Philips 14PV125-39, 14PV422-39, 14PV225-39 User Manual

TVCR
MODEL NO.:
14PV125/39, 14PV225/39 14PV422/39
Thank you for buying a Philips TV-Video combi.This TV-Video combi is one of the most sophisticat­ed and easy-to-use TV-Video combi on the market. Please take the time to read this operating manu­al before using your TV-Video combi.It contains important information and notes regarding operation. The TV-Video combi should not be turned on immediately after transportation from a cold to a hot area or vice versa, or in conditions of extreme humidity.Wait at least three hours after transport­ing the device.The TV-Video combi needs this time in order to become acclimatised to its new envi­ronment (temperature, air humidity, etc.).
This TV-Video combi is used for the recording and playback of VHS videocassettes. Cassettes with the VHS-C label (VHS cassettes for camcorders) may only be used
PAL SECAM
with a suitable adapter.
We hope you enjoy your new TV-Video combi.
Important notes regarding operation
Danger: High voltage!
"
There is a risk of an electrical shock!
The TV-Video combi does not contain any
"
components that can be repaired by the customer.Please leave all maintenance work for qualified personnel.
As soon as the TV-Video combi is connect-
"
ed to the power supply, some components are in constant operation.To-switch off the TV-Video combi completely you must dis­connect it from the mains or switch it off with the main switch.
Make sure that air can circulate freely
!
through the ventilation slots on the TV-Video combi. Do not place the device on an unsteady base.
Make sure that no objects or liquids enter
!
the TV-Video combi. Do not place vases or the like on the TV-Video combi.If liquid is spilt into it, immediately disconnect the TV­Video combi from the power supply and call After-sales Service for advice.
Do not place any combustible objects on the
!
device (candles, etc.). Make sure that children do not place any
!
foreign objects within the openings or venti­lation slots.
These operating instructions have been printed on non-polluting paper.
Deposit old batteries at the appropriate col­lection points.
Please make use of the facilities available in your country for disposing of the packaging of the TV-Video combi in a way that helps to protect the environment.
This electronic device contains many materi­als that can be recycled. Please enquire about the possibilities for recycling your old device.
So that you can identify your machine for service questions or in the event of theft, enter the serial number here.The serial number (PROD.NO.) is printed on the type plate fixed at the back of the device.
MODEL NO. : 14PV125/39, 14PV225/39
14PV422/39
PROD. NO. ...........................
This product complies with the requirements of Directive 73/23/EEC +89/336/EEC +93/68 EEC.
IN BRIEF
o
l
p
o l p
The remote control
REC STANDBY/ON
1 2 3
4 5 6
7 8 9
SLEEP SYSTEM
0
PLAYSTATUS/EXIT CLEAR
REW FWD
MENU
STOP
P
P
PROGVOL
STILL
P
MUTE
p l o
o l p
CLEAR
To delete last entr y/Clear programmed recording (TIMER).
REC I
To record the TV channel selected at this moment or press repeatedly to
start a One-Touch Recording.
22
STILL
To stop the tape and show a still picture.
+
PROG P–PROG P
To select the programme number. During nor mal or slow
motion playback, press to adjust the tracking or vertical jitter.
MUTE
To eliminate the sound. Press again to restore the volume.
+
VOL5
SYSTEM SLEEP STANDBY/ON
MENU
STATUS/EXIT
VOL5
To adjust the volume.
To change the video (colour) system.
To select the switch-off time in 30 minutes intervals.
yy
To switch TVCR on or off, interrupt menu function.
To call up main menu of TVCR.
To access or remove the TVCR’s on-screen status display.To exit on-
screen menus.
0..9
Press to select channels.
FWD
When tape playback is stopped, press to fast forward the tape at hight
1- B
speed. During playback, press to fast forward the tape while the picture stay on the screen.To store or confirm entry in the menu. Press to adjust the controls of TVCR menu.
REW
When tape playback is stoped, press to rewind the tape at high speed.
0- s
During playback, press to rewind the tape while the picture stay on the screen.To return the cursor in the menu. Press to adjust the controls of TVCR menu.
PLAY STOP
To play a tape, select an item in the menu of TVCR.
B- K
C- L
To stop the tape, select an item in the menu of TVCR.
Red button / Green button / Yellow button/ Blue button / Doesn’t work on these models.
<14PV225>
: To switch TELETEXT on or off, or transparent mode. : enlarge font : select TELETEXT sub-page : recall hidden information : stop page changes : go back to start page.
