Philips 22PFL4758-V7, 24PFL4738-V7, 29PFL4738-V7, 32PFL4738-V7, 40PFL4758-V7 User Manual
...
Register your product and get support at
www.philips.com/welcome
50PFL4758/V7
46PFL4758/V7
40PFL4758/V7
32PFL4738/V7
29PFL4738/V7
24PFL4738/V7
22PFL4758/V7
EN User manual
Contents
1 Notice 2
2 Important 3
Product disposal Guidelines 4
Use your TV 5
3
4
Use more of your TV 11
5
Play photos, music and videos
on USB storage devices
6 Troubleshooting
7 Product information
8
Table Stand Installation
9
Consumer Guidelines
Warranty
10
14
16
18
20
21
22
EN 1
1 Notice
Pixel characteristics
This LCD/LED product has a high number of
color pixels. Although it has effective pixels of
99.999% or more, black dots or bright points of
light (red, green or blue) may appear constantly
on the screen. This is a structural property of
the display (within common industry standards)
and is not a malfunction.
Warranty
No components are user serviceable. Do not
open or remove covers to the inside of the
product. Repairs may only be done by Philips
Service Centres and official repair shops.
Failure to do shall void any warranty, stated
or implied.
Any operation expressly prohibited in
this manual, or any adjustments and
assembly procedures not recommended
or authorised in this manual shall void the
warranty.
2 EN
2 Important
Read and understand all instructions before you
use your TV. If damage is caused by failure to
follow instructions, the warranty does not apply.
Safety
Risk of electric shock or fire!
• Never expose the TV to rain or water.
Never place liquid containers, such as
vases, near the TV. If liquids are spilt on
or into the TV, disconnect the TV from
the power outlet immediately. Contact
Philips Consumer Care to have the TV
checked before use.
• Never place the TV, remote control or
batteries near naked flames or other
heat sources, including direct sunlight. To
prevent the spread of fire, keep candles
or other flames away from the TV, remote
control and batteries at all times.
• Never insert objects into the ventilation
slots or other openings on the TV.
• When the TV is swivelled ensure that
no strain is exerted on the power cord.
Strain on the power cord can loosen
connections and cause arcing.
Risk of short circuit or fire!
• Never expose the remote control or
batteries to rain, water or excessive heat.
• Avoid force coming onto power plugs.
Loose power plugs can cause arcing or
fire.
Risk of injury or damage to the TV!
• Two people are required to lift and carry
a TV that weighs more than 25 kg or 55
lbs.
• When stand mounting the TV, use only
the supplied stand. Secure the stand to
the TV tightly. Place the TV on a flat, level
surface that can support the combined
weight of the TV and the stand.
• When wall mounting the TV, use only a
wall mount that can support the weight of
the TV. Secure the wall mount to a wall
that can support the combined weight of
the TV and wall mount.PE Electronics
Ltd. bears no responsibility
for improper wall mounting that result in
accident, injury or damage.
Risk of injury to children!
Follow these precautions to prevent the
TV from toppling over and causing injury to
children:
• Never place the TV on a surface covered
by a cloth or other material that can be
pulled away.
• Ensure that no part of the TV hangs over
the edge of the surface.
• Never place the TV on tall furniture (such
as a bookcase) without anchoring both
the furniture and TV to the wall or a
suitable support.
• Educate children about the dangers of
climbing on furniture to reach the TV.
Risk of swallowing batteries!
• The product/remote control may
contain a coin-type battery, which can be
swallowed. Keep the battery out of reach
of children at all times!
Risk of overheating!
• Never install the TV in a confined space.
Always leave a space of at least 4 inches
or 10 cm around the TV for ventilation.
Ensure curtains or other objects never
cover the ventilation slots on the TV.
EN 3
Risk of damage to the TV!
• Before you connect the TV to the power
outlet, ensure that the power voltage
matches the value printed on the back
of the TV. Never connect the TV to the
power outlet if the voltage is different.
Risk of injury, fire or power cord damage!
• Never place the TV or any objects on the
power cord.
• To easily disconnect the TV power cord
from the power outlet, ensure that you
have full access to the power cord at all
times.
