideshow for 120 minutes before entering standby mode. If sleeptimer is enabled, the Scenea picture or slideshow is displayed for the duration of the sleeptimer (see ‘Use timers’ on page 17).

Update the TV software

Philips continuously tries to improve its products and we recommend that you update the TV software when updates are available. Check www.philips.com/support for availability.

Check the current software version

1 Press (Home).

Select • [Update now] to update the software immediately. Select • [Remind me later] to exit the update screen at that time and be reminded later. Select • [Cancel] to skip the update.

2 If you select [Cancel], you can manually

access the OAD update by selecting

[Setup] > [Software update] > [Local updates] > [OAD].

2 Press to select [Setup] >

[Software update] > [Current software].

The TV displays the current software » information.

Update software (digital broadcasts)

You can update the TV software via a USB device or OAD.

Update using a USB device

Connect your USB device to the USB port at the side of your TV.

1 If the software update screen does not

appear automatically, select [Setup] > [Software update] > [Local updates]

> [USB] to update the TV software manually.

2 Follow the on-screen instructions to

complete the update.

Note

The TV restar ts after the software update is • complete.

Update using OAD (On the Air software Download)

1 If using (DVB-T) digital broadcast, your

TV automatically receives software updates. If you receive a message on your screen asking you to update your software:

3 Select the available version of OAD and

press OK.

4 Follow the on-screen instructions to start

the update.

Note

The TV restar ts after the software update is • complete.

Change TV preferences

Press (Home).

2 Press to select [Setup] >

[Installation] > [Preferences].

3 Press OK or to enter [Preferences].

• [Location]Optimises TV settings for

your location - home or shop.

• [Volume bar]Displays the volume

bar when adjusting the volume.

• [Channel info.]Displays information

about the TV channel every time you switch channels. Select [Full] to view channel information or [Off] to turn off the channel information.

• [EasyLink]Enables one-touch play

and one-touch standby between EasyLink-compliant devices.

• [Pixel Plus Link]Overrides the

settings of connected devices and uses the settings of the TV. (Available only when [EasyLink] > [On] is selected).

• [Teletext 2.5]Enables or disables Teletex t 2.5 .

• [E-sticker]For shop mode only. Sets the location of the e-sticker.

Start a TV demo

Press DEMO on the remote control.

2 Press to select a demo and press OK

to view it.

English

Access decoder channel

You can map channels provided through a decoder or descrambler to your TV channel selection. In this way, you can select these channels by using the RC of your TV. The decoder or a descrambler must be connected to EXT1 (SCART).

Set decoder channel

Map channels from a decoder or descrambler

1 Press (Home). 2 Press to select [Setup] >

[Installation] > [Decoder].

3 Press OK or to enter [Decoder] menu

4 Press to select [Channel] and press

OK or

to enter.

A list of analogue channels appears on » the screen.

3 Press DEMO to exit.

Reset the TV to factory settings

You can restore the default picture and sound settings of your TV. Channel installation settings remain the same.

1 Press (Home). 2 Press to select [Setup] >

[Installation] > [Factory settings].

3 Press OK or to enter the [Factory

settings] menu.

A factory setting message appears. »

4 Select [Reset] to start resetting. 5 Press (Home) to exit.

5 Press to select one channel to map

to the decoder/descrambler channel and press OK to conﬁrm.

6 Select [Status] and press OK or to

enter.

7 Press to select [EXT 1] (SCART)

the connector used by the decoder/ descrambler.

8 Press OK. 9 Press (Home) to exit.

6 Install channels

The ﬁrst time you set up your TV, you are prompted to select a menu language and to install TV and digital radio channels (if available). This chapter provides instructions on how to re-install and ﬁne tune channels.

Automatically install channels


Sound

Features

Installation

Software update

Language

Channel install.

Preferences

Decoder

Clock

Factory settings

Menu language

Channel assistant

Location

Channel

Auto clock

Action

3 Press OK or to enter the menu.

The country menu appears. »

This section describes how to search and store channels automatically.

