DOMEX ROOF MOUNTED FAN - DIRECT DRIVE MODELS
DX08SR, DX10SR, DX11VSR, DX11Q, DX13VSR and DX13Q
4
PENNBARRY |
1401 N. Plano Road; Richardson, TX 75081 | www.PennBarry.com
DOMEX ROOF MOUNTED FAN - DIRECT DRIVE MODELS
DX08SR DX10SR DX11VSR
REF. # DESCRIPTION
1 Hood / Apron 1 18299-0 18299-0 18299-0
2 Top Plate 1 18300-0 18300-0 18300-0
3 Vertical Brace 4 18301-0 18302-0 18302-0
4 Conduit Pipe 1 19305-0 18306-0 18306-0
5 Base / Venturi 1 18303-1 18303-1 18303-1
6 Wheel 1 18174-1 18175-1 18176-2
7 Bird Screen 1 18308-0 18307-0 18307-0
8 Motor (115/1/60) ODP 1 63745-0 63746-0 63747-0
8 Motor (115/1/60) TE 1 63580-0 63769-0 63770-0
9 Screen Clip 4 55102-0 55102-0 55102-0
10 1/4 - 20 Acorn Nut 4 55490-0 55490-0 55490-0
11 Serrated Nut 4 — — —
12 Screw 1 — — —
13 Rubber Washers 4 63017-0 63017-0 63017-0
REF. # DESCRIPTION QTY PART # PART # PART #
1 Hood / Apron 1 18299-0 18309-0 18309-0
2 Top Plate 1 18300-0 18449-0 18449-0
3 Vertical Brace 4 18302-0 18302-0 18302-0
4 Conduit Pipe 1 18306-0 18306-0 18306-0
5 Base / Venturi 1 18303-1 18310-1 18310-1
6 Wheel 1 18176-2 18179-2 18179-2
7 Bird Screen 1 18307-0 18307-0 18307-0
8 Motor (115/1/60) ODP 1 63753-0 63748-0 63749-0
8 Motor (115/1/60) TE 1 63781-0 63769-0 63772-0
9 Screen Clip 4 55102-0 55102-0 55102-0
10 1/4 - 20 Acorn Nut 4 55490-0 55490-0 55490-0
11 Serrated Nut 4 — — —
12 Screw 1 — — —
13 Rubber Washers 4 63017-0 63014-0 63014-0
QTY /
UNIT
PART # PART # PART #
DX11Q DX13VSR DX13Q
PENNBARRY | 1401 N. Plano Road; Richardson, TX 75081 | www.PennBarry.com
5
DOMEX ROOF MOUNTED FAN - DIRECT DRIVE MODELS
DX16VSR, DX16Q1, DX16Q2 and DX18V
6
PENNBARRY |
1401 N. Plano Road; Richardson, TX 75081 | www.PennBarry.com
DOMEX ROOF MOUNTED FAN - DIRECT DRIVE MODELS
DX16VSR DX16Q1
REF. # DESCRIPTION
1 Hood / Apron 1 13701-0 13701-0
2 Top Plate 1 18379-0 18379-0
3 Vertical Brace 3 16250-0 16250-0
4 Conduit Pipe 1 16370-0 16370-0
5 Base 1 13693-1 13693-1
6 Wheel 1 18181-1 18181-1
7 Bird Screen 1 16380-0 16380-0
8 Motor (115/1/60) ODP 1 63750-0 63751-0
8 Motor (115/1/60) TE 1 63773-0 —
9 Screen Clip 3 — —
10 1/4 - 20 Acorn Nut 4 55490-0 55490-0
11 Serrated Nut 4 — —
12 Screw 1 — —
13 Rubber Washers 4 63014-0 63014-0
14 Venturi 1 13704-0 13704-0
QTY /
UNIT
PART # PART #
DX16Q2 DX18V
REF. # DESCRIPTION
1 Hood/Apron (Hood Only 18V) 1 13701-0 16175-0
2 Top Plate 1 18379-0 16052-1
3 Vertical Brace 4 16250-0 16252-0
4 Conduit Pipe 1 16370-0 16372-0
5 Base 1 13693-1 16003-1
6 Wheel 1 18181-1 21185-0
7 Bird Screen 1 16380-0 16382-0
8 Motor (115/1/60) ODP 1 63752-0 67234-0
8 Motor (115/1/60) TE 1 63774-0 —
9 Screen Clip 3 — —
10 1/4 - 20 Acorn Nut 4 55490-0 55490-0
11 Serrated Nut 4 — —
12 Screw 1 — —
13 Rubber Washers 4 63014-0 63014-0
14 Venturi 1 13704-0 16033-0
15 Apron (18V Only) 1 — 16125-0
QTY /
UNIT
PART # PART #