• When you disconnect the power cord,
always pull the plug, never the cable.
• Disconnect the TV from the power
outlet and antenna before lightning
storms. During lightning storms, never
touch any part of the TV, power cord or
antenna cable.
Risk of hearing damage!
• Avoid using earphones or headphones at
high volumes or for prolonged periods of
time.
Low temperatures
• If the TV is transported in temperatures
below 5°C or 41°F, unpack the TV and
wait until the TV temperature matches
room temperature before connecting the
TV to the power outlet.
Screen care
• Avoid stationary images as much as
possible. Stationary images are images
that remain on-screen for extended
periods of time. Examples include:
on-screen menus, black bars and time
displays. If you must use stationary
images, reduce screen contrast and
brightness to avoid screen damage.
• Unplug the TV before cleaning.
• Clean the TV and frame with a soft,
damp cloth. Never use substances such as
alcohol, chemicals or household cleaners
on the TV.
• Risk of damage to the TV screen! Never
touch, push, rub or strike the screen with
any object.
• To avoid deformations and colour fading,
wipe off water drops as soon as possible.
Product disposal Guidelines:
For the purpose of recycling to facilitate effective utilization of resources, please
return this product to a nearby authorized collection center, registered dismantler,
recycler, service center when disposing of this product.
In case of further assistance, you may contact nearest authorized service center.
Or Please see the Company website for further information on collection centers etc.
Visit-http://www.philips.com
OR Toll 1860 200 0129, For MTNL user 33550129
Visit-http://www.philips.com
OR Toll 1860 200 0129, For MTNL user 33550129
R
o
H
S
COMPLIANT
4 EN
( )
3 Use your TV
Congratulations on your purchase, and
support that Philips offers, register your TV at
3.1 Name and Function of Control on Set
(22PFL4758/V7 & 24PFL4738/V7 & 29PFL4738/V7)
A) TV controls and Indicators
1) IR SENSOR
2) LED INDICATOR
3) KEY BOARD
welcome to Philips. To fully benefit from the
www.philips.com/welcome.
3
1
2
SOURCE
MENU
CH+
CH-
VOL+
VOL-
STANDBY
9
RF
B) Connectivity
10
AV IN
VIDEO
L R
1
1) AV IN(YPbPr Audio IN)
2) AV OUT
3) USB
4) HDMI
5) YPbPr
Note :
1) Above sketch and connectivity are just for representation actual product may look
different as per model selection.
AV OUT
VIDEO
L R
2
6) HEADPHONE
7) PC/VGA AUDIO IN
8) VGA IN
9) RF IN
10) AC POWER IN
8
7
6
VGA
PC AUDIO
5
Y Pb Pr
4
HDMI2 HDMI1
3
USB
EN 5
3.2 Name and Function of Control on Set
(32PFL4738/V7)
A) TV controls and Indicators
3
1
2
1) IR SENSOR
2) LED INDICATOR
3) KEY BOARD
SOURCE
MENU
CH+
CH-
VOL+
VOL-
STANDBY
10
R F
B) Connectivity
9
8
7
6
AV IN
L R
VIDEO
2
1
AC-INP UT
110-240V ~ 50/60 Hz
1) AC POWER IN
2) AV IN(YPbPr Audio IN)
3) AV OUT
4) USB
5) HDMI
Note :
1) Above sketch and connectivity are just for representation actual product may look
different as per model selection.
6 EN
AV OUT
VIDEO
L R
3
6) YPbPr
7) HEADPHONE
8) PC/VGA AUDIO IN
9) VGA IN
10) RF IN
5
VGA
PC AUDIO
HEAD PHONE
Pr
Pb
Y
HDMI 1USB
HDMI 2
4
3.3 Name and Function of Control on Set
( & & )40PFL4758/V7 46PFL4758/V7 50PFL4758/V7
A) TV controls and Indicators
3
1
2
1) IR SENSOR
2) LED INDICATOR
3) KEY BOARD
SOURCE
MENU
CH+
CH-
VOL+
VOL-
STANDBY
9
B) Connectivity
1
1) AC POWER IN
2) AV IN(YPbPr Audio IN)
3) YPbPr
4) HDMI
2
3
6) AV OUT
7) PC/VGA AUDIO IN
8) VGA IN
9) RF IN
8
7
6
5
4
5) USB
Note :
1) Above sketch and connectivity are just for representation actual product may look
different as per model selection.
