QUICK
REFERENCE
GUIDE
PELCO.COM
FIXED CAMERAS - QUICK REFERENCE GUIDE
FIXED INDOOR CAMERAS
®
ENHANCED INDOOR DOME 3 SERIES SARIX® ENHANCED OUTDOOR DOME 3 SERIES SARIX® ENHANCED OUTDOOR IR BULLET 3 SERIES SARIX® ENHANCED INDOOR BOX 3 SERIES SARIX® CORNER CAMERA 3 SERIES
Model Name
Part Number
Description Indoor Camera with SureVision Outdoor Camera with SureVision Outdoor Camera with SureVision Indoor Camera with SureVision Vandal-Resistant- Anti-Ligature Security Camera
Max Resolution
Lens 2.8-8 / 4-9 mm, 8-20 / 9-20 mm 2.8-8 / 4-9 mm, 8-20 / 9-20 mm 2.8-8 mm, 4-9 mm, 8-20 mm, 9-20 mm
WDR Up to 130 dB Up to 130 dB Up to 130 dB Up to 130 dB Up to 126 dB
IR Illumination Up to 50 M Up to 50 M Yes Not applicable Up to 15 M
Image Stabilization Yes Yes Yes Yes Not applicable
Video Analytics Advanced Learning Analytics available. Enhanced Analytics included Advanced Learning Analytics available. Enhanced Analytics included Advanced Learning Analytics available. Enhanced Analytics included Advanced Learning Analytics available. Enhanced Analytics included Smart Analytics, powered by Motorola Solutions
Power Input PoE, 24 VAC, 12 VDC PoE, 24 VAC, 12 VDC PoE, 24 VAC, 12 VDC PoE, 24 VAC, 12 VDC
Environment Indoor, Vandal resistant, IK10+ 50J Outdoor Vandal resistant (IK10+ 50J, IK10, IP66, IP67, IP68, IP69K) Outdoor Vandal resistant (IK10, IP66, IP67, IP68, IP69K) Indoor IP66/67 Type 4x* (*stainless steel models)
Mounts IME3ICM-E, IME3PM-E, IME3EBAP-E, WMVE-SW IME3ICM-E, IME3PM-E, IME3EBAP-E, WMVE-SW IBP3-PLMT, IBP3BBAP-ES, IBP3BBAP-EI C11-UM CNBX-1001, IBD-FP, IBD-FPSS
Input/Output Audio Bidirectional: Built-in Microphone, Line In - Line Out Bidirectional: Built-in Microphone, Line In - Line Out Bidirectional: Built-in Microphone, Line In - Line Out Bidirectional: Built-in Microphone, Line In - Line Out Bidirectional: Built-in Microphone, Line In- Line Out
Codec H.265, H.264 H.265, H.264 H.265, H.264 H.265, H.264 H.264, H.265
Years of Warranty 3 3 3 3 5
SARIX
IME238-1IRS (2.1 MP), IME338-1IRS (3.1 MP)
IME332-1IRS (3.1 MP), IME539-1IRS (5.0 MP)
IME839-1IRS (8.3 MP, 4K), IME832-1IRS (8.3 MP, 4K)
1920 x 1080 (2 MP), 2048 x 1536 (3 MP)
2592 x 1944 (5 MP), 3840 x 2160 (8 MP)
IIME238-1ERS (2.1 MP), IME338-1ERS (3.1 MP)
IME332-1ERS (3.1 MP), IME539-1ERS (5.0 MP)
IME839-1ERS (8.3 MP, 4K), IME832-1ERS (8.3 MP, 4K)
1920 x 1080 (2.1 MP), 2048 x 1536 (3.1 MP)