Step 1 Select your menu language

1 Press (Home). 2 Press to select [Setup] >

[Installation] > [Language] > [Menu language].

3 Press OK or to enter [Menu language].


Sound

Menu language

Features

Installation

Software update

Language

Channel install.

Preferences

Decoder

Menu language

Clock

Factory settings

Menu language

Primary subtitle in

English

ock

4 Press to select a language setting. 5 Press OK to conﬁrm. 6 Press to return to [Installation] menu.

Select your country, then press OK

Slovakia

Slovenia

Spain

Sweden

Switzerland

Turkey

Ukraine

4 Press to select your country. 5 Press OK to conﬁrm your choice.

The channel installation guide appears » on the screen.

Step 3 Install channels

Install the available analogue and digital TV channels and digital radio channels automatically.

1 From the channel installation guide

screen (see ‘Step 2 Select your country’ on page 26), select [Full installation] to automatically install all TV channels and digital radio channels.

Step 2 Select your country

Select your country for proper channel installation.

1 Press (Home). 2 Press to select [Setup] >

[Installation] > [Channel install.] > [Channel assistant].

Start automatic installation. This takes a few minutes.

Full installation

Skip installation

2 Press OK to conﬁrm.

The TV starts to search and store all » the available channels.

System searching. Please wait.

Stop

Digital channels found Analogue channels found

7 0

3 When installation is complete, press OK

to return to [Installation] menu.

Step 4 Update the channel list


Sound

Analogue: Manual

Features

Installation

Software update

Language

Channel install.

Preferences Start up message

Preferences

Decoder

Clock

Factory settings

Channel assistant

Standby update

System

Digital Test recept...

Analogue: Manual

English

You can choose to enable auto update of channels, if your TV is in standby mode. If you enable this feature, the channels stored in your TV are updated every morning according to the information in the broadcast.

1 Press (Home). 2 Press to select [Setup] >

[Installation] > [Channel install.] > [Standby update].

3 Select [On] to enable the automatic

update or select [Off] to disable it.

Manually install channels

This section describes how to search and store analogue TV channels manually.

3 Press OK or to enter [System] menu. 4 Press to select your country or

region.

5 Press OK to conﬁrm. 6 Press to return to [Channel install.]

menu.

Step 2 Search and store new TV channels

1 Press (Home). 2 Press to select [Setup] >

[Installation] > [Channel install.] > [Analogue: Manual].

The » [Analogue: Manual] menu appears.

3 Press to select [Search] and then OK

to enter [Search].

Step 1 Select your system

Note

Skip this step if your system settings are • correct.

1 Press (Home). 2 Press to select [Setup] >

[Installation] > [Channel install.] > [Analogue: Manual].

The » [Analogue: Manual] menu appears.

4 Press to manually enter the three-

digit frequency.

5 Press OK to begin search.

If a channel is unavailable at the » selected frequency, press OK to search for the next available channel.

6 Press BACK when the new channel is

found.

7 Press to select [Store new channel]

to store the new channel under a new channel number.

8 Press OK or to enter [Store new

channel] and press OK.

9 Press to return to the [Analogue:

Manual] menu.

Step 3 Fine-tune analogue channels

Reorder channels

1 Press (Home). 2 Press to select [Setup] >

[Installation] > [Channel install.] > [Analogue: Manual].

The » [Analogue: Manual] menu appears.

3 Press to select [Fine-tune] and then

OK or

to enter [Fine-tune].

4 Press to adjust frequency. 5 Press OK when done. 6 Press to select [Store current

channel] to store the ﬁne-tuned channel

under the current channel number.

7 Press OK or to enter [Store current

channel] and press OK.

8 Press to return to the [Analogue:

Manual] menu.

After you install channels, you can rearrange the order in which they appear.

1 When watching TV, press OK to display

the channel grid .

2 Press OPTIONS.

The channel options menu appears. »

3 Press to select [Reorder] and then

OK to return to the channel grid.

4 Press to select the channel you

want to reorder and press OK.

The selected channel is highlighted. »

5 Press to move the highlighted

channel to your preferred position.

