INTELLICHLOR®

SALT CHLORINE GENERATOR

MODEL IC15, IC20, IC40, IC60

INSTALLATION AND

USER’S GUIDE

IMPORTANT SAFETY INSTRUCTIONS

READ AND FOLLOW ALL INSTRUCTIONS

SAVE THESE INSTRUCTIONS

KEEP OUT OF REACH OF CHILDREN

CUSTOMER SERVICE / TECHNICAL SUPPORT

If you have questions about ordering Pentair Water Pool and Spa replacement parts, and pool products, please contact:

Customer Service and Technical Support, USA

8 A.M. to 7:30 P.M

Phone: (800) 831-7133

Fax: (800) 284-4151

Web site

Visit www.pentairpool.com or www.staritepool.com

Salt is an inherently corrosive material. While the levels of salt required for proper operation of the IntelliChlor Salt Chlorine Generatorr (SCG) are relatively low when compared to sea water and other salt solutions, placing any amount of salt in your pool increases the likelihood of corrosion or other deterioration of pool equipment and any surfaces used in and around your pool. Metal parts (including metal pools) and certain natural and man-made surfaces are particularly susceptible to corrosion and deterioration when used in and around salt water pools. Pentair Water Pool and Spa, Inc. (“Pentair”) does not represent or otherwise guarantee that the proper use of the (SCG) will prevent corrosion or other deterioration of pool equipment and any surfaces used in and around your pool. Consult your experienced pool professional, who should be able to advise you on the proper material selection, installation techniques for those materials, and the proper use, care and maintenance of those materials

for your specic pool type and location in order to minimize the corrosion and deterioration that is inherent in and

around salt water pools.

Sanford, North Carolina

Phone: (919) 566-8000

Fax: (919) 566-8920

Moorpark, California

Phone: (805) 553-5000 (Ext. 5591)

Fax: (805) 553-5515

All Pentair trademarks and logos are owned by Pentair or one of its global affiliates. Pentair Aquatic Systems®, IntelliChlor®, EasyTouch®, IntelliTouch®,

SunTouch

, Rainbow™ and Eco Select® are trademarks and/or registered trademarks of Pentair Water Pool and Spa, Inc. and/or its affiliated companies in the United States and/ or other countries. Unless expressly noted, names and brands of third parties that may be used in this document are not used to indicate an affiliation or endorsement between the owners of these names and brands and Pentair Water Pool and Spa, Inc. Those names and brands may be the trademarks or registered trademarks of those third parties. Because we are continuously improving our products and services, Pentair reserves the right to change specifications without prior notice. Pentair is an equal opportunity employer.

P/N 520589 Rev. N 2/2016

Contents

Important Warnings and Safety Instructions ................................................................................. iii - iv

Technical Support ....................................................................................................................................... ii

IntelliChlor Salt Chlorine Generator (SCG) Overview................................................................................ 1

IntelliChlor SCG Models .............................................................................................................................2

IntelliChlor SCG Control Panel and Cell Description.................................................................................. 2

System Components ..................................................................................................................................2

IntelliChlor SCG IC20, IC40, IC60 Power Center ....................................................................................... 3

IntelliChlor SCG IC15 Power Supply .......................................................................................................... 3

System Schematic Diagram .......................................................................................................................4

Install Chlorine/Bromine Feeders after the IntelliChlor SCG cell ...............................................................4

Loop Plumbing Diagram..............................................................................................................................5

IntelliChlor SCG Plumbing Diagram ...........................................................................................................5

Pool W ater Preparation ...............................................................................................................................6

Determining Pool Size (Gallons of Water in Your Pool) .......................................................................... 6

Determining Pool Size (liters of water in your pool) ............................................................................... 6

Section 1: IntelliChlor SCG Control Panel ..................................................................................7

Salt Level Status LEDs ...............................................................................................................................7

Status LEDs ................................................................................................................................................ 7

Sanitizer Output LED Indicators .................................................................................................................8

More and Less Output Buttons................................................................................................................... 8

Self-Cleaning ..............................................................................................................................................8

Section 2: Pool Water and Chemistry, Conditions and Precautions ........................................9

Pool Water Chemistry, Conditions and Precautions ...................................................................................9

Optimum Pool Water Conditions for Salt Water Pools (using the IntelliChlor Salt Chlorine Generator) ... 10

Covered Pools and Vinyl Liner Pool and Lowering Chlorine Output Levels .............................................. 10

Chlorine Testing ........................................................................................................................................11

What Type of Salt to Use .......................................................................................................................... 11

How Much Salt to Use? ............................................................................................................................11

Calculating the Saturation Index............................................................................................................... 12

TDS Factor ...........................................................................................................................................12

Langelier Saturation Index Factors .......................................................................................................12

How to Add Salt to the Pool...................................................................................................................... 13

Table 1. Approximate Pounds (Kg) of salt needed to obtain 3,400 ppm in pool ............................. 13

Table 2. Approximate amount of stabilizer (cyanuric acid) to obtain 40 ppm in pool ....................14

Section 3: Operating IntelliChlor SCG ...................................................................................... 15

Initial Start-up Period................................................................................................................................ 15

Operation.............................................................................................................................................. 15

Use of an external Pool Pump Timer is not required ............................................................................ 15

If you use a Pool Pump Timer .............................................................................................................. 15

Start-up Procedure (Super Chlorination) .................................................................................................. 16

Sanitizer Output Settings and Adjustments.............................................................................................. 16

Operating in Winter...................................................................................................................................16

General Recommendations ..................................................................................................................17

General Cautions..................................................................................................................................17

IntelliChlor Electronic Chlorine Generator Installation and User’s Guide

Contents

(continued)

Section 4: User Maintenance .................................................................................................... 18

Daily service ............................................................................................................................................18

Weekly service......................................................................................................................................... 18

Monthly Service ........................................................................................................................................ 18

Usage Hours Meter .................................................................................................................................. 19

Cleaning the IECG Cell Blades................................................................................................................. 19

Winterizing................................................................................................................................................ 20

Section 5: Installation ................................................................................................................21

Kit Contents .............................................................................................................................................. 21

Required T ools .......................................................................................................................................... 21

IntelliChlor “Dummy” Cell.......................................................................................................................... 22

Selecting Model Size - IntelliChlor Model IC20, IC40, IC60 .....................................................................22

Installing the IntelliChlor Cell Assembly................................................................................................... 22

Connecting the Cell Power Cable to the Power Center ........................................................................ 23

Connecting the Power Supply Cable to the IC15 Cell .......................................................................... 23

Connecting IC20, IC40, IC60 Power Center to IntelliTouch, EasyTouch or SunTouch System ............ 24

Connecting IntelliChlor Communication Cable (RS-485) ................................................................. 25

Connecting IntelliChlor to a SunTouch System ....................................................................................26

Wiring AC Power from IntelliChlor SCG and IntelliFlo to Automation Control System

(IntelliTouch, EasyTouch and SunTouch Automation Control System) ..................................................... 26

Section 6: Troubleshooting .......................................................................................................28

Table 1: Troubleshooting ..........................................................................................................................28

System Specifications - 110 VAC and 220 V A C Wiring ............................................................................ 30

220 VAC Basic System Wiring .............................................................................................................30

110 VAC Basic System Wiring .............................................................................................................31

IC15 SCG System Specifications and Wiring...............................................................................33

Customer Support

8 A.M. to 7:30 PM

Phone: (800) 831-7133 Fax: (800) 284-4151

Download the IntelliChlor Userʼs Guide (PDF)

http://www.pentairpool.com/pdfs/IntelliChlorOM.pdf http://www.pentairpool.com/pdfs/IntelliChlorIC15IG.pdf

IntelliChlor Electronic Chlorine Generator Installation and User’s Guide

iii

IMPORTANT WARNINGS AND SAFETY INSTRUCTIONS

SAVE THESE INSTRUCTIONS

Important Notice:

installation, operation and safe use of this product. This information should be given to the owner and/or operator of this equipment. When installing and using this electrical equipment, basic safety precautions should always be followed, including the following:

WARNING:IMPORTANT SAFETY INSTRUCTIONS PERTAINING TO A RISK OF

FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS. READ AND FOLLOW ALL INSTRUCTIONS.

Before installing this product, read and follow all warning notices and instr uctions which are included. Failure to follow safety warnings and instructions can result in severe injury, death, or property damage. Call (800) 831-7133 for additional free copies of these instructions, or obtain a copy of these instructions at:

http://www.pentairpool.com/misc/owners_manuals/sanitizers/IntelliChlor_Owners.pdf

WARNING: To reduce the risk of injury, do not permit children to use this product.

WARNING: CHLORINE GAS BUILDUP CAN OCCUR WITH IMPROPER WIRING: To reduce the risk of

personal injury the IntelliChlor wirded to the load side of the time clock, electronically controlled switch, or relay load side, so that it will receive power only when the pool pump is on. Otherwise, dangerous chlorine gas buildup can occur. The IECG should never be energized when the pool pump is OFF and water is not flowing through the unit.

WARNING: To reduce the risk of injury, service should only be personnel by a qualified pool service professional.

WARNING: Never operate the IIntelliChlor Salt Chlorine Generator (SCG) without proper flow or

water circulation. A build-up of flammable gases will result in hazardous conditions.

Attention Installer: This manual contains important information about the

Salt Chlorine Generator (SCG) Power Center must be installed on and

CAUTION - IntelliChlorSalt Chlorine Generator (SCG) is for use with permanently-installed pools and may also be used with hot tubs and spas if so marked. Do not use with storable or steel pools. A permanently-installed pool is constructed in or on the ground or in a building such that it cannot be readily disassembled for storage. A storable pool is constructed so that it is capable of being readily disassembled for storage and reassembled to its original integrity .

CAUTION - When using the IntelliChlor Salt Chlorine Generator (SCG) with an IntelliTouch®,

EasyTouch Power Center to the pump side of the relay located in the IntelliTouch, EasyTouch or SunTouch load center. This wiring method does not require a ground fault circuit-interrupter (GFCI) to protect the circuit. A green colored terminal (or a wire connector marked “G”, “GR”, “Ground” or “Grounding”) is provided within the terminal compartment in the Power Center transformer enclosure. To reduce risk of electric shock, connect this terminal or connector to the grounding terminal of your electric service or supply panel with a conductor equivalent in size to the circuit conductors supplying this equipment. The power supply must be interconnected with pool pump motor power source. This insures the SCG and pool pump will switch on and off together.

or SunTouch® Control System, always wire the IntelliChlor Salt Chlorine Generator (SCG)

IntelliChlor Electronic Chlorine Generator Installation and User’s Guide

IMPORTANT WARNING AND SAFETY INSTRUCTIONS

SAVE THESE INSTRUCTIONS

ARNING: When mixing acid with water, ALWAYS ADD ACID TO WATER. NEVER ADD

WATER TO ACID.