PENNBARRY | 1401 N. Plano Road; Richardson, TX 75081 | www.PennBarry.com
7
DOMEX ROOF MOUNTED FAN - BELT DRIVE MODELS
DX06B, DX08B and DX11B
DX06B & DX08B DX11B
8
PENNBARRY |
1401 N. Plano Road; Richardson, TX 75081 | www.PennBarry.com
DOMEX ROOF MOUNTED FAN - BELT DRIVE MODELS
DX06B DX08B DX11B
REF. # DESCRIPTION
1 Hood 1 18427-0 18427-0 19629-0
2 Top Plate / Apron 1 18428-0 18428-0 16051-0
3 Vertical Brace 3 18302-0 18302-0 16250-0
4 Conduit Pipe 1 18306-0 18306-0 16370-0
5 Base / Venturi 1 18303-1 18310-1 —
6 Wheel 1 18176-9 18179-9 18181-7
7 Bird Screen 1 18307-0 18307-0 16380-0
8 Motor (115/1/60) 1 63821-0 63821-0 —
9 Shaft 1 18900-0 18900-0 18797-0
10 Motor / Bearing Fr 1 18450-0 18450-0 —
11 Mtr Fr Supp ang. 2 18451-0 18451-0 —
12 Hood Mtng lugs 4 19596-0 19596-0 —
13 Screen Clip 4 — — —
15 Base 1 — — 13693-1
16 Venturi 1 — — 13704-0
18 Junction Box 1 01617-4 01617-1 —
19 Junction Box Cvr 1 05543-1 — —
21 Bearings 1 36165-0 36165-0 36165-0
22 1/4 - 20 Nut 4 — — —
23 Rubber Bushing 4 — — —
24 Bolt Clip 1 — — —
25 Bearing Support pt. 1 — — —
26 Motor Support Plt. 1 — — 16300-0
27 Motor Pulley 1 62800-0 62800-0 —
28 Fan Pulley 1 62002-0 62002-0 —
29 Belt 1 62734-0 62764-0 —
QTY /
UNIT
PART # PART # PART #
DX11B - MOTOR / BELT / PULLEY PARTS
HP PHASE
.25 115/1/60 60396-0 62802-0 62477-0 62108-0 560 - 840
.33 115/1/60 63720-0 62851-0 62553-0 62109-0 895 - 1200
.50 115/1/60 63726-0 62851-0 62477-0 62109-0 980 - 1330
.75 115/1/60 60196-0 62807-0 62453-0 62108-0 1230 - 1660
.25 230/3/60 60117-0 62802-0 62477-0 62108-0 560 - 840
.33 230/3/60 60905-0 62807-0 62553-0 62109-0 895 - 1200
.50 230/3/60 60920-0 62807-0 62477-0 62109-0 980 - 1330
.75 230/3/60 60930-0 62807-0 62453-0 62108-0 1230 - 1660
PENNBARRY | 1401 N. Plano Road; Richardson, TX 75081 | www.PennBarry.com
MOTOR
PART #
MOTOR
PULLEY
FAN
PULLEY
BELT
RPM
RANGE
9
DOMEX ROOF MOUNTED FAN - BELT DRIVE MODELS
DX12B, DX14B and DX16B
10
PENNBARRY |
1401 N. Plano Road; Richardson, TX 75081 | www.PennBarry.com
DOMEX ROOF MOUNTED FAN - BELT DRIVE MODELS
DX12B DX14B DX16B
REF. # DESCRIPTION
1 Hood 1 16326-0 16326-0 16175-0
2 Apron 1 — — 16125-0
3 Vertical Brace 4 16251-0 16251-0 16252-0
4 Conduit Pipe 1 16371-0 16371-0 16372-0
5 Base 1 16002-1 16002-1 16003-1
6 Wheel 1 21166-1 21166-0 21168-0
7 Bird Screen 1 16381-0 16381-0 16382-0
8 Motor (115/1/60) 1 — — —
9 Shaft 1 03359-0 03397-0 03397-0
10 Motor / Bearing Fr 1 — — —
11 Mtr Fr Supp ang. 2 16275-0 16275-0 16277-0
12 Hood Mtng lugs 4 — — —
13 Screen Clip 4 — — —
14 Top Plate 1 16051-0 16051-0 16052-0
16 Venturi 1 16031-0 16031-0 16032-0
21 Bearings 1 36165-0 36165-0 36165-0
22 1/4 - 20 Nut 4 — — —
23 Rubber Bushing 4 — — —
24 Bearing Support pt. 1 — — —
25 Motor Support Plt. 1 16300-0 16300-0 16301-0
26 Motor Pulley 1
27 Fan Pulley 1
28 Belt 1
QTY /
UNIT
PART # PART # PART #