2592 x 1944 (5.0 MP), 3840 x 2160 (8.3 MP, 4K)
IBE538-1ER, IBE838-1ER
IBE832-1ER
1920 x 1080 (2.1 MP)
2048 x 1536 (3.1 MP)
1XE23 (2 MP), IXE33 (3 MP)
IXE 53 (5 MP), IXE83 (8 MP)
1920 x 1080 (2 MP), 2048 x 1536 (3 MP)
2592 x 1944 (5 MP), 3840 x 2160 (8 MP)
i-CS lenses available separately
MI2.8-8.5P, MI3.9-10P, MI9-50P
IBD332-1, IBD332-1SS,IBD532-1, IBD532-1SS
2048 x 1536 (3 MP) 2592 x 1944 (5 MP)
2.3 mm
VDC: 12 V ± 10%, 12 W min VAC: 24 V ± 10%, 13 VA min
PoE: IEEE802.3af Class 3 compliant
FIXED OUTDOOR CAMERAS
®
PROFESSIONAL INDOOR DOME 3 SERIES SARIX® PROFESSIONAL OUTDOOR DOME 3 SERIES SARIX® PROFESSIONAL OUTDOOR IR BULLET 3 SERIES SARIX® PROFESSIONAL INDOOR BOX 3 SERIES SARIX® PROFESSIONAL OUTDOOR IR WEDGE 3 SERIES
Model Name
Part Number
Description Indoor Vandal-Resistant Cameras Outdoor Vandal-Resistant Camera Outdoor Vandal-Resistant Camera Outdoor Vandal-Resistant Camera Indoor Security Cameras Outdoor Vandal-Resistant Camera
Max Resolution
Lens 2.8-12 mm nominal 2.8-12 mm (nominal), varifocal 2.8-12 mm (nominal), varifocal 9-22 mm (2.1 MP); 7-22 (5 MP)
WDR Up to 120 dB Up to 120 dB Up to 120 dB Up to 120 dB Up to 120 dB Up to 120 dB
IR Illumination On IR models Not applicable Up to 50 M Up to 50 M Not applicable Not applicable
Image Stabilization Not applicable Not applicable Not applicable Not applicable Not applicable Not applicable
Video Analytics Pro Analytics Pro Analytics Pro Analytics Pro Analytics Pro Analytics Pro Analytics
Power Input PoE, 24 VAC, 12 VDC PoE+, 12VDC, 24 VAC PoE+, 24 VAC, 12 VDC PoE+, 24 VAC, 12 VDC PoE, 24 VAC, 12 VDC PoE
Environment Indoor Vandal resistant IK10
Mounts WMVE-SW, IMPICM-1I, IMPPM-1I, IMPPMB-1I WMVE-SR, IMP3ICM-1E, IMP3PM-1E IBP3BBAP-EI, IBP3BBAP-ES, IBP3-PLMT IBP3BBAP-EI, IBP3BBAP-ES, IBP3-PLMT C11-UM IMP3PMB-1I, IMP3EBAP
Input/Output Audio Line-in Line out Bidirectional Line-in Line out Bidirectional Line-in Line out Bidirectional Line-in Line out Bidirectional Line-in Line out Bidirectional Line-in Line out Bidirectional
Codec H.265, H.264 H.265, H.264 H.265, H.264 H.265, H.264 H.265, H.264 H.265, H.264
Years of Warranty 3 3 3 3 3 3
SARIX
IMP131-1RS (1 MP), IMP231-1IS
IMP231-1IRS (2 MP), IMP331-1IS, IMP331-IIRS (3 MP)
IMP531-1IS, IMP531-1IRS (5 MP)
1280 x 960 (1.2 MP), 1920 x 1080 (2.1 MP)
2048 x 1536 (3.2 MP), 2592 x 1944 (5.0 MP)
IR MODELS
IMP131-1ERS (1.2 MP)
IMP231-1ERS (2.1 MP)
IMP331-1ERS (3.1 MP)
IMP531-1ERS (5 MP)
