PRODUCT SPECIFICATION |
camera solutions |
|
|
Sarix® IMP Series Environmental Mini Domes
STD DEF/MEGAPIXEL, H.264, DAY/NIGHT IP DOMES
Product Features
•Up to 5 Megapixel (MPx) Resolution
•Up to 30 Images per Second (ips) at 1080p
•Autofocus Motorized Remote Zoom Lens
•Accessible Edge Storage with Micro SD Card
•Motion Detection and Camera Sabotage Detection
•Operating Temperature from –45° to 50°C (–50° to 122°F)
•Power over Ethernet (PoE) and 24 VAC Power Input
•Compatible with Pelco and Third-Party Video Systems
•ONVIF Profile S and Profile G Conformant
•3-Year Warranty and Support
Sarix Professional Range
Powerful, versatile, and affordable, the Sarix® Professional (P) range cameras pack the most popular features and functionality of Sarix technology into a wide range of indoor and environmental options, including IP box cameras, bullet cameras, and domes. Mix and match the performance options and form factor you need for almost any lighting condition, environment, and application.
Camera
Within the Sarix Professional range, the Sarix IMP Series mini dome cameras feature a remote zoom lens for wide angle or long range surveillance needs. Autofocus capability ensures the camera can be automatically refocused when needed. Additionally, the Sarix IMP Series features advanced color science and a mechanical IR cut filter for increased sensitivity in low-light installations.
Video
Sarix Professional range cameras support up to two simultaneous video streams and a third service stream. The two streams can be compressed with efficient H.264 High or Main profiles or MJPEG formats. The streams can be configured to a variety of frame rates and bit rates to optimize image quality with bandwidth and storage efficiency.
Edge Storage
Sarix Professional range cameras feature onboard edge storage with a micro SD card. Video clips of varying lengths can be stored to the card upon alarm, or video can be written continuously to the SD card in the case of network outage. Video can be retrieved from the card through the FTP protocol or by using an ONVIF Profile G enabled client.
Sarix Professional range cameras feature simple motion detection algorithms allowing the camera to record or send an alarm when there is motion detected in a selected zone or within the entire scene. A camera sabotage alarm is triggered if the lens is obstructed or when the camera is repositioned.
Open and Integrated
Sarix Professional range cameras seamlessly connect to Pelco video management systems such as Endura® version 2.0 (or later) and Digital Sentry® version 7.3 (or later). Sarix Professional range cameras integrate with major third-party video management systems through the Pelco API and other third-party software and systems through the open ONVIF Profile S and Profile G standards.
Standard Web Interface
Pelco cameras use a standard Web browser interface for easy remote setup and administration. Controls are optimized for convenient one-step camera configuration for features including color, exposure, flicker control, and streaming.
International Standards
Organization Registered Firm;
ISO 9001 Quality System
C3951 / REVISED 12-17-15
TECHNICAL SPECIFICATIONS
BACK BOX FEATURES
VALUES IN PARENTHESES ARE INCHES; ALL OTHERS ARE CENTIMETERS.
Ø 2.69 (1.06)
8.50
(3.34)
18.04
(7.10)
Ø 9.66
(3.80)
Ø 15.00 (5.90)
8.88
(3.49)
13.88
(5.46)
Ø 9.66 (3.80)
Ø 15.52 (6.11)
Environmental, In-Ceiling
•Clearance Above Ceiling 10.16 cm (4 in.)
•Maximum Ceiling Thickness 3.81 cm (1.5 in.)
•3/4-Inch NPT or 25 mm Conduit Attachments On Side and Top of Back Box
•IP66 Ingress Protection
•NEMA Type 4X
•NEMA TS-2 (Temp.) para 2.2.7.3 - 2.2.7.7
•IK10 (20J) Impact Resistance
•Plenum Rated Back Box
Environmental, Surface Mount
•Attaches to Standard 4-Inch Square Outlet Box and Standard 2-Gang Electrical Box
•3/4-Inch NPT or 25 mm Conduit Attachments On Side and Top of Back Box
•IP66 Ingress Protection
•NEMA Type 4X
•NEMA TS-2 (Temp.) para 2.2.7.3 - 2.2.7.7
•IK10 (20J) Impact Resistance
|
|
Environmental, Pendant |
|
|
18.54 |
• 1.5-Inch NPT Thread for Use With Pelco Wall Mounts |
|
|
• |
IP66 Ingress Protection |
|
|
(7.30) |
||
|
|
|
|
|
|
• |
NEMA Type 4X |
|
|
• NEMA TS-2 (Temp.) para 2.2.7.3 - 2.2.7.7 |
|
Ø 9.66 |
|
• |
IK10 (20J) Impact Resistance |
(3.80) |
|
|
|
|
Ø 15.00 (5.90) |
|
|
