INSTALLATION AND OPERATION MANUAL

FTV10(M,S)1(ST,FC) Series

SINGLE DIGITAL 10-BIT VIDEO TRANSMITTER
PLUS CONTACT CLOSURE

The FTV10(M,S)1(ST,FC) series video transmitter supports the transmission

of short-haul quality 10-bit digital video and contact closure over one

multimode or single mode optical fiber. This module is universally compatible

with major CCTV camera manufacturers. This unit is compatible with the

FRV20(M,S)2(ST,FC) series dual channel receivers. Plug-and-play design

ensures ease of installation and no electrical or optical adjustments are

ever required. Bi-color (Red/Green) LED indicators are provided for rapidly

ascertaining equipment operating status. Figure 3 on Page 3 describes the

indicators for each light on the unit.

These units are interchangeable between stand-alone or card mount

configurations. See Figure A on Page 4 for mounting instructions.

TECH SUPPORT: [phone] INTERNATIONAL: [phone]

C5627M / REV 04-18-12

IMPORTANT SAFETY INSTRUCTIONS

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with dry cloth.

7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.

8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.

9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other.
A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the
provided plug does not fit into your outlet consult an electrician for replacement of the obsolete outlet.

10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the points where they exit
from the apparatus.

11. Only use attachments/accessories specified by the manufacturer.

12. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use
caution when moving the cart/apparatus combination to avoid injury from tip-over.

13. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as
power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed
to rain or moisture, does not operate normally, or has been dropped.

14. Apparatus shall not be exposed to dripping or splashing and that no objects filled with liquids, such as vases shall be placed on the
apparatus.

15. WARNING: To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture.

16. Installation should be done only by qualified personnel and conform to all local codes.

17. Unless the unit is specifically marked as a NEMA Type 3, 3R, 3S, 4, 4X, 6, or 6P enclosure, it is designed for indoor use only and it must
not be installed where exposed to rain and moisture.

18. Use only installation methods and materials capable of supporting four times the maximum specified load.

19. A CCC-approved power cord must be used to power this equipment when used in China.

20. CAUTION: These servicing instructions are for use by qualified service personnel only. To reduce the risk of electric shock do not
perform any servicing other than that contained in the operating instructions unless you are qualified to do so.

The product and/or manual may bear the following marks:

This symbol indicates that dangerous voltage constituting a risk of electric shock is present within this unit.

This symbol indicates that there are important operating and maintenance instructions in the literature accompanying this unit.

CAUTION:

RISK OF ELECTRIC SHOCK.

DO NOT OPEN.