6 Press OPTIONS.

» [Done reordering] appears on the

screen.

7 Press OK to ﬁnish reordering.

Rename channels

Channels can be renamed so that a name of your choice appears whenever the channel is selected.

1 When watching TV, press OK to display

the channel grid .

2 Press to select the channel you

want to rename.

3 Press OPTIONS.

The channel options menu appears. »

4 Press to select [Rename channel].

A text input box appears. »

5 Press to select and change

characters.

6 Select [Done] to ﬁnish renaming

channels.

Tip

Press • [Aa] to change uppercase to lowercase and vice versa.

Test digital reception

If using digital broadcasts, you can check the quality and signal strength of digital channels. This allows you to reposition and test your antenna or satellite dish.

1 Press (Home). 2 Press to select [Setup] >

[Installation] > [Channel install.] > [Digital: test recept].

3 Press OK or to enter the menu. 4 Press to enter the frequency of

the channel you want to test.

5 Press OK to conﬁrm the frequency and

then press OK again to conﬁrm [Search].

6 When complete, select [Store] to store

the frequency.

Note

If the signal quality and strength is poor, • reposition the aerial or satellite dish and retest. If you still have problems with the reception

•

of your digital broadcast, contact a specialised installer.

7 Connect devices

a PC IN (VGA and AUDIO IN)

Audio and video input from a computer.

This section describes how to connect various devices with different connectors and supplements examples provided in the Quick Start.

Note

Different types of connectors may be used to • connect a device to your TV, depending on availability and your needs.

Back connector for 22 inch TV

PC IN(AUDIO)

VGA

b EXT 2 (Y Pb Pr and AUDIO L/R)

Analogue audio and video input from analogue or digital devices such as DVD players or game consoles.

English

VGA

c EXT 1 (CVBS and RGB)

Analogue audio and video input from analogue or digital devices such as DVD players or game consoles.

AUDIO

f SPDIF OUT

Digital audio output to home theatres and other digital audio systems.

SPDIF OUT

d TV ANTENNA

Signal input from an antenna, cable or satellite.

TV ANTENNA

e AV OUT (VIDEO OUT and AUDIO

OUT L/R)

Audio and video output to analogue devices such as another TV or a recording device.

g HDMI 1

Digital audio and video input from highdeﬁnition digital devices such as Blu-ray players.

Connections via DVI or VGA require an additional audio cable (see ‘Connect a computer’ on page 33).

h SERV. U

For software update.

Back connectors for 26 inch TV

AUDIO IN : LEFT/ RIGHT HDMI 1/ DVI HDMI 2/ DVI

VGA

b PC IN (AUDIO IN and VGA)

Audio and video input from a computer.

For TV of size 22 inch and smaller

PC IN(AUDIO)

For TV of size 26 inch and larger

AUDIO IN : LEFT / RIGHT

HDMI 1/ DVI HDMI 2/ DVI VGA

English

DVI

SERV.U

a HDMI 1/2

Digital audio and video input from highdeﬁnition digital devices such as Blu-ray players.

/ HDMI 2

c EXT 3 (Y Pb Pr and AUDIO L/R)

Analogue audio and video input from analogue or digital devices such as DVD players or game consoles.

Connections via DVI or VGA require an additional audio cable (see ‘Connect a computer’ on page 33).

d EXT 1 (RGB and CVBS)/EXT 2 (CVBS)

Analogue audio and video input from analogue or digital devices such as DVD players or game consoles. EXT 2 supports S-Video.

EXT1/ EXT2

(RGB/CVBS)/ (CVBS)

g SERV. U

For software update.

Side connectors

3 4

e TV ANTENNA

Signal input from an antenna, cable or satellite.

TV ANTENNA

f SPDIF OUT

Digital audio output to home theatres and other digital audio systems.

a COMMON INTERFACE

Slot for a Conditional Access Module (CAM).

b AUDIO L/R

Audio input from analogue devices connected to VIDEO.

