Technology You Can See

!

★★

According to DisplaySearch, various publications

* Quarterly Large-Area TFT-LCD Shipment Report of Q1 ‘06

** Annual Customer Satisfaction Reports for 2002, 2003, 2004 and 2005

†

Listed in the Guinness World Records 2007

- Highest rated in DisplaySearch’s Customer Satisfaction Award**

- World’s #1 15” and above LCD notebook PC module supplier by units*

- World’s #1 large-area TFT-LCD supplier by input area*

- World’s first & third 5th generation LCD
factories started mass production

- Highest rated in DisplaySearch’s Customer Satisfaction Award**

- SID Display of the Year Award

- World’s #1 large-area TFT-LCD supplier by input shipments, revenue and area*

- World’s #1 15” and above LCD notebook PC module supplier by units

- World’s first & third 5th generation LCD
factories started mass production

- Highest rated in DisplaySearch’s Customer Satisfaction Award**

- SID Display of the Year Award

- World’s #1 15” and above LCD notebook PC module supplier by units*

- World’s largest 6

th

generation factory started mass production

- Highest rated in DisplaySearch’s Customer Satisfaction Award**

- World’s #1 large-area TFT-LCD supplier by input shipments, revenue and area*

- World’s #1 LCD TV and monitor module supplier*

- World’s #1 15” and above LCD notebook PC module supplier by units

LG.Philips LCD on the Top of LCD Technology

55" Full HDTV, the world's

largest shipping LCD for TVs

★4-time winner ; DisplaySearch Customer Satisfaction Award 2002~2005

★2-time winner ; SID Display of the Year Award 2003 & 2004

March

DISPLAYSEARCH

April

DISPLAYSEARCH

March

DISPLAYSEARCH

May

DISPLAYSEARCH

20.1" UXGA display

with Copper Bus Technology

LG.Philips LCD provides a full line up of large & wide LCD TV modules, all with S-IPS!

LG.Philips LCD’s products have won many awards and often
appeared on the cover of world's leading display publications.

In July 2004, LG.Philips LCD became the world’s first company
to be concurrently dual listed on the KRX and NYSE.

LG.Philips LCD Milestones

- BSC (Balanced Scorecard) Hall of Fame Award

- World’s largest 7thgeneration factory started mass production

- First to develop the world’s largest 100” Full HD LCD module

†

World's Largest 7thGeneration Fab*

World's Largest 6thGeneration Fab*

World's First and Third 5

th

Generation Fabs

Gumi, Korea

Paju, Korea

Gumi, Korea

LG.Philips LCD's 5thgeneration fabs, P4 and P5, expedited the transition into a new, display-centric era of consumer
electronics during 2002 and 2003.

With the introduction of the world's largest 7

th

generation fab in 2006*and the world’s largest 6thgeneration fab in 2004,
LG.Philips LCD is enabling a new flat TV market, while improving its position as a capacity and cost leader without
sacrificing the quality or service that customers have come to expect.

LG.Philips LCD's P4, P5, P6 and P7 plants are setting the standard for future generation fabs, paving the way for TFT-LCDs
to become an affordable, mainstream display solution.

*

As of 2006

Larger Sheets of Glass = More End Products

Examples of possible number of cuts per substrate

Generation Fab History

8up (42”W)

24up (17”)

15up (15”)

2250 x1950
(Gen 7)

1850 x1500
(Gen 6)

1250 x1100
(Gen 5)

P7

P6

P5

With slim and sleek industrial design, LCD TVs are great in any room and are
the perfect displays for high definition digital media. LG.Philips LCD offers a
wide array of state-of-the-art display modules for television applications
with Super IPS technology, and our display sizes have become leading
industry standards.

LG.Philips LCD is well positioned to lead this promising market based on its
cutting-edge technology and broad product portfolio. The company is dedicated
to further developing LCD TV technology and the market to facilitate the
adoption of high definition digital broadcasting and the trend toward new larger
and wider digital display screens.

※ Super IPS technology applied to all products. ▶ Design and specifications are subject to change without prior notice.