1280 x 960 (1.2 MP), 1920 x 1080 (2.1 MP)
2048 x 1536 (3.1 MP), 2592 x 1944 (5.0 MP)
Outdoor / Vandal
(IK10, IP66, IP67)
NON IR MODELS
IMP531-1IS, IMP531-1ES,
IMP331-1IS, IMP331-1ES,
IMP231-1IS, IMP231-1ES,
IMP221-1ES
IBP131-1ER (1.2 MP), IBP231-1ER (2.1 MP)
IBP235-1ER (2.1 MP), IBP331-1ER (3.1 MP)
IPB335-1ER (3.1 MP), IBP531-1ER (5 MP)
1280 x 960 (1.2 MP), 1920 x 1080 (2.1 MP)
2048 x 1536 (3.1 MP), 2592 x 1944 (5.0 MP)
Outdoor / Vandal
(IP66, IP67, IK10)
IBP232-1ER (2.1 MP)
IBP532-1ER (5 MP)
1920 x 1080 (2.1 MP)
2592 x 1944 (5.0 MP)
Outdoor / Vandal
(IP66, IP67, IK10)
IXP13 (1.2 MP), IXP23 (2.1 MP)
IXP33 (3.1 MP), IXP53 (5 MP)
1280 x 960 (1.2 MP), 1920 x 1080 (2.1 MP)
2048 x 1536 (3.1 MP), 2592 x 1944 (5.0 MP)
15-50 mm, 2.8-8 mm, 2.2-6 mm, 2.8-8.5 mm, 9-40 mm
CS lenses available separately
Indoor
IWP133-1ERS (1 MP), IWP233-1ERS, IWP232-1ERS
IWP234-1ERS, IWP236-1ERS (2 MP), IWP333-1ERS (3 MP)
IWP533-1ERS, IWP532-1ERS (5 MP)
1280 x 960 (1.2 MP), 1920 x 1080 (2.1 MP)
2048 x 1536 (3.1 MP), 2592 x 1944 (5.0 MP)
2.4 mm, 2.8 mm, 4 mm, 6 mm
Outdoor / Vandal
(IK10, IP66, IP67)
PELCO QUICK REFERENCE GUIDE
2
FIXED CAMERAS - QUICK REFERENCE GUIDE
FIXED OUTDOOR CAMERAS
®
VALUE VARIFOCAL DOME SERIES SARIX® VALUE FIXED FOCAL DOME SERIES SARIX® VALUE VARIFOCAL BULLET SERIES SARIX® VALUE VARIFOCAL TURRET SERIES SARIX® VALUE FIXED FOCAL TURRET SERIES SARIX® MODULAR
Model Name
Part Number
Description Indoor/Outdoor Vandal-Resistant Camera Indoor/Outdoor Vandal Resistant Camera Indoor/Outdoor Overt Monitoring Solution Indoor/Outdoor 5 MP Camera Indoor/Outdoor 5 MP Camera Unobtrusive, Flexible Monitoring Solution
Max Resolution 1920 x 1080 (2MP) 2560 x 1920 (5 MP) 1920 x 1080 (2 MP) 2560 x 1920 (5 MP) 1920 x 1080 (2 MP) 2560 x 1920 (5 MP) 2560 x 1920 (5 MP) 1920 x 1080 (2 MP) 2560 x 1920 (5 MP)
Lens 3.4 mm-9.4 mm 3.6 mm, 2.8 mm 3.4 mm-9.4 mm 3.4 mm-9.4 mm 2.8 mm, 3.6 mm
WDR Up to 120 dB Up to 120 dB Up to 120 dB Up to 120 dB Up to 120 dB Up to 120 dB
IR Illumination Up to 30 M Up to 30 M Up to 30 M Up to 30 M Up to 30 M Not applicable
Image Stabilization Not applicable Not applicable Not applicable Not applicable Not applicable Not applicable
Video Analytics
Power Input IEEE 802.3af PoE Class 3 IEEE 802.3af PoE Class 2 IEEE 802.3af PoE Class 3 IEEE 802.3af PoE Class 3 IEEE 802.3af PoE Class 2
Environment Outdoor/Vandal (IP66,IK10) Outdoor/Vandal (IP66,IK10) Outdoor/Indoor (IP66) Outdoor/Indoor (IP66) Outdoor/Indoor (IP66)