SPDIF OUT

c VIDEO

Composite video input from analogue devices such as VCRs.

g HDMI

Digital audio and video input from highdeﬁnition digital devices such as Blu-ray players.

English

d S-VIDEO

S-Video (side) to be used with Audio L/R connectors for camcorder, game console, etc. When you use the S-Video (side) for video signals, do not use the Composite video (side) input for video signals.

e USB

Data input from USB storage devices.

Connect a computer

Before you connect a computer to the TV

Set the screen refresh rate on your • computer to 60Hz. Select a supported screen resolution on • your computer.

Connect a computer with one of the following connectors:

Note

Connections via DVI or VGA require an • additional audio cable.

• HDMI cable

f (Headphone)

Stereo audio output to headphones or earphones.

• DVI-HDMI cable

For TV of size 22 inch and smaller

PC IN(AUDIO)

For TV of size 26 inch and larger

AUDIO IN :

LEFT / RIGHT

HDMI 1/ DVI HDMI 2/ DVI VGA

Use a Conditional Access Module

A Conditional Access Module (CAM) is provided by digital TV service operators to decode digital TV channels.

Note

/ HDMI 2

• HDMI cable and HDMI-DVI adaptor

For TV of size 22 inch and smaller

PC IN(AUDIO)

For TV of size 26 inch and larger

AUDIO IN : LEFT / RIGHT HDMI 1/ DVI HDMI 2/ DVI VGA

/ HDMI 2

DVI

If required, refer to documentation from your • operator on how to insert a smart card into the Conditional Access Module.

Insert and activate a CAM

Caution

Be sure to follow the instructions described • below. Wrong inser tion of a CAM may damage both the CAM and your TV.

1 Switch off the TV. 2 Following the directions printed on the

CAM, gently inser t the CAM into the COMMON INTERFACE at the side of the TV.

• VGA cable

For TV of size 22 inch and smaller

PC IN(AUDIO)

For TV of size 26 inch and larger

AUDIO IN : LEFT / RIGHT HDMI 1/ DVI HDMI 2/ DVI VGA

VGA

3 Push the CAM in as far as it will go. 4 Turn on the TV and wait for the CAM

to be activated. This may take several minutes. Do not remove the CAM from the slot when in use — removing the CAM will deactivate digital services.

Access CAM services

1 After inserting and activating the CAM,

press

(Home).

2 Press to select [Setup] >

[Features] > [Common interface].

Applications provided by the digital TV » service operator appear on the screen.

Note

This menu option is available only if the CAM • is inserted and activated correctly.

Use Philips EasyLink

Your TV supports Philips EasyLink, which uses the HDMI CEC (Consumer Electronics Control) protocol. EasyLink-compliant devices that are connected through HDMI connectors can be controlled by a single remote control.

Home theatre system or an AV receiver), your TV can switch automatically to play audio from the connected ampliﬁer. To use one-touch audio, you must map the audio input from the connected ampliﬁer to your TV. You can use the remote control of the connected ampliﬁer or your TV to adjust the volume.

• Remote control pass-through (RC key forwarding):RC key forwarding allows you to control EasyLink-compliant devices using your TV remote control.

• Pixel Plus Link:Overrides the settings of connected devices and uses the settings of the TV.

Enable or disable EasyLink

Note

English

Note

The EasyLink-compliant device must be • switched on and selected as the source. Philips does not guarantee 100%

•

interoperability with all HDMI CEC devices.

EasyLink features

Your TV supports the following Easylink features :

• One-touch play:When you connect

your TV to devices that suppor t onetouch play, you can control your TV and the devices with one remote control. For example, when you press ‘Play’ on your DVD remote control, your TV automatically switches to the correct channel to show the DVD content.

• One-touch standby: When you connect

your TV to devices that suppor t standby, you can use your TV remote control to put your TV and all connected HDMI devices in standby mode.

• System audio control (One-touch audio):

When you connect your TV to HDMI CEC compliant ampliﬁer (such as, a

Do not enable Philips EasyLink if you do not • intend to use it.