CAUTION - Use of chemicals other than those recommended ma y be hazardous. Even proper use of the

recommended chemicals can be hazardous. Follow the Chemical Manufacturer’s Instructions.

CAUTION - To reduce the risk of electric shock, install IntelliChlor Salt Chlorine Generator (SCG)

CAUTION - Install the IntellliChlor SCG a minimum of three (3) feet away from the heater outlet.

CAUTION - A solid copper, bonding conductor not smaller than No. 8 AWG (8.4 mm) should be

connected from the accessible wire connector on the unit to all metal parts of the swimming pool, spa, or hot tub structure and to all electrical equipment, metal conduit, and metal piping within five (5) feet (1.5 m) of the inside walls of a swimming pool, spa, or hot tub, when the unit is installed within five (5) feet of the inside walls of the swimming pool, spa, or hot tub.

Canada - Industry Canada (IC) - This device complies with RSS210 of Industry Canada. (1999) FCC Standard - 47 CFR Part 15, Subpart C (Section 15.247). This version is limited to chapter 1 to chapter 11

by specified firmware controlled in the U.S.A. Federal Communications Commission (FCC) - This de vice complies with P art 15 of the FCC Rules.

Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.

Interference Statement - This equipment has been tested and found to comply with the limits f or a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonab le protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. How ev er, there is no guar antee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

Note: Modifications not e xpressly approv ed by the party responsible f or FCC compliance could void the user’ s authority to operate the device.

a minimum of five (5) feet away from the inside wall of the pool.

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver .

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

CAUTION - The IntelliChlor IC15 Power Supply must be interconnected with pool pump motor power source. This ensures the IntelliChlor SCG and pool pump will switch on and off together. When the IntelliChlor SCG IC15 is installed in Europe. The IntelliChlor IC15 power supply fuses must ONLY be obtained from the manufacturer.

WARNING - The IntelliChlor IC15 Power Supply is only intended for use with the IntelliChlor SCG IC15 cell, DO NOT PLUG ANY OTHER INTELLICHLOR CELL INTO THIS POWER SUPPLY, SEVERE DAMAGE WILL RESULT.

IntelliChlor Electronic Chlorine Generator Installation and User’s Guide

IntelliChlor® Salt Chlorine Generator (SCG) Overview

The IntelliChlor Salt Chlorine Generator (SCG) uses a process known as electrolysis to produce chlorine gas which immediately dissolves into a solution to create Hypochlorite and Hypochlorous acid pool and spa water sanitizer from a low concentration of salt added to the pool water. Hypochlorite and Hypochlorous kill bacteria, oxidizes organic material, and kills algae, then reverts back to salt. The IntelliChlor SCG then reuses the salt and the process starts over again. The IntelliChlor SCG residential system is comprised of the IntelliChlor SCG cell and Power Center.

The IntelliChlor SCG is designed only to produce chlorine. The IntelliChlor SCG does not monitor or control

chlorine levels in the pool or spa water. It is the pool ownerʼs responsibility for monitoring and maintaining

free chlorine levels at the APSP recommended range of 2.0 to 4.0 parts per million (ppm). It is the pool

ownerʼs responsibility to check, on a regular basis, the free chlorine level while the pool pump is running, and

adjust the IntelliChlor SCG accordingly.

Salt is an inherently corrosive material. While the levels of salt required for proper operation of the IntelliChlor SCG are relatively low when compared to sea water and other salt solutions, placing any amount of salt in your pool increases the likelihood of corrosion or other deterioration of pool equipment and any surfaces used in and around your pool. Metal parts (including steel pools) and certain natural and manmade surfaces are particularly susceptible to corrosion and deterioration when used in and around salt water pools. Pentair Water Pool and Spa, Inc. (“Pentair”) does not represent or otherwise guarantee that the proper use of the IntelliChlor SCG will prevent corrosion or other deterioration of pool equipment and any surfaces used in and around your pool. Consult your experienced pool professional, who should be able to advise you on the proper material selection, installation techniques for those materials, and the proper use,

care and maintenance of those materials for your specific pool type and location in order to minimize the

corrosion and deterioration that is inherent in and around salt water pools.

FOR ALL NEWLY CONSTRUCTED OR RESURFACED PLASTER POOLS: Do not operate the IntelliChlor SCG with newly poured or resurfaced pool plaster. Salt is a corrosive element and severe salt damage

can occur to your pool. Wait at least ONE (1) MONTH after construction to allow plaster to cure before adding salt and operating IntelliChlor SCG. Follow the pool surface manufacturerʼs guidelines

for your specific pool. FOR NEW VINYL LINER POOLS, contact the manufacturer for recommended guidelines before adding salt and operating the IntelliChlor SCG.

IntelliChlor® SCG Models

An IntelliChlor Salt Chlorine Generator system consists of one or more of the following. Note: The cell will produce pure chlorine per 24 hours of continuous pool pump run time.

SU: e z i Sl ooP

) ret iL(. laG

l l eC5 1C I

888025N/ P( )

l l eC0 2C I

)455025N /P (

l l eC0 4C I

555025N/ P (

l l eC0 6C I

)501025N /P (

) 187 (000 , 517)2.0(06.0

) 57 (000 , 0)223.0(07.0

) 051 (000 , 0)446.0(04.1

) 722 (000 , 0)61. 0 (2

decudo rPen i r o l hC

4 2r e P) . gK( .sbL

r u oH

Note: IC15 cell includes Power Supply (P/N 520888).

IntelliChlor

PC100 (P/N 520556):

•

Power Center Kit (sold separately). Provides power and control communication to and from the IntelliChlor cell. Used for IC20, IC40 and IC60 IntelliChlor SCG cell.

•

IntelliChlor “pass-through” cell

(P/N 520588):

Salt Chlorine Generator Installation and User’s Guide

For new pool start-up.

IntelliChlor SCG Control Panel and Cell Description

The IntelliChlor SCG includes a control panel with buttons and LED indicators to control the IntelliChlor SCG and produce chlorine (see page 7). The IntelliChlor SCG measures the water temperature and salt level to produce chlorine at the defined output. If the salt level in the pool water is too low (red on salt display), the cell is turned off until salt is added to the pool. The SCG cell has a self-cleaning cycle which reverses the cell polarity, reducing calcium buildup. This feature turns the cell on and off at regular intervals to minimize calcium and scale buildup and further maximizes cell life (see page 15).

Control Panel status LEDs

Cell Union Coupling with o-ring (2x)

MORE and LESS output buttons

Water flow out

IntelliChlor® Salt Chlorine Generator (SCG) Cell

Internal Flow Switch

Cell Union Coupling with o-ring

Water flow in

System Components

The chlorine production can be varied by either adjusting the sanitizer output level on the control panel and/or by varying the number of hours the IntelliChlor SCG is on each day. The IntelliChlor

SCG automatically reverses the cell electrode blades every few hours to help clean the cell. This process does not interrupt the production of Chlorine.

• Flow Sensor: A flow sensor assures that there will always be adequate water flow through the IntelliChlor SCG. If the IntelliChlor SCG is not properly plumbed and/or does not receive adequate water flow, no chlorine will be produced.

• Temperature Sensor: To protect the IntelliChlor SCG from operation and potential damage when the temperature of the pool water falls below 52° F, ±3° F (11° C, ±1.67° C), the temperature sensor switches the IntelliChlor SCG off, illuminates the COLD WATER light and no chlorine will be produced.

• Salt Sensor: Two (2) salt sensor probes in the IntelliChlor SCG are activated each time the IntelliChlor SCG is switched on and again during every 12 hours of operation. At each of those times, the salt level LED indicator lights flash in a scrolling sequence for two (2) minutes to indicate that the IntelliChlor SCG is in analysis mode. After two (2) minutes, the LED indicators lights will signal one (1) of three (3) salinity ranges. For more information, see “Salt Level Status LEDs” on page 7.

Note: The salt sensor reading is within +/- 500 ppm accuracy.

IntelliChlor

Salt Chlorine Generator Installation and User’s Guide

IntelliChlor®SCG Power Center (IC20, IC40 IC60)

The IntelliChlor Power Center converts AC electrical current to a low-voltage DC electrical current which is required to produce chlorine. The power supply is connected with the pool circulation pump electrical source so that the IntelliChlor SCG only operates when the pool pump is on. The Power Center should be mounted vertically on the wall up to fifteen (15) feet away from the IntelliChlor SCG. The Power Center contains the transformer, fuse, connector to the cell and the AC electrical current wiring configuration with the DC electrical current output cable to the IntelliChlor SCG. A fuse is mounted on circuit board inside the enclosure for additional protection. There are no other controls or lights on the Power Center. For information about installing and proper use of the Power Center, see the “IntelliChlor Power Center Installation Guide,” (P/N 520590).

WARNING: CHLORINE GAS BUILDUP

CAN OCCUR WITH IMPROPER WIRING: To

reduce the risk of personal injury the IntelliChlor SCG Power Center must be installed on and wirded to the load side of the time clock, electronically controlled switch, or relay load side, so that it will receive power only when the pool pump is on. Otherwise, dangerous chlorine gas buildup can occur. The IntelliChlor SCG

should never be energized when the pool pump

is OFF and water is not flowing through the unit.

IntelliChlor SCG Power Center (Model PC 100). Used with IC20, IC40 IC60

CAUTION - Before plugging or

unplugging the IntelliChlor SCG to the Power Center, first switch off the AC power to the Power Center.

IntelliChlor SCG IC15 Power Supply

The IntelliChlor SCG IC15 Power Supply converts AC electrical current to a low-voltage AC electrical current which is required to produce chlorine. The Power Supply should be connected with the pool circulation pump electrical source so that the IntelliChlor SCG only operates when the pool pump is on. A 15 ft. cord connected to the IC15 unit plugs into the Power Supply which plugs directly into a 110VAC outlet. The Power Supply can be mounted vertically on the wall up to fifteen (15) feet away from the IntelliChlor SCG.. The Power Supply contains the transformer, fuse (1.5 AMP 250 V, 3 AG), connector to the cell and the AC electrical cord with plug. There are no other controls or lights on the Power Supply. The Power Supply must be connected to a GFCI protected outlet.

WARNING: CHLORINE GAS BUILDUP

CAN OCCUR WITH IMPROPER WIRING: To

should never be energized when the pool pump

is OFF and water is not flowing through the unit.

IntelliChlor SCG IC15 External Power Supply

CAUTION - First

switch OFF AC power to the Power Supply before plugging or unplugging the IntelliChlor IC15.

IntelliChlor

Salt Chlorine Generator Installation and User’s Guide

System Schematic Diagram

The following schematic diagram shows a typical IntelliChlor

Note: Refer to the relevant portions of this Installation and User’s Guide for information regarding proper placement and spacing of all equipment depicted in the schematic diagram shown below. The schematic diagram is not drawn to scale. .

