Programming

Set-up on installation 9-10

Block loading of Access Passes 10

Deleting individual Access Passes 10-11

Validating individual Access Passes 11

Block deletion of Access Passes 11

Changing lock output time 11

Changing the Master Code 11

ECP290 Additional Features 12-13

Dual Security, Code + Access Pass 13

Fail Safe locking schematic 14

Automation/Volt Free schematic 14

General Locking schematic 15

Din Rail Mounting 15

Din Rail Power Supplies 16

Powering ECP Door Controllers using Din Rail PSU 17

Programming Keypad Codes 18-19

ECP190 / ECP290

DOOR CONTROLLERS

ECP190 / ECP290
DOOR CONTROLLERS

3

NORALSY® ACCESS PASSES

Site

Code

The number of each and every Access Pass is visible. Just by looking at it,
you know which Access Pass you have. Noralsy

®

pre-number each Access
Pass because this is the only way you can know for sure what you have
received, what you need to program the system to accept (or, reject in the
case of loss, theft or non-return) and, who has been issued with which
Access Pass.

ALL ACCESS PASSES ARE
VISIBLY NUMBERED

ALL ACCESS PASSES ARE SITE CODED

TELBIP
or TELBIPHF

KCP3
Proximity Key

Rear of
TELBIP/TELBIPHF
or TELBIPHFP

Numbered

The full 5no. digit Site Code is written on the Access Pass Information Sheet supplied by Noralsy®with each
delivery of Access Passes.

*The full 5n

0

digit site code is printed on KBP Proximity Cards.

Holder

Number

Access Passes are always supplied in groups that are
sequentially numbered which simplifies programming because it
enables block loading and block deleting of Access Passes. It
also means that you can quickly and easily determine which
Access Passes are missing and need, therefore, to be deleted
in order to restore the integrity of your system.

KCP3

Proximity Key

Holder

Number

ALL ACCESS PASSES ARE SEQUENTIALLY NUMBERED

The Holder Numbers supplied are also recorded on
the Access Pass Information Sheet.

Rear of
TELBIP/TELBIPHF
or TELBIPHFP

Last 3 digits engraved
refer to Holder Number.

The Holder Numbers supplied are also recorded on
the Access Pass Information Sheet.

Numbered

The first 3no. digits of the 5no. digit Site Code

are always engraved on each Access Pass.

The last 2n

o

. digits are usually the year of

manufacture.

Site Code =

Not 
engraved*

Engraved
on Access Pass

An Access Pass is always part of a unique group referred to as a Site Code and
represented by a 5 digit number. Your purchase of Noralsy

®

Access Passes buys you
that group (Site Code) regardless of how many Access Passes you require. That Site
Code belongs to you and you alone. Noralsy®will never make an Access Pass with
your Site Code for anybody else. That is your security.

KCP3
Proximity Key

Site

Code

Example: First 3 digits engraved on Access
Pass are

494.

Year of manufacture 2001, therefore,
last 2n

0

digits of site code are 01.

4

®

Noralsy ECP Door Controllers

1 2 3

1 2 4 5 631 2 3

1 2 431 2 3

1 2 4 531 2 3

1 2 3

1 2

1 2 3

1 2 43

1 2 4 53

1 2 4 5 63

1 2 4 5 6 73

1 2 4 5 6 7 83

1 2 1 2 4 5 63

Standardisation of Terminal Numbering

Place Noralsy unit on a flat surface with PCB facing skywards.
View terminal blocks from the outside looking in. Terminal No. 1
is always the first on the left of every terminal block strip.

IMPORTANT

–If NOT Monitoring Door Open/Closed Status

ECP Door Controller

ELEC/INST/GEN

ELEC/INST/800

OR

ECP ALARM

BUZZES CONTINUOUSLY

ON

1

654321654321

5

®

ECP190 Door Controller for

1 n

0

Door/Access Point

■ Capacity 999 Users

ELEC/INST/801

Supply 12V DC ± 10%

Dimensions 103 L x 106 W x 83 D (6 DIN units)

Weight 0.44 Kg

Power Consumption 55mA quiescent

CE Norms EN50082, EN55022 Class B

ECP 190 Door Controller

If not used, link terminals 3 & 4 to
create a permanently closed circuit.