Television

|

Television

|

LC550W01

Category

Resolution

Definition

Aspect Ratio

Number of Colors

Frequency

Max. Brightness (nit)

Color Saturation (%)

Max. Contrast Ratio

Viewing Angle (CR≧10)

Response Time (ms)

Interface

Outline Dimension (mm)

Thickness (mm)

MP Schedule

*

GTG : Gray-to-Gray **DCR : Dynamic Contrast Ratio

20.1”

LC201V02

640 x 480

SD

4 : 3

16.7M (8 bit)

60Hz

500

72

800 : 1

178/178

25 (on/off)

TTL

432.0 x 331.5

25.0

MP

26” Wide

LC260WX2

1,366 x 768

HD

16 : 9

16.7M (8 bit)

60Hz

600

72

1400 : 1**

178/178

8 (GTG*)

LVDS 1 port

626.0 x 373.0

44.1

MP

32” Wide

LC320W01(60Hz)/

LC320WX1(120Hz)

1,366 x 768

HD

16 : 9

16.7M (8 bit)

60Hz/120Hz

600

72

5000 : 1**

178/178

5 (GTG*)

LVDS 1 port/2 port

760.0 x 450.0

48.0

MP

LC370WX1/

LC370WX2

1,366 x 768

HD

16 : 9

8 bit/10bit

60Hz/120Hz

600

72

5000:1**

178/178

5 (GTG*)

LVDS 1 port/2 port

877.0 x 516.8

55.5

MP

LC370WU1/

LC370WU2

1,920 x 1,080

Full HD

16 : 9

8 bit/10bit

60Hz/120Hz

600

72/92

5000:1**

178/178

8 (GTG*)

LVDS 2 port/4 port

877.0 x 516.8

55.5

MP

LC420WX3/

LC420WX4

1,366 x 768

HD

16 : 9

16.7M (8 bit)

60Hz/120Hz

600

72

5000 : 1**

178/178

5 (GTG*)

LVDS 1 port

983.0 x 576.0

51.0

MP

LC420WU1/

LC420WU4

1,920 x 1,080

Full HD

16 : 9

8 bit/10 bit

60Hz/120Hz

600

72/92

5000 : 1**

178/178

5 (GTG*)

LVDS 1 port/2 port

983.0 x 576.0

51.0

MP

LC470WX1

1,366 x 768

HD

16 : 9

8 bit/10 bit

60Hz/120Hz

600

72

5000 : 1**

178/178

5 (GTG*)

LVDS 1 port/2 port

1,096.0 x 640.0

51.0

MP

LC470WU1/

LC470WU2

1,920 x 1,080

Full HD

16 : 9

8 bit/10 bit

60Hz/120Hz

600

72/92

5000 : 1**

178/178

5 (GTG*)

LVDS 2 port/4port

1,096.0 x 640.0

51.0

MP

52” Wide

LC520WU/

LC520WU2

1,920 x 1,080

Full HD

16 : 9

10 bit

60Hz/120Hz

600

72/92

5000 : 1**

178/178

5 (GTG*)

LVDS 2 port/4 port

1,236.0 x 719.2

57.5

Q1, ‘07

55” Wide

LC550W01

1,920 x 1,080

Full HD

16 : 9

16.7M (8 bit)

60Hz

600

72

1200 : 1**

178/178

8 (GTG*)

LVDS 2 port

1,264.0 x 738.4

49.8

MP

47” Wide42” Wide37” Wide

Monitor

LM300W01

LM201U05

A wider, brighter and crisper screen image! LG.Philips LCD's technological
advancements have enabled it to lead the TFT-LCD market not only for
desktop monitors, but also for large and wide multi-functional monitors.

LG.Philips LCD was the first to introduce 20.1" UXGA and 23" WUXGA modules,
and continues to lead the industry through technology advancements, such as
wide viewing angle, fast response time, high brightness and high resolution.