SCG system installation.

Install Chlorine/Bromine Feeders after the IntelliChlor® SCG Cell

CAUTION

(such as Pentair Aquatic SystemsRainbow shown below. When using the IntelliChlor SCG with an in-floor cleaning system, it is recommended that a separate return line be used for the cleaner to reduce the increased water pressure stress on the IntelliChlor cell.

Pool pump and Power

center MUST be wired to

ON/OFF switch together.

24-hour pool pump timer,

switch or controller

115/230 VAC

electrical power supply

Chlorine/Bromine

- To avoid permanent damage to the IntelliChlor SCG cell, in-line chlorine/bromine feeders

(*) IntelliChlor

SCG

cell

Automatic

Feeder

models) MUST be installed AFTER the IntelliChlor SCG cell as

IntelliChlor SCG Power Center. Provdied VDC

electrical supply (see IntelliChlor SCG Power Center Installation Guide P/N 520590)















Heater **















To Drain (Backwash)

Filter





Not to scale

IntelliChlor





Return to Pool

From Pool

IntelliChlor SCG System Schematic Diagram

Salt Chlorine Generator Installation and User’s Guide





Pump

Note: For best flow

sensing, provide at least

12"-18" of straight pipe in

front of the cell inlet.

Note: (*) Install IntelliChlor SCG cell

vertically for best performance.

(**) The IntelliChlor SCG should

be at least three (3) feet away

from the heater outlet.

Loop Plumbing Diagram

The IntelliChlor® SCG is designed to operate with water flow rates from 25 +/- 5 gallons per minute (gpm) up to 105 gpm. Refer to the pipe manufacturer specifications for recommended maximum flow rate. For flow rates over 80 gpm you must use a bypass loop (as shown below) for best chlorine production. Installations with flow rates over 80 gpm include those that have in-floor cleaning systems or booster pumps. These systems MUST use a bypass loop with the IntelliChlor SCG with a flow control valve that assures that the flow through the IntelliChlor SCG is maintained within its designed operating water flow rates.

IntelliChlor SCG Cell

Not to scale

IntelliChlor SCG System Loop Plumbing Diagram

IntelliChlor SCG Plumbing Diagram

Plumbing the IntelliChlor® Salt Chlorine Generator:

• Always install the IntelliChlor SCG AFTER the filter and heater (see “System Schematic Diagram”

on page 4). The IntelliChlor SCG should be at least three (3) feet away from the heater outlet.

• If the IntelliChlor SCG is installed on a pool/spa combination system, install (see diagram below) the

IntelliChlor SCG BEFORE the pool/spa return valve to allow proper chlorination of both the pool and spa and also to avoid creating gas being traped in the pool plumbing.

Note: For best flow sensing, provide at least 12"-18" of straight pipe in front of the cell inlet.

IntelliChlor SCG System Plumbing Diagram

IntelliChlor

NOT TO SCALE

Salt Chlorine Generator Installation and User’s Guide

Note: Install IntelliChlor SCG cell vertically for best performance.

Pool Water Preparation

Determining Pool Size (Gallons of Water in Your Pool)

• Rectangular Pools: Length x width x average depth x 7.5

• Circular Pools: Diameter x diameter x average depth x 5.9

• Oval Pools: Length x width x average depth x 6.7

• Sloping Sides: Multiply total gallons by 0.85 = gallon capacity

Determining Pool Size (liters of water in your pool)

• Rectangular Pools: Length x width (meters) x average depth x 1000

• Circular Pools: Diameter x diameter x average depth x 785

• Oval Pools: Length x width (meters) x average depth x 893

• Sloping Sides: Multiply total liters by 0.85 = liter capacity.

CAUTION - Never use dry acid (sodium bisulfate) to adjust pH in arid geographic areas with

excessive evaporation and minimal dilution of pool water with fresh water. A buildup of byproducts can damage the IntelliChlor

SCG.

IntelliChlor

Salt Chlorine Generator Installation and User’s Guide

Section 1

IntelliChlor®SCG Control Panel

Salt Level Status LEDs

The IntelliChlor SCG checks the pool salinity water daily and displays the levels as follows:

Green LED: Good salt. The pool water salt level is between 2800



ppm and 4500.

Green LED (Flashing): Salt level is above 4500 ppm. The salt level is high which increases the risk of corrosion and deterioration of pool equipment and surfaces in and around the pool.

Red LED:



IntelliChlor SCG will be producing chlorine at reduced efficiency. It is highly recommended to add salt. See (*) Note below.

Red LED:

ppm. The IntelliChlor SCG will not produce chlorine until salt is added. The IntelliChlor SCG is OFF. See (*) Note below.

NOTE (*): After every salt addition, pump should be allowed to run for at least 24 hours for proper dilution. Salinity readings should only be taken, after the dilution period.

Status LEDs

Cold Water: Shows the IntelliChlor SCG power status:



Cell: Shows the status of the IntelliChlor SCG.



Flow: This light indicates the status of water flowing through the



IntelliChlor SCG.

Sanitizer Output LED indicators: See page 8.



Less / More Buttons:



Low salt.

The water salt level is below 2800 ppm. The



Very low salt

. The water salt level has fallen below 2600







• No Light: The IntelliChlor SCG is operating in the normal

temperature range (> 52° F (11° C)

• Red: The IntelliChlor SCG is in “Standby” mode (system off,

no chlorine production) due to a cold water condition. The IntelliChlor SCG will resume to normal operation mode, including accurate salinity report, once water temperature goes above 52° F (11° C).

• Green (flashing): The IntelliChlor SCG needs to be

inspected. The blades may have calcium buildup. The IntelliChlor SCG is not producing chlorine.

• Green: IntelliChlor SCG is good and producing chlorine

No Light: IntelliChlor SCG is off and not producing chlorine.

It may be in an off-period of the sanitizing cycle and will

return on shortly.

• Red: Insufficient water flow through the IntelliChlor SCG, no chlorine is being produced.

• Green: Sufficient water flow to produce chlorine.

Controls the percentage of the total output capacity that the IntelliChlor SCG is producing while the pump is on (see Sanitizer Output LED indicators above). See page 8.







SWIMMING POOL AND SPA CHLORINATOR

IntelliChlor

Salt Chlorine Generator Installation and User’s Guide

Operator Control Panel (continued)

Sanitizer Output LED Indicators

The five (5) LED indicators display as a bar graph to show the cell output in either 2% or 20% increments, the percentage of the total output capacity of chlorine being produced. Percentages from 2% to 10% are represented by blinking LEDs. Percentages from 20% to 100% are represented by solid LEDs. In BOOST mode, these LEDs scroll from left to right.

0% No LEDs lit - No chlorine produced - IntelliChlor SCG is off. 2% 1 LED blinking Produces chlorine for 64 seconds of every hour. 4% 2 LEDs blinking Produces chlorine for 127 seconds of every hour. 6% 3 LEDs blinking Produces chlorine for 16 seconds of each 5 minute period. 8% 4 LEDs blinking Produces chlorine for 21 seconds of each 5 minute period. 10% 5 LEDs blinking Produces chlorine for 27 seconds of each 5 minute period. 20% 1 LED solid Produces chlorine for 53 seconds of each 5 minute period. 40% 2 LEDs solid Produces chlorine for 106 seconds of each 5 minute period. 60% 3 LEDs solid Produces chlorine for 159 seconds of each 5 minute period. 80% 4 LEDs solid Produces chlorine for 212 seconds of each 5 minute period.

100% 5 LEDs solid Produces chlorine for 265 seconds of each 5 minute period.

More and Less Output Buttons

The More and Less buttons control the percentage of the total output capacity that the IntelliChlor SCG is producing while the pump is on (see Sanitizer Output LED indicators above).The lights act as a bar graph: the more lights that are on, the more chlorine is produced. Blinking LEDs represent 2%, 4%, 6%, 8% & 10% while solid LEDs represent 20%, 40%, 60%, 80% and 100%.Slide the panel cover up to access the More, Less and Boost On/Off buttons. Note: When an IntelliChlor is connected to an IntelliTouch®,EasyTouch® or SunTouch

Control System, the Less and More buttons are disabled and IntelliChlor SCG Sanitizer Output is controlled externally.

More: Increases the output of the cell in 2% increments up to 10% and then 20% increments. Example: The Sanitizer Output display is showing 8%. Pressing the MORE button once will blink the 10% light. The unit will produce chlorine at 10% of total capacity. Pressing MORE again will turn on the 20% light, and so on until all five (5) lights are on solid.

Less: Decreases the time the cell produces chlorine, in either 2% or 20% increments (from 20% to 100%). Example: The Sanitizer Output display is showing 40%. Pressing the LESS button once will turn off the 40% light, leaving only the 20% light. The unit will produce 20% of total capacity of the cell. Pressing LESS again will turn go to 10% (all 5 LEDs blinking).

Boost On/Off: Press both the More and Less buttons together to turn Boost mode on or off. Boost mode sets the sanitizer output to run 100% for the next 24 hours of pool pump run time. If the time clock switches off the pump cycle, then switches power back on the next day, Boost mode will continue until 24 hours has elapsed since Boost mode was turned on or Boost mode is canceled by the user. The Sanitizer Output display will scroll the output LEDs to indicate Boost mode.

Self-Cleaning

The self-cleaning feature reduces scale buildup on the blades of the IntelliChlor SCG. The self-cleaning cycle tends to reduce the life of the IntelliChlor SCG, therefore, it should be used only to the extent necessary to minimize the scale buildup on the blades. It is factory set to two (2) hours for the first 30 days of operation, then automatically switches to three (3) hours.

IntelliChlor

Salt Chlorine Generator Installation and User’s Guide

Section 2

Pool Water Chemistry, Conditions and Precautions

This section describes the start up procedure and operating instructions for IntelliChlor® SCG.

CAUTION: The use of dry acid (sodium bisulfate) to adjust pool pH is discouraged especially in arid regions where pool water is subject to excessive evaporation and is not commonly diluted with

fresh water. Dry acid can cause a buildup of by-products that can damage your chlorinator cell.

Pool Water Chemistry, Conditions and Precautions

1. New Pool Water: A recently filled or newly-refinished pool may contain undesirable matter. This undesirable matter could interfere with the IntelliChlor SCG’s ability to chlorinate properly. Make sure the water is tested by a pool professional and properly balanced before switching on the IntelliChlor SCG.