321 2 1

(—) (+)

321

1

2

3

4

5

123456

123456

321 21

5

4

3

2

1

1ON

123456

=

=

6

®

ECP290 Door Controller for

2n

0

Doors/Access Points

ANTI-PASSBACK FEATURE AVAILABLE

Supply 12V DC ± 10%

Dimensions 163 L x 106 W x 83 D (10 DIN units)

Weight 0.56 Kg

Power Consumption 160mA quiescent

CE Norms EN50082, EN55022 Class B

ECP 290 Door Controller

■ Capacity 999 Users per door

ELEC/INST/830

* If not used, link terminals 3 & 4 to
create a permanently closed circuit.

7

®

Programming Stand-Alone
Access Control Systems
using TELPRO™ Programmer.

MLP3 Proximity

MIR Infra-Red

MILB Card Reader

LB20 Swipe Card

Access Control Modules, Readers, Receivers without integral Infra-Red

Access Control Modules with integral Infra-Red

The TELPRO™
Programmer is
supplied with a
connector cable.
Simply connect to
ECP Door Controller
to program.

The TELPRO™ Programmer
can be used as a wirefree
infra-red programmer. Simply
point at the reader/receiver
module to program.

TELPRO™

Programmer

TELPRO™

Programmer

If the entrance or door panel includes a MICAM/MICIM Keypad Module connected to the ECP Door Controller, all
programming can be effected directly via the MICAM/MICIM Keypad ie. TELPRO™ Programmer would not be
required. You would also then have the option of having keypad access codes.

LTP03

Office Proximity Reader

Dim:
120L x 60W x 25D

TELPRO™ PROGRAMMER

The TELPRO™ Programmer is a handheld
keypad used for programming Noralsy

®

stand-alone access control systems.

Installation companies only ever need 1no.
TELPRO™ Programmer.

TELPRO™ can be used on any system
provided, of course, the Master Code (also
referred to as the Engineer Code) which
grants access into programming mode is
known or, access to the ECP Door Controller
itself is available.

The final customer only needs a TELPRO™
unit if they wish to effect programming
themselves.

All measurements in millimetres.

LHF

Radio receiver

ECP190
ECP290
ECP100
ECP200

Important:
Each press of a button
is confirmed (as
received) by the
reader/receiver by a
single beep. Press the
TELPRO

™

buttons

gently.

Programming using TELPRO™as a remote
wire-free programmer.

Remote Programming Range:

Infra-Red Receiver 20 cms - 5 metres
Proximity Reader 5 cms - 10 cms

How to use the TELPRO:

Flick TELPRO switch to ON - Red LED on the right must light up.

(Remember to turn unit off when finished)

Point TELPRO at the reader/receiver.

Enter the Master Code and wait for the reader/receiver to start beeping every 4 seconds

OR

Flick Programming Switch SW1 and wait for the reader/receiver to start beeping every 4 seconds

(Remember to turn off the programming switch SW1 when you have finished programming).

Follow programming instructions

Note: An incorrect programming operation is signalled by a series of 3 beeps.

8

Programming using TELPRO™as a
hard-wired programmer

How to use the TELPRO as a hard wired unit:

Insert the jack connection into the top of the TELPRO unit.

Plug the connector terminal onto J5 on ECP Door Controller.

Enter the Master Code and wait for the unit

to start beeping every 4 seconds

OR

Flick Programming Switch SW1 and wait for the unit

to start beeping every 4 seconds

(Remember to turn off the programming switch SW1

when you have finished programming)

Follow programming instructions.

Dimensions (mm):
120L x 60W x 25D

J5 = Access Point 1
J6 = Access Point 2

ECP290/ECP200

Important:
Each press of a button is confirmed (as
received) by the Door Controller by a
single beep.
Press the TELPRO

™

buttons gently.

9

PROGRAMMING

08

Example

Basic configuration,
just do it!

Basic configuration,
just do it!

seconds

ECP Door Controller with
ACCESS PASS CONTROL

TOP POINTS TO REMEMBER

■ Programming is effected via the TELPRO programming keypad.

■ Site Code is always a 5 digit number.

■ Site Code is always stored in Slot No. 01.

■ Master Code (Programming Access Code) is always a 5 digit number.

■ Master Code is always stored in Slot No. 06.

TIP - WHEN YOU ARE PROGRAMMING

It is a good idea to have written down in advance what you want to program. Enter the numbers in quick succession
after a beep. Do not wait more than 2-3 seconds in between entering numbers as this will confuse the system.