EN
2
Front of the device
EXT/AV1
VIDEO AUDIO
STANDBY
Standby/on: To switch TVCR on or off, interrupt menu function.
yy
Volume:In connection with the button , to adjust the volume.
55
Programme number minus: previous programme number
P-
Programme number plus: next programme number
P+
I
Record: To record the programme currently selected.
B
Playback: To play a recorded cassette.
C
AA
/
Pause/Stop, eject cassette: To stop the tape;If this key is depressed while in STOP, the cassette is then
P
+
ejected from the machine.
When tape playback is stopped, press to fast forward the tape at hight speed.
1
0
When tape playback is stoped, press to rewind the tape at hight speed.
Sockets on the front:
White socket / input socket: To connect a camcorder or video games (audio). Yellow socket / input socket: To connect a camcorder or video games (video).
AUDIO
VIDEO
Small socket / socket for headphones: To connect headphones.
Back of the set
Aerial input socket: To connect the aerial cable
EXT1/AV1
Scart socket :To connect a satellite receiver, decoder, video recorder, etc
Power switch: To switch the TV-Video Combi off.
Caution: If you switch off using the power switch, TIMER-recordings are impossible!
The control lights at the front of machine
STANDBY Standby light: lights up when the TV-Video Combi has been switched on by means of the main
switch. RECORD Recording light:lights up during recording.
Fast blink:recording pause; timer recording not stand-by. Slow blink: timer recording is stored in a timer block.
3
EN
Specifications
Voltage: 220-240V/50Hz Power consumption (Standby): less than 5W Rewind time: less than 260 seconds (cassette E-180) Number of video heads : 2 Recording/playback time: 3 hours (SP)
(cassette E-180)
Weight without packing in kg: 11.5 Dimensions in cm (HxWxD):40.0x37.3x38.0 Power consumption : 52W
Supplied accessories
• Operating instructions
• Remote control and batteries
1. Connecting the TV-Video Combi
3.If the little red standby light (STANDBY ) at
Preparing the remote control for operation
The remote control and its batteries are packed separately in the original TV-Video Combi pack­aging.You must install the batteries in the remote control before use.
1.Take the remote control and the enclosed bat-
1.
teries (2 batteries).
2.Open the remote control's battery compart-
2.
ment and place the batteries in it as shown in
the picture and close the battery compartment. The remote control is now ready to use. Its range is approximately 7 metres.
Connecting the cable
3.
the front panel of the set is not lit, please switch on the set using the main power switch.The power switch is located on the left side panel of the set.
4.Language setting picture will appear on the
4.
screen.
I do not see a Language setting picture
* Check the cable connections.
You can find more details in chapter 'Preparation for use'.
SELECTIONNER KL
FRANÇAIS
DEUTSCH NEDERLANDS
APP. MENU POUR CONTINUER
1.Insert the aerial cable plug into the AERIAL at
1.
the back of the TV-Video Combi.
2.Connect the mains cable to the wall socket.
2.
EN
Connecting additional devices
You can connect additional devices such as decoders, satellite receivers, camcorders, etc.to the EXT1 socket.
The respective scart socket is usually marked 'AV'
or 'TV'on the decoder or satellite receiver.
4
2. Important notes for operation
Switching on
You can switch on the TV-Video Combi with
STANDBY/ON
If you press , ,
PROG P–
yy
.
STOP C-LPLAYB-K REW0- sFWD 1- B
,
, or while
PROG P+
0..9
,
the set is in Stand-by, the power will be auto­matically turned on.
Note that the keys will be inactive for
0..9
about 5 seconds just after having switched the TV-Video combi off.
Power outage/no power
Channel information remains saved for up to 10 year, the time and timer information is saved for up to 1 minute.
Navigation in the screen menu
You can check/change many functions and set­tings of your TV-Video Combi via on-screen menu.The individual functions are selected, via the remote control as follows:
0..9
CLEAR
MENU
STOP C-LPLAYB-K
STOP C-LPLAYB-K
FWD 1- B
Call up the menu: with . To select: with .
To enter or change your selection: with the
number buttons or with .
To save or confirm: with . To cancel: with . To end: with .
STATUS/EXIT
SELECT KL CHOOSE B
TIMER
PICTURE CONTROL RECORD SET UP VCR SET UP TUNER SET UP GENERAL SET UP
END=EXIT
5
EN