1 Press (Home). 2 Press to select [Setup] >

[Installation] > [Preferences] > [EasyLink].

3 Select [On] or [Off].

Use one-touch play

1 After enabling EasyLink, press play on

your device.

The TV automatically switches to the » correct source.

Use one-touch standby

1 Press and hold Standby on the TV’s or

device’s remote control for at least three seconds.

The TV and all connected HDMI » devices switch to standby.

System audio control

When enabled, this feature automatically turns off TV speakers when content from an EasyLink-compliant home theatre system is played. Audio is played only from the ampliﬁer’s speakers such as home theatre system’s speakers or AV receiver.

An ampliﬁer with only one HDMI output. • Audio can be played by the ampliﬁer from the device or TV.

HDMI Device

HDMI

Note

Follow the instructions in the user manual • of the connected devices to map the audio input to your TV correctly (see ‘Connect an ampliﬁer’ on page 36).

1 Enable one-touch play and one-touch

standby between your Easylink compliant devices by following the instructions in the previous section (see ‘Enable or disable EasyLink’ on page 35).

2 Press (Home). 3 Press to select [Setup] > [Sound]

> [TV speakers] > [Auto EasyLink].

The TV speakers are turned off » automatically when content from an Easylink compliant system is detected.

4 Press to select [Setup] > [Sound]

> [TV speakers] > [On] to disable system audio control and enable the TV speakers.

Amplifier

Ampliﬁer with one HDMI input and • several HDMI outputs. Audio can be played by the ampliﬁer via HDMI connector from your device.

HDMI Device

HDMI

Note

If you select • [TV speakers] > [Off], the TV speakers and ampliﬁer’s speakers are muted.

Connect an ampliﬁer

An ampliﬁer such as Home theatre System or AV receiver can be used to play audio from an Easylink compliant device connected to your TV. An ampliﬁer can be connected in the following different ways :

Note

You must map the audio input from the • connected device to your TV in order to use this feature.

Amplifier

Enable or disable remote control pass-through

1 Enable one-touch play and one-touch

standby between easylink compliant devices by following the instructions in the previous section (see ‘Enable or disable EasyLink’ on page 35).

2 Press (Home). 3 Press to select a device with

HDMI connector from your home menu.

4 Press OPTIONS. 5 Press to select [Enable RC pass-

through] and press OK.

RC pass-through is enabled on the » selected device with HDMI connector.

6 Repeat the steps 1 to 5 to disable remote

control pass-through.

• [TV speakers]Turns TV speakers

on or off. Setting TV speakers to automatic mode turns off the speakers when content from an EasyLink-compliant home theatre system is detected.

• [Dev. root menu]Accesses the root

menu of the CD/DVD/game disc.

• [Device setup menu]Accesses the

main menu of the connected device such as DVD player, HDD recorder, or game console.

• [Dev. content menu]Accesses the

content menu of the CD/DVD/game disc.

4 Press OK to enter or activate your

selection.

English

Note

Easylink compliant device must be connected • to the TV via HDMI connector.

Access menu after enabling RC passthrough

1 Enable remote control pass-through by

following the instructions in the previous section (see ‘Enable or disable remote control pass-through’ on page 37).

2 Press to select a device that has

been enabled to support RC passthrough and press OK to enter.

3 Press OPTIONS to access one of the

following menus for TV or the active device connected to the TV:

• [TV setup]Accesses menus that

allow you to change picture, sound and other TV settings.

• [Clock]Displays the clock on the TV

screen.

Use a Kensington lock

There is a Kensington security slot at the back of the TV. Prevent theft by looping a Kensington lock between the slot and a permanent object, such as a heavy table.

8 Product

Multimedia

information

Product information is subject to change without notice. For detailed product

information, go to www.philips.com/support.