SET-UP ON INSTALLATION

Wire up according to appropriate electrical wiring schematic for your installation, then power up the Door Controller.
Flick the

Programming Switch SW1. The unit will start beeping every 4 seconds.

STEP 1

Decide Now -- For how many seconds do you want the door to open:

After a beep enter on the TELPRO:

000005 08

The last 2no. digits, shown as underlined, set the door open time in seconds. You can choose any length between 01 ­99 seconds. For automation control, 01 seconds is usually more than adequate.

A sharp beep confirms that you have correctly entered the above. Programming mode beep - every 4 seconds ­resumes.

STEP 2

After a beep enter on the TELPRO: 02A0

A sharp beep confirms that you have correctly entered the above. Programming mode beep - every 4 seconds ­resumes.

STEP 3

You must now set the Master Code of your choice. This is the code that allows you to access programming mode
without having to open up the Door Controller and flicking switch SW1.

The Master Code is always stored in Slot N

o

. 06.

The Master Code must be a 5 digit number, for example: 19388.

After a beep enter on the TELPRO:

A sharp beep confirms that you have correctly entered the Master Code. Programming mode beep - every 4 seconds ­resumes.

10

*See Tip Wizard
on page 13

*

STEP 4

You must now inform the Door Controller of the Site Code of the Access Passes supplied.

The Site Code is always stored in Slot N

o

. 01.

The Site Code is always a 5 digit number.

Check the Access Pass Information Sheet delivered with the Access Passes. It will tell you the Site Code of the Access
Passes delivered.

Example: Site Code = 45801

After a beep enter on the TELPRO:

A sharp beep confirms that you have correctly entered the Site Code. Programming mode beep - every 4 seconds ­resumes.

*KBP Proximity Cards have the full site code printed on each card.

STEP 5

You must now inform the Door Controller of the Access Pass Holder Numbers supplied.

Check the Access Pass Information Sheet delivered with the Access Passes. It will tell you which Holder Numbers we
have supplied.

Example: 150no. Access Passes Supplied........HOLDER NUMBERS 001-150.

After a beep enter on the TELPRO:

A series of 3n

o

. beeps followed by a sharper beep confirms that you have correctly entered the Holder Numbers.

Programming mode beep - every 4 seconds - resumes.

STEP 6

Turn off programming switch SW1 in the Door Controller. You have successfully programmed the system. The Access
Passes should now all work.

ADVANCED PROGRAMMING

In the following examples of programming we are assuming that the Master Code = 19388. This is purely for
demonstration purposes. When programming for real, you must enter the Master Code that you chose and set when
the system was installed.

Example A: Block Loading/Validation of Access Passes.

You have just received an additional 25no. Access Passes for the system. Holder Numbers 151- 175.

Enter the Master Code 19388 on the TELPRO. Beeps every 4 seconds indicate that you have accessed Programming
Mode.

After a beep enter on the TELPRO:

A series of 3n

o

. beeps followed by a sharper beep confirms that you have correctly entered the Holder Numbers.

Programming mode beep - every 4 seconds - resumes.

Example B: Deletion of 1no. Access Pass

You have just been informed that Alan Jones has lost his Access Pass. Alan was Holder Number 074. You have to
delete it immediately to restore system security. Enter the Master Code 19388 on the TELPRO. Beeps every 4 seconds
indicate that you have accessed Programming Mode.

11

After a beep enter on the TELPRO:

A sharp beep confirms that you have correctly deleted Holder Number 074. Programming mode beep - every 4
seconds - resumes.

Example C: Validation of 1no. Access Pass

You have just received the additional Access Pass ordered for Alan Jones who had lost his earlier in the week. The last
3no. digits on the Access Pass are 176. Alan Jones is now Holder Number 176 and you have to program the system to
accept Holder Number 176.

Enter the Master Code 19388 on the TELPRO. Beeps every 4 seconds indicate that you have accessed Programming
Mode.

After a beep enter on the TELPRO:

A sharp beep confirms that you have correctly programmed new Holder Number 176. Programming mode beep - every
4 seconds - resumes.

Example D: Block Deletion of Access Passes

You have just been informed that a set of 20 Access Passes reserved for visitors and held in reception have been
stolen. You have to immediately delete them to restore system security. The Holder Numbers stolen were 080-099.

Enter the Master Code 19388 on the TELPRO. Beeps every 4 seconds indicate that you have accessed Programming
Mode.