▶ Design and specifications are subject to change without prior notice.

|

Monitor

|

Category

Resolution

Aspect Ratio

Number of Colors

Brightness (nit)

Color Saturation (%)

Max. Contrast Ratio

Viewing Angle (°,H / V)

Response Time (ms)

Interface

Outline Dimension (mm)

Thickness (mm)

MP Schedule

15”

LM150X08

1,024 x 768

XGA

4 : 3

16.2 M

(6 bit+FRC)

250

60

550 : 1

130/100

8

LVDS

326.5 x 253.5

11.2

MP

17”

LM170E03

1,280 x 1,024

SXGA

5 : 4

16.7 M

(6 bit+A-FRC)

300/420

72

800 : 1

160/160

5

LVDS

358.5 x 296.5

17.0

MP

19”

LM190E08

1,280 x 1,024

SXGA

5 : 4

16.7 M

(6 bit+A-FRC)

300/450

72

800 : 1

160/160

5

LVDS

396.0 x 324.0

16.5

MP

20.1”

LM201U05

1,600 x 1,200

UXGA

4 : 3

16.7 M

(8 bit)

300

72

800 : 1

178/178

†

8 (GTG*)

LVDS

432.0 x 331.5

25.0

MP

17” Wide

LM171W02

1,440 x 900

WXGA

+

16 : 10

252K

(6 bit)

250

62

550 : 1

140/120

16

LVDS/TMDS

395.0 x 256.4

11.0

MP

19” Wide

LM190WX1

1,440 x 900

WXGA

+

16 : 10

16.7 M

(6 bit+A-FRC)

300

72

1000 : 1

160/160

5

LVDS

427.2 x 277.4

15.3

MP

LM201W01

1,680 x 1,050

WSXGA

+

16 : 10

16.7 M

(8 bit)

300

72

800 : 1

178/178

†

8 (GTG*)

LVDS

459.4 x 296.4

22.8

MP

LM201WE3

1,680 x 1,050

WSXGA

+

16 : 10

16.7 M

(6 bit+A-FRC)

300/450

72

1000 : 1

160/160

5

LVDS

459.4 x 296.4

22.8/16.5

MP

22” Wide

LM220WE1

1,680 x 1,050

WSXGA

+

16 : 10

16.7 M

(6 bit+A-FRC)

300

72

1000 : 1

160/160

5

LVDS

493.7 x 320.1

16.5

MP

23” Wide

LM230WU3

1,920 x 1,200

WUXGA

16 : 10

16.7 M

(8 bit)

300/400

72

700 : 1

178/178

†

12

LVDS/TMDS

523.4 x 335.6

41.0

MP

LM240WU1

1,920 x 1,200

WUXGA

16 : 10

16.7 M

(8 bit)

500

72

1600 : 1**

178/178

†

6 (GTG*)

LVDS

546.4 x 352.0

40.3 (w/inv.)

MP

LM240WU3

1,920 x 1,200

WUXGA

16 : 10

16.7 M

(6 bit+A-FRC)

400

92

1000 : 1**

160/160

5

LVDS

546.4 x 350.0

35.8 (w/o inv.)

Q2, ‘07

26” Wide

LM260WU1

1,920 x 1,200

WUXGA

16 : 10

16.7 M

(8 bit)

500

92

1600 : 1**

178/178

†

5 (GTG*)

LVDS

582.0 x 375.6

41.5

MP

LM300W01

2,560 x 1,600

WQXGA

+

16 : 10

16.7 M

(8 bit)

400

72

700 : 1

178/178

†

8 (GTG*)

TMDS

677.3 x 436.8

42.3

MP

LM300WQ3

2,560 x 1,600

WQXGA

+

16 : 10

16.7 M

(8 bit)

300

92

1000 : 1

178/178

†

8 (GTG*)

TMDS

677.3 x 436.8

42.3

MP

20” Wide 24” Wide 30” Wide

* GTG : Gray-to-Gray **DCR : Dynamic Contrast Ratio †Super IPS Technology Applied

Notebook PC

LP141WX1

Large, wide and high performance LCDs! You can use mobile devices
made with our thin and light notebook PC modules anywhere, anytime!

LG.Philips LCD has led the industry in providing perfect display solutions for
notebook PCs, ranging from ultra mobile to desktop replacement.
With larger and wider format of thin and light notebook PC modules,
LG.Philips LCD delivers the real mobility experience to your satisfaction.