L R
AV OUT
VIDEO
HDMI 2 HDMI 1 USB R FVGAPC AUDIO
EN 7
3.4 Name and Function of Control on Remote
1
2
3
4
5
6
7
8
9
10
11
12
13
20
19
18
17
16
8 EN
14 15
(Standby-On)
1
• Switches the TV ON or OFF.
The TV is not powered off completely
unless it is physically unplugged
Multimedia Control buttons
2
• Control video or music.
SOURCE
• Selects connected devices.
TV
Access the TV mode.
•
LIST
Access the Channel List.
•
( Navigation buttons)
• Navigate through menus and select
items. (Also in USB mode).
OK
• Confirm an entry or selection.
FORMAT
• Adjust picture format.
• Return to the previous menu or exit
a function.
CH - / CH + Previous/Next )
Switch channels or navigate through
•
menu pages, tracks, albums or
folders.
)
5
7
8
9
10
3
4
6
15
TEXT
• Depending on model.
16
17
18
19
20
Mute or restore audio.
•
OPTIONS
• Access the menu to adjust settings.
INFO
• Displays the status information.
( Home )
• Access the home menu.
GUIDE
• Access the channel programme
edit menu.
3.5 Remote control usage
When you use the remote control, hold it close
to the TV and point it at the remote control
sensor. Make sure that the line-of-sight between
the remote control and TV is not blocked by
furniture, walls or other objects.
~5m
~30º
+/-
11
• Adjust volume.
Color buttons
12
• Select tasks or options.
13
0-9 Numeric buttons
•
Select channels.
14
SUBTITLE
• Depending on model.
EN 9
3.6 Battery Installation
1. Remove the battery compartment door.
2. Install 2 “AAA” or UM-4 (1.5V) batteries or equivalent with the correct polarity
as indicated.
3. Refix the battery compartment door.
10 EN
4 Use more of
your TV
4.1 Main Menu
Menus help you to install channels, change
picture and sound settings and access other
TV features.
1
Press
» The menu screen appears.
Watch TV Device List
Browse USB Setup
2 Select one of the following, then press
OK
[Watch TV]
•
antenna is selected, switch back to
the antenna source
•
[Browse USB]:
play music and movies contained in
USB storage devices.
• [Device List]
change other source by pressing key.
•
[Setup]
picture, sound and other settings.
4.2 Manually adjust picture setting
Sound
Features
Installation
: If a source other than
View photos and
: Access menus to
: Access menus to change
Smart Picture
Contrast
Brightness
Color
Hue
Sharpness
Pixel Precise HD
Format
Sound
Features
Installation
1
Press .
2
Select [Setup] then press OK
Dynamic Contrast
Noise Reduction
Flesh Tone
Dynamic Backlight
Off
Middle
Off
Off
> Select [Picture].
3
Select one of the following settings, then
Press to move, and press to adjust.
• [Smart picture]
: Access predefined smart
picture settings.
• [Contrast]
: Adjust the intensity of
backlight areas, while the video contents
are kept unchanged.
• [Brightness]
: Adjust the intensity and
details of dark areas.
•
•
: Adjust color saturation.
[Color]
[Hue]
: Compensate for color variations.
(Available only for NTSC channels).
•
[Sharpness]
: Adjust sharpness in the
image.
[Pixel Precise HD] :
•
To enhance the picture quality
[Dynamic contrast]
•
: Enhance
contrast, you can switch this feature
Low,Middle and High.
•
[Noise Reduction]: Filter and reduce noise
in an Image, you can switch this feature
Low,Middle and High.
colors more vivid and
[Flesh Tone]
•
improve the
: Make
details in bright colors. You can
switch this feature ON or OFF.
[Dynamic Backlight]
•
: Enhance brightness
you can switch this feature low, middle,
High, Off.