After a beep enter on the TELPRO:

A series of 3n

o

. beeps followed by a sharper beep confirms that you have deleted the Holder Numbers. Programming

mode beep - every 4 seconds - resumes.

Example E: Changing the Relay/Lock Output Time

You have been asked to change the Relay Output Time to 12 seconds.

Enter the current Master Code 19388 on the TELPRO. Beeps every 4 seconds indicate that you have accessed
Programming Mode.

After a beep enter on the TELPRO:

A sharp beep confirms that you have correctly reprogrammed the relay output time for 12 seconds. Programming
mode beep - every 4 seconds - resumes.

Example F: Changing the Master Code

You have been asked to change the Master Code to 11821.

Enter the current Master Code 19388 on the TELPRO. Beeps every 4 seconds indicate that you have accessed
Programming Mode.

After a beep enter on the TELPRO:

A sharp beep confirms that you have correctly entered the new Master Code. Programming mode beep - every 4
seconds - resumes.

12

ECP290 DOOR CONTROLLER FOR 2 DOORS – IMPORTANT
INFORMATION

FLICKING PROGRAMMING SWITCH SW1.

The access control readers on both doors will start to beep every 4 seconds indicating programming mode status. Only
1 n

o

. access point (door) can be programmed at a time.

IF USING THE TELPRO PROGRAMMER IN WIREFREE INFRA-RED MODE:

Simply point at the relevant reader to effect programming for its related access point (door). Repeat the process for the
2nd access control reader on the ECP290. Remember to turn off programming switch SW1 when finished.

IF USING TELPRO PROGRAMMER IN HARDWIRED MODE:

Connect as follows:

J5 for the reader connected to I2A1, Access Point 1.
J6 for the reader connected to I2A2, Access Point 2.

Remember to turn off programming switch SW1 when finished.

Note: Programming mode can, of course, be accessed via entering the Master Code (the code stored in Slot

No. 06)

as explained earlier.

ADDITIONAL FEATURES OF ECP290

Activating one of the additional features offered by the ECP290 is very straightforward and involves a very slight
modification of Step 1 (see page 9) of the Programming Operation.

Remember: The programming operation has to be effected for each access point (door).

00000508 = Standard Set-Up, adequate for the vast majority of installations. If this is sufficient, simply copy the

procedure, as explained on page 9, for both doors.

Mode 2 - Access Pass to Operate Only if Vehicle Present

00200500 = Set-Up, Mode 2

È

Alarm delay time in minutes. A 00 setting disables the alarm function.

When a valid access pass is presented to the reader, the relay output will be activated for 2 seconds

BUT ONLY IF the
Magnetic Induction Loop (M.I.L) contacts, terminals 1 & 2 of J10A1 or J10A2, have closed ie a vehicle is present. If the
M.I.L contacts remain closed for longer than the preset alarm delay time, the access control reader/receiver/keypad will
sound an alarm.

Mode 3 - Access Pass to Operate Only if Door Closed

00300500 = Set-Up, Mode 3

È

Alarm delay time in minutes. A 00 setting disables the alarm function.

The status of the door is controlled by 2no. sets of contacts as follows:

Open Position Reached (OPR) Contacts: Terminals 2 & 3 of J10A1 (Access Point 1)
Door Open Contacts (DO): Terminals 3 & 4 of J9A1 (Access Point 1)

Open Position Reached (OPR) Contacts: Terminals 2 & 3 of J10A2 (Access Point 2)
Door Open Contacts (DO): Terminals 3 & 4 of J9A2 (Access Point 2)

When a valid access pass is presented to the reader, the relay output will be activated for 2 seconds

BUT ONLY IF the
related Access Point (Door) is closed. If the Access Point (Door) remains open for longer than the preset alarm delay
time (DO Contacts OPEN and OPR Contacts CLOSED) or, if the Access Point (Door) is blocked/stuck for longer than
the preset alarm delay time (DO Contacts OPEN and OPR Contacts OPEN), the access control reader/receiver/keypad
will sound an alarm.

13

Mode 4 - Dual Security, Access Pass + Keypad Code

00400508 = Set-Up, Mode 4

È

Relay output time in seconds

User required to present a valid access pass and then enter a valid code or vice versa in order to gain access. A
maximum of 27n

o

.5 digit keypad codes can be set at any one time. Any 1no. of these keypad codes together with a

valid access pass is sufficient to gain entry. This feature is also available on the ECP190 Door Controller.

