Pentax IQZoom 105SDATE, IQZoom 105S User Manual
Specifications and Main Features
- Exposure control: Automatic programmed exposure control, from EV10 to EV17 at 38mm, EV14 to EV19 at 105mm the left ranges for both is Auto or Daylight-Sync mode (ISO 400).
- Flash: Comes with an integrated flash with a red-eye removal feature, and low light condition flash.
- Flash effective range: 0.65 to 8.2m (38mm), 0.65 to3.3m for 105mm or shutterspeed of 1/320 (using iso 400 film)
- Flash recycling time: 5 seconds based on tests performed
- Power source: 1-3V Lithium AA – CR-123A or equivalent
- Battery life: 15 rolls of 24 exposure film on average based on ratio of 1:15
- Size & Weight: 118.5mm by 69mm by 53.5mm and the weight without battery is 240g or 8.50 oz.
- Date Model: 2049 auto calendar is available and for crystal quartz control imprinting modes can be employed.
Frequently Asked Questions
Q: What type of film can I use with the Pentax IQ Zoom 105S?
A: This camera is for use with DX-coded films of ISO 25 to ISO 3200.
Q: How do I load film into the camera?
A: Insert the film cartridge after opening the back cover, take the film leader towards the take-up spool, close the back cover and let the camera wind the film to the first frame automatically.
Q: What steps do I take when the shutter fails to release?
A: Evaluate whether the main switch is on, battery has charge, or film has not finished.
Q: How autofocus feature works?
A: The Active infra-red autofocusing feature of the camera has a range of 0.65m (2.1ft) to infinity. Point the autofocus frame on your subject and it should work smoother.
Q: Is it okay to use the flash in bright daylight?
A: From the Daylight Sync shooting mode, yes. The flash will fire during dark and bright situations.
Q: On a date model, how do I input the correct date?
A: To change a year, month, day, hour, and minute, pull out the strap clamp’s protrusion and turn the SELECT and ADJUST buttons accordingly.
Q: What is the situation when battery gets depleted?
A: In case the battery is almost depleted, the LCD panel shows battery exhaustion warning signs and the shutter is locked.