Mounts
SARIX
IMV229-1ERS, IMV529-1ERS IJV223-1ERS, IJV522-1ERS IBV229-1ER, IBV529-1ER ITV529-1ERS IFV222-1ERS, IFV523-1ERS
Basic Analytics: Motion detection,
Camera Tamper Detection
SRXV-WMS, SRXV-WMP, IMV-WMJB
SRXV-PP, SRXV-PCF, SRXV-CM
SRXV-PLM, IMJTV-JB, IMV-PA, IMV-AP
Basic Analytics: Motion detection,
Camera Tamper Detection
SRXV-WMS, IJTFV-PA, SRXV-WMP
IMV-WMJB, SRXV-PP, SRXV-PCF
SRXV-CM, SRXV-PLM, IJTV-AP, IMJTV-JB
Basic Analytics: Motion detection,
Camera Tamper Detection
SRXV-CM, SRXV-PLM
IBV-A4S, IFBV-JB
Basic Analytics: Motion detection,
Camera Tamper Detection
SRXV-WMS, IJTFV-PA, SRXV-WMP
IMV-WMJB, SRXV-PP, SRXV-PCF
SRXV-CM, SRXV-PLM, IJTV-AP, IMJTV-JB
Basic Analytics: Motion detection,
Camera Tamper Detection
SRXV-WMS, IJTFV-PA, SRXV-WMP
IMV-WMJB, SRXV-PP, SRXV-PCF
SRXV-CM, SRXV-PLM, IFBV-JB
IDL0-PU2, IDL302-FXI, IDL502-FXI,
IDL303-PHI, CBL2M-1001
Right Angle Pinhole: 2128 x 1368 (3 MP)
Micro Bullet: 2128 x 1536 (3 MP)
2688 x 1944 (5 MP)
Right Angle Pinhole: 3.7 mm
Micro Bullet: 2.8 mm
Smart Analytics, powered by
Motorola Solutions
PoE: IEEE 802.3af Class 3 compliant VDC: 12 V
+/-10%, 11.5 W min
Micro Bullet Imager: Outdoor IP66
Main Unit & Right Angle Pinhole Imager: Indoor
DIN Rail Mount for Main Unit: BRKTMD-1001
MOTOROLA SOLUTIONS INDOOR/OUTDOOR VB400
Model Name
Part Number
Dimensions 2.7 x 3.5 x 1.04 in (68 x 89 x 26.6 mm)
Weight 5.7 OZ (162 G), plus mounting
Charging Up to eight hours from a fully flat battery
Bluetooth BT 2.1 + EDR, BLE 4.2
Recording Storage 64 GB
Recording Time Up to 12 hours
Battery On Standby 48 hours
Battery Type Lithium-Polymer
Horizontal Field of View 120 degrees
Peer-Assisted Recording Within 32.8 ft (10 m) of another device
VB400 INDOOR/OUTDOOR
VB-440-64-QR-N, VB-440-64-VF-N,
VB-440-64-KF-N, VB-440-64-ALIG
Input/Output Audio One way audio; G.711, G.726 Not applicable Not applicable One way audio; G.711, G.726 One way audio; G.711, G.726 Line in Line out Bidirectional
Codec H.265, H.264 H.265, H.264 H.265, H.264 H.265, H.264 H.265, H.264 H.265, H.264
Years of Warranty 3 3 3 3 3 5
PELCO QUICK REFERENCE GUIDE
WiFi Specification 802.11 a/b/g/n (2.4 GHz & 5 GHz
WiFi Security WPA2-PSK
WiFi Streaming 640 x 360, 25 or 30 fps
Years of Warranty 1
3
PANORAMIC CAMERAS - QUICK REFERENCE GUIDE
FIXED INDOOR CAMERAS
®
360° MULTI-SENSOR OPTERA® 270° MULTI-SENSOR OPTERA® 180° MULTI-SENSOR PELCO FISHEYE SARIX® MULTI PRO CAMERA