Mode 5 - Anti-Passback

00500508 = Set-Up, Mode 5

È

Relay output time in seconds (this is an example only).

For Anti-Passback to operate, terminals 3 and 4 of J9A1 and J9A2 must be connected to the
Door Contacts fitted to the controlled doors. This is imperative because the Door Controller
cannot operate Anti-Passback if it does not know whether the door was opened or not.

Basic operation is as follows:

The presentation of a valid Access Pass on Door 1 activates the relevant lock release relay. If Door 1 is opened, this
Access Pass is immediately and automatically barred on Door 1 until it has been presented on Door 2 with Door 2 then
being opened. As soon as this Access Pass is presented on Door 2 with Door 2 being opened, it is immediately and
automatically barred on Door 2 until it has been presented on Door 1 with Door 1 then being opened etc etc.

Tip Wizard

Access Passes can be programmed into the access control system even if
they have not yet been manufactured by Noralsy® . Your customer may have
ordered only 50n

o

. Access Passes and would have had delivered, for
example holders 001-050 on their unique Site Code but, there is nothing to
stop you from block programming all 999 holders. It takes the same
amount of time to program 1no. Access Pass into the system as it does to
program 999 Access Passes! So, future supplies of Access Passes are
already programmed into the system and your customer should only ever
have to delete lost or stolen Access Passes!

It is so easy: B001 B999.

VERY IMPORTANT

Noralsy®Access Passes must not be compared or confused with random Access Passes­for example, certain brands of proximity key - where the onus is on the installation
company to “accurately” identify each Access Pass programmed into the system and
physically mark them so that they can be “sure” who is issued with what or, those
systems, which rely on shadow cards or master keys/fobs for programming purposes.

14

Noralsy® ECP Door Controller

321 2 1321

Fail Safe Locking

ECP190 Door Controller

ECP190 Door Controller

ECP190 Door Controller

Automation Control / Volt Free

Entrance/Exit

Access point requiring access control on both
sides of the door, gate or barrier.
ie. Access Pass to be presented to enter and
again to exit through the same control point.

Note: In this type of installation, programming

can take place via the TELPRO
programmer at either one of the Access
Pass readers/receivers or, alternatively, at
the Door Controller itself.
You only need to program at 1n

o

. point.

* Terminal numbering shown for

reasons of schematic clarity.
Terminal 1 is actually first on left.

ELEC/INST/802

ELEC/INST/803

ELEC/INST/804

®®

+

321

21321

(—) (+)

1 2 4 5 63 6 5 3 2 14

654321 654321

15

Locking

ECP190 Door Controller

Noralsy® ECP Door Controller

DIN Rail Mounting

Wall Mounting

DIN Rail

ELEC/INST/805

ELEC/INST/806

ELEC/INST/807

®®

321

21321

(–) (+)

16

Noralsy® DIN Rail Power Supplies

ELEC/INST/808

ELEC/INST/809

ELEC/INST/810

ELEC/INST/811

ARE121 12V AC/DC
1 AMP MAXIMUM OUTPUT

ARE122 12V DC
2 AMP MAXIMUM OUTPUT

ARS122 12V DC
2 AMP MAXIMUM OUTPUT

AB126 BATTERY STANDBY

®

®

17

®

Noralsy®

Powering ECP Door Controller(s)
using Noralsy® DIN Rail Power
Supply Units

ELEC/INST/812

ARE121 + ECP190

ARE122 + ECP290

ELEC/INST/812A

18

ECP190 DOOR CONTROLLER with
KEYPAD ACCESS CODE CONTROL

TOP POINTS TO REMEMBER

■ Programming is effected directly via the keypad.

■ Master Code (Programming Access Code) is always a 5 digit number.

■ Master Code is always stored in Slot No. 06.

■ Keypad Access Codes are always 5 digit numbers.

■ Keypad Access Codes can be stored in Slot Nos. 03 - 05 and 07 - 30 only.

SET-UP ON INSTALLATION

Proceed exactly as detailed before in section ECP Door Controller with Access Pass Control. Stop when you have
completed Step 3. Then - Turn off programming switch SW1 in the Door Controller.

PROGRAMMING KEYPAD ACCESS CODES

Keypad Access Codes must be 5 digits in length and can only be stored in Slot Numbers 03-05 and 07-30.

Example: You want to program codes: 46296 for Alan

78327 for Tony
32534 for Alex

Enter the Master Code on the keypad:

Beeps every 4 seconds indicate that you have accessed Programming Mode.