•
[ ]Format
: Select picture format.
EN 11
Sound
Features
Installation
[Color Temp.]
•
Color Temp.
Freeze
: Adjust the color balance
in an image.
•
[Freeze]
picture.
: Select option as ON to freeze the
Note
• Depending on the format of the picture
source, some picture settings may not be available.
4.3 Use Smart Picture
Use smart picture to apply pre-defined
picture settings.
Smart Picture
Press OPTIONS.
1
2
Select one of the following settings, by
[Vivid]
•
: Rich and dynamic settings,
ideal for daytime.
[Cinema]
•
[Personal]
•
: Ideal settings for movies.
: Apply your customised
picture settings.
[Bright]
•
: Ideal settings for night time.
Vivid
4.4 Manually adjust sound setting
Smart Sound
Balance
Sound
Treble
Bass
Features
AVL
Installation
Equalizer
Incredible Surround
Press
1
2
.
Select [Setup] then press OK
> Select [Sound].
3
Select one of the following settings, then
Press to move, and press to adjust.
• [Smart Sound]
: Access predefined smart
sound settings.
[Balance]
•
: Adjust the balance of the right
and left speakers.
[Treble] :
•
[Bass] :
•
• [AVL] :
Adjust the treble level.
Adjust the bass level.
Auto volume leveler
automatically reduces sudden
volume changes, for example when
switching channels.
•
[Equalizer]
: Adjust the equalizer ON
various frequencies.
•
[Incredible Surround ] :
Enable Incredible Surround for stereo
Sources
4.5 Use Smart Sound
Use smart sound to apply pre-defined
Sound settings.
Smart Sound
Standard
12 EN
Press OPTIONS.
1
2
Select one of the following settings, by
• [Standard]
: Settings that suit most
environments and types of audio.
• [Music]
• [Movie]
: Ideal settings for listening to music.
: Ideal settings for spoken audio,
such as news.
• [Personal]
: Apply the settings that were
customised in the sound menu.
4.6 Features Menu
Press
1
2 Select [Setup]
Select [Features]
>
3 Select one of the following settings then
Press to move, and press to adjust.
Sound
Features
Installation
•
[OSD Duration] :This function is used to OSD
timeout in step of 15,30,45,60 secs.
•
[Hotel Mode Control] :Hotel mode control
selection.
Notes:
The default password is 0000, and the master
password is 8202.
•
[Back Light] :Adjust the back light brightness.
•
[Sleep Time] :This function is used to ON/OFF
step of 10,20,30,60,90,120,180,240 mins.
•
[Factory Settings]
Reset to factory default settings.
•
[HDMI CEC]
•
[Blueback] :This function is used to ON/OFF
the blue screen at no signal condition.
Sound
Features
Installation
[Features in Hotel Mode Control] :
• [Hotel Mode Switch]: This function is used to
ON/OFF the hotel mode.
[Set Password]:
•
t he new password to access the hotel mode
control.
[Panel Key Lock]:
•
•
ON/OFF the panel pad key lock or unlock.
then press
OSD Duration
Hotel Mode Control
Back Light
Sleep Time
Factory Settings
HDMI CEC
Blueback
OK
:This function is used for
:HDMI CEC switch.ON/OFF
Hotel Mode Switch
Set Password
Panel Key Lock
Max Volume
Start Source
Start Channel
Volume Default
Input Source Change
Off
Off
TV
1
On
This function is used to set
This function is used to
• [Max Volume]: This function is used to
limit the max volume in TV.
[Start Source]:
•
This function is used to set
t he signal source after TV power on.
[Start Channel]:
•
•
This function is used to set
the access channel after TV power on.
[Volume Default]:
•
•
This function is used to set
the default volume value after TV power on.
[Input Source Change]:
•
•
This function is used
to ON/OFF the input source change after TV
power on.
Note
•
A ll above features would be available in
h otel mode switch is on.
Hotel Mode Control
Back Light
[Features in VGA Mode] :
• [Auto Adjust]: This automatically adjust
H & V-position, Phase and Clock for VGA
mode.
[H-Position]:
•
Adjust the horizontal
position of image [Only in VGA].
