Pfister BRB-F1KK User Manual [en, es, fr]
■BRB-F1■
Towel Ring
Toallero De Anillo
Anneau Porte-Serviettes
1-800-PFAUCET (1-800-732-8238)
• Installation Support
1-800-PFAUCET (1-800-732-8238) or visit www.pricepster.com
• Care and Warranty Information
Español:
Para obtener información mediante llamadas gratis,
llame al 1-800-PFAUCET
(1-800-732-8238) o visite www.pricepster.com
• Apoyo a instaladores
• Información sobre cuidado y garantías
07-01-10 EO7706B
Copyright © 2010, Price Pster, Inc.
For Toll-Free Pfaucet information call
Français:
Pour les renseignment concernant le service san
frais de Pfaucet, appelez 1-800-PFAUCET (1-800732 8238) appel ou visite www.pricepster.
• Assistance à l’installation
• Informations sur l’entretien et la garantie
A COMPANY
35541-0200
A B C
D
3
2
1
6
4
8
3
1
7
1
5
5
6
4
4
1
8
7
INSTALLATION:
A. Use Mounting Bracket (1) to determine a desired location. Use the Mounting Bracket Holes (2) to mark the
screw hole locations, as shown.
B. If installing into a stud, drill 1/ 8” holes and do not use the Anchors. If installing into drywall, drill two
1/4” holes (3) as shown. Insert Anchors (4) into the holes and tap ush with wall.
C.
Install Mounting Bracket (1) by using the screws (5) over the Anchors (4). Mounting Bracket (1) must be vertically
leveled.
D. Place the Mounting Post (6) over Mounting Bracket (1). Orient Mounting Post (6) so that the Ring (7) hangs
down. Secure by tightening Set Screw (8) onto Decorative Post (6). Do Not Over Tighten!
MAINTENANCE AND CARE
Cleaning Instructions:
For all handles and decorative nishes, use only a soft damp cloth to clean and shine. Use of polish, detergents, abrasive
cleaners, organic solvents, or acid may cause damage. Use of other than a soft damp cloth will nullify our warranty!
Special Trim:
Trim products which contain porcelain or other similar substances are not acceptable for public areas or commercial use.
Installation of said trim is at user’s risk!
2
