Peripheral Electronics PGHTY1 User Manual
Expand Your Factory Radio
add
add
®
®
iPod
iPod
TOYOTA / LEXUS /
Owner’s
SCION
Manual
Owner’s Manual
Media Gateway
Media Gateway
PXAMG
PXAMG
PGHTY1
Peripheral Electronics®,
Peripheral Electronics®,
a division of AAMP of America™
a division of AAMP of America™
13160 56th Court Clearwater, Florida 33760
13160 56th Court Clearwater, Florida 33760
Ph. 866-788-4237
Ph. 800-477-2267 ext. 230
support@peripheralelectronics.com
support@peripheralelectronics.com
©2007 AAMP of Florida, Inc.
©2009 AAMP of Florida, Inc.
Rev. 2-5-09
Inst003
Table of Contents
Pages
1. Introduction 2
2. Precautions
3. Compatibility Notes
4. Dipswitch Settings
5. Installation
6. iPod
Operation 5-6
7. HD Radio Operation (if equipped) 7
8.
Selecting AUX Input
9.
Selecting Factory Satellite
(if equipped)
10. Troubleshooting
Warranty Info
11.
2
3
3
4
7
7
8
9
Peripheral Electronics®,
a division of AAMP of America™
13160 56th Court Clearwater, Florida 33760
Ph. 800-477-2267 ext. 230
support@peripheralelectronics.com
©2009 AAMP of Florida, Inc.
1
Media Gateway & Optional Add-ons
Factory Radio
Not Included
iPod
Not Included
Media Gateway Harness
Part #: PGHTY1
Media Gateway
Part #: PXAMG
(Sold with HDRT)
11Ft. iPod Cable
3Ft. HD Radio Cable
HD RadioTM Tuner
(sold separately)
Part #: HDRT
2
1. Introduction
Thank you for purchasing the Peripheral Electronics® Media Gateway. The Media
Gateway is designed to provide endless hours of listening pleasure from your
factory radio. To ensure that your iPod performs correctly with your radio, we
recommend that you read this entire manual before attempting installation of the
Media Gateway.
The Media Gateway allows connectivity for iPod and the HD Radio tuner (HDRT sold
separately), enabling full control of these devices from the factory installed radio.
It also retains original system features such as satellite radio and rear seat
entertainment (if equipped).
2. Precautions
UPDATING iPod FIRMWARE
For proper operation of the Media Gateway, your iPod must be updated with the most
recent version of rmware from Apple. This is done on your computer. To update the
software on the iPod go to: http://www.apple.com/ipod/download/.
Follow the directions on the website to complete the download. There is no charge for
this update.
PREVENTING DAMAGE TO YOUR VEHICLE OR IPOD.
To eliminate the risk of an electrical short, we recommend disconnecting the
vehicle’s battery prior to installation. If you do not feel comfortable making these
connections, we suggest you seek professional installation. We recommend that the
iPod be disconnected from the interface when the vehicle is not in use.
PROPER MOUNTING LOCATION
Securely install the interface in a location free from; heat, humidity, moving parts,
sharp metal edges or direct sunlight. We recommend securing the interface to a
suitable location using; double sided tape, VelcroTM or zip-ties.
3
3. Compatibility Notes
This section will inform you of the specic requirements for your factory radio
to be compatible with the Media Gateway. These notes will inform you of any
issues or circumstances that can affect the compatibility of our product with your
radio, audio system, or accessories. Not all Factory radios are compatible with
the Media Gateway. The Media Gateway will only work on models equipped with
the specications listed below. Please read and understand these notes before
proceeding:
Radio Requirements
Radios have a button labeled “SAT” or “AM/SAT”. This indicates that the
required connection is present on the rear of the head unit and that the radio has
the necessary functionality to operate the Media Gateway.
Please visit www.peripheralelectronics.com/apps
to verify your vehicle’s compatibility.
4. Dipswitch Settings
All 4 dipswitches MUST be set in the OFF (up) position for proper operation.
(Fig. A)
ALL VEHICLES