[V-Position]:
•
•
Adjust the vertical
position of image [Only in VGA].
[Clock]: Adjust the picture if not in sync
•
•
with TV screen.
[Phase]: Adjust the picture if there is any
•
•
blurring or shimmer in text.
[Only in VGA].
4.7 Installation Menu
EN 13
Press
1
2
.
Select [Setup]
> Select
[Installation]
then press
OK
3 Select one of the following settings, then
Press to move, and press to adjust.
[Color System] : Change the color system
•
(AUTO/PAL/NTSC) setting if the picture
is not reproduced properly.
Note: For India color system is Auto or
PAL.
[Sound System]
•
: Change the sound
sound system (BG/M/DK/I) setting if sound
is not reproduced properly.
Note: For India sound system is BG.
[Skip]:
•
This function is used to Skip any
program.
•
[Auto Search]
:Select the function TV
set will start auto tuning for all available
channels.
[Manual ]Search
•
:Select this for manually
searching the channels,select the function
from which tuning will start.
[Fine Tune]:
•
You can Fine tune the program,
In case poor reception.
[Channel Edit]:
•
You can Delete, Rename,
Move or Skip any programmes.
1 55.25MHz ----- On
2 62.25MHz ----- Off
3 69.25MHz ----- Off
4 76.25MHz ----- Off
5 97.25MHz ----- Off
6 112.25MHz ----- Off
7 119.25MHz ----- Off
8 126.25MHz ----- Off
9 147.25MHz ----- Off
10 161.25MHz ----- Off
Rename
Delete
Select Delete option by Pressing Red color
button,the program will be deleted.
Rename
Move the cursor to the program, Select
Rename option by pressing Green color button
to rename the program. Press to choose
Press to move the cursor.the character.
Press OK button to Enter ,
Press Menu button to Return the Edit Menu.
Move
Move the cursor to the program, Select
Move option by pressing Yellow color button
and press to move the program.
Select program no on which you want move
the current program, then press ok key.
Skip
Select Skip option by pressing Blue color
button to skip this program.
4.8 Use the Options menu
Smart Picture
Smart Picture
Smart Sound
Smart Sound
While you watch TV, press
1
The TV options menu appears.
2 Select one of the following options, switch
option by .
• [Smart Picture]:
Vivid
Vivid
Stand
Standard
OPTIONS.
Access predefined
smart picture settings.
[ ]:Smart Sound
Access predefined
smart sound settings.
4.9 Use the Format menu
While you watch TV, press
1
The TV format menu appears to adjust.
picture format.
2 Select or switch the option by .
FORMAT
4.10 Use the List menu
While you watch ATV, press
1
The ATV channel list menu appears.
2 Access or select the channels by .
Program Edit
5 Play photos, music and videos
1
48.25MHZ
2
83.25MHZ
on USB storage devices
3
105.25MHZ
4
5
6
7
8
9
175.25MHZ
203.25MHZ
224.25MHZ
463.25MHZ
545.75MHZ
LIST
14 EN
5.1 Connect a USB storage device to play
photos, music or videos stored on it.
1 Switch on the TV.
2 Connect the USB device to the USB port
on the side of your TV.
3 Press
4 Select [Browse USB], then press OK
The USB browser appears.
5.2 View photos
1 In the USB browser, select [Photo], then
press OK.
2 Select a photo or a photo album by pressing
OK key,then press to view the photo.
5.3 View a slide show of your photos
Press the following buttons to control
play of selected photos.:
Select photos by pressing OK key :
to play.
•
• to pause.
• or to play the previous or next
photo.
5.7 Music, Photo, Movie, Text
mode control menu bars
You can select the multimedia functions
like play, Pause, FF, FB, Next, Previous.
Stop etc.
To use above functions press OK key
while playing files on TV screen.
Picture mode menu bar:
Press to select the function icon, press
OK button to confirm the function.
Music mode menu bar:
5.4 Listen to music
1
In the USB browser, select [Music], then
press OK.
2 Select a music track or album by pressing
OK key.
to play.
•
• to pause.