Supported display resolutions

Computer formats

Resolution - refresh rate:•

640 x 480 - 60Hz• 720 x 480 - 60Hz• 800 x 600 - 60Hz• 1024 x 768 - 60Hz• 1280 x 720 - 60 Hz• 1280 x 768 - 60 Hz• 1280 x 1024 - 60 Hz• 1366 x 768 - 60 Hz• 1360 x 768 - 60Hz• 1440 x 900 - 60Hz (For Full HD • only) 1680 x 1050 - 50Hz, 60Hz (For Full • HD only) Via HDMI/DVI input•

Video formats

Resolution - refresh rate:•

480i - 60Hz• 480p - 60Hz• 576i - 50Hz• 576p - 50Hz• 720p - 50Hz, 60Hz• 1080i - 50Hz, 60Hz• 1080p - 24Hz, 25Hz, 30Hz, 50Hz, •

60Hz.

Supported storage device: USB (Only • FAT or FAT 32 USB storage devices are supported) Supported multimedia ﬁle formats:•

Images: JPEG• Audio: MP3•

Note

Multimedia ﬁle names must not exceed 128 • characters.

Tuner/Reception/ Transmission

Aerial input: 75ohm coaxial (IEC75)• DVB: DVB Terrestrial, DVB-T MPEG4 • (only in some models) TV system: DVB COFDM 2K/8K; PAL I, • B/G, D/K; SECAM B/G, D/K, L/L’ Video playback: NTSC, SECAM, PAL• Tuner Bands: Hyperband, S-channel, UHF, •

VHF

Remote control

Type : PF 02E 09B• Batteries: 2 x AAA (LR03 type)•

Power

Mains power: 220-240V, 50Hz• Standby power: < 0.15W• Ambient temperature: 5 to 40 degrees • Celsius

Supported TV mounts

To mount the TV, purchase a Philips TV mount or a VESA-compatible TV mount. To prevent damage to cables and connectors, be sure to leave a clearance of at least 2.2 inches or 5.5cm

from the back of the TV.

Warning

Follow all instructions provided with the TV • mount. Koninklijke Philips Electronics N.V. bears no responsibility for improper TV mounting that results in accident, injury or damage.

English

TV screen size (inches)

Required pitch (mm)

Required mounting bolts

22 100 x 100 4 x M4 26 200 x 100 6 x M4

9 Troubleshooting

This section describes commonly encountered issues and accompanying solutions.

General TV issues

The TV does not switch on:

Disconnect the power cable from the • power outlet. Wait for one minute then reconnect it. Check that the power cable is securely • connected.

The remote control is not working properly:

Check that the remote control batteries • are correctly inser ted according to the +/- orientation. Replace the remote control batteries if • they are ﬂat or weak. Clean the remote control and TV sensor • lens.

The standby light on the TV blinks red:

Disconnect the power cable from the • power outlet. Wait until the TV cools down before reconnecting the power cable. If the blinking reoccurs, contact Philips Consumer Care.

You forgot the code to unlock the TV lock feature

Enter ‘8888’. •

The TV menu is in the wrong language.

Change the TV menu to your preferred • language.

When turning the TV on/off/to standby, you hear a creaking sound from the TV chassis:

No action is required. The creaking sound • is normal expansion and contraction of the TV as it cools down and warms up. This does not impact performance.

TV channel issues

Previously installed channels do not appear in the channel list:

Check that the correct channel list is • selected.

No digital channels were found during the installation:

Check that the TV supports DVB-T or • DVB-C in your country. See the listed countries on the back of the TV.

Picture issues

The TV is on, but there is no picture:

Check that the antenna is properly • connected to the TV. Check that the correct device is selected • as the TV source.

There is sound but no picture:

Check that the picture settings are • correctly set.

There is poor TV reception from an antenna connection:

Check that the antenna is properly • connected to the TV. Loudspeakers, unearthed audio devices, • neon lights, high buildings and other large objects can inﬂuence reception quality. If possible, try to improve the reception quality by changing the antenna direction or moving devices away from the TV. If reception on only one channel is poor, • ﬁne tune this channel.

There is poor picture quality from connected devices:

Check that the devices are connected • properly. Check that the picture settings are • correctly set.

The TV did not save your picture settings:

Check that the TV location is set to the • home setting. This mode offers you the ﬂexibility to change and save settings.

