17 inch CRT Monitor 17 inch CRT Monitor
LightFrame™, lead-free design and
LightFrame™, lead-free design and
ideal size
ideal size
With LightFrame™ for the best-ever sharpness and brightness, ideal screen size, a high brightness
Real Flat CRT tube and lead-free design, this great 107P5 CRT adds vibrancy and excitement to the
professional multimedia experience.
Outstanding front of screen performance
• LightFrame™ delivers best-ever sharpness and brightness
• SXGA 1280 x 1024 resolution for sharper display
• Easy-on-the-eyes high-bright, high-contrast tube
• Real flat CRT for natural, distortion and glare-free display
• sRGB ensures color matching between display and printouts
Great convenience
• Compatibility with PC and Mac platforms
• Quick and easy-to-personalize on-screen-display controls
107P50
Green design
• Lead-free display protects your health and our environment
• Lower power consumption than the industry average
• TCO guarantees the highest safety and ergonomics standards
• Environmentally responsible Energy Star partner
• Flame retardant case safeguards the display from fire
Page 2
Commercial Specifications Product Highlights
Picture/Display
• Display Screen Type Real Flat Picture Tube
Panel Size 17"/ 41 cm
•
Phosphor P22
•
Recommended Display Area 310 x 230 mm
•
(12.2" x 9.0")
• Dot Pitch 0.25 mm
Horizontal Dot Pitch 0.21 mm
•
White Chromaticity, 5500º K x = 0.332 / y = 0.347
•
White Chromaticity, 6500º K x = 0.313 / y = 0.329
•
White Chromaticity, 9300º K x = 0.283 / y = 0.297
•
• Maximum Resolution 1600 x 1200 @ 75 Hz
Recommended Resolution 1280 x 1024 @ 85 Hz
•
Factory Preset Modes 11 modes:
•
640 x 350 @ 85 Hz, 640 x 480 @ 60 Hz,
640 x 480 @ 85 Hz, 720 x 400 @ 70 Hz,
800 x 600 @ 56 Hz, 800 x 600 @ 75 Hz
800 x 600 @ 85 Hz, 1024 x 768 @ 75 Hz,
1024 x 768 @ 85 Hz, 1280 x 1024 @ 75 Hz,
1280 x1024 @ 85 Hz
• Factory Preload Modes 29 modes
Video Dot Rate 250 MHz
•
Horizontal Scanning Frequency 30 - 97 KHz
•
Vertical Scanning Frequency 50 - 160 Hz
•
Recommended Refresh Rate 85 Hz
•
Screen Enhancements Anti-glare Polarizer,
•
Anti-reflection, Anti-static,
High Brightness,
High Contrast
• LightFrame™ Yes
• sRGB Yes
• GTF Yes
Connectivity
• Cables D-sub Video Cable,
Power Cord
• Sync Input Impedance (ohm) 4.7 k
• Video Input Impedance (ohm) 75
• Video Input Signal Levels 0.7 Vpp
• Video Sync Input Signal Separate Sync,
Composite Sync
• Video Sync Polarities Positive and Negative
• Cable Connection AC Power in
Accessories
• Included Accessories AC Power Cord
• Optional Accessories Multi-media Base
• User Manual Yes
Dimensions
• Depth (with base) 419 mm
• Height (with base) 410 mm
• Width (with base) 399 mm
• Temperature Range (Operation) 0°C to 40°C
• Temperature Range (Storage) -25°C to 65°C
• Weight 15.1 kg
Power
• Complies With Energy Star, NUTEK, E2000
• Consumption 70 W (Typical)
• Off Mode 1 W
• Power LED Indicator Off, Flashing Green;
Operation, Green
• Power Supply Built-in
LightFrame™
An intelligent and revolutionary technology for enhancing monitor's
brightness, sharpness, contrast, and color. Images enhanced by
LightFrame™ are lively, realistic, clear, attractive and colorful.
SXGA, 1280 x 1024 resolution
For graphics monitors, the screen resolution signifies the number
of dots (pixels) on the entire screen. For example, a 1280-by-1024
pixel screen is capable of displaying 1280 distinct dots on each
of 1024 lines, or about 1.3 million pixels.
High-bright, high-contrast tube
A CRT tube designed to increase display brightness and contrast
by increasing the CRT ray gun's beam current.
Real flat CRT display
Philips advanced flat CRT technology that minimizes glare while
reducing reflection and distortion, providing display quality superior
to that of conventional CRTs.
sRGB ready
Calibrated RGB that is optimized for the vast majority of computer
peripherals, monitors, operating systems and browsers, allowing
accurate color mapping with very little data overhead.
Two platform compatibility
The ability to work with a variety of platforms; Philips monitors are
compatible to connect with PC by employing a VGA connection
and connect with Macintosh.
OSD (On-Screen-Display control)
An on-screen panel for adjusting a monitor. The OSD is used for
contrast, brightness, horizontal and vertical positioning and other
monitor adjustments.
Lead free
Lead-free display products are designed and produced in
compliance with strict European Community Restriction of
Hazardous Substances (RoHS) standards that restrict lead and
other toxic substances that can harm health and the environment.
Energy efficiency
Reduction of the electrical power required to operate a device to
achieve real savings.
Convenience
• Convenience Enhancements Menu Languages,
On-screen Display
• Monitor Controls Brightness Direct Access,
Contrast Direct Access,
LightFrame Hotkey, Menu,
Power On/Off
• OSD Languages English, French, German,
Italian, Spanish, Portuguese,
Korean, Simplified Chinese
• Plug & Play Compatibility DDC 2B, sRGB,
Windows 95/98/ME,
Windows 2000/NT/XP
• Regulatory Approvals TCO'03, TÜV/GS,
TÜV Ergo, FCC-B,
UL, CSA, DHHS, SEMKO,
Poland-B sign, C-Tick,
CE Mark, BSMI, PSB,
NUTEK, Energy Star,
E2000
• Swivel +/- 90°
• Tilt -5° to 13°
TCO compliance
A TCO (Swedish confederation of Professional Employees) standard
even more stringent than MPR-II for safety and ergonomics,
especially concerning alternating electric fields (AEF).
Energy Star Partner
Power conservation requirements set forth by the Environmental
Protection Agency of the U.S. government.
Flame retardant case
A system of limiting accidental fires by engineering flame retardants
into the monitor's case.
Trademarks owned by Royal Philips Electronics
2004 © Royal Philips Electronics - All rights reserved
As an Energy Star partner, Philips has determined that
this product meets the Energy Star guidelines for
energy efficiency.
Microsoft and Windows are registered trademarks of
Microsoft Corporation.
All data subject to change without notice
Release date: November 2004, v.3