• or to play the previous or next
5.5 Watch video
1 In the USB browser, select [Movie],then
press OK.
Select video files by pressing OK key.
2
To control play, press the play buttons:
3
•
to play/pause.
• or to play the previous or next
video.
5.6 Text
1 In the USB browser, select [Text], then
press OK.
2 Select a Text File, then Press to play.
Press to select the function icon, press
OK button to confirm the function.
Movie mode menu bar:
Step Forward
Press to select the function icon, press
OK button to confirm the function.
Text mode menu bar:
Press to select the function icon, press
OK button to confirm the function.
5.8 Disconnect a USB storage device
Caution
•
Follow this procedure to avoid damage to your
USB storage device.
1 Press to exit the USB browser.
2 Wait for five seconds, then disconnect
the USB storage device.
EN 15
6 Troubleshooting
This section describes commonly encountered
issues and accompanying solutions.
6.1 General TV issues
The TV does not switch on:
Disconnect the power cable from the power
outlet. Wait for one minute then reconnect it.
Check that the power cable is securely
connected.
The remote control is not working properly:
Check that the remote control batteries
are correctly inserted according to the +/orientation.
Replace the remote control batteries if they are
flat or weak.
Clean the remote control and TV sensor lens.
The standby light on the TV blinks red:
Disconnect the power cable from the power
outlet. Wait until the TV cools down before
reconnecting the power cable. If the blinking
reoccurs, contact Philips Consumer Care.
When turning the TV on/off/to standby, you hear a
creaking sound from the TV chassis:
No action is required. The creaking sound is
normal expansion and contraction of the TV as it
cools down and warms up. This does not impact
performance.
6.2 TV channel issues
Previously installed channels do not appear in
the channel list:
Check that the correct channel list is
selected.
6.3 Picture issues
The TV is on, but there is no picture:
Check that the antenna is properly
connected to the TV.
Check that the correct device is selected
as the TV source.
There is sound but no picture:
Check that the picture settings are
correctly set.
There is poor TV reception from an antenna
connection:
Check that the antenna is properly
connected to the TV.
Loudspeakers, unearthed audio devices,
neon lights, high buildings and other large
objects can influence reception quality.
If possible, try to improve the reception
quality by changing the antenna direction
or moving devices away from the TV.
If reception on only one channel is poor,
fine tune this channel.
There is poor picture quality from connected
devices:
Check that the devices are connected
properly.
Check that the picture settings are
correctly set.
The TV did not save your picture settings:
Check that the TV location is set to the
home setting. This mode offers you the
flexibility to change and save settings.
The picture does not fit the screen; it is too
big or too small:
Try using a different picture format.
The picture position is incorrect:
Picture signals from some devices may
not fit the screen correctly. Check the
signal output of the device.
16 EN
6.4 Sound issues
There is a picture but sound quality is poor:
Note
If no audio signal is detected, the TV
automatically switches the audio output off
this does not indicate malfunction.
Check that all cables are properly connected.
Check that the volume is not set to 0.
Check that the sound is not muted.
There is a picture but the sound quality is poor:
Check that the sound settings are correctly
set.
There is a picture but sound comes from one
speaker only:
Verify that sound balance is set to the centre.
6.5 HDMI connection issues
There are problems with HDMI devices:
If the TV does not recognise the HDMI
device and no picture is displayed, try
switching the source from one device to
another and back again.
If there are intermittent sound disruptions,
check that output settings from the HDMI
device are correct.
If you use an HDMI-to-DVI adapter or
HDMI-to-DVI cable, check that an additional
audio cable is connected to AV IN.
6.7 Contact us
If you cannot resolve your problem, refer to the
FAQs for this product at www.philips.com/support.
or Contact Customer Service Center.
Warning
Do not attempt to repair the product yourself.
This may cause severe injury, irreparable
damage to your product or void your
warranty.
Note
Make a note of your TV model and serial
number before you contact Philips. These
numbers are printed on the back of the TV
and on the packaging.
6.6 Computer connection issues
The computer display on the TV is not stable:
Check that your PC uses the supported
resolution and refresh rate.
Select the “Auto Adjust” function.