Salt is an inherently corrosive material. While the levels of salt required for proper operation of the IntelliChlor SCG are relatively low when compared to sea water and other salt solutions, placing any amount of salt in your pool increases the likelihood of corrosion or other deterioration of pool equipment and any surfaces used in and around your pool. Metal parts (including steel pools) and certain natural and manmade surfaces are particularly susceptible to corrosion and deterioration when used in and around salt water pools. Pentair Water Pool and Spa (“Pentair”) does not represent or otherwise guarantee that the proper use of the IntelliChlor SCG will prevent corrosion or other deterioration of pool equipment and any surfaces used in and around your pool. Consult your experienced pool professional, who should be able to advise you on the proper material selection, installation techniques for those materials, and the proper use,

care and maintenance of those materials for your specific pool type and location in order to minimize the

corrosion and deterioration that is inherent in and around salt water pools.

2. Super Chlorination burns out the swimmer waste that has combined with chlorine. This frees the chlorine for sanitizing. This is accomplished by raising the chlorine level quickly and dramatically. When the chlorine level is raised to ten (10) times the amount of combined chlorine the pool water is said to have been super chlorinated. As pool water is continuously passed through the IntelliChlor SCG while the unit is powered on, the water inside the IntelliChlor SCG is being super chlorinated.

Note: On initial start-up of a pool, it is best to super chlorinate using an outside source, i.e., use a shock treatment available at your local pool supplier.

3. Chloramines should not be present in pool water. Chloramines are formed when ammonia (which is found in urine and sweat) combine with free chlorine. This ties up the free chlorine in your pool and does not allow the chlorine in your pool to disinfect. Chloramines also burn the eyes and are foul smelling. Super Chlorinate to remove chloramines at the initial start-up of the pool and as needed to maintain proper levels of free chlorine.

4. Cyanuric acid is needed in outdoor pools to help to stabilize and maintain proper levels of chlorine. 90% of unstabilized chlorine is destroyed by the UV radiation from the sun within two hours. Cyanuric acid stabilizes chlorine in water from UV degradation. When using the IntelliChlor SCG, the cyanuric acid level should be maintained between 30-50 ppm. See Table 2, on page 13. NOTE: DO NOT USE CYANURIC ACID IN INDOOR POOLS.

5. Total Dissolved Solids (TDS): Adding salt to pool water will raise the TDS level. While this does not adversely affect the pool water chemistry or clarity, the pool water professional testing for TDS must be made aware salt has been added to the IntelliChlor SCG system. The individual performing the TDS test (see page 19) may then subtract the salinity level to arrive at a TDS level that would be compatible to a TDS reading for a non-salt water pool.

Continue on next page.

IntelliChlor

Salt Chlorine Generator Installation and User’s Guide

Pool Water Chemistry, Conditions and Precautions

6. Metals - Some metals, i.e. copper and iron, can cause loss of chlorine. Also, metals can stain your pool. Metals can also damage the IntelliChlor

SCG. Have your local pool professional check for

(Continued)

metals and recommend methods of removal.

7. Nitrates and Phosphates can cause extremely high chlorine demands and will deplete chlorine from your swimming pool. In some cases nitrates may even lower your chlorine levels to zero. Your local pool professional can test for nitrates and phosphates. While a 0 ppm level of nitrates is the ideal, the pool owner should make sure that nitrates DO NOT exceed 10 ppm. Phosphates should not exceed 125 parts per billion (ppb).

Optimum Pool Water Chemistry Conditions for Salt Water Pools

(using the IntelliChlor SCG)

In accordance with the Association of Pool and Spa Professionals (APSP) standards, it is recommended that the following pool water chemistry conditions be maintained on an on going basis to help protect pool users, pool related equipment and surfaces in and around the pool. These values are important to maintaining the pool equipment in proper operating condition and preventing corrosion. For more information, refer to your local agency having jurisdiction, NSPI (National Spa and Pool Institute), the CDC (Centers for Disease Control), or the WHO (World Health Organization).

Free Chlorine: 2.0 - 4.0 ppm. Above 4.0 ppm may cause corrosion of metal components

Combined Chlorine (Chloramines): None (super chlorinate to remove all chloramines)

pH: 7.2 - 7.8 (USE MURIATIC ACID to lower pH and Soda Ash to raise pH.)

Cyanuric Acid: 30 - 50 ppm

Total Alkalinity: 80 - 120 ppm

Calcium Hardness: 200 - 400 ppm

TDS (includes salt): 3000 minimum to 5700 to 6000 maximum ppm

Salt: 3600 - 4500 ppm (ideal 3600 ppm)

Metals (Copper, Iron, Manganese): None

Nitrates: None

Phosphates: Less than 125 ppb

Saturation Index -.3 to .3 (zero (0) best)

Covered Pools and Vinyl Liner Pool and Lowering Chlorine Output Levels

When using the IntelliChlor SCG with covered pools and/or vinyl liner pools, less chlorine is needed. It is recommend to lower the chlorine output level while the pool is covered. For more information about chlorine output levels, see “More or Less Output Buttons” page 8.

IntelliChlor

Salt Chlorine Generator Installation and User’s Guide

Chlorine Testing

It is recommended that chlorine test samples be taken from two (2) locations in the pool. Compare the samples. A higher level should be found at the pool return line. The higher level at the pool return line indicates the IntelliChlor® SCG is producing chlorine. Take chlorine samples for testing at:

• The pool return line.

• 18 inches (457 mm) below the surface and well away from the pool return line.

What Type of Salt to Use

Use salt that is at least 99.8% pure NaCl, sodium chloride. The preferred and recommended salt is an evaporated, granulated, food quality, non-iodized salt with no additives. Consult your salt supplier.

• Avoid using salt with anti-caking agents (sodium ferrocyanide, also known as YPS or yellow

prussiate of soda). Filling agents can cause some discoloration of fittings and surface finishes in pool.

• Water conditioning salt pellets are compressed forms of evaporated salt and may be used, but will

take longer to dissolve. Such pellets could damage pool plaster and other surfaces in and around the pool.

• Do not use calcium chloride or potassium chloride as a source of salt. (Use sodium chloride only).

• Do not use Rock salt (insoluble impurities mixed with the rock salt can shorten the life of the

IntelliChlor SCG.

How Much Salt to Use?

CAUTION - FOR ALL NEWLY SURFACED PLASTER POOLS: Do not operate the IntelliChlor SCG

with newly surfaced pool plaster. Salt is a corrosive element and severe salt damage can occur to your pool. Wait at least ONE (1) MONTH after construction to allow plaster to cure before adding salt and

operating IntelliChlor SCG. Follow the pool surface manufacturerʼs guidelines for your specific pool.

FOR NEW VINYL LINER POOLS, contact the manufacturer for recommended guidelines before adding salt and operating the IntelliChlor SCG.

Use Table 2 (page 14) to determine how much salt will be needed. Most pools contain some salt, depending on the water source and chemicals used for sanitizing. Therefore, the pool owner must always test salt levels before adding salt. A hand held meter calibrated for NaCl (salt) can be used to determine the salt levels of the water. After the IntelliChlor SCG is powered on, the LED salt level lights will blink from bottom to top for two (2) minutes while it analyzes the pool water, then the LED indicators will show one (1) of four (4) salt level ranges. See “Salt Status LEDs” on page 7 for more information.

• 3600 ppm of salt is recommended for optimum water condition.

• Low salt concentration below 2600 ppm will cause the unit to turn off

• High salt concentration above 4500 ppm may cause excessive corrosion or deterioration to pool

equipment and surrounding surfaces in and around the pool.

Note: Salt measurements will vary between measuring devices (salt test strips, electronic testers, and titration). The salt sensor reading is within +/- 500 ppm accuracy. For more troubleshooting information about high salt levels, see “Troubleshooting,” on page 28.

IntelliChlor

Salt Chlorine Generator Installation and User’s Guide

Calculating the Saturation Index

The saturation index is a formula that measures a solution ability to dissolve or deposit calcium carbonate and is used as an indicator of the corroosivity of the solution and temperature. A well balanced water will have a formula result ranging between -0.3 and +0.3 Outside this range, the pool water is considered out of balance, potentially damaging pool equipment or scaling the IntelliChlor SCG.

The equation to calculate Si is:

SI = pH + CHF + AF + TF + TDSF

Saturation Index

Cyanuric acid in the form of cyanurate ions contribute to alkalinity. Thus, a correction must be made to total alkalinity. We subtract 1/3 of the cyanuric acid level from the reading obtained in the total alkalinity test.

pH as tested

Calcium Hardness Factor

Alkalinity Factor

Total Alkalinity - 1/3 Cyanuric Acid = Corrected Alkalinity

This correction can be considerable in established pools with high cyanuric acid levels; for example, at 100 ppm cyanuric acid, the correction amounts to 33 ppm (100 ÷ 3 = 33.3).

Temperature Factor

TDS Factor

(Factors shown below are based on the actual measured value for the particular parameter)

TDS Factor

<1000 12.10 1000 12.19 2000 12.29 3000 12.35 4000 12.41 5000 12.44

Langelier Saturation Index Factors

Note: Use the reading closest to your actual reading in choosing the factor.

Total alkalinity in this context refer to the total of carbonate and bicarbonate alkalinity. If cyanuric acid is used, a correction factor must be used (see cyanuric acid Table 1 on page 13).

IntelliChlor

Salt Chlorine Generator Installation and User’s Guide

How to Add Salt to the Pool

CAUTION - FOR ALL NEWLY SURFACED PLASTER POOLS: Do not operate the IntelliChlor SCG with

newly surfaced pool plaster. Salt is a corrosive element and severe salt damage can occur to your pool. Wait at least ONE (1) MONTH after construction to allow plaster to cure before adding salt and operating

IntelliChlor SCG. Follow the pool surface manufacturerʼs guidelines for your specific pool. FOR NEW VINYL

LINER POOLS, contact the manufacturer for recommended guidelines before adding salt and operating the IntelliChlor SCG.

1. Check salt level in the water before adding any salt to pool.

2. Determine the amount of salt from the following chart.

3. Slowly pour the salt around the outer perimeter of the pool for quick and even distribution. To

avoid clogging the filter or damaging pool related equipment and surrounding surfaces, do not add salt through the skimmer or surge tank.

4. Brush the pool bottom and allow water to circulate for 24 hours to dissolve salt completely.

5. After 24 hours, verify correct salt level reading by checking the LED indicators on the IntelliChlor

SCG and by a separate reliable test method.

6. Power on the IntelliChlor

the appropriate free chlorine levels in the pool water (i.e., within the 2.0 - 4.0 ppm, APSP recommended range).