Model Name
OPTERA
Part Number
Description Indoor/Outdoor Panoramic Camera Indoor/Outdoor Panoramic Camera Indoor/Outdoor Panoramic Camera Indoor/Outdoor Camera With Superior Situational Awareness Indoor/Outdoor Multi-Directional Camera
Max Resolution 2048 x 1536 x 4 (12 MP) 2048 x 1536 x 4 (12 MP) 2048 x 1536 x 4 (12 MP)
Lens 2.7 mm 2.7 mm 4.8 mm
WDR Up to 120 dB Up to 120 dB Up to 120 dB Up to 120 dB Up to 100 dB
IR Illumination Not applicable Not applicable Not applicable
Video Analytics Enhanced Analytics Enhanced Analytics Enhanced Analytics Smart Analytics, powered by Motorola Solutions Motion detection and Camera Sabotage detection
Power Input PoE+ (IEEE 802.3at, Class 4) PoE+ (IEEE 802.3at, Class 4) PoE+ (IEEE 802.3at, Class 4)
Environment
IMM12036-X IMM12027-X IMM12018-X
Vandal Indoor & Outdoor models
Outdoor/Vandal (IP66,4x)
Vandal Indoor & Outdoor models
Outdoor/Vandal (IP66,4x)
Vandal Indoor & Outdoor models
Outdoor/Vandal (IP66,4x)
IMF82-1ES; IMF82-1ERS, IMF122-1ES; IMF122-1ERS,
IMF82-1I; IMF122-1I
2048 x 2048 (4 MP)
3008 x 3008 (9 MP)
8 MP: 1.4 mm
12 MP: 1.6 mm
8MP: Up to 17 m (55 ft)
12MP: Up to 12 m (39 ft)
With IR: PoE+: IEEE 802.3at, Class 4
Without IR: PoE: IEEE 802.3af, Class 3
Surface Mount: IK10 Impact Rating, IP66 and IP67, Type 4X
In-Ceiling: IP5X Rating
IMD9118; IMD9127; IMD15118; IMD15127; IMD24118; IMD24127;
IMD12136; IMD20136; IMD32136
2048 x 1536 (3 MP)
2592 x 1944 (5 MP)
3840 x 2160 (4K)
3 MP: 2.8 mm
5 MP: 2.8 mm
4K: 4 mm
per imager
Up to 30 m (100 ft)
PoE+ 24 VDC ± 10 %; 24 VAC rms ± 10 %, 50 or 60 Hz
IP66/67 Nema 4X
IK10 on outdoor rated configurations
In Ceiling: IMD1-INC
Mounts
Input/Output Audio Line-in Line out Bidirectional Line-in Line out Bidirectional Line-in Line out Bidirectional
Codec H.264 H.264 H.264 H.265, H.264 H.264, H.265
Years of Warranty 3 3 3 5 5
IMM-PNL, IMM-CM, IMM-DF5
WMVE-SR, WMVE-WT/BK PA101
IMM-PNL, IMM-CM, IMM-DF5
WMVE-SR, WMVE-WT/BK PA101
IMM-PNL, IMM-CM, IMM-DF5
WMVE-SR, WMVE-WT/BK PA101
Surface Mount Models: IMF-PM (Pendant Adapter),
WMVE-AW (Wall Mount, for use with IMF-PM),
IMM-CMAW (Corner Mount, for use with WMVE-AW)
Built-in Microphone
Line-in Line out Bidirectional
IMD1-INCLD1 or IMD1-INCLD0
Surface Mount: IMD1-SMT
IMD1-SPLD0 or IMD1-SPLD1
Pendant: IMD1-PMT
IMD1-SPLD0 or IMD1-SPLD1
Line-in Line out Bidirectional
PELCO QUICK REFERENCE GUIDE
4
