PRODUCTS HEATERS, THERMOSTATS AND HYGROSTATS
FLH 010–FLH 150
RADIANT HEATERS 10−150 W
FLH radiant heaters are used in combination with a thermostat
or hygrostat, predominantly for the avoidance of excessively
low temperatures or excessively high humidity in the control
cabinet. Different performance ratings from 10 to 150 Watts
ensure that the correct heating power is always available.
The total required heat can be distributed in a control cabinet
according to needs.
Available with either terminal or connecting cable.
PRODUCT FLH 010 FLH 015 FLH 030 FLH 045
ARTICLE NO. with terminal 17001005007 17001505007 17003005007 17004505007
ARTICLE NO. with cable 17001005017 17001505017 17003005017 17004505017
DATA
Heating performance (Ta = +20 °C) 10 15 30 45 W
Rated voltage
Functional range 110–250 V AC 50 | 60 Hz
Max. starting current 1.0 1.1 1.2 1.8 A
Max. surface temperature 55 65 90 105
Operating temperature –40 … +70
System of protection for intended
purpose of use
Protection class I
Device construction aluminium profile, brightly anodised
Type of mounting snap fastening for 35 mm profile bars according to EN 60715
Type of connection plug terminal connector | connecting cable (500 mm)
Weight 250 g
1
±10 %
IP 44 (connecting cable) and IP 20 (plug terminal connector)
AC 50 | 60 Hz
230 V
PRODUCT FLH 060 FLH 075 FLH 100 FLH 150
ARTICLE NO. with terminal 17006005007 17007505007 17010005007 17015005007
ARTICLE NO. with cable 17006005017 17007505017 17010005017 17015005017
DATA
Heating performance (Ta = +20 °C) 60 75 100 150 W
Rated voltage
Functional range 110–250 V AC 50 | 60 Hz
Max. starting current 2.5 4.5 5 7.5 A
Max. surface temperature 105 120 130 150
Operating temperature –40 … +70
System of protection for intended
purpose of use
Protection class I
Device construction aluminium profile, brightly anodised
Type of mounting snap fastening for 35 mm profile bars according to EN 60715
Type of connection plug terminal connector | connecting cable (500 mm)
Weight 450 510 770 g
1
other voltages availabale on request
1
±10 %
IP 44 (connecting cable) and IP 20 (plug terminal connector)
AC 50 | 60 Hz
230 V
Unit
°C
Unit
°C
ACCESSORIES
Thermostat 17111000000
Hygrostat 17207000000
Internal enclosure fan 18110000000
For additional models, options and voltages visit www.pfannenberg.com or contact us directly.
Dimensions
ARTICLE NUMBER
mm
X
Y1
Y2
Z
L
FLH 010 | 015 | 030 | 045 FLH 060 | 075 | 100 FLH 150
70 70 70
65 140 215
35 35 35
50 50 50
500 500 500
Z
X
Z
Y1
Y2
X
Y1
Y2
L