Table 1. Approximate amount of stabilizer (cyanuric acid) to obtain 40 ppm in pool

t n e r r uC

g000 , 01

d i cAc i r un ayC

) L000 , 83 (

mp p - l e v e L

)gk74.1(52.3 )gk77.1(09.3 )gk6.2(55.4)g k6 3.2(02.5)gk56.2(58.5)gk49.2(05.6)g k4 2 . 3(51 . 7)gk35.3(0 8.7)gk38 .3(54 . 8 )gk21.4(01.9)gk24.4(57.9

)gk01. 1(34.2)g k2 3.1(29.2)gk45.1(04.3 )gk67. 1(98.3 )gk89.1(73.4)gk02.2(68.4)gk24.2(53.5)gk46.2(38 .5)g k6 8. 2 (2 3.6)gk80.3(0 8.6)g k0 3.3(92.7

) gk37.0(26.1)gk88 .0(49.1)gk30.1 (72 . 2)gk71.1(95.2)g k2 3.1(29.2)gk74.1(42.3 )gk16.1(65.3 )gk67.1(98.3 )gk19.1(12.4)gk50.2(45.4)gk02.2(68.4

SCG and set the Sanitizer Output level to the proper setting to maintain

g000 , 21

g000 , 41

g000 , 61

g000 , 81

g000 , 02

g000 , 22

g000 , 42

g000 , 62

) L524 , 54 (

) L000 , 35 (

) L006 , 06 (

) L731 , 86 (

) L000 , 67 (

) L003 , 38 (

) L058 , 09 (

g000 , 82

) L124 , 89

g000 , 03

) L000 , 601

) L000 , 431 (

NOTE: The cyanuric acid reading should be maintained at 30 - 50 ppm.

See Table 2 (page 14) for approximate pounds (lbs) / kilogram (kg) of salt needed to obtain 3,600 ppm in pool.

IntelliChlor

Salt Chlorine Generator Installation and User’s Guide

POOL SIZE IN GALLONS

10,000 15,000 20,000 25,000 30,000 35,000 40,000 45,000 50,000 55,000 60,000

IntelliChlor

lbs 300.43 450.65 600.87 751.08 901.30 1051.52 1201.73 1351.95 1502.17 1652.39 1802.60

Kg 136.27 204.41 272.55 340.68 408.82 476.96 545.09 613.23 681.37 749.51 817.64

lbs 279.57 419.36 559.14 698.93 838.71 978.50 1118.28 1258.07 1397.85 1537.64 1677.42

Kg 126.81 190.22 253.62 317.03 380.43 443.84 507.24 570.65 634.05 697.46 760.86

lbs 258.71 388.06 517.41 646.77 776.12 905.47 1034.83 1164.18 1293.53 1422.89 1552.24

Kg 117.35 176.02 234.69 293.37 352.04 410.71 469.39 528.06 586.73 645.41 704.08

lbs 237.84 356.76 475.69 594.61 713.53 832.45 951.37 1070.29 1189.22 1308.14 1427.06

Kg 107.88 161.83 215.77 269.71 323.65 377.59 431.53 485.48 539.42 593.36 647.30

lbs 216.98 325.47 433.96 542.45 650.94 759.43 867.92 976.41 1084.90 1193.39 1301.88

Kg 98.42 147.63 196.84 246.05 295.26 344.47 393.68 442.89 492.10 541.31 590.52

lbs 196.12 294.17 392.23 490.29 588.35 686.41 784.47 882.52 980.58 1078.64 1176.70

Kg 88.96 133.43 177.91 222.39 266.87 311.35 355.83 400.30 444.78 489.26 533.74

lbs 175.25 262.88 350.51 438.13 525.76 613.39 701.01 788.64 876.26 963.89 1051.52

Kg 79.49 119.24 158.99 198.73 238.48 278.23 317.97 357.72 397.46 437.21 476.96

lbs 154.39 231.58 308.78 385.97 463.17 540.36 617.56 694.75 771.95 849.14 926.34

Kg 70.03 105.04 140.06 175.07 210.09 245.10 280.12 315.13 350.15 385.16 420.18

1,500

1,750

lbs 133.53 200.29 267.05 333.82 400.58 467.34 534.10 600.87 667.63 734.39 801.16

2,000

250

500

750

1,000

1,250

CURRENT

Salt Chlorine Generator Installation and User’s Guide

SALINIT

Table 2. Approximate pounds (lbs) / kilogram (kg) of salt needed to obtain 3,600 ppm in pool

Kg 60.57 90.85 121.13 151.42 181.70 211.98 242.26 272.55 302.83 333.11 363.40

lbs 112.66 168.99 225.33 281.66 337.99 394.32 450.65 506.98 563.31 619.64 675.98

Kg 51.10 76.65 102.21 127.76 153.31 178.86 204.41 229.96 255.51 281.06 306.62

lbs 91.80 137.70 183.60 229.50 275.40 321.30 367.20 413.10 459.00 504.90 550.80

Kg 41.64 62.46 83.28 104.10 124.92 145.74 166.56 187.38 208.20 229.02 249.84

lbs 70.94 106.40 141.87 177.34 212.81 248.28 283.74 319.21 354.68 390.15 425.61

Kg 32.18 48.26 64.35 80.44 96.53 112.62 128.70 144.79 160.88 176.97 193.05

lbs 50.07 75.11 100.14 125.18 150.22 175.25 200.29 225.33 250.36 275.40 300.43

Kg 22.71 34.07 45.42 56.78 68.14 79.49 90.85 102.21 113.56 124.92 136.27

lbs 29.21 43.81 58.42 73.02 87.63 102.23 116.84 131.44 146.04 160.65 175.25

Kg 13.25 19.87 26.50 33.12 39.75 46.37 53.00 59.62 66.24 72.87 79.49

lbs 8.35 12.52 16.69 20.86 25.04 29.21 33.38 37.55 41.73 45.90 50.07

Kg 3.79 5.68 7.57 9.46 11.36 13.25 15.14 17.03 18.93 20.82 22.71

3,500

3,250

2,250

2,500

3,000

2,750

LEVEL

Section 3

Operating IntelliChlor® SCG

This section describes the start up procedure and operating instructions for IntelliChlor® SCG.

Before starting up and operating the IntelliChlor SCG, the pool in which the IntelliChlor SCG will be used must have been completed and filled with water for at least one (1) month (for plaster pools) and the pool water salt level must be stable and being maintained at 3600 ppm.

Initial Start up Period

For the first thirty (30) days of cell operation, the self-cleaning cycle, is factory set to two (2) hours. After thirty (30) days has elapsed, the IntelliChlor SCG will automatically set itself to a three (3) hour self-cleaning cycle. This feature will clean the IntelliChlor SCG blades more often during the initial installation, then go to a more standard self-cleaning cycle for longer cell life.

Operation

IMPORTANT! Use of an external Pool Pump Timer is Required

The IntelliChlor SCG is designed to supply a sufficient amount of chlorine to sanitize pool water on a daily basis. If the pool pump is continuously running and the IntelliChlor SCG is operated 24 hours a day at 100%, more chlorine would be generated than would be needed by most pools (2-4 ppm, per APSP recommendations). The IntelliChlor SCG has its own internal timer which cycles the electrolytic cell on and off depending on what percent the Sanitizer Output is set. For instance, at 100% the cell works all the time while the pool pump is running. When set at 80%, the cell is allowed to rest 20% of the time while the pool pump is running prolonging cell life. In order to fine tune IntelliChlor SCG to your pool size just increase or decrease the Sanitizer Output from 20% to 100% of the time. For more information, see “More and Less Output Buttons,” on page 8.

CAUTION - The IntelliChlor SCG is designed to only produce chlorine. The IntelliChlor SCG does not

monitor or control chlorine levels in the pool or spa water. It is the pool ownerʼs responsibility for monitoring

and maintaining free chlorine levels at 2.0 to 4.0 parts per million (ppm) according to APSP

recommendations. It is the pool ownerʼs responsibility to check the free chlorine level while the pool pump is running on a regular basis, and adjust the Sanitizer Output on the IntelliChlor SCG accordingly.

CAUTION - Before attempting to operate IntelliChlor refer to “General Recommendations and General Cautions,” on page 17, and “Pool Water Preparation,” on page 6.

If you use a Pool Pump Timer

The Association of Pool and Spa Professionals (APSP) recommends that all water in a residential pool pass through the filtration system at least once every six (6) hours, four (4) turns every 24 hours (referred to as pool water turnover). However, many factors have an effect on actual pump and filter system run times. Pool size, source of water, direct sun light, indoor/outdoor, screened/unscreened, filtration system, cold or hot weather, swimmer load, rain, organic debris, algae, etc., are all factors which contribute to either more or less pool pump and filter system run times. Because of these differences, it is extremely difficult to set a standard initial run time (starting point) for the pool pump and chlorinating system.

IntelliChlor

Salt Chlorine Generator Installation and User’s Guide

If you use a Pool Pump Timer (Continued)

Try initially setting the pool pump timer to twelve (12) hours. It will take a few days to achieve the correct amount of pool pump operating time. When IntelliChlor

SCG is wired with a pool pump timer results will vary

greatly from one pool installation to the next, so this should be discussed with your pool professional. The key points are:

• Operate the pool pump at least the minimum time needed for good filtration and adequate chlorine production by the IntelliChlor SCG, according to your pool professional’s recommendations.

• While pool pump timers can reduce energy consumption, the pool pump must be running for the IntelliChlor SCG to provide chlorine and must remain running long enough to maintain proper chlorine levels (i.e., 2.0 - 4.0 ppm of free available chlorine).

Note: Exception - For Cold Weather Operation: The unit turns off in water temperatures of 52° F, ±3° F (11° C, ±1.67° C) and below, and will not produce chlorine. This feature extends the life of the cell.

Start-up Procedure (Super Chlorination)

Super Chlorination is recommended before pool start-up. Start out with clean, properly chlorinated, pool water from the beginning. The IntelliChlor SCG will build up a sufficient level of chlorine for sanitation in several hours. However, if the pool water has a high demand from the start-up the IntelliChlor SCG will not be able to produce enough chlorine to reach break-point chlorination. So, it is best to super chlorinate using an outside source at the time of pool start-up. Then, wait until the chlorine level has returned to 2.0 to 4.0 ppm before switching on the IntelliChlor SCG.

Sanitizer Output Settings and Adjustments

• Switch on the pool pump switch or pool pump timer. The salt display will blink both LEDs (bottom to top) for two (2) minutes, indicating that it has not checked the salt level yet. After two (2) minutes, the salt will be checked and one (1) of the salt level LEDs will be displayed. If the salinity is below 2600 ppm, the salt display will light the red LOW SALT indicator, and the CELL light will go blank, indicating there is not enough salt in the pool for chlorine to be produced.

• Set the Sanitizer Output to 60% by pressing the MORE or LESS button (see page 8).

• After 24 hours, use a reliable test method to test the pool water for free available chlorine. The ideal range to maintain is 2.0-4.0 ppm. If the free chlorine level of the pool water is too low,

increase chlorine production by pressing the MORE button. If the free chlorine level of the pool water is too high, decrease chlorine production by pressing the LESS button.