—
See Next Page For Details
PENNBARRY | 1401 N. Plano Road; Richardson, TX 75081 | www.PennBarry.com
11
DOMEX ROOF MOUNTED FAN - BELT DRIVE MODELS
DX12B, DX14B and DX16B
12
PENNBARRY |
1401 N. Plano Road; Richardson, TX 75081 | www.PennBarry.com
DOMEX ROOF MOUNTED FAN - BELT DRIVE MODELS
DX12B - MOTOR / BELT / PULLEY PARTS
HP PHASE
.25 115/1/60 60396-0 62805-0 62477-0 62107-0 700 - 990
.33 115/1/60 63720-0 62805-0 62477-0 62107-0 840 - 1190
.50 115/1/60 63726-0 62851-0 62477-0 62108-0 840 - 1190
.75 115/1/60 60196-0 62807-0 62496-0 62107-0 1090 - 1470
.25 230/3/60 60117-0 62805-0 62477-0 62107-0 700 - 990
.33 230/3/60 60905-0 62806-0 62477-0 62107-0 840 - 1190
.50 230/3/60 60920-0 62807-0 62477-0 62108-0 840 - 1190
.75 230/3/60 60930-0 62807-0 62496-0 62107-0 1090 - 1470
MOTOR
PART #
MOTOR
PULLEY
FAN
PULLEY
BELT
DX14B - MOTOR / BELT / PULLEY PARTS
HP PHASE
.25 115/1/60 60396-0 62805-0 62478-0 62109-0 560 - 840
.33 115/1/60 63720-0 62805-0 62553-0 62109-0 765 - 1080
.50 115/1/60 63726-0 62805-0 62477-0 62107-0 840 - 1190
.75 115/1/60 60196-0 62807-0 62496-0 62107-0 1090 - 1470
.25 230/3/60 60117-0 62805-0 62478-0 62109-0 560 - 840
.33 230/3/60 60905-0 62806-0 62553-0 62109-0 765 - 1080
.50 230/3/60 60920-0 62806-0 62477-0 62107-0 840 - 1190
.75 230/3/60 60930-0 62807-0 62496-0 62107-0 1090 - 1470
1.0 230/3/60 60935-0 62812-0 62477-0 62290-0 1190 - 1540
MOTOR
PART #
MOTOR
PULLEY
FAN
PULLEY
BELT
RPM
RANGE
RPM
RANGE
DX16B - MOTOR / BELT / PULLEY PARTS
HP PHASE
.25 115/1/60 60396-0 62802-0 62595-0 62111-0 475 - 725
.33 115/1/60 63720-0 62805-0 62170-0 62115-0 525 - 740
.50 115/1/60 63726-0 62805-0 62595-0 62113-0 600 - 850
.75 115/1/60 60196-0 62806-0 62478-0 62110-0 700 - 990
.25 230/3/60 60117-0 62802-0 62595-0 62111-0 475 - 725
.33 230/3/60 60905-0 62806-0 62170-0 62115-0 525 - 740
.50 230/3/60 60920-0 62806-0 62595-0 62113-0 600 - 850
.75 230/3/60 60930-0 62806-0 62478-0 62110-0 700 - 990
1.0 230/3/60 60935-0 62807-0 62478-0 62278-0 820 - 1100
1.5 230/3/60 60942-0 62807-0 62478-0 62278-0 820 - 1100
MOTOR
PART #
MOTOR
PULLEY
FAN
PULLEY
BELT
RPM
RANGE
PENNBARRY | 1401 N. Plano Road; Richardson, TX 75081 | www.PennBarry.com
13
DOMEX ROOF MOUNTED FAN - BELT DRIVE MODELS
DX18B, DX24B and DX30B
14
PENNBARRY |
1401 N. Plano Road; Richardson, TX 75081 | www.PennBarry.com
DOMEX ROOF MOUNTED FAN - BELT DRIVE MODELS
DX18B DX24B DX30B
REF. # DESCRIPTION
1 Hood 1 16175-0 16176-0 16177-0
2 Apron 1 16125-0 16126-0 16127-0
3 Vertical Brace 4 16252-0 16253-0 16254-0
4 Conduit Pipe 1 16372-0 16373-0 16374-0
5 Base 1 16003-1 16004-1 16005-1
6 Wheel 1 21171-0 21174-0 21177-0
7 Bird Screen 1 16382-0 16383-0 16384-0
8 Motor (115/1/60) 1 — — —
9 Shaft 1 03397-0 03391-0 03391-0
10 Motor / Bearing Fr 1 — — —
11 Mtr Fr Supp ang. 2 16277-0 16278-0 16279-0
13 Screen Clip 4 — — —