After a beep enter on the keypad:

A sharp beep confirms that Alan’s code is recorded. Programming mode beep - every 4 seconds - resumes.

After a beep enter on the keypad:

A sharp beep confirms that Tony’s code is recorded. Programming mode beep - every 4 seconds - resumes.

After a beep enter on the keypad:

A sharp beep confirms that Alex’s code is recorded. Programming mode beep - every 4 seconds - resumes.

Note Carefully:

Never program a keypad access code into Slot Numbers 01, 02 or 06.

DELETING KEYPAD ACCESS CODES

Example: You want to delete Alan’s code 46296 which is stored in Slot No. 03

You want to delete Alex’s code 32534 which is stored in Slot N

o

. 07

Enter the Master Code on the keypad:

Beeps every 4 seconds indicate that you have accessed Programming Mode.

19

After a beep enter on the keypad:

A sharp beep confirms that you have deleted Alan’s code. Programming mode beep - every 4 seconds - resumes.

After a beep enter on the keypad:

A sharp beep confirms that you have deleted Alex’s code. Programming mode beep - every 4 seconds - resumes.

Note 1. You do not need to know the actual code itself which needs to be deleted, only the Slot Number in which it is

stored.

Note 2. Capacity is never reduced as a result of deleting codes. You can always add or change codes.

CHANGING THE MASTER CODE

Refer to page 11.

CHANGING RELAY/LOCK OUTPUT TIME

Refer to page 11.

Automatic Time-Out – whenever programming accessed via Master Code

System automatically reverts to normal mode approximately 20 seconds after the last
programming operation. A single longer sharp beep signals that the system has exited
from programming mode and returned to normal mode.

N.A.C.D. Limited Unit 10, Avebury Court, Mark Road, Hemel Hempstead, Herts HP2 7TA.

TEL: [phone] FAX: [phone] EMAIL: [e-mail] WEB: www.nacd.co.uk

Our policy is one of continuous product improvement, we reserve the right to change specifications and prices without notice. All information is given in good
faith. No responsibility can be accepted for errors, omissions or incorrect assumptions. Picture reproduction of products are within the limitations of both colour
and black and white printing and are intended as a guide only. © Copyright 2001 N.A.C.D.Limited. All rights reserved.

20

Input 85VAC - 264VAC

Output 12V AC/DC - 1AMP

Dimensions 135 L x 106 W x 85 D (8 DIN units)

Weight 1.05 Kg

CE Norms EN50082, EN55022 Class B

ARE121 POWER SUPPLY WITH STAND-BY FACILITY

Input 85VAC - 264VAC

Output 12V DC - 2AMP

Dimensions 160 L x 106 W x 85 D (10 DIN units)

Weight 0.5 Kg

CE Norms EN55022 Class B, EN 60950, UL 94 VO

ARE122 POWER SUPPLY

Input 85VAC - 264VAC

Output 12V DC - 2AMP

Dimensions 160 L x 106 W x 85 D (10 DIN units)

Weight 0.5 Kg

CE Norms EN55022 Class B, EN 60950, UL 94 VO

ARS122 POWER SUPPLY WITH STAND-BY FACILITY

Battery 12V/6A.H.

Output 12V DC - 2AMP

Dimensions 162 L x 106 W x 112 D (10 DIN units)

Weight 3.0 Kg

CE Norms VDS, IEC 1056

AB126 BATTERY STANDBY

Supply 12V DC ±10%

Dimensions 103 L x 106 W x 83 D (6 DIN units)

Weight 0.44 Kg

Power Consumption 55mA quiescent

CE Norms EN50082, EN55022 Class B

ECP 190 DOOR CONTROLLER

ACCESS CONTROL MODULES

REFERENCE DESCRIPTION POWER CONSUMPTION

MIR Infra-Red Receiver 25mA quiescent

MILB Card Reader Insert 47mA quiescent

LB20 Card Reader Swipe 30mA quiescent

MICAM/MICIM Keypad 50mA quiescent

MLP3 Proximity Reader 120mA quiescent

LHF Radio Receiver 25mA quiescent

LPT03 Proximity Reader (office) 120mA quiescent

Supply 12V DC ± 10%

Dimensions 163 L x 106 W x 83 D (10 DIN units)

Weight 0.56 Kg

Power Consumption 160mA quiescent

CE Norms EN50082, EN55022 Class B

ECP 290 DOOR CONTROLLER