• Due to a varying free chlorine demand of pool water, it may take a few days to determine the number of daily pool operating hours and “Sanitizer Output” percentage setting (see page 8) for your pool. Continue adjusting as necessary, allowing 24 hours between adjustments until the free chlorine level of the pool water is stabilized at 2.0 - 4.0 ppm, per APSP recommendations.

Operating in Winter

The IntelliChlor SCG switches off and will not produce chlorine in water temperatures of 52° F, ±3° F (11° C, ±1.67° C) and below. This feature extends the life of the IntelliChlor SCG. See “Winterizing,” on page 20.

IntelliChlor

Salt Chlorine Generator Installation and User’s Guide

General Recommendations

• After new pool construction has been completed, before installing the IntelliChlor IntelliChlor “empty cell” (P/N 520588) to remove debris from the pipes for thirty (30) days and to allow sufficient time for the pool plaster (or other similar material) to properly cure and seal.

• Read and keep this Installation and User’s Guide in a safe place.

• Increase Sanitizer Output level as necessary after heavy rain (outdoor pools) and return to normal afterwards.

• Increase Sanitizer Output level when air and water temperature rise.

• Increase Sanitizer Output level when number of pool users increase.

• Use Cyanuric Acid ONLY as necessary to stabilize chlorine in the pool water in outdoor pools. NOTE: DO NOT USE CYANURIC ACID IN INDOOR POOLS.

• Once a month take a pool water sample to a pool professional for a complete analysis.

SCG, install the

General Cautions

• Do not get fertilizer in your pool. Fertilizers contain nitrates, which cause a high chlorine demand.

• Never use dry acid to adjust pH in arid geographic areas with excessive

evaporation and minimal dilution of pool water with fresh water. A buildup of byproducts can damage the IntelliChlor SCG.

• Do not add any pool water balancing chemicals (including salt) unless the

IntelliChlor SCG is switched off.

• Do not let the Cyanuric Acid level drop below 30 ppm in outdoor pools. NOTE: DO NOT USE CYANURIC ACID IN INDOOR POOLS.

IntelliChlor

Salt Chlorine Generator Installation and User’s Guide

Section 4

User Maintenance

This section describes how to maintain the IntelliChlor® SCG.

Daily service

None is needed.

Weekly service

pH Level Test:

according to your pool professional’s recommendations. APSP’s recommended ideal range for pH is

7.4 to 7.6, although 7.2 to 7.8 is an acceptable range under APSP’s guidelines.

Note: Never use dry acid (sodium bisulfate) to adjust pH in arid geographic areas with excessive evaporation and minimal dilution of pool water with fresh water. A buildup of byproducts can damage the IntelliChlor SCG.

Total Alkalinity Test:

2. according to your pool professional’s recommendations. APSP’s recommended ideal range for total alkalinity is 80 to 120 ppm.

Chlorine Test:

3. ideal range by adjusting the IntelliChlor SCG Sanitize Output settings. See “More and Less Output Buttons,” on page 8.

• Desired Free Chlorine is 2.0-4.0 ppm, per APSP recommendations.

Test the pH level of your pool water with a reliable test method. If necessary, adjust

Test the pool water for total alkalinity with a reliable test method. Adjust

Test the pool water the for free chlorine level with a reliable test method. Maintain

Note: Above 4.0 ppm of chlorine may cause excessive corrosion of metal components and possibly cause damage to associated pool equipment.

Note: It is recommended that free chlorine readings be taken from samples of pool water taken from two (2) places, one at the pool return line, the other well away from the pool return line. Compare the test results. A higher free chlorine level should be found at the pool return line. The higher free chlorine level at the pool return line indicates IntelliChlor SCG is producing chlorine.

Monthly Service

To ensure that the correct chemical balance is maintained in your pool, it is important to perform the following recommended salt and pool water tests every month using a reliable test method.

Salt Level Test:

and is not flashing.

• If the red LOW LED salt light is on. Add salt to the pool water (see charts beginning on

page 13).

• If salt level does not rise after 24 hours, see “Troubleshooting,” page 28.

Pool Water Sample:

IntelliChlor

Salt Chlorine Generator Installation and User’s Guide

Check salt display lights on the unit and check that the green “GOOD” light is on

Take a sample of the pool water to your local pool store for testing.

Monthly Service

Cyanuric Acid:

(Continued)

Sample the pool water and test for cyanuric acid level using a reliable test method.

When using the IntelliChlor SCG the recommended ideal cyanuric acid level is 30-50 ppm.

Calcium Hardness:

Test pool water for calcium hardness level using a reliable test method. If necessary, adjust according to your pool professional’s recommendations. APSP’s recommended ideal range for calcium is 200 to 400 ppm for pools.

Metals Test:

It is recommended that the pool water be sampled and tested periodically for the presence of metals such as copper, iron, and manganese. These metals can damage the IntelliChlor SCG and other related pool equipment and should not be present in the pool water. If those metals are present, contact your pool professional.

TDS (Total Dissolved Solids):

Test pool water for TDS level using test kit or by having a water sample tested by a pool professional. If necessary, adjust according to your pool professional’s recommendations. APSP standard of 3000 minimum to 5700 - 6000 maximum ppm (which includes the salt) is recommended for salt pools.

IntelliChlor SCG Usage Hours Meter

The IntelliChlor® SCG provides a built-in cell “usage hours” meter that reports how many hours IntelliChlor has been operating. The IntelliChlor SCG is designed to operate for approximately 10,000 hours before replacement is needed or roughly five (5) years of average use.

To access the system status mode:

1. Press and hold the MORE button for three (3) seconds until the lights scroll across the unit.

2. One (1) of the five (5) Sanitizer Output LED indicators (20%, 40%, 60%, 80% and 100%) will be lit, indicating the hours of usage. The Output LEDs are as follows:

• 2000 hours (20% LED on)

• 4000 hours (40% LED on)

• 6000 hours (60% LED on)

• 8000 hours (80% LED on)

• 10,000 hours (100% LED on)

Cleaning the IntelliChlor SCG Cell Blades

Note: Before acid washing, remove the calcium buildup in cell: Use a garden hose on the jet setting and spray directly into both ends of the cell. Most of this calcium buildup has a slushy consistency and will be blown out of the cell. Once the majority of the calcium has been removed, continue with acid washing which will now be more effective since most of the calcium has been removed.

1. Automatic Cleaning: The IntelliChlor SCG has an automatic cell blade cleaning feature (cell reversing) that helps remove scale deposits from the IntelliChlor SCG blades. Note: Automatic cleaning does not interrupt chlorine production. “Scale” is a white crusty deposit that forms in excessively hard water or from pool water that is out of balance and in a scaling condition. If the IntelliChlor SCG blades show excessive scaling, you need to perform an acid wash cleaning. Proceed to “Acid Wash Cleaning,” Step 2.

2. Acid Wash Cleaning: If the IntelliChlor SCG blades show a tendency to scale, it is recommended that every two (2) months the IntelliChlor SCG be removed and inspected for scale formation and/or debris on the IntelliChlor SCG blades. High hardness areas may require more frequent cleaning. Some filters allow debris to pass through to the IntelliChlor SCG, possibly lodging between the blades in the IntelliChlor SCG. A small amount of scale formation is normal. If by looking through the IntelliChlor SCG it is observed that there is excessive scale formation between the blades or debris is present, the IntelliChlor SCG must be cleaned as follows:

a. Use a high-pressure jet of water from a garden hose. If the blades cannot be reasonably cleaned in

this manner, acid cleaning is necessary.

IntelliChlor

Salt Chlorine Generator Installation and User’s Guide

Cleaning the IntelliChlor® SCG Blades

(Continued)

b. To acid clean the IntelliChlor SCG blades: Disconnect the AC power from the Power Center.

Disconnect the IntelliChlor SCG cell communication cable from the Power Center.

c. Mix one (1) quart of muriatic acid with one (1) gallon of tap water in a plastic bucket.

Working with muriatic acid can be dangerous. When cleaning the IntelliChlor SCG always wear rubber gloves and eye protection. Always add acid to water, do not add water to acid. Always work in a well-ventilated area. Splashing or spilling acid can cause severe personal

injury and/or property damage.

Note: The IntelliChlor SCG acid cleaning kit (P/N 520670) provides a cap for the IntelliChlor SCG to allow diluted acid solution to be poured into the IntelliChlor SCG to immerse the blades for cleaning.

d. Screw the cap with washer and o-ring onto the threaded end of the IntelliChlor SCG cell (the cap, o-

ring and washer are provided with the cleaning kit). Place the Intellichlor SCG vertically in a five

(5) gallon bucket. Pour the acid solution (as described in step c) into the IntelliChlor SCG until the cell blades and salinity probes are just covered. Allow the acid solution to bubble, and to clean the blades. Note: The acid should only be contained inside the IntelliChlor SCG covering the blades.

Try not to spill the acid on the outside of the IntelliChlor SCG. If acid does spill on the outside of the IntelliChlor SCG, wash it off with water. A foaming action will begin, which is caused by scale

(calcium carbonate) being dissolved from the blades. If rigorous foaming action does not begin, the blades do not need to be cleaned (STOP THE CLEANING PROCESS - go on to step “e).

Otherwise, allow the blades to remain immersed in the solution until the foaming has stopped. However, do not leave acid in the IntelliChlor SCG for more than thirty (30) minutes. Excessive acid washing will damage the blades.

e. Remove the IntelliChlor SCG from the bucket and place in an empty five (5) gallon bucket. Rinse

the inside and outside of the IntelliChlor SCG thoroughly with clean tap water and inspect. If deposits are still visible, repeat the acid cleaning process.

f. Rinse the IntelliChlor SCG again with clean tap water and inspect. Once clean, replace the

IntelliChlor SCG and resume normal operation.

g. If the acid wash procedure is necessary, it is recommended that a sample of pool water be analyzed

by a pool professional for excessive calcium hardness (i.e. ideal range is 200 to 400 ppm) and/or improper water balance.

h. Inspect the inside of the IntelliChlor SCG every two (2) months (or more frequent in hard

water areas). If no scale or debris deposits are observed inside the IntelliChlor SCG after four (4) months, it is not necessary to continue inspections every two (2) months. However, due to possible changes in pool water chemistry and filtering effectiveness, it is recommended that the cell be removed for inspection at least twice a year.

i. Reconnect the IntelliChlor SCG communication cable plug in the Power Center, then reconnect AC

power to the IntelliChlor SCG Power Center.

Winterizing

Very little chlorine production is needed in cold water so long as free chlorine levels are maintained at 2.0 - 4.0 ppm. The IntelliChlor SCG will not produce chlorine below 52° F ±3° F (11° C, ±1.67° C). This lowtemperature cutoff extends the life of the cell. If preventative measures are not taken, freezing water may cause severe damage to the cell. Prevent freeze damage to the cell by running the pool pump continuously or winterize the pool by draining water from pump, filter, and all intake and return lines. Remove the cell, clean and store it.

