P R O D U C T S E X S I G N A L I N G D E V I C E S
LED LIGHT
BExBG L1D ATEX
IP 67
protection system
The LED light is ideal for almost all mounting requirements: side, ceiling and floor mounting.
•Categories 2G (Zones 1 and 2), 2D (Zones 21 and 22).
•Large connection box for simple mounting.
•Also available with connection box in increased safety version.
•Very sturdy, manufactured from seawater-resistant aluminium and stainless steel protection cage.
•Can be mounted in all operating positions.
•A total of 9 different operating modes can be set.
•2 additional operating modes can be controlled externally.
+55 °C
–50 °C
operating temperature
PRODUCT |
|
BExBG L1D |
|
Rated voltage |
|
230 V |
|
|
|
||
|
AC 50 | 60 Hz |
||
|
|
|
|
|
|
|
|
Operating range |
|
±10 % |
|
|
|
|
|
Nominal current consumption |
|
70 mA |
|
|
|
|
|
Type of protection |
|
Ex d IP 67 |
|
Explosion protection 1 |
|
II 2G EEx d IIC T4 or T5 |
|
|
II 2G EEx de IIC T4 or T5 |
||
|
|
|
II 2D T135°C or T100°C |
Category (area of use) |
|
2G (Zone 1, 2) |
|
|
2D (Zone 21, 22) |
||
|
|
|
|
Certificate of conformity |
|
KEMA 01 ATEX 2006 X |
|
Testing body |
|
KEMA |
|
Light source |
|
32 LEDs |
|
Temperature class T |
|
T4 / T135°C @ Ta –50 °C ... +55 °C |
|
|
T5 / T100°C @ Ta –50 °C ... +40 °C |
||
|
|
|
|
|
|
|
|
Storage temperature |
|
–50 °C … +70 °C |
|
|
|
|
|
Relative humidity |
|
90 % |
|
|
|
|
|
Duty cycle |
|
100 % |
|
|
|
|
|
Service life of the light source |
|
>50,000 hrs |
|
|
|
|
|
|
|
lens |
glass |
|
|
|
|
Material |
housing |
die-cast aluminium, resistant to salt water, marine grade LM6, red (RAL 3000) |
|
|
|
|
|
|
protective cage and bracket |
stainless steel |
|
|
|
|
|
Type of connection |
|
1x 4 mm2 or 2x 2.5 mm2 |
|
Cable entry 1 |
|
2x M20, of which one open, optionally PG13.5 or 1/2" NPT |
|
Weight |
|
2.75 kg |
|
|
|
|
|
1 Ex cable gland not included |
|
|
|
DIMENSIONS
|
EEx d |
|
|
|
EEx de |
|
|
165 |
|
|
|
| <![if ! IE]> <![endif]>63 |
<![if ! IE]> <![endif]>75 |
|
|
<![if ! IE]> <![endif]>63 75 |
|
|
|
<![if ! IE]> <![endif]>226.5 |
|
|
<![if ! IE]> <![endif]>239.5 |
|
|
<![if ! IE]> <![endif]>151.5 |
|
<![if ! IE]> <![endif]>145 |
<![if ! IE]> <![endif]>164.5 |
|
|
30 |
30 |
|
|
|
|
|
mounting holes 3x Ø 7 |
|
|
CONNECTION DIAGRAM |
|
|
|
|
|
|
|
|
|
|
|
|
AC |
|
|
|
DC |
operation mode |
|
|
connecting terminals |
operation mode |
|
selection |
|
|
|
selection |
|
control
stage S2 and S3 control
stage S2 and S3
OPERATING MODES
Mode |
|
Internal |
External |
||
|
Stage 1 |
Stage 2 |
|
Stage 3 |
|
|
|
||||
|
|
|
|||
1 |
|
|
|
|
|
all on |
|
9 |
8 |
||
|
|
|
|
|
|
2 |
rotation 3 LED fast “ON” |
7 |
1 |
||
|
|
|
|
|
|
3 |
rotation 6 |
LED fast “ON” |
8 |
1 |
|
|
|
|
|
|
|
4 |
rotation 3 |
LED slow “ON” |
9 |
1 |
|
|
|
|
|
|
|
5 |
rotation 6 |
LED slow “ON” |
6 |
1 |
|
|
|
|
|
|
|
Modes |
Internal |
External |
||
Stage 1 |
Stage 2 |
Stage 3 |
||
|
||||
6 |
double flash 1 Hz |
9 |
1 |
|
|
|
|
|
|
7 |
single flash 2 Hz |
3 |
1 |
|
|
|
|
|
|
8 |
double flash 2 Hz |
3 |
1 |
|
|
|
|
|
|
9 |
alternating flash 1:1 2 Hz |
3 |
1 |
|
|
|
|
|
|
ARTICLE NO. |
BExBG L1D |
Lens colour |
230 V AC |
31151104000
Article numbers for other colours and voltages on request.
MANUFACTURER’S DECLARATION
We hereby declare that the explosion-protected means of alarm with the type designation BExBG L1D ATEX has been developed and manufactured in accordance with section 5.1.2 of EN 50014.
This declaration is based on compliance with the following regulations and standards:
94/9/EG |
CE conformity |
EN 50014 |
Electrical equipment for areas at risk of explosions – General requirements |
EN 50018 |
Pressure-resistant encapsulation “d” |
EN 50019 |
Enhanced safety “e” |
EN 50281-1-1 |
Electrical equipment for use in areas with combustible dust |
EN 60529 |
Types of protection by enclosure (IP code) |
89/336/EWG |
“Electromagnetic compatibility” |
The BExBG L1D ATEX LED light is approved for use in potentially explosive areas in Zones 1, 2, 21 and 22 as per 94/9/EU.