1. Press
2. Select [Setup] >[Features] >
[Auto Adjust].
EN 17
7 Product
information
Product information is subject to change
without notice. For detailed product
information, go to www.philips.com/support.
7.1 Supported display resolutions
Computer formats (HDMI)
Resolution - refresh rate:
720 x 480p - 60Hz
720 x 576p - 50Hz
1280 x 720p - 50Hz,60Hz
1920 x 1080p -50Hz,60Hz
Computer formats (VGA)
Resolution - refresh rate:
640 x 480 - 60Hz,72Hz,75Hz
800 x 600 - 56Hz,60Hz,72Hz,75Hz
1024 x768 - 60Hz,70Hz,75Hz
1280 x 1024 - 60Hz
Video Formats
Resolution - refresh rate:
720 x 480i - 60Hz
720 x 480p - 60Hz
720 x 576i - 50Hz
720 x 576p - 50Hz
1280 x 720p - 50Hz, 60Hz
1920 x 1080i - 50Hz, 60Hz
Note
1)
1080p support only for FHD model
7.2 Tuner/Reception/
Transmission
Antenna input: 75ohm coaxial (IEC75)
TV system: PAL, B/G
Video playback: NTSC,PAL
Tuner Bands: UHF, VHF
7.3 Remote control
Type: YKF293-001
Batteries: 2 x AAA (LR03 type)
7.4 Multimedia
Supported USB storage device:
(Only FAT 16 or FAT 32 USB storage
devices are supported)
Supported storage file formats:
Images : JPEG, BMP, PNG
Audio : MP3,WMA.
Text : TEXT
Video :
Note
1)
2) The USB features/functions may vary
names must not exceed 128
USB
file
characters.
from file to file depending on relative
information present in the file
7.5 Power
Mains power: AC 110-240V~, 50/60Hz
Ambient temperature: 5 to 40 degrees
Celsius
Power consumption
50PFL4758/V7: 125W
46PFL4758/V7: 120W
40PFL4758/V7
32PFL4738/V7
29PFL4738/V7
24PFL4738/V7: 50W
22PFL4758/V7: 45W
: 100W
: 75W
: 60W
Note :- HD Natural Motion are inbuilt feature in chipset solution.
18 EN
7.6 Supported TV mounts
To mount the TV, purchase a Philips TV mount
- compatible TV mount. To Prevent damage
to cables and connectors, be sure to leave a
clearance of at least 2.2 inches or 5.5 cm from
the back of the TV.
Warning
Follow all instructions provided with the TV
mount. PE Electronics Ltd. bears no
responsibility for improper TV
mounting that results in accident, injury or
damage.
TV screen
size (inches)
50PFL4758/V7 200x200 4 x M6
46PFL4758/V7 200x200 4 x M6
40PFL4758/V7 200x200 4 x M6
32PFL4738/V7 200x100 4 x M4
29PFL4738/V7 200x100 4 x M4
24PFL4738/V7 100 2 x M4
22PFL4758/V7 100 2 x M4
Required
pitch (mm)
Required
mounting bolts
40PFL4758/V7
With TV stand
Dimension(WxDxH): 892 x 250 x 582 (mm)
Weight: 8.5 kg
Without TV stand
Dimension(WxDxH): 892 x 63 x 529 (mm)
Weight: 7 kg
32PFL4738/V7
With TV stand
Dimension(WxDxH): 738 x 200 x 498 (mm)
Weight: 5 kg
Without TV stand
Dimension(WxDxH): 738 x 62 x 443 (mm)
Weight: 4.1 kg
29PFL4738/V7
With TV stand
Dimension(WxDxH): 641 x 200 x 445 (mm)
Weight: 5.3 kg
Without TV stand
Dimension(WxDxH): 641 x 36 x 390 (mm)
Weight: 4.4 kg
7.7 Product specification
Design and specifications are subject to change
without notice.