IntelliChlor

Salt Chlorine Generator Installation and User’s Guide

Section 5

Installation

This section describes how to install the IntelliChlor® SCG into the pool plumbing system. Also, included are connection instructions for IntelliTouch, EasyTouch and SunTouch systems. Before installing, review the IntelliChlor kit contents and required tools.

Note: For Power Center installation instructions, see the “IntelliChlor Power Center Installation Guide” (P/N

520590).

Note: Salt is not provided. For details about the type of salt to use, see “What Type of Salt to Use,” on page 11.

Note: A TIME CLOCK must be used if the IntelliChlor SCG is used in “stand alone” mode without an automation control system.

Kit Contents

- One IntelliChlor SCG cell

- Two (2) cell unions with two (2) o-rings

- Userʼs Guide (this manual)

Required Tools

- Tape measure

- Phillips and flathead screwdriver

- Pliers

- Hacksaw

- An NSF

approved all purpose PVC/CPVC/ABS cleaner primer

- An NSF

approved all purpose PVC/CPVC/ABS cement

When using electrical products, basic precautions should always be followed, including the following:

•

DANGER: RISK OF ELECTRIC SHOCK, WHICH CAN RESULT IN SERIOUS INJURY OR DEATH.

Before attempting installation of service, ensure that all power to the circuit supplying power to the system is disconnected/turned off at the circuit breaker. It is recommended, but not mandatory that the IntelliChlor Power Center be connected to a circuit protected by a ground fault circuit-interrupter (GFCI).

• Grounding (earth bonding) is required. The unit should be installed by a qualified service person and grounded.

• Install to allow access to cell buttons and power center.

• Read Safety Precautions and Important Instructions (page ii and iii). Before attempting any

electrical wiring, be sure to read and follow Safety Instructions. Wiring should only be performed by a qualified professional.

• Install the IntelliChlor unit a minimum of three (3) feet away from the heater outlet.

• Pipe couplings: Schedule 80, maximum pressure 75 psi at 70° F (21° C).

• Note: Operate unit with minimum flow of 25 gpm. For high flow applications, use a bypass loop (see

page 4) for best flow sensing.

• Note: Provide at least 12"-18" of straight pipe in front of the cell inlet.

IntelliChlor

Salt Chlorine Generator Installation and User’s Guide

IntelliChlor® SCG “Dummy” Cell

After new pool construction has been completed, in order to prevent debris from entering the IntelliChlor SCG, it is recommended that the IntelliChlor SCG “pass-through” cell (P/N 520588) be installed before installing the IntelliChlor SCG. After the pool system has flushed the debris from the pipes, remove the “dummy cell” and install the IntelliChlor SCG.

Selecting Model Size (see chart on page 1)

Installing the IntelliChlor SCG Cell Assembly

Install the IntelliChlor cell assembly no closer than three (3) feet away from the heater outlet, if used. For more information see plumbing diagrams on page 4 and 5.

Note: For best flow sensing, provide at least 12"-18" of straight pipe in front of the cell inlet.

Note: After new pool construction has been completed, in order to prevent debris from entering the

IntelliChlor cell assembly, it is recommended that the IntelliChlor SCG pass-through cell (P/N 520588) be installed before installing the IntelliChlor SCG cell. After the pool system has flushed the debris from the pipes, remove the pass-through cell and install the IntelliChlor cell.

Note: Pipe couplings: Schedule 80, maximum pressure 75 psi at 70° F (21° C)

To install the IntelliChlor® SCG Cell:

1. Using PVC glue, mount the PVC couplings to the plumbing pipe. Allow the glue to dry.

2. Mount the cell vertically. Allow access to the cell operator control panel. Install the cell onto the couplings. Ensure the O-rings are seated properly.

3. Switch on the pump and visually inspect for leaks around the couplings.

IntelliChlor

Cell Union Coupling with o-ring (2x)

Water flow out

Salt Chlorine Generator Installation and User’s Guide

Cell Union Coupling with o-ring (2x)

Water flow in

Connecting the IntelliChlor IC20, IC40 IC60 SCG Cell Power Cable to the Power Center

After the cell installation is completed, connect InitelliChlor SCG cell’s power cable to the Power Center:

WARNING - Switch OFF main system power to the Power Center before making any connections.

1. Be sure that AC power is switched OFF before connecting the power cord to the Power Center.

2. Align the four (4) pins of the cell power cord connector with the socket on the bottom of the Power Center and insert the connector. Turn the round socket nut until it locks the connector in place.

Connector socket nut.

To cell assembly

Connecting the Power Supply Cable to the IC15 SCG Cell

WARNING - Switch OFF main system power to the Power Supply before making any connections.

After the IC15 cell installation is completed, connect the cell power cable to the Power Supply:

•

Align the four (4) pins of the cell power cord connector with the socket on the side of the Power

Supply and insert the connector. Turn the round socket nut until it locks the connector in place.

IntelliChlor SCG Power Supply socket

IntelliChlor SCG IC15 Power Supply

IntelliChlor

Salt Chlorine Generator Installation and User’s Guide

Connecting the IntelliChlor® IC20, IC40 or IC60 SCG Power Center to an IntelliTouch

To operate IntelliChlor SCG with the IntelliTouch, EasyTouch or SunTouch system, connect a four wire cable from the IntelliChlor SCG Power Center to the IntelliTouch, EasyTouch or SunTouch load center. Note: Only one IntelliChlor cell can be installed per system. An alternate connection can be made by splicing anywhere along the four wire connection that connects the IntelliTouch or EasyTouch Control System indoor control panel to the load center.

Note: See the following manuals for IntelliChlor SCG operating instructions when connected to a Pentair Control System:

CAUTION - Wire the Power Center AC to the filter pump relay on the LOAD SIDE for maximum safety.

To connect IntelliChlor Power Center four wire cable to the IntelliTouch, EasyTouch or SunTouch Control System load center:

1. Remove the cover screw securing the Power Center cover. Remove the cover.

2. Run a UL approved four conductor cable (22 AWG) from the IntelliChlor Power Center to the Load

3. Remove the cover screw securing the Power Center cover. Remove the cover.

4. Remove one (1) of the knockouts from the underside of the Power Center.

5. Route the four conductor cable up through the lower hole.

6. Strip back the cable conductors 1-1/4 in. Insert the wires into the screw terminals (provided in the

7. Plug the screw terminal onto the four (4) pins located on the Power Center board.

8. Reinstall the cover and secure with the cover screw.

9. Proceed to “Connecting IntelliChlor to an IntelliTouch Control System,” on page 25, “Connecting

, EasyTouch® or SunTouch® Control System

- IntelliTouch Control System User’s Guide (P/N 521075)

- EasyTouch Control System User’s Guide” (P/N 521044)

- SunTouch Control System User’s Guide” (P/N 520785)

WARNING - Switch OFF main system power to the Load Center before making any connections.

Center. The preferred wire color scheme is red, yellow, green, and black.

kit). Secure the wires with the screws. Make sure to match the color coding of the wires: Red = +15, Yellow = +DT, Green = -DT, and GND = Black.

IntelliChlor to an EasyTouch Control System,” on page 26, and “Connecting an IntelliChlor SCG to a SunTouch Control System,” on page 26.

IntelliChlor

IntelliChlor SCG Power Center (cover removed)

Conduit knockout

Salt Chlorine Generator Installation and User’s Guide

Screw terminal

1DNGKLB

2TD-NRG

3TD+LEY

4V51DER

Screw terminal pin-outs

BLK GRN YEL RED

Personality board

(Connector J7 or J8)

WARNING - Switch OFF main system power to the Load Center before making any connections.

Connecting IntelliChlor®SCG Communication Cable (RS485):

1. Unlatch the load center/power center enclosure door spring latch, and open the door.

2. EasyTouch

/ IntelliTouch® Control System: Loosen the two (2) retaining screws from the control

panel.

(a) Lower down the control panel on its hinges to access the motherboard located behind the control panel.

(b) Route the four conductor cable up through the low voltage raceway in the load center to the motherboard.

Note: For SunTouch

Control System see page 26 for details.

3. Strip back the cable conductors ¼ in. Insert the wires into the connector screw terminals (provided in the kit). Secure the wires with the screws. Make sure to match the color coding of the wires; Red = +15, Yellow = +DT, Green = -DT, and GND = Black.

4. Insert the connector screw terminal onto the COM Port pins on the circuit board: (EasyTouch J20, IntelliTouch J7/8).

7. When the connection is completed: EasyTouch/IntelliTouch: Close the control panel and secure it with the two (2) retaining screws.

8. Close the load center front door. Fasten the spring latch.

COM PORT

(J20)

Indoor Control Panel IntelliChlor IntelliFlo RF Transceiver

EasyTouch Control System Circuit Board

Note: EasyTouch or IntelliTouch Control System Load Center

For information about connecting an IntelliChlor SCG to an EasyTouch or IntelliTouch Control System Load Center with built-in IntelliChlor SCG power supply, please refer to the EasyTouch or IntelliTouch Pool and Spa Control System (with optional IntelliChlor Salt Chlorine Generator) Load Center Installation Guide (P/N 521139)

IntelliChlor

COM ports

IntelliTouch Control System Personality Circuit Board

Salt Chlorine Generator Installation and User’s Guide

ONLY

SOLAR

CLNR

Connecting IntelliChlor®SCG to an SunTouch® Control System

To connect the four wire communication cable from the IntelliChlor SCG Power Center (see page 27) to the motherboard located in the SunTouch® Control System Power Center:

WARNING - Switch OFF main system power to the Load Center before making any connections.

To access the Power Center electronics compartment:

1. Unlatch the front door of the Power Center, and open the door.

2. Loosen the retaining screw on front panel. Open the hinged front panel to access the electronics compartment.

3. Route the four conductor cable up through the Power Center grommet opening located on the left side, and up through the low voltage raceway to the motherboard.

4. Strip back the cable conductors 1-1/4 in. Insert the wires into the screw terminals (provided in the kit). Secure the wires with the screws. Make sure to match the color coding of the wires: Red = +15, Yellow = +DT, Green = -DT, and GND = Black.