The picture does not ﬁt the screen; it is too big or too small:

Try using a different picture format. •

The picture position is incorrect:

Picture signals from some devices may • not ﬁt the screen correctly. Check the signal output of the device.

Sound issues

There is a picture but sound quality is poor:

Note

If a HDMI-to-DVI adaptor or HDMI to • DVI cable is used, check that an additional audio cable is connected to AUDIO L/R or AUDIO IN (mini-jack only).

Computer connection issues

The computer display on the TV is not stable:

Check that a supported resolution and • refresh rate is selected on the computer. Set the TV picture format to unscaled. •

English

If no audio signal is detected, the TV • automatically switches the audio output off — this does not indicate malfunction.

Check that all cables are properly • connected. Check that the volume is not set to 0. • Check that the sound is not muted. •

There is a picture but the sound quality is poor:

Check that the sound settings are • correctly set.

There is a picture but sound comes from one speaker only:

Verify that sound balance is set to the • centre.

HDMI connection issues

There are problems with HDMI devices:

Note that HDCP support can delay the • time taken for a TV to display content from a HDMI device. If the TV does not recognize the HDMI • device and no picture is displayed, try switching the source from one device to another and back again. If there are intermittent sound • disruptions, check that output settings from the HDMI device are correct.

If you cannot resolve your problem, refer to the FAQs for this product at www.philips. com/support. If the problem remains unresolved, contact Philips Consumer Care in your country as listed in the Addendum.

Warning

Do not attempt to repair the product yourself. • This may cause severe injury, irreparable damage to your product or void your warranty.

Note

Make a note of your TV model and serial • number before you contact Philips. These numbers are printed on the back of the TV and on the packaging.

10 Index

analogue channel

ﬁne-tune 28

bracket 39

Channel decoder 25 Channel list

favourite 15 troubleshooting 40 update 16

Channels

favourite list 15 install

automatic 26

manual 27 rename 28 reorder 28 test reception 28

child lock

ratings lock 19 TV lock/child lock 18

Clock 20 computer format

technical speciﬁcations 38

Conditional Access Module 34, 32 Connections

HDMI

troubleshooting 41 mains cord 29 overview 29 technical speciﬁcations 38 troubleshooting 41

connectors

overview 29

add to home menu 11 connect 29 watch 9

Digital channel

test reception 28

digital radio 23 digital services

CAM 34 teletext 15, 14

display

resolution 38

Dual view 17

EasyLink

disable 35 enable 35 one-touch play 35 one-touch standby 35 System audio control 36, 35

environmental care 5

factory settings 25 favourite list

select 15 set up 15

HDMI cable

troubleshooting 41

install channels

automatic 26 manual 27

Kensington lock 37

demo 25 devices

location 24 lock

Kensington 37 TV lock/child lock 18

main menu 11 teletext 14

Multimedia

technical speciﬁcations 38

music

digital radio 23 USB 22

One-touch play 35 One-touch standby 35

pc connection 33

picture format

picture format change 12 troubleshooting 40

Picture settings 11 PIN code 18

ratings 19 reception 40 remote control

overview 6 RC pass-through 37, 35 technical speciﬁcations 38

settings

sound 14

settings assistant 11 Smart card 34 Smart settings 11, 13 software

version 24

sound settings 13 , 14 Subtitles

language 20 on analogue channel 19 on digital channel 20

Table of Pages 15 technical specifcations 38 Teletext

features 14 subpages 15 table of pages 15 teletext 2.5 15

timer

on timer 18 Sleep timer 17 standby 17

troubleshooting 40 TV

adjust volume 9 as PC monitor 33 menu 11 pc connection 33 preferences 24 screen care 5 software 24 standby 8 switch channels 8 switch off 8 switch on 8 troubleshooting 40 tuner technical speciﬁcations 38 wall mount 39

TV lock/child lock

lock channels 18 lock connected devices 18 PIN code 18

USB

listen to music 22 view photos 21

Video format

video format technical speciﬁcations 38

volume

adjust 9

Wallpaper 22