※ Side-mounting technology applied to all products. ▶ Design and specifications are subject to change without prior notice.

|

Notebook PC

|

Category

Resolution

Aspect Ratio

Number of Colors

Brightness (nit)

Contrast Ratio

Viewing Angle (°,H / V)

Response Time (ms)

Interface

Outline Dimension (mm)

Thickness (mm) (typ.)

Thickness (mm) (max.)

Power Consumption (W)

Weight (g)

Remarks

MP Schedule

5” Wide

LP050WV1

800 x 480

WVGA

15 : 9

262K (6 bit)

300

400 : 1

130/100

16

LVDS 1 port

122.4 x 79.0

3.0*

3.2*

-

60

*

:Except for PCB

Q3, ‘07

12.1” Wide

LP121WX1

1,280 x 800

WXGA

16 : 10

262K (6 bit)

200

300 : 1

90/50

25

LVDS 1 port

275.8 x 178.0

4.7

5.0

5.0

250

MP

13.3” Wide

LP133WX1

1,280 x 800

WXGA

16 : 10

262K (6 bit)

250

400 : 1

90/50

25

LVDS 1 port

299.5 x 195.5

5.3

5.5

5.0

350

MP

LP141WX1

1,280 x 800

WXGA

16 : 10

262K (6 bit)

200

400 : 1

90/50

16

LVDS 1 port

320.0 x 206.0

5.1

5.3

5.4

390

MP

LP141WP1

1,440 x 900

WXGA

+

16 : 10

262K (6 bit)

240

400 : 1

90/50

16

LVDS 2 port

320.0 x 206.0

5.3

5.5

6.0

425

MP

LP154W01

1,280 x 800

WXGA

16 : 10

262K (6 bit)

200

400 : 1

90/50

16

LVDS 1 port

344.0 x 222.0

6.2

6.5

5.6

560

MP

LP154WX3

1,280 x 800

WXGA

16 : 10

262K (6 bit)

500

700 : 1

130/120

16

LVDS 1 port

344.0 x 225.0

6.7

7.0

10.0

585

72% Color

Q1, ‘07

LP154WP1

1,440 x 900

WXGA

+

16 : 10

262K (6 bit)

250

400 : 1

150/110

16

LVDS 2 port

344.5 x 222.5

6.1

6.4

6.0

505

MP

LP154WE2

1,680 x 1,050

WSXGA

+

16 : 10

262K (6 bit)

200

500 : 1

130/100

16

LVDS 2 port

344.0 x 222.0

6.2

6.5

5.9

550

MP

LP154WU1

1,920 x 1,200

WUXGA

16 : 10

262K (6 bit)

210

600 : 1

130/100

16

LVDS 2 port

344.0 x 222.0

6.2

6.5

6.5

560

Q1, ‘07

LP171WX2

1,440 x 900

WXGA

+

16 : 10

262K (6 bit)

200

500 : 1

140/120

16

LVDS 2 port

382.7 x 244.5

6.2

6.5

6.2

670

MP

LP171WP7

1,440 x 900

WXGA

+

16 : 10

262K (6 bit)

500

700 : 1

140/120

8

LVDS 2 port

382.2 x 247.5

6.7

7.0

10.5

735

72% Color

Q1, ‘07

LP171WE2

1,680 x 1,050

WSXGA

+

16 : 10

262K (6 bit)

300

600 : 1

130/100

25

LVDS 2 port

382.2 x 244.5

6.2

6.5

6.1

670

MP

LP171WU1

1,920 x 1,200

WUXGA

16 : 10

262K (6 bit)

260

700 : 1

140/120

16

LVDS 2 port

382.7 x 245.0

6.3

6.6

6.9

690

50% Color

MP

20.1” Wide

LP201WE1

1,680 x 1,050

WSXGA

+

16 : 10

16.7M (8 bit)

320

1000 : 1

160/140

5

LVDS 2 port

453.5 x 296.5

11.5

8.5

16.8

1,210

72% Color

Q2, ‘07

14.1” Wide 15.4” Wide 17.1” Wide

Applications & Mobile

LB070WV1

LH220J01

▶ Design and specifications are subject to change without prior notice.

LG.Philips LCD offers a full line of display solutions geared towards
satisfying the application/industrial market. With a diverse product line­up that provides solutions ranging from small size panels used in mobile
products to large size monochrome panels for medical displays, we have
what you need.