5. Insert the connector on the COM-PORT (J11) screw terminal on the motherboard.

6. When the connection is completed, close the control panel and secure it with the retaining screw.

7. Close the front door. Fasten the spring latch.

COM PORT

GAS HEATER

RESET

INTAKE

VLV A

VALVE ACTUATORS

RETURN

VLV B

SOLAR

VLV C

PUMP

AUX 1

AUX 2

AUX 3

SunTouch Control System motherboard

Wiring AC Power from IntelliChlor (SCG) and IntelliFlo® pump to

IntelliTouch

, EasyTouch® and SunTouch® Control System

(see page 27 for diagram)

IntelliChlor (SCG) AC Wiring Instructions: When using the IntelliChlor SCG and an IntelliFlo pump (or 2-speed pump) with an IntelliTouch, EasyTouch or SunTouch Control System, the IntelliChlor AC

power center wires must be connected to the LOAD SIDE OF THE FILTER PUMP RELAY located in the

Load/Power Center (see diagram on page 27). This ensures that the IntelliChlor SCG cell produces

chlorine only when the main filter pump is on. This method does not require a ground fault circuit-

interrupter (GFCI) to protect the circuit. Note: For non-automation control systems using a time clock,

see page 30 for wiring information.

IntelliChlor

Salt Chlorine Generator Installation and User’s Guide

Wiring IntelliChlor®SCG AC Power Cord

to Automation Control System Filter Pump Relay

IntelliChlor

Salt Chlorine Generator Installation and User’s Guide

Section 6

Troubleshooting

Use the following troubleshooting information to resolve possible problems with the IntelliChlor® SCG.

WARNING - Switch OFF main system power to the IntelliChlor SCG cell before before servicing.

Note: Switch power off to unit before to attempting service or repair. Always remove AC power to Power Center when plugging or unplugging the IntelliChlor SCG cell into the Power Center.

Table 1: Troubleshooting

me l b o r PesuaCe l b i ssoPnoi tcAevi tcer roC

.eni rolhconrowoLloopnilevel)dicaci runayc(rezi l ibatswoL

. ) y l nos l oopr ood t uo ( r e t aw

. 31egap, 1

. GCS

.%0t af f or o

. retawloopnitneserps lateM . l ano i s s e f o rPl ooPt c a t noC

.put rats

. l l ecy t r i dr odeggo l C . y r assecenf inae lC. no i t cepsn i r o f l l ecevomeR

rolhCi l letnIehtfosruohgni tarepotnei c i f fusnI

wo loo t t esega t nec r epTUPTUOREZ I T I NAS

e r u t a r epme tr eh t aewn isesae r cn i t neceR

. t up t uOr ez i t i naSGCSeh tgn i s ae r cn i t uoh t i w

yvaeho teuden i r o l hcf osso l y r a r opmeT

yvaehr or ez i l i t r e f , s evae l , n i a r , dao lc i nag r o

. l oopgn i sus t epr o, y t r apt nece r , dao l r eh t ab

l oopn i l eve l t l a s)mpp0062nah ts se l (woL

.noi tcudorpeni rolhcf fostuhs, retaw

. l e ve le t ahp sohpdnae t a r t i nhg i H . l ano i s s e f o rPl ooPt c a t noC

nopuy l r epo r pdekcohst onr o, r e t awl oopweN

. 8egapeeS. no t t ubEROM

.7egap" ,sDELsutatS

. l ooPe t an i r o l hCr epuS

. 61egap

. ) 91egapee s (

o ty l nos l oopr ood t uon id i c ac i r unay cddA

s ' l ano i s se f o r pl oopr epMPP05-03n i a t n i am

e l baT, t r ahCr ez i l i ba t SeeS. sno i t adnemmoc e r

eeS. yadr epemi tgn i t a r epoGCSeh tesae r cn I

. no i t amr o f n iemi tnu rpmupr o f51egap

ehtgn i sserpybTUPTUOREZITINASesaercnI

42r o fnu ro two l l adnaedom" t sooB" t eS

- r epus, wo loo t l l i t sf I , k cehceR. s r uoh ek aT ( . ec r uosed i s t uonagn i suy be t an i r o l hc

. ) l ano i s se f o r pl oopo te l pmasr e t awl oop

leveLt laS"eeS.sthgi lyalpsiDt laSevresbO

, " ) no i t an i r o l hCr epuS (e r udeco r Ppu - t r a t S"eeS

IntelliChlor

Salt Chlorine Generator Installation and User’s Guide

Table 1: Troubleshooting (Continued)

me l b o r PesuaCe l b i s soPnoi tcAev i tcerroC

. no

gnihsal f

n os i

. de r

s i D E L t l a sWO L d e R

not hg i lTLASWOLdeR

t hg i lLLECnee r gdna

t h g i l T L ASKCEHCd e R

t hg i l t l asDOOGnee rG

gnihsal fsi

s i t hg i lRETAWDLOC

. decudo r p

. gn i t cepsn i

. l lafniaRyvaeH

. l oopn i kaeL

. seca f r us

gn i ebs i en i r o l hcoN. t l assdeenr e t awl ooP

deenyamdnawo ls i r e t awl oopn i l e ve l t l aS

. l oopn i t l ashguonet oN

o tegamades uacy aM. l oopn i t l ash cumooT

gn i dnuo r r usdnat nemp i uqede t ae l e r l oop

. F °25wo l ebs i r e t aW o tF° 25ev obaebt sume r u t a r epme t r e t awehT

. 41, 31segapnodeb i r c sedsat l asddA

DOOGo ty ras secenf idda, l eve l t l askcehC

f I. retawnix imott lasrofsruoh42wol lA. level

, s r uoh42r e t f agn i hs a l f l l i t ss i t hg i lLLEC

. y r as se cenf inae l cdnal l ect cepsn idnaevome r

.mpp0063eve i h cao t l oopo t t l a sddA

. 31, 21egapeeS

neht, retawemosgn ini ardybretawl oopetul iD

retawhser fht iwgni l l i f

. en i r o l hcecudo r p

t onseodt hg i lLLEC

. n oemo c

. nee r g

gnihsal fsithgi lLLEC

. de rs i t hg i lwo l F.wol fretawtneic i f fusedi vorpots l iafpmuP , . e . i , pmupeh t f ono i t a r epot ce r r ocr o fk cehC

seodt inurolhCi l letnI

. r ewopevaht on

levelt laskcehC

. gn i nae l c

. sev l a vdeso lC .stnemngi laev lavl latcerrocdnakcehC

.retlifytriD . s e r udeco r pgn i nae l cr e t l i fwo l l oF

.%00o t t esno i t cudo r Pen i r o l hC d e r i s e d o t NO I T CUDOR PE N I RO L HC t s u j d A

ht iwdeggulps il leC.wol fretawtne ici f fusnI

. emi r pt s o l sahpmup, s i r bed

.mpp0062wo l ebl e ve l t l aS . 31, 21segapnodeb i r c sedsat l asddA

se r i uqe rdnapu - d l i ubmu i c l acsahl l eC

. ec na l abdnay r t s imehcr e t awk cehC

.mpp0ebd l uohs t ne t noc l a t emETON

. l lecGCSehtninoi tcur tsbO gninaelcwol loF.noi tcepsnirofl lecevomeR

. nepos i r e t neCr ewoPn ie suF . r e t neCr ewoPeh tn ide t aco l , esu fCAeca l peR

. retneCrewoPotrewopCAoN 022r oCAV011gn i d i v o r ps i k co l cemi ty f i r eV

. ega t nec r ep

eeS. l l ecnae l cr o / dnano i t cu r t sboe vomeR

. y r as se cenf ipmupemi rP. 01egap

mpp0063n i a t n i amo t y r as secenf i t l asddA

.mumi n im

d i c ar o fe r udec o rPec nane t n i aMo t r e f eR

" , ecnane t n i aMr esU"eeS. gn i nae l c / hs aw

. 81egapno

l a c i me h cg n i s u r e t awmo r f s l a t eme v ome R

.noi tulos

r en i a r t sdeggo l cr oem i r ppmupf os so l

. s t e ks ab

" ,gninaelCl leCc i tylortcelE"eeS.serudecorp

. 01egapno

. ev i t canehwr e t neCr ewoPo tCAV

. retneC

IntelliChlor

rewoPniy l t cer rocder iwtonsdae lremro f snarT

. revocret neCrewoP

Salt Chlorine Generator Installation and User’s Guide

ybec r uosCAo tde r i wsdae l r emr o f sna r ty f i r eV

foedisninolacedmargaidgni r iwotgni rrefer

System Specifications - 110 VAC and 230 VAC Wiring

Circuit Protection: Two-pole 20 AMP device at the electrical panel.

IntelliChlor SCG Model IC20, IC40 and IC60

Input: 95-130 VAC, 50/60 Hz, 220 Watts (2 AMP) or 220-240 VAC, 50/60 Hz, 220 Watts (1 AMP).

Output: 22-39 VDC @ 7.5 AMPS maximum from the Power Center.

Note: A TIME CLOCK must be used if the IntelliChlor SCG is used in “stand alone” mode without an automation control system.

IntelliChlor (SCG) AC Wiring Instructions:

SCG and an IntelliFlo pump (or 2-speed pump) with an IntelliTouch

EasyTouch center wires must be connected to the LOAD SIDE OF THE MAIN FILTER PUMP

RELAY located in the load/power center (see page 27 for diagram). This

ensures that the IntelliChlor SCG cell produces chlorine only when the main filter pump is on. This method does not require a ground fault circuit-interrupter

(GFCI) to protect the circuit.

or SunTouch® Control System, the IntelliChlor SCG AC power

When using the IntelliChlor

IMPORTANT: When using IntelliChlor SCG with an IntelliTouch Control System, it is recommended to wire the Power Center to the pump side of the relay located in the IntelliTouch Control System Load Center. This method does not require a ground fault circuit-interrupter

(GFCI) to protect the circuit.

IntelliChlor

115 VAC Basic System Wiring with Pool Pump Timer

Salt Chlorine Generator Installation and User’s Guide

220 VAC Basic System Wiring with Pool Pump Timer

ntelliChlor Power Center 230 and 115 VAC Transformer Wiring

IntelliChlor

Salt Chlorine Generator Installation and User’s Guide

IntelliChlor® SCG IC15 System Specifications and Wiring

Circuit Protection: Two-pole 20 AMP device at the electrical panel.

IntelliChlor SCG Model IC15

Input: 85-130 VAC, 50/60 Hz, 65 watts

Output: 24 VAC (4 AMPS) to internal blades of cell.

IntelliChlor

110 VAC Basic System Wiring with Pool Pump Timer

Salt Chlorine Generator Installation and User’s Guide

Notes

IntelliChlor

Salt Chlorine Generator Installation and User’s Guide

1620 HAWKINS AVE., SANFORD, NC 27330 • (919) 566-8000 10951 WEST LOS ANGELES AVE., MOORPARK, CA 93021 • (805) 553-5000 WWW.PENTAIRPOOL.COM © 2016 Pentair Water Pool and Spa, Inc. All rights reserved. This document is subject to change without notice.

*520589*

P/N 520589 REV. N 2/2016

Pentair INTELLICHLOR IC15, INTELLICHLOR IC60, INTELLICHLOR IC20, INTELLICHLOR IC40 Installation And User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