14 Top Plate 1 16052-0 16053-0 16054-0
16 Venturi 1 16033-0 16034-0 16035-0
21 Bearings 1 36165-0 36166-0 36166-0
22 1/4 - 20 Nut 4 — — —
23 Rubber Bushing 4 — — —
24 Bearing Support pt. 1 — — —
25 Motor Support Plt. 1 16301-0 16302-0 16303-0
26 Motor Pulley 1
27 Fan Pulley 1
28 Belt 1
QTY /
UNIT
PART # PART # PART #
See Next Page For Details
PENNBARRY | 1401 N. Plano Road; Richardson, TX 75081 | www.PennBarry.com
15
DOMEX ROOF MOUNTED FAN - BELT DRIVE MODELS
DX18B, DX24B and DX30B
16
PENNBARRY |
1401 N. Plano Road; Richardson, TX 75081 | www.PennBarry.com
DOMEX ROOF MOUNTED FAN - BELT DRIVE MODELS
DX18B - MOTOR / BELT / PULLEY PARTS
HP PHASE
.25 115/1/60 60396-0 62802-0 62170-0 62114-0 420 - 630
.33 115/1/60 63720-0 62802-0 62595-0 62111-0 475 - 725
.50 115/1/60 63726-0 62805-0 62595-0 62112-0 600 - 850
.75 115/1/60 60196-0 62807-0 62595-0 62280-0 700 - 950
.25 230/3/60 60117-0 62802-0 62170-0 62114-0 420 - 630
.33 230/3/60 60905-0 62803-0 62595-0 62111-0 475 - 725
.50 230/3/60 60920-0 62806-0 62595-0 62112-0 600 - 850
.75 230/3/60 60930-0 62807-0 62595-0 62280-0 700 - 950
1.0 230/3/60 60935-0 62806-0 62478-0 62290-0 700 - 990
1.5 230/3/60 60942-0 62807-0 62478-0 62278-0 820 - 1100
2.0 230/3/60 63832-0 62813-0 62478-0 62280-0 995 - 1280
MOTOR
PART #
MOTOR
PULLEY
FAN
PULLEY
BELT
DX24B - MOTOR / BELT / PULLEY PARTS
HP PHASE
.25 115/1/60 60396-0 62802-0 62402-0 62122-0 310 - 460
.33 115/1/60 63720-0 62802-0 62430-0 62120-0 340 - 500
.50 115/1/60 63726-0 62802-0 62544-0 62200-0 370 - 560
.75 115/1/60 60196-0 62806-0 62544-0 62200-0 470 - 660
.25 230/3/60 60117-0 62802-0 62402-0 62122-0 310 - 460
.33 230/3/60 60905-0 62803-0 62430-0 62120-0 340 - 500
.50 230/3/60 60920-0 62803-0 62544-0 62200-0 370 - 560
.75 230/3/60 60930-0 62806-0 62544-0 62200-0 470 - 660
1.0 230/3/60 60935-0 62807-0 62544-0 62270-0 550 - 730
1.5 230/3/60 60942-0 62812-0 62544-0 62270-0 665 - 850
2.0 230/3/60 63832-0 62812-0 62507-0 62199-0 745 - 960
MOTOR
PART #
MOTOR
PULLEY
FAN
PULLEY
BELT RPM RANGE
RPM
RANGE
DX30B - MOTOR / BELT / PULLEY PARTS
HP PHASE
.33 115/1/60 63720-0 62802-0 62438-0 62213-0 240 - 360
.50 115/1/60 63726-0 62802-0 62431-0 62370-0 280 - 420
.75 115/1/60 60196-0 62803-0 62430-0 62203-0 340 - 500
.33 230/3/60 60905-0 62803-0 62438-0 62213-0 240 - 360
.50 230/3/60 60920-0 62803-0 62431-0 62280-0 280 - 420
.75 230/3/60 60930-0 62803-0 62430-0 62203-0 340 - 500
1.0 230/3/60 60935-0 62806-0 62402-0 62206-0 385 - 540
1.5 230/3/60 60942-0 62807-0 62402-0 62280-0 445 - 605
2.0 230/3/60 63832-0 62809-0 62430-0 62206-0 490 - 665
3.0 230/3/60 63833-0 62831-0 62567-0 62206-0 595 - 770
5.0 230/3/60 63834-0 62836-0 62567-0 62208-0 735 - 910
PENNBARRY | 1401 N. Plano Road; Richardson, TX 75081 | www.PennBarry.com
MOTOR
PART #
MOTOR
PULLEY
FAN
PULLEY
BELT RPM RANGE
17
Loading...
