Typical wide angle lens
Lenses
SL183A
DC-autoiris
ML183A
DC-autoiris
SL183M
Manual iris
ML183M
Manual iris
Focal length
1.8-3.0mm
Linear Optical Technology®
Yes (Note: this technology causes the image to be flipped)
Distortion
<1%
Resolution
5+ megapixel
F/#
F/1.8 to close
IR Correction
Day/Night
Focus range
0.5m to ∞
EasyZoom™
Yes
Mount
CS C CS C Iris cable length
30cm
N/A
30cm
N/A
Operating temperature
-20C to 60C (<70% humidity, non-condensing)
Storage temperature
-20C to 70C (<90% humidity, non-condensing)
Sensor size
1/3”
1/2.7” HD
1/2.5”
1/2.3” 4K*
Field of view (H)
105° - 77°
116° - 89°
115° - 88°
120° - 92°
Field of view (V)
90° - 62°
84° - 57°
99° - 71°
104° - 76°
Field of view (D)
117° - 90°
123° - 96°
126° - 100°
130° - 105°
C5022S
Pelco Model M1.8-3
SL183 Varifocal
Ultra wide No Distortion 5 Megapixel Lens
Patented Linear Optical Technology® provides
ultra wide field of view adjustable up to 120°
for greater coverage with fewer cameras
EasyZoom™ allows the user to optimize the
field of view with minimal need for refocusing
IR corrected for true Day/Night cameras
Supports multi megapixel resolution
cameras for demanding applications
Compatible with 1/3”, 1/2.7” HD, 1/2.5”, 1/2.3”
4K* and 1/2”** sensor sizes
With slip ring for ease of installation &
positioning
*4K format = 4000 x 2000 pixels ** On 1/2” sensor crop image vertically to eliminate dark corners
SL183 family www.TheiaTech.com
For more information, contact
Theia Technologies
Phone: +1-503-570-3296
www.TheiaTech.com SL183 family