50PFL4758/V7
With TV stand
Dimension(WxDxH): 1136 x 280 x 723 (mm)
Weight: 14.6 kg
Without TV stand
Dimension(WxDxH): 1136 x 71 x 666 (mm)
Weight: 12.7 kg
46PFL4758/V7
With TV stand
Dimension(WxDxH): 1060 x 280 x 685 (mm)
Weight: 12.6 kg
Without TV stand
Dimension(WxDxH): 1060 x 65 x 625 (mm)
Weight: 10.7 kg
24PFL4738/V7
With TV stand
Dimension(WxDxH): 556 x 160 x 385 (mm)
Weight: 3.9 kg
Without TV stand
Dimension(WxDxH): 556 x 36 x 337 (mm)
Weight: 3.5 kg
22PFL4758/V7
With TV stand
Dimension(WxDxH): 513 x 160 x 360 (mm)
Weight: 3.1 kg
Without TV stand
Dimension(WxDxH): 513 x 36 x 312 (mm)
Weight: 2.7 kg
EN 19
Table Stand Installation
Notes: If the table stand has been assembled, just ignore the following instructions.
Follow the instructions accordingly based on the table stand supplied to you and
graphics shown below are for illustrative purposes only.
The TV unit and screws is subject to material object.
1. Place the TV with the display side down on a flat surface, Use a cloth to protect the display.
2. Attach the stand Pillar to the TV set and fix the stand pillar with scerw supplied.
50PFL4758/V7 & 46PFL4758/V7
22PFL4758/V7 & 24PFL4738/V7
3. Attach the stand base plate to the stand pillar fix the stand with screw supplied.
29PFL4738/V7 32PFL4738/V7 & 40PFL4758/V7
Notes: Graphics contained within this publication are presentation only.
When the TV faced down, do not impact the screen with sharp edges to avoid
scratching the screen.
20 EN
Consumer Guidelines
1.Kindly ensure that the dealer fills out warranty card correctly.
2.To avail the Warranty please register your product with the Philips-
• Log on to www.Philips.com
OR
• Contact Philips Consumer Care Centre
3.In the unlikely event of a defect developing in the TV set contact the Philips Customer
Care Centre for obtaining warranty service and inform of the defect observed in the
set, the type no. and serial no. of the set.
4.On your lodging a complaint, a trained technician will call on you promptly. In the
event of the technician deciding that set requires attention at the service station;the
technician would arrange to get the set picked up to be delivered to service station
for further attention. “Homecalls” by the technician would however be restricted within
municipal limits of the city/town in which the set has been registered.the
Type no. Serial No. Date of Purchase
Purchased By: Name
Address:
Tel.No.
Sold by: Name
Address:
Tel.No.
Sold by(User rubber stamp)
Model no.:
50PFL4758/V7
46PFL4758/V7
40PFL4758/V7
32PFL4738/V7
29PFL4738/V7
24PFL4738/V7
22PFL4758/V7
Serial no.:
Contact Customer Service Executive at:
Toll :- 1860 200 0129
MTNL User :- 33550129
Regd Office: PE Electronics Ltd,Auto Cars Compound,Adalat Road,Aurangabad,431005.
EN 21
WARRANTY
This TV receiver is covered under from whom the set has been purchased or
warranty against any defect arising out through an Authorised Service Center for
of faulty or defective material or workman warranty service. However, if the
ship for a period of 12 months from the Purchaser has to shift his residence to
date of purchase. another town on account of transfer or
other reasons, the warranty benefit will be
Should a defect develop in this set during available at the Authorised Service Center
the period of warranty, PE Electronics
Limited undertakes to get the
set repaired free of charge either
The warranty is not valid in case of any of
the following events:
The TV set is not used according to instructions given in the ‘Direction for use’
/ ‘User Manual’
Defects are caused by improper or reckless use.
Any repair work carried out by persons other than a Philips dealer or Authorised
Service Center.
Any modification or alteration of any nature made in the electrical circuitry of the set.
This Warranty Card is not completed and signed immediately on delivery of the set
by the Philips Dealer.
Fading effects and/or Ghosts (Multiple Image) in picture, if any,arising due to location
/ signal reception.
Defects due to causes beyond control like lightning, abnormal voltage, Acts of God or
while in transit to purchaser’s residence.
of that town.
(Refer Consumer Guidelines for further details)
22 EN
Loading...