With our proven technology leadership, we are developing TFT-LCD panels,
which utilize the latest technology and industry leading manufacturing
processes. This allows us to offer our customers the very best products to
meet their stringent needs.

Mobile

Automotive

Portable AV

Industrial

|

Applications & Mobile

|

1.76”

LH176J01

176 x 220

262K (6 bit)

300

400 : 1

90/50

CPU

34.0 x 45.5

1.9

TN

-20 ~ 70

-30 ~ 80

MP

1.77”

LH177J01

128 x 160

262K (6 bit)

200 (min)

350 : 1

90/50

CPU

33.9 x 45.9

2.1

TN

-20 ~ 70

-30 ~ 80

MP

2”

LH200Q04

240 x 320

262K (6 bit)

250

350 : 1

170/170

CPU

37.2 x 52.1

1.9

IPS

-20 ~ 70

-30 ~ 80

MP

2.2”

LH220J01

240 x 320

262K (6 bit)

200 (min)

350 : 1

90/50

CPU

40.9 x 54.4

2.1

TN

-20 ~ 70

-30 ~ 80

MP

LB040Q02

320 x 240

262K (6 bit)

450

400 : 1

120/90

Digital (TTL)

98.4 x 78

10.4

TN

-30 ~ 85

-40 ~ 85

MP

LB040Q03

320 x 240

262K (6 bit)

400

450 : 1

130/125

Digital (RGB+SPI)

96 x 75.6

3.95

TN

-20 ~ 70

-30 ~ 80

MP

LB065WQ2

400 x 234

Full Colors

*

500

400 : 1

120/90

Analog

155.5 x 89.8

8

TN

-30 ~ 85

-40 ~ 85

MP

LB065WQ3

400 x 240

262K (6 bit)

450

400 : 1

120/90

Digital (TTL)

155.3 x 91

10

TN

-30 ~ 85

-40 ~ 85

MP

LB070WQ3

400 x 234

Full Colors

*

400

400 : 1

140/110

Analog

167.5 x93.2

6.9

TN

-30 ~ 85

-40 ~ 85

MP

LB070WV1

800 x 480

262K (6 bit)

500 : 1

140/110

Digital (TTL)

170 x 109.6

20

TN

-30 ~ 85

-40 ~ 85

MP

8”

LB080WV4

800 x 480

262K (6 bit)

500

400 : 1

120/90

Composite

199 x 121

16.5

TN

-30 ~ 85

-40 ~ 85

MP

10.2”

LB102WV1

800 x 480

262K (6 bit)

250

300 : 1

140/110

Digital (TTL)

235 x 145.8

6.1

TN

-10 ~ 60

-20 ~ 70

Q2, ’07

19”

LB190E01

1,280 x 1,024

Mono

1,000

900 : 1

178/178

Digital (LVDS)

396 x 324

20

IPS

0 ~ 50

-20 ~ 60

MP

Category

Resolution

Number of Colors

Brightness (nit)

Contrast Ratio

Viewing Angle (CR>10)

Interface

Outline Dimension (mm)

Thickness (mm)

Mode

Operation Temp. (°C)

Storage Temp. (°C)

MP Schedule

* Full color : Full color depth depends on application IC's and frame buffer **With Light Control Film

4” 6.5” 7”

320 (left 30°)

250 (rigth 30°)

**

Enhanced Super IPS delivers the widest

viewing angle and great color fidelity!

Enhanced Super IPS

BEST WIDE VIEWING ANGLE PERFORMANCE

Enhanced S-IPS provides less color variation from any viewing

angle by maintaining higher color accuracy, lower gamma
distortion and higher contrast ratio uniformity.

*Color Accuracy=(1-u'v') x 100(%) @ 60˚

(u'v'=Color Difference metric in the 1976 CIE color space)

High Color Accuracy

*

99%

97%

Higher=Better

VA

**Gamma Distortion=[Gamma(0˚)-Gamma(60˚)]/Gamma(0˚) x 100(%)

Low Gamma Distortion

**

Lower=Better

VA

3%

20%

|

Enhanced Super IPS

|
