PEUGEOT Elyseo, Elyseo 50cc, Elyseo 100cc Owner's Manual

Owners manual

50cc / 100cc

1

Information

Information.................................................................. 2-3

Equipement.................................................................... 4

Instrument panel ............................................................ 5

Switch............................................................................ 6

Petrol / Oil ..................................................................... 7

Battery / Fuse................................................................ 8

Lighting / Signalling ........................................................ 9

S tarting the engine....................................................... 10

Running / driving / Mission box / S park plug .................1 1

Braking / parking.......................................................... 12

Tyres ........................................................................... 13

Removing / Refitting front / rear wheel ........................ 14

Integrated.................................................................... 15

Transponder ................................................................ 16

S pecifications............................................................... 17

Information

You have just purchased a PEUGEOT scooter.
Thank you for the confidence that you have
shown in our company.

This guide describes how to control, use and perform
basic maintenance on your new PEUGEOT scoo­ter. As with all high technology machinery, you will
find it easier to control and you will obtain the best
results from your SCOOTER if you use it and
maintain it with care and attention. Your dealer will
advise and inform you and use his experience to
strictly respect the maintenance plan this is essential
to keep your scooter in perfect working condition.
Your PEUGEOT dealer knows all your scooter’s
special features. He has PEUGEOT original parts
and special tools to perform standard maintenance
on your scooter under optimum conditions.

Safety recommendations

The safety of a scooter depends on the care taken
by its driver.
Excessive speed is a decisive factor in many acci­dents.
Respect speed limits and never go faster than is
safe under the road conditions. Take care not to skid
on road marking lines. Always do a general check
before using your scooter to make sure that it can
be used safely. Traffic rules require that the driver
and his passenger wear a helmet. It is also
recommended that you wear gloves, an eye protec­tion and bright and visible clothes to increase safety .
A new Scooter driver should become familiar with
his scooter before starting to drive in traffic. A scoo­ter driver must signal his presence to other users
by:

- Switching on his lights when in motion

- Avoiding driving in places in which he is not

visible to other vehicles

- Driving carefully

Please take

the time to

read it

carefully.

- Taking special care at intersections, car park
entrances and exits, and slip roads. Your scooter is
designed for town use on the road only. Optional
luggage and briefcase carriers are designed to trans­port lightweight objects. Make sure that the weight
is distributed evenly and that loads are securely
fastened.

- Maximum Loads : 3 kg

Your scooter is designed to satisfy legal
requirements, please do not make any modifications
to it particularly to the exhaust.
Use only petrol, oil and lubricants tested and
recommended by PEUGEOT .

Maintenance recommendation

In order to keep your scooter in a safe and reliable
riding condition, do not modify it and only use gennine
PEUGEOT parts for maintenance and repair. Use
of other spare parts may detrimentel to your vehicle
If your scooter is involved in a crash, have the main
parts checked carefully , for example all parts making
up the frame,suspension and steering system. This
inspection will help to restore essential safety con­ditions.
It is recommended that you make a general check
after storing your scooter for an extended period of
time .

T o avoid injury , always make sure that the engine
is switched off and the scooter is stable on its
stand on a flat surface before performing any
maintenance operations.

Take your scooter to a Peugeot dealer to do any
repair work, checks, tune-ups, maintenance or to
obtain recommendations for use.
You have chosen a Peugeot scooter for its fine
technical qualities and for its attractive finish and
appearance.
The bodywork is made of plastic parts coated with
special paints making it easy to keep it looking as
good as new.
Cleaning consists of washing dirty parts with soapy
water or with a mild detergent, rinsing frequently with
clean water and drying with a chamois leather.
In general do not use high pressure cleaners or
solvents such as petrol or highly alkaline detergents.
Y ou can always call a Peugeot dealer if in doubt. He
will advise you about how to use maintenance
products or to repair scratched or grazed parts.

2

Inspection before the vehicle

leaves

What the buyer has to do.

To Check

- The fuel level

- The oil level in the tank

- The possible leaks

- The state of the tyres and their inflating

- The level of the brake fluid *

To check the smooth

working of

- The front and the back brakes

- The accelerator

- The front and back lightings

- The stop light and the indicators

- The horn

* According to the model

3

Protection of the environment

Fuel / Lubricant

- Use only unleaded fuel.

- Avoid to run out of fuel while driving.

- Use only the recommended lubricants

- Don´t use any additives for fuel or lubricants

Ignition

- In case of misfiring or loss of power, slow
down and cut off the engine as described.
Contact your local dealer when the problems
persists

Cutting off the engine

- Switch off ignition only when the engine runs
at idle speed.

Starting the engine

- In case of problems when starting the
engine, contact your dealer to have it checked.

Using your vehicle

- Avoid driving or stationing your vehicle on
flammable underground (e.g. dry leaves).

4

Equipement

- Battery housing

- Stand handle

- Saddle lock

- Rear brake : drum brake

- Kick pedal

- Stand lever

- Central stand with lever

- Side stand *

- Front disk brake

- hand glove box

- Right glove box

- Towing hook *

- Engine number

- Frame number

- Front brake lever

- Throttle

- Front brake fluid level

- Rear brake lever

- Bag hook *

- Ignition key

* According to the model

A
B
C
D
E

F
G
H

I
J
K
L

M
N
O
P
Q

R
S
T

B

A

H

G

D

E

F

J K

M

L

N

O R

I

T

S

C

Q

P

5

Instrument panel

- Headlight indicator light

- Oil warning light

Alert

If the oil alert indicator remains on while you are driving, you
must top up with oil quickly.

- Indicator light

- Antit theft warning light *

- Fuel level meter

Once the pointer has reached point , autonomy is about
20km.

- Speedometer

The needle shows the vehicle speed in km/h or mph.

- Digital clock

Battery-fed, the clock constantly displays hours and
minutes : the colon flashes on and off.

The month and the day are displayed when is pressed
sets the hour, minutes, month and days function

- (A) am

- (P) pm

press to select the function required

- Fuel reserve warning
light *

- Odometer

Shows the total distance travelled in kilometers.

* According to the model

C

A

B

C

A

B C

1
2

3
4

5

6

7

8

9

431 2

5 9 7

6

8
